Woodworking Equipment For Sale

TIMESAVERS 36" SPEEDSANDER WIDE BELT SANDER1-Head; 36" width cap.; combination sanding head with: 4" Dia. contact roll & 1-1/2" wide polishing platen; 7-1/2 HP, 1-phase motor. -- Abrasive belt size: 37" x 60" with: Electronic abrasive belt tracking; 4" max. thickness with: 34" - 38" pass line; rough-top conveyor with: 5 - 20 FPM variable feed via AC Frequency drive. -- Equipped with: Air activated emergency brake; outboard door interlock; infeed emergency stop bar; emergency stop buttons on outfeed. -- Includes: (1) 4" Dust outlet; ProScale digital readout; casters.

TIMESAVERS - 1311-13-1: Single-Head Wide Belt Sander1-Head; 37" cap.; 0 - 5" opening (33" - 38" pass line). -- Combination head with: 4-3/4" Contact roll & 2-1/2" finishing platen; 15 HP motor; 37" x 60" abrasive belt; disc brakes on main motor; centralized control panel. -- Features: Digital thickness readout; double infeed & outfeed holddown rollers; variable feed speed from 20 - 40 FPM; hour meter; main motor load meter/watt meter. -- Includes: Dial indicators on drums/platen; auto setup device; motorized lift; 13" infeed loading area; (4) bed jacks; quick release outboard support; through-beam abrasives belt tracking; infeed stop bar; UL listed controls.NOTE: Extra Sanding belts included.

Timesaver - Series 1300: Wide Belt Sander (3) Heads43" Width cap. drum; drum combination head.Specifications -- Dial indicators on drums/platens. -- 8" Drums. -- 5 1/2" Dia. on combination heads. -- 2-1/2" Width platen on combination head. -- 75" Abrasive belt length. -- 0 - 5" Opening (33 - 38" pass line).Equipped with & Features: -- Disc brakes on main motor. -- 20 - 45 FPM Feed speed A/C. --Auto set-up device. --Motorized lift. -- 14" Infeed loading area. -- Quick release outboard support. -- Through-beam abrasive belt tracking. -- 15" Minimum part length. -- Emergency stops at infeed and outfeed location.

TIMESAVERS - 2321-23-21, ...Planer Sander (2) Heads2-Head; 36" width cap.Specifications: -- 1st Head. 6" Dia. Helical head with: (6) Spirals of 4-sided carbide inserts; 25 HP motor. -- 2nd Head. Combination head with: 5-1/2" Dia. contact roll and 2-1/2" wide finishing platen; 20 HP motor; sanding head with 37" x 75" Abrasive belt with "POSI-TRAK" electronic tracking. -- Dial indicators for height adjustments. -- Conveyor belt feed with Variable feed speed 20 - 45 FPM; automatic conveyor belt tracking. -- Anti-kickback fingers on infeed; planer head with sectional infeed shoe and double hold-down rolls on outfeed; double infeed and outfeed rubber-covered hold-down rolls on the sanding head. -- Motorized part thickness adjustment: 0" - 5" With mechanical digital readout. -- Minimum part length: 15"; pass line height: 33"-38". Complete with: -- Controls mounted on belt loading side; air activated caliper disc brakes on all heads; load meters for each head; 14" infeed loading area. -- Dust extraction: 3,500 CFM; compressed air usage: 3 CFM @ 90 PSI. -- Total load amps at 230 Volts - 145 Amps.

Unused machine - never put into service! Manufacturer specifications: Timesavers Wood Distressing Sander Adjustable brush heads Dial indicators on each head 24" width Brushes powered by 7.5 hp motor 33" - 38" variable passline 9.5" diameter brush head Double infeed and outfeed hold-down rolls Go to device Infeed stop bar Main motor lead meters Oscillation on brush VFD on each head. 2 heads (16 gauge crimp and nylon abrasive impregnated 80 grit) 15-45 FPM speed 200-12200 rpm abrasive brush CW/CCW 0-5" thickness machine opening 25" maximum width 62 FLA (full load amps) 3,100 CFM dust collection flow 2 CFM air supply flow 3/60/230 volt The Distresser is a top-of-the-line machine that can distress material such as; flooring, furniture parts, signage, cabinets, millwork, solid wood panels, veneer panels, old barn wood, and many other types of material. It can run cabinet doors, face frames, moulding, trim, solid wood, veneer panels, flooring, and more.

