46 Results Found for Gang Rip Saw Viewing 1 - 20 of 46 results
STANDARD LISTINGS
CAM-WOOD TRS 150S Frame SawThe CAM-WOOD Frame Saw is engineered and designed to make extremely accurate cuts, cutting products with very tight tolerances up to 0.004" and eliminating sanding before proceeding to the next step in production. The unique thin frame saw design accepts different saw frame and blade combinations and allows multiple saw fence configurations to produce single, double or multiple cuts in a single pass.Specifications: -- 3/4" Min. to 6" max. working width; 1-1/4" min. to 7-3/4" max. working thickness; finished material > 0.1094". -- 0.043" to 0.055" Saw blade thickness; runs up to (22) blades at one time at (450) stroke/Min with a 8-1/4" stroke length; accommodates blades 1.575" wide x 19.685" long. -- Saw blade frame is powered by a 15 HP motor. Feed speeds of 1 to 5 FPM by 1 HP motor. -- Features automatic oil lubrication system requiring 90 PSI air pressure. Cooling system via water and air. -- Minimum kerf multi-blade frame saw designed to maximize production and minimize material loss. -- Machine supplied with PLC controller to allow operator fast, instant set-up changes. -- All controls are centrally located for the operator to easily adjust & control operation. -- Material waste reductions of up to 20% are achievable by use of the thin kerf blades (0.043" ~ 0.055"). -- A special air blast system cools the blade for longer service intervals and removes saw dust from the gullet of the blade to reduce temperature and increase blade life.Note: The rigid saw blades frame is available in different configurations.
Equipment Location:WEST COAST
Jeff Terrill
800-374-5009 ext:349
CAM-WOOD TRS-2120 Heavy Duty Dip Chain Gang RipsawThe TRS-2120 Rip saw is manufactured to precise tolerances, and features the newest designs for operator safety and volume production.Features: -- 50" x 68" Cast Iron frame for perfect stability. -- Straight line caterpillar type feed chain with heavy guides; chain blocks made of special cast iron, heat treated & precision ground pins. -- 70 mm Nickel chrome steel saw arbor with double keyed quick change sleeve. -- Precision fence for absolute accuracy between blade & fence, with precision measuring gauge. -- (3) Sets of anti-kickback fingers, (2) top, (1) bottom. -- Powered rise & fall of the pressure rollers -- Automatic centralized lubrication system, automatic Star-Delta starter (slow speed start), and low voltage controlsSpecifications: -- 6-5/8" Max. thickness; min. length 29"; 13-1/2" usable saw sleeve length; 13-1/2" between outside saws. -- Throat depth (max. distance to the right of the 1st blade is 12") 10" to 20" sawblade dia.; 70mm saw arbor with (2) keyways. -- 75 HP saw arbor motor with belt drive to the 2,600 RPM with powered pressure rollers (rise/fall); 8 to 80 FPM feed speeds via 4 HP feed motor. -- Double anti-kickback fingers mounted at the in-feed side provided maximum safety protection. -- Variable feed speed to match different requirement of material. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- The auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil. -- Precision built saw head assures accuracy for straight line rip saw operations. -- Four bearing spindle mount ensures rigidity & long life. -- (4) Pressure rollers & (2) hold-down plates for precise cutting of large and small work pieces. -- (10) V-Belt ARBOR DRIVE ensures maximum motor output and guarantees heavy duty multiple rip cutting. -- The saw arbor is manufactured form NI-Cr-MO alloy steel for durability, heat treated, precision ground, balanced providing precise cutting performance. -- Adjustable guide rollers make cutting straight for slight radials material. They also secure glue joint on short pieces or long stacks.
