Woodworking Equipment For Sale

CAM-WOOD SM-124TAX 4-Sided Planer/Moulder; 11-3/4"; Wide x 4" to 9"; HighCompact construction with moulding & planing capabilities and flexible performance at an attractive price. Designed for furniture, cabinet, and yes, even industrial arts and large hobby shops. The perfect machine for tongue & groove flooring, wall paneling, S4S work, etc. Specifications: -- 2-Sided Planing Capacity: 7/16"; to 9"; thick x 11-5/8"; wide -- 4-Sided Planing Capacity: 7/16"; to 9"; thick x 10-1/4"; wide. -- All cutters run at 7,000 RPM -- Top and bottom heads are 2-27/32"; (72 mm) diameter. -- Right and left side heads are 3-1/2"; (90 mm) diameter -- All spindles powered by 4.1 HP (3 kW) motors -- Top Spindle will profile to a 3/8"; pattern depth and 5/16"; max. stock removal when planing. -- Bottom Spindle will profile to a 3/16"; pattern depth and 3/16"; max. stock removal when planing. -- Right & left side spindles are 4"; long and have a max. moulding depth of 13/16";. -- Machined and hard chromed table is 24"; wide x 40"; long and travels 9"; (230 mm) vertically -- Feed system runs at 11 to 52 FPM and is powered by a 1/2 HP variable speed drive. -- Overall dimensions are 54"; long x 42"; wide x 44"; high and weighs 1,370 Lbs.Features: -- Large 11-5/8"; wide x 9"; thick 2-sided planing capacity or 10-1/4"; wide x 4"; thick 4-sided planing and moulding work. -- Individual motors drive each spindle; 7,000 RPM spindle speeds on all heads. -- Mechanical meter for accurate thickness adjustments. -- Heavy-duty spindle assemblies for durability & run-out free finishes. -- Rigidly mounted alloy steel spindles in precision bearings provide accurate and vibration-free power transfer. -- Spindle height adjustment by precision rack & pinion gear system. -- Compact construction, Heavy-duty welded steel frame and See through top guard. -- Magnetic overload switch for protection. -- Industrial-rated TEFC motors with sealed-for-life ball bearings.

CAM-WOOD SET-46TS 6 Heads 48" Double End Tenoner: Soring, trimming and shapingCapacity: -- Max. 48" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Motorized opening with LED indicator; -- Single-post machine, single "dual-track" base, right side fixed, left side movable.Each side equipped -- Front of post: Bottom scoring unit, 2 HP - 3,600 RPM motor, 1" dia. arbor & up to 10" blade; -- Top trim head, 3 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade; (saw blade included) -- Back of post: Vertical shaping head, 5 HP - 7,200 RPM motor, 5-7/8" (150 mm) long & 1" dia. arbor, 8" max. dia. cutter-head. -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads and dogs at 6" center, --Spring loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional $ 61,125) -- Hopper feed magazine (additional )Extended infeed 42" (additional $5,625) -- Sound enclosure additional $ 8,625 -- Pneumatic jump control on scoring or shaping unit -- Same machine with 8' opening

CAM-WOOD PL-12SX 12" Wide Top & Bottom Straightening PlanerFeatures & Equipped with: -- Spiral Insert Cutterheads. -- Standard equipped with Automatic Thickness Controller, easy and quick setting for the cutting thickness. -- Top & bottom carbide cutter heads for accurate and powerful two-sided planing in one pass. -- Auto digital thickness control for quick and accurate setup. -- The worktable surface was precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planing. -- Variable speed control by inverter for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The in-feed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then an accurate planing surface can be performed to prevent jumping during the processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with a heavy-duty drive chain and gears to provide a smooth even feeding during rough or finish planing. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload Specifications: -- 7-1/2 HP Top Head Motor -- 5 HP Bottom Head Motor -- 12-1/2"; Max. Working Width -- 4-3/4"; Max. Working Thickness -- 19/32"; Min. Working Thickness -- 13"; Min. Working Length -- 1/4"; Max. Cutting Depth per Head -- 2 HP Feed Motor -- Feed Speed (Inverter drive) from 15 to 52 FPM -- 5,000 RPM Cutter Head Speed -- 1/2 HP Elevation Motor -- With (2) 6" diameter dust outlets -- Spiral Insert Cutterheads with (45) 12 x 30 x 1.5 mm carbide insert knives with (2) cutting edges. Allows for fast, accurate insert changes and minimum downtime -- If required, change of electrics, will be quoted separately

