Woodworking Equipment For Sale

BIESSE SKIPPER 100 2-Head CNC Machining Center, with Infeed & Outfeed Tables – Seller states that machine was run (2) shifts from 2005 - 2021, then only a few hours per day since!Specifications: -- Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system.Working Capacity: -- "X" Axis 3,000 mm (118.11"), "Y" Axis 1,000 mm (39.37"), Max. part thickness 60 mm (2.36"). -- Min. workable part size: "X" Axis 90 mm (3.54"), "Y" Axis 70 mm (2.76"), & "Z" Axis 8 mm (0.31").Work Table: -- Left-hand infeed & Right-hand outfeed, Each with 20-1/2"; x 66"; x 35-1/2"; H infeed & outfeed areas with Fixed caster-type conveyor rails.Positioning Speed: -- "X" Axis 120 MPM (393 FPM), "Y" Axis 90 MPM (295 FPM), "Z" Axis 30 MPM (98 FPM).Boring Units: -- (1) Top & (1) Bottom boring blocks, Each with: 3 kW (4 HP) Motor, Boring spindle speed 4,000 RPM, (29) Vertical spindles with (17) "X" Axis & (12) "Y" Axis, (10) Horizontal spindles with (4 + 4) "X" Axis & (1 + 1) "Y" Axis, & (1) "X" Axis Grooving saw with 3 kW (4 HP) Motor, Blade speed 5,000 RPM, & Blade diameter 150 mm (5.91").Machining: -- (1) Top & (1) Bottom 3.5 kW (4-3/4 HP) Electrospindles, Each with: Variable spindle speeds 7,000 - 18,000 RPM, Right-hand/Left-hand rotation, HSK D-50 Adapters for Manual push-button quick tool change, ERC-32 Toolholders & RC-32 Collets.Operator & Machine Control: -- Mobile Control Console, with PC-Based Control, 18" LCD Monitor, BIESSE "WORKS" + "WINDOWS" Operating system. -- Pedestal & Pendant controls.Equipped with: -- Universal transformer, 200 - 600 V, 50/60 Cy, 3-Ph., Automatic lubrication system for guides & ways, Sound hood, 79" H Safety fence with Lock-out door, & TAPESWITCH "CONTROLMAT CKP" 24" x 72" Heavy-duty ribbed pressure-sensitive safety mat.Complete with: -- 7’ x 9’ x 35-1/2"; H Infeed Table, with Rails & Pusher. -- 6-1/2’ x 8’ x 35-1/2"; H right Outfeed Table, with Transfer Belts. -- (2) Handheld Bar Code Readers. -- Dust Manifold.Dimensions including Safety Fence: 307" x 184" x 98" H.

BIESSE SKIPPER 100 2-Head CNC Machining Center, with Outfeed TableSpecifications: -- Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system.Working Capacity: -- "X" Axis 2,500 mm (98.43"), "Y" Axis 1,000 mm (39.37"), Max. part thickness 60 mm (2.36"). -- Min. workable part size: "X" Axis 90 mm (3.54"), "Y" Axis 70 mm (2.76"), & "Z" Axis 8 mm (0.31").Work Table: -- Left-hand infeed & Right-hand outfeed Y-Beam with Clamps. -- 22"; W x 71"; L x 34-1/2"; H Air flotation loading table. -- 24"; W x 8’ L Unloading table, with 1-1/16"; Dia. Coated rollers on 9-1/8"; centers.Positioning Speed: -- "X" Axis 120 MPM (393 FPM), "Y" Axis 90 MPM (295 FPM), "Z" Axis 30 MPM (98 FPM).Boring Units: -- (1) Top & (1) Bottom boring blocks, 1.7 kW (2-1/4 HP) Motor, Variable spindle speeds 4,000 - 6,000 RPM, Each with: (29) Vertical spindles with (17) "X" Axis & (12) "Y" Axis, (10) Horizontal spindles with (4 + 4) "X" Axis & (1 + 1) "Y" Axis, & (1) "X" Axis Grooving saw with 1.7 kW (2-1/4 HP) Motor, Blade speed 5,000 RPM, Right-hand rotation, & Blade diameter 150 mm (5.91").Machining: -- (1) Top & (1) Bottom 3.5 kW (4-3/4 HP) Electrospindles, Each with: Variable spindle speeds 7,000 - 18,000 RPM, Right-hand/Left-hand rotation, Max. tool dia. 40 mm (1.57"), HSK D-50 Adapters for Manual push-button quick tool change, ERC-32 Toolholders & RC-32 Collets.Operator & Machine Control: -- Mobile Control Console, with PC-Based Control, 19" LCD Monitor, BIESSE "WORKS" + "WINDOWS" Operating system. -- Pendant control.Equipped with: -- Universal transformer, Automatic lubrication system for guides & ways, Sound hood, 79" H Safety fence with Lock-out door, & 3-1/2’ x 12-1/2’ Coin pattern pressure-sensitive safety mat.Complete with: -- User Manual. -- 6-1/2’ x 8’ x 35"; H Outfeed Table, with (9) 1/2"; W Transfer Belts.Dimensions including Safety Fence: 292" x 196" x 87" H.

