BIESSE ROVER - A 3.30: CNC Machining Center (w/ATC/Boring) -- SPECIFICATIONSWorking cap. - "X" Axis: 118" (3,000 mm) any unit; "Y" Axis: For routing, 45.2" (1,150 mm; "Y" Axis for: Boring; 49.6" (1,260 mm); "Z" Axis stroke: 7.8" (198 mm); max. material thickness: 5.9" (150 mm). -- Positioning Speed Both "X & Y" Axis is: 262 FPM (80 MPM); "Z": 111 FPM (34 MPM); helical rack & pinion drive: On "X" axis; precision ball screw on: "Y & Z" Axes. -- Worktable (6) Support rails with: (3) Vacuum pods per rail; (6) pop-up back stops, (4) pop-up side-stops; (2) independent working areas.Prepared for (optional) "quick fit" vacuum outlets for: Optional clamping of small or awkward shaped parts; each work zone with (1) "Quick connect" vacuum outlet: For custom vacuum fixtures. -- Boring Unit(14) Independent vertical boring spindles forming an L-configuration with: (7) Spindles in "X" Axis & (7) spindles in "Y" Axis.(6) Horizontal spindles with: (2 + 2) in "X" axis; (1 + 1) in "Y" Axis; (1) "X" Axis grooving saw for: Max. 120 mm dia. blade. -- Machining (1) 9.5 HP (7 kW) Vertically mounted HSD electrospindle router with: HSK F63 Adaptor.Inverter driven 1,000 - 24,000 RPM with: Max. torque from 12,000 - 24,000 RPM. (1) 18-Position "Ride-Along", "on the fly" automatic tool changer. -- Operator & Machine ControlPC Front-End with: BIESSE "XP600" + Windows "XP" + BIESSE "WORKS" Operating System.INTEL "Celeron" 2.0 GHz Processor; 4 GB Hard drive; 15" color monitor; international keyboard; soft touch keypad & industrial mouse; RS-232 serial port; (1) 1.44 MB floppy disk drive.BiesseWORKS: An easy CAD program that can be done from the office or at the machine; Operating System: Real-Time multitask processing; programs can be transferred via diskette or downloaded by wire. -- Complete with: (1) 250 M³/Hr Vacuum Pump; 11 KVA stabilized autotransformer for voltages between: 220 - 600 Volts. Equipped with: Centralized manual Lubrication System for guides & ball screw; built-in 1,500 W air conditioner for constant temperature & dust-free environment. Emergency stop rope & sound absorbing protective head enclosure with: Debris curtain around bottom edge. -- Actual model: BIESSE ROVER - A 3.30

BIESSE - ROXYL 5.5: Edgebander (w/Premill & Corner Rounding)SpecificationsEdgebanding Cap. - Edge thickness for strips: Min./max.: 0.4 - 22 mm (0.02" - 0.87"); coiled material from: 0.4 - 3 mm (0.02 - 0.12"); panel thickness from: 10 - 60 mm (0.39 - 2.36"); workpiece width; Min.: 85 mm (3.34"); workpiece length min.: 140 mm (5.51"); feed speeds: 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). Machine Interface -- "Roxyl-Matic" Automated machine setup; MS/Windows XP Operating System; floppy drive; 4 GB HD; USB port, keyboard, and mouse interface. -- Flat-Screen (17") with Color graphics interface: Programs can be easily created & recalled at will; graphic interface makes programming easy: Icon of each unit may be brought up on the screen to show the Operator the status of the unit & parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine Infeed Configuration -- Premilling Station "FL-502". (2) LH & RH Rotating NC controlled spindles with: Automatic center positioning. -- Anti-Adhesive: "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to workpiece surfaces. -- Infrared Heating Lamp. Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine. Automatic for processing coiled & strip edgebanding material. -- Pressure Section Servo controlled programmable pressure section with: (1) Large driven roller and (4) idle rollers.Gluing System -- EVA (Hot Melt) "QM-705" Quick premelting granulate with: Glue roller applicator to cover conventional edgebanding material. Workstations -- End Trimming Unit "IN-801": Front & Rear trimming motors; unipoint swivel: 0° - 15° Bevel; programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors. -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled: (2) Servo motors (one for horizontal tool position; one for tool up/down position); uses combination bevel/radius/flush insert knives; prepositioning of motors by pneumatic air cylinders. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner and upper & lower edge profiling. -- Profile Scraping Unit "RBK-503": Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit "RCC-701": Flat top/bottom; digital positioning indicators; pneumatic controlled for in/out position. -- Buffing Station "SP-501" Top & Bottom buffing motors with: 150 mm (6") Cloth buffing wheel diameter; adjusts in multiple directions. -- Edge Reactivation Unit "PH-700": Top/Bottom hot air blowers to restore original color to profile scraped PVC edge material.Complete with: -- Top Pressure Beam with: Driven flat belt & programmable height positioning.Includes: Multi-Tap Transformer. - Sound Hoods with interior lights. - Outboard panel support.