Equipment Location:WEST COAST
Jeff Terrill
800-374-5009 ext:349
CAM-WOOD XL 300 Dip Chain Gang Rip Saw: 12" Width cap.; 4-3/4” max. cutting depth; 14” min. stock length;Specifications: -- 70 mm Dia. saw sleeve (one is included) with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0,25 mm (see drawing after the "literature link); with 12” useable cutting width. -- Accepts saw blades from 12” to 14” dia.; arbor is powered by a 50 HP motor driving the spindle at 3,200 RPM. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 30 to 100 FPM; feed chain is 12” wide. -- Table is 30” wide x 62” with 12” between the column and the 1st saw blade. Integrated 6” dia. dust extraction connection.General Description: -- Designed for high quality production line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- Precision fence ensures absolute accuracy between blade & fence, equipped with measuring ruler gauge. -- Double anti-kickback fingers mounted at the infeed side provide maximum safety protection. -- Heavy-duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage.Feed System: -- Variable feed speed enables the machines to meet different requirement of work. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines. Features & Equipped with: -- Precision built saw head ensures accuracy for straight line rip saw operations. -- (4) Bearing spindle assembly ensures rigidity & long life. -- (4) Pressure rollers & (2) hold-down plates for precise cutting of large and small workpieces. -- 10-Piece V-Belt for maximum motor power output and guarantees heavy duty multiple rip cutting. -- The saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground and balanced providing precise cutting performance. -- Adjustable guide rollers make cutting straight or slight radials rip cuts. They also firmly secure lumber to the feed chain for glue joint work on short parts or long lumber. Options when ordered with machine: -- Additional saw sleeve, ...$990 -- Power raise & lower of the holddown system when ordered with the machine, ...$1,500
Equipment Location:WEST COAST
Jeff Terrill
800-374-5009 ext:349
CAM-WOOD MODEL TRS-1200TB SLAT RIPPER - (1)) top & bottom saw or moulder spindles and 2nd bottom rip spindle.FEATURES: -- The machine can plane or shape the wood at two surfaces then rip it. Ideal for shutters, louver slats, yard stick blanks, etc.. -- Special profile hold down & groove table for slat ripping., optional -- Designed to meet the exacting standards required for high quality production line use. -- CAM-WOOD’s Slat Rip Saws are manufactured to precise tolerances, and feature the newest designs for operator safety and volume production. -- All of these features combine to show what a true value these machines are in today’s highly competitive market. -- Precision fence assures absolute accuracy between cutterheads & fence and is equipped with measuring gauge. -- Double anti-kickback fingers mounted at the infeed end of the machine provided maximum safety protection. -- Heavy duty industrial TEFC motor ensures full depth cutting capacity in all materials. -- Ruggedly constructed steel frame for durability and extended machine life. -- The variable speed feed works allows the machine to meet the cutting requirements of different materials. -- Saw head built to precise tolerances assures accuracy for all straight line ripping operations and provides a stellar quality of cut. -- Top & bottom powered pneumatically tensioned feed rolls for precise feeding and cutting. -- Saw arbor is manufactured from alloy steel for dependability and anti-fatigue, heat treated, precision ground and balanced providing precise cutting performance.SPECIFICATIONS: -- 8” Max. Cutting Width -- 5” Max. Cutting Depth -- 10” Min. Workpiece Length -- 4” to 6” Dia. Top Spindle Sawblade Size -- 8” to 12” Dia. Bottom Spindle Sawblade Size -- 6,000 RPM Top & Bottom Moulder Spindle Speed -- 8” Spindle Length -- 40mm Rip Saw Arbor Diameter (with key) -- 10 HP Top Rip Saw Motor -- 15 HP Bottom Rip Saw Motor -- 12 to 60 FPM Feeding Speed (Variable) -- 1/2 HP Feed Roll & Top Head Elevating Motor -- 1/2 HP Rip Saw Arbor Elevating Motor -- 3 HP Feed Motor