Biesse Skipper 100 CNC Center Still under power - ready to be packed and shipped!

BIESSE - SKIPPER 100 L, ...CNC Machining Center (2-Head): -- SpecificationsFlexible "Top & Bottom" Machining Center that uses an innovative panel handling system. -- Workable Part Size"X" Axis is 118" (3,000 mm); "Y" axis is 39.4" (1,000 mm); max. part thickness of 2.4" (60 mm).Min. workable part size in "X" axis is 3-1/2" (90 mm); "Y" axis is 2.7" (70 mm); "Z" axis is 0.3" (8 mm). -- WorktableAutomatic LH infeed transfer conveyor with: Belts & rollers; Automatic RH outfeed transfer conveyor with: Belts & rollers; Infeed/outfeed table is: "Robot Ready". -- Positioning Speed"X" Axis is 394 FPM (120 MPM); "Y" axis 295 FPM (MPM); "Z" axis is 98 FPM (30 MPM). -- Boring Units (1) Top mounted boring block: 4.2 HP (3 kW) - 4,000 RPM; (29) vertical spindles: (17) Spindles in "X" axis & (12) spindles in "Y" axis. -- (10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis. -- (1) "X" Axis grooving saw with: 2.2 HP (1.7 kW) Motor - 5,000 RPM; 150 mm dia. blade. -- (1) Bottom mounted boring block: 4.2 HP (3 kW), 4,000 RPM; (29) Vertical spindles: (17) Spindles in "X" axis & (12) spindles in "Y" axis. -- (10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis. -- (1) "X" Axis grooving saw with: 2.2 HP (1.7 kW) Motor - 5,000 RPM; 150 mm dia. blade. -- Machining(1) Top mounted 4.8 HP (3.5 kW) electro-spindle; 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change; ERC-32 tool holders & RC-32 collets. -- (1) Bottom mounted 4.8 HP (3.5 kW) electro-spindle; 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change; ERC-32 tool holders & RC-32 collets. -- Operator InterfacePC Front-End with: "BIESSE Work" + Windows Operating System; 15" color monitor; international keyboard with soft touch keypad & industrial mouse.RS-232 Serial ports for possible downloading from an office PC; USB ports; (1) 48x CD ROM drive; all mounted in a separate control console with: Built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with:Universal transformer for voltages from: 200 - 600 Volts, 50/60 Hz, 3-Phase; automatic lubrication system for guides & ways; sound enclosure and complete set of safety fences/devices; machine docs & manuals.

