Woodworking Equipment For Sale

SCM ACTION FL 2500 (CASE CLAMP (AUTOMATIC): -- Specifications:Max. standard working dimensions: 2,500 mm (98.4") Wide x 1,250 mm (49.2") high x 800 mm (31-1/2") depth. -- Min. standard working dimensions: 250 mm (9.8" Wide x 250 mm (9.8") high x 150 mm (5.9") depth. -- Working height: 508 mm (20"). -- Vertical pressing force: 15 KN (3,372 Lbs).Features: -- Full top & bottom platen for maximizing pressing PSI on the box. -- Rack & Pinion guides at all (4) corners of the top platen & side pressure to keep the top platen parallel and the side pressure square. -- Sizes of box can be input for efficient cycle control when running repetitive box closings. -- Machine can also find the size of the box, so all the Operator has to do is open the Clamp to a size larger than the box to be clamped. -- The vertical & horizontal pressure is adjustable according to the type of furniture to be assembled. -- Machine is equipped with: (3) Side pressure bars & able to sequence different furniture pieces without manual intervention. -- Pressure supplied by infinitely adjustable brushless electro-motors.Complete with: -- 5.7" Touchscreen panel with: Software by CPC in order to program cycles. -- Rack & Pinion system, Brushless motors. -- Front & rear photocell barriers. -- Actual Model is: SCM CPC ACTION FL 2500

SCM - OLIMPIC K 201 HFA, ...Automatic Compact Edgebander with: 3 mm Max. coiled edgebanding thickness & High Frequency motorsSpecifications: -- Edgebanding thickness cap. (for both coil & strip): 0.4 - 3 mm (0.02" - 0.19"). -- Min. panel length for coiled edges (min. width 200 mm) 140 mm (5.51"). -- Min. panel width for coiled edges: 65 mm (2.56"). -- Panel thickness: 8 - 40 mm (0.31" - 1.57"). -- Feed speed:9 MPM (29 FPM).Equipped with: -- Automatic adjustment of all units when panel thickness is changed. -- 20" Dia. coil table. -- Automatic coil feed magazine; manual strip feed. -- Teflon-coated glue pot. -- 1.2 mm (0.05") Cap. guillotine. -- Eye-level control with: GEFRAN "1000" LED Temperature controller. -- Adjustable feet.Workstations: -- Single-motor end trimming unit with: (1) 0.19 kW (1/4 HP) - 12,000 RPM High-frequency motor & copying device. -- Top & bottom flush trimming unit with: (2) 0.35 kW (1/2 HP) - 12,000 RPM high-frequency motors, and front & vertical copying devices.

SCMI - K201 HFE, ...Single Sided Edgebander1/8" Max. edge cap. and 1-1/2" max. panel thickness; semi-automatic strip & coil feed magazine (manual single strip feed), Teflon coated glue pot w/fast 8-Minute heat-up time, 1.2 mm cap. guillotine. -- Workstations: Single motor front & rear end trim, 0.8 HP - 10,000 RPM motor; top & bottom flush trims, 0.8 HP - 27,000 RPM ea. motor; straight or 12° bevel cutters. -- Top & bottom buffing unit, 0.25 HP - 2,800 RPM motors. 25 FPM Fixed feed speed with 0.8 HP drive. -- Complete with: Sound enclosure, frequency converter, and used tooling.

SCM MINIMAX - FORMULA S1, ...Sliding Table SawSpecifications: -- 120" Cap. with: Scoring; 9 HP main motor & belt driven scoring blade; -- Manual tilting of the arbor 0° - 45°; Manual raise-and-lower of the main blade; -- 50" crosscut capacity with a movable fence.Features: -- "Easy-Set" scoring adjustment; heavy cast iron trunnion; 12" main saw blade dia. with 1" Arbor, 110 mm scoring blade dia.; -- Max. cutting height 3-1/2" at 90° & 2-3/4" at 45°; 1-speed arbor; 8,000 RPM on scoring blade. -- Complete with: 4" Main dust extraction outlet, miter fence & crosscut fence assembly with (2) flip stops.

SCMI MINI MAX Formula S 2 Sliding Table SawSpecifications & Features: -- 128" Cutting cap. w/ Standard scoring saw and carriage, 5 HP motor, stop on fence for cuts extendable to 128"; 50" Cutting width w/ rip fence.Equipped with: -- 14" main blade, 4-1/2" scoring blade, 4-1/2" max. blade cutting height at 90°, 3-1/2" max. blade cutting height at 45°. -- 4,000 RPM Main blade speed, 8,500 RPM scoring blade; 90° - 45° blade tilting.

