Woodworking Equipment For Sale

SCM - S 52, ...Straight Knife Planer20" Width cap.; knife cutterhead; 9 HP main motor (approx.); 1/8" to 9-1/4" motorized opening with mechanical digital readout; max. depth of cut 5/16"; 10" min. length of workpiece; (4) feed speeds at: 21 - 32 - 42 & 55 FPM; table size: 20-1/2" x 33-1/4". -- Equipped with: Chip breaker; sectional grooved infeed & solid outfeed roller.

SCM - S520 E, ...Planer Specifications: -- 20" Width cap.; 9 HP main motor; 4-3/4" dia. 4-knife TERSA cutterhead at 4,500 RPM. -- 1/8" - 9-1/4" Powered opening with digital readout for fine adjustment; max. depth of cut 5/16"; 10" min. length of workpiece. -- (4) Feed speeds: 20 - 33 - 43 & 56 FPM; table size 20-3/4" x 39".Equipped with: -- Chip breaker; sectional grooved infeed & solid outfeed rollers; (2) adjustable bed rollers. -- Complete with: Magnetic starter & shaving hood.

SCM TOP 35 BORING MACHINE(35) Spindles on 32 mm centers, pivoting boring head, drills vertically from the top and horizontally from the rear,Specifications: -- 0° - 90° Motorized tilting of the head, can be locked at any angle between; max. panel width 1.280 mm. -- (2) 6 HP - 2,800 RPM Motor; quick boring depth setting with (6) depth stops on revolving turret, viscous damper for smooth drilling & through boring. -- Designed with: Lead screw w/veneer scale for head displacement setup.Complete with: -- Back fence w/flip stops, plus fence extension with (4) mechanical reference stops, (4) pneumatic hold-downs; 33" worktable height.

SCMI OLIMPIC K 560TE EDGEBANDER (W/PRE-MILLING): -- Specifications: Edge Capacity: 0.4 to 6 mm (0.016 to 1/4") for strip feeding. -- Panel Capacity: Min. panel width: 60 mm (2.375"); min. panel length: 140 mm (5-1/2").Min./max. Panel thickness: 8 - 54 mm (0.375" - 2.125"); min. distance between panels: 600 mm (24").Equipped with: -- Pre-milling Station: (2) 2.0 HP (1.5 kW) motors; rectifies/cleans panels already sized. -- Adjustable Infeed Fence: Manually preset with digital indicator; pneumatic in/out positioning. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: For EVA (Hot Melt) with: Quick change/disconnect Teflon glue pot for fast glue tanks change if needed; Heat up time approx. (10) Min. -- Pressure Section: Manual digital positioning; Teflon coated pneumatic driven roller & (2) spring loaded idle rollers.Workstations: -- End Trimming Station: (2) Front & rear 1/2 HP - 12,000 RPM motors mounted on THK guides; swivels 0° - 15° for straight & angle cutting. -- Top & Bottom Trimming Unit: (2) 0.7 HP - 12.000 RPM Motors; capable of tilting & pneumatic positioning for (3) settings, flush/bevel/radius trimming for quick setup. -- Top & Bottom Profile Scraping Unit with: Digital indicators; large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue scraping Unit: Eliminates any excess glue. -- Buffing Unit: (2)Top/bottom 1/4 HP - 2,800 RPM motors; tilting up to 12°.Operator & Machine Control: -- "STARTOUCH" Controller with: 12" Touchscreen display; capable of storing (100) programs. -- Machine automation by PLC function and encoder positioned in the panel feed track pinion. -- Diagnostics for a quick solution to errors: Process statistics data (i.e., number of pieces/edges) and track feeding.Features & Complete with: -- 2-Speed feed speed of 40 & 60 FPM (12 & 18 MPM); (1) 2-1/2 HP feed drive motor. -- 200 Hz frequency inverter for all trimming units. -- Manual adjustable top hold-down pressure beam. -- Full sound enclosure cover and outboard panel support. -- Actual Model is: SCM OLIMPIC K 560TE

