19 Results Found for End Matcher Viewing 1 - 19 of 19 results
STANDARD LISTINGS
AUBURN End Pro End Matcher: 8" Max. width cap., 2" max. thickness, 6" min. stock length.Specifications: -- Single vertical spindle, 7.5 HP - 5,000 to 7,000 variable RPM motor powered by AC inverter. -- 1-1/4" Dia. x 6" long stackable reversing spindle, 6-3/4" max. cutting circle with 1" max. depth of cut, spindle travel mechanically actuated with variable control. -- Right & left tables are stationary, 3-1/2" individual adjustment up & down with mechanical digital readouts for tongue & groove work or finger joint production. -- Equipped with: Automatic spindle brake, (2) horizontal and (1) vertical clamp on each table. รท Note: Machine does not work properly and is sold as is where is!
Equipment Location:MID ATLANTIC
Jeff Terrill
800-374-5009 ext:349
CAM-WOOD EX-300 End Matcher, 12" Performs tongue and groove, tenoning, mortising, and shaping at both ends of the boards -- Includes powered conveyors for infeed and outfeed -- Air operated hold downs keep material firmly in place during the machining process -- Cutter heads move in and out while cutting a tongue on the trailing end of one part and a groove on the leading end of the following piece.FEATURES: -- PLC controls combined with touch-sensing screen for maximum convenience of operation. -- Each cutter head is driven by a separate motor driving the spindle at 7,500 rpm spindle speed. -- Accepts unlimited wood lengths via an automated conveyor for infeed and outfeed processing. -- Cutterheads feed thru the wood is controlled by a frequency inverter that permits speed changes to suit various cutting conditions. -- Pressure plates are actuated by air cylinders. -- Hard chrome-plated table features maximum wear resistance. -- Table rollers increase feed smoothness. -- Powered in feed roller conveyor is driven by a 1 HP motor. -- 3,400 mm in feed roller conveyor and 2,200 mm out feed conveyor table are standard equipment. -- Fully enclosed chip guards. -- Air-operated clamp holds stock firmly in place. After work piece is clamped, cutter head moves in and performs shaping operation. -- The spindle is precision constructed to cut accurately -- The spindle height adjustment is displayed on a dial gauge. -- CAM-WOOD’S (2) spindle design accommodate cutterhead dia. up to 6"; -- When end matching, one spindle cuts the tongue and the second cutterhead machines the groove. SPECIFICATIONS: -- 1-1/2" To 12" width cap. -- 10-1/2” min. length cap. -- Unlimited length restriction. -- Material feed speeds up to 297 FPM; cutterhead travel speed of 79 FPM. -- (2) 5-1/2 HP Spindle motors and a 2 HP feed drive -- 1/2 HP motor for in/out cutterhead travel. -- 40 mm dia. spindle -- Requires 1300 CFM dust collection.
Equipment Location:WEST COAST
Jeff Terrill
800-374-5009 ext:349
CANTEK EM-12 End Matcher;1.6" to 12" width x 0.4" to 1.38" thickness (to 2-1/4" optional) x 10.6" min. length capacity. Unlimited lengths possible. Feed speeds to 295 FPM with approximate production speeds of 77 FPM (based on 6-1/2' incoming boards). -- Standard 176" long infeed table and standard 130" long outfeed table; (2) 7-1/2 HP cutterhead motors with 40 mm spindle diameters; 1 HP feed motor; 1/2 HP motor drive to cutterhead carriage; clamping pressure from top and side; 24 volt DC controls.Standard equipment and Features: -- Designed for machining tongue & groove with or without V's on flooring and panel products; designed to be used for finger joint cutting. -- Heavy-duty self supporting main frame; compact design requires minimum floor space.Feedworks: -- Capable of processing material as short as 11" to an unlimited length; variable speed through-feed systems is controlled by frequency inverter; through-feed system allows the tongue to be cut simultaneously on the tail of one board and the leading edge of the next board. -- Powered top Urethane rolls and spring loaded bed rollers feed the material into position for processing. -- Pneumatic side pressure ensures the material is held square against the fence.Complete with: Safety and noise reduction enclosure; convenient touch screen control is used to quickly activate and adjust the machine functions. -- Powered 176" long infeed conveyor is included (additional length optional); with a 130" long outfeed table (additional length optional). -- Includes: (4) individual Precision Insert Tooling Heads as Supplied with Machine & stacked to make (1) pair of heads; set of heads provided for groove on left and tongue on right.
