Woodworking Equipment For Sale

SCHELLING FM-430/410 CNC Front Load Panel SawSpecifications & Features: 169" (4292 mm) Cutting length & 165.3" (4,200 mm) pull back, 3.75" (95 mm) max. saw blade projection; 25 HP (19 kW) 4,100 RPM main & 3.4 HP (2.5 kW) 5,600 RPM scoring motor. -- Equipped with: Variable saw carriage travel speed from 0 - 278.8 FPM (85 MPM), constant return of 278 FPM (85 MPM). -- Electronically controlled overhead program fence with rack & pinion driven on both sides; forward speed from 0 - 278 FPM (85 MPM), return speed of 278.8 FPM (85 MPM); equipped with (8) gripper clamps (open up to 5" (130 mm). -- Features: SCHELLING "COMPOSER" IBM-AT Compatible Computer Control; aftermarket color monitor (displays cutting dimensions and patterns w/moving graphics) , self-diagnostic, data input by keyboard; onboard optimization program. -- Complete with: 2-3/4" to 87" (2,200 mm) Long side/cross-cut aligning zone, (1) aligner in front & (1) behind the cut line. -- (3) Front mounted air float tables for moving panel from rip section to the cross-cut section, (2) movable and (1) fixed; each with their own blower. -- Rear of machine fully enclosed for safety with man-height sheet metal panels & wire screen windows. T

Schuetz Tool Bladder Press Specifications: (2) Shuttle tables, approx. 55” x 106” press capacity. Hot air design with 3mm silicone membrane to press veneer into profile, typical cycle time 3 minutes using proper glue that sets at 200°F. Can use PVA which would extend cycle time to approx. 15 > 45 minutes depending on the actual glue mix used to achieve 80%+ cure strength. Includes Hydraulic Pump. SPECIAL NOTE: Fully operational, however, need 4 or 5 heating rods replaced, new rod parts are included for you to install ( don't have the capability to remove them). The current average operational temperature is 150° F. NOTE: Above specs are taken from literature and thought to be accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

--In Auction--Starting bid: $100-- Schuetz Tool Bladder Press Specifications: (2) Shuttle tables, approx. 55” x 106” press capacity. Hot air design with 3mm silicone membrane to press veneer into profile, typical cycle time 3 minutes using proper glue that sets at 200°F. Can use PVA which would extend cycle time to approx. 15 > 45 minutes depending on the actual glue mix used to achieve 80%+ cure strength. Includes Hydraulic Pump. SPECIAL NOTE: Fully operational, however, need 4 or 5 heating rods replaced, new rod parts are included for you to install ( don't have the capability to remove them). The current average operational temperature is 150° F. NOTE: Above specs are taken from literature and thought to be accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

Tubeless Vaccum (TNV) Electro-Spindle with HSK63F quick release Toolholder Rotation speed 600-2400 rpm Air Cooling by rear electrofan Static Inverter Centralized dust collection system with automatic blast gates

SCM - S520 E, ...Planer Specifications: -- 20" Width cap.; 9 HP main motor; 4-3/4" dia. 4-knife TERSA cutterhead at 4,500 RPM. -- 1/8" - 9-1/4" Powered opening with digital readout for fine adjustment; max. depth of cut 5/16"; 10" min. length of workpiece. -- (4) Feed speeds: 20 - 33 - 43 & 56 FPM; table size 20-3/4" x 39".Equipped with: -- Chip breaker; sectional grooved infeed & solid outfeed rollers; (2) adjustable bed rollers. -- Complete with: Magnetic starter & shaving hood.

2008 SCM Morbidelli Universal 3612

1998 SCM TECH 30 Super Router

SCM - S 52, ...Straight Knife Planer20" Width cap.; knife cutterhead; 9 HP main motor (approx.); 1/8" to 9-1/4" motorized opening with mechanical digital readout; max. depth of cut 5/16"; 10" min. length of workpiece; (4) feed speeds at: 21 - 32 - 42 & 55 FPM; table size: 20-1/2" x 33-1/4". -- Equipped with: Chip breaker; sectional grooved infeed & solid outfeed roller.