SCMI OLIMPIC K230R EVO EDGEBANDER (W/PRE-MILLING): -- Specifications:0.4mm to 3mm Edge thickness, Panel thickness 8mm to 50mm (0.3" to 1.96"), minimum part width 60mm (2.36"), minimum part length 160mm (6.30").Minimum distance between panels: 559 mm (22";), 29.5 FPM (98 MPM) Fixed feed speed, 1.0 HP (0.75 kW) feed drive.Pre-milling station: (2) 2.0 HP (1.5 kW) motors, to rectify/clean panels already sized. -- Adjustable In-feed Fence: Manually pre-set with digital indicator, pneumatic in/out positioning.Equipped with: 1.5 Kg Teflon-coated glue pot, glue roller application system complete w/automatic recycling device for unused glue.Digital thermostat adjustment for temperature control. pneumatic guillotine, heating time approx. 8-10 min.3-Roll pressure unit w/pneumatic controls for all pressure rollers. -- Automatic strip & coil feed magazineWorkstations:2-Motor front & rear End Trimming (0.5 HP - 12,000 RPM ea. motor.), tilts 0° - 15°, end trimmers mounted on THK guide. -- Top & bottom flush & bevel trims with quick release mount and plug-in motors for quick tooling changes(0.5 HP - 12.000 RPM motor ea.), bevels 0° - 15° with precision digital indicators for quick setup. -- Top & bottom scraping unit w/manual positioning. -- Top & bottom buffing unit (0.25 HP - 3,000 RPM motors), tilts up to 12°. Operator & Machine Control:Orion 1 Plus controller, located at the infeed of the machine. It is capable of operating all the work units via soft touch buttons.It pneumatically tilt’s the end trim unit from the control panel, it eliminates the use of micro switches, as well as control the temperature of the glue.The control is tilted slightly upward for a more ergonomically friendly position for the operator. -- Actual Model is SCM OLIMPIC K230R EVO.

SCMI OLIMPIC K 560 R EDGEBANDER (W/PRE-MILLING): Specifications: -- Edge Capacity, 0.4 to 6 mm (0.016 to 0.25") for strip feeding. -- Panel Capacity, Min. Panel width 60 mm (2.375"); Min Panel length 140 mm (5.5").Min./max. Panel thickness 8 - 54 mm (0.375" - 2.125"); Minimum distance between panels 600 mm (24").Equipped With: -- Pre-milling station: (2) 2.0 HP (1.5 kW) motors, to rectify/clean panels already sized. -- Adjustable In-feed Fence: Manually pre-set with digital indicator, pneumatic in/out positioning. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: For EVA (Hot Melt) with Quick change/disconnect Teflon glue pot for fast glue tanks change if needed. Heat-up time approx. 10 Min. -- Pressure Section: Manual digital positioning; Teflon coated pneumatic driven roller & (2) spring loaded idle rollers.Workstations: -- End Trimming Station: Front & rear 2 x 0.5 HP, 12,000 RPM motors mounted on THK guides, swivels 0° - 15° for straight & angle cutting. -- Top & Bottom Trimming Unit: 2 x 0.7 HP - 12.000 RPM motors, capable of tilting & pneumatic positioning for (3) settings, flush/bevel/radius trimming for quick setup. -- Top & Bottom Profile Scraping Unit: with digital indicators. Large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue scraping Unit: Eliminates any excess glue. -- Buffing Unit: Top/bottom, 2 x 0.25 HP - 2,800 RPM motors, tilting up to 12°.Operator & Machine Control: -- "STARTOUCH" Controller with 12" touchscreen display, capable of storing (100) programs. Machine automation by PLC function and encoder positioned in the panel feed track pinion.Diagnostics for a quick solution to errors. Process statistics data, i.e. No. of pieces/edges, and track feeding.Features & Complete With: -- 2-Speed feed-speed of 40 & 60 FPM (12 & 18 MPM); 1 x 2.5 HP feed drive motor; -- 200 Hz frequency inverter for all trimming units; -- Manual adjustable top hold-down pressure beam; -- Full sound enclosure cover and outboard panel support. -- Actual Model is SCM OLIMPIC K 560 R.

