This Pneumatic Vertical Clamping System features upper and lower 12" wide and up to 42" long steel platens for face gluing a variety of solid wood components. With its modular design with each section having its own pressure control and 40" opening, 13" daylight. -- 12" Deep x 42" long clamping cap. -- Air operated assembly, for face gluing of engineered stiles & rails, kickers, headers, and many other solid wood applications. -- Single lever valve operation with dial regulator pressure controls for quick & accurate clamping pressure. -- Up to 30 Ton max. clamping pressure @ 120 PSI.

JLT 79F- 6-PC Multi Level Panel Clamp6' Wide, free-standing or wall mount Clamp Rack unit.Equipped with: -- (5) Levels for mounting clamps; -- (8) clamps manually adjusted - side-to-side and manual open-and-close for all clamps. -- Clamps have a 40" opening with a 3-1/2" high x 4" wide jaw. (52" clamp available upon request)Available Options: -- Pneumatic panel flattener with single lever valve operation, 40" reach and flatten up to 1-1/2" thick material, additional: ...$1,500 -- Glue applicator Redi spreader 6" x 27" grid capacity, additional ...$ 1,200 -- Glue applicator Plate spreader 8" x 48" grid capacity, additional ...$2,350 -- Clamp 3 1/2" X 40" opening ... $ 149 -- 79-1680-Handle $110 for use with 1/2" drive impact gun (adjustable torque preferred with setting of 50-55 ft/lbsFloor space requirement: 75" x 70" x 48" high

JLT 79F-8-PC Multi Level Panel Clamp8' Wide, free-standing or wall mount Clamp Rack unit.Equipped with: -- (5) Levels for mounting clamps; -- (18) clamps manually adjusted - side-to-side and manual open-and-close for all clamps. -- Clamps have a 40" opening with a 3-1/2" high x 4" wide jaw.Available Options: -- Pneumatic panel flattener with single lever valve operation, 40" reach and flatten up to 1-1/2" thick material, additional: ...$1,500 -- Glue applicator Redi spreader 6" x 27" grid capacity, additional ...$ 1,200 -- Glue applicator Plate spreader 8" x 48" grid capacity, additional ...$2,350 -- Clamp 3 1/2" X 40" opening ... $ 149 -- 79-1680-Handle $110 for use with 1/2" drive impact gun (adjustable torque preferred with setting of 50-55 ft/lbsFloor space requirement: 100" x 70" x 48" high

JLT 79F-12-PC Multi Level Panel Clamp12' Wide, free-standing or wall mount Clamp Rack unit.Equipped with: -- (5) Levels for mounting clamps; -- (6) clamps per level (a total of 30) manually adjusted - side-to-side and manual open-and-close for all clamps. -- Clamps have a 40" opening with a 3-1/2" high x 4" wide jaw.Available Options: -- Pneumatic panel flattener with single lever valve operation, 40" reach and flatten up to 1-1/2" thick material, additional: ...$1,500 -- Glue applicator Redi spreader 6" x 27" grid capacity, additional ...$ 1,200 -- Glue applicator Plate spreader 8" x 48" grid capacity, additional ...$2,350 -- Clamp 3 1/2" X 40" opening ... $ 149 -- 79-1680-Handle $110 for use with 1/2" drive impact gun (adjustable torque preferred with setting of 50-55 ft/lbsFloor space requirement: 144" x 78" x 52" high

JLT 79F-16-PC Multi Level Panel Clamp16' Wide, free-standing or wall mount Clamp Rack unit.Equipped with: -- (5) Levels for mounting clamps; -- (36) clamps total manually adjusted - side-to-side and manual open-and-close for all clamps. -- Clamps # 302-40-H-R with 40" opening with a 3-1/2" high x 4" wide jaw. -- (72) # 80-1706 Rocker adaptor plates for up to 6" thick glue stock -- (1) Fastener and shim kit for precise clamp alignmentAvailable Options: -- Pneumatic panel flattener with single lever valve operation, 40" reach and flatten up to 1-1/2" thick material, additional: ...$1,500 -- Glue applicator Redi spreader 6" x 27" grid capacity, additional ...$ 1,200 -- Glue applicator Plate spreader 8" x 48" grid capacity, additional ...$2,350 -- Clamp 3 1/2" X 40" opening ... $ 149 -- 79-1680-Handle $110 for use with 1/2" drive impact gun (adjustable torque preferred with setting of 50-55 ft/lbsFloor space requirement: 16' x 52"W x 70" high

JLT CLAMPS 78H-12-42-40 Mini Pod PressSingle section 12" wide x 42" long cap., 40" max. opening, 13" daylight, 30 ton max.,clamping pressure at 120 PSI, Pod Press is powered by a total of (18) 20 square inch diaphragm cylinders, upper platen has a 2" stroke when air is activated.Features: Heavy duty upper and lower steel platens, single lever valve pneumatic operation with dial regulator pressure controls, stack multiple wood components up to 12" wide and ships pre-assembled. Includes: Manual jack for platen adjustment.

