AES - EXTREME 1325, ... Nested Based CNC Router with Boring & ATC.Description:4' x 8' Single-Zone Stationary Aluminum Grid "MATRIX" Table with Traveling "Bridge Gantry"Specifications: -- Working Field: X-Axis is 98.4" (2,500 mm); Y-axis is 51.2" (1,300 mm); Z-axis stroke is 7.8" (200 mm); max. material thickness 5.1" (130 mm).Square grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining". -- Positioning Speed: X- & Y-Axis at 2,365 IPM (60 MPM), Z-axis at 780 IPM (20 MPM).YASKAWA Brushless, high torque AC Servo motor drives control on all axes.High precision "Rack & Pinion" system in X- & Y-axis & ground ball screw Z-axis.All components ride on THK precision profile linear guide ways. -- Boring Unit: HSD" Drilling Head, 3 HP (2.2 kW), variable speed from 4,500 - 8,000 RPM motor.(10) Independent vertical spindles on 32 mm centers; (6) spindles in X-axis & (4) spindles in Y-axis.(6) Horizontal spindles with (2 + 2) in X-axis & (1 + 1) in Y-axis.(1) X-Axis grooving saw for max. 120 mm dia blade, variable speed from 5,500 - 10,000 RPM. -- Spindle and ATC: 12 HP (9 kW) HSD Air cooled electro spindle motor with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 12-Position ATC rotary tool magazine located at the back of the gantry and traveling with the X-axis. -- Operator & Machine Control: OSAI Open Industrial PC control with: Windows "7" operating system; 17" high resolution LCD flat-screen; ergonomic keypad; compatible with all CAD/CAM software in the market.Program & Data transfer via USB ports or downloading by wire is possible via serial port connections for RS-232, RS-242 & Ethernet adaptor;.OSAI Control offers incredible list of functions from (a) auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- CAD/CAM Software: ALPHACAM "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving and is Upgradable to full 5-Axis so it can grow with your business.ALPHACAM - As easy as you need it to be and as powerful as you want it to be. -- Features: ● (1) BECKER 250 cbm/Hr Vacuum Pump ● Hand-Held Remote Control Pendant. ● Automatic Tool Offset Unit ● Automatic Lubrication Unit to 19 Central Lubrication Points ● Pneumatic Part Location Referencing Pop-up Pins -- Safety System: Safety enclosure around the spindle carriage; photocell safety sensors & perimeter fencing; machine prewired to accept safety mats. -- Supplied with: Comprehensive technical documentation & manuals and covered by 1-Year Parts & 6-Month labor warranty. -- Available Options: ● NC Controlled C-Axis for 360° operation. ● Workpiece Outfeed Pusher (Rake). ● Offloading Conveyor Belt Outfeed Table.NOTE: EX-FACTO
Equipment Location:MIDWEST, AL
EX-FACTORY INC.
704-841-2001
|
|
AES - EXTREME 1632, ... Nested Base CNC Router with Boring & ATC: Description:5' x 10' Single-Zone Stationary Aluminum Grid "MATRIX" Table with Traveling "Bridge Gantry", Boring Head and ATCSpecifications: -- Working Field: X-Axis is 126" (3,200 mm); Y-axis is 63" (1,600 mm); Z-axis stroke is 7.8" (200 mm); max. material thickness of 5.1" (130 mm).Square grid pattern allows the use of vacuum pods or closed cell rope gasketing material with spoil boards for "nested base machining". -- Positioning Speed: X- & Y-Axis 2,365 IPM (60 MPM), Z-axis at 780 IPM (20 MPM).YASKAWA Brushless, high torque AC Servo motor drives control on all axes.High precision "Rack & Pinion" system in X- & Y-axis & ground ball screw Z-axis.All components ride on THK precision profile linear guide ways. -- Boring unit w/Saw: HSD Drilling Head, 3 HP (2.2 kW), variable speed from 4,500 - 8,000 RPM motor. (10) Independent vertical spindles on 32 mm centers, (6) spindles in X-axis & (4) spindles in Y-axis.(6) Horizontal spindles with (2 + 2) in X-axis & (1 + 1) in Y-axis.(1) X-Axis grooving saw for max. 120 mm dia blade, variable speed from 5,500 - 10,000 RPM. -- Spindle and ATC: (1) 12 HP (9 kW) HSD Air cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 12-Position ATC rotary tool magazine located at the back of the gantry and traveling with the X-Axis. -- Operator & Machine Control: OSAI Industrial PC Front-End with: Windows "7" operating system; 17" high resolution LCD flat-screen; ergonomic keypad; compatible with most CAD/CAM software in the market.Program & Data transfer via USB ports or downloading by wire is possible via serial port connections for RS-232, RS-242 & Ethernet adaptor. OSAI Control offers incredible list of functions from (a) auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- CAD/CAM Software: ALPHACAM "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving and is Upgradable to full 5-Axis so it can grow with your business.ALPHACAM - As easy as you need it to be and as powerful as you want it to be. -- Features: ● (1) BECKER 250 cbm/Hr Vacuum Pump ● Handheld Remote Control Pendant ● Automatic Lubrication System to 19 Central Points ● Automatic Tool Offset Unit ● Pneumatic Part Location Referencing Pop-up Pins -- Safety System: Full safety enclosure around the spindle carriage, photocell safety sensors with perimeter fencing, machine prewired to accept safety mats. -- Supplied with: Comprehensive technical documentation & manuals and covered by 1-Year Parts & 6-Month labor warranty. --Available Options: ● NC Controlled C-Axis for 360° operation. ● Workpiece Outfeed Pusher (Rake). ● Offloading Conveyor Belt Outfeed TableNO
Equipment Location:MIDWEST, AL
EX-FACTORY INC.