BIESSE - ELIX B: CNC Bore, Glue, and Dowel InserterBIESSE Drill & Dowel Inserter features: Single-spindle for drilling; dowel insertion unit; glue injecting unit installed on a carriage moving in the X-axis.Position for drilling dowel insertion provided through simple programs through the NC control or third party software. Operator Control interface is: Intuitive, user-friendly, and very easy to use. -- Specifications Max. parts length: 1,300 mm (51";); min. parts length:120 mm (4.7";); parts thickness: 10 - 40 mm (0.4"; to 1-1/2";). -- Positioning Speed "X" & "Y" Axis positioning speed: 40 MPM (131 FPM); "Z" axis has manual adjustment with: Max stroke of 40 mm (1.57").The working units travel: Precision machine ground ball screws; powered by brushless AC Servo motors. -- Worktable(4) Working Zones with: Center fence position in up mode; (2) large work zones in down position; (4) holddown cylinders. -- Boring UnitDrilling Uunit. High-speed unit with: 6,000 RPM spindle; max. drilling depth of 30 mm (1-1/4"); max. drill bit dia.: 12 mm (0.47"); manual adjustment of depth with: Digital indicator. -- Dowel Insertion UnitDowel prepositioning ensures: high repeatability of inserting dowels for each hole; distance between the dowel insertion unit and the drilling spindle: 32 mm (1.3") for simultaneous drilling; dowel insertion when holes are spaced at 32 mm; standard dowel dimensions: 8 x 30 mm; Max. dowel projection: 14 mm (0.551"). Glue Tank: Holds up to 8 liters (3.1 gallons) of glue; max. glue density: 900 CPS. - Glue inserting unit: Flow sensor and electronic adjustment of the amount of glue. -- Operator InterfaceIndustrial Numerical Control with: Extremely simple Program Editor; macro & parametric programming. Icon driven. -- Includes: Original Factory Machine Documentation. -- Actual Model: BIESSE ELIX B

BIESSE - AKRON 1130 J: Edgebander (w/Premill & Corner Rounding) -- SpecificationsWorking Capacity Edgebanding thickness: 0.4 - 3 mm Capacity; min. panel width: 85 mm (3.3"); min. panel length: 140 mm (5-1/2"); panel thickness: 10 - 50 mm (0.39" - 1.96"). - Feed Speed: 9 MPM (30 FPM).Front-End Equipped with: -- Premilling Unit "RT01" with: "Auto Set" Automatic intervention; Strip & Coil Edge magazine; automatic shear type guillotine. -- Hot Melt Glue System. Teflon coated glue pot; digital thermostats with automatic kickdown when machine is in idle mode.Pressure Section with: (1) Large dia. "nonstick" coated drive roller & (1) TEFLON plated idle rollers. Workstations -- "IT01" End Trimming Unit. Single motor end trimming unit with: Linear bearing support. -- "RT01" Premilling Unit. Asymmetrical diamond tools; max. height = 55 mm. -- "RF01" Tilting Fine Trimming Unit. Multiprofile cutters for: Flush trimming; 25° chamfer & 3 mm radius trimming. -- "AR01" Corner Rounding Unit. Single motor corner rounding unit with: 3 mm Radius tooling. -- RB01 Unit. Profile Scraping; Top & bottom 3 mm thick PVC banding. -- "RC01" Flat Scraping Unit. Top & Bottom glue scraping. -- "SZ01" Buffing Unit. Top & Bottom buffing unit; 1/2 HP (0.37 kW) - 2,800 RPM motors; units tilt 0° - 30°.Operator & Machine Control -- BIESSE "SMART TOUCH 7": User-Friendly touchscreen control panel for workstations.Complete with: -- Insulated sound enclosure over all trim stations with: Split dust hood; viewing windows.