SCMI Olimpic K 360 Compact Edgebander with Pre-Milling.Specifications: -- Edge Capacity, 0.3 to 3 mm (0.012 to 0.118") for coiled edges (0.3 - 6 mm for strips with 6x60 mm kit included). Coil holder-plate dia. 780 mm (31"). -- Panel Capacity, min. width 90 mm and 140 mm min. length, (3.5" and 5.5"). Panel thickness min./max. 8 - 50 mm (3/8" - 2") - max. 60 mm (2.4" with 6x60 kit, included. Equipped With: -- Adjustable In-feed Fence: Manually pre-set with digital indicator, pneumatic in/out positioning. -- Pre-Milling Station, RT-VP: Spindles 2 x 2.0 HP, 19,000 RPM, (1) with PLC controlled jump action and diamond cutter heads -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: For EVA (Hot Melt) with Teflon coated glue tank and quick disconnect to change glue tanks fast if needed. Heat-up time approx. 10 Min. Includes 1.5 kg glue pot instead of standard. -- Pressure Section: Manual digital positioning, (3) pressure rollers, first larger, Teflon coated and powered. Workstations: -- End Trimming Station, K2: Front & rear 2 x 0.5 HP (included extra), 12,000 RPM motors mounted on THK guides, swivels 0° - 15°, rapid set up between straight and angled cutting with the automatic swivel cylinder. Automatic positioning for (3) cutting modes: straight, chamfered, and radiusing of thick edges -- Top & Bottom Trimming Unit, R-K: Trimming unit. Remote (via control panel) pneumatic positioning for (3) settings, flush/bevel/radius trimming, 2 x 0.7 HP - 12.000 RPM motors with precision digital indicators for quick setup. -- Top & Bottom Profile Scraping Unit: Manual pre-set up with digital indicators. Large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Buffing Unit, SP-V: Top/bottom, 2 x 0.25 HP - 2,800 RPM motors, tilting up to 12°. Cleaning and polishing of edges.Controls: -- Orion 1 Plus Controller, fixed at in-feed of machine. with soft keys, graphics and 4" LCD display panel. It handles most machine set-up functions and workstations. Machine automation by PLC function and encoder positioned in the panel feed track pinion. Diagnostics for a quick solution to many errors. Process statistics data, ie. No. of pieces/edges, and track feeding.Features & Complete With: -- Feed-speed, 36 FPM fixed, 1 x 2.0 HP feed drive motor, 200 Hz frequency inverter for all trimming units, manual adjustable hold-down pressure beam, full sound enclosure cover and outboard panel support. -- Overall dimensions:3600 mm (142") x 900 mm (36") x 1600 mm (63"). Weight approx. 997 Kgs ( 2,200 Lbs). -- UL/CSA approved version.

SCMI MINI MAX Formula S 2 Sliding Table SawSpecifications & Features: -- 128" Cutting cap. w/ Standard scoring saw and carriage, 5 HP motor, stop on fence for cuts extendable to 128"; 50" Cutting width w/ rip fence.Equipped with: -- 14" main blade, 4-1/2" scoring blade, 4-1/2" max. blade cutting height at 90°, 3-1/2" max. blade cutting height at 45°. -- 4,000 RPM Main blade speed, 8,500 RPM scoring blade; 90° - 45° blade tilting.

SCM Sandya 5 Wide Belt Thickness Sander (Model 5 RCS 110)43" width cap, Drum, Combination headHead configuration1ST Head : Contact roll, 5-1/2″ dia., 25 HP motor;2nd Head: Combination head, rubber covered contact roll, 5-1/2″ dia., and 2″ wide finishing platen for veneer, 18 HP motor.Specifications -- 43″ x 85″ or 103″ Abrasive belts with electronic tracking & pneumatic belt tensioning, -- Pneumatic exclusion of all contact rolls. -- Conveyor belt feed with variable feed speed, 10 – 60 FPM, 3 HP feed motor, Equipped with & Features: -- Automatic part thickness adjustment, -- Motorized thickness opening with LED readout, -- 0″ – 6-1/4″ via (4) precision conveyor bed jacks. -- In feed & out feed spring loaded rubber covered hold down rolls on all heads, -- Motor load meters -- In feed and out feed conveyor extensions. -- Automatic advancement carpet -- Grooved rubber precision rollers Aspiration dust fans -- Emergency device to save hands while pieces in feedingMore info -- Dimensions 77″ x 64″ x 92″ Weight 1210 kG - Specifications, Dimensions & Weight data are to the best of our knowledge.

