Woodworking Equipment For Sale

MORBIDELLI - N 100 15. Flat Table Machine with: ATC, Boring -- Specifications5' x 12' x 37"; H - High efficiency laminate aluminum with: Vacuum locking system.Grid pattern allows: Use of vacuum pods or closed cell rope gasket material; use of spoilboards for nested-base machining. Part location pop-up pins mounted on: Table perimeter; chips conveying device. -- Working AreaX-Axis: 3,686 mm (145.12"); Y-Axis: 1,555 mm (61.22"); Z- Axis stroke: 250 mm (9.8"); Z- Axis: 150 mm (5.9"). -- TravelsX-Axis: 4,230 mm (166.54"); Y-Axis: 1,985 mm (78.15"); Z-Axis: 250 mm (9.84"). -- Positioning SpeedsX- & Y- Axes: 35 MPM (114 FPM); moving gantry, high precision rack & pinion system for: X & Y Axes; ground ball screws for: Z-Axis. All axes ride on extra large precision profile linear guide ways. -- Boring Unit2.2 kW (3 HP) Motor; (12) independent vertical roto-axial spindles with: (8) In X-Axis; (4) in Y-Axis; max. spindle speed: 8,000 RPM. -- Machining(1) 9.6 kW (13 HP) Air-cooled electrospindle with: HSK F63 Adaptor; variable spindle speeds: 1,500 - 24,000 RPM; (1) 14-position TR side tool changer. -- Operator InterfaceMobile console: 17" LCD Display with Windows 7 Operating System.“XILOG PLUS Operator Interface & Xilog MAESRO CAD CAM free-form software with labeling. "MAESTRO SUITE" with: Auto-diagnostic to zooming; controlled acceleration & deceleration; encoder feedback; dynamic tool correction via PLC: Due to active tool wear using space-and-time criteria; "TECPAD" remote pendant with: 7" Color touchscreen & fitted with a USB port, which allows for a quick load & setup of new programs. -- Complete with: (1) 300 CBM/Hr Vacuum Pumps; air-conditioned electrical cabinet. - Universal 3-phase transformer.Electronic tool detecting length (touch probe) allows for: Detecting tool length without running a test program.Safety bumpers on both sides of the mobile unit allow: Safe movement while saving space by eliminating caging around the machine.

12 vertical spindles X 16 vertical spindles Y 3 vertical hinge units 3 vertical spindles in Y 2 + 2 horizontal spindles in X 2 horizontal spindles in Y Y Prime: 11 vertical spindles in X, 3 vertical spindles in Y, 2 + 2 horizontal spindles in X 2x 10HP electrospindle (HSK 63F) - one lower & one upper 6 + 6 position tool holder: to manage 6 tools for upper electrospindle and 6 tools for lower electrospindle Loading table: table with cross belts for pre-loading 2 overlapped panels Unloading station with cross belts Auto-transformer Included (208, 230, or 460 volt) AC electrical cabinet Automatic Lubrication System