704-841-2001
|
|
AES - EXTREME 1640, ...Nested Base CNC Router with Boring & ATC:Description:5' x 12' Single-Zone Stationary Aluminum Grid "MATRIX" Table with Traveling "Bridge Gantry"Specifications: -- Working Field: X-Axis is 157" (3,200 mm); Y-axis is 63" (1,600 mm); Z-axis stroke is 7.8" (200 mm); max. material thickness of 5.1" (130 mm).Square grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining". -- Positioning Speed: X- & Y-Axis at 2,365 IPM (60 MPM), Z-axis at 780 IPM (20 MPM).YASKAWA Brushless, high torque AC Servo motor drives control on all axes.High precision "Rack & Pinion" system in X- & Y-axis & ground ball screw Z-axis. All components ride on THK precision profile linear guideways. -- Boring unit: HSD Drilling Head, 3 HP (2.2 kW), variable speed from 4,500 - 8,000 RPM motor. (10) Independent vertical spindles on 32 mm centers; (6) spindles in X-axis & (4) spindles in Y-axis.(6) Horizontal spindles with (2 + 2) in X-axis & (1 + 1) in Y-axis.(1) X-Axis grooving saw for max. 120 mm dia blade, variable speed from 5,500 - 10,000 RPM. -- Spindle and ATC: 12 HP (9 kW) HSD Air cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 12-Position ATC rotary tool magazine located at the back of the gantry and traveling with the X-Axis. -- Operator & Machine Control:OSAI Industrial PC Front-End with: Windows "7" operating system; 17" high resolution LCD flat-screen; ergonomic keypad; compatible with most CAD/CAM software in the market.Program & Data transfer via USB ports or downloading by wire is possible via serial port connections for RS-232, RS-242 & Ethernet adaptor. OSAI Control offers incredible list of functions from (a) auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- CAD/CAM Software: ALPHACAM "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving and is Upgradable to full 5-Axis so it can grow with your business.ALPHACAM - As easy as you need it to be and as powerful as you want it to be. -- Features: ● (1) BECKER 250 cbm/Hr Vacuum Pump ● Handheld Remote Control Pendant ● Automatic Lubrication System to 19 Central Points ● Automatic Tool Offset Unit ● Pneumatic Part Location Referencing Pop-up Pins -- Safety System: Full safety enclosure around the spindle carriage, photocell safety sensors with perimeter fencing, machine prewired to accept safety mats. -- Supplied with: Comprehensive technical documentation & manuals and covered by 1-Year Part & 6-Month labor warranty. --Available Options: ● NC Controlled C-Axis. ● Workpiece Outfeed Pusher (Rake). ● Offloading Conveyor Belt Outfeed Table NOTE: EX-FACTORY has a similar AES Nesting Syste
Equipment Location:MIDWEST
Norm Schust
800-374-5009 ext:445
|
|
AES - EXTREME LINE 1325, ...Nested Base CNC Router with Loading and Unloading System:Description:4' x 8' Single-zone Stationary Aluminum Grid "MATRIX" table with Traveling "Bridge Gantry", Boring Head, ATC, and Auto Loading & Unloading SystemSpecifications: -- Working Field: X-Axis is 98.4" (2,500 mm); Y-axis is 51" (1,300 mm); Z-axis stroke is 7.8" (200 mm); max. material thickness of 5.1" (130 mm).Square grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining". -- Positioning Speed: X- & Y-Axis 2,365 IPM (60 MPM), Z-axis at 780 IPM (20 MPM).YASKAWA Brushless, high torque AC Servo motor drives control on all axes.High precision "Rack & Pinion" system in X- & Y-axis & ground ball screw Z-axis.All components ride on THK precision profile linear guideways. -- Boring Unit: HSD" Drilling Head, 3 HP (2.2 kW), variable speed from 4,500 - 8,000 RPM motor. (10) Independent vertical spindles on 32 mm centers, (6) spindles in X-axis & (4) spindles in Y-axis.(6) Horizontal spindles with (2 + 2) in X-axis & (1 + 1) in Y-axis.(1) X-Axis grooving saw for max. 120 mm dia blade, variable speed from 5,500 - 10,000 RPM. -- Machining: 12 HP (9 kW) HSD Air cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 12-Position ATC rotary tool magazine located at the back of the gantry and traveling with the X-Axis. -- Operator & Machine Control: OSAI Industrial PC Front-End with: Windows "7" operating system; 17" high resolution LCD flat-screen; ergonomic keypad; compatible with most CAD/CAM software in the market.Program & Data transfer via USB ports or downloading by wire is possible via serial port connections for RS-232, RS-242 & Ethernet adaptor. OSAI Control offers incredible list of functions from (a) auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- CAD/CAM Software: ALPHACAM "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving and is Upgradable to full 5-Axis so it can grow with your business.ALPHACAM - As easy as you need it to be and as powerful as you want it to be. --System Includes: ● (1) Lifting Table with Automatic Indexing: Panel stack specifications: Max. panel stack height is 700 mm (27.55"), Max. panel stack weight is 4,000 kG (8,800 Lbs),Max. panel stack misalignment for X-Axis is 30 mm (1.18") & Y-Axis is 5 mm (0.19").The panel stack automatically indexes to the machine worktable height, allowing the loading unit suction cups to grip the top panel. ● (1) Workpiece Loading Unit with Suction Cups:Vacuum device with row of suction cups mounted on backside of gantry bridge grip the upper panel of the stack and move it up to the machine table support stops.Max. weight o
Equipment Location:MIDWEST
Norm Schust
800-374-5009 ext:445
|
|