Equipment Location:WEST COAST
Jeff Terrill
800-374-5009 ext:349
CANTEK MRS 300 Multi Blade (Gang) Rip Saw: General Description: -- Frame is Cast Iron, all the main parts are enclosed, ensuring protection and perfect stability. -- Straight line caterpillar style feeding with heavy guided chain. Chain blocks are special cast iron with heat treated & precision ground pins. -- Nickel chrome steel Saw Arbor with 70 mm OD – dble. keyed quick removal sleeve.Features & Includes: -- (3) Sets of Anti-Kickback Fingers (2) top, (1) bottom. -- Powered Rise & Fall to the pressure rollers. -- New style round Fence Bar support with quick shift long fence. -- Automatic Centralized lubrication system. -- Automatic Star-Delta Starter (slow speed start) and low voltage controls. -- C.E style European guard & safety features. -- Long fence for control of long material. -- Electrics to 230/460 or 575 Volts, 3-Phase, 60 Cycles.Specifications: -- Max. Working Thickness, 4 5/8” (120 mm) with 15” Blade diameter. -- Min. Length, 20” standard or 12" with short stock attachment. -- Saw Sleeve Usable Length(between outside saws), 12" (305 mm). -- Sawblade Dia., 200 to 350 mm (8” to 14”). -- Saw arbor Sleeve OD (Diameter), 70 mm; Saw arbor diameter, 50 mm. -- Saw arbor vertical adjustment, 3.6” (90 mm).Equipped with: -- 50 HP Saw Motor – Saw Arbor Speed 3,800 RPM. -- Powered Pressure Rollers (Rise/Fall), 1/2 HP motor. -- Feed Speeds 25 - 100 FPM (8 - 39 MPM); Feed Motor with 2 HP drive. -- (2) 6” Dia. Dust Hood. -- Table Size, 30” x 60"; Table Height from floor 33.5".Other Information: -- Net Weight, 4,510 Lbs, Shipping Weight, 5,060 Lbs - Machine Dimensions, 82.68” 59” x 56.5", Shipping dimensions, 71” x 67” x 63”. -- Included: (1) Removable saw sleeve, (1) Set of (38) spacers; NOTE: Saw blades not included.Optional Extras: -- Short Stock & Thin material cutting attachment, 12" (300 mm) min. length & 3.75" (95 mm) max. thickness (can be added and/or used at any time), required for high accuracy cutting, ...$ 595. -- 20MW Laser (FP MLC1320W) & Laser Holder with 6” Bolt on Base Stand, ...$ 595.00. -- Single Blade Mechanical Quick Lock Collars that can be used on the 70 mm sleeve for individual blade quick setting and locking process (no spacers required) – This is desirable especially if you have to quick change from size to size and you don’t have the spacers to run a special size of product, (each) ...$ 180. -- Spare saw sleeve ...$ 370 -- Set (38) of spacing collars ...$ 390. -- 75 KVA Auto Transformer for 230 Volt operation, On request.
Equipment Location:PACIFIC NORTHWEST
Jeff Terrill
800-374-5009 ext:349
CANTEK MR-320 Multiple Rip Saw -- 12-1/2" Width cap. x 1/8" to 5-1/8" cutting depth, -- 50 HP - 3,840 RPM belt driven nickel chrome steel arbor accepts 10" - 16" dia. saw blades x 70 mm bore 55 mm saw sleeve bore, -- 55 mm saw spindle double keyed with (2) 20 mm wide keyways for quick sleeve removal; -- Depth of cut adjustment with 1/4 HP motor for power raise and lower for thickness adjustment, 30" throat depth from outside of blade to support post, 15" min. stock length standard; max. 30" max. width capacity.. -- 3 HP Variable frequency feed motor with feed speeds from 30 to 120 FPM. -- 13-3/16" wide feed track of cast iron blocks and heat treated chain and race with precision ground chain pins, automatic chain lubrication with low oil shutdown; automatic centralized lubrication system, 75" x 36" table. Equipped with: -- (2) Upper infeed and (2) upper outfeed pneumatic loaded rollers at 3" in dia.; (3) sets of anti-kickback fingers, (2) 6" DIA. dust hoods, adjustable infeed fence with new style fence support bar.
