Woodworking Equipment For Sale

BRANDT KDF 650 (1650 HIGHFLEX) Edgebander, with 3,339 Hrs. (As of 10/31/23), Pre-Mill & Corner RoundingSpecifications: -- 0.4 - 12 mm (1/2") Edge cap., panel thickness 5/16" - 2-3/16", min. panel length 160 mm (6-3/8") and 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function. -- Automatic height adjustment with top pressure beam for all work stations, equipped with digital height indicator. -- "PC-16" Program Control with: 21-1/2"; Display, signal infeed light to ensure proper spacing between panels.Equipped with: -- Pre-milling station for cleaning edges of the panel; "Quick change" glue tank for maintenance & glue color change. -- 32"; Dia. Coil table. -- Automatic magazine for strip & coil stock, 3 mm PVC guillotine, (1) drive plus (3) idle roll "pneumatically controlled" pressure sections with digital indicator for quick edge thickness changeover.Workstations: -- End trim (0.33 HP - 12,000 RPM motors), chamfers 0° - 15°; -- Top & bottom flush/bevel/radius trim, bevels 0° - 15° (0.5 HP - 12,000 RPM motors) with insert knives for 2 mm PVC radius. Vertical copy wheels are servo-controlled for quick changeover, programmable from the control panel. -- 2-Motor (4 corners) contour trim for profile corner rounding (two 0.5 HP - 12,000 RPM motors), with insert knives for 2 mm PVC radius. -- Top & bottom scraping for 2 - 6 mm radius, pneumatically controlled blow off nozzles; -- Top & bottom buffing (0.25 HP - 1,400 RPM motors). -- End trim, flush/bevel/radius trim & corner rounding stations have HF motors with electronic brakes; feed chain track speed 42 FPM, 2 HP feed drive.Complete with: -- Operator control panel, PLC (Programmable Logic Control) keypad, and LED readouts; used tooling.NOTE: Actual Model "KDF 650".NOTE: Specifications must be confirmed.Machine Dimensions: 254"; x 50"; x 68"; H.Machine Dimensions with Outboard Panel Support Extended: 254"; x 66"; x 68"; H.

2008 Brandt Edgebander 230Y/133V 3 Phase Currently in Production

Brewer Step Planer 24in, BR425, S/N 12286, 50HP Electric Motor Up to 6" thick

Brewer BR-425 Step Planer

Brewer Step Planer #00728

Brewer 3 Head Resaw Model: Golden Eagle 2000 Year: 1998 Blade Size: 2" Voltage: 480 3ph Material Capacity: 7.5" - 12" width Serial #: No Placard Condition: Fully Functional, no rust, Updated electrical panel. Spare Parts: 2" Blades Dimensions: 20' long x 11' wide New Bearing on all wheels front and back. We put a new rubber belt on the infeed, we still have the steel belt infeed if they want to change it back. About 20-40 2” band saw blades included. Saw Head 3 has 1 new motor.

Brewer 1695 Chop Saw 20HP 3 strand log deck Live roll 15' infeed 10' outfeed Needs chains and rollers

--This machine is in Auction @ https://exfactoryauctions.com/Detail/PM-231011/event/A122024$1. --NO RESERVE! BRIANZOLA SIMCOR 10" W Rotary Embossing Press Specifications: Max. thickness 4" (Depending on head diameter). Equipped with: Slotted table, with 11-1/2” x 3/4” Adjustable left & right material guides. Fixed arbor, with 1 HP - 1,700 RPM - 260/440 V Motor & Adjustable arbor support. 19-1/4” L x Approx. 10” Dia. Motorized smooth steel feed roller synchronized with arbor, Electronically-controlled feed speeds. Complete with: 8” Dia. x 1” W Embossing Head.

New conveyor system that is NEW/NEVER INSTALLED. Everything is ready to load and will take approx two full flatbed trucks to move. See photos for all specs.