AES - EXTREME LINE 1632, ... Nested Base CNC Router with Loading & Unloading System:Description: 5' X 10' Single-zone Stationary Aluminum Grid "MATRIX" table with Traveling "Bridge Gantry", Boring Head, ATC, and Auto Loading & Unloading SystemSpecifications: -- Working Field: X-Axis is 125.98" (3,000 mm); Y-axis is 62.99" (1,300 mm); Z-axis stroke is 7.8" (200 mm); max. material thickness 5.1" (130 mm).Square grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining". -- Positioning Speed: X- & Y-Axis 2,365 IPM (60 MPM), Z-axis at 780 IPM (20 MPM).YASKAWA Brushless, high torque AC Servo motor drives control on all axes.High precision "Rack & Pinion" system in X- & Y-axis & ground ball screw Z-axis.All components ride on THK precision profile linear guideways. -- Boring unit: HSD Drilling Head, 3 HP (2.2 kW), variable speed from 4,500 - 8,000 RPM motor.(10) Independent vertical spindles on 32 mm centers, (7) spindles in X-axis & (3) spindles in Y-axis. -- Spindle and ATC: 12 HP (9 kW) HSD Air cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 12-Position ATC rotary tool magazine located at the back of the gantry and traveling with the X-Axis. -- Operator & Machine Control: OSAI Industrial PC Front-End with: Windows "7" operating system; 17" high resolution LCD flat-screen; ergonomic keypad; compatible with most CAD/CAM software in the market.Program & Data transfer via USB ports or downloading by wire is possible via serial port connections for RS-232, RS-242 & Ethernet adaptor; OSAI Control offers incredible list of functions from (a) auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- CAD/CAM Software: ALPHACAM "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving and is Upgradable to full 5-Axis so it can grow with your business.ALPHACAM - As easy as you need it to be and as powerful as you want it to be. --System Includes: ● (1) Automatically Indexing Lifting Table - Panel stack specifications: Max. panel stack height is 700 mm (27.55"), max. panel stack weight is 4,000 kG (8,800 Lbs), max. panel stack misalignment for X-axis is 30 mm (1.18") & Y-axis is 5 mm (0.19").The panel stack indexes up to the machine worktable height, allowing the suction cups to grip the top panel. ● (1) Workpiece Loading Unit with Suction Cups - Vacuum device with row of suction cups mounted on backside of gantry bridge grip the upper panel of the stack and move it up to the machine table support stops.Max. weight of single workpiece to be loaded is 200 kG (440 Lbs), max. panel thickness is 30 mm (1.18"), min. panel thickness is 10 mm (0.39"), min. workpiece to be loaded 900 x 1,600 mm (35" x
Equipment Location:MIDWEST, AL
EX-FACTORY INC.
704-841-2001
|
|
AES - EXTREME LINE 1640, ...Nested Base CNC Router with Loading & Unloading System.Description:5' x 12' Single-zone Stationary Aluminum Grid "MATRIX" table with Traveling "Bridge Gantry", Boring Head, ATC, and Auto Loading & Unloading SystemSpecifications: -- Working Field: X-Axis is 157.48" (4,000mm); Y-axis is 63" (1,600 mm); Z-axis stroke is 7.87" (200 mm); max. material thickness 5.1" (130 mm).Square grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining". -- Positioning Speed: X- & Y-Axis 2,365 IPM (60 MPM), Z-axis at 780 IPM (20 MPM).YASKAWA Brushless, high torque AC Servo motor drives control on all axes.High precision "Rack & Pinion" system in X- & Y-axis & ground ball screw Z-axis.All components ride on THK precision profile linear guideways. -- Boring unit: HSD Drilling Head, 3 HP (2.2 kW), variable speed 4,500 - 8,000 RPM motor. (10) Independent vertical spindles on 32 mm centers, (6) spindles in X-axis & (4) spindles in Y-axis.(6) Horizontal spindles with (2 + 2) in X-axis & (1 + 1) in Y-axis.(1) X-Axis grooving saw for max. 120 mm dia blade, variable speed from 5,500 - 10,000 RPM. -- Spindle and ATC: 12 HP (9 kW) HSD Air cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 12-Position ATC rotary tool magazine located at the back of the gantry and traveling with the X-Axis. -- Operator & Machine Control: OSAI Industrial PC Front-End with Windows "7" operating system; 17" high resolution LCD flat-screen; ergonomic keypad; compatible with most CAD/CAM software in the market.Program & Data transfer via USB ports or downloading by wire is possible via serial port connections for RS-232, RS-242 & Ethernet adaptor. OSAI Control offers incredible list of functions from (a) auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- CAD/CAM Software: ALPHACAM "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving and is Upgradable to full 5-Axis so it can grow with your business.ALPHACAM - As easy as you need it to be and as powerful as you want it to be. --System Includes: ● (1) Automatically Indexing Lifting Table - Panel Stack Specifications: Max. panel stack height is 700 mm (27.55"), max. panel stack weight is 4,000 kG (8,800 Lbs), max. panel stack misalignment for X-axis is 30 mm (1.18") & Y-axis is 5 mm (0.19").The panel stack indexes up to the machine worktable height, allowing the suction cups to grip the top panel. ● (1) Workpiece Loading Unit with Suction Cups - Vacuum device with row of suction cups mounted on backside of gantry bridge grip the upper panel of the stack and move it up to the machine table support stops.Max. weight of single workpiece to be loaded
Equipment Location:MIDWEST, AL
EX-FACTORY INC.