BIESSE - ROXYL 5.5: Edgebander (w/Premill & Corner Rounding)SpecificationsEdgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"); coiled material from: 0.4 - 3 mm (0.02 - 0.12"); panel thickness from: 10 - 60 mm (0.39 - 2.36"); workpiece width min.: 85 mm (3.34"); workpiece length min.: 140 mm (5.51"); feed speeds: 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). Machine Interface -- "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System; floppy drive; 4 GB HD; USB port, keyboard, and mouse interface. -- Flat-Screen (17") with Color graphics interface: Programs can be easily created & recalled at will; graphic interface makes programming easy: Icon of each unit may be brought up on the screen to show the Operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine Infeed Configuration -- Premilling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to work piece surfaces. -- Infrared Heating Lamp: Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine: Automatic for processing coiled and strip edgebanding material. -- Pressure Section: Servo controlled programmable pressure section with: (1) Large driven roller and (4) idle rollers.Gluing System -- EVA (Hot Melt) "QM-705" Quick premelting granulate with: Glue roller applicator to cover conventional edgebanding material. Workstations -- End Trimming Unit "IN-801": Front & rear trimming motors; uni-point swivel: 0° - 15° Bevel; programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors. -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled; (2) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-positioning of motors by pneumatic air cylinders. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner and upper & lower edge profiling. -- Profile Scraping Unit "RBK-503": Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit "RCC-701": Flat top/bottom; digital positioning indicators; pneumatic controlled for in/out position. -- Buffing Station "SP-501" Top & Bottom buffing motors with: 150 mm (6") Cloth buffing wheel diameter; adjusts in multiple directions. -- Edge Reactivation Unit "PH-700": Top/Bottom hot air blowers to restore original color to profile scraped PVC edge material.Complete with: -- Top Pressure Beam with: Driven flat belt and programmable height positioning.Includes" Multi-Tap Transformer. - Sound Hoods with interior lights. - Outboard panel support.

BIESSE - ROVER 24 FTS: Flat Table Machine (w/ATC/Boring) -- Specifications4' x 10' "Matrix" Grid phenolic surface table for "Nested Base Manufacturing". -- Working Capacity"X" Axis is 122" (3,100 mm);"Y" axis 49.2" (1,250 mm); "Z" axis stroke is 9.8" (250 mm); max. material thickness of 6.1" (155 mm). -- Positioning Speed "X" & "Y" Axis is 328 FPM (100 MPM); Z-axis 98 FPM (30 MPM); "X" axis uses a helical rack & pinion system; "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides & ways & controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Work AreaFlat table design with: "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas.(14) External pop-up reference pins with: (6) Pins on the front of the table: (4) On the back of the table; (2) on the RH side; (2) on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit(1) 2.5 HP (1.7 kW) - 4,000 RPM Motor; (14) independent vertical spindles: (7) In "X" axis & (7) in "Y" axis.(6) Horizontal spindles with: (2 + 2) In "X" axis & (1 + 1) in "Y" axis; (1) 120 mm dia. "X" axis grooving saw.(1) 6-Position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Machining(1) 10.2 HP (7.6 kW) Air-cooled electrospindle with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM. -- Operator & Machine ControlPC Front-End with: NC 1000" + WINDOWS "NT" Operating System; 17" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:(1) 250 CBM/Hr Vacuum Pump; universal Autotransformer for voltages between: 200 - 600 V, 50/60 Hz; includes: Manuals, documents, safety mats, fencing. -- Actual Model is: BIESSE ROVER 24 FTS.

