Woodworking Equipment For Sale

MASTERWOOD PROJECT 313 CNC MACHINING CENTER (W/ACT/BORING): -- Specifications:Working Capacity:"X" Axis 3,080 mm (121"), "Y" axis 1,100 mm (43") width; -- Positioning Speed:Programming speed in X-axis 197 FPM (60 MPM), Y-axis 162 FPM (49 MPM), Z-axis 58 FPM (18 MPM). -- Boring unit:(13) independent vertical spindles, (9) in X-axis, (5) in Y-axis; (4) horizontal spindles with (1 + 1) in X-axis for edge boring in the left- & right-hand panel edges. -- Machining:(1) 7.5 HP (5.6 kW) high speed router (1,000 - 24,000 RPM) by frequency inverter; 1.5 HP (1.1 kW), 6,000 RPM grooving saw with manual rotation for X-axis or Y-axis; -- Work Table: (6) moveable support rails with (2) vacuum cups ea., double zero settings, (6) pneumatic backstops and (2) pneumatic side stops creating (2) working zones. -- Operator & Machine Control:TECNOSUD "K68800" Microprocessor control for (3) axis, lineal, circular, and helical interpolation. Equipped with 14" color video graphic monitor, keyboard for data entry, 1.44 MB floppy disk drive, 64K RAM, RS-232 for possible connection to office PC, all mounted in separate free-standing control cabinet; features to run CPL/Parametric "TRIG" programming and "Spline" CAD/CAM. -- Complete with: Dual zone vacuum pump. Ontario Hydro approved electrics. -- Actual Model is MASTERWOOD PROJECT 313

Madison 202 Straight Line Rip Saw

Mattison 404 Rip Saw Seller was using until they upgraded to a gang rip. Ready to ship.

The Rip Saw is still in good running condition and still in use.

MATTISON - 404, ...Straight Line Rip SawSpecifications: approx.20HP - 3,600 RPM Direct drive arbor motor; 14" dia. max. saw blade cap. (9" smallest dia.), 1-1/2" dia. arbor; 4" thickness capy. -- Table size: 65" x 77" Long. -- 30" Distance from saw to left edge of table. -- 24-1/4" Between saw & column and 24" rip distance to right of gauge. -- Top roller holddown with 7-1/2" shortest stock handled under (1) roll, 15" under (2) rolls.Equipped with & Features: -- Overhead cutting design with single cast chain links. -- Chain with automatic oil lubrication. -- 2 HP Feed motor with (2) feed speeds of 50 & 100 FPM

MATTISON 229 Push Feed Moulder4-Head Push Feed Moulder, 4" x 10" capacity. -- Head sequence: 10 HP Top head, 10 HP left head, 10 HP right head, 10 HP bottom head. -- 20 HP feed motor. -- 2-1/8" dia. top and bottom spindles; 1-13/16" dia. left and right spindles. -- Includes (6) extra heads that go with the machine.Approximate dimensions of 11 feet long, 4.5 feet deep, and 5.5 feet tall. The machine weight is approx. 5 Tons.

MATTISON Model 228 Push Feed Moulder ( 4 ) HeadsSPECIFICATIONS -- 4-Head -- 16" x 6" width cap. -- Roll FeedHead sequence: --Top 20 HP, left tilting 7.5 HP, right tilting 7.5 HP, bottom 20 HP motor -- 2-1/8" dia. spindles and all heads jointed -- Sectional bed plates.Equipped with & Features -- Assortment of cutter heads -- Tools & wrenches, and factory dust hoods. -- List of heads with the machine :Width Qty2.5 11.5 12 93 34 55 16 28 510 216 1 NOTE : Some spec's have to be verified

Mattison 404 Straight Line Rip 230 Volt 3 Phase 25 HP Total 230/460 Dual Voltage on 20HP Mandrel Motor

MATTISON - 404, ...Straight Line Rip SawSpecifications: -- 15 HP - 3,600 RPM Direct drive arbor motor; 14" dia. max. saw blade cap. (9" smallest dia.), 1-1/2" dia. arbor; 4" thickness capacity. -- Table size of 65" x 77" long. -- 30" Distance from saw to left edge of table. -- 24-1/4" Between saw & column; 24" rip distance to right of gauge. -- Top roller holddown with 7-1/2" shortest stock handled under (1) roll; 15" under (2) rolls.Equipped with & Features: -- Overhead cutting design with single cast chain links. -- Chain with automatic oil lubrication. -- 2 HP Feed motor with (4) feed speeds. -- (2) Carbide rip blades.NOTE. Comes with a 208 Volt Transformer.