Equipment Location:PACIFIC NORTHWEST
Jeff Terrill
800-374-5009 ext:349
COMPUTERIZED DEFECT AND END-MATCHING SYSTEM consisting of a Cantek model CFS-100 Optimizing Cut-Off Saw followed by a Cantek Model EM-10 or EM 12 Through-Feed End Matcher and with the following specifications and features: -- 4" x 11" or 3.2" x 12" cutting capacity with 18" x 30mm bore sawblade is driven by a 10 HP motor driving the saw spindle at 3,200 RPM; 2.7 HP serve drive feed system drives the stock up to 260 FPM; 0.787" min. distance between crayon marks; requires 75 to 80 PSI at the saw and 100 to 120 PSI at defect blow-off station. Machine comes completely wired and programmed. -- Machine is ideal for defect cutting finger joint blocks or cutting fixed lengths against a predetermined cutting list; cuts fixed lengths, random blocks and optimization; provides 3 to 5 times greater production than manual cut-off saws.; 5% + material recovery )5% yield increase) over manual cutting; compact and user-friendly design; controller adopts an industrial grade computer that employs a 32-bit floating-point DSP system and features flash and battery backup SRAM for double security; superior to conventional PC-based controls, it can fully eliminate the machine going down or being damaged due to a poor environment, such as, unstable voltage, high temperature, sawdust, etc. -- With defect blow-off system combined with computerized logic control permits the blow-off time and the length of defect to be set as desired; provides efficient defect removal and eliminates defects from bumping against the sawblade, resulting in the machine going down or sawblade damage. -- Computer control provides easy and fast maintenance; feed system driven by a servo motor for fast and accurate motion and position control; max. feed speed up to 260 FPM; cutting rate up to 80 cuts per minute with cutting accuracy within approx. ±1mm /0.40"; control employs a touch screen for easy learning and operation; new machine design features maximum maintenance convenience; high quality electric components provide maximum dependability; safety guards for maximum operator protection; 48" long infeed table standard - longer available option; 18" carbide blade included. -- (5) Cutting modes include: -- Adjustable end cuts to a max. of 10mm(.4") -- Fixed length of cutting mode -- Sequential cutting mode with (10) sets of cutting sizes held in memory (for sequential cutting mode only) -- Cutting on fluorescent marks with double end trimming -- Reading fluorescent marks with double end trim, fixed length, finger joint block cutting. -- CANTEK model EM-10 / EM-12 END MATCHER & FINGER JOINT SHAPER with continuous through-feed system; handles random length min. 10.6" to any length x 0.4" to 1.38" thickness x 10" or 12" width capacity; 295 FPM max. feed speed; 75 FPM based on 6'-6" board lengths; with 118" infeed and 98" outfeed tables; 5.5 HP shaper motors, 1 HP feed motor and 1/2 HP cutter stroke motor and 24-volt control system; clamping from top and outside side; 40mm spindle
Equipment Location:PACIFIC NORTHWEST
Jeff Terrill
800-374-5009 ext:349
