Woodworking Equipment For Sale

BOERE - TPK-900, ...Planer Sander with (2) Heads -- 2-Head, 900 mm (36") width cap.; -- Equipped with (1) Knife planer head and (1) Rubberized Drum. -- 1st Head. Helical knife planer head with: (4) Spirals of 4-sided carbide inserts, each 14 mm x 14 mm; 20 HP motor. -- 2nd Head. Drum approx. 10" dia. rubber covered contact roll; 15 HP motor; all heads with air-operated caliper disc brakes. -- Variable feed speed: 13 - 52 FPM; 2-1/2 HP motor; automatic conveyor belt tracking; -- Anti-kickback fingers on infeed; infeed hold-down shoes' double outfeed pinch rolls on outfeed. -- Motorized part thickness adjustment: 0" - 6"; LED readout display. Complete with: -- Controls are mounted on the belt loading side, load meters for each head, and conveyor infeed extension.

50” width drum/drum/platen heads 480 volt 3-phase Bottom and top sanders can be sold separately Pictures coming for bottom sander

BOSS - BOSS 4×8 Performance with ATC: -- Specifications:• Industrial Windows 10 Computer with SSD Hard drive, keyboard and mouse• 22" High-Definition Monitor• 10 HP HSD ATC Spindle• 8 Tool Change Positions• 1KW 3000 RPM Leadshine AC Servo Motors• 10:1 Apex Planetary Gearboxes• 3/4 Nook Ballscrew on Z Axis• Rack & Pinion with 2 inch- Diameter Pinions on X and Y Axis• Gantry is driven on both sides with AC Servo Motors• CE Solid Phenolic Table High Flow Vacuum Design• ASTM 8500 3x3, 3/16"; gauge heavy duty steel• Hybrid Steel Gantry – 4X6 & 4X4 Thick Wall Steel Welded Frame• 10 Hp Vacuum Blower• ROUTER-Cad programming software,• Touch off device• Docs, manuals.• Software Disclaimer:EX-Factory, INC offers NO warranty or support, written or implied concerning any/all "optional" or "additional" manufacturer or 3rd party software supplied with this machine. All software related issues including re-licensing fees/requirements/functionality & training is ultimately the sole responsibility of the "Buyer"

Brandt KDF 440C Edgebander

Great Condition Recently Fully Serviced Profile Scrapers and Surface Scrapers No Premill/No Buffers

Brandt KDN 770 2C Machine has been removed from service. Owner claims it is ready to run! Specs (to be confirmed): Hot Melt granulate quick heat-up glue system, overhead glue tank for easy maintenance & glue color change. Automatic magazine for strip & coil (large 800 mm dia. coil table to accommodate large coils of 3 mm PVC) stock, 3 mm PVC guillotine. (1) Drive plus (3) idle rolls "pneumatically controlled" pressure sections. End Trimming: 0.33 HP - 12,000 RPM Motors, chamfers 0° - 15°. Flush Trimming: Top & bottom, bevels 0° - 15° with (4) revolver type index pre-sets, (2) 0.5 HP - 12,000 RPM motors, cutter heads with insert knives. Fine/Radius Trimming: Top & bottom, bevels 0° - 15° with (4) revolver type index presets (0.5 HP - 12,000 RPM motors), cutter heads with insert knives for 3 mm PVC radius. 2 motor corner rounding Scraping Unit: Top & bottom for 2 - 6 mm radius, pneumatically controlled blowoff nozzles. Buffing Unit: Top & bottom buffing (0.25 HP - 1,400 RPM motors). Variable feed chain track speed from 8 - 20 MPM (26 - 65 FPM), 2 HP feed drive.