SCM STARTECH CN - CNC MULTI SPINDLE DRILLINGFeatures: -- Easy Motion Work Table -- 7" Touchscreen -- (7) Independent Vertical Boring SpindlesSpecifications: -- Maximum Panel Dimensions X-Y-Z (3050mm x 800mm x 50mm), Minimum Panel Dimensions X-Y-Z (300 mm X 90 mm x 10 mm) -- Drilling/Grooving working area: 0mm x 800 mm/0mm x 800 mm ÷X-Axis Stroke: 750 mm÷X-Y maximum axis speed: 25m/Min. -- Vertical Spindles: 7 (4X-4Y one of them is shared) Horizontal Spindles: (along Y-axis): 2 (1+1) -- Horizontal Spindles: (along X axis): -- 1 Fixed Integrated Blade (cutting into direction): X Blade Diameter: 100 mm Maximum Blade Thickness: 5 mm -- Motor Power: 3 HP (2.2 kW) Spindle Rotation Speed: 3350 RPM÷Blade Rotation Speed: 4300 RPM -- Electrical Supply: 230 Volt (60 Hz) Installed Motor Power: 4.5 KVAHigh-performance numeric controlled (NC) Drilling Machine engineered for full-production woodworking shops and craftsmen. The Startech CN drilling head's seven (7) independent vertical spindles, the spindle and blade in the “X"; axis, and the possibility of drilling in the “Y"; axis make it both flexible and ideal for batch furniture productions. This machine allows the operator unparalleled flexibility for tailored products without the need of operator intervention for the worktable and machine set-up according to the panel dimensions.

SCM TECH Z 30 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications:Working Field "X" axis 120" (3,050 mm); "Y" axis 52.7" (1,340 mm) for routing & 44" (1,118 mm) for boring; "Z" axis stroke 7.8" (200 mm); max. material thickness 3.9" (100 mm). -- Positioning Speed:"X" & "Y" Axes are 197 FPM (60 MPM); "Z" axis is 72 FPM (22 MPM).Axes positioning by: AC Brushless motors and YASKAWA drives; high precision ball screw drive system in "X", "Y". "Z" Axes;All axes ride on prismatic guideways & sliding blocks. -- Worktable:(6) "TV" Tubeless mobile support rails, (2) vacuum pods per rail; (4) pneumatic lifter rails for heavy panels.(6) Pneumatic pop-up backstops, (6) pneumatic pop-up front stops; (2) pneumatic pop-up side stops.LED Display positioning assistance for the support rails & vacuum pods; (2) independent working fields. -- Boring Head:3 HP (2.2 kW) motor - 4,000 RPM; (15) independent vertical spindles: (8) Spindles in "X" & (7) spindles in "Y".(6) Horizontal spindles (2 + 2) in "X" & (1 + 1) in "Y-axis".(1) X-axis grooving saw with 100 mm dia. blade - 6,000 RPM. -- Machining:(1) 10 HP (7.5 kW) Electro-spindle router with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM, max. torque achieved at 12,000 RPM.Static inverter for stepless speed & rapid shutdown rotation.(1) 6-Position ATC tool plate mounted on the on the machine for "on the fly" ATC; max. tool weight is 8 kG (17.6 Lbs). -- Operator & Machine Control:PC Front-End with: SCM "UNIVERSAL K2" + "Xilog Plus" + Windows "XP" Pro Operating System; 15" CRT color display, CELERON 2 GHz processor, enclosed in air-conditioned cabinet. -- Complete with:(1) 100 m³/Hr Vacuum Pump; automatic lubrication system; "BUMP STOP" safety system. -- Actual Model is SCM TECH Z30 R6

1998 SCM TECH 30 Super Router

SCM TOP 35 BORING MACHINE(35) Spindles on 32 mm centers, pivoting boring head, drills vertically from the top and horizontally from the rear,Specifications: -- 0° - 90° Motorized tilting of the head, can be locked at any angle between; max. panel width 1.280 mm. -- (2) 6 HP - 2,800 RPM Motor; quick boring depth setting with (6) depth stops on revolving turret, viscous damper for smooth drilling & through boring. -- Designed with: Lead screw w/veneer scale for head displacement setup.Complete with: -- Back fence w/flip stops, plus fence extension with (4) mechanical reference stops, (4) pneumatic hold-downs; 33" worktable height.

SCM SANDYA 7 RCS Wide Belt Sander2-Head, 42" cap. - Great solid wood finish Sander. -- 1st Head: Grooved steel contact roll, 6-1/4" dia., 30 HP motor -- 2nd Head: Combination head, rubber covered contact roll, 6-1/4" dia. (65 Shore), and 2" wide finishing platen, 25 HP motor. -- 43" x 75" or 85" Abrasive belts with electronic tracking & pneumatic belt tensioning, pneumatic exclusion of all contact rolls. -- Conveyor belt feed with variable feed speed, 14.5 - 30 FPM, 1.5 HP motor, automatic part thickness adjustment, -- Motorized thickness opening with LED readout,0" - 6-1/4" via (4) precision conveyor bed jacks. -- Infeed & outfeed spring loaded rubber covered holddown rolls on all heads, -- Motor load meters, infeed and outfeed conveyor extensions, WYE-DELTA soft start.