CAM-WOOD PL-43-SX 43" TOP AND BOTTOM SURFACER with Spiral CutterSPECIFICATIONS: -- 40"; Maximum Working Width. -- 3/8" to 8" Maximum Working Thickness. -- 1/4"; Max. Depth of cut (Per Side). -- 4,000 RPM Cutter Head Speed. -- 6-1/4"; Cutter Head Diameter. -- 15 x 15 x 2.5mm Spiral Cutter Head Carbide Insert Knives. -- 40 HP Top Cutter Head Motor -- 30 HP Bottom Cutter Head Motor -- 2 HP Elevation Motor -- (1) 7.5 HP Feed Motors -- Feed Speed (Variable by Inverter drive) from 15 to 52 FPM -- 5-3/4 Feed Roll Diameter. -- Universal Joint & Shaft Drive System. -- Machine Weight, 11,600 Lbs. -- Machine Size (L x W x H) 81" x 106" x 63". FEATURES: -- Roll feed eliminates slipping when running green and heavy wood. -- Universal Joint and Shaft Driven Feed Rolls ensure adequate feeding power for wet, rough lumber as well as warped, cupped and bowed material and provide needed power transmission against heavy cutting depths. -- Top and bottom feed rolls are directly driven by universal joints and drive shafts for full-power transmission. -- A movable control box provides additional convenience in operation and setup. -- Standard equipment includes automatic thickness control to aid in easy and quick setting for the thickness to be planed. -- Worktable surface is precision ground and electric chrome-plated and polished to a smooth mirror finish. The durable wear-resistance surface is easy to clean and maintain and promotes good feeding of all types of wood. -- Stepless variable speed control (VFD) for smooth adjustment of feed rate depending on the material hardness, depth of cut & width. Used to provide the best finish surface and fast feed performance. -- Twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- Heavy, rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial-duty motors for maximum power transmission. -- All precision sealed, long-life bearings for durability. -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth, chatter-free planing regardless of the feed rate or hardness of material being planed.

CAM-WOOD SET-42TS-S 2 Heads 48" Double End Tenoner: Trimming only Capacity: -- Max. 48" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Motorized opening with LED indicator; -- Single-post machine, single "dual-track" base, right side fixed, left side movable.Each side equipped -- Top trim head, 5 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade; -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads and dogs at 6" center, --Spring loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional $ 61,125) -- Hopper feed magazine (additional $4,990)Extended infeed 42" (additional $5,620) -- Pneumatic jump control on scoring or shaping unit -- Same machine with 8' opening

CAM-WOOD MODEL PL-52 SHX TOP AND BOTTOM SURFACERSpecifications: -- 52"; Maximum Working Width -- 12-1/4"; Maximum Working Thickness -- 1/2"; Minimum Working Thickness (3/8" on request) -- 1/2"; Max. Depth of cut (Per Side) -- 4,000 RPM Cutter Head Speed -- 6-1/4"; Cutter Head Diameter -- 15 x 15 x 2.5 mm Spiral Cutter Head Carbide Insert Knives -- 40 HP Top Cutter Head Motor -- 30 HP Bottom Cutter Head Motor -- 2 HP Elevation Motor -- Feed Speed (Variable by Invertor drive) from 12 to 55 FPM -- 5-3/4 Feed Roll Diameter -- (2) 5 HP Feed Motors -- Machine Weight, 15,700 Lbs -- Machine Size (L x W x H) 81" x 112" x 63" Features: -- Roll feed eliminates slipping when running green and heavy wood. -- Universal Jointed Shaft Feed Rolls to ensure adequate feeding power for wet, rough lumber as well as warped, cupped and bowed material for heavy cutting depths -- Top and bottom feed rolls are directly driven by universal joints and drive shafts for full-power transmission. -- Movable control box provides additional convenience in operation and setup. -- Standard equipment includes automatic thickness control to aid in easy and quick setting for the thickness to be planned. -- Worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear-resistant surface is easy to clean and maintain and promotes good feeding of all types of wood. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width. Used to provide the best finish surface and fast feed performance. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- Heavy, rigid cast iron frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial-duty motors for maximum power transmission. -- All precision sealed, long-life bearings for durability. -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth, chatter-free planing regardless of the feed rate or hardness of material being planed.OPTION: -- 600 volts 3 phases 60 HZ additional: $2,100