SCM S 630 PLANER WITH TERSA HEADSpecifications: -- 24" Width cap.; 12 HP main motor, 2 HP feed motor; 4-3/4" dia. with reversible knife TERSA Planer Head rotates @ 4,500 RPM; -- 1/8" - 11-3/4" Thickness opening via motorized bed with LED readout for fine adjustment. -- Max. depth of cut 5/16"; 10" min. length of work piece; variable infeed speed from 20 - 56 FPM.Equipped with: -- 20-3/4" x 39" Cast iron table, sectional chip breaker, sectional grooved infeed & solid outfeed rollers, adjustable bed rollers. -- neoprene out feed rollersComplete with: -- Magnetic starter and dust hood w/6" dia. dust outlet.Owner states: Condition- like new 24" thickness planer- third owner in a one man shop. Machine has seen very few hours of operation.

SCM PRATIX S-15-B FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:Single 5' x 12' traveling "Bridge Gantry" and stationary aluminum dual vacuum table with a MATRIX square grid pattern for fixturing parts.Grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining".(8) Part location pop-up pins mounted on the table perimeter. -- Working field:"X" Axis is 145.11" (3,686 mm); "Y" axis is 61.2" (1,555 mm); "Z" axis stroke is 9.8" (250 mm); max. material thickness 4" (100 mm). -- Positioning Speed:"X" & "Y" Axis 115 FPM (35 MPM); "Z" axis at 82 FPM (26 MPM); closed loop AC Servo drive system.High precision "Rack & Pinion" system in "X" & "Y" axis & ground ball screws "Z" axis; all axes ride on extra large precision profile linear guideways. -- Boring Unit:3 HP (2.2 kW) - 6,000 RPM motor; (7) vertical spindles on 32 mm centers, (5) in "X" axis & (2) in "Y" axis. -- Machining:(1) 9 HP (6.7 kW) Air-cooled electro spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 14-Position ATC tool rack mounted to the machine base. -- Operator & Machine Control:PC Front End with: "XILOG Plus" + Windows "XP Pro" Operating System; 17" high resolution LCD; ergonomic keypad.USB Ports, serial ports RS-232 & RS-242 & Ethernet adaptor; programs can be transferred via disk or downloading by wire is possible.All computer components are mounted on a mobile stand.XILOG Plus Offers: Incredible list of functions from: (a) Auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- Additionally equipped with:Onboard mini-CAD with built-in programming for writing circles, ellipses & angles with only a few keystrokes; Onboard cycle optimization, onboard calculator, mirror-imaging, and repeat imaging. -- Complete with:(1) 300 m³/Hr Vacuum Pump; external transformer 208/230/480 Volt; safety enclosure around the spindle carriage; tool length probe sensor; manual centralized lubrication.Includes: (1) Universal Remote Pendant, 7" color display allows for the effective management of all machine functions from manual Jog Mode to loading & execution of a program.The pendant is fitted with a USB port to allow quick load & setup of new programs; safety "bump-stop" bumpers; emergency stop rope & manuals. -- Actual Model is SCM - PRATIX S-15-B.