SCM Sandy 10 -RCS-110 Wide Belt Sander (2) Heads43" Width cap. Drum, Combination HeadHead Configuration:1st. Head: 7" diameter corrugated metal roller for calibration 35 HP ( Drives both Heads )2nd Head: Combination head with 7" dia. contact roller (spiral grooved rubber covered); air/jump finishing platen controlled with timers to eliminate any rounding on leading & trailing edges of the panel, 2" wide platen.Specifications --103" long x 43" wide Abrasive belts --Air tracking, floating & rigid bed for sanding of veneers & solid panels; infeed & outfeed spring loaded holddown rolls -- Minimum workpiece length 16" --Thickness capacity 6.25". --Separate 2.5 H.P. variable speed feed motor delivering feed speeds from 15 to 70 FPMNote: The seller has 20 boxes of various sandpaper belts (80 – 150 grit) that will be included.

SCM SANDYA 15S (3) Head Wide Belt Sander42" Width cap, Drum, Drum, Combination HeadHead Configuration:1st Head: Steel contact roll, 7" dia., 35 HP motor;2nd Head: Rubber-covered contact roll, 24 HP motor3rd head: Combination head, rubber-covered contact roll (45 Shore) and 3" wide finishing platen, 17.4 HP motor.Specifications: -- 43" x 103" Abrasive belts -- Electronic tracking & pneumatic belt tensioning, abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 4 HP motor -- Automatic part thickness adjustment -- Motorized thickness opening via (4) precision conveyor bed jacksEquipped With & Features: -- LED readout, 0" - 6-1/4" opening. -- Infeed & outfeed spring loaded rubber covered hold-down rollers -- Motor load meters -- Infeed and outfeed roller conveyor extensions.

SCMI SANDYA S300 RCS 110 DUAL HEAD WIDE BELT SANDER43" Width capacity, (1) contact roll & (1) combination head with contact roll & segmented platen.Head Configuration1st Head : 5-1/2" diameter steel calibrating contact roll2nd Head : 5-1/2" diameter rubber covered contact roll and adjustable segmented finishing platen.Specifications -- 0" to 6.69" thickness capacity via motorized bed adjustment with auto set up device. -- Abrasive Belt dimensions 43" X 75" -- Rubber coated pressing rollers before and after working unit -- 1 HP Inverter variable speed feed unit. -- Feed speeds 10 - 60 FPMEquipped with and Features -- Y-Delta two-stage reduced voltage starter on 18 HP main motor -- 2 Roller Infeed and Outfeed table extensions -- Automatic Electronic Table Positioning Device -- Adjustable sanding drum and pad position for micro precision adjustment -- Electronic digital thickness readout of work table position -- Powered table lifting by means of (4) heavy duty motor and lifting columns double fastened at both top and bottom of the lifting columns to provide exceptional table stability -- Electronic tracking of abrasive belt -- Automatic feed mat tracking -- Pneumatic belt tensioning with center fulcrum to compensate for tapering of abrasive belt

SCM SANDYA - 40 M3 135, ...3-Head Wide Belt Sander 52" Width cap. Drum, Drum, Combination HeadHead Configuration:1st Head: Steel Contact 22 kW Pneumatic blowdown and alignment.2nd Head : Rubber Contact 18.5 kW Pneumatic blowdown and alignment.3rd Head: Combination Platen 15 kW Pneumatic blowdown and alignment.Note:The SCM sander does not have a brush. After the 3rd head, it has this pneumatic blow-off bar with multiple blow-offs running the length of the sanders width. Sander can be seen under power if needed.Specifications: -- 53" x 103" Abrasive belts with electronic tracking. -- All heads with abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 5 HP motor. -- Automatic part thickness adjustment. -- Motorized thickness opening via (4) precision conveyor bed jacks with LED readout. --0" - 7-7/8" opening. -- Equipped with & Features -- Outfeed rubber covered holddown rolls or shoes on all heads. -- Motor load meters. --Infeed and outfeed conveyor extensions. -- WYE-DELTA soft start.Note: The SANDYA model "40" is more or less the same as the SANDYA "30" but more Heavy Duty.