BUILDERS AUTOMATION MFSR CNC 5-Axis Multi-Function Stair Routing Machine, fully programmable.Specifications: -- Axis Configuration: 1.) X axis; 2.) Y axis; 3.) Top Z (top router depth control); 4.) Bottom Z (bottom router depth control); 5.) Axis A (advancing of board) -- Features: Programmable Touch Screen for simpler stair characteristic input by operator; Touch Screen for landing cut both top & bottom for open box & contemporary; Two (2) high frequency routers with 7.5 HP @ 24,000 RPM fan-cooled spindles that can accommodate shanks of ½" or 3/8" diameter.Accepts one or two stringers at a time -¾", 1", 1½" thick for a total of 3" maximum thickness and 7¾" to 15¾" wide; Extra wide ¾" guide rails for more bearing surface with a 3¼" high fence. -- Includes: (5) Cylinder clamps - 3 fixed and 2 adjustable for up to 2,950 Lbs of vertical stringer clamping force. Additional 1,180 Lbs horizontal clamp force for a total of 4,130 Lbs.; Self-centering feed system on linear bearings for better support and elimination of wear on the brass parts; Accommodates staircase angles from 20° to 45° and riser kickback from 5° to 11° with landing cut; Cuts up to ½" deep in yellow pine at the maximum rate of 20" per second and an open stringer in a single cut;Programmable to cut any combination of box, contemporary, or open stairs with landing cut; Completes the top and bottom landing cut without additional handling or manual sawing. Adjustable setting for wedge fit or material variances. -- Production rate: Approx. cycle time 10 Seconds per 7/11 tread in 1 or 2 stringers. -- Comes with: Dust collection cups on each router for clean efficient operation.Manufacturer's standard 1 year. -- Overall Dimensions/Weight: Measures approx. 8′ x 6′ 5″ x 7′ high; Gross weight approx. 3,500 pounds. -- Services required: Air requirements 15 CFM @ 110 psi, (minimum ¾" diameter unrestricted line);Electrical requirement 230 V, 3-phase at 70 Amps. -- Available Option: Extra wide, custom version that cuts down the middle of up to a 24" wide stringer, yielding two sets with no waste (except sawdust).

BUILDERS AUTOMATION (BAM) 2220 Stair Wedge Cutter. Automatically cuts wood wedges used to lock stair treads and risers into slots in stair stringers.. -- Equipped with: 10" Dia. saw blade with 1.5 HP direct drive motor, hopper feeds material automatically, air operated with 6 CFM compressed air requirement, 1.8 Sec/stroke. -- Features: Auto-shutoff feature and capability to cut glue blocks. -- Upright guide expandable to hold up to 40 pieces of wood at one time -- Rapid changeover to cut glue blocks for more efficient operation -- Once cycle started, hands-free use for labor-saving utilization -- Enables you to easily change size or angle without tools saving time and improving productivity -- Utilizes a 1.5 HP saw that automatically cuts pieces up to 9-1/2" W x 11-1/2" L -- Operator panel includes key start and e-stop controls for the saw motor and start/stop control for the pneumatic system that coordinates all machine motions -- Capable of producing wedges of varying thickness on alternate strokes of the saw -- Scrap material is ejected under the machine, and the wedges are discharged into user-supplied hoppers -- An included discharge chute diverter separates automatically and directs wedges of different thicknesses (produced on alternate saw strokes) into separate hoppers (user-supplied) -- Sawdust carried away from the saw guard pick-up through a 3" diameter hose -- Comes with manufacturer's standard 1-year warranty -- Complete with: Self-diagnostics, built-in starter, automatic shutoff feature, air filter & lubricator.

•Burelbach 4 x 10ft stacker •Removed from plywood mill that went out of business, was in use at time of shut down •Currently stored inside

This machine was customized to be a wire brush machine for a floor finishing line.

BURKLE - VBM 1688, ...Stain Wiping MachineSingle sided machine, 1,600 mm wide; 2-Brush Panel Cleaner (TAMPICO brushes). Features: &#9679 Heads can be positioned as needed spacing between the brushes by sliding brackets. &#9679 Brush raising & lowering accomplished by means of handwheel adjustment. &#9679 Brushes are removed at side of machine by sliding out of shroud/channel support rail. &#9679 Safety bar checks part thickness for overthickness parts. &#9679 SIEMENS Control to set rotation speeds & feed belt speed. &#9679 Rigid Aluminum bolted base construction. &#9679 Solid feed belt (NO vacuum holddown)

Manufacturer Specifications Width capacity 1300 mm Panel thickness: 3 - 80 mm variable feedspeed 6-30 m/min Coating roller 55° Shore with variable speed and scraper Chrome doctor roller with variable speed and scraper

Burkle Roll Coat Line (2) Roll Coaters - Model SAS 1300 - Model SLC 1300 Brush Machine IR Oven Max Feed Speed 25m/mim. This system was removed in good working condition with low hours.