BIESSEROVER B 4.40 CNC MACHINING CENTER (W/ATC/BORING)Specifications: -- Working cap "X" Axis 143.3" (3,640 mm), "Y" axis 51.4" (1,306 mm), "Z" axis stroke is 8.8" (225 mm), max. material thickness 7"(180 mm). -- Positioning Speed: "X" & "Y" axis is 262 FPM (80 MPM), "Z" axis is 98 FPM (30 MPM); helical rack and pinion drive on "X" axis & ballscrew on "Y" & "Z" axis. -- Work Table: (6) Panel support rails with (4) lifting bars to assist with panel loading/unloading, digital display readouts for rail & pod placement according to the programs, (3) Vacuum pods per panel support, (2) independent working areas with pop-up locating pins for positioning of parts on the worktable -- Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with (1) "quick connect" vacuum outlet for custom vacuum fixtures. -- Boring unit: (24) Independent vertical boring spindles with (14) spindles in "X" axis & (10) spindles in "Y" axis, (10) horizontal spindles with (3+3) in "X" axis & (2+2) in "Y" axis, (1) "X" axis grooving saw with 120 mm dia blade. -- Machining unit: (1) 16 HP (12 kW) Vertically mounted HSD "Electro-spindle" router with ISO 30 adapter, inverter driven 1,000 - 20,000 RPM with max. torque from 12,000 - 20,000 RPM -- (1) 12-position ride-along ATC for "on the fly" tool change. -- Operator & Machine Control: PC Front End with: Biesse "XP 600" + BiesseWORKS Advanced + Windows "XP" operating system, INTEL "Celeron" 2.0 GHZ processor; 4 GB Hard drive; 15" color monitor, international keyboard, soft touch keypad & industrial mouse, RS-232 serial port, USB ports, CD ROM & 1.44MB disk drives -- Separate control panel with built-in 1,500 W air conditioner for constant temperature & dust-free environment, 11 KVA Stabilized auto-transformer for voltages between 200 - 600 Volts. -- Complete With: (1) 100 M3/Hr Vacuum Pump, Centralized manual lubrication system for guides & ball screw, emergency stop rope, safety mat protection barrier & sound absorbing protective head enclosure with debris curtain around bottom edge.

BIESSE0 - Levia 110: 43" 2-Head Wide Belt SanderWidth cap: 43"; Drum: Combination Head.Head configurations1st Head: 5" diameter steel contact roll2nd Head 5" diameter rubber drum 45 shore with 2 1/2" wide platenSpecification -- Width cap 43" -- 1st Head: Steel contact roll, 30 HP motor. -- 2nd Head: Combination head with a rubber covered contact roll and finishing platen 24 HP motor. -- 43" x 85" abrasive belts, electronic abrasive belt tracking, abrasive belt grit compensation on both heads with 4-position turret stop. -- Conveyor belt feed, 10 - 40 FPM variable feed speed with inverter control from control panel, 1.5 HP feed drive,Equipped with & Features -- Automatic conveyor belt tracking, -- 0" - 7-7/8" motorized thickness adjustment with LED readout. -- Automatic part thickness adjustment, -- Infeed and outfeed rubber covered holddown rolls. infeed panel -- Over-thickness" sensor, -- Electronic brakes on both sanding head motors. -- Infeed emergency stop, -- 3-Roll infeed extension -- Twin motor load meter.

BIESSE ROVER B 7.65 R FTK FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:5' x 20' Flat table design for "Nested Base" processing: Working field; "X" axis 240" (6,095 mm), "Y" axis 61.4" (1,552 mm), "Z" axis stroke is 7" (180 mm); max material thickness 5.9" (150 mm). -- Positioning Speed:"X" & "Y" axis 262 FPM (80 MPM), "Z" axis 98 FPM (30 MPM); "X" axis uses a helical rack & pinion system, "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides & ways & controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Work Table:Phenolic "MATRIX" grid vacuum table for FT "Nesting" or single part processing using (optional) pods or jigs; (1+1) side pop-up pins for easy material location. -- Boring Unit:(1) 2.5 HP (1.7 kW) - 4,000 RPM motor: (14) independent vertical spindles, (7) in "X" axis & (7) in "Y" axis; (4) horizontal spindles with (1+1) in "X" axis & (1+1) in "Y" axis. -- Machining unit:(1) 16 HP (12 kW) liquid cooled electro-spindle with HSK-F63 adaptor, variable speed from 1,000 - 24,000 RPM; (1) 12-position ride along tool changer for "on the fly" ATC. -- Operator Interface:PC Front End Controls with Biesse "NC 1000" + WINDOWS "XP" operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:(2) 10 HP (7.5 kW) BUSH vacuum pump; original manuals & documentation; safety fencing & perimeter devices. -- Actual Model is Biesse Rover B 7.65 R FTK.

