Woodworking Equipment For Sale

C.R. ONSRUD "MATE" 97M12 Series Moving Gantry 4 X 8 CNC Router with ATC: -- Specifications:• 97" x 49" Axes travel in a front-to-back configuration• Onsrud Universal High Flow Vacuum Table System for flow-through spoil boards and dedicated fixtures• (1) vacuum zone with (3) pop-up positioning pins.• (1) Router Head (HSD Mechatronics ES 929 4-Pole Spindle) 12 HP, 24,000 RPM• Fully Programmable, Variable Speed, Reversible, Capable of Routing & Drilling• Spindle adaptor HSK 63 Tooling (4 Tool Holders Included)• (10) Position Fixed Rack Automatic Tool Changer• Approximate Travel: X-Axis 97", Y-Axis 49"• Z-Axis 10" under bridge clearance and 9" Z-stroke.• Machining Speed 1,400 IPM• X & Y Rapid Traverse 2,500 IPM• Integrated Dust Transition System & Dust Extraction Hood• B & R Pendant CNC Controller• Airtech Vacuum Pump 8.6KW (11.5HP), 3,460 RPM

C.R ONSRUD - Pro Series 615DG24H8 "Dual Gantry Series" CNC router with ATC Multi spindles:5' X 51' working table with Multi spindles and Dual Gantry aluminum non-vacuum table. -- Features:Dual Gantry each with (4) spindles, each gantry has its own 12 position hide away tool changer. -- Thermal Heat Treated:Stress Relieved, & Normalized One-Piece, Steel Frame Base, & Thermal Heat Treated, Stress Relieved, & Normalized Steel Bridge; Dual Support, Dual Drive, Moving Gantry, Fixed Table Design with standard 2,500"; per minute machining speed, full 3-D capability, precision ball screw drives for Z & Y axis, case-hardened, precision ground, helical rack & pinion drives for X axis with forced-air continuous rack cleansing system & anti-contamination shielding, precision linear profile guide ways, centralized manual lubrication system, 11-inches of Z stroke - 14"; under bridge clearance & 11"; Z axis stroke.. -- Spindles:Total of (8), (4) per gantry, 18kW, 24HP "QTC" – 24,000 RPM Liquid cooled Long Nose Spindle w/ HSK-63F Spindle Taper, fully programmable & reversible, variable speed, liquid-cooled, quick-change spindle, capable of routing, drilling and ridged tapping, programmable feed rates w/override capability supported with a 12 hideaway tool changer on each gantry total of 24, Automatic Oil Mist Lubricator for each spindle. -- Spindle adjustments:Servo Adjustment of Spindle Center Distance. -- Controls:(2) FANUC 31i-B5 Machine Controller With Integrated PC Interface one for each gantry Fanuc 31i-B5 is Industrial CNC Machine Controller with Fanuc Panel-i HMI w/High Res touch screen. Includes: Network capability, adds Larger FANUC Digital Drives & Servos. Includes Full remote diagnostic troubleshooting capabilities. -- Complete with:Assorted tool holders, centralized grease lubrication on Multi-Head, 63kVA Isolation Transformer, FANUC MPG Handheld Remote Jog Pendant, and manuals. -- Machine floor space required 64' by 14' 5"