JLT Clamps 302-40-H-R DOOR AND PANEL CLAMP40" Capcity clamp (min 8-1/2") Patented Equalizer Design Provides Equal Clamping from the Front and Rear Jaws, Resulting in a Higher Quality Panel. #302 Style Clamp with Standard 3-1/2" High Jaws for Increased Durability and Less Clamps Per Glue Up.Also available with 36", 44" and 52" capacities.

JLT CLAMPS - 79X-5-DM: Dual Station Miter Door Pro5-Section rotating Clamp; 26" x 42" max. cap.; 4" x 12" min. cap.; 2-1/2" max. thickness capacity. -- (2) Horizontal & (2) Vertical Clamps for: Applying pressure to Mitered Doors. -- Recommended for miter and stile & rail doors. -- 1-Lever operation; clamp & square a door in (2) seconds; 500 Lbs of clamping force per cylinder; machine rotates counterclockwise for safety.

JLT CLAMPS 190C-M2 Drawer Clamp Heavy-duty Upper Box and Case Clamp, maximum capacity 12" H x 48" L x 48" W -- Achieve 3,500 Lbs clamping force at 100 PSI air pressure. -- Easy to use mounted lever valve with intergrated pressure hold kit. -- Pneumatic foot pedal activation. -- (4) Clamp Design provides equal pressure from top to bottom. -- Horizontial aluminum side pressure walls offer a non-marking smooth durable surface. -- Fast, easy changeovers with minimal adjusting. -- Vertical clamping carriage slides smoothly for horizontial width adjustments. -- (5) Sets of pressure shoes for added strength also eliminates vertical (drawer depth) adjustments. -- Includes: (1) Set of aluminum side plates, (1) lever valve pressure hold kit.

JLT 190B-M3 Drawer Clamp. Heavy-duty Drawer and Box clamp, maximum capacity 10" H x 24" L x 36" W Specifications & Features: -- Achieve 3,000 Lbs. clamping force at 100 PSI air pressure. -- Easy to use mounted lever valve with intergraded pressure hold kit. -- Pneumatic foot pedal activation. -- 2- Clamp Design provides equal pressure from top to bottom. -- Horizontal aluminum side pressure walls offer a non-marking smooth durable surface. -- Fast, easy changeovers with minimal adjusting. -- The vertical clamping carriage slides smoothly for horizontal width adjustments.Complete with: -- (3) Sets of pressure shoes for added strength also eliminate vertical (drawer depth) adjustments. -- (1) Set of aluminum side plates. -- (1) Lever valve pressure hold kit.

JLT CLAMPS 79F-16-PC Panel and Door Clamp. This Clamp for the Custom Woodworker who produces 16' Railing, Long Posts and Face Glue Solid Wood Components up to 6" thick. -- (3) Levels of 16' long x 52"wide x 70" high -- Heavy tubular frame with (36) # 302-40-H-R 3.5" high Jaw 40" Taylor Clamps. Made of solid steel and are manually tightened with a JLT "T" handle. -- Manually adjustable bar clamps that easily set in place and move from side-to-side. -- Heavy Duty Construction with 5000 Lbs. capacity. Great for the big jobs. -- Clamps are aligned perfectly for a straight and precise clamp face. -- 6" High rocker adapter Plates offer consistent clamping pressure throughout the glue joint. -- -- JLT heavy duty clamps offer up to 3000 Lbs of clamping pressure. -- JLT Clamps are guaranteed Never to twist, bow or bend! -- Clamping System Package Includes: (1) #79F-16-PC 16' long multi-level panel clamp. -- (36) #302-40-H-R 3.5" High jaw 40"opening Taylor Clamps. -- (72) #80-1706 Gocker adapter plates for up to 6" thick glue ups. -- (1) Fastener and shim kit for precise clamp alignment.

JLT CLAMPS 160B-M3 Glue ApplicatorThe Door Stile spreader compliments the JLT Door Clamp for providing a quick simple method of applying glue to cabinet door stiles. -- Foot pedal operation. -- Includes: (2) Pre-cut profiles and UHMW material to produce up to 12 more profiles. -- Virtually no clean up (end of the day spray with water form the provided spray bottle and cover). Minimize potential for squeeze out. Final set up dimensions: 16"; L x 16" W x 38"; H

JLT 190B-M3-48 Drawer Clamp. Heavy-duty Drawer and Box clamp, maximum capacity 12" H x 24" L x 48" W -- Achieve 3,000 Lbs. clamping force at 100 PSI air pressure. -- Easy to use mounted lever valve with intergraded pressure hold kit. -- Pneumatic foot pedal activation. -- (2) Clamp Design provides equal pressure from top to bottom. -- Horizontal aluminum side pressure walls offer a non-marking smooth durable surface. -- Fast, easy changeovers with minimal adjusting. -- Vertical clamping carriage slides smoothly for horizontal width adjustments. -- (3) Sets of pressure shoes for added strength also eliminates vertical (drawer depth) adjustments. -- (1) Set of aluminum side plates. -- (1) Lever valve pressure hold kit.