Worktable dimensions: 145? x 61? Z -Axis stroke: 9.84? Spindle speed: 24,000 RPM Electrospindle (S1/S6 rating): 7.5 HP / 9HP Tool Changer: 10 position Spindle Taper: HSK 63 Boring Block (7) Spindles: 6,000 RPM Maximum positioning vectorial speeds: X/Y axis: 115 feet/minute Electrics: 208/230/460 volts, 3-phase, 60 cycles EQUIPPED WITH: Windows Based Operating system 17” Flat Panel Monitor Remote Pendant with 7? Display 7-Spindle Boring Block Touch Probe Spindle Air Blowers Built In Vacuum Pumps- 2 Zones

SCM Minimax T-50 Tilting Spindle Shaper -- Specifications: -- 1-1/4" Dia. interchangeable spindle tilts -5° to +45°, -- 6.6 HP motor; 3-1/2" cap. under nut, (4) spindle speeds of 1,700 - 4,000 - 7,000 & 9,000 RPM. -- Table size 18" x 43" with adjustable side extension tables; 3" - 5" - 7" & 8" table insert openings -- 4-1/2" max. spindle height above table -- 2" max. tooling retraction under table with 7" max. tooling dia.; working height 37".Equipped with: Outrigger Sliding Table, micro-adjustable fence, spindle lock, magnetic starter w/overload protection, reversing switch, and 4-3/4" dia. dust outlet. Includes: Several New Cutter-heads

SCMI OLIMPIC S1000 T-ERL EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) -- Specifications:Edge Capacity, 0.4 to 15 mm (0.016 to 5/8") for strip feeding. -- Panel Capacity, min. width 50 mm and 140 mm min. length, (2.0" and 5-1/2"). Panel thickness min./max. 8 - 60 mm (3/8" - 2-3/8"). Equipped With: Adjustable In-feed Fence: Manually pre-set with digital indicator and pneumatic panel spacing device. -- Pre-Milling Station, RT-E: Spindles 2 x 5.25 HP, 12,000 RPM, (1) with PLC controlled jump action and manual digital indicators positioning and Diamond Cutter-heads. -- Anti-Adhesive Spraying System: Top/Bottom, positioned prior to the Pre-Milling Unit, it prevents glue buildup on the work-piece surfaces. It consists of (2) independent spray nozzles, and a tank for anti-adhesive liquids. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station, Vc/1000: For EVA (Hot Melt) with Teflon coated glue tank and quick disconnect to change glue tanks fast if needed. Heat-up time approx. 10 Min. -- Pressure Section: Servo motor positioning, (4) pressure rollers, first larger, Teflon coated and powered. Workstations: End Trimming Station K-SEL: Front & rear 2 x 0.5 HP, 12,000 RPM motors mounted on THK guides, swivels 0ø - 15ø, rapid set up between straight and angled cutting with the automatic swivel cylinder. -- Flush Trimming Unit, Rsp: Top/Bottom, 2 x 1.5 HP, 12,000 RPM with 2 pre-set pneumatic positions, flush and overhang, remote pneumatic in/out positioning. -- Bevel/Radius Trimming Unit, Ri/S: Programmable, servo motor positioning, 2 x 1.0 HP - 12.000 RPM motors for change-over on the fly. -- Corner Rounding / Trimming Unit, Round-K: For additional top & bottom trimming of linear an/or vertical leading & trailing corner when edgebanding all (4) sides, 2 x 0.8 HP - 12,000 RPM motor. Comes with (2) pre-set pneumatic positions to allow to go from thick to thin pvc automatically. -- Profile Scraping Unit "RAS/1000": Top/Bottom with (2) indexed manual pre-sets. Large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue Scraping Unit, "RCA/2c": Top/bottom flat glue scraper with pneumatic positioning through controller and air-blow off nozzle to keep the knifes clean. -- Buffing Unit "SPN": Top/bottom, oscillating 2 x 0.25 HP - 3,000 RPM motors, tilting up to 12°. -- Hot Air Unit: Single blower with adjustable heat range and directional heat shield for top/bottom coverage. Restores color luster on thick pvc edging materials that may be lost during the edge scraping process.Controls: -- Startouch Controller, 12" color touch screen, swivels 270° at in-feed of machine. Capable to store (100) programs, (6) at the touch of a single key. Graphical display of all working units. Tracks production data, diagnostic information and monitors maintenance schedules. Complete With & Features: -- Feed-speed, 40/60 FPM, 1 x 2.5 HP feed drive motor, 200 Hz frequency inverter for all