C.R. ONSRUD 122RH18CDA Roller Hold Down Series with Roller Hold-Down, Boring, ATC, "C" axis, Loading & Off Loading: 5 x10 - Work Envelope. Manufactured in the USA. Designed and engineered utilizing Finite Element Analysis. Fabricated base consisting of heavy steel construction, cast iron bridge and fabricated vertical supports. All structural components are stress relieved utilizing thermal heat treatment. -- Specifications:Fixed bridge design with single moving table allows for up to – 4,000 IPM programmable feed rates. and 1G of acceleration. High precision ball-screw drive for all axis movements. -- Aluminum Universal Vacuum Table System - Includes: 4"; intake manifold, high-capacity vacuum plumbing, high-flow 45mm wide waffle patterns, with Onsrud’s Unique High Flow Vacuum Inlets, to offer maximum vacuum airflow & absolutely minimal airflow restriction for excellent part holding. -- High Flow Vacuum Zone - Pneumatic Ball Valve, actuated via Push Button or PLC Controlled -- 10' x 5' worktable with, 11-inches of Z stroke - 14"; under bridge clearance & 11"; Z axis stroke. -- Table includes pressure sensitive safety stop “edge switch"; on front and rear. In addition, a 360-degree emergency stop cable surrounds the machine. Industrial machine control system with full 3D capability (multi-axis interpolation). -- Operator Interface:FANUC 0i Machine Controller System - Industrial CNC Machine Controller with Fanuc Panel-i HMI w/High-Res touch screen. Fanuc 0i is not a PC with a control card but is a dedicated Industrial PLC designed to control CNC motion, for maximum reliability and performance. -- Full remote diagnostic troubleshooting capabilities. M-code controlled vacuum zones. Provided with 4-port network hub. Network capability, FANUC Digital Drives & Servos. Air-Conditioned Electronics Cabinet. -- Machining:18 HP Spindle - 4-Pole, 13.5kW, 18HP – 24,000 RPM fully programmable & reversible, variable speed, HSK 63F tool interface, quick-change spindle, with air blast, capable of routing & drilling, programmable feed rates w/override capability. -- (1) 12 Tool - Dynamic Automatic Rotary Tool Changer - Fully Servo controlled instead of Stepper controlled or Rack-Style tool changers. Design eliminates misfires & quickly changes between 12 different tools. -- C-Axis Ability for Use with Aggregates - Adds a continuous rotation, rotational C-axis to Aggregate Tool Changer & Capability. Includes Aggregate Anti-Rotation Spindle Adapter Ring Option. -- Boring:9 Spindle Drilling Block Package - (Multi-Spindle Line Drills) Includes 9 independent or simultaneous firing. Vertical spindles arranged to drill up to 5 holes at a time in the X axis or 5 holes at a time in Y axis. -- Features:Roller Hold Down Option - 2 Rollers on each side of the cutting spindles, automatically extend & retract as rollers roll off cutting table, for holding down warped sheet stock such as low-grade plywood. Each roller’s pressure can be r

CALPE TH5-1600 Heavy-Duty High-Production, Fully Automatic CNC Lathe: General Description: -- Multi-Spindle cutting simultaneously, (5) spindles using V-type gouge knives. -- 63" (1,600 mm) Max. distance between centers; 5-1/2" (140 mm) max. swing diameter between spindles. -- CNC Controlled with 2.95" (75 mm) travel for depth of cut. Motors/Speeds: -- Servo controlled CNC drives: -- CNC controlled electronic variable speed head drives the movement of the (5) gouge tools. -- CNC controlled feed speed carriage, variable up to 50 FPM (15 MPM). -- (1) Head stock variable speed drive for the (5) spindles, up to 6,000 RPM, approx 10 HP. -- Fast return travel of up to 590 IPM (15,000 mm/Min). 2 HP approx hydraulic drive -- Loading device & tail stock powered by hydraulic pump with 2 HP - 1,750 RPM motor; No. 5 Morse taper on main spindle shaft. Features: -- Automatic loading & unloading device; carriage mounted with linear guides providing high precision movement. -- Full CNC controller with on-screen CAD programming for all products.Matching CALPE L6-1600, record number LC-010996 spindle sander is available at additional cost at same facility.

CALPE L6-1600 Spindle Sander with Hopper Feed. -- (6) Spindles, semi-automatic sanding machine; distance between centers 63", 6-3/16" max sanding diameter, capable of sanding 1800 spindles per hour. -- 4 HP - 1,800 RPM head motor, (5) sandpaper holders, each for different grits, 4000-3200-2200-850 RPM head spindle speeds. Copier unit that follows all contours. -- Oscillating sanding units & stationary pick up of part. -- NOTE: This sander was running with lathe on our record number LC-010811 and owner prefers to sell at the same time.