DOUCET DH-8-S2 End Matcher --- Heavy Duty double sided hydraulic feed with traverse bars and transfer roller conveyors. - 9/16" to 1" thickness cap., 8" to 96" max. material length, 96" max. between right & left heads. -- Feed traverse bars are 2" wide on 9" centers machined to allow 9/16" min. material thickness x 7" max. width, 2" wide at the ends and 1-3/4" wide in the center connected by tubes so each side of the feed bars are adjustable making each side of the matcher independently adjustable. -- Configuration: Groove Unit, Tongue Unit; Groove Unit: 5 HP Trim saw, 5 HP Trim Saw, Jump Shaper, 5 HP Horizontal Groove Saw. -- Tongue Unit: 5 HP Trim Saw, 5 HP Trim Saw, Two 5 HP Tongue Saws; (2) sets of Lateral Feed Rollers: one before each working unit; 8' Traverse Bars; Distance Between Traverse Bars: 7"; Traverse Bar Center-to-Center: 9" Infeed table length: 6'; End-Matcher Length: 34'; with 25 HP Hydraulic drive. Feed speed 60 FPM
Equipment Location:MID ATLANTIC
Jeff Terrill
800-374-5009 ext:349
Production Machine designed, "precision end-matching" of plank flooring up to 9" wide. -- Specifically to meet specialty flooring producers' requirements from low to mid-volume; features a traverse bar conveyor with high precision ductile iron chains, identical to those on DOUCET's larger models. -- Bars are laid out on 12" spacing to allow machine boards up to 9" wide. -- Conveyor is powered by a 10 HP electric motor with variable speed from 20 - 60 FPM. -- Tongue & groove machining stations are fully enclosed units; boards are placed between the traverse bars at the infeed end of the PFM. -- Random length pieces are brought forward by traverse bars, floorboards are side-shifted to the machining stations by roller conveyors imbedded in the traverse bar conveyor. -- The central set of side-shift rollers are selectively turned on or off to allow the operator to machine either one or both of ends of a board. -- Material length capability ranges from a min. of 12" to a max. of 96"; min. width is 1-3/4" to a max. width of 8" with bars set on 12โ€ center. -- Machining thickness capability ranges from a min. of 3/8" to a max. of 3/4". -- 10 HP Main motor drive, 20 - 60 FPM variable feed speed; 3.5 HP motors for the roller conveyor; precision ductile iron tenoner chains; (3) side-shift rollers 24" at infeed, 24" crossover, and 24" behind exit. -- Even ender for boards longer than 60"; universal traverse bars for machining material 3/8โ€ to 3/4โ€ thick for min. setup time; transverse bars 12" on center; automatic chain oil dispensers. -- (5) 3 HP Motors for machining: Tongue trimmer with or without micro-bevel blade, top tongue groover, bottom tongue groover, groove trimmer with or without micro-bevel. -- (4) 6" Dia., 500 CFM dust collection outlets; hard steel top holddowns; tooling not included. -- Control Cabinet includes central power and control panel with OMRON PLC, starters, VFDs, and other internal components. -- Software is NOT included; operator interface console on the main panel door with push buttons; external hookup for distance troubleshooting and programming changes via Ethernet card. -- Safety Features include: Safety guards on motor chains or other pinch points; the ones fixed on the equipment are included. - All others safety fences or walkways to secure working area from surrounding hazards are not included in this sale, except if shown on the drawing layout presented with a quote. -- Additional safety fences or walkway can be built by DOUCET at extra charge. -- General Features - Machine colors are: Side guarding Light Grey RAL 7035, frame Grey RAL 7037, safety guard Safety Yellow RAL 1023, and moving components Safety Orange RAL 2011. -- Includes an instructions manual with part list, safety guidelines and critical maintenance tasks. -- Available Options: Coping module to prevent tear out in groove, please add ...$ 7,650; Soft-touch holddown for pre-varnish products, add ...$ 6,375.