SCM PRATIX S-12-B FLAT TABLE MACHINE (W/ATC/BORING): -- SpecificationsSingle 4' x 8' traveling "Bridge Gantry" and stationary aluminum dual-vacuum table with: "MATRIX" square grid pattern for fixturing parts.Grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil-boards for "nested base machining".Part location pop-up pins mounted on the table perimeter. -- Working field:"X" Axis is 98" (2,486 mm); "Y" axis is 49.4" (1,255 mm); "Z" axis stroke is 9.8" (250 mm); max. material thickness 5.9" (150 mm). -- Positioning Speed:"X" & "Y" Axis 115 FPM (35 MPM), "Z" axis at 82 FPM (26 MPM); closed loop AC Servo drive system.High precision "Rack & Pinion" system in "X" & "Y" axis & ground ball screws "Z" axis; all axes ride on extra-large precision profile linear guideways. -- Boring Unit:3 HP (2.2 kW) - 6,000 RPM motor; (7) vertical spindles on 32 mm centers, (5) spindles in "X" axis & (2) spindles in "Y" axis. -- Machining:(1) 9 HP (6.7 kW) Air-cooled electro-spindle with HSK F63 adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 7-Position ATC tool rack mounted to the machine base RH side. -- Operator & Machine Control:PC Front-End with: "XILOG Plus" + Windows "XP Pro" Operating System; 17" high resolution LCD; ergonomic keypad.USB Ports, serial ports RS-232 & RS-242 & Ethernet adaptor; programs can be transferred via disk or downloading by wire is possible.All computer components are mounted on a mobile stand.XILOG Plus Offers incredible list of functions from: (a) Auto-diagnostic to (z) zooming; controlled acceleration & deceleration, encoder feedback, dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- Additionally Equipped with:Onboard mini-CAD with built-in programming for writing: Circles, ellipses & angles with only a few keystrokes.Onboard cycle optimization, onboard calculator, mirror-imaging, and repeat imaging. -- Complete with:(2) 150 cbm Vacuum Pumps; safety enclosure around the spindle carriage. Tool length measuring device.(1) Universal remote Pendant; 7" color display allows for the effective management of all machine functions from manual Jog Mode to loading & execution of a program. The pendant is fitted with a USB port to allow quick load & setup of new programs.Safety "bump-stop" bumpers; emergency stop rope, doc's & manuals. -- Actual Model: SCM PRATIX S-12-B

SCMI Compact 22/S 4-Head Moulder4-Head (B-R-L-T), working cap. 8-5/8" x 4-11/16". -- Head sequence: Bottom 5.5 HP motor, right/left 7.5 HP motor and top 5.5 HP motor. -- Spindle dia. 35 mm with cutterhead speed of 6,000 RPM. Variable feed speed 14 to 72 FPM with a 2 HP motor. -- Complete with: 2M (6'6") Infeed straightening table, sound insulation hood, dust hoods, and Owner's Manual.

SCM OLIMPIC K230-EVO SINGLE SIDED EDGEBANDERSpecifications: --0.4mm to 3mm Edge thickness, Panel thickness 8mm to 50mm (3/8" to 1-15/15"), minimum part width 110mm (4.33"), minimum part length 160mm (6.30"). -- Equipped with: -- 1.5 Kg Teflon-coated glue pot, glue roller application system complete w/automatic recycling device for unused glue, digital thermostat adjustment for temperature control. pneumatic guillotine, 3-Roll pressure unit w/pneumatic controls for all pressure rollers. -- Automatic strip & coil feed magazine --Workstations: --÷Double motor front & rear (0.4 HP - 12,000 RPM motor ea.), tilts 0° - 15°, end trimmers mounted on 45° THK guide. --Top & bottom flush & bevel trims with quick release mount and plug-in motors for quick tooling changes (0.7 HP - 12.000 RPM motor ea.), bevels 0° - 15° with precision digital indicators for quick setup. --Top & bottom scraping unit w/pneumatic positioning from the control panel. -- Top & bottom buffing unit (0.25 HP - 2,800 RPM motors). 29.5FPM Fixed feed speed, 0.75 HP feed drive.