SCM TECNOMAX - SC/4 WS, ...8-1/2' Sliding Table SawSpecifications: -- Max. depth of cut with 315 mm (12.40"); dia. blade: 100 mm (3.94") at 90°; 70 mm (2.76") at 45°. -- Main saw: 3.6 kW (4.82 HP) Motor; blade dia. 315 mm (12.40"); arbor tilt 0° - 45°; blade speed 4,000 RPM. -- Scoring saw: Blade dia. 100 mm (3.94").Equipped with: -- 11-1/2"; x 102"; x 35-1/2"; H Aluminum sliding table; 840 mm (33.07") LR fixed table. -- Manual raise, lower & tilt. -- Mechanical digital tilt indicator.Complete with: -- 39-1/4"; L x 3-1/2"; H Rip fence with: 51" Cutting width cap. & cam locking. -- 650 x 1,100 mm (29.59" x 43.32") Squaring frame with: Crosscut fence; 1,800 mm (70.87") cutting cap.; (2) flip stops & siding outrigger support.NOTE: Saw is deinstalled as pictured in Photo #2. - Photo #1 shows Seller's other Saw, which is also available to purchase (EXF # PS-011935). Both Saws are one serial number apart. Seller confirms that all machine components are present.

SCM SI 350 N - 10-1/2', ...Sliding Table SawSpecifications: -- Cutting length 3,200 mm (126"); max. depth of cut: 118 mm (4.65") at 90°; 81 mm (3.19") at 45°. -- Main saw: 6.6 kW (9 HP) Motor; blade dia. 250 - 350 mm (9.84" - 13.78"); arbor dia. 1"; arbor tilt 0° - 45°; blade speed 4,000 RPM. -- Scoring saw: 0.75 kW (1 HP) Motor; max. blade dia. 120 mm (4.72"); arbor dia. 20 mm (3/4"); blade speed 8,500 RPM; external scoring blade adjustments.Equipped with: -- 14-1/4"; x 126"; x 35-1/2"; H Aluminum sliding table; 630 mm (24.80") x 1,040 mm (40.94") Fixed table. -- 2-Position table lock mechanism; manual raise, lower & tilt. -- Mechanical digital tilt indicator. -- Pivoting blade guard with dust outlet.Complete with: -- 47-1/4"; L x 3-1/2"; H Rip Fence with: 67" Cutting width cap. -- Crosscut Fence with: 84" Cutting cap.; (2) flip stops & Sliding outrigger support.

SCMI SI 16 W Sliding Table Panel SawSpecifications: -- 126" Cap. with scoring, 9 HP main and 1 HP scoring motors; tilting arbor 0° - 45°, 5-1/2" depth of cut with 15-3/4" blade dia.; 3,200 - 4,500 & 6,000 RPM arbor speed; 59" max. width to rip fence. -- Complete with: -- Telescoping crosscut fence with (2) large flip stops, mechanical work holddown attachment, 2-position sliding table lock and push button magnetic controls.

SCM TECNOMAX SC/4 WS 8-1/2' Sliding Table SawSpecifications: -- Max. depth of cut with 315 mm (12.40") Dia. blade: 100 mm (3.94") at 90°, 70 mm (2.76") at 45°. -- Main saw: 3.6 kW (4.82 HP) Motor, Blade dia. 315 mm (12.40"), Arbor tilt 0° - 45°, Blade speed 4,000 RPM. -- Scoring saw: Blade dia. 100 mm (3.94").Equipped with: -- 11-1/2"; x 102"; x 35-1/2"; H Aluminum sliding table, 840 mm (33.07") LR Fixed table. -- Manual raise, lower & tilt. -- Mechanical digital tilt indicator.Complete with: -- 39-1/4"; L x 3-1/2"; H Rip fence, with 51" Cutting width cap. & Cam-locking. -- 650 x 1,100 mm (29.59" x 43.32") Squaring frame, with Crosscut fence with 1,800 mm (70.87") Cutting cap., (2) Flip stops & Sliding outrigger support.Actual model is SC/4 WS-N.