BIESSE - SKIPPER 130: CNC Machining Center (2-Head) -- Specifications Flexible "Top & Bottom" Machining Center that: Uses an innovative panel handling system. -- Working Cap.Max. workable part size: "X" Axis is 118" (3,000 mm); "Y" axis is 51.1" (1,300 mm); max. part thickness of 3.5" (90 mm).Min. workable part size: "X" Axis is 3-1/2" (90 mm); "Y" axis is 2.7" (70 mm); "Z" axis 0.3" (8 mm). -- WorktableLH Infeed air cushion transfer table & part clamping devices; automatic RH outfeed transfer conveyor with belts; outfeed is "Robot Ready". -- Positioning Speed"X" Axis is: 394 FPM (120 MPM); "Y" axis: 295 FPM (MPM); "Z" axis: 98 FPM (30 MPM). -- Boring Units(1) Top mounted boring block: 4.2 HP (3 kW) - 4,000 RPM; (31) vertical spindles; (18) spindles in "X" axis & (13) spindles in "Y" axis.(10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis; (1) "X" axis grooving Saw with 2.2 HP (1.7 kW) motor - 5,000 RPM; 150 mm dia. blade.(1) Bottom mounted boring block: 4.2 HP (3 kW) - 4,000 RPM; (31) Vertical spindles; (18) spindles in "X" axis & (13) spindles in "Y" axis.(10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis; (1) "X" axis grooving Saw with 2.2 HP (1.7 kW) motor - 5,000 RPM; 150 mm dia. blade. -- Machining(1) Top mounted 6 HP (4.5 kW) electro spindle; 1,800 - 24,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change.(1) Bottom mounted 6 HP (4.5 kW) electro-spindle; 1,800 - 24,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change. -- Operator & Machine ControlPC Front-End with: BIESSE "WORKS" + Windows "XP" Operating System; 15" color monitor; international keyboard with soft touch keypad & industrial mouse.RS-232 Serial ports for possible downloading from an office PC; USB ports; (1) 48x CD ROM drive; all mounted in a separate control console with a built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with:Pneumatic part clamping: Air table infeed & motorized outfeed transfer conveyors; universal transformer for voltages from: 200 - 600 Volts; 50/60 Hz; 3-Phase; automatic lubrication system for: Guides & ways; safety mats/fences/devices; machine docs & manuals.

Manufacturer Specs premill hot glue end trim top/bottom trim corner rounding scraping buffing Computer interface

Pressure Beam Type: Rollers Pre-Milling Station: 2 Motors Glue Station Pressure Rollers: 4 End Trimming Station: Straight & Bevel (2 motors) Rough Milling Station: 2 Motor Fine Milling Station: 2 Motor Corner Rounding Station: 2 Motor Flat Scraping Station: Top & Bottom Profile Scraping Station: Top & Bottom Buffing Station: Top & Bottom Heat: Top & Bottom Panel Height: 10-50 mm Edge-banding Material Height: 13-55 mm Min. Thickness of Edge-Banding Strip in Rolls: 0.4-3 mm Max. Edge Thickness w/Trimming Unit: 8 mm Max. Edge Thickness w/o Trimming: 3 mm Max. Section of Solid Wood: 8 x 55 mm Panel Protrusion from Track: 25 mm Min. Panel Length: 150 mm Min. Panel Width (150mm Length): 85 mm Min. Panel Width (250mm Length): 55 mm Chain Feed Speed: 12 m/min Dimensions: 18' L x 4' W x 5' H Weight: 4,000 lbs Electrical: 230 V 3 Phase

Min. Panel Thickness: 0.39? Max Panel Thickness: 2.36? Height of Edge-Band Material: 0.55-2.51? Min. Banding Thickness: 0.01? Max Banding Thickness: 0.39? Min. Panel Length: 5.51? Min. Panel Width: 1.96? 2 Feed Speeds: 39ft/min & 59ft/min Electrical: 230V, 60Hz, 3Phase Equipped With Siemens TD200

Biesse Rover 15 Pod and Rail. In Great condition for its age!