MORBIDELLI - X200: Flat Table Machine with ATC / BORING / RAKE / OFFLOADING -- Specifications5' x 10' Traveling "Bridge Gantry"; stationary aluminum "MATRIX" grid table with: Square grid pattern for fixturing parts.Grid pattern allows: Use of vacuum pods or closed cell rope gasketing material; use of spoil boards for "nested base machining".(8) Vacuum zones controlled by electronic switches; (5) part location pop-up pins mounted on the table perimeter.Working Flow from left-to-right direction. -- Working Field"X" Axis: 123" (3,117 mm); "Y" axis: 61" (1,557 mm); "Z" axis stroke: 9.4" (240 mm); max. material thickness: 5.9" (150 mm). -- Work TableWorktable divided into (8) Vacuum Zones with: Automatic & manual selection. -- Positioning SpeedPRO-SPEED "X" & "Y" Axis vectorial speed; 370 FPM (113 MPM); "Z" axis positioning: 82 FPM (26 MPM); closed loop AC Servo drive system.High precision "Rack & Pinion" system in: "X" & "Y" axis; ground ball screws "Z" axis; all axes ride on extra-large precision profile linear guideways. -- Boring Unit"F16V Ro.Ax" Boring Unit: 3 HP (2.2 kW); variable speed: 1,000 - 8,000 Max. RPM motor.(16) Independent vertical spindles on 32 mm Centers; (8) spindles in: "X" axis; (8) spindles in: "Y" axis. (12) Horizontal Spindles with: (4 + 4) in "X" axis; (2 + 2) in "Y" axis. (1) "X" Axis Grooving Saw with: Max. 120 mm dia. blade. -- Machining(1) 20 HP (14 KW) Air-cooled electro spindle with: HSK F63 Adaptor; variable spindle speeds: 1,500 - 24,000 RPM.(1) 14-Position "FAST 14" ATC tool rack mounted inside the protective cage on the mobile unit. -- Operator InterfacePC Front-End with: "Eye-M"; + "Maestro-Active HMI" (Human-Machine Interface Software) + Windows "10" Operating System.21-1/2" Full HD touchscreen; USB ports; serial ports: RS-232 & RS-242; Ethernet adaptor.Programs can be transferred via USB or downloading by wire is possible; all computer components are mounted on a mobile stand. "Xilog Maestro Active HMI" (Human Machine Interface software)"; offers incredible list of functions from: (a) Auto-diagnostic to (z) zooming; controlled acceleration & deceleration; encoder feedback; dynamic tool correction via PLC due to active tool wear using space-and-time criteria.MSL Connector (Maestro Scripting Language): Software module developed by SCM Group to directly connect its own CNC machines with: Main 3rd Party software packages available on the market.Maestro is: Protected against unauthorized copy through a hardware USB key.Includes 1-License for: "Xilog Maestro CAD CAM" Free Form Software + Maestro-Connect: (1) Year subscription service.Maestro-Connect: Complete hardware preset for IoT Platform. Additionally equipped with onboard mini-CAD with: Built-in programming for writing circles, ellipses, & angles with only a few keystrokes.Onboard cycle optimization, onboard calculator, mirror imaging, and repeat imaging. -- Complete with:(2) 300 m³/Hr Vacuum Pumps; Handheld "TECPAD" remote control with: 7" Touchscreen, co

CNCPD 5 axis gear head 10 hp Yaskawa VFD 9 hp Hiteco ATC spindle motor Fagor 8055 Power CNC system controller Ethernet Tool center programming 5 position tool stand CNCPD tool height setter Moving wires and cables replaced New wiring and plumbing to spindle Spare parts included Vetric Aspire and Fusion 360 Post Processors Assorted tooling included, see pictures Transformer to step up from 220 V to 440 V (2) 10 hp 220 V vacuum turbine pumps

ME R80 14" Radial Arm Saw

Infeed Deck & Conveyors. Infeed Deck: 12' motorized chain driven - 4 metal chains. Stationary table with 4 sets of 5.5" rollers for Moulder

MULTICAM APEX 3R with 5' X 10' Table and ATC:60" x 120" Fixed table, moving gantry machine in a front-to-back configuration with a multi-zone vacuum table supported by a 20 HP vacuum blower system. -- Equipped with:(1) 10 HP "HSD" spindle with 8-position static tool changer, variable speed by inverter up to 24,000 RPM. -- Full table coverage:X- & Y-axis, rack & pinion gantry drive with brushless Servo motors using integrated 25 mm linear roller bearing rack system, 8" Z-axis travel via lead screw drive. 1,000 IPM Max. cutting feed, 1,700 IPM max. rapid traverse rate on X- & Y-axis. -- Control:The MULTICAM CNC controller Is a stand-alone RISC/DSP system. The controller includes a keypad interface with hot keys for repetitious functions and DNC access to host computer. Memory for instant job replay, 32-bit processor, 12 MB RAM & 2 MB flash memory, interprets HPGL and M & G codes, RS-232 interface for PC communication. -- Includes:(20 HP) Vacuum blower for hold-down, assorted collets and tool-holder will be included.