SCM MINIMAX - FORMULA S1, ...Sliding Table SawSpecifications: -- 120" Cap. with: Scoring; 9 HP main motor & belt driven scoring blade; -- Manual tilting of the arbor 0° - 45°; Manual raise-and-lower of the main blade; -- 50" crosscut capacity with a movable fence.Features: -- "Easy-Set" scoring adjustment; heavy cast iron trunnion; 12" main saw blade dia. with 1" Arbor, 110 mm scoring blade dia.; -- Max. cutting height 3-1/2" at 90° & 2-3/4" at 45°; 1-speed arbor; 8,000 RPM on scoring blade. -- Complete with: 4" Main dust extraction outlet, miter fence & crosscut fence assembly with (2) flip stops.

SCM SANDYA 10/S M2 2-Head Wide Belt SanderHead Configuration1st Head: 7" Diameter Spirally-grooved steel contact roll, 20 HP Motor.2nd Head: Combination head, 7" Diameter Spirally-grooved rubber-coated contact roll, Finishing platen with Electronic sectional pad with EPICS System, 3-1/2" Steel contact roll, 13 kW (17-1/2 HP) Motor.Specifications: -- 4.5 - 9 m/min (15 - 30 FPM) Variable feed speeds, -- Part thickness 4 mm (0.2") to 170 mm (6.7"). -- 43" W x 103" L Abrasive belt, Electronic sanding belt tracking & Pneumatic belt tensioning. -- 34" H Natural rubber feed belt,Equipped with & Features -- Automatic thickness adjustment, Automatic feed belt tracking & Tensioning, -- Motorized rise & fall of working table, -- Part thickness & Conveyor belt speed LED readout, -- Infeed safety bar for operator protection and oversized parts. -- 3" Diameter Entry & exit rolls, 13" L 2-Roll Infeed & Outfeed extensions with 2" Diameter Rollers & Manifold. -- Unopened box of (10) KP520 100 Grit Belts (Purchased for $500).Dimensions: 88" L x 86" W x 90" H.Weight: 4,440 Lbs.

SCMI SANDYA S300 RCS 110 DUAL HEAD WIDE BELT SANDER43" Width capacity, (1) contact roll & (1) combination head with contact roll & segmented platen.Head Configuration1st Head : 5-1/2" diameter steel calibrating contact roll2nd Head : 5-1/2" diameter rubber covered contact roll and adjustable segmented finishing platen.Specifications -- 0" to 6.69" thickness capacity via motorized bed adjustment with auto set up device. -- Abrasive Belt dimensions 43" X 75" -- Rubber coated pressing rollers before and after working unit -- 1 HP Inverter variable speed feed unit. -- Feed speeds 10 - 60 FPMEquipped with and Features -- Y-Delta two-stage reduced voltage starter on 18 HP main motor -- 2 Roller Infeed and Outfeed table extensions -- Automatic Electronic Table Positioning Device -- Adjustable sanding drum and pad position for micro precision adjustment -- Electronic digital thickness readout of work table position -- Powered table lifting by means of (4) heavy duty motor and lifting columns double fastened at both top and bottom of the lifting columns to provide exceptional table stability -- Electronic tracking of abrasive belt -- Automatic feed mat tracking -- Pneumatic belt tensioning with center fulcrum to compensate for tapering of abrasive belt

SCMI STARTECH/23 23-Spindle Construction Boring Machine.Specifications: -- Distance between spindles 32 mm (1.26"), Maximum drilling head distance 704 mm (27.72"), Maximum drilling depth 45 mm (1.77"). -- Panel thickness 10 - 75 mm (0.39" - 2.95"), Maximum panel width under bridge 1,000 mm (39.37"). -- Maximum panel size:270 mm(10.63") (with vertical head), 130 mm (5.12") (with horizontal head). -- Drilling head stroke 63 mm (2.48"), Tool diameter 5 - 10 mm (0.20" - 0.39"), Tool length 55 - 75 mm (2.17" - 2.95"). -- 26-1/4" x 40" x 33-1/2" H Table, 2.64 kW (3-1/2 HP) 3,390 RPM Motor.Equipped with: -- 23-Spindle Boring head (Aluminum alloy single block), Drills vertically from top & horizontally from rear. -- Manual tilt with Gas shock cylinder assist, Positive stop at 45° for boring at angle. -- 6-Position Turret depth stop. -- (2) 3" Diameter Air hold-down clamps, Foot pedal operated. -- Index pins for line boring, 15-1/4" L x 1-1/2" H Side fences.Complete with: Operation & Maintenance Manual & SHOP FOX Mobile Base with Swivel Casters. -- Dimensions: 58" x 48" x 46" H. Weight: 1,100 Lbs.