SCMI - K201 HFE: Single Sided Edgebander1/8" Max. edge cap.; 1-1/2" max. panel thickness; semiautomatic strip & coil feed magazine (manual single strip feed); Teflon coated glue pot w/fast 8-Minute heat up time; 1.2 mm cap. guillotine. -- Workstations: Single motor front & rear end trim; 0.8 HP - 10,000 RPM motor; top & bottom flush trims, 0.8 HP - 27,000 RPM ea. motor; straight or 12° bevel cutters. -- Top & Bottom buffing unit, 0.25 HP - 2,800 RPM motors; 25 FPM fixed feed speed with 0.8 HP drive. -- Complete with: Sound enclosure, frequency converter, and used tooling.

SCM - OLIMPIC K 201 HFA, ...Automatic Compact Edgebander with: 3 mm Max. coiled edgebanding thickness & High Frequency motorsSpecifications: -- Edgebanding thickness cap. (for both coil & strip): 0.4 - 3 mm (0.02" - 0.19"). -- Min. panel length for coiled edges (min. width 200 mm) 140 mm (5.51"). -- Min. panel width for coiled edges: 65 mm (2.56"). -- Panel thickness: 8 - 40 mm (0.31" - 1.57"). -- Feed speed:9 MPM (29 FPM).Equipped with: -- Automatic adjustment of all units when panel thickness is changed. -- 20" Dia. coil table. -- Automatic coil feed magazine; manual strip feed. -- Teflon-coated glue pot. -- 1.2 mm (0.05") Cap. guillotine. -- Eye-level control with: GEFRAN "1000" LED Temperature controller. -- Adjustable feet.Workstations: -- Single-motor end trimming unit with: (1) 0.19 kW (1/4 HP) - 12,000 RPM High-frequency motor & copying device. -- Top & bottom flush trimming unit with: (2) 0.35 kW (1/2 HP) - 12,000 RPM high-frequency motors, and front & vertical copying devices.

SCM - ACCORD 25 FX-M: CNC Machining Center (w/ATC) -- Specifications4' x 20' Aluminum "MATRIX" grid 2-zone vacuum table. -- Working Capacity"X" Axis 242.9" (6,170 mm); "Y" axis 51.9" (1,320 mm); "Z" axis stroke 17.3" (440 mm); 9.8" (250 mm) max. material thickness. -- Positioning speed"X" & "Y" Axis 197 FPM (60 MPM); "Z" axis is 82 FPM (25 MPM).Movement control: by AC Brushless motors & YASKAWA drives; high precision rack & pinion system for "X" & "Y"; precision ball screw for "Z" axis.Working unit travels on prismatic guideways & sliding blocks with: Preloaded recirculating balls; NC controlled automatic lubrication system. -- Worktable"FX-MATIC" Aluminum "MATRIX" Grid 2-zone vacuum table with: (6) Adjustable pneumatic pop up reference stops; can be positioned on the perimeter of the worktable. -- Boring Unit3 HP (2.2 kW); Boring block with: (8) Independent vertical units; variable speed from: 2,000 - 8,000 RPM; (4) bits in "X" axis & (4) bits in "Y" axis.(1) NC Controlled "X" Grooving saw: Max. 125 mm dia. blade(4) Horizontal Boring units with: (2 + 2) In "X" axis; (2 + 2) in "Y" axis. -- Machining Units(1) 16 HP (12 kW) Electrospindle router with: HSK F63 Adaptor; rotation speed: 600 - 24,000 RPM.Constant torque achieved at: 12,000 RPM; Router controlled by: 12 kW Inverter for stepless speed & rapid shutdown rotation.(1) Rapid 16-position ATC plate mounted at the back of the "Y" axis carriage for: "On the fly" ATC; center distance between tools: 104 mm (4.13"); max. tool dia.: 300 mm (11.18"); max. tool weight/tool: 8 kG (17.6 Lbs). -- Operator InterfacePC Front with: SCMI "Xilog MAESTRO" + "eye-M" + Windows "10-IOT" 64-bit Operating System. 21" Full HD, LCD Display; ergonomic industrial keyboard & mouse; central USB connection; RJ45 Ethernet port for possible link to an office PC. "Xilog MAESTRO" + "eye-M" Software: Full real time 2-3D graphic interface for programming assistance & error diagnostics. -- Complete with:Tool Touch-off Probe; "TECPAD" handheld mobile console with 7" Color display; "Pro-Space" safety system with photocell barriers & bump-stop; safety fences; 208 / 230 / 460 V multitap autotransformer for various voltages. -- Actual Model: SCM ACCORD 25 FX-MNOTE: No Vacuum Pump is included with this machine.