BIESSE ROVER 20 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working field: "X" Axis 113.9" (2,893 mm); "Y" axis 37.4" (950 mm); "Z" axis stroke is 3.9" (100 mm), max. panel thickness 2-1/2" (65 mm). -- Positioning Speed:"X" Axis at 246 FPM (75 MPM); "Y" axis 147 FPM (45 MPM); "Z" axis 49 FPM (15 MPM)."X" Axis moves on high precision prismatic guides and ground helical rack; "Y" & "Z" axis via hardened ground ball screw. -- Worktable:(6) Pneumatically locked & manually positioned panel supports with (2) vacuum cups each.(2) Working zones with: (6) Pneumatic backstops; (2) pneumatic side & (2) center stops; stops raised & lowered automatically by start/stop of machining cycle. -- Boring Unit:(1) 2.3 HP - 5,135 RPM Motor; (10) vertical spindles independently operated with (6) in "X" axis & (4) in "Y" axis.(6) Horizontal spindles: (2 +2) in "X" Axis & (1 + 1) in "Y" axis; 2-1/2" (65 mm) max. boring depth.(1) "X" Axis grooving saw with: 120 mm Dia. blade - 5,200 RPM. -- Machining: Equipped with: (1) 9 HP (6.6 kW) Air-cooled "Quick Change" electro spindle with ISO 30 adaptor.Router is driven by: 10.2 HP (7.5 kW) Inverter for variable speed from 1,000 - 24,000 RPM; RH & LH rotation.(1) 3-Position automatic tool changer mounted at the back of the machine for "on the fly" ATC. -- Operator & Machine Control: Separate Control Console with: CNi "NC 410" Operating System housed in air-conditioned cabinet.8" LCD Monitor: Displays programming graphics, numerical & function keyboard; 512 KB RAM memory; (1) "UPGRADED" USB drive.RS-422 Serial port for PC and RS-425 port for inverter connection; EPROM for machine data & subroutines; machine runs production programs while programming and editing. -- Complete with:Stabilized autotransformer for voltages between 200 - 600 Volt 50/60 Hz; (1) 100 cbm/Hr Vacuum Pump; triple photocell barrier; assortment of misc. parts and tooling; Users operator/maintenance manuals & backup disks. -- Actual Model is: BIESSE - ROVER 20.