704-841-2001
|
|
AES - FLEXA 1632, ...5' x 10' Nested Base 3-Axis CNC Router with Manual Tool Change. Description:5' x 10' (3,200 x 1,600 mm) Single-Zone Stationary Phenolic Grid "Matrix" Table with travelling "Bridge Gantry".Specifications: -- Working Field: X-Axis is 126" (3,200 mm), Y-Axis is 63" (1,600 mm), and Z-Axis Stroke is 12" (300 mm).Square grid pattern allows the use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining". -- Positioning Speed: Y-Axis at 60 MPM (197 FPM), X-axis at 60 MPM (197 FPM), Z-axis at 20 MPM (65 FPM).YASKAWA Brushless, high torque AC Servo Motor drive control on all axes.High Precision "Rack & Pinion" system in X- & Y-axis with a precision ground ball screw on the Z-axis.All components ride on THK profile linear guide ways. -- HSD Spindle: 7 HP (5.5 kW) HSK F63 Air cooled electro spindle with variable spindles speeds from 1,500 to 18,000 RPM; Manual Tool Change. -- Operator & Machine Control: CNC Control by Osai ISAAC Open controller with a 32-Axis Servo control capacity, single Spindle-control, Remote I/O with additional 256 input/output; Windows Based Operating System.15.6” TFT Colored LCD screen running WINDOWS "8", Integrated Ethernet, Pulse or Servo control voltage, with quick setup feature; Automatic corner slowdown function (G09). -- CAD/CAM Software: ALPHACAM - "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving.ALPHACAM - As easy as you need it to be and as powerful as you want it to be. -- Equipped with & Features: ● (1) BECKER Vacuum pump 140 cbm/Hr wired through the machine so no disconnect needed. ● (1) 220 V - 380 Volt transformer. ● Handheld MPG (Manual Pulse Generator) and ● Safety Light Barriers. ● Pneumatic pop up reference pins mounted within the table perimeter. -- Supplied with: Comprehensive technical documentation & manuals and covered by a 12-month Factory Warranty. NOTE: EX-FACTORY has a similar AES machine under power & available for inspection & demonstration at our Zeeland, MI Showroom!
Equipment Location:MIDWEST, AL
EX-FACTORY INC.
704-841-2001
|
|
AES - Nova 1325, ...4' x 8' Nested Base CNC Router with ATC & Boring:Description:4' x 8' Single-Zone Stationary Phenolic Grid "Matrix" Table with Dual Driven Traveling "Bridge Gantry".Specifications: -- Working Field: X-Axis is 98" (2,500 mm); Y-Axis is 51" (1,300 mm); Z-Axis stroke is 8" (300 mm) Square grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining". --Positioning Speed: X-Axis at 60 MPM (197 FPM), Y-Axis at 60 MPM (197 FPM), Z-Axis Speed 20 MPM (65 FPM), Z-Axis Stroke 200 mm (8").Yaskawa Brushless, high torque AC Servo motor drive control on all axes.High Precision "Rack & Pinion" system on X- & Y-axis with a ground ball screw on Z-Axis.All components ride on THK precision linear guide ways. -- HSD Boring Unit: 2.2 HP (1.7 kW) Drilling Head; Tool connections 10 mm collet, (9) Independent Vertical Spindles on 32mm centers, (5) X-Axis, and (5) on Y-Axis, maximum drill spindle speed 6,000 RPM. -- Spindle & ATC: 12 HP 9 kW HSD Air cooled electro spindle with HSK F63 adapter, variable spindles speeds from 1,500 to 24,000 RPM(1) 8-position Automatic Linear Tool Changer Rack. -- Operator & Machine Control: OSAI Open Industrial PC control with: Windows "8" operating system, 15.6” TFT colored LCD screen; ergonomic keypad; compatible with all CAD/CAM software on the market Program & Data transfer via USB ports or downloading by wire is made possible via serial port connections for RS-232, RS-242 & Ethernet adaptor.OSAI Control offers an incredible list of functions from (a) auto- diagnostics to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to due to active tool wear using space-and-time criteria. -- CAD/CAM Software: ALPHACAM "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving and is Upgradable to full 5-Axis so it can grow with your business. ALPHACAM - As easy as you need it to be and as powerful as you want it to be. -- Features: ● (1) BECKER 250 cbm/Hr Vacuum Pump ● Hand-Held Remote Control Pendant ● Automatic Tool Offset Unit ● Manual Lubrication Unit to 19 Central Lubrication Points ● Pneumatic Part Location Referencing Pop-up Pins -- Safety System: Safety enclosure around the spindle carriage; photocell safety sensors & perimeter fencing. -- Supplied with: Comprehensive technical documentation & manuals and covered by a 1 - year Parts and 6 - month Labor factory warrantyNOTE: EX-FACTORY has this AES machine under power & available for inspection at their Zeeland, MI Showroom!