CAM-WOOD WP-4 S2C-500-16 4-SIDED PLANEROutstanding Performance - Quality Components -- Floating bottom infeed rolls for smooth, positive feeding -- PLC controls with touch-screen interface for ease of operation -- Variable feed speeds by VFD. Controlled from touch screen -- Drive shaft and universal joint feed roll transmission for each feed roll -- Power elevation of overhead mechanism via touch screen control -- Thickness settings from touch screen control -- With cutterheads and carbide knives for straight knife work -- With spindles for easing top edges -- Tables, fences, etc. are precision ground and hard chromed to provide long life and smooth feeding -- Overhead mechanism travels up/down and is support by (6) hard chromed posts -- Motor Control Center with under voltage and overload protection; includes UL and CSA approved electrical componentsWorking Capacities: -- 19 3/4" wide x 16"; high -- Min. thickness: 3/4"; -- Min. width 4-3/4"; -- Max. depth of cut: 1/4"; all heads -- Max. length: Unlimited -- Min. length: 70"; for feed-thru; butt-feed down to 40". (40"; to 70"; may have minor inaccuracies at edge due the hold-down restrictions) -- Feed speeds from 20 to 65 FPMCutterhead Motors: -- 25 HP Top and Bottom (see optional equipment for larger motors) -- 20 HP Right & Left Side Heads (see optional equipment for larger motors) -- Includes Right & Left Spindles for eased edge at top of board; consists of (2) 1 HP floating spindles to accurately ease top edges. Profile knives in primary side heads ease bottom edges.Feed Works: -- (2) 5 HP VFD’s -- (1) motor drives top set and (1) motor drives the bottom set of feed rolls -- Boards synchronize top and bottom feed roll speed and torque Cutterheads and Spindles: -- Top and bottom spindles with 60mm (2.362";) spindle dia. Other diameters on request. -- Includes a set of (2) 4-knife x 25-1/2"; long x 5-1/2"; dia. spiral carbide cutterheads. -- Side heads with 1-1/4" spindle dia. Other diameters on request -- Includes a set of (2) 4-knife x 20"; long spiral carbide heads -- Includes (1) set per head: 15 x 15 x 3mm carbide knives with (4) cutting edges -- All spindles with hydro-lock outboard bearings -- Left & Right Side Heads can be used for profile work with owner provided tooling -- Eased Edge Spindles: 1-1/4"; dia. -- Eased Edge Cutting Circle: 4.9";Dust hoods: -- 8"; dia top and bottom head hoods; 6"; dia. side head hoodsOptional Equipment: -- Optional HP on Top & Bottom Heads, up to 40 HP, -- Optional HP on Right & Left, up to 30 HP, -- Electric Brakes for side spindles, -- Power raise/lower and auto-setting for side spindles, Machine Dimensions and Weight: -- 10’ long x 7-1/2’ wide x 6-1/2’ high x 20,000 Lbs.

CAM-WOOD WP-20L8-V4X, 20"; WIDE X 5" HIGH 4-SIDED PLANER/MOULDER, (8" Optional)Planer or Combination Planer/Ripsaw is designed for furniture, cabinet, flooring, intermittent planing millwork, and other industrial applications. The perfect Planer for S2S and S4S planing, planing and ripping, tongue & groove flooring, wall paneling, etc. up to approximately 75 FPM depending on the depth of cuts and dimensions of parts.Working Capacities: -- Width: 3/4"; to 20";. -- Height: 3/8"; to 5", (8"; optional additional $4,950). -- Length: 20"; Minimum, Maximum Unlimited. -- Maximum Cutting Depth: Top & Bottom Heads 1/2";, Side Heads 1";. Included Tooling Is Slip-On Spiral or Profile Cutterheads: -- Standard with Slip-On HAR Series Profile / Spiral Cutter head. Profile Knives combined with 15 x 15 mm x 3° Carbide Insert knives. 1/2"; Max depth of cut. The top and Bottom spindles are 60 mm (2.36";) in diameter. Optional Profile Cutterheads Available. -- Left & Right-Side Spindles with Standard HAR Series Profile Heads. -- Max depth of cut 1";. With 40 mm (1.57";) Spindle Diameter. Cutting Circle from 6" to 7";. -- Left & Right-Side Heads will run profiles with owner-provided tooling. Quality Features = Long and Outstanding Performance -- Simple touch screen with Digital Positioning Controllers for width adjustment, thickness adjustment and variable feed speed. -- Hard Chrome Plated Table for long life and smooth feeding. -- Automatic Top Head Adjustment – cutter head height adjustment entered via HMI touch screen control with PLC. -- Floating Bottom Infeed Rolls for smooth, positive feeding. -- Variable Feed Speeds by VFD Controlled from Touch Screen. -- Heavy-duty Spindle Assemblies for durability & smooth finishes. -- Overhead assembly travels up/down and positions via touch screen control. Assembly is support by (4) hard chromed, polished posts and precision screws. -- Tables, fences, etc. are precision ground, polished and hard chromed to provide long life and smooth feeding. -- Massive, heavy-duty sheet metal frame aids in vibration absorbing finishes and extra-long bearing life. Compact construction with exclusive see-through top guard. -- Motor Control Center with under voltage and overload protection. UL and CSA labeled electric components. Motors and Feed Works: -- Top and Bottom Cutter Heads Motors, each: 15 HP, 5,000 RPM. -- Right & Left Side Cutter Motors, each: 10 HP, 5,000 RPM. -- Variable Feed Speeds from 20 to 65 FPM by VFD (invertor). -- Feed is powered by (2) each 2 HP VFD feed motors. -- (1) motor drives the top infeed and (1) Motor drives the top outfeed feed rolls. Top-powered feed rolls are air cylinder loaded / floating. -- (8) non-powered bottom rolls, (4) infeed and (4) outfeed.Machine Sizes / Dimensions and Weight: -- 76"; Length x 52"; Width x 71"; Height. -- Weight 4,920 LbsOptional Equipment: -- Type MP Carbide Side Head Tooling for profile work. Price on request. -- With a 20" spindle length -- 40 mm arbor diameter