MATTISON - 404, ...Straight Line Rip SawSpecifications: -- 15 HP - 3,600 RPM Direct drive arbor motor; 14" dia. max. saw blade cap. (9" smallest dia.), 1-1/2" dia. arbor; 4" thickness capacity. -- Table size: 65" x 77" long. -- 30" Distance from saw to left edge of table. -- 24-1/4" Between saw & column, and 24" rip distance to right of gauge. -- Top roller holddown with 7-1/2" shortest stock handled under (1) roll; 15" under (2) rolls.Equipped with & Features: -- Overhead cutting design with single cast chain links. -- Chain with automatic oil lubrication.. --4-Speed Feed: 62 - 93 - 124, & 186 FPM.

MATTISON - 202, ...Straight Line Rip SawSpecifications: -- 15 HP - 3,400 RPM Saw arbor motor, 9" - 14" max. blade capacity, 1-1/2" diameter arbor, overhead arbor design. -- 4" Max. depth of cut, 13" min. stock length, 24" max. rip capacity to the right of the blade, 77" x 65" table size.Equipped with & Features: --Overhead holddown with: (6) Pressure rollers, (3) front and (3) back; 2 HP feed drive, (4) feed speeds of 56 - 84 - 112 & 168 FPM (fixed at 25 FPM ).

MATTISON - 404, ...Straight Line Rip SawSpecifications: -- 20HP - 3,600 RPM Direct drive arbor motor; 14" dia. max. saw blade cap. (9" smallest dia.), 1-1/2" dia. arbor; 4" thickness capy. -- Table size: 65" x 77" Long. -- 30" Distance from saw to left edge of table. -- 24-1/4" Between saw & column and 24" rip distance to right of gauge. -- Top roller holddown with 7-1/2" shortest stock handled under (1) roll, 15" under (2) rolls.Equipped with & Features: -- Overhead cutting design with single cast chain links. -- Chain with automatic oil lubrication. -- 2 HP Feed motor with (2) feed speeds of 50 & 100 FPM. -- Laser light -- 480V to 240V Transformer -- Comes with some 12" 30 Tooth bladesNote : Seller claims the saw will give a glue line

MATTISON 404 Straight Line Rip Saw;Specifications: --25 HP - 3,600 RPM Direct drive arbor motor; --14" dia. max. saw blade cap. (9" smallest dia.), --1-1/2" dia. arbor; 4" thickness capacity. -- Table size 65" x 77" long. -- 30" Distance from saw to left edge of table. -- 24-1/4" Between saw & column, and 24" rip distance to right of gauge. --Top roller holddown with 7-1/2" shortest stock handled under (1) roll, 15" under (2) rolls.Equipped with & Features: -- Overhead cutting design with single cast chain links. --Chain with automatic oil lubrication. -- 2 HP Feed motor with (4) feed speeds 62, 93, 124, & 186 FPM

Description Mattison "55-F" Turning Lathe - Back Knife 30" Cap. in length and 4" x 4" cap. dia. - Pneumatic feed; rear arbor with cutter-head driven by a 10 HP V-belt motor. Work piece rotation is belt driven by main motor with variable speed gear box, double end drive, mechanical feed of work piece into cutter head. Rear dust shroud with collection outlet.