CAM-WOOD BR-2132 Boring Machine21-Spindle boring head on 32 mm centers with position indicator.Features & Specifications: -- Stops in 0° & 90° with pneumatically assisted positioning in vertical & horizontal. -- 0" - 3" Adjustable drilling depth with speed control. -- Head height fine adjustment with mechanical digital readout. -- 2 HP - 3,400 RPM Motor. -- Cast iron 37-1/2" x 19-1/4" table with side fences for mirror-image. -- Line boring fence with repeat stops. -- Foot actuated pneumatic clamps & drill cycle.Complete with: Magnetic starter, overload protection. -- Optional: Quick-change chucks $28.00 ea.

CAM-WOOD BR-OO42BX DOUBLE ROW LINE BORERHeavy Double Head Line Borer with (2) 21-spindle heads; 32 mm spindle spacing.Specifications: -- Drilling from the bottom up and with 5-1/2" - 23-1/2" distance between rows. -- Drilling vertically from the bottom allows the chips to drop down falling out of the holes. -- Drilling depth of up to 3" max., takes only seconds to set. -- (2) 2 HP - 3,400 RPM motors; spindles with steel gears & high quality bearings. -- Easy repetition by (2) air index pins for continuous line drilling, left and right roller track supports extend up to 400 mm (15-3/4") for larger panels.Features and Includes: -- 120" Back fence with (4) repeat "flip" stops; includes 27-3/4" (704 mm) fence for quick positioning of flip stops. -- (6) Pneumatic holddowns to automatically actuate when the drill cycle begins. -- (42) "Quick Change" chucks for easy tool change. -- Magnetic motor controls and 1/4" air regulator with filter and oiler; 100 PSI required air pressure.

CAM-WOOD BR-50 Universal Boring MachineFeatures & Specifications: -- 3 HP Pneumatic Universal Boring Machine, all adjustments feature an index plate for accurate and convenient reading, workplace clamping. -- Vertical Base travel, 24". Horizontal Base travel 12". -- 0" - 4" Spindle stroke, 7/16" - 14-thread screw shank, 1/2" max. bit capacity. -- Table Size: 15" x 22". -- Complete with: Air operated overhead hold-down clamp and foot pedal operated drill cycle. -- Drill Head can be swiveled 360° and Optional Multi-Spindle drill heads available.

CAM-WOOD BR 25 Horizontal DrillFeatures & Specifications: -- Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back. -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic hold-down clamp for up to 3" thickness. -- 12" x 10" Table size. -- 1/2" Drill chuck / 3/4" max. bit diameter.

CAM-WOOD BR 25 + 1 Horizontal and Vertical DrillFeatures & Specifications: The model BR-25+ 1 has the same features as the BR-25, except it's fitted with an additionaluniversal boring head, making it ideal for drilling holes on K/D furniture. -- The boring head can be swiveled 360 degrees for angular drilling, as desired -- Vercical Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back., spindle node threaded 7/16-14" -- Horizontal spindle 2 HP, 3450 RPM-3 phases motor, adjustable 360 degree, spindle nose threaded 7/16-14" -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic holddown clamp for up to 3" thickness. -- 12" x 10" Table size.

CAM-WOOD WS-M1000 NAX Planer Sander -- 2 Heads with 39.4" width capacity planer head and combination sanding headFeatures: -- This machine is especially designed for tale off heavy materials such as glue panel, bend board, rough lumber. -- The first head is a knife planer head, with 25 HP motor. The spiral planer cutterhead is fitted with 14 x 14 mm, four edge throw away Tungsten Carbide knife inserts, providing superior chip removal rate, minimum noise, and extremely smooth cutting effect. Changing knife inserts are conveniently done without removing the cutterhead. Planer head with motorized height adjustment with digital read out display -- The second head is a combination of drum and platen driven by a 20 HP motor, belt size 40.5" x 78 3/4". (1030mm X 2000 mm) -- Anti-kickback fingers, mounted at the infeed of the machine, this anti-kickback finger gives a safety guard for the operator. -- Insufficient pressure protection, in case insufficient working air pressure occurs, the machine brakes automatically for safety guard.Irreversible running of pressure roller, runs a single direction only, giving an additional safety guard for panel kickback. -- Motorized elevation of conveyor table (micro-computer controlled with digital readout), it accurately displays the position of the conveyor table and automatically moves to the setting thickness for planning, sanding. -- Panel cleaning brush roller; built at outfeed end of the machine, this cleaning brush roller cleans the powder on the sanded panel. -- Hold-down plate is hard chrome treated for maximum wear resistance.Technical Specification: -- Working width 39.4" (1000 mm). -- Working thickness up to 6 1/4". -- Minimum working length 21". -- Feed speed 10 to 90 FPM inverted driven by 3 HP motor. -- Table raised and lowered by 1/2 HP motor. -- Cleaning brush driven by 1/2 HP