BIESSE ROVER 20 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working field: "X" Axis 113.9" (2,893 mm); "Y" axis 37.4" (950 mm); "Z" axis stroke is 3.9" (100 mm), max. panel thickness 2-1/2" (65 mm). -- Positioning Speed:"X" Axis at 246 FPM (75 MPM); "Y" axis 147 FPM (45 MPM); "Z" axis 49 FPM (15 MPM)."X" Axis moves on high precision prismatic guides and ground helical rack; "Y" & "Z" axis via hardened ground ball screw. -- Worktable:(6) Pneumatically locked & manually positioned panel supports with (2) vacuum cups each.(2) Working zones with: (6) Pneumatic backstops; (2) pneumatic side & (2) center stops; stops raised & lowered automatically by start/stop of machining cycle. -- Boring Unit:(1) 2.3 HP - 5,135 RPM Motor; (10) vertical spindles independently operated with (6) in "X" axis & (4) in "Y" axis.(6) Horizontal spindles: (2 +2) in "X" Axis & (1 + 1) in "Y" axis; 2-1/2" (65 mm) max. boring depth.(1) "X" Axis grooving saw with: 120 mm Dia. blade - 5,200 RPM. -- Machining: Equipped with: (1) 9 HP (6.6 kW) Air-cooled "Quick Change" electro spindle with ISO 30 adaptor.Router is driven by: 10.2 HP (7.5 kW) Inverter for variable speed from 1,000 - 24,000 RPM; RH & LH rotation.(1) 3-Position automatic tool changer mounted at the back of the machine for "on the fly" ATC. -- Operator & Machine Control: Separate Control Console with: CNi "NC 410" Operating System housed in air-conditioned cabinet.8" LCD Monitor: Displays programming graphics, numerical & function keyboard; 512 KB RAM memory; (1) "UPGRADED" USB drive.RS-422 Serial port for PC and RS-425 port for inverter connection; EPROM for machine data & subroutines; machine runs production programs while programming and editing. -- Complete with:Stabilized autotransformer for voltages between 200 - 600 Volt 50/60 Hz; (1) 100 cbm/Hr Vacuum Pump; triple photocell barrier; assortment of misc. parts and tooling; Users operator/maintenance manuals & backup disks. -- Actual Model is: BIESSE - ROVER 20.

Biesse Rover 24 FT Router Series # 09665 Year: 2001 Power Supply: 20 KW, 480 V, 28 A., 60Hz., 110 24 Low Tensions Air supply: 7 minimum Bar Suction Air Speed: 30 M/1 Vacuum Pump Additional photos and details available Router is still hooked up and running. Price includes dismantling & loading Contact us for a freight rate

BIESSE ROVER 24 FTS FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:4' x 10' "Matrix" grid phenolic surface table for "Nested Base Manufacturing". -- Working Cap."X" Axis is 122" (3,100 mm), "Y" axis 49.2" (1,250 mm), "Z" axis stroke is 9.8" (250 mm).Max. material thickness of 6.1" (155 mm). -- Positioning Speed:"X" & "Y" Axis is 328 FPM (100 MPM), "Z" axis 98 FPM (30 MPM)."X" axis uses a helical rack & pinion system, "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides / ways & controlled by digital, brushless AC Servo motors.All motion components are maintained by a lubrication system. -- Work area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas.(4) External pop-up reference pins: Reference pins are adjustable & can be placed on the front of the table, on the back of the table, on the RH side & on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts,Each work zone with (1) "quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) - 4,000 RPM Motor; (14) Independent vertical spindles, (7) in "X" axis & (7) in "Y" axis.(6) Horizontal spindles with: (2+2) in "X" axis & (1+1) in "Y" axis; (1) "X" axis grooving saw for max. 120 mm dia blade.(1) 6-Position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Machining:(1) 10.2 HP (7.6 kW) Electro-spindle Router, variable speed from 1,000 - 20,000 RPM; -- Operator & Machine Control:PC Front End with: NC 1000" + WINDOWS "NT" operating system; 15" color CRT display.40 GB Hard drive; floppy & CD drives; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:Universal Auto-Transformer for voltages between 200 - 600 V, 50/60 Hz.; Manuals, documents & safety perimeter devices. -- Actual Model is BIESSE ROVER 24 FTS.NOTE: The Vacuum Pump is NOT Included with this machine