SCM - ACCORD 25 FX -M: CNC Machining Center (w/ATC) -- Specifications4' x 20' Aluminum "MATRIX" grid 2-zone vacuum table. -- Working Capacity"X" Axis: 242.9" (6,170 mm); "Y" axis: 51.9" (1,320 mm); "Z" axis stroke: 17.3" (440 mm) & 9.8" (250 mm) Max. material thickness. -- Positioning Speed"X" & "Y" Axis 197 FPM (60 MPM), "Z" axis is 82 FPM (25 MPM).Movement controlled by: AC Brushless motors; YASKAWA drives; high precision rack & pinion system for "X" & "Y"; precision ball screw for "Z" axis.Working unit travels on Prismatic guideways & sliding blocks with: Preloaded recirculating balls; NC controlled automatic lubrication system. -- Worktable"FX-MATIC" Aluminum "MATRIX" Grid 2-zone vacuum table with: (6) Adjustable pneumatic pop up reference stops; can be positioned on the perimeter of the worktable. -- Boring Unit3 HP (2.2 kW) Boring Block with: (8) Independent vertical units; variable speed: 2,000 - 8,000 RPM; (4) bits in "X" axis; (4) bits in "Y" axis.(1) NC Controlled "X" Grooving saw: 125 mm Dia. blade.(4) Horizontal Boring units: (2 + 2) in "X" axis' (2 + 2) in "Y" axis. -- Machining Units(1) 16 HP (12 kW) Electrospindle router with: HSK F63 Adaptor; rotation speed: 600 - 24,000 RPM.Constant torque achieved at 12,000 RPM: Router controlled by 12 kW inverter for stepless speed & rapid shutdown rotation.(1) Rapid 16-position ATC plate: Mounted at the back of the "Y" axis carriage for "on the fly" ATC; center distance between tools: 104 mm (4.13"); max. tool dia.; 300 mm (11.18"); max. tool weight/tool: 8 kG (17.6 Lbs). -- Operator InterfacePC Front-End: SCMI "Xilog MAESTRO" + "eye-M" + Windows "10-IOT" 64-bit Operating System. 21" Full HD; LCD display; ergonomic industrial keyboard & mouse; central USB connection; RJ45 Ethernet port for possible link to an office PC. "Xilog MAESTRO" + "eye-M" Software offers full real time 2 - 3 D graphic interface for: Programming assistance & error diagnostics. -- Complete with:Tool Touch Off Probe; "TECPAD" handheld mobile console; 7" color display; "Pro Space" safety system with: Photocell barriers & bump stop; safety fences; 208 / 230 / 460 V Multi-tap autotransformer for various voltages. -- Actual Model: SCM - ACCORD 25 FX-MNOTE: No Vacuum pump is included with this machine