Equipment Location:MIDWEST
Norm Schust
800-374-5009 ext:445
|
|
ANDI STRATOS CNC Router 4' X 8' with Automatic Tool Changer:48" x 96" Vacuum table w/Phenolic resin top; axis stroke: X-axis is 110", Y-axis is 51" and Z-axis is 8"; fixed table - moving gantry. -- Equipped with: (1) 10 HP Router with oil mist lubrication, infinitely variable 1,000 - 18,000 RPM spindle speed, controlled by 13 KVA inverter. 8-Position carousel type automatic tool changer with "ISO-30" tool holders. -- Axes Travel & Speed:All axes move on profile way bearing systems and are driven by precision ball screws with anti-backlash ball nuts with rapid feed-rates up to 900 IPM on the X- & Y-axis, 236 IPM on Z-axis. -- Operator & Machine Control: FANUC "OM" CNC Controller with: 9" CRT Screen w/graphic display; RS-232 interface in separate free-standing control console. -- Controller features:Linear, circular & helical interpolation; automatic acceleration & deceleration; absolute & incremental programming. Feed rate, and spindle speed manual override. -- Complete with:(1) BECKER 10 HP Vacuum Pump assorted tool holders and manuals.
Equipment Location:MID ATLANTIC
Norm Schust
800-374-5009 ext:445
|
|
AES - NOVA 1632, ...5' x 10' Nested Base CNC Router with ATC & Boring. Description:5’ x 10' Single-Zone Stationary Phenolic Grid "Matrix" Table with Dual Driven Traveling "Bridge Gantry".Specifications: -- Working Field: X-Axis is 126" (3,200 mm), Y-Axis is 63" (1,600 mm), and Z-Axis Stroke is 12" (300 mm).Square grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining". --Positioning Speed: X-Axis at 60 MPM (197 FPM), Y-Axis at 60 MPM (197 FPM), Z-Axis Speed 20 MPM (65 FPM), Z-Axis Stroke 200 mm (8").Yaskawa Brushless, high torque AC Servo motor drive control on all axes.High Precision "Rack & Pinion" system on X- & Y-axis with a ground ball screw on Z-Axis.All components ride on THK precision linear guide ways. -- HSD Boring Unit: 2.2 HP (1.7 kW) Drilling Head; Tool connections 10 mm collet; (9) Independent Vertical Spindles on 32mm centers, (5) X-Axis, and (5) on Y-Axis; maximum vertical spindle speed 6,000 RPM. -- Spindle & ATC: 12 HP (9 kW) HSD Air cooled electro spindle with HSK F63 adapter, variable spindles speeds from 1,500 to 24,000 RPM(1) 8-position Automatic Linear Tool Changer Rack. -- Operator & Machine Control: OSAI Open Industrial PC control with: Windows "8" operating system, 15.6” TFT colored LCD screen; ergonomic keypad; compatible with all CAD/CAM software on the market Program & Data transfer via USB ports or downloading by wire is made possible via serial port connections for RS-232, RS-242 & Ethernet adaptor.OSAI Control offers an incredible list of functions from (a) auto- diagnostics to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to due to active tool wear using space-and-time criteria. -- CAD/CAM Software: ALPHACAM "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving and is Upgradable to full 5-Axis so it can grow with your business.ALPHACAM - As easy as you need it to be and as powerful as you want it to be. -- Features: ● (1) BECKER 250 cbm/Hr Vacuum Pump ● Hand-Held Remote Control Pendant ● Automatic Tool Offset Unit ● Manual Lubrication Unit to 19 Central Lubrication Points ● Pneumatic Part Location Referencing Pop-up Pins -- Safety System: Safety enclosure around the spindle carriage; photocell safety sensors & perimeter fencing. -- Supplied with: Comprehensive technical documentation & manuals and covered by a 1 - year Parts and 6 - month Labor factory warrantyNOTE: EX-FACTORY has this AES machine under power & available for inspection at their Zeeland, MI Showroom!