BIESSE ROVER K 1532 CNC MACHINING CENTER (W/ATC & "C" AXIS): -- Specifications:"BRIDGE GANTRY" machine with a working field in "X" axis 126" (3,200 mm), "Y" axis 61" (1,560 mm), max. material thickness 6" (165 mm). -- Positioning speed:"X" Axis 279 FPM (85 MPM), "Y" Axis 196 FPM (60 MPM), "Z" axis 65 FPM (20 MPM). -- Work Table:(8) "ATS" Panels supports with lifting rails for heavy pieces; (4) "ATS" vacuum pods with universal clamping systems on each panel support.BIESSE "Set Up Assist" & digital readouts for pod & rail placement.(2) Independent working areas with (8) pneumatic back stops, (2) pneumatic side stops & (2) pneumatic central stops. -- Boring Unit:4 HP (3 kW) motor with variable speed from 1,500 - 7,500 RPM;"BL 30" Boring head with (20) "Quick Change" independent vertical spindles, (9) spindles in "X" axis & (11) spindles in "Y" axis;(8) Horizontal boring spindles with (2+2) in "X" axis & (2+2) in "Y" axis;(1) "X" axis grooving saw with 120 mm dia. blade. -- Machining:(1) 17 HP (12.6 kW) electro-spindle router with HSK F63 adaptor, variable speed from 3,000 - 24,000 RPM.Motorized dust deflector shield & 6-position adjustable dust suction hood,(1) NC controlled "C" axis for 360° horizontal processing.(1) 16-position ATC tool plate mounted on board the "X" axis at the rear of the machine. -- Operator & Machine Control:PC Front End with Biesse "BH 660" + Biesse "bSolid" + Windows "7 WRT" operating system,15" Flat screen monitor, full standard keyboard & mouse, 1.44MB & CD ROM disk drives for data entry,RS 232 & USB ports, Ethernet connection, specific function controls & internet trouble shooting capabilities.Electronics are mounted in an air conditioning & dust free environment control cabinet. -- Biesse "bSolid" is a 2D/3D Cad/Cam software program that supports the performance of any machining operation thanks to vertical modules designed for specific manufacturing processes.Planning with "bSolid" takes just a few clicks & has endless possibilities; "Real-Time" simulation allows the operator to visualize the piece prior to processing, it provides virtual prototyping of the piece to avoid collisions & ensures optimal machine performance. -- Complete with:(1) 250 m³/Hr Vacuum pump; Hand-held "Remote Control" pendant for immediate operator control; LED bar with (5) colors that show the machine's status in "Real-Time".Safety fences, safety bumpers, safety photocells & safety mats; scrap conveyor; original documentation + user & maintenance manuals, wiring diagrams and operation of Numerical Control. -- Actual Model is BIESSE ROVER K 1532 G VS2

BINKS - COMET 3, ...Paint PumpMounted on a roll-around cart.

Infra Red heating unit designed to be used over a conveyor (not included). Currently set up to roll a shop cart under to assist us in some finishing processes. This is a two zone unit with an overall heating area of 56 sq ft. between the two infrared panels. Each section of infrared panels is 4'x7' allowing you an array of options to meet your needs. They do however, get controlled off the same control panel. --Unit has a mechanical percentage timer in control cabinet that is used to cycle power on and off as a means to control temperature. Controlling the distance from emitters to work surface is your other form of temperature control. The patented Black Body emitter consists of a serpentine configuration of NiChrome wire embedded in a refractory pad that is 12 inches square and approx.3/8" thick and coated with a high-emissivity black coating. -- Unit is complete and will need some retrofitting to meet your specific requirements.

BLACK BROTHERS - Cold Press Laminating Line (Complete)with: BLACK BROTHERS - APP PL: 5 x 12, 50 PSI End-Loading Fixed Opening Air Pod PressCurrent Line Setup: Infeed Scissor Lift; Panel Pusher; Panel Cleaning Brush; Glue Spreader; Stack building Scissors Lift; Laminate Rack over Conveyor; Stack Staging; Press Loading Conveyor; Cold Press. -- Station 1: Pneumatic Panel Feeder Panel Pusher feeds individual panels from side loaded (w/Forklift) Scissor Lift into Panel Cleaner. Photoelectric eye activates arm that pushes panel into Panel Cleaner. Pusher Arm: Feed panels into machine on demand. Switch: Remote mounting. Pass Line: 44"; 24" Stroke with 4' of adjustment: Feeds panels from 1/2 thickness, up to 250#, in lengths of 8', 10', or 12'; Controls on (Left or Right). NEMA 12 Enclosure with main power disconnect switch and over-current protection: 230 or 460 Volt; 3 Phase, 60 Hertz, 24 VDC Control Circuits. Dual Limit Switch Arrangement: Controls the Scissors Lift with "hand/auto" selector and a Barrier Guard to prevent double boardfeed. -- Station 2: Scissors Lift 36" Vertical travel foot operated raise/lower switch. 48" x 120" Plain deck with: 6,000 Lbs Capacity. Pin adjustable Edge Guides, mounted on SL and Anchor Clips for mounting. Transverse Conveyors with: Air brake to allow loading or unloading from side. -- Station 3: MIDWEST AUTOMATION - PC160: Panel Cleaner 63" Working width capacity; (2) spiral type cleaning brushes; 0" - 3" thickness opening; single end adjustment with roll opening (scale-type) indicator. Variable feed speed: 30 - 150 FPM with 1 HP - 1,725 RPM Drive; (2) 6" dia. infeed and (2) 6" dia. outfeed rolls; variable brush speed with 3 HP motor. - Equipped with: All guards, dust hoods, and magnetic starter. -- Station 4: BLACK BROTHERS - 775: Top & Bottom Adhesive Spreader; 68" width capacity Application: Apply water-based adhesive to top & bottom particle board, plywood, and MDF substrate. Upper Elevator: 0 - 4-1/2" Opening. Roll Opening Indicator: Shows opening between rolls in 0.001 increments. Riser Base: 44" Pass line height. Caster Arrangement: (4) Plain rigid casters with guide track and lock. Coating Rolls: (2) 7-3/4" Max. O.D.; 60 Durometer - Neoprene/SPR; Grooved: 16 TPI. Doctor Rolls: (2) 7" Max. O.D.; 100 Durometer - Ebonite; ground smooth single hand wheel Doctor Roll adjustment with mechanical digital readout. Electrical Interlocks on nip guard(s). NEMA 12 Enclosure with: Main power disconnect switch and overcurrent protection. 1-1/2 HP, Single speed with: 3" Reverse lockout 88 FPM. Pivoting Infeed Table. Operating hand wheels & controls: Parallel to the direction of flow on the right; motor on left end. Operating control bars. Liquid level control: FIBER OPTIC. Machine mounted double-diaphragm Pump: l" Ports