Equipment Location:EASTERN CDN
Jeff Terrill
800-374-5009 ext:349
DOUCET SPFM High Production End Matcher For Strip or Plank Flooring. 10" to 96" board length capacity; 3/8" to 3/4" thickness capability minimum width 1 3/4"; maximum width 3 1/4", 5 1/4" or 8 1/4" (relative to traverse 6", 9" or 12" bar spacing). End-Matcher model SPFM is designed for high production and is suitable for production capacities of 20,000 to 30,000 board feet of random length Strip or Plank Flooring per shift.Specifications: -- High precision ductile iron chains, hardened steel sprockets, massive traverse bars -- 20 HP Electric Motor with a Variable Speed Drive up to 80 feet per minute -- 5 HP spindle motors -- 9 inch center to center standard traverse bar spacing -- Fully enclosed machining centers, all adjustments made easy by dial indicators -- Dynamic braking on all spindle motors -- Electronically controlled chain lubrication systemStandard Features: -- 27' long by 96" wide feed conveyor -- 3" Pitch ductile iron chains, linked by 3/4" press fit dowel pins, driven by 15" hardened steel sprockets -- Massive 2" by 3/4" traverse bars suitable for machining 0.375" to 0.75" thick flooring -- Air Bag & Belt hold-downs -- 9" Center to center traverse bar spacing (6" and 12" possible) -- Feed speed up to 80 FPM powered by a variable flow 20 HP hydraulic power unit -- Injection type chain lubrication system -- (3) 36" Wide side-shift conveyors -- 3" Diameter side-shift rollers dual driven by 1 HP motors -- Tongue and groove machining centers laid out on opposite sides of the feed conveyor -- Machining centers are totally enclosed and equipped with interlocked doors -- (2) 6" Dust collector connectors on lower side of each machining center (1000 CFM each) -- Tongue machining center with 3 - 5HP spindle motors, (trimmer, top and bottom tongue groovers) -- Groove machining center with 2 - 5HP spindle motors, (trimmer and horizontal groover) -- Tooling system for regular or beveled top end-matching -- 12" Dia. x 30mm bore trim saws and 12" groover saws -- All spindle motors feature position indicator dials -- Dynamic (emergency) braking on all spindle motorsEXTRAS: (2) Sets of beveled T&G Cutterheads and (1) set of flooring T&G Heads
Equipment Location:SOUTHEAST
Jeff Terrill
800-374-5009 ext:349
Equipment Location:GA
Carolina Machinery Sales, Inc
704-288-1904
FRUILMAC "RANDOMAT- E PLUS End Matcher; For End Matching flooring or cabinet & entry door rails; feed thru system allows continuous feeding of random length parts with any kind of profile.Capacity & Description: -- Width cap. 1-3/16" x 16" ; length cap. 6-5/16" x R/L length (longer lengths with additional support); 3/8" min. - 1-3/16" max. thickness cap. -- Approx. (10) cycles/Min depending on part length & width; feed system withow , parts are automatically fed & positioned with sensors, and a positive stop to the 1st vertical shaper head (a 2nd shaper head is next to the 1st one); cope cycle is automatic. -- Parts are conveyed past the 1st & 2nd shaper head, automatically reversed and positioned to a positive stop for the 2nd cut on the other end of the part. At the same time the 1st shaper head would be coping the 1st end of another part.Equipped with: -- Twin 7.5 HP - 7,500 RPM high speed shaper motors which pneumatically traverse in tandom for each cutting cycle. -- Cutting station with overhead holddown wheels and 4-point pneumatic clamping with (2) overhead & (2) horizontal clamps.Controller & Operator Interface: -- Touch-Screen SIEMENS Controller, PLC controlled conveyor & shaper cut cycle for automatic operation, variable feed speed conveyor line, and shaper head advance with led readout on the controls. RARE 16" WIDTH CAPACITY IN REMARKABLE CONDITION!
Equipment Location:EASTERN CDN
Jeff Terrill
800-374-5009 ext:349
Working capacity: Length 7-7/8" (200 mm) to 78" (2000 mm) Width-2" (50 mm) to15-3/4" (400mm); Thickness min. 3/8" (10 mm) to 1-1/2" (40 mm.) Automatic end matching and defecting all in one. Trimming units 7.5 hp (5.5kw) Scoring units 3 hp (1.2) kw Profiling units 9 HP (6.0kw) Conveyor belt speeds 90- 600 FPM (30-200m/min.) with 4 HP (2.7 kw) motor. This system is available immediately.