BIESSE - ROVER 24 FTS: Flat Table Machine (w/ATC/Boring) -- Specifications4' x 10' "Matrix" Grid phenolic surface table for "Nested Base Manufacturing". -- Working Capacity"X" Axis is 122" (3,100 mm);"Y" axis 49.2" (1,250 mm); "Z" axis stroke is 9.8" (250 mm); max. material thickness of 6.1" (155 mm). -- Positioning Speed "X" & "Y" Axis is 328 FPM (100 MPM); Z-axis 98 FPM (30 MPM); "X" axis uses a helical rack & pinion system; "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides & ways & controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Work AreaFlat table design with: "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas.(14) External pop up reference pins with: (6) Pins on the front of the table: (4) On the back of the table; (2) on the RH side; (2) on the LH side.Prepared for (optional): "Quick fit" Vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick Connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit(1) 2-1/2 HP (1.7 kW) - 4,000 RPM Motor; (14) independent vertical spindles: (7) In "X" axis & (7) in "Y" axis.(6) Horizontal spindles with: (2 + 2) In "X" axis & (1 + 1) in "Y" axis; (1) 120 mm dia. "X" axis grooving saw.(1) 6-Position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Machining(1) 10.2 HP (7.6 kW) Air-cooled electrospindle with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM. -- Operator & Machine ControlPC Front End with: NC 1000" + WINDOWS "NT" Operating System; 17" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:(1) 250 cbm/Hr Vacuum Pump; universal Autotransformer for voltages between: 200 - 600 V, 50/60 Hz; includes: Manuals, documents, safety mats, fencing. -- Actual Model is: BIESSE - ROVER 24 FTS.

?????Rover 24 FIXL CNC Router

BIESSE - ROVER 37XL FT: w/ATC/Boring -- Specifications 5' x 12' Phenolic "MATRIX" grid vacuum Flat Table design for: "Nested Base" processing.Working Cap. -- "X" Axis: 243-1/2" (6,180 mm); "Y" axis: 72.8" (1,850 mm); "Z" axis stroke: 7.1" (180 mm).Positioning Speed -- X" & "Y" Axes: 328 FPM (100 MPM); "Z" axis: 98 FPM (30 MPM); "X" axis: Uses helical rack & pinion system; "Y" & "Z" axes use: Precision ball screws.All axes movement: Precision linear guides & ways; controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system.Worktable -- Phenolic "MATRIX" grid vacuum table for: FT "Nesting" or single part processing using (optional) pods or jigs; (2) sides & (8) rear & (4) side pop-up pins for easy material location.Boring Unit -- (1) 4 HP (3.3 kW) - 4,000 RPM motor; (14) independent vertical spindles: (7) X-axes & (7) Y-axes; (6) horizontal spindles with: (2 + 2) in X-axis & (1 + 1) in Y-axis; (1) "X" axis grooving saw with: 150 mm dia. blade.Machining Unit -- (1) 16.3 HP (12 kW) HSD electro spindle router with: HSK F63 Adaptor; inverter driven 1,000 - 20,000 RPM with: Max. torque from 12,000 - 20,000 RPM.(1) 6-Position "Ride Along" Automatic tool changer for: "On-the-fly" ATC.Operatory Interface -- PC Front-End with: BIESSE "NC 1000 + WINDOWS "2000" operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. Programs can be transferred via diskette or downloaded by wire.Built-in 1,500 W air conditioner for: Constant temperature & dust-free environment.Complete & supplied with: -- (1) 11 KVA stabilized autotransformer for: Voltages between 200 - 600 V; automatic "forced" lubrication system for: Guides & ball screw. -- Includes: Emergency stop rope & pressure sensitive safety mats that will instantly place machine in "pause cycle" when stepped on; sound absorbing protective head enclosure with: Debris curtain around bottom edge. -- Actual Model: BIESSE ROVER 37 XL FT.Note: There is "NO" Vacuum Pump with the machine.