BLACK BROTHERS - 22-D-875-32, ...Top Only Glue Spreader.Capacity 32" Working width. -- 8-3/4" Dia. Rubber roll -- 6-1/2" Dia. chromed steel doctor rolls. -- Top elevator opening w/Readout -- Constant pass line: 36-3/4" -- Outfeed roller conveyor -- 7.5 HP MotorComplete with:1 Spare rollerNOTE: Machine is currently wired for 220v

BLACK BROTHERS 22-D-875-74, Wide Format (74") Top & Bottom Glue Spreader74" Working width, 8-3/4" dia. grooved rubber covered applicator rolls, 6-1/4" chrome plated doctor rolls -- Complete with: Push button magnetic starter, safety guards, and safety reversing bar. -- Top elevator style glue spreader, constant pass line --Main Motor 1HP, 3ph --Feed speed 88FPM --Thickness adjustment via manual hand crank

BLACK BROTHERS 22-D-875-74, Wide Format (74") Top & Bottom Glue Spreader74" Working width, 8-3/4" dia. Grooved rubber covered applicator rolls, 6-1/4" hard rubber covered doctor rolls --Main motor 1.5hp -- Bottom roll adjustment -- Complete with: Push button magnetic starter, safety guards, and safety reversing bar.NOTE: Currently wired for 460v

BLACK BROTHERS 1205 Air Pod Press Overall 146" x 62" platen dimension with (3) individual top platens, side loading on 146" side. -- Motorized vertical daylight up to 30" -- (3) Individual platen zone controls for up to 5’ x 12’ press area, (3) 4’ x 5’, pneumatic top pressure via (48) 5-1/2" stroke air pods producing a maximum 50 PSI specific pressure. -- Air-assisted pop-up rollers in bottom platen for loading-and-unloading, pass line height for loading is 29".

Black Brothers 22D glue spreader Max working width 50"Max working thickness 3" 1/2 Hp, 230/460 volt three phase drive motor Table passline height 40" 7-1/4" diameter x 50-1/2" long top and bottom chrome doctor rollers 9" diameter x 50-1/2" long top and bottom rubber covered applicator rollers (Please note that the top doctor roller and top applicator roller is segmented) 11-3/4" long and 38" long top roller segments

BLACK BROTHERS 22D-875-62 Top & Bottom Glue SpreaderSpecifications: -- 62" Working width, 8-3/4" dia. Grooved Neoprene applicator roll with 24 TPI, 6-1/2" dia. smooth Neoprene doctor roll -- Lower elevator opening 0" - 4-1/2", -- Single speed of 88 FPM with 1.5 HP drive; -- NEMA 12 electrics. -- Complete with: Push button magnetic starter, safety guards, all warning labels.