Equipment Location:ON
Carolina Machinery Sales, Inc
704-288-1904
FRIULMAC RANDOMAX EVO 200-003B Defect Saw and End Matcher All in ONE, Automatic Defect Cutting and End Matching machine: Specifications: -- 7-1/2 HP (5.5 kW) Trim saw -- 1-1/2 HP (1.2 kW) Scoring saws -- 8 HP (6 kW) Profiling unitsCapacities: -- 8” (200 mm) Min. to 78” (2000 mm) max. length -- 2” (50 mm) Min. to 15-3/4” (400 mm) max. width -- 3/8” (10 mm) Min. to 1-1/2” (40 mm) max. thickness -- Conveyor belt speeds from 30 - 200 FPM via 3-1/2 HP (2.7 kW) feed motor -- Machine is built for 460-Volt, 60-Cycle, 3-Phase power and converted for 600-Volt operation with a transformerMACHINE FEATURES:Machine Base: -- The machine base is built of sturdy electro-welded steel able to absorb and avoid vibrations and resonances generated by the working process. Feed System: -- The workpieces are positioned onto infeed belt transfer by the operator and transferred inside the machine by means of motorized bottom tracks with free rollers top pressure system. -- A laser photo-eye activates an electronic measuring procedure to determine the workpiece positioning with reference to the size of the scrap to be removed. -- The scrap size has to be preset on the control panel. -- Once positioned, the first workpiece gets references and clamped by means of controlled pneumatic pressure sequence; all movements are realized on precision linear guides. -- When the end-processing has finished, the workpiece gets released from the clamping and moves to the next step to repeat the above described procedure with reference to the trailing end. -- From here on, the machine keeps positioning and processing the leading and trailing ends simultaneously. -- All parameters, including speed and clamping sequences, can be modified directly from the control panel, depending on the requested working process. Working Sequence: -- Once the workpiece is positioned, the working units start their stroke to process the end-trimming with the vertical unit from top and the scoring/profiling operation. -- The trimming unit displacement from the top to the bottom is driven by pneumatic cylinder. -- The scoring & profiling units are assembled on a movable base that slides on precision linear guides by means of pinion (connected with a brushless motor) and rack. -- The speed (forward, profiling & backward) is adjustable directly from the control board. -- An aluminum back-up blocks and anti-breakout blocks system, driven by pneumatic cylinder, assures a great result of the workpieces end-working.NOTE: Installed new in September 2014!
Equipment Location:EASTERN CDN
Jeff Terrill
800-374-5009 ext:349
2006 Fruilmac model Randomat Serial Number #3889A End Matcher. Infeed deck, End Matcher machine, Outfeed deck,Nesting station Less than 3000 Hrs.
Equipment Location:Clarksburg, TN
LPS Equipment & Acquisition Co.
731-986-4351
Manufacturer specs (to be confirmed): 1-3/16" Min. - 9-13/16" max. width cap., 10" min. - 98" max. length, 3/8" min. - 1-3/16" max. thickness cap. Approx. (10 - 12) cycles/Min (depending on part length & width); operates with (2) 13' long x 10" wide powered in- & outfeed belt conveyors, parts are automatically feed & positioned with sensors, and a positive stop to the 1st vertical shaper head; cut cycle is automatic, parts are conveyed past the 1st shaper to a 2nd shaper head, and automatically trims the other end of the part. IIncludes: Twin 7.5 HP high speed 7,600 RPM shaper motors which pneumatically traverse in tandom for each cutting cycle, PLC controlled conveyor & shaper cut cycle for automatic operation, variable feed speed conveyor line and shaper head advance with led readout on the controls.
Equipment Location:WI
Carolina Machinery Sales, Inc
704-288-1904
Grutter End Groover with 10HP Motor and control Box
Equipment Location:Clarksburg, TN
LPS Equipment & Acquisition Co.
731-986-4351
Hasko End Matcher Complete
Equipment Location:Clarksburg, TN
LPS Equipment & Acquisition Co.