SCM - OLIMPIC K 201 HFA, ...Automatic Compact Edgebander with: 3 mm Max. coiled edgebanding thickness & High Frequency motorsSpecifications: -- Edgebanding thickness cap. (for both coil & strip): 0.4 - 3 mm (0.02" - 0.19"). -- Min. panel length for coiled edges (min. width 200 mm) 140 mm (5.51"). -- Min. panel width for coiled edges: 65 mm (2.56"). -- Panel thickness: 8 - 40 mm (0.31" - 1.57"). -- Feed speed:9 MPM (29 FPM).Equipped with: -- Automatic adjustment of all units when panel thickness is changed. -- 20" Dia. coil table. -- Automatic coil feed magazine; manual strip feed. -- Teflon-coated glue pot. -- 1.2 mm (0.05") Cap. guillotine. -- Eye-level control with: GEFRAN "1000" LED Temperature controller. -- Adjustable feet.Workstations: -- Single-motor end trimming unit with: (1) 0.19 kW (1/4 HP) - 12,000 RPM High-frequency motor & copying device. -- Top & bottom flush trimming unit with: (2) 0.35 kW (1/2 HP) - 12,000 RPM high-frequency motors, and front & vertical copying devices.

SCM S 630 PLANER WITH TERSA HEADSpecifications: -- 24" Width cap.; 12 HP main motor, 2 HP feed motor; 4-3/4" dia. with reversible knife TERSA Planer Head rotates @ 4,500 RPM; -- 1/8" - 11-3/4" Thickness opening via motorized bed with LED readout for fine adjustment. -- Max. depth of cut 5/16"; 10" min. length of work piece; variable infeed speed from 20 - 56 FPM.Equipped with: -- 20-3/4" x 39" Cast iron table, sectional chip breaker, sectional grooved infeed & solid outfeed rollers, adjustable bed rollers. -- neoprene out feed rollersComplete with: -- Magnetic starter and dust hood w/6" dia. dust outlet.Owner states: Condition- like new 24" thickness planer- third owner in a one man shop. Machine has seen very few hours of operation.

SCM STARTECH CN - CNC MULTI SPINDLE DRILLINGFeatures: -- Easy Motion Work Table -- 7" Touchscreen -- (7) Independent Vertical Boring SpindlesSpecifications: -- Maximum Panel Dimensions X-Y-Z (3050mm x 800mm x 50mm), Minimum Panel Dimensions X-Y-Z (300 mm X 90 mm x 10 mm) -- Drilling/Grooving working area: 0mm x 800 mm/0mm x 800 mm ÷X-Axis Stroke: 750 mm÷X-Y maximum axis speed: 25m/Min. -- Vertical Spindles: 7 (4X-4Y one of them is shared) Horizontal Spindles: (along Y-axis): 2 (1+1) -- Horizontal Spindles: (along X axis): -- 1 Fixed Integrated Blade (cutting into direction): X Blade Diameter: 100 mm Maximum Blade Thickness: 5 mm -- Motor Power: 3 HP (2.2 kW) Spindle Rotation Speed: 3350 RPM÷Blade Rotation Speed: 4300 RPM -- Electrical Supply: 230 Volt (60 Hz) Installed Motor Power: 4.5 KVAHigh-performance numeric controlled (NC) Drilling Machine engineered for full-production woodworking shops and craftsmen. The Startech CN drilling head's seven (7) independent vertical spindles, the spindle and blade in the “X"; axis, and the possibility of drilling in the “Y"; axis make it both flexible and ideal for batch furniture productions. This machine allows the operator unparalleled flexibility for tailored products without the need of operator intervention for the worktable and machine set-up according to the panel dimensions.