CAM-WOOD SM-324D 4-Sided Planer Specifications: -- Maximum Working Width 12";, Max. Thickness 4"; -- Hard chrome-plated table for maximum wear resistance. -- Anti-impact plate for over-width and over-thickness protection. -- Oversized top and bottom rollers run synchronized, ensuring smooth feeding. -- FRP plastic steel safety guard provides maximum durability and impact resistance. -- The three independent sections; pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers can be set with individual pressure allowing for consistent feeding and outstanding results. -- The smooth initial feeding of the stock is achieved by the independently powered infeed rollers. -- Specifically designed template inserted pressure plate suits various stock thicknesses and profile variations. -- A special pressure plate based on the table feeding roller design provides smooth and precise cutting of dry and wet wood, reducing the possibility of material jams.Features: -- The base is machined by CNC machine equipment to ensure the utmost working accuracy. -- The first bottom horizontal spindle can be fitted with a trimming cutter for trimming a groove on the workpiece side to achieve perfect straightness. -- The specially designed short stock feeding mechanism combined with auxiliary pressure wheels permits the machine to perform machining on extra short stocks. -- All spindles are precision constructed and specially heat treated to provide maximum cutting stability and permanent accuracy. -- Each spindle is equipped with a mechanical digital readout giving accurate adjustment. -- Every cutter spindle can be adjusted "up and down" and "in and out" for quick setup. -- Industrial full-power motors for maximum cutting capacity.Capacity and Heads: -- Max. Working Width 12"; -- Max. Working Thickness 4-3/4" -- Min. Working Length 9½" -- Vertical stroke of side head 30 mm (1.18") -- 1st Spindle Horsepower 10 HP -- 2nd, 3rd, 4th Spindle Horsepower 10, 10, 10 HP -- Feed Motor 7½ HP -- Elevation motor 1 HP -- Spindle arbor Diameter 40 mm -- Cutter Speeds (RPM) 6,500 -- Variable Feed Speeds (FPM) 16 ~ 82Cutterhead Diameter -- 1st Bottom Head 6"; Dia x 12"; L -- 2nd & 3rd Vertical Head 6"; Dia x 3"; L -- Top Head 6"; Dia x 12"; L -- Pneumatic Air 90 PSI (CFM) 5 -- Dust Outlets Diameter 5" x 4 outlets -- N.W. (Lbs) 9800Option: -- Sound enclosure Add ...$10,900

CAM-WOOD INFEED AND OUTFEED PLANER TRANSFER LINE: 20"; Wide X 20’ Long Roller Conveyors with 6,000 lbs capacity and Consisting of the following: NON POWERED IDLE INFEED RIGHT ANGLE ROLLER TRANSFER CONVEYORS -- (4) Conveyor Sections, each 14"; Wide X 8’ Long (SEE DRAWING). -- 2-11/64"; Roller Diameter -- Rolls on 3"; Centers to Handle 2"; x 4"; and Wider -- Supports up to 6,000 lbsPOWERED INFEED CANTED ROLLER CONVEYOR -- With VFD Drive with speed feed 18' to 70 FPM -- 22"; Wide X 20’ Long -- Heavy Duty 3-11/32"; Roll Diameter -- (9) Rolls on 36"; Centers -- (5) Pneumatic jumped transfer roll -- Back Side Adjustable FencePOWERED OUTFEED STRAIGHT ROLLER CONVEYOR -- With VFD Drive with speed feed 18' to 70 FPM -- 22"; Wide X 20’ Long (Longer with Owner Provided Outboard Roller) -- Heavy Duty 3-11/32"; Roll Diameter -- Rolls on 36"; Centers -- Includes (4) Sections of Pneumatically Jumped Skate Rolls -- Heavy Duty Type, Sections are 6"; Wide X 20"; Long NON POWERED IDLE OUTFEED RIGHT ANGLE TRANSFER ROLLER CONVEYORS (SEE DRAWING) -- (4) Conveyor Sections, each 14"; Wide X 8’ Long. -- 2-11/64"; Roller Diameter. -- Rolls on 3"; Centers to Handle 2"; x 4"; and Wider -- Supports up to 6,000 Lbs.

