Description:

CANTEK EM-12 Finger Jointer / End Matcher; Machine arranged to finger joint but can be easily converted to end match.Specifications: -- 1.6" to 12" width x .4" to 2" thickness x 10.6" min. length capacity. Unlimited lengths possible. Feed speeds to 295 FPM with approx. production speeds of 77 FPM (based on 6-1/2" incoming boards). -- With standard 118" long infeed table and standard 98" long outfeed table. -- (2) 5-1/2 HP cutterhead motors; 40 mm spindle diameters; 1 HP feed motor; 1/2 HP motor drive to cutterhead carriage; clamping pressure from top and side.Standard equipment and features: -- Heavy-duty self supporting main frame; compact design requires minimum floor space; capable of processing material as short as 11" to an unlimited length. -- Variable speed through-feed systems is controlled by frequency inverter; through-feed system allows the fingers to be cut simultaneously on the tail of one board and the leading edge of the next board. -- Powered top urethane rolls and spring loaded bed rollers feed the material into position for processing. -- Pneumatic side pressure ensures the material is held square against the fence. -- Complete safety and noise reduction enclosure; convenient touch screen control is used to quickly activate and adjust the machine functions. -- Infeed and Outfeed roller conveyor