MULTICAM APEX 3R with 4' X 8' Table and ATC:48" x 96" Fixed table, moving gantry machine in a front-to-back configuration with a 4-zone vacuum table supported by a 20 HP Republic vacuum blower system. -- Equipped with:(1) 13.4 HP "HSD" spindle with HSK F63 adaptor. (1) 6-position static tool changer, variable speed by inverter up to 24,000 RPM. -- 4 Zone Pneumatic Table:X- & Y-axis, rack & pinion gantry drive with brushless Servo motors using integrated 25 mm linear roller bearing rack system, 6" Z-axis clearance via lead screw drive. 1,000 IPM Max. cutting feed, 1,700 IPM max. rapid traverse rate on X- & Y-axis. -- Control:The MULTICAM Pendant Programmable Controller, PC, is a stand-alone RISC/DSP system. The controller includes a keypad interface with hot keys for repetitious functions and DNC access to host computer. Memory for instant job replay, 32-bit processor, 12 MB RAM & 2 MB flash memory, interprets HPGL and M & G codes, RS-232 interface for PC communication. -- Includes:Surface Probe and Auto Calibration Sensor; Laser Pointer System; Dual Knife System (Electric Oscillating and Quick Change); K31 Multi-Tool Cutting Head; K41Knife Cutting Head; (1) 20 HP Republic vacuum blower for hold-down, (6) collets and tool-holder will be included.

(2) Saws sold as a pair Used for ripping 48" plywood and wafer board Saws can be adjusted anywhere on the shaft. Single Phase motors and variable speed drive motor, 2hp on main shaft.

Multiscore CD 4 Panel Grover Capacity: 30" X 50" Weight: 3500# Dimensions: Length: 70" Width: 78" Height: 51" Table Height: 36" Arbor Drive Motor: 15 HP 3450 RPM Feed Drive Motor: ¾HP geared, with brake Feed Speed: 50 f.p.m. Electric Service Tooling: 480V, 3 phase Dust collection: One 10" diameter outlet

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5y 15 HP Fan motor, free-standing interior/exterior unit rated @ 3,900 CFM. Equipped with: (48) Filter bags having a total of 352 sq. ft. of cloth filter area in a fabricated steel enclosure; 12" dia. inlet. Magnetic starter; rotary air lock, estimated weight: 3,500 Lbs. Unit stands 13.5' tall when fully assembled, but with the legs and muffler removed, it can easily be transported on an open 5'x10' trailer. Machine State: Still in place, but disconnected NOTE: The above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

MURPHY-RODGERS HEC-216-S/10 33,000 CFM Continuous Duty Automatic Self-Cleaning Pulse Jet Baghouse Dust Collector Equipped with: (216) 5" Dia. x 10' L Cloth filter bags for a total of 2,827 sq/ff. of filter area. (2) 42-1/2" W x 68" H & (2) 40-1/2" x 68" H Top access doors. (3) Front & (2) side 27" W x 54" H Filter access doors. (2) Square cone bottom hoppers, Each with, 25" x 25" Discharge openings. System utilizes (2) 4-1/2’ x 6’ x 4’ H Waste containers (NOT included). CHICAGO 100 HP - 1,780 RPM Roof-mounted blower, with 41” Dia. inlet. Motorized dampers for winter & summer modes. Winter mode: Directs air back into building, reducing heat loss. Summer mode: Directs air outside, cooling building. Electrical controls (as pictured). Complete with: Spare Filter Bags. NOTE: Installed Used in 2016 with "New" 100 HP motor, new bearings in blower & "New" spring mounts. NOTE: Variable Frequency Drive needs to be replaced. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