BRANDT - KDN 770-2C: EdgebanderSpecifications -- Hot Melt granulate quick heat up glue system; overhead glue tank for easy maintenance & glue color change. -- Automatic magazine for strip & coil: Large 800 mm dia. coil table to accommodate large coils of 3 mm PVC stock; 3 mm PVC guillotine. -- (1) Drive plus: (3) Idle rolls "pneumatically controlled" pressure sections. -- End Trimming: 0.33 HP - 12,000 RPM Motors; chamfers 0° - 15°. -- Flush Trimming. Top & bottom bevels 0° - 15° with: (4) Revolver type index presets; (2) 1/2 HP - 12,000 RPM motors; cutterheads with insert knives.Features -- Fine/Radius Trimming. Top & Bottom; bevels 0° - 15° with: (4) Revolver-type index presets; 1/2 HP - 12,000 RPM motors; cutterheads with: Insert knives for 3 mm PVC radius. -- 2-Motor corner rounding. -- Scraping Unit. Top & Bottom for: 2 - 6 mm Radius; pneumatically controlled blowoff nozzles. -- Buffing Unit: Top & bottom buffing; 1/4 HP - 1,400 RPM motors. -- Variable feed chain track speed from: 8 - 20 MPM (26 - 65 FPM); 2 HP feed drive.NOTE: Description based on: Model Type, manufacturer's plate, and information from Seller. Please inspect to confirm the required specifications. Dimensions & weight data are based on 3rd party information and could be incorrect; please verify & confirm if accurate dimensions & weight are required.

Brandt KTD 65 Edgebander

BRANDT KTD 72 ... Contour Edgebander; Features & Specifications: -- Designed for straight & curved edgebanding. 0.5 - 3 mm edge thickness capacity, max. edge height 10 - 60 mm, for 3 mm PVC banding max. edge height 30 mm. Automatic advance of banding material from 13 - 29 FPM, 25 mm min. radius. 7" Minimum workpiece length. -- Small glue pot for quick heat-up, edgebanding turntable for coiled or straight strips, guillotine cut-off. Manual advance of the panel through glue roller. -- Work-piece elevating spacers allow for edgebanding material overhang on the bottom and eliminate the need for templates for contoured parts, simplifying the edgebanding process. -- Edge length cut-off, by foot pedal activation for short runs or pre-selected by digital counter for larger production runs...NOTE: owner states "It needs a new trim knife"

BRANDT KTD 720 CONTOUR EDGEBANDER0.4 - 3 mm (1/8") Edge cap., panel thickness 5/8" - 1-5/8", min. panel length 100 mm (4") and 100 mm (4") min. width. Variable feed speeds 2-14 FPM. -- Gluing/taping unit applies glue to the edging material, presses it onto the workpiece and moves via a motorized system which is guided by the operator. -- Quick heat-up glue system,(approx. 12 minutes) w/glue tank for maintenance & glue color change. Glue temperature indicator for both the glue pot and glue roller with LED thermostat and automatic temperature reduction if the machine is idle for 15 minutes or more. Pre-heating devise for thicker PVC eding is standard equipment to allow material to more pliable. -- Automatic coil cut off devise is supplied to pre-cut the banding material to lenth. -- Vacuum table equipped with (5) pods to secure panels to worktable. -- Also equipped with BRANDT OPTIMAT F13 top and bottom trimmer Sold per pair.

--make offer--excellent condition-- BRANDT OPTIMAT KTD 820 Contour Edgebander Specifications: Designed for straight, curved (contour), or beveled edgebanding. Edgebanding thickness 0.4 - 3 mm (0.02” - 0.12”). Coil cutoff 0.4 - 3 mm (0.02” - 0.12”) (Max. edge height 45 mm/1.77”). Panel thickness 16 - 40 mm (0.63” - 1.57”). Min. radius 25 mm (0.98”). Min. panel length 180 mm (7.09”), Min. panel width 100 mm (3.94”). Feed speeds 0.7 - 4.2 MPM (2.30 - 13.80 FPM). Equipped with: 33” Dia. Vertical coil table. Small glue pot for quick heat-up. Magazine for coil or solid strips. Guillotine. Handheld gluing unit, with Tool balancer & Rotating jib with 8’ Travel. (2) 23-1/2” x 27-1/2” x 35 H Work tables. Large panels can be glued by guiding handheld gluing unit around panel mounted to vacuum suction table. Small panels can be glued by guiding panel along gluing unit mounted to table. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