MATTISON 69-42 MATTI-MAX Heavy Duty Automatic Rotary, high production Turning Lathe.Microprocessor controlled for quality turnings and ease of setup; 42" long turning cap. with rotating rear arbor, 4" x 4" max. and 3/4" x 3/4" min. stock size. -- Drives & Speeds: Equipped with: 20 HP - 2,700 RPM Cutterhead Drive, 2-5/8" dia. arbor with variable speed, 2 - 45 RPM stock-rotational speed via 1.5 HP DC drive (reversing) & self-contained hydraulic unit for precise feed control.. -- Complete With: Automatic hopper feed; MATTI-MAX microprocessor-based PLC controller with keypad entry; machine functions & operations parameters are set directly from the control; RPM of workpiece and feed rate can be programmed to vary during the cut. Matching the feed rate to the stock-rotational speed produces an efficient cut -- Features: MATTI-MAX also allows rough cutting at higher speeds (especially rounding of corners) and fine finish cutting at slower speeds. . Pneumatic tailstock with dual pressure to insure penetration of spur center at high pressure and can be adjusted lower for small dia. turnings. -- Total electrical load 27 Amps.

MATTISON - 69- 54: Automatic Lathe -- 54" Length capacity with working dimensions: 4" x 4" Max. x 3/4" x 3/4" min. -- Hopper feed with: Automatic chucking and pop-up. rest. -- Spindle drive: 25 HP motor; spindle dia.: 2-5/8"; arbor speed: 2,700 RPM. -- Feed rates: 2 - 45 RPM; Variable feed speed and double-end drive.NOTE: Lot of additional knives & heads available at additional cost.

MATTISON - 69-42 MATTI-MAX: Heavy-Duty Automatic Rotary, high production Turning Lathe with Hopper FeedMicroprocessor controlled for quality turnings and ease of setup; 42" long turning cap. with rotating rear arbor; 4" x 4" max. and 3/4" x 3/4" min. stock size. -- Drives & Speeds: Equipped with: 25 HP - 2,700 RPM Cutterhead Drive; 2-5/8" dia. arbor with variable speed. -- 2 - 45 RPM Stock rotational speed with: 1.5 HP DC Drive (reversing) & self-contained hydraulic unit for precise feed control.Complete with: -- Automatic hopper feed; MATTI-MAX microprocessor-based PLC Controller with keypad entry; machine functions & operation parameters are set directly from the control; RPM of workpiece & feed rate can be programmed to vary during the cut.Matching the feed rate to the stock rotational speed produces an efficient cut.Features -- MATTI-MAX Allows rough cutting at higher speeds (especially rounding of corners) and fine finish cutting at slower speeds. -- Pneumatic tailstock with: Dual pressure to ensure penetration of spur center at high pressure and can be adjusted lower for small dia. turnings. -- Total electrical load: 26.5 HP. -- Setup Stand.NOTE: Large quantity of knife & heads available for additional cost.

Mattison 202 Straight Line Rip

Heat treated and dynamically balanced 36" aluminum disc. -- Commercial duty 5 HP motor base mounted with multiple drive belts. -- Heavy cast iron 16" x 46" table w/miter gauge slot. -- Easy precise tilting of the work table with 45° forward and 30° back. -- Rack and pinion adjustment of the table rise & fall and rack and pinion tilting of the table. -- Sanding station is mounted to (4) 3-1/2" heavy columns. -- Heavy bolt-down cast iron base. -- Optional: Motorized table elevation add.....$16, Motorized table elevation with limit switches add....., Electric brake add....., Circular attachment add....., Miter gauge add..... Hoist (chain drive lift for heavy parts) add..... JIL package (oil/dust proof switch components) add.. OPTIONS QUOTED UPON REQUEST.

Heat treated and dynamically balanced 18" aluminum disc. -- Commercial duty 1.5 HP direct drive motor. -- Heavy cast iron 10-1/2" x 24" table w/miter gauge slot. -- Easy precise tilting of the work table with 45° forward and 30° back. -- Rack and pinion adjustment of the table rise & fall and manual tilting of the table. -- Sanding station is mounted to a heavy column. -- Heavy bolt-down cast iron base. -- Optional: Upgrade to a 2 HP motor add.....$240, Miter gauge add.....$270, Rack and pinion movement of the tilt add....$400, Single Phase 1.5 HP motor add.....$120.