Equipment Location:EASTERN CDN
Jeff Terrill
800-374-5009 ext:349
COSMEC SM120 DIP CHAIN RIP SAW 11-7/8" Arbor cap., 40 HP arbor motor,Specifications: --3-1/2" max. cutting height, 23" min. board length; 50 mm dia. --3,700 RPM arbor --10" min. to 13-3/4" max. blade dia. -- 12-5/8" Wide feed chain --2-speed feed motor with 0.8 HP & 1.2 HP & inverter controlled variable feed speed for each motor --Speed range of 13 - 40 FPM and 26 - 80 FPM --1 HP motorized opening of the pressure roller assembly. -- Complete with: (4) Rows of anti-kickback fingers --Automatic chain lubrication, "quick adjust" infeed fence --Motor load meter, emergency stop button, and magnetic starter with overload protection. --Note: Model number has to be varified
Equipment Location:PACIFIC NORTHWEST
Jeff Terrill
800-374-5009 ext:349
Machine Number: 1001 Machine Type: Rip Saw / Gang Manufacturer: Diehl Model #: 990 Year: 1958 Location: South East Diehl 990 Gangrip Saw 75 HP - 3600 RPM arbor motor-AB size 4 starter-110 volt controls 12 " arbor width with 3-1/2" maximum thickness 8 roll feed - 4 top (powered) - 4 bottom Anti-kick back fingers : top and bottom One (1) saw cartridge-2 3/4 " saw blade bore New arbor bearings 5 HP feed: single speed Rip fence Outboard bearing on arbor 3" throat capacity to 1st saw blade Cleaned, painted and checked Serial # : 54174
Equipment Location:Blowing Rock, NC
Carolina Used Machinery
828-773-2204
3-Moveable Blades Infeed system: Driven sequence deck, motorized servo fence, powered infeed rolls, 5-stage infeed stabilizing arms, laser blade positioning Automatic optimization from cut list
Equipment Location:NC
Carolina Machinery Sales, Inc
704-288-1904
0.6" TO 63" width x 0.4 to 2" thickness capacity. With 1 HP raise/lower motor, 15 HP feed motor (larger avail.) with speeds from 20 to 200 FPM, 3.15 (80 mm) spindle dia. at 3,200 RPM powered by 100 HP motor. -- High precision spindle assembly with hydro-Loc bearing at outboard end; slides out of machine for quick and accurate saw setting. -- Frame is stress relieved; sound & safety enclosure with internal lighting; infeed table hardened and chremed. -- Variable pressure to top feed rolls; feed roll drive by Cardan shaft drive with heavy duty gearboxes; (8) sets powered top and (6) sets bottom powered and full width rolls powered by heavy duty 15 HP variable frequency drive. Arbor motor with Wye-Delta low amp starters. -- Complete with: 1 arbor and 1 cart, (8) 6" (150 mm) dust hoods, (4) top and (4) bottom, documention includes maintenance manuals, operator's manual, electrical schematics, and detailed parts list.
Equipment Location:PACIFIC NORTHWEST
Jeff Terrill
800-374-5009 ext:349
.6" TO 51" width x .4 to 4" thickness capacity. With 1 HP raise/lower motor, 7.5 HP feed motor (larger avail.) with speeds from 20 to 50 FPM (100 or 200 FPM optional), 3.15 (80mm) spindle dia. at 3,200 RPM powered by 75 HP motor. Spindle with hydro-Loc bearing at outboard end; slides out of machine for quick and accurate saw setting. -- Frame is stress relieved; sound & safety enclosure with internal lighting; infeed table hardened and chromed. -- Variable pressure to top feed rolls; feed roll drive by Cardan shaft drive with heavy duty gearboxes; (8) sets powered top and (6) sets bottom powered and full width rolls powered by heavy duty variable frequency drive. Arbor motor with Wye-Delta low amp starters. Complete with (8) 6" (150) mm dust hoods, (4) top and (4) bottom, documentation includes maintenance manuals, operator's manual, electrical schematics, and detailed parts list. -- Available as optional equipment: -- 100 HP arbor motor, 100 FPM top speed. -- Call Jeff Terrill @ Ext 349 for pricing
Equipment Location:PACIFIC NORTHWEST
Jeff Terrill
800-374-5009 ext:349
Model 424 DC 75 HP Motor 3 HP Variable Speed Motor from 50 to 150 FPM Mereen Johnson Posi-Feed Manual Raise/Lower 24" Arbor 14" Max Diameter Blades Optional items available: Rooftop conveyor: 65' Long x 12' wide, 6-strand, separated in middle for easy shipping Rip Saw Outfeed Conveyor with Pinch Roll: 24" Wide x 15' Long Roll Case Conveyor: 55' Long x 5' Wide, heavy duty Lasers with Stand: Includes Pinchroll This machine is still under power and available for inspection.