JLT 720A-8W Face Frame Assembly Table. The JLT CLAMPS Face Frame Assembly System simplifies the assembling process. -- This is to ensure flush alignment of frames regardless of thickness of material. -- Major face sanding is eliminated. -- Total 1"; thick, 5' x 8' clamping surface featuring a high quality UHMW top layer for a flat, sturdy and easy to clean surface. -- Innovative vertical pressure over arm with (5) hold down clamps and squaring bar. (Replaces #78G-5-8)

JLT 720A-12W Face Frame Assembly Table. The JLT CLAMPS Face Frame Assembly System simplifies the assembling process. -- This is to ensure flush alignment of frames regardless of thickness of material. -- Major face sanding is eliminated. -- Total 1"; thick, 5' x 12' clamping surface featuring a high quality UHMW top layer for a flat, sturdy and easy to clean surface. -- Innovative vertical pressure over arm with (5) hold down clamps and (2) squaring bars.(Replaces P/N 78G-5-12)

JLT - 79K-10: Entry Panel & Door ClampVersatility: Leave the center squaring bar to do multiple doors at once or remove the bar to take advantage of the full capacity of the machine. -- Capacity for solid wood doors: 48" x 120". -- Quick release latches on the jaws; moveable squaring bar. -- Squaring mechanism can be recalibrated, if necessary. -- (2) Horizontal pneumatic clamps. -- (4) Vertical pneumatic clamps. -- 1-Lever operation. -- 1,000 Lbs Clamping force per cylinder. -- 3" Stroke from each cylinder.

JLT CLAMPS 718A-M2-12-M Panel and Door ClampBuddy System includes #79F-12-PC & #717CUnique all-in-one Panel Clamp & Cabinet Door Clamp. -- The DDC has a larger clamping area of 38" Deep x 98" Wide with a splitter for two (2) door clamping. -- Double door design, air operated assembly clamp specifically designed for entry doors, cabinet doors or windows. -- (2) Heavy Duty quick adjusting pneumatic clamping cylinders & (1) quick adjusting cross-clamp on the side. -- (1) Quick adjusting cross-clamp for the rails with (3) draw clamps for the stiles. -- 2" Deep squaring fence along left and bottom sides. -- Single-lever cylinders for quick & accurate clamping pressure. -- Shelf area to hold the pieces of the frame prior to clamping for all squaring components. -- 5-Tier self-supporting rack unit; each tier is 12' wide; total of (18) clamps on the rack. -- 32" or 40" Opening clamps available; must be specified when placing order. -- Clamps with 2-1/2" high jaws and manual movement & tightening. -- Additional clamps are available. -- 40 Sq. ft. footprint.

JLT CLAMPS 79F-M2-8-PC Panel and Door Clamp. An Industry standard for Cabinet doors and so much more. -- (5) Levels of 8' wide x 40" deep cap. -- Heavy tubular frame with (18) clamps. -- Manually adjustable bar clamps that easily set in place and move from side-to-side. -- 40" Clamp opening with a 3-1/2" high x 4" wide jaw. -- Additional opening clamps available.

JLT CLAMPS 79F-M2-6-PC Panel and Door ClampAn Industry standard for Cabinet doors and so much more. -- (5) Levels of 6' wide x 40" deep cap. -- Heavy tubular frame with (8) clamps. -- Manually adjusted bar clamps that easily set in place and move from side-to-side. -- 40" Clamp opening with a 3-1/2" high x 4" wide jaw. -- Additional clamps are available.

JLT 717C-DC Cabinet Door Clamp:Pneumatically operated Cabinet Door Clamp to square & clamp door in (1) Second. -- 26" Front-to-back x 62" left-to-right clamping capacity. -- Single row door clamp with (1) horizontal pneumatic clamp & (2) vertical pneumatic clamps. -- Special mount on a 30° angle for ease of loading & less operator fatigue. -- (3) Large diaphragm cylinders for quick clamping pressure with single lever operation. -- 40 PSI Air pressure to produce 500 Lbs of force on each clamp. -- Shelf to hold the pieces of the frame before pressing on all squaring components. -- 40 Sq. ft. floor space requirement.(Replaces: #717A-DC)