Brandt 520 Single Sided Edgebander Edge band thickness 0.4 – 8mm (0.016" - 1/4” ) Coil cutoff maximum 0.8 x 60 mm; 3.0 x 45 mm (PVC) Edgeband height 12 - 65 mm (1/2" – 2 9/16 ") Panel length min. 160 mm (6 3/8") Panel width min. 65 mm (2 3/8") Panel thickness - min. 8 mm (5/16") - max. 60 mm (2 3/8") Feed speed – 11 m/min. Internal modem for remote diagnostic link. Smooth upper pressure rollers. Automatic feed track lubrication system. First pressure roller driven and three idle pressure rollers. Double motor end trimming unit. Program controlled indexing from straight to bevel end trimming. Fine Trimming Station: Top/bottom (2) motors, 0.35 kW (0.50 HP) 12,000 RPM, bevels 0° - 25°, with combination flush/radius/chamfer cutterheads; horizontal and vertical tracing wheels. Radius Scraping (PVC): Top/bottom with pneumatic control, pvc scrape collection box. Buffing Station: Top/bottom (2) motors, 0.09 KW (0.125 HP) 1,400 RPM.

BRANDT - Ambition 1440 AT (KDF-440 AT): Edgebander (w/Premill & Corner Rounding) + "AirTec" PUR/EVA Gluing Technology -- Specifications Edge & workpiece capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness; 8 - 60 mm (0.31" - 2.36") panel thickness; 160 mm (6.30") min. panel length; 70 mm (2.76") min. panel width.Equipped with: -- Heated Adjustable Infeed Fence. Radiant Heated with: Manual adjustment. -- Joint Trimming/Premilling Station. (2) 2.2 kW (3 HP) - 12,000 RPM Motors; left-hand & right-hand rotation with: Pneumatic jump control for chip-free & clean panel edges. -- Roller Separating Device. 3 mm x 45 mm (0.12" x 1.77") Or 1 mm x 55 mm (0.04" x 2.17") max. roll cutting; 0.4 - 8 mm (0.016" - 0.31") strip thickness; 3 mm (0.12") PVC max. coil thickness. -- "AirTec" PUR Glue Application: For preglued PUR banding. -- Hot Melt Glue Application Unit: 6 - 10 kG/Hr (13 - 22 Lbs/Hr) Melting capacity (depending on glue type). -- Pressure Zone. (1) Driven & (2) idle rollers; timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- Feed Speeds. 8 - 14 MPM (27 - 45 FPM); 11 MPM (36 FPM) when contour trimming. -- BRANDT "POWERTOUCH" Control with: 21" HD LCD Touchscreen Monitor.Workstations -- Front & Rear End Trimming Unit. (2) 0.18 kW (1/4 HP) - 12,000 RPM Motors with: 0° - 15° Automatic chamfer; pneumatic adjustment; activation/deactivation of edging material overhang using "POWERTOUCH" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit. (2) 0.55 kW (3/4 HP) - 12,000 RPM Motors; 0° - 25° automatic tilt with: Horizontal & vertical tracing wheels; brushless multiaccess Servo motors for positioning of work unit; horizontal copy wheels for Quick changeover with: (3) Positioning options: Profile 1, Profile 2 & Flush Trimming. -- Multifunctional Trimming Unit. (2) 0.4 kW (1/2 HP) - 12,000 RPM Motors for top & bottom, leading & trailing edges, and corner rounding of panels.Servo Motors for: Positioning of work unit & horizontal copy wheels.Either radius or chamfer cutters can be mounted: 3 mm (0.12") Max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit. (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08").Servo Control positioning of: Vertical & horizontal copy wheels.PVC Scrape collection box, pneumatic adjustment using: "POWERTOUCH" Control, pneumatic disengagement. -- Top & Bottom Flat Glue Scrapping Unit. To remove excess before Buffing. -- Top & Bottom Buffing Unit. (2) 0.09 kW (0.12 HP) - 2,750 RPM Motors.Complete with: -- Rubber padded feed chain w/top idle holddown rollers; 1.5 kW (2 HP) feed motor; 32" diameter coil table; padded sound enclosure. -- Actual Model: BRANDT - AMBITION 1440 AT (KDF 440 AT).