Equipment Location:MIDWEST
Norm Schust
800-374-5009 ext:445
|
|
AES - NOVA 1640, ...5' x 12' Nested Base CNC Router with Boring & ATC.Description:5' x 12' Single-Zone Stationary Phenolic Grid "Matrix" Table with Dual Driven Traveling "Bridge Gantry".Specifications: -- Working Field: X-Axis is 157.48" (4,000 mm) Y-Axis is 62.99" (1,600 mm) Z-Axis Stroke is 7.87" (200 mm).Square grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining". -- Positioning Speed: X-Axis at 60 MPM (197 FPM), Y-Axis at 60 MPM (197 FPM), Z-Axis Speed 20 MPM (65 FPM), Z-Axis Stroke 200 mm (8").Yaskawa Brushless, high torque AC Servo motor drive control on all axes.High Precision "Rack & Pinion" system on X- & Y-axis with a ground ball screw on Z-Axis.All components ride on THK precision linear guide ways. -- HSD Boring Unit: 2.2 HP (1.7 kW) Drilling Head; Tool connections 10 mm collet, (9) Independent Vertical Spindles on 32mm centers, (5) X-Axis, and (5) on Y-Axis; maximum drill spindle speed 6,000 RPM. - . -- Spindle & ATC: 12 HP (9 kW) HSD Air cooled electro spindle with HSK F63 adapter, variable spindles speeds from 1,500 to 24,000 RPM(1) 8-position Automatic Linear Tool Changer Rack. -- Operator & Machine Control: OSAI Open Industrial PC control with: Windows "8" operating system, 15.6” TFT colored LCD screen; ergonomic keypad; compatible with all CAD/CAM software on the market Program & Data transfer via USB ports or downloading by wire is made possible via serial port connections for RS-232, RS-242 & Ethernet adaptor.OSAI Control offers an incredible list of functions from (a) auto- diagnostics to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to due to active tool wear using space-and-time criteria. -- CAD/CAM Software: ALPHACAM "Essential" 2D CAD/CAM package, the most efficient and widely used CAD/CAM software in the woodworking industry, is included with machine. This package includes 3D Engraving and is Upgradable to full 5-Axis so it can grow with your business.ALPHACAM - As easy as you need it to be and as powerful as you want it to be. -- Features:● (1) BECKER 250 cbm/Hr Vacuum Pump● Hand-Held Remote Control Pendant● Automatic Tool Offset Unit● Manual Lubrication Unit to 19 Central Lubrication Points● Pneumatic Part Location Referencing Pop-up Pins -- Safety System: Safety enclosure around the spindle carriage; photocell safety sensors & perimeter fencing. -- Supplied with: Comprehensive technical documentation & manuals and covered by a 1 - year Parts and 6 - month Labor factory warrantyNOTE: EX-FACTORY has a similar AES machine under power & available for inspection at their Zeeland, MI Showroom!
Equipment Location:MIDWEST
Norm Schust
800-374-5009 ext:445
|
|
ANDI SELEXX Series "BDT" with ATC and Boring; only 285 hours!4' x 8' Fixed table, moving gantry machine with a single-zone vacuum table. -- Equipped with:(1) 7.5 HP ISO-30 Type ATC spindle, air cooled, ceramic bearings, variable spindle speed from 1,000 - 18,000 RPM; 6-station automatic tool changer and 2 HP 6-spindle vertical drill bank (6 in Y-axis). -- Axis stroke:1,800 mm in X, 2,880 mm in Y, and 200 mm in Z-axis. -- Max. feed rate:50 MPM (1,950 IPM) in X & Y, 10 MPM (328 IPM) in Z-axIs. Equipped with & Features: -- Tool Length Measuring System (Tool Touch-off device). -- SYNTECH controller with network compatible WINDOWS PC based front-end, color monitor, keyboard, mouse. -- Full function hand held pendant, absolute & incremental programming, cutter & tool length compensation, feed rate & spindle speed override, inch/metric operation, and linear/circular & helical interpolation. Complete with: -- 10 HP BECKER Vacuum Pump. Tool holders collets and Light safety fences. -- Maintenance supplies (grease, grease guns), and full manuals & product literature.
Equipment Location:SOUTHEAST
Norm Schust
800-374-5009 ext:445
|
|
ANDI STRATOS PRO 5 X 12 with ATC & Boring only 781 Hours:5' x 12' Moving gantry, stationary table design in a front-to-back configuration with a double-zone phenolic vacuum plenum; (11) pop-up pins for part location within the table & (3) around the table perimeter for nested base manufacturing. -- Equipped with: (1) 15 HP HSK-63F Type grease lubricated spindle, variable speed from 1,000 - 24,000 RPM, ATC with 10-station tool carousel. - (1) 16-Spindle L-shape vertical drill block with (4) horizontal for X- & Y-axis; 15 HP is achieved at 15,000 RPM. -- All axes: powered by FANUC brushless AC Servo motors. The X-axis is driven by twin synchronous helical rack & pinion drive, and the Y- & Z-axis by precision ground ball screws with anti-lash ball nuts. All axes ride on STAR linear guides & recirculating linear roller bearing's for rapid feed rates up to 3,150 IPM on the X-axis, 2,362 IPM on the Y-axis and 1,181 IPM on Z-axis. -- Motion components:Are serviced by an automatic lubrication system. Router spindle features an automatic damper dust collection shroud. -- Control:ANDI - FANUC "0i" CNC PC front system with PC WINDOWS XP & PLC control; color monitor, large hard disk for program storage, USB and RS-232 interface. -- Features:Linear, circular & helical interpolation, automatic acceleration & deceleration, fast corner function, hand held teach pendant, absolute & incremental programming, feed rate and spindle speed manual override. -- Includes:(1) 25 HP "BECKER" Vacuum pump, assortment of HSK-63 tool holders, assorted collets, and documentation.