CAM-WOOD WP-4 S2C-500-12 4-SIDED PLANEROutstanding Performance - Quality Components 4 sided with 6 heads as: top and bottom, left and right, (2) chamfer units -- Floating bottom infeed rolls for smooth, positive feeding -- PLC controls with touch-screen interface for ease of operation -- Variable feed speeds by VFD. Controlled from touch screen -- Drive shaft and universal joint feed roll transmission for each feed roll -- Power elevation of overhead mechanism via touch screen control -- Thickness settings from touch screen control -- With cutterheads and carbide knives for straight knife work -- With spindles for easing top edges -- Tables, fences, etc. are precision ground and hard chromed to provide long life and smooth feeding -- Overhead mechanism travels up/down and is support by (6) hard chromed posts -- Motor Control Center with under voltage and overload protection; includes UL and CSA approved electrical componentsWorking Capacities: -- 19 3/4" wide x 12"; high (500 mm X 305 mm) -- Min. thickness: 3/4"; -- Min. width 2-3/4"; -- Max. depth of cut: 1/4"; all heads -- Max. length: Unlimited -- Min. length: 70"; for feed-thru; butt-feed down to 40". (40"; to 70"; may have minor inaccuracies at edge due the hold-down restrictions) -- Feed speeds from 20 to 66 FPMCutterhead Motors: -- 25 HP Top and Bottom (see optional equipment for larger motors) -- 20 HP Right & Left Side Heads (see optional equipment for larger motors) -- Includes Right & Left Spindles for eased edge at top of board; consists of (2) 1 HP floating spindles to accurately ease top edges. Profile knives in primary side heads ease bottom edges. -- Chamfer motor 1/2 HP Feed Works: -- (2) 5 HP VFD’s -- (1) motor drives top set and (1) motor drives the bottom set of feed rolls -- Boards synchronize top and bottom feed roll speed and torque --Cutterheads and Spindles: -- Top and bottom spindles with 60mm (2.362";) spindle dia. Other diameters on request. -- Includes a set of (2) 4-knife x 20"; long x 5-1/2"; dia. spiral carbide cutterheads. -- Side heads with 40mm spindle dia. Other diameters on request -- Includes a set of (2) 4-knife x 12"; long spiral carbide heads -- Includes (1) set per head: 15 x 15 x 3mm carbide knives with (4) cutting edges -- All spindles with hydro-lock outboard bearings -- Left & Right Side Heads can be used for profile work with owner provided tooling -- Eased Edge Spindles: 30mm"; dia. -- Eased Edge Cutting Circle: 4.9"; -- Powered side pressure device at infeed Dust hoods: -- 6"; dia top and bottom head hoods; 6"; dia. side head hoodsOptional Equipment: -- Optional HP on Top & Bottom Heads, up to 40 HP, -- Optional HP on Right & Left, up to 30 HP, -- Electric Brakes for side spindles, -- Power raise/lower and auto-setting for side spindles, Machine Dimensions and Weight: -- 110" long x 86" wide x 94" high x 15200 Lbs.

CAM-WOOD MODEL PL-40 SHX TOP AND BOTTOM SURFACER with Roll FeedSpecifications: -- 40"; Maximum Working Width -- 12-1/4"; Maximum Working Thickness÷Minimum Working Thickness Standard 2" but with special excution it can cgo down to 7 mm (0.275" on request)( Special minimum thickness Must be specified at time of order) -- 1/2"; Max. Depth of cut (Per Side) -- 4,500 RPM Cutter Head Speed -- 6-1/4"; Cutter Head Diameter -- 15 x 15 x 2.5 mm Spiral Cutter Head Carbide Insert Knives -- 30 HP Top Cutter Head Motor -- 20 HP Bottom Cutter Head Motor -- 2 HP Elevation Motor -- Feed Speed (Variable by Invertor drive) from 12 to 55 FPM -- 5-3/4 Feed Roll Diameter -- (2) 5 HP Feed Motors -- Machine Weight, 11,600 Lbs -- Machine Size (L x W x H) 106" x 81" x 63" Features: -- Roll feed eliminates slipping when running green and heavy wood. -- Universal Jointed Shaft Feed Rolls to ensure adequate feeding power for wet, rough lumber as well as warped, cupped and bowed material for heavy cutting depths -- Top and bottom feed rolls are directly driven by universal joints and drive shafts for full-power transmission. -- Movable control box provides additional convenience in operation and setup. -- Standard equipment includes automatic thickness control to aid in easy and quick setting for the thickness to be planned. -- Worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear-resistant surface is easy to clean and maintain and promotes good feeding of all types of wood. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width. Used to provide the best finish surface and fast feed performance. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- Heavy, rigid cast iron frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial-duty motors for maximum power transmission. -- All precision sealed, long-life bearings for durability. -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth, chatter-free planing regardless of the feed rate or hardness of material being planed.