CAM-WOOD WS-MN700NAX Planer/Sander Equipped with: -- (2) Heads with 27" width capacity planer head and combination sanding head -- This machine is specially designed for take-off heavy materials such as glued-up panels, bend boards, and rough lumber. -- The first head is a knife planer head, with 20 HP motor. The spiral planer cutterhead is fitted with 14 x 14 MM, four edge throw away Tungsten Carbide knife inserts, providing superior chip removal rate, minimum noise, and extremely smooth cutting effect. Changing knife inserts are conveniently done without removing the cutterhead. -- The second head is a combination of drum and platen driven by a 20 HP motor, belt size 28 3/4" X 75" -- Anti-kickback fingers, mounted at the infeed of the machine, these anti-kickback fingers provide a safety guard for the operator.Features: -- Insufficient pressure protection, in case insufficient working air pressure occurs, the machine brakes automatically for safety guard.Irreversible running of pressure roller, runs a single direction only, giving an additional safety guard for panel kickback. -- Motorized elevation of conveyor table (micro-computer controlled with digital readout), it accurately displays the position of the conveyor table and automatically moves to the setting thickness for planning, sanding. -- Panel cleaning brush roller; built-in at the outfeed end of the machine, the cleaning brush roller cleans the fine sanding dust off the sanded panel. -- Hold-down plate is hard chrome treated for maximum wear resistance.Technical Specification: -- Working width 27" -- Working thickness up to 6 1/4" -- Minimum working length 20" -- Feed speed 20 to 90 FPM inverted driven by 3 HP motor -- Table raised and lowered by 1/2 HP motor -- Cleaning brush driven by 1/2 HP

CAM-WOOD WS-NDA 1300 3-Head Planer Sander[Equipped with Planer, Drum and combi head]Features: -- This machine is especially designed for removing heavy material such as glued-up panels, bent boards, and rough lumber. -- The first station is a knife planer head, followed by a combi head with drum and platen at the second station and a finishing platen head at the third station. -- Head configuration can be made to meet customer’s requirements. -- The spiral planer cutter head is fitted with 14 x 14 MM, four-edge throwaway Tungsten Carbide knife inserts, providing a superior chip removal rate, minimum noise, and an extremely smooth cutting effect. -- Changing knife inserts is convenient without removing the cutter head. The spiral cutter head is precision machined from special aluminum alloy steel, tempered, and precision ground by a CNC machine center. -- Anti-kickback fingers, mounted at the infeed of the machine, this anti-kickback finger gives a safety guard for the operator. -- Insufficient pressure protection: If inadequate working air pressure occurs, the machine brakes automatically for safety guard. -- The irreversible running of the pressure roller runs in a single direction only, giving an additional safety guard for panel kickback. -- Automatic elevation of conveyor table (micro-computer controlled with digital readout): it accurately displays the position of the conveyor table. It automatically moves to the setting thickness for planning and sanding. -- Panel cleaning brush roller: built at the outfeed end of the machine, this cleaning brush roller cleans the powder on the sanded panel. -- Hold-down plate is hard chrome treated for maximum wear resistance.Specifications: -- First head Planer with 40 HP motor -- Second head combi drum & platen with 30 HP motor -- Third head finishing platen with 30 HP motor -- Panel cleaning brush at outfeed with 1/2 HP motor -- Working width: 52" -- Working thickness minimum 1/4" and up to 6 1/4" -- Minimum working length: 21" -- Feed speed 10 FPM to 90FPM inverted driven by 5.5 HP motor -- Table hoist motor 1 HP -- Sanding belt size 52" X 75" -- Floor space requirement: 107" X 103" X 80", weight 12,300 Lbs