Equipment Location:PACIFIC NORTHWEST
Norm Schust
800-374-5009 ext:445
|
|
ANDI STRATOS SUP 5 X 10 CNC Router with ATC & Boring with only (473) hours:61" x 120" Vacuum table w/Phenolic resin top; axis stroke: X-axis is 120", Y-axis is 61" and Z-axis is 8"; fixed table - moving gantry. -- Equipped with:(1) 10 HP Router with oil mist lubrication, infinitely variable 1,000 - 18,000 RPM spindle speed, controlled by 13 KVA inverter; 8-position carousel type automatic tool changer with "ISO-30" tool holders. -- Boring unit:(1) (11) spindle boaring block with (9) vertical and (2) horizontal. -- All axes:Move on profile way bearing systems and are driven by precision ball screws with anti-backlash ball nuts for rapid feed-rates up to 945 IPM on the X- & Y-axis, 236 IPM on Z-axis. -- Control:FANUC "21i-mb" CNC Controller with: 9" CRT Screen display, RS-232 interface in separate free-standing control console. -- Controller features:Linear, circular & helical interpolation; automatic acceleration & deceleration, absolute & incremental programming, feed rate override. -- Complete with:Assorted tool holders and original documentation. Note: There is no vacuum pump included.
Equipment Location:MIDWEST
Norm Schust
800-374-5009 ext:445
|
|
AXIOM - AC-510, ...Flat Table CNC Router with Tool Changer.5' x 10' Flat Table CNC Router, great for "Nested Base Manufacturing" or just about any type of 3-Axis work.Machine Bed/Base: -- The "Stacked Design" welded structurally engineered machine base provides a solid foundation for superior cut quality; the entire frame is stress relieved and heat treated. -- The Moving Gantry Bridge travels on "HIWIN" 1.2" (30 mm) thick hardened & precision ground rectangle linear guide slider-ways giving extra smooth movement for high speed traverse and accurate cutting. -- Tool Gantry Movement by 1" (25 mm) thick inclined teeth rack & pinion; bridge movement and vertical Z axis travels on a 1" (25.4 mm) dia. precision ball screw for smooth consistent movement.CNC Control & Operator Interface: -- Industrial Grade "OSAI 10/510i" TURNKEY PC based CNC control with: 19" Color monitor; includes self-diagnosis & alarm history display & background editing; up to (5) simultaneously controlled axes with 3D simulation, helical interpolation, tool offset, length compensation & backlash compensation 2 USB ports. -- Compatible with virtually all CAD/CAM programming software on the market. - You choose the software that best suits your needs.Required Utilities: -- Machine weighs approx. 8,100 Lbs, air consumption at 90 PSI is 15 CFM; machine power supply is wired for 220 Volts, 60 Cy, 3-Phase. -- Axes Travel range & feed speed: X-Axis is 65" (1,650 mm), Y-axis 125" (3,175 mm) and Z-axis is 10" (254 mm). -- Working Table: 61" (1,550 mm) x 122" (3,100 mm). There are (3) pop-up stops to aid in panel positioning & "M-code" controlled 2-zone electro valve; special high flow vacuum table system. -- X- & Y-Axis speeds are 1,850 IPM (154 FPM / 46 MPM) and Z-axis is 1,400 IPM (117 FPM / 35 MPM) for quick traverse positioning that reduces total CNC machining time between cutting cycles. -- "YASKAWA" Servo drives power the axes movement.Routing & Machining: -- (1) 12 HP (8.8 kW) Air cooled "HSD" Router spindle with: ISO 30 Adaptor, variable programming speeds from 1,000 to 24,000 RPM, tools are loaded into the "HSD" spindle by (1) 8-position, aluminum plate "on the fly" ride along carousel ATC (automatic tool changer), machine requires ER-32 tool collets.Complete with & Includes: -- 20 HP (15 kW) "ROOTS" type Vacuum Blower. Because there is minimal friction between moving parts, the ROOTS Blower allows high speed rotation giving high flow rates great for full sheet work; dust hood with 6" manifold connection; (8) ISO 30 tool holders; safety bumper system on both sides of the moving bridge & safety bars around the back of the machine.With 8,000 Lbs the AXIOM "AC-510" is one of the heaviest CNC Routers in its class and with a world class OSAI "10/510" Industrial Controller!Option Notes: -- If you require a transformer to 440 Volts, please add ...$ 1,250. - If you do not require the Vacuum Blower, reduce the machine price by ...$ 4,500.
Equipment Location:MIDWEST
Norm Schust
800-374-5009 ext:445
|
|
AXYZ AUTOMATION 4012 CNC ROUTER (SINGLE SPINDLE):Moving gantry machine in a front-to-back configuration with stationary table. -- 57" X 120" process area; over 12" Z axis movement and approximately 19" gantry clearance max. speed 1,000 IPM; aluminum table has overhead vertical framework with clamping pistons built into the table on one end and hydraulics on the other end to provide overhead clamping of material. -- T-slot fixturing capability; heavy duty gantry bridge rides on double drive integral rack & pinion system. -- Has been fitted with router motor and dual aggregate head (also has an unused spare aggregate head and extra tools). -- Equipped with:8.5 KW (10 HP) spindle motor, variable RPM up to 24,000 RPM with a 90° manual rotation for X- & Y-axis horizontal routing using a included speed control; Pneumatic quick change. -- Control system includes:The AXYZ software, and hand-held pendant with a user friendly WINDOWS PC (CE version 9.92RG based control system. -- NOTE:The extra equipment shown in the pictures can come with the CNC at an extra cost.