CAM-WOOD SET-82TS S Double End Tenoner, 2 HeadsCapacity & Style: -- Max. 98" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Top trim head, 5 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade. -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring-loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross-transfer system with transfer line 4' X 8' transfer table with rollers (additional $61,125). -- Hopper feed magazine (additional $4,990). -- 42" Infeed extension (additional $5,620) -- Pneumatic jump control on scoring or shaping unit. -- Sound enclosure (additional $ 7,900) -- Electric motor brake -- Central supportNote: Pictures are showing the machine with several options included

CAM-WOOD WS-DA3760 Wide Belt Sander, (2) HeadsWith the two-head wide belt sander, you can accurately, and heavily sand your stock with the first drum head, and with the second combination head, you can give an unlimited fine finish.Application: -- Rugged heavy-duty sheet metal construction designed for durability usage. -- Powerful industrial motors drive sanding and auto infeed smoothly. -- Infeed and outfeed have spring-loaded hold-down rollers to ensure positive feeding without sanding marks. -- Combination platen & drum sanding head for best sanding choice such as: --With the platen up, the sander functions as a drum-only machine, for sanding with a 40 ~ 100 grit belt. -- With the platen and drum same level, intermediate and final finishing is possible, using a grit of 120 ~ 180. -- With the platen down (below the drum), used for the fine finishing or lacquer sealer sanding, with 180 ~ 600 grit.Head Configuration:1st Head : 20 HP Drum2nd Head : 15 HP Combination HeadSpecifications: -- Max. Working Width 37" Max. -- Working Thickness 5". -- Min Working Length 12½". -- Sanding Belt Dimensions (W x L) 37" x 60". -- Dust Collection Hood (Dia x Holes) 6" x 2. -- Main Motors 20 and 15 HP. -- Conveyor bed Feed Motor 2 HP. --Table Raising / Lowering Motor 1/2 HP -- Variable Feed Speed 20 - 80 FPM. -- Working Air Pressure 6 CFM. -- Exhaust Volume Require 2,400 CFM. -- N.W. weight 5,100 Lbs.Equipped with and Features: -- Sanding platen with a quick release and lock down design for easy removal or loading of graphite platen. -- Computerized thickness adjustment control with accurate digital readout; key in the size desired and automatic table movement for sanding thickness within 0.005"; accuracy -- Large size diameter contact drum is dynamically balanced, rubber-covered spiral grooves designed to provide considerable advantages for the effective removal of material. -- Special rubber feed belt for safe non-slipping, transporting the workpieces. -- The abrasive belts are tracked by oscillating cylinders linked to the upper roller. The edge of the belt is detected by an electric eye sensor, which in turn controls the air supply to the position via solenoid value. Also, one limit switch is located on each end of the top roller of the sandpaper for quick stop in case of belt breakage. -- The main table is designed with the convenient leveling adjustment which ensures greater stability with excellent tolerance providing a variable from 0"; ~ 5"; range sanding thickness. -- (4) Heavy-duty jackscrews power conveyor table elevation.

CAM-WOOD WS-DA4375X DUAL HEAD WIDE BELT SANDERWith the two-head wide belt sander, you can accurately, heavily sand your stock with the first drum head, and with the second combination head, you can give an unlimited fine finish.Application: -- Rugged heavy-duty sheet metal construction designed for durability usage. -- Powerful industrial motors drive sanding and auto infeed smoothly. -- Infeed and outfeed have spring-loaded hold-down rollers to ensure positive feeding without sanding marks. -- Combination platen & drum sanding head for best sanding choice such as: --With the platen up, the sander functions as a drum only machine, for sanding with a 40 ~ 100 grit belt. -- With the platen and drum same level, intermediate and final finishing is possible, using a grit of 120 ~ 180. -- With the platen down (below drum), used for the fine finishing or lacquer sealer sanding, with 180 ~ 600 grit.Head Configuration:1st Head : 30 HP Drum2nd Head : 20 HP Combination HeadSpecifications: -- Max. Working Width 43" Max. -- Max. Working Thickness 5". -- Min Working Length 12½". -- Sanding Belt Dimensions (W x L) 43" x 75". -- Dust Collection Hood (Dia x Holes) 6" x 2. -- Main Motors 30 and 20 HP. -- Conveyor bed Feed Motor 3 HP. --Table Raising / Lowering Motor 1/2 HP -- Variable Feed Speed 20 - 80 FPM. -- Working Air Pressure 6 CFM. -- Exhaust Volume Require 3,800 CFM. -- N.W. weight 6,160 Lbs.Equipped with and Features: -- Sanding platen with a quick release and lock down design for easy removal or loading of graphite platen. -- Computerized thickness adjustment control with accurate digital readout; key in the size desired and automatic table movement for sanding thickness within 0.005"; accuracy -- Large size diameter contact drum is dynamically balanced, rubber covered spiral grooves designed to provide considerable advantages for the effective removal of material. -- Special rubber feed belt for safe non-slipping, transporting the workpieces. -- The abrasive belts are tracked by oscillating cylinders linked to the upper roller. The edge of the belt is detected by an electric eye sensor, which in turn controls the air supply to the position via solenoid value. Also, one limit switch is located on each end of the top roller of the sandpaper for quick stop in case of belt breakage. -- Main table designed with the convenient leveling adjustment which ensures greater stability with excellent tolerance providing a variable from 0"; ~ 5"; range sanding thickness. -- (4) Heavy-duty jackscrews power conveyor table elevation.