BRANDT KDF 440/AMBITION 1440 Edgebander, with Pre-Mill & Corner RoundingUSAGE NOTE: Seller believes total hours & total pieces were reset, so this information in the photo of the control screen are not likely to be accurate.EQUIPMENT NOTE: Glue Pot was recently replaced with a brand new unit.Specifications: -- Edgebanding thickness 0.4 - 8 mm (0.02" - 0.31"). -- Panel thickness 8 - 60 mm (0.31" - 2.36"), Min. panel length 160 mm (6.30"), & Min. panel width 70 mm (2.76"). -- Feed speeds: 8 - 14 MPM (27 - 45 FPM), 11 MPM (36 FPM) with Contour trimming.Equipped with: -- Motorized infeed fence, with 0.049 kW (0.07 HP) Motor. -- Joint trimming/pre-mill unit, with (2) 2.2 kW (3 HP) - 12,000 RPM Motors, Left-hand & Right-hand rotation, & Pneumatic jump control. -- Roller separating device, with 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting, 0.4 - 8 mm (0.016" - 0.31") Strip thickness, & 3 mm (0.12") PVC Max. coil thickness. -- Hot melt glue application unit, with 6 - 10 kg/Hr. (13 - 22 Lbs./Hr.) Melting capacity (Depending on glue type). -- Workpiece preheating unit. -- Pressure zone, with (1) Driven & (2) Idle rollers, Timed pneumatic pressure controlled, & Servo motor positioning for programmable edge thickness changeover. -- BRANDT "POWERCONTROL PC 20+" Control, with LCD Display & Touchpad.Workstations: -- Front & Rear End Trimming Unit, with (2) 0.18 kW (1/4 HP) - 12,000 RPM Motors, 0° - 15° Automatic chamfer, Pneumatic adjustment & Activation/deactivation of edging material overhang using "POWERCONTROL" control. -- Top & Bottom Flush/Chamfer/Radius Trimming Unit, with (2) 0.55 kW (3/4 HP) - 12,000 RPM Motors, 0° - 25° Automatic tilt, Horizontal & Vertical Tracing wheels, Brushless multi-axis servo motors for positioning of work-unit & horizontal copy wheels for quick changeover, with (3) Positioning options: Profile 1, Profile 2 & Flush trimming. -- Multi-Functional Trimming Unit, with (2) 0.4 kW (1/2 HP) - 12,000 RPM Motors for leading & trailing edges vertical corner rounding of panels, Either radius or chamfer cutters can be mounted, 3 mm (0.12") Max. edge thickness. -- Top & Bottom Multi-Profile (PVC) Scraping Unit, with (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"), Servo control positioning of vertical & horizontal copy wheels, PVC Scrape collection box, Pneumatic adjustment using "POWERCONTROL" control, & Pneumatic disengagement. -- Top & Bottom Glue Scraping Unit, Flush on panel surface, with Floating insert knives. -- Top & Bottom Buffing Unit, with (2) 0.09 kW (0.12 HP) 2,750 RPM Motors.Complete with: -- Motorized, programmable hold-down pressure beam, & Padded sound enclosure.