Working Capacity: "X axis 125.9" (3,200 mm), "Y" axis 52" (1,320 mm), "Z" axis stroke 13.7" (350 mm), max material thickness 9.6" (245 mm). Positioning speed:"X" 262 FPM (80 MPM), "Y" Axis 196 FPM (60 MPM), "Z" axis 98 FPM (30 MPM) AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. Work Table:(6) Tube-less panel supports with lifting bars for heavy panels, (3) ATS vacuum pods per panel support (6) Pneumatic back stops, (6) pneumatic front stops, (2) pneumatic side stops & (2) pneumatic central stops. Boring Unit:4 HP (3 kW) motor with variable speed from 1,500 - 7,500 RPM; (18) "Quick Change" independent vertical spindles with (9) spindles in "X" axis & (9) spindles in "Y" axis;(8) horizontal boring spindles with (2+2) in "X" axis & (2+2) in "Y" axis;(1) 0° - 90° NC controlled "X"-"Y" Axis grooving saw for max 200 mm dia saw blade. Machining:(1) 17 HP (13 kW) Liquid Cooled "HSD" electro-spindle router with HSK F63 adaptor, variable speed from 3,000 - 22,000 RPM;(26) Total ATC positions with (1) 8-Position ATC tool plate located on the machine head for "on the fly" ATC Operator & Machine Control:PC Front End: Biesse "BH 600" + BiesseWORKS Advanced + WINDOWS "XP" operating system,15" TFT monitor, full standard keyboard & mouse, CD ROM disk drives,RS 232 & USB ports, Ethernet connection, specific function controls & and internet trouble shooting capabilities;Control cabinet with air conditioning & dust free environment. "Biesse WORKS" is a multitask operating system, input/output modules, axes override, 4-axes interpolation, diagnostic graphics aid for programming, machine data & tool management. Complete with:(1) 250 m³/Hr vacuum pump; automatic lubrication system; original documentation; hand held pendant; safety fences & mats; scrap conveyor;

BIESSE ROVER - A 3.30: CNC Machining Center (w/ATC/Boring) -- SPECIFICATIONSWorking cap. - "X" Axis: 118" (3,000 mm) any unit; "Y" Axis: For routing, 45.2" (1,150 mm; "Y" Axis for: Boring; 49.6" (1,260 mm); "Z" Axis stroke: 7.8" (198 mm); max. material thickness: 5.9" (150 mm). -- Positioning Speed Both "X & Y" Axis is: 262 FPM (80 MPM); "Z": 111 FPM (34 MPM); helical rack & pinion drive: On "X" axis; precision ball screw on: "Y & Z" Axes. -- Worktable (6) Support rails with: (3) Vacuum pods per rail; (6) pop-up back stops, (4) pop-up side-stops; (2) independent working areas.Prepared for (optional) "quick fit" vacuum outlets for: Optional clamping of small or awkward shaped parts; each work zone with (1) "Quick connect" vacuum outlet: For custom vacuum fixtures. -- Boring Unit(14) Independent vertical boring spindles forming an L-configuration with: (7) Spindles in "X" Axis & (7) spindles in "Y" Axis.(6) Horizontal spindles with: (2 + 2) in "X" axis; (1 + 1) in "Y" Axis; (1) "X" Axis grooving saw for: Max. 120 mm dia. blade. -- Machining (1) 9.5 HP (7 kW) Vertically mounted HSD electrospindle router with: HSK F63 Adaptor.Inverter driven 1,000 - 24,000 RPM with: Max. torque from 12,000 - 24,000 RPM. (1) 18-Position "Ride-Along", "on the fly" automatic tool changer. -- Operator & Machine ControlPC Front-End with: BIESSE "XP600" + Windows "XP" + BIESSE "WORKS" Operating System.INTEL "Celeron" 2.0 GHz Processor; 4 GB Hard drive; 15" color monitor; international keyboard; soft touch keypad & industrial mouse; RS-232 serial port; (1) 1.44 MB floppy disk drive.BiesseWORKS: An easy CAD program that can be done from the office or at the machine; Operating System: Real-Time multitask processing; programs can be transferred via diskette or downloaded by wire. -- Complete with: (1) 250 M³/Hr Vacuum Pump; 11 KVA stabilized autotransformer for voltages between: 220 - 600 Volts. Equipped with: Centralized manual Lubrication System for guides & ball screw; built-in 1,500 W air conditioner for constant temperature & dust-free environment. Emergency stop rope & sound absorbing protective head enclosure with: Debris curtain around bottom edge. -- Actual model: BIESSE ROVER - A 3.30