Equipment Location:MIDWEST
Norm Schust
800-374-5009 ext:445
|
|
AXYZ 6010 CNC Router
AXYZ 6012 CNC Router
82" x 144" Table
5 HP Spindle
Mister for cutting aluminum
(1) 10 HP Becker Vacuum Pump
Vacuum lift also included....
Customer is selling the package of two AXYZ CNC Routers. One is up and running and the other is available to put under power. They are being replaced by one large machine. Seller has spare parts and all information on the machines. Buyer will need to rig them out. Seller does not want to split up the package at this time. All the parts are interchangeable so one could be used just as a parts machine!
Equipment Location:SC
Carolina Machinery Sales, Inc
704-288-1904
|
|
AXYZ AUTOMATION 7012 CNC Router with ATC:82" x 144" Moving gantry, fixed table design in a front-to-back configuration with an aluminum T-slot table arranged for multi-zone vacuum including manual controls. -- Equipped with:(1) 8.9 HP QTC type routing spindle with a traveling (8) position tool-changer , variable speed from 6,000 - 24,000 RPM. -- Axis movement:All axes ride on profiled rails and are driven by Servo motors with rack-n-pinion mechanics on the X & Y axes, and a ball screw on the Z axis. -- Control:The A2MC Controller is compatible with any CAM package, Connects via TCP/IP to host LAN system so transferring files is instant, Handheld operator controller. -- Complete with:(1) 3 HP BECKER vacuum pump, assorted tooling, new Z-Axis drive belt and documentation.
Equipment Location:MIDWEST
Norm Schust
800-374-5009 ext:445
|
|
BIESSE ARROW ATS: with (2) 20 HP Router Spindles and (2) Tables: -- Specifications: Working Capacity (2) 59" x 61" work zones can operate independently for loading/unloading on one while the other is in process or together for a large 118" x 61" work area, and are outfitted with BIESSE'S "ATS" (Advanced Table System). -- Positioning Speed:"X", & "Y" 262 FPM (80 MPM), "Z' axis 82 FPM (25 MPM).Closed loop AC Servo motors drive anti-backlash, helical rack & pinion mechanisms on the "X" & "Y" & a precision ballscrew on "Z" axis.All axes ride on precision roller bearing guide ways; an automatic lubrication system services the way bearing, ballscrews and rack & pinion components. --Work areas:(8) "ATS" Panel supports (4 per zone) that can be manually moved left or right by a handle with push button release and have a digital readout for accurate positioning.(2) NC Controlled stop pins per panel support (total 16), (1) NC controlled up/down material load bar per panel support (total 8), (6) aluminum side stop bars (3 per work zone) with (2) adjustable, NC controlled stop pins per bar (12 total).Each panel support has (3) "ATS" sliding vacuum units (24 total), manually adjustable front-to-back, that can accept vacuum pod modules in a variety of shapes and sizes. -- Boring Unit:(1) 2.3 HP (1.7 kW) motors - variable speed to 4,000 RPM; 13 independent vertical spindles with (8) spindles in "X" axis & (5) spindles in "Y" axis.(6) horizontal spindles, (2+2) in "X" axis & (1+1) in "Y" axis. -- Machining Units:(1) 20 HP (15 kW) Liquid cooled electro-spindle with HSK F63 adaptor mounted to the LH side of the machine; variable speed from 1,000 - 20,000 RPM & controlled by a programmable digital inverter.(2) 10-Position rotary tool changers mounted at front of each router for "on the fly" ATC (max. tool dia. between positions 6.89"). -- (1) Additional 20 HP (15 kW) Liquid cooled electro-spindle with HSK F63 adaptor NC controlled and ATCvariable speed from 1,000 - 20,000 RPM & controlled by a programmable digital inverter. -- Operator & Machine Control: PC front end with: Biesse "NC 1000" + Windows NT operating system: INTEL "Celeron" Processor at 600 MHz, 9.3 GB hard drive, 17" color monitor, 101-key keyboard, mouse, parallel port, RS-232 serial port, (2) USB ports, CD ROM, 128 MB RAM memory, ethernet card, and 1.44 MB floppy disk drive.Control features 3-Axes simultaneous linear & 2-axis simultaneous circular interpolation, custom editor for part program creation, graphic setup of panel supports, internal modem for teleservice support, tool-path display, and controls dedicated to activation of the machine functions. -- No vacuum pump included.Machine safety fencing, and original manuals and documentation. -- Actual Model is Biesse ARROW ATS
Equipment Location:EASTERN CDN
Norm Schust
800-374-5009 ext:445
|
|
Biesse Rover 30
5' x 11' Table with (2) independent work zones
X Axis 135", Y Axis 61", Z Axis11", max material thickness 9"
Boring Unit: 4 HP with 20 Spindles (10 in X, 10 in Y)
13 HP Spindle with HSK F63 adapter
7-Position ATC
40 HP Travaini Vacuum Pump
Equipment Location:GA
Carolina Machinery Sales, Inc
704-288-1904
|