731-986-4351
HASKO HSEM - 506 End Matcher High Speed Feed Through; Specifications: -- The feed thru system allows for continuous feeding of random length parts with any kind of profile. -- Width cap. 1" x 7"; length cap. 8-1/2" x 12'-0" lengths; 5/16"- 2" max. thickness cap.; -- Endmatcher with feed speed from 12 - 154 lugs per minute. -- Infeed powered roller conveyor 12" x 16', feeding singulator wheels for introducing lumber onto 9-strand infeed chain deck for the Endmatcher. -- Chain deck allows for spacing of boards for singulation between the spacing bars on the infeed deck system feeding the right-hand & left-hand stations. -- Infeed to tongue cut 19'-4" x 10', Crossover chain 14' x 10' to groove cut. outfeed chain 24'-0". Transport sprockets 50 pitch.Equipped with: -- Tongue first position and groove second; (3) heads per station all with VFD 5 HP motors at 6,000 RPM. -- Both the right and left hand processing stations have a scoring, trim and profiling head. Includes: -- (One) Auxiliary infeed 8' x 7" ABC for infeed to Tongue unit with 3/4 HP variable speed drive -- (One) Auxiliary outfeed conveyor 13'-6" long x 7" wide slider belt with 3/4 HP variable speed drive to be installed behind the groove unit and extends out for grading station.Tooling: 12" in diameter.
Equipment Location:SOUTH
Jeff Terrill
800-374-5009 ext:349
Holytek Ultra ED-10 End Matcher
Equipment Location:Clarksburg, TN
LPS Equipment & Acquisition Co.
731-986-4351
Through Feed End Matcher, compact design does not inhibit its ability for high output; high quality product. -- Whether finger jointing or tongue & groove end matching, machine accepts material up to 12" wide and 1-3/8" thick. -- Min. stock dimensions of 1.57" wide x 0.4" thick, min. length of 10.6"; ideal for reclaiming and finger joint blocks; there is no max.length capacity. -- (2) Opposing, counter-rotating heads process stock via (2) 5.5 HP motors and 40 mm spindles; tongue & groove profiles are simultaneously cut on the trailing end of one board and the leading end of the next; a PLC controls feeding, clamping, and cutting. -- Feed speeds up to 295 FPM with processing speeds up to 77 FPM (based on 6-1/2' incoming stock) are possible. -- The PLC tallies the piece count and displays the results via a touch-screen control panel, which can be set to shutdown once the desired count is reached; different operating parameters such as operating speed can be set on the touch-screen. -- Equipped with: Safety and sound enclosure, powered 133" infeed roller system, and 129" gravity drop outfeed table system. -- Different infeed & outfeed lengths may be ordered, on request; includes (1) set of stackable cutterheads w/insert knives for tongue & groove end matching, including a V-groove cutter, which can be used if desired. -- Setup for different stock dimensions is straight forward and can be accomplished in minutes.
Equipment Location:PACIFIC NORTHWEST, AL
EX-FACTORY INC.
704-841-2001
S. A. WOODS 525 BM-2 End Matcher;(1) Left and (1) Right separated shaper units. -- Tongue unit with: Trim saw approx. 5 HP motor, (1) set of Top/Bottom. heads approx. 5 HP motors for machining the tongue. -- Grooving unit with: (2) sets of Top/Bottom units (4 heads total) for machining the groove, approx. 5 HP motors on each. -- Part Dimensions: Approx. 3/8" - 1" Max. stock thickness, 8" Max. width, and 10" min. by 7.5' Max. length. -- Feed drives: Separate 3 HP gear motor feed units on each machine/conveyor with heavy duty precision link block chains on hardened guide rails, approx. 20 to 60 lugs/Min, dog spacing is every other link, infeed stock holddowns with overhead pressure bars and adjustable shoe pressure. -- Material transport: Heavy duty powered conveyor with 60" wide slick-polished wood strips. Powered overhead rough top transfer belt is supported over the conveyor frame. -- Separate new floor standing control panel for starters and machine controls. 5" & 4" dust collection ports on each end matcher. -- Total load is 40 HP. Overall floor space required is 32' long by 14' wide. total weight approx. 14,000 Lbs. -- Unit can be inspected running until approx. Nov 10, 2017. See video attached.
Equipment Location:EASTERN CDN
Jeff Terrill
800-374-5009 ext:349