BIESSE - ROVER A 3.40 FT: Flat Table Machine (w/ATC/Boring) -- Specifications4' x 12' Flat Table with: "Matrix" grid phenolic surface for "Nested Base Manufacturing". -- Working cap:"X" Axis: 145" (3,683 mm); "Y" axis: 53-1/2" (1,360 mm); "Z" axis stroke: 6.3" (160 mm); max. material thickness 5.9" (150 mm). -- Positioning Speed"X" & "Y" Axes are: 262 FPM (80 MPM); "Z" axis: 98 FPM (30 MPM); helical rack & pinion drive on "X" axis; ball screw on: "Y" & "Z" Axis. -- Work AreaFlat table design with: "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas; (4) external pop-up reference pins with: (3) On the back of the table & (1) on the LH side.Prepared for: (Optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit (1) 2-1/2 HP (1.7 kW) - 4,000 RPM Motor: (12) Independent vertical spindles: (6) In "X" axis & (6) in "Y" axis.(6) Horizontal spindles with: (2 + 2) In "X" axis; (1 + 1) in "Y" axis; (1) 120 mm dia. "X" axis grooving saw. -- Machining(1) 10.2 HP (7.5 kW) Electrospindle with: ISO 30 Adaptor; variable speed from: 1,000 - 20,000 RPM.(1) 10-Position ride along tool changer plate for: "On the fly" ATC. -- Operator InterfacePC Front-End with: BIESSE "XP600 + WINDOWS "XP" Operating System; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with: Universal Autotransformer for voltages between 200 - 600 V, 50/60 Hz; (2) 10 HP; (7.5 kW) BUSCH Vacuum Pumps; safety mats & fencing. -- Actual Model: BIESSE ROVER A 3.40 FT.

BIESSE ROVER A 2231 G FT FLAT TABLE MACHINE (W/LOADING, UNLOADING): -- Specifications:7' x 10' "Matrix" grid Phenolic surface for "Nested Base Manufacturing". Cell Configuration for sheets moving from the RH side to LH side of the line.The loading section is on the RH side, the offloading on the LH side from the operator standpoint. -- Working Capacity: "X" Axis 123 (3,130 mm), "Y" axis 86.6" (2,200 mm), "Z" axis stroke is 12.7" (325 mm), max. material thickness 4.7" (120 mm). -- Positioning Speed: "X" axis 262 FPM (80 MPM), "Y" axis 197 FPM (60 MPM), "Z" axis 66 FPM (20 MPM). All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors. All motion components are maintained by an automatic lubrication system. "X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws. -- Work area:Flat table design with HI-FLOW, multi-zone Matrix" grid Phenolic surface for "Nested Base Manufacturing". Automatic NC controlled zoning of the vacuum table with (16) individual zones. (2) Pneumatic "side" pop-up reference stops, (1) pneumatic "back" pop-up reference stop, & (1) pneumatic "front" pop-up reference stop. Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with "quick connect" vacuum outlet for custom vacuum pods & fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) Motor, variable speed up to 6,000 RPM: Boring block with (10) independent vertical spindles, (7) in "X" axis & (3) in "Y" axis. (6) Independent Horizontal Spindles with (4+4) in "X" axis & (2+2) in "Y" axis. (1) "X" axis grooving saw for max 120 mm dia blade. -- Machining:(1) 18 HP (13.2 kW) Air cooled HSD Electro Spindle with HSK 63 adaptor, variable speed from 1,000 - 24,000 RPM. (1) 8-position ATC tool changer plate located at the back of the machine base. NC controlled presetting for the measurement of the tool length. -- Operator & Machine Control:PC Front-End with: BIESSE BH 660 + BiesseWORKS + BiesseNest + Windows XP/WRT operating system. 17" TFT Flat screen monitor; server, full keyboard, & mouse all mounted on a mobile cart; Ethernet connection capabilities. BiesseWORKS Graphic interface makes full use of the operating methods typical of the WINDOWS operating system: Assisted graphic editor used to program machining operations; programming, and guided creation of parametric macros. Import of CAD and other external software files in DXF & CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(2) 300 m³/Hr BUSCH Vacuum Pump; Safety mats/devices & fencing; Tool touch-off probe for automatic program update according to the tool length. Automatic Lubrication System for linear guides, rack & recirculating ball screw. Tele-Service capabilities. -- Options Include: • (1) NC Controlled infeed Scissor Lift table with vacuum loading; • (1) Rake system; • (1) NC controlled & power