CAM-WOOD SET-86TS SJC Double End Tenoner, 6 HeadsCapacity & Style: -- Max. 98" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Top scoring head, 2 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade -- Top trim head, 10 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade. -- Cope shaping head, 7.5 HP - 7,200 RPM motor, (150 mm) 5 7/8" long X 1" diameter arbor, 6" to 8" max. dia. cutter head -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring-loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross-transfer system with transfer line 4' X 8' transfer table with rollers (additional $61,125). -- Hopper feed magazine (additional $4,990). -- 42" Infeed extension (additional $5,620) -- Pneumatic jump control on scoring or shaping unit. -- Sound enclosure (additional $ 8,620) -- Electric motor brake -- Central supportNote: Pictures are showing the machine with several options included

CAM-WOOD SET-56SAT 6-Head Double End Tenoner (Not Feed Through)Capacity: -- Length of cut: 12" to 60" (opening). -- Max. width of cut: 24" (cross cut). -- Max. clamping thickness: 4-1/2". -- Saw blade dia. 8" to 12"; saw arbor dia. 1"; saw blade speed 3,400 RPM; saw head swivels 180 degrees. -- Moulder (Shaper) spindle: 1" Dia. x 5" long; spindle speed 6,000 RPM; spindle swivels 180 degrees. -- Vertical travel: 17" vertical. -- Carriage (table) travel (front/back): 24".Equipped with: -- Saw motors: (4), each 2 HP motors (1 top & bottom each side). -- Shaper spindles: (2), each 3 HP motors (1 each side). -- Powered length setting: 1/2 HP motor (machine opening).Features: -- With the double end miter saw set-up, you can cut-off stock faster or consider a double end miter saw combined with moulding (shaper) head. It lets you cut and machine stock and moulding pattern in a single feed, saves time, space and cost. -- Air-operated vertical clamps hold sticks firmly in place. After the work piece is clamped, table start to feed, performs trimming and shaping operations. -- Trim saw allows to cut stock accurately with a clean cut. -- Moulding (Shaper) spindle mounted at the rear of saw head enables the machine to perform edge moulding after stock is cut off. -- The entire cutting cycle, cut-off, shaping/tenon or mortise is automatically operated in a single pass of stock feeding. -- The material Clamping table travels on a precision linear motion guide for stability. -- The table traverse is motorized, ensuring very stable, smooth workpiece feeding. -- Material transport thru machine powered by variable speed inverter drive for 10 to 20 Sec per cycle -- Variable feed speed permits proper feed selection for hard or soft wood materials. -- Large hand-wheel to adjust depth of cut. -- All controls are grouped in a control panel. -- Industrial motors for optimal cutting results.Machine Stations: -- 1: Top & Bottom Trim Saws powered by (4) 2 HP saw arbor motors for trimming to length. -- 2: Shaper spindles powered by (2) 2 HP spindle motors for applying tenons and grooves. -- Floor space requirement: 94" X 40" X 54" high. -- Cycle time: 10 to 20 Sec per cycle.Available option at additional cost: -- Auto Outfeed device -- Return conveyor

CAM-WOOD SET-88DET-SHJCJC 8-Head, 96" Double End Tenoner -- Suitable for mass production of woodworking task for double-end cutting, tenoning, grooving, profiling and sanding -- Scoring, Hogger/Saw, Jump Shaper, Jump Shaper: Total (4) stations on both sides. -- A solid, powerful machine great for Heavy-Duty production.Capacity: -- The specially designed numeric controller allows quick setting of sizes, for the tolerance within 0.004";. -- Variable speed, through feed, wide rubber pad chain, spring-loaded dogs at 8" center conveyor for the best finish selections. -- Heavy-duty pressure rolls at top of wide width conveyor to hold the material tight to prevent sliding during the cutting process. -- Shaper heads can be moved up & down, forward & backward. -- Max. 96" working capacity, min. 12"; max. 3-1/8" opening, 24" load area in front of hold-downs. -- The automatic high-speed through feed device allows for perfect finishing at speeds ranging from 20 - 66 FPM. -- Motorized opening with LED indicator.Each side equipped -- Top Scoring saw unit , 2 HP - 3,600 RPM motor, 1" dia. arbor & up to 8" blade -- Hogging/ Trim saw tiltable unit, 5 HP - 3,600 RPM motor, 1" arbor and up to 10" blade. -- Jump Shape/coping head unit, 7.5. HP - 4,500-7,000 RPM motor, 40mm dia. arbor for 6" to 8" cutter head. -- Jump Shape/coping head unit, 7.5 HP - 4,500-7,000 RPM motor, 40 mm dia. arbor for 6" to 8" cutter head -- Variable feed speed from 20 - 66 FPM, 2 HP motor, steel feed chains with plastic anti-slip pads and dogs at 16" center. -- Spring-loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Not Included -- Hopper feed magazine $3,960) -- Extended infeed 42" in front of hold-down belt $4,900) -- Sound enclosure $ 8,900Floor space : 8.5' X 9' X 6', weight 10,500 Lbs