CAM-WOOD PT-48VAX Door Clamp (Single Sided). -- Work Space: 48" Max. width x 97" max. length, hydraulically operated.Specifications: -- Applies max. 11,000 PSI pressure from (2) sides; 90 PSI from holddown. -- Includes 5 HP hydraulic pressure system. -- Hydraulically operated assembly table; twin hydraulic cylinders for moveable rams at two sides pressing for max. assembly capacity. -- Easy adjustments of rams, makes changing sizes simple; separate controls for adjusting the each side of press rams. -- Fixed reference points for lower & left edges ensure 90° assembly of face frames; heavy gauge steel metal table & frame.NOTE: Also available as a 2-sided Clamp for ...$26,500.

CAM-WOOD PTX-2513 Entry Door/Window Hydraulic Assembly Press, 4' x 8'. Hydraulically operated. Solidly constructed and welded with great precision.Specifications: -- Working area:1300 mm (51") Max. width; 2500 mm (98") max. length. -- (2) Vertical cylinders, each of stroke 80 x 600st; (2) side cylinders, each of stroke 50 x 800st. -- Comes with: 2 HP hydraulic pump motor. -- Outer structure is made of two vertical beams which are individually located at the upper and the bottom side of the machine. The horizontal beams have vertical hydraulic cylinders thereby moving beams up and down to distribute the pressure evenly on the workpiece. The overhead push button operates the hydraulic motor. -- Stops (square blocks) are moved manually to set to the desired position. The mobile pressing platen of the square block and the horizontal upper beam can be moved by the vertical hydraulic cylinder. -- Equipped with: A pressure gauge and pressure control valve to regulate the vertical and horizontal hydraulic cylinders for precise, desired working pressure. -- Overall Dimensions/eight: 3000 x 1200 x 2200 mm (120 x 48 x 87"). Weight: 1200 Kg (2650 Lbs).NOTE: Also available in 5' x 10' Press for ... Please inquire for prices.

CAM-WOOD - EX-ARES ...CNC Door Processing Machine Center for Pre-Hung Doors with Automatic Tool Changer. Distinctive design for Door Pre-Hang Processing. -- All the 5-side Project Processing -- Automatic Feed Through (Options with Auto Loading and Out-Feeding) -- Hinge Face Milling, Screw Hole Drilling -- Lock Bore Drilling -- Latch Face Milling, Latch Bore Drilling. FEATURES: -- DSP CNC controller is setup to accept standard G-code programming formats along with on board conversational applications. -- Optional CAD/CAM system can create and edit part programs then send to machine for easy cutting. DXF files can imported, modified, and edited from here to create a G-code. -- Horizontal and vertical spindle for top and side stock processing -- Machine designed ready for 3-D cutting usage and superior performance. -- Moving gantry construction for space saving. -- The rigid steel frame construction has been stressed relieved prior to finish machining to provide repeatability and accuracy. --Automatic frequency brake for the spindle allows rapid deceleration resulting in faster tool changes. -- Linear guides and sliding blocks are prismatic pre-loaded with recirculation bearings to ensure maximum rapid traverse and precision. -- The X & Y axis equipped with a precision rack & pinion driving system. The Z axis utilizes a ball screw assembly complete with the pre-loaded and ground screw for long life and optimum accuracy.SPECIFICATIONS: -- Working size 51"; Width x 98"; Length x 7-7/8"; Height (Door Lock Maximum Depth 4-3/4";) -- Custom made door vacuum table (Optional Vacuum Pump) -- SYNTEC 60WA control with All in one PC Controller -- 9.0KW air cooling Spindle with 4 pcs ISO30 tools linear ATC for Top Side Milling, Drilling, Lock, Bore.. Processing -- 6.0KW double Side milling Spindle at X direction for X Axis Two Side, Milling, Drilling, Ball Catch, Split Line. Processing -- 6.0KW double milling spindle at Y direction, Two Side, Milling, Drilling, Hinge, Latch Hole, Face, Dead Ball, Processing -- 2.2KW 4 Side Milling Spindle for All the 4 Side, Small Holes, or Screw Hole Drilling process -- 1500W servo drive. -- Max travel speed 200 FPM (60m/min), Max working speed 50 fpm (15m/min) (According different processing material) -- Professional PTP table with German SCHMALZ Vacuum pads 6pcs -- 2M helical rack, 30 square rails & Ball screw -- Automatic control with Aluminum oil pipe Oil lubrication.OPTIONS: -- 10' table capacity ...............$US. Please call. -- ARES Options for 3 Degrees Bevel.A.) Pre-set the Angle heads point to left or right side at tool rack. HSD Angle Head $US8,990.00 each (most time, it will need at least two units, preset to 3 degrees, one bigger cutter for routing, one small cutter to do re-fine the latch corner or drill the screw holes).B.) Upgrade to Italy HSD C Axis System add $US Please call . (Horizontal 360 Degrees turning, it can work on all the 4 door edges). Plus, HSD Angle Head $8,990.00 each (most time, it will n