BIESSE - ROVER A 1564 G FT: "GANTRY"5' x 21' "Matrix" Grid phenolic surface for: Nested Base Manufacturing.Working Cap."X" Axis: 251.9" (6,400 mm); "Y" axis: 62.4" (1,585 mm); "Z" axis stroke: 12.7" (324 mm);, max. material thickness: 6.7" (170 mm).Positioning Speed"X" & "Y" Axis: 279 FPM (85 MPM); "Z" axis: 98.4 FPM (30 MPM). - All axes movement: On precision linear guides & ways; controlled by: Digital, brushless AC Servo motors.All motion components maintained by: Automatic lubrication system. "X" & "Y" Axes use: Precision rack & pinion system; "Z" axis uses: Precision ball screws.WorktableFlat table design with: Matrix grid phenolic surface for Nested Base Manufacturing; (2) external pneumatic pop-up reference stops in "Y" axis; (4) pneumatic pop-up reference stops in "X" axis; (2) zone tables with: Automatic NC controlled zoning of each vacuum table. Prepared for (optional): "Quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with: "Quick connect" vacuum outlet for custom vacuum pods & fixtures. Boring Unit(1) 2-1/2 HP (1.7 kW) Motor. Variable speed: up to 6,000 RPM; (10) independent vertical spindles with: (5) In "X" axis; (5) in "Y" axis. (4) Horizontal spindles with: (1 + 1) In "X" axis; (1 + 1) in "Y" axis; (1) "X axis grooving saw with: 120 mm Dia. blade.Machining(1) 16.1 HP (12 kW) Air-cooled HSD electro-spindle with: HSK F63 Adaptor; variable speed from: 1,000 - 24,000 RPM; (1) 16-position ride-along tool changer for "on the fly" ATC; NC controlled presetting for: measurement of the tool length. Operator & Machine ControlPC Front-End with: BIESSE "XP 600" + WINDOWS WRT Operating system. 15" TFT Flat screen monitor; server; full keyboard & mouse: All mounted on a mobile cart; Ethernet connection capabilities.Graphic interface makes full use of the operating methods typical of the Windows Operating System: Assisted graphic editor used to program machining operations; programming & guided creation of parametric macros. Import of CAD and other external software files in: DXF & CID3 format; 3D simulation of the tool path; calculation of machining time; ability to create rotate virtual faces.Complete with:25 HP TRAVAINI Vacuum Pump; safety mats & fencing; Tool Touch Off Probe; automatic lubrication system for: Linear guides; pads; recirculating ball screw; Tele-Service capabilities; Universal Autotransformer for: Voltages between 200 - 600 V 50/60 Hz.Actual Model: BIESSE ROVER A 1564 G FT.