NANXING MJK1132F1 Sliding Table Saw w/Motorized Raise/Lower/Tilt & Programmable Rip FenceUp, down, and tilting of the main saw and scoring saw blades are controlled electrically by simply pressing buttons. The rip fence enables movement to the required position by inputting a number on a user-friendly touchscreenSpecifications & Features: -- 3,100 mm (122") Cutting length w/scoring; 126" x 16" Anodized sliding table that locks in any position for easy loading. -- Saw blade moves up or down, tilting and fence movement driven by electric servo motor. -- Scoring unit for clean, accurate chip-free cutting, ready for edge banding. Equipped with: -- 7.5 HP Main saw motor; 45° tilting (30 mm) main saw arbor; 13.77" (350 mm) main blade dia.; 3,800/5,200 RPM; -- 4" Max. material thickness at 90°; 2-3/4" at 45°. -- 1.5 HP Scoring saw motor, 4.72" dia. scoring blade; 9,000 RPM. -- Extendable crosscut fence with (2) flip stops, w/digital readout. -- Miter fence; articulating overarm protection guard; outboard and rear extension tables.

NASH 50-72 Spindle Sander(10) Spindles, 72" chucking cap., 3/8" - 6" dia. range;Specifications: -- 2-1/4" Dia. main arbor with long keys for driving head & tailstock wheels. -- Variable spindle speeds from 700 - 3,000 RPM, 7.5 HP spindle motor, 2 HP feed & oscillation rack motor, variable oscillating speed (60 - 120) strokes/Min, oscillating stroke adjustable up to 2" in length. -- (5) 72" Sanding racks, self-adjusting & oscillating. -- Equipped with: Overhead mounted dust hood, push-button control panel; production rate of (10 - 30) pieces/Min. -- Includes: brushes and sandpaper

NASH - 50-72: Spindle Sander -- (10) Spindles; 72" chucking. -- Cap., 3/8" - 6" dia. range; 2-1/4" dia. main arbor with long keys for driving head & tailstock wheels. -- Variable spindle speeds: 700 - 3,000 RPM; 7.5 HP spindle motor. -- 2 HP Feed & oscillation sanding rack motor; 60" max. sanding cap. with: (5) Sanding racks, self-adjusting and oscillating. -- Variable oscillating speed: (60 - 120) Strokes/Min; oscillating stroke adjustable up to 2" in length.Equipped with: -- Overhead mounted dust hood., -- Push-button control panel; production rate of (10 - 30) pieces/Min.

New Venture Manufacturing Gang Rip Saw Hydraulic Tank (5) Moving Blades Laser Tower Touchscreen Controls This machine has been removed from service. The photos showing the system setup were taken before it was removed

Newman KF-24 Gang Rip Saw

This Newman HP-688 press is powered by a 10 HP hydraulic pump. It consists of two 30? X 74? bays. Each bay has (3) individual 24? X 30? platens. Each platen is 15/16? thick and it’s back structure is webbed every 5-1/2? X 7-1/2?. Each platen is driven by a 5? hydraulic cylinder with it’s own control. The max daylight opening is 48? while the minimum is 37?. On the bottom you will find pop up bed rolls. Over all the press is in excellent condition, is extremely heavily built. This fully functional machine has been fully cleaned, checked, and is ready to work

Newman HP-688 Twin Bay Hydraulic Cold Press6-Sections (top platens) each 24" x 30" each, Center posts between third and fourth platens, creating two overall areas of 30" x 74". Specifications: -- Max. fixed opening 48" with 11" cylinder stroke, each platen section has (1) 10" bore with 5" dia. ram cylinder; -- Each platen is 15/16″ thick and it’s back structure is webbed every 5-1/2″ X 7-1/2″. -- Side-mounted self-contained hydraulic system w/tank, 10 HP continuous operating pressure compensating pump. -- Hand-Valves to Cycle Individual Platens with pressure gauges for each platen. -- Idle Pop-Up Bed Rollers in the bottom platen for easy loading and unloading.Over all the press is in excellent condition, is extremely heavily built, and is also a beautiful impressive press in person.

Newman Power Feed 24"x12' rollcase with spiral positioner, infeed to planer, electric variable drive