SLC 1300 Roll Coater 1300 mm wide

BURKLE - Roll Coat, ...Lacquering Line with: UV Curing & HEESEMAN Sander. General Line Data:Working width: 1,300 mm (51")Working height: 900 mm +/- 20 mm (35 - 36")Production speed: 10 MPMPassing height 3 - 80 mm (3/16" - 3-1/4")Shortest length of boards 350 mm (14")Operating side: Right-hand side Electric:Operating voltage: 480 Volt, AC, 60 Cycles, 3-PhaseControl voltage 24 Volt, DC LINE CONFIGURATION:STATION #1 - 2-Roll Coating Machine - "SAS 1300" (Filling Machine) For single-sided application of base coating materials suitable for circulation. The machine is suited for base coating veneered, boardlike workpieces or solid components simultaneously filling fine grain or hairline cracks in the veneer by means of the Reversing Smoothing Roller. Application Unit:- Separate, infinitely adjustable frequency-controlled direct drive for the application roll. Rubber-covered application roll of double thickness of the rubber covering, with corrosion-resisting roller ends.- Quickchange coupling for the application roll with hinged bearings and an OLDHAM coupling. Oscillating scraper blade for the application and doctor rolls with an ergonomically designed scraper blade support is quickly removable for cleaning, and can easily be placed back by a self-locking worm gear.- Separate, infinitely adjustable frequency-controlled direct drive for the reversing Doctor Roller. - Change of rotation of the Forward Doctor Roll by an electric reversing switch in the Control Panel.- Hard chromium-plated doctor roll with a fine adjustment by a worm gear gap adjustment via a mechanical digital indicator in the handwheel.- Hood, which can easily be opened, features integrated radiation protection. Smoothing Unit: - Hard chromium plated smoothing roll with an infinitely adjustable, frequency-controlled direct drive. - Scraper blade for the smoothing roll with an exchangeable plastic blade. - Distance from the smoothing roll to the application roll approx. 0.5 mm, for the automatic return of the material, readjustable when regrinding the application roll. Material Circulation System:- Pneumatic double diaphragm pump (R 1“) with pressure reducing valve & stop for careful lacquer feed, particularly suited for very viscous and solvent-free lacquer systems.- Material supply by means of a chemical resistant hose and special steel pipe, ergonomically designed and fitted underneath the hood, with discharge hose and stop.- Large-dimensioned lateral collecting troughs and return gutter made of special steel.- Spring-loaded end plates with exchangeable screwed-on plastic coverings.- Suitable for one way containers of 30 liters contents (max. height 400 mm). Motorized Height Adjustment:- (2) Separate, motorized precision lifting gears wit

BUSCH MINK MM 1322 A VV8 VACUUM PUMP, ROTARY (DRY CLAW): -- Specifications:360 m³/Hr., Dry Rotary Claw Vacuum Pump, Model: MM 1322 A VV8. Nominal pumping speed displacement 212 ACFM; Ultimate pressure 112.5 TORR; Nominal motor rating 10.9 HP; Nominal motor speed 3,600 RPM;Noise level (ISO 2151) 82 dB(A); Weight approx. 655 Lbs.; Dimensions (L x W x H) 46.9 x 21.5 x 17.9 inches; Gas inlet/outlet, 2" / 1¼" NPT. -- Industry Uses:Woodworking Handling devices, Drying, Handling robots, Clamping on CNC routers, Pneumatic conveying.

BUSCH MINK MM 1322 A VV8 VACUUM PUMP, ROTARY (DRY CLAW): -- Specifications:360 m³/Hr., Dry Rotary Claw Vacuum Pump, Model: MM 1322 A VV8. Nominal pumping speed displacement 212 ACFM; Ultimate pressure 112.5 TORR; Nominal motor rating 10.9 HP; Nominal motor speed 3,600 RPM;Noise level (ISO 2151) 82 dB(A); Weight approx. 655 Lbs.; Dimensions (L x W x H) 46.9 x 21.5 x 17.9 inches; Gas inlet/outlet, 2" / 1¼" NPT. -- Industry Uses:Woodworking Handling devices, Drying, Handling robots, Clamping on CNC routers, Pneumatic conveying.