CAM-WOOD 86PAAU Raised Panel Door Machine machines entry door stile and rail door parts as well as cabinet door parts, chair legs and furniture parts, up to 86" length and 7" width.. One operator to machine profiles to the rail copes, stile and rail sticking and raised panels with rapid change over all on one machine for high productivity. Features Include: -- Hydraulic table movements from right to left to achieve powerful cutting and adjust cutting speed variability. Table movements in and out are pneumatic powered to follow a template sensitively. --One operator to machine all profiles for stiles and rails on one machine, along with raising all panels both edges top and bottom. -- Capacity for machining a 6" arch/oval on panels and rails, and raises both face on a raised panel at the same time (arc size varies depending on cutter diameter). -- Raise a curved panel up to 6" radius both on rails and panels. -- Hydraulic pump unit for accurate table speed control. -- Simple guide system follows templates for curved or arched profiles and is quickly repositioned for straight machining profiles. -- Cutterhead knives can be stacked on the same spindle to eliminate changing machines to machine door parts. -- Easy stop system for door stiles or rail lengths. Two separate stops work for rail/stile/panel arch cut positions. -- Heavy duty 10 HP motor, allows for high speed cutterhead to eliminate unnecessary sanding. -- Proximity switches control the cutting stroke. Linear guide rails and bearing for a lightweight & smooth slide. -- More than one part may be milled at one time. Pneumatic holddown cylinders hold parts tightly without slide during cutting. -- Easy positioning of parts on a precision ground, cast iron table ensures accurate stile rail and panel machining and alignments. -- Machines door stiles up to 86" in length.More Specifications: -- Spindle Motor 10 HP @ 7,000 RPM; Hydraulic Motor 1 HP; Feed Speed 0-60 FPM. -- Spindle Diameter 1-1/4"; Spindle Height 7"; Depth of Radius Cut 6";; Min. Radius Cut 6" (based on cutter diameter) machine door stiles up to 86" in length. Dust Hood is 4" dia. -- Dimension: Length 120";; Operating Length 228";; Width 48";; Height 48";. Weight 300 lbs. Air Supply Required 100 PSI -- Note: Delivery time about 10-12 weeks.

CAM-WOOD PL-18 18" Wide Top & Bottom Straightening Planer. -- 18" Planer with straight knife heads with HSS knives for accurate and powerful two-sided planning in one pass.ADD for Spiral Heads with Carbide Insert Knives... $3,200.00Specifications: -- 17-3/4"; Max. Planning Width. -- 3/8 to 8" Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 10"; Min. Planning Length. -- 15 to 70 FPM Feeding Speed (Inverter Driven). -- 4,200 RPM Cutter Straight Knife Head Speed. (6,000 RPM for Spiral Cutter Head). -- (4) Knife Cutterheads. -- 15 HP Upper Motor. -- 10 HP Bottom Motor. -- 2 HP Feed Motor. -- 1/2 HP Elevation Motor. -- Table Size (L x W) 88" x 16". -- N.W. 6,500 Lbs.Features: -- Standard equipped with automatic thickness controller, easy, accurate and quick setting for the cutting thickness. -- Upper & lower straight knives or spiral cutterheads for accurate and powerful two-sided planing in one pass. -- The worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planning. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The infeed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then accurate planing of the surface can be performed to prevent jumping during processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with heavy-duty drive chains and gears to provide a smooth even feeding during rough or finish planning. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- The heavy-duty rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial motor for maximum cutting capacity. -- All precision sealed long-life bearing for durability -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Changing the knife on the upper cutterhead only requires removal of the upper dust chute. -- The optional spiral insert head design allows for fast, accurate insert changes and minimum down time. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth chatter-free planing regardless of the feed rate or hardness of material being planed. -- A powerful motor is utilized to make adjustments quickly