Timesavers 37" Planer Sander Helical Planer Head

TIMESAVERS 43- 3 OB Orbital Sander3-Head, 43" width cap. with (2) Orbital heads and (1) finishing brush. -- 1st & 2nd Orbital Heads: Each orbital head with (1) 10" wide platen for a total of (2) platens, each platen features a "dual action" head with a high-speed orbit and combined back-and-forth oscillation to remove abrasive belt cross-grain scratches. -- "Quick change" system for abrasive material, (2) 7.5 HP main orbit motors, and 1 HP oscillation motor. 3rd Head: Rotary abrasive brush with 2 HP motor, single side brush wear/height adjustment. -- Conveyor belt feed with Ruff-Tex conveyor belt, variable feed speed from 5 - 20 FPM, infeed & outfeed holddown pinch rollers on all heads. -- 0" - 6" Motorized part thickness opening, constant pass line-height of conveyor bed assembly, extended infeed load area, motor load meters on sanding heads. -- Includes a DOUCET Return Conveyor System -- New transformer for 230 or 460 Volt, specifically for this machine is available at an additional cost

TIMESAVERS BM24-2 Wood Brush Sander. One 24" sanding brush is followed by a second brush for finish or sealer sanding. -- Includes MASTER SAND (1) set of hubs and hard nylon brushes. -- Drives: 7.5 HP Variable Speed Drives on each head. 1 HP Variable Mechanical feed drive. Feed speed is adjustable from 10 - 40 FPM. -- Features: Spring-Loaded holddown rolls that can feed min. 12" long parts. Rough-top conveyor belt. (2) dust outlet connections at 4" dia. requiring about 450 CFM each.Other Specifications: -- Sanding wheel diameters: 11" rotating at 200 - 1,200 RPM. -- Feed/Passline height variable: 29 - 34.5" -- Maximum workpiece width: 24". -- Maximum workpiece height: 5.5". Minimum thickness: 0.200" -- Dust collection required: 900 CFM. -- Machine dimensions/Weight: 58" Long, 48" wide, 52" high. 925 Lbs. -- Electrical Load: 21 Amps @ 460/3/60.

TIMESAVERS 52-20 ORBITAL SANDER2-Head, 52" width cap. with (2) Orbital heads.Specifications: 1st & 2nd Orbital Heads: Each orbital head with (2) 5" wide platens, each platen features a "dual action" head with a high-speed orbit and combined back-and-forth oscillation to remove abrasive belt cross-grain scratches. -- 1st Head: 7.5 HP 230/460V 3PH motor -- 2nd Head: Oscillating platen 7.5HP, 330/460V, 3Ph"Quick change" system for abrasive material -- Conveyor belt feed with Ruff-Tex conveyor belt, variable hydraulic feed speed from 5 - 20 FPM, vacuum bed assembly, infeed & outfeed holddown pinch rollers on all heads. -- 0" - 6" Motorized part thickness opening with mechanical digital readout, constant pass line of conveyor feed bed assembly, motor load meters on sanding heads -- Push button controlsNOTE: Feed Motor and Feed Belt have been taken apart for shippingThe above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify.

TIMESAVERS 2331-04-334 DUAL HEAD DENIBBING SANDER2-Head, 42" width capacity Sanding / Denibbing system. -- (2) 5" Wide platens featuring a "dual" action head with a high-speed orbital movement and combined back & forth oscillation to remove abrasive belt cross-grain scratches; platens designed with a quick change system for abrasive material. -- (1) Nylon abrasive impregnated (150 grit) Cleaning / De-Nibbing brush, 10" dia., drive unit for brush rotation, brush wear adjustment via jack screws. -- Vacuum holddown conveyor system with variable feed speed 5 - 15 FPM. -- Double infeed and outfeed holddown pinch rollers. -- Power raising and lowering of the conveyor bed with AUTO-SET feature, 0" to 6" part thickness capacity. (4) DUFF-NORTON acme screw jacks under conveyor bed, 36" infeed conveyor area.....below in the comments see what the current owner says:

Reconditioned Torit 156RF10 baghouse

Dust Collection System

TORREDA HIDROPAL-1400 COPY LATHE

TORREDA TORMADEX S.A. PA-1200 Hydraulic Wood Turning Back Knife Lathe:Nicely equipped Spanish lathe with dual hydraulic tracers for making quick work of all your demanding woodturning production runs! ... Great for turning baseball bats!Specifications: -- 47" Max. between centers, 9-7/8" max. dia. without traveling steady. -- 3-1/3" Max. dia. through steady rest (larger dia. of 6.2" cap. OPTIONAL); -- High speed automatic loading, feeder accepts pieces up to 4" square. -- 4 HP Motor with (4) turning speeds, 1,200, 2,800, 3,500, and 4,550 RPM. -- (2) HIDRO "T-75" hydraulic reproducing heads with 3" stroke. -- (2) Top mounted hydraulic knives for tenon or pattern cutting (accepts form tools up to 3" wide). -- 2 HP Hydraulic pump motor with (3) carriage feed speeds. -- Features: Pressure sensitive Hydraulic tailstock with Pressure Regulating Valve needed for small, slender turnings to avoid buckling. Pre-rounding tool in front of travelling steady rest. -- Includes: Safety guard, tooling with several roughing and finishing knives.

Tri State Machinery Straight Line Rip Saw S/N 4.5.74-72

Custom Ceiling / Flooring Table Table Size: 32' x 6'9" to 14'3" Table Operated by Both Push Button and Key Fob Controls Floor can be built manually on the table Clamping Stud Locators at 16" & 24"

Twin City Fan Blower Air Lock Can BE Added For Additional Cost

TWIN FLOW Air Make-Up Unit 14,000 CFM. Vertical mount with Remote Control Panel: -- CFM: 14,000 CFM @ 1.75" ESP, 10 HPTEFC motor -- BTU: 1.38 MBTUH -- Burner: MAXON burner -- Temperature Control: 80º F temperature rise in spray cycle -- -- Mounting: Vertical, outdoor/indoor mounted -- Fuel required: Natural gas, 0.3 PSI pressure -- Intake/Discharge: Vertical, screened, air intake with vertical discharge -- Filter Sections: V-Bank style with 1’’ cleanable air intake disposable type filters -- Gas Control: Control cabinet and pre-piped gas combustion system mounted on burner section to FM, Electronic Modulation -- Specifications includes: Digital Temperature Controller, ON/OFF & Summer/Winter Switch, pressure regulator, metering valve, pilot pressure regulator & pilot gas valve, flame rod, high limit switch, air flow switch, power transformer, ignition transformer and spark plug -- Electrical Control cabinet includes: main breaker disconnects, magnetic motor starters with adjustable overload protection for air makeup, motor fuse protection -- Enclosure Design: Framed, with 18 ga. metal walls and 1" insulation -- Note: Available in Horizontal and Vertical mount. Please inquire. -- Also available: Controls option: - Two stages for 14,000 or 7,000 CFM at extra cost of about $3,000.

TWIN FLOW Air Make-Up Unit 7,000 CFM. Vertical mount with Remote Control Panel: -- CFM: 7,000 CFM @ 1.75" ESP, 5HP/575v/3ph/60Hz TEFC motor -- BTU: 0.68 MBTUH -- Burner: MAXON burner -- Temperature Control: 80º F temperature rise in spray cycle -- Mounting: Vertical, outdoor/indoor mounted -- Fuel required: Natural gas, 0.3 PSI pressure -- Intake/Discharge: Vertical, screened, air intake with vertical discharge -- Filter Sections: V-Bank style with 1’’ cleanable air intake disposable type filters -- Gas Control: Control cabinet and pre-piped gas combustion system mounted on burner section to FM, Electronic Modulation -- Specifications includes: Digital Temperature Controller, ON/OFF & Summer/Winter Switch, pressure regulator, metering valve, pilot pressure regulator & pilot gas valve, flame rod, high limit switch, air flow switch, power transformer, ignition transformer and spark plug -- Electrical Control cabinet includes: main breaker disconnects, magnetic motor starters with adjustable overload protection for air makeup, motor fuse protection -- Motor Control: Control cabinet includes: main breaker disconnects, magnetic motor starters with adjustable overload protection for air makeup, motor fuse protection -- Enclosure Design: Framed, with 18 ga. metal walls and 1" insulation -- Note: Available in Horizontal and Vertical mount. Please inquire.

--In Auctions; https://exfactoryauctions.com/Detail/DL-230113/event/A122024$1 - NO RESERVE -- TYLER French-Type Dovetail Machine Equipped with: (2) 14-1/2” x 17” Tables. (2) 2 HP Routing heads for mounting of drawer sides. (1) 2 HP Grooving head for drawer bottom dado, (2) 2-Spindle Vertical boring heads for drawer hardware. (2) Pneumatic hold-down clamps