CAM-WOOD SET-810SHJCR , Double End Tenoner with Sanding12-Head Double End Tenoner, suitable for mass production in a woodworking factory, processing double end cutting, tenoning, grooving, moulding, and sanding.Features: -- Automatic high-speed through feed device allows for perfect finishing at speeds ranging from 20 - 75 FPM. -- In addition to the double-end cutting, all the settings and other processing can also be executed with high accuracy. -- Since the machine is so versatile, we believe it will be one of the most satisfactory machines for bulk production lumber-processing factories. -- The specially designed numeric controller allows quick setting of length sizes for tolerance within 0.004". -- The numeric control system provides highly accurate settings, and a special memory retains all settings, even if there is a power failure. -- Variable speed, through feed, wide rubber pads with spring-loaded dogs located at 16" center distance with conveyor speed for the best finish selections. -- Heavy-duty powered pressure rolls at top of the wide width conveyor holds the material tight to prevent sliding during the cutting and sanding process. -- Shaper head can be moved up & down, forward & backward. -- Workstations are powered by industrial motors for full power cutting and utilizing the entire sanding capacity range. -- Two sanding heads can use brush, flap wheel or profile disc for fine finish with one pass. -- Trim saws and sanding heads can be tilted for different angular setup. -- Heavy cast iron base for durability and heavy duty usage.Specifications: -- Thickness: ½" to 4" -- Length: 10" to 96" -- Miter Saw Blade: 10" x 30 mm Dia. -- Grooving Saw Blade: 8" x 1" Dia. -- Shaper Cutter: 6" - 10" x 30 mm Dia. -- Feed Speed: Variable, 20 ~ 75 FPM -- Trim Saw 3 HP x 2, 3,450 RPM -- Hogging Saw 10 HP x 2, 3,450 RPM -- Jump Shaper 10 HP x 2, 4,500 to 7,000 RPM -- Shaper 10 HP x 2 4,500 to 7,000 RPM -- Belt Sanding 3 HP x 2, 0-1500 RPM -- Brush Sanding 3 HP x 2 with 30 mm arbor 0-1500 RPM -- Feeding 3 HP x 1 -- Width (Opening) Setting 1 HP x 1 Option: -- Sound enclosure ...$ 8,800

CAM-WOOD SM-623-HS 6-Head High-Speed Trough Feed Moulder(6)-Heads (B-R-L-T-T-B), working cap. 9" x 6-1/4".Specifications: -- Max/Min working width 9-3/4" -- Max/Min thickness 6-1/4" - 5/16" -- Minimum length 9-1/2" -- Head sequence: Bottom 10 HP, right 10 HP, left 10 HP, top 15 HP, top 15 HP and bottom 15 HP motor. -- Spindle dia. 40 mm (or by request) with cutterhead speed of 6,200 RPM. -- Feed works: Inverter driven, 10 HP feed system with feed speeds of 20 - 260 FPM. -- Infeed table 2 M (6'6"), chromed tables, and fences. Side pressure roller mounted at the infeed. Features and complete with: -- SM-237-DG where the last bottom spindle can be used for cutter head or saws with inverter RPM control -- HMI Touch Screen Control for all the head positions -- Automatic setting from 2nd to 6th heads, (2) axis positions and thickness control by servo control movement -- 200 sets of memory (Extendable) -- Feed speeds ranging from 20' ~ 260' per minute are standard specifications. -- Hard chrome-plated table for maximum wear resistance. -- Full enclosure safety hood reduces noise and completely prevents chips from splashing. -- Anti-impact plate for over-width and over-thickness protection. -- Oversize top and bottom rollers run synchronized, ensuring smooth feeding. -- FRP plastic steel safety guard features maximum durability and is impact resistance. -- The three independent section pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers canbe set with individual pressure allowing for consistent feeding results and outstanding effect. -- The smooth initial feeding of the stock is achieved by the independently powered infeed rollers. -- Exclusively designed template inserted pressure plate suits various stock thicknesses and profile variations. -- A special pressure plate with table feeding roller design, provides smooth and precise cutting of dry and wetwood, reducing the possibility of material jams. -- All control levers for the spindles are located at the front of the machine for convenient adjustment. -- Vertical spindle adjustment up to 80 mm, allows fitting several tools on the vertical spindle, eliminating troublesome cutter change. -- Separate adjustment of the vertical spindle and insert table permits the table to be positioned extremely close to the cutterhead for added cutting stability. -- An individual motor drives each spindle and is separately mounted to eliminate spindle chattering during high-speed running. -- Centralized lubrication system Available options: -- Automatic jointer head for all (6) heads add ...$ 58,500 -- Siko encoder with digital display for all axis add ...$ 4,200 per head -- Automatic lateral chain feeder P.O.R.