--make offer--requires repair-- BRANDT KDF 440 C/AMBITION 1440 FC EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) & 3,359 Hrs. Specifications: Edge & Workpiece Capacity: 0.4 - 8 mm (0.016" - 0.31") Edgebanding thickness, 8 - 60 mm (0.31" - 2.36") Panel thickness, 160 mm (6.30") Min. panel length, 70 mm (2.76") Min. panel width. Equipped with: Adjustable Infeed Fence: Motorized adjustment with 0.049 kW (0.07 HP) Motor. Joint Trimming/Pre-Milling Station: (2) 2.2 kW (3 HP) 12,000 RPM Motors, Left-Hand & Right-hand rotation with Pneumatic jump control for chip-free & clean panel edges. Roller Separating Device: 3 mm x 45 mm (0.12" x 1.77") or 1 mm x 55 mm (0.04" x 2.17") Max. roll cutting, 0.4 - 8 mm (0.016" - 0.31") Strip thickness, 3 mm (0.12") PVC Max. coil thickness. Hot Melt Glue Application Unit: 6 - 10 kg/Hr. (13 - 22 Lbs./Hr.) Melting capacity (Depending on glue type). Workpiece Preheating Unit Pressure Zone: (1) Driven & (2) Idle Rollers, Timed pneumatic pressure controlled, Servo motor positioning for programmable edge thickness changeover. Feed Speeds: 8 - 14 MPM (27 - 45 FPM), 11 MPM (36 FPM) with Contour trimming. BRANDT "POWERTOUCH" Control: With 21" HD LCD Touchscreen monitor. Workstations: Front & Rear End Trimming Unit: (2) 0.18 kW (1/4 HP) 12,000 RPM Motors, with 0° - 15° Automatic chamfer, Pneumatic adjustment & Activation/deactivation of edging material overhang using "POWERTOUCH" control. Top & Bottom Flush/Chamfer/Radius Trimming Unit: (2) 0.55 kW (3/4 HP) 12,000 RPM Motors, 0° - 25° Automatic tilt, with Horizontal & Vertical Tracing wheels, Brushless multi-axis servo motors for positioning of work-unit & horizontal copy wheels for quick changeover, with (3) Positioning options: Profile 1, Profile 2 & Flush trimming. Multi-Functional Trimming Unit: (2) 0.4 kW (1/2 HP) 12,000 RPM Motors for leading & trailing edges vertical corner rounding of panels, Either radius or chamfer cutters can be mounted, 3 mm (0.12") Max. edge thickness. Top & Bottom Multi-Profile (PVC) Scraping Unit: (2) Profiles: 1 mm (0.04") & 2 mm (0.08") or 3 mm (0.12") instead of 2 mm (0.08"), Servo control positioning of vertical & horizontal copy wheels, PVC Scrape collection box, Pneumatic adjustment using "POWERTOUCH" control, Pneumatic disengagement. Top & Bottom Glue Scraping Unit: Flush on panel surface, with Floating insert knives. Top & Bottom Buffing Unit: (2) 0.09 kW (0.12 HP) 2,750 RPM Motors. Complete with: Motorized, programmable hold-down pressure beam with 0.12 kW (0.16 HP) Motor, 1.5 kW (2 HP) Feed motor, 32" Diameter Coil table, Padded sound enclosure. NOTE: CPU needs to be replaced. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

BRANDT - FP 10: Corner Rounding Unit -- SpecificationsFreestanding unit for: Profiling, shaping, chamfering, or rounding most common type & shape of corner/edge on an edgebanded panel. -- Capacity: 55 mm (2-1/8") Max. panel thickness; 90 x 140 mm min. panel size; 3 mm max. edge thickness (depending on radius & edge material).Plunge in & plunge out points for tooling are: Programmable on Operator Control Panel with digital readout. -- Automatically scans profile with: SPS control; handles 90° & 180° symmetric profiles; tracing wheel & shoe follow exact shape contour of edgeband of corner. -- Equipped with: 3/4 HP - 27,000 RPM Motor; pneumatic clamping cylinder; optional 1/4 HP table mounted Buffing Wheel; electro-pneumatic operation with foot pedal control.