SCM Sandya 5 Wide Belt Thickness Sander (Model 5 RCS 110)43" width cap, Drum, Combination headHead configuration1ST Head : Contact roll, 5-1/2″ dia., 25 HP motor;2nd Head: Combination head, rubber covered contact roll, 5-1/2″ dia., and 2″ wide finishing platen for veneer, 18 HP motor.Specifications -- 43″ x 85″ or 103″ Abrasive belts with electronic tracking & pneumatic belt tensioning, -- Pneumatic exclusion of all contact rolls. -- Conveyor belt feed with variable feed speed, 10 – 60 FPM, 3 HP feed motor, Equipped with & Features: -- Automatic part thickness adjustment, -- Motorized thickness opening with LED readout, -- 0″ – 6-1/4″ via (4) precision conveyor bed jacks. -- In feed & out feed spring loaded rubber covered hold down rolls on all heads, -- Motor load meters -- In feed and out feed conveyor extensions. -- Automatic advancement carpet -- Grooved rubber precision rollers Aspiration dust fans -- Emergency device to save hands while pieces in feedingMore info -- Dimensions 77″ x 64″ x 92″ Weight 1210 kG - Specifications, Dimensions & Weight data are to the best of our knowledge.

Tubeless Vaccum (TNV) Electro-Spindle with HSK63F quick release Toolholder Rotation speed 600-2400 rpm Air Cooling by rear electrofan Static Inverter Centralized dust collection system with automatic blast gates

SCM - S 52, ...Straight Knife Planer20" Width cap.; knife cutterhead; 9 HP main motor (approx.); 1/8" to 9-1/4" motorized opening with mechanical digital readout; max. depth of cut 5/16"; 10" min. length of workpiece; (4) feed speeds at: 21 - 32 - 42 & 55 FPM; table size: 20-1/2" x 33-1/4". -- Equipped with: Chip breaker; sectional grooved infeed & solid outfeed roller.

20" (520 mm) Width cap.7,5 HP (5,5 kW) main motor ÷4-knife cutterhead÷1/8" to 9-1/2" (3 - 240 mm) ÷motorized opening mechanical scale for bed position max. depth of cut 5/16"÷10" min. length of workpiece ÷(4) feed speeds at 18/30/39/51 FPM (6/10/13/17 m/min.)÷table size 20-3/4" x 33-1/4". ÷Includes: Knife sharpening attachment ÷ Equipped with: Chip-breaker, sectional grooved infeed & solid outfeed roller.

SCM - S520 E, ...Planer Specifications: -- 20" Width cap.; 9 HP main motor; 4-3/4" dia. 4-knife TERSA cutterhead at 4,500 RPM. -- 1/8" - 9-1/4" Powered opening with digital readout for fine adjustment; max. depth of cut 5/16"; 10" min. length of workpiece. -- (4) Feed speeds: 20 - 33 - 43 & 56 FPM; table size 20-3/4" x 39".Equipped with: -- Chip breaker; sectional grooved infeed & solid outfeed rollers; (2) adjustable bed rollers. -- Complete with: Magnetic starter & shaving hood.

SCMI SIGMA PRIMA 50 FRONT LOAD, AUTOMATIC PANEL SAW: -- Specifications: Working cap:149.6" (3,800 mm) Max. rip cut cap. 125.9" (3,200 mm) pusher stroke; 1.96" (50 mm) max. saw blade projection; 12 HP (9 kW) main saw motor (3,900 RPM); 2 HP (1.5 kW) scoring saw motor (6,300 RPM).Main blade diameter: 11.8" (300 mm), Main blade arbor diameter: 80 mm; Scoring blade diameter: 6.37" (160 mm), Scoring blade arbor diameter: 55 mmAutomatic exclusion of scoring unit when motor is in off position. -- Saw carriageFeed speed 0 - 327 FPM (0 - 100 MPM), return speed 327 FPM (100 MPM),Automatic saw carriage lubrication, balanced on hardened cylindrical guides; external score saw adjustment, THK guides for vertical saw movement. -- Pusher Fence:Feed Speed 0 -230 FPM (0 - 70 MPM) forward speed, 230 FPM (70 MPM) reverse speed;Programmable rear fence with (7) material gripper clamps, rack & pinion movement,Grippers fit into a slotted pressure beam for positive material control during the final cut. -- Operator & Machine Control:PC front-end with: SCM Real time "WinCut" + Windows "7 Professional" operating system; Pentium 300 MHz, 6.4 GB hard drive, 64 MB RAM,17" color super VGA flat screen monitor, on-screen diagnostics & production reports; (2) serial ports & (1) parallel port, spacing available for networking cards. "Cutty" optimization software is included which allows: 30 lines per program, 300 max number of pieces per line, and 3 cutting levels. -- Complete with:Side alignment device: Min. part width 2.36"; Max. part width 48"; Rear support rails with rollers;(1) Front fixed air table 98" x 24" (2,500 x 609 mm), (2) Adjustable air tables 59" x 24" (1,500 x 609 mm).Plastic safety guards; emergency stop bar; enclosed cutting area; triple dust collector outlet. -- Actual model is SCMI SIGMA PRIMA 50.