CAM-WOOD PL-38 TOP & BOTTOM STRAIGHTENING PLANERIncludes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Insert Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $10.00 EACHSpecifications: -- 3" to 38"; Max. Planning Width -- 3/8" to 8"; Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 52 FPM Feed Speeds (Variable). -- 4,000 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges 40 HP Top Head Motor. -- 25 HP Bottom Head Motor. -- 5 HP Feed Motor -- 2 HP Elevation Motor. -- Net weight 9,900 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-free planing regardless of the feed rate or hardness of planed material. -- 1/2 HP Motor provides quick and accurate top head thickness adjustments.

CAM-WOOD MODEL WP-4S 650 2C 25"-20 4-SIDED PLANER WITH MOULDING CAPABILITIES: Designed for heavy furniture, cabinet, flooring, intermittent planing millwork, and other industrial uses. Perfect Planer for S2S and S4S planing up to 16" high x 25" wide timbers, tongue & groove flooring, wall paneling, etc. up to approximately 75 FPM depending on depth of cuts and dimensions of parts.SPECIFICATIONS: -- Width capacity from 2-3/4"; to 25";. -- Thickness capacity from 3/4"; to 20";. -- Feed speeds variable from 18 to 65 FPM -- 30 HP Bottom head motor -- 30 HP Top head motor -- 20 HP Left (outside) spindle motor -- 20 HP Right (inside) spindle motor -- 1/2 HP motors on right & left champhering (top eased edge) spindles -- (2) X 7.5 HP feed motor -- 5"; dia. top and bottom cutterheads -- 5"; or 6"; dia. right & left cutterheads -- 60 mm (2.362";) dia. spindles on top and bottom heads -- 40 mm (1.574";) dia. spindles on top and bottom heads -- 30 mm (1.181") champhering spindles -- 15 x 15 x 2.5 mm insert knives -- (4) Dust outlets, each 6"; diameter -- Planer measurements: 110"; long x 91"; wide x 94"; high -- Planer weighs 19,500 Lbs. FEATURES: -- Compact construction with planing and moulding capabilities; provides flexible performance at an affordable price -- Equipped with a digital controller to set thickness & width automatically -- Rigidly mounted alloy steel spindle with outboard bearing support for accurate, vibration-free planing surfaces on horizontal spindles -- Spindle height adjustment by precision rack & pinion gear sets. -- Bedplates are precision ground, chrome-plated and polished to a mirror finish; provide a smooth, wear-resistant surface -- Variable speed inverter control for smooth feed speed adjustment depending on lumber hardness, depth of cut & width. Speed adjusts to provide the best finish and highest speed for best overall performance. -- Feed rolls are driven by geared transmission boxes and drive shafts with heavy-duty universal joints and drive shafts; provide smooth, even feeding for rough or finish planing -- Heavy fabricated steel plate frame, heated and stress relieved for vibration-free finishes, supports the worktable and helps dampen vibration for a superior finish. Ensures years of dependable service -- Industrial-grade, standard off-the-shelf motors for maximum cutting capacity and ease of service -- Bearings are precision, sealed, long-life bearings for durability and service life -- Removable cutterheads on all spindles, designed for convenient knife changing or rotating, including the bottom head. -- Changing or rotating knives on the top head only requires removal of the dust hood -- 4-Row spiral insert knife head design allows fast, accurate insert knife changes and minimum down time. Uses standard 15 x 15 x 2.5 mm insert knives -- Minimized setup time on top head when using the auto material thickness device -- All cutter heads are precision balanced to provide consistently smoo