Brandt KF 76F Edgebander: Pre-milling, top/bottom trim, buffing, extra glue pot

BRANDT - KDF-550 C, ...Edgebander with Premill & Corner RoundingEdge & workpiece capacity. Edge: 0.4 - 8 mm (0.016 - 0.31"); panel thickness: 8 -60 mm (0.31" - 2-3/8"); min. panel length: 60 mm (6.29"); min. panel width: 70 mm (2-3/4").Equipped with: -- Premilling Station with: Diamond cutterheads; (2) motors @ 2.25 kW (3.0 HP) - 12.000 RPM; LH & RH rotation w/pneumatic jump control for chip free & clean panel edges. -- Infeed fence with: Servo motor positioning. -- Automatic Edge Magazine. For strip & coil stock; strips: 0.4 mm - 8 mm (0.016" - 0.31"); coils up to 3 mm PVC and "HD" guillotine. -- Pressure Section. 1st Roller driven; plus (3) idle rollers; timed pneumatic pressure controlled; Servo motor positioning for programmable edge thickness changeover. -- Feed Speed: Variable; 8 - 14 MPM (26 - 46 FPM); 11 MPM (36 FPM) when using contour trimming. -- BRANDT "PowerControl PC 16"; memory: 256 MB RAM; 1 GB Flash Card Drive; Operator control panel with: 22" Color HD wide screen; soft keypad; internal modem for remote diagnostic link.Workstations -- End Trimming; (2) Motors @ 0.35 kW (1/2 HP) 12,000 RPM; automatic chamfer from the control panel: 0°- 15°. -- Flush/Bevel-Fine/Radius Trimming Unit: Top/bottom (2) motors; 0.55 kW (3/4 HP) 12,000 RPM; auto tilt positioning 0° - 25°; combination flush/radius/chamfer cutterheads; horizontal and vertical tracing wheels. -- Includes: (3) Positioning options: Profile 1, profile 2, and flush trimming. -- Corner Rounding Unit: (1) Motor; 0.35 kW (1/2 HP) - 12,000 RPM for leading & trailing edges; vertical corner rounding of panels; either radius or chamfer cutters can be mounted; 3 mm max. edge thickness. -- Scraping, Multi-Profile (PVC) Top/Bottom with (2) profiles: 1 mm & 2 mm or 3 mm Instead of 2 mm; Servo control positioning of vertical & horizontal copy wheels; PVC scrape collection box. -- Scraping Glue Unit: Flush top/bottom on the panel surface with floating insert knives. -- Buffing Unit: Top/bottom (2) motors; 0.10 kW (0.125 HP) - 2,800 RPM.Complete with: Motorized, programmable holddown pressure beam; padded sound enclosure. -- Actual Model: BRANDT, OPTIMATKDF 550 C

Brandt KDF 650 Edgebander

--MAKE AN OFFER!--VERY GOOD CONDITION-- BRANDT KDF 650 (1650 HIGHFLEX) Edgebander, with 3,339 Hrs. (As of 10/31/23), Pre-Mill & Corner Rounding Specifications: 0.4 - 12 mm (1/2") Edge cap., panel thickness 5/16" - 2-3/16", min. panel length 160 mm (6-3/8") and 65 mm (2-1/2") min. width; line control (NO limit switches) for workstation function. Automatic height adjustment with top pressure beam for all work stations, equipped with digital height indicator. "PC-16" Program Control with: 21-1/2” Display, signal infeed light to ensure proper spacing between panels. Equipped with: Pre-milling station for cleaning edges of the panel; "Quick change" glue tank for maintenance & glue color change. 32” Dia. Coil table. Automatic magazine for strip & coil stock, 3 mm PVC guillotine, (1) drive plus (3) idle roll "pneumatically controlled" pressure sections with digital indicator for quick edge thickness changeover. Workstations: End trim (0.33 HP - 12,000 RPM motors), chamfers 0° - 15°; Top & bottom flush/bevel/radius trim, bevels 0° - 15° (0.5 HP - 12,000 RPM motors) with insert knives for 2 mm PVC radius. Vertical copy wheels are servo-controlled for quick changeover, programmable from the control panel. 2-Motor (4 corners) contour trim for profile corner rounding (two 0.5 HP - 12,000 RPM motors), with insert knives for 2 mm PVC radius. Top & bottom scraping for 2 - 6 mm radius, pneumatically controlled blowoff nozzles; Top & bottom buffing (0.25 HP - 1,400 RPM motors). End trim, flush/bevel/radius trim & corner rounding stations have HF motors with electronic brakes; feed chain track speed 42 FPM, 2 HP feed drive. Complete with: Operator control panel, PLC (Programmable Logic Control) keypad, and LED readouts; used tooling. NOTE: Actual Model "KDF 650". NOTE: Specifications must be confirmed. Machine Dimensions: 254” x 50” x 68” H. Machine Dimensions with Outboard Panel Support Extended: 254” x 66” x 68” H. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.