Equipment Location:NC
Carolina Machinery Sales, Inc
704-288-1904
2004 Cameron Auto Opti-Rip Infeed Model: 34F-M1 Serial: OR164 100% Servo (only Servo is this Cameron) Full amp load 81 44" W bed Up to 20 saws can be run on the arbor No moving blades BUT there are moving lasers Although this one has been pulled from service, they have an identical one still running and available for inspection....
Equipment Location:WI
Carolina Machinery Sales, Inc
704-288-1904
50 HP Motor 12" Width Capacity 6" Throat Variable Speed: 30 - 150 FPM This machine has a broken arbor. A new one will need to be purchased through MJ or machined.
Equipment Location:AL
Carolina Machinery Sales, Inc
704-288-1904
MEREEN-JOHNSON MODEL 424 DIPCHAIN GANG RIPSAW -- 24" Arbor width cap., 14" max. dia. tooling, 3-1/2" max. motorized thickness adjustment, 29" min. length for glue joint accuracy and 22" min. for busting only, 6" throat. -- Equipped with: 75 HP - 3,600 RPM TEFC direct drive motor, arbor with disc brake & load meter, arbor lockout on access door. -- Feed & chain: 5 HP Variable feed speed 30 - 170 FPM with adjustable jam protection, M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, "Quad Life" hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, automatic chain oiler with low level shutoff. -- Complete with: (4) 3" dia. air loaded overhead pressure rolls; full width spring loaded overhead bed plate, pressure rolls & bed plate unit with powered adjustment; with scale & pointer for thickness reference; anti-kickback finger system with (1) lower & (2) upper on infeed, (1) upper assembly on outfeed. -- Includes (1) Saw Sleeve and spacer set
Equipment Location:MID ATLANTIC
Jeff Terrill
800-374-5009 ext:349
MEREEN-JOHNSON MODEL 424 DIPCHAIN GANG RIPSAW -- 24" Arbor width cap., 14" max. dia. tooling, 3-1/2" max. motorized thickness adjustment, 29" min. length for glue joint accuracy and 22" min. for busting only, 6" throat. -- Equipped with: 75 HP - 3,600 RPM TEFC direct drive motor, arbor with disc brake & load meter, arbor lockout on access door. -- Feed & chain: 5 HP Variable feed speed 30 - 170 FPM with adjustable jam protection, M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, "Quad Life" hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, automatic chain oiler with low level shutoff. -- Complete with: (4) 3" dia. air loaded overhead pressure rolls; full width spring loaded overhead bed plate, pressure rolls & bed plate unit with powered adjustment; with scale & pointer for thickness reference; anti-kickback finger system with (1) lower & (2) upper on infeed, (1) upper assembly on outfeed. -- Includes (1) Saw Sleeve and spacer set.
Equipment Location:MIDWEST
Jeff Terrill
800-374-5009 ext:349
MEREEN-JOHNSON 424 Gang Ripsaw24" Arbor width cap., 14" max. dia. tooling,Specifications: -- 3-1/2" max. motorized thickness adjustment, 29" min. length for glue joint accuracy and 22" min. for busting only, 6" throat. -- Equipped with: 75 HP - 3,600 RPM TEFC direct drive motor, arbor with disc brake & load meter, arbor lockout on access door. -- Feed & chain: 5 HP Variable feed speed 30 - 170 FPM with adjustable jam protection, M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, "Quad Life" hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, automatic chain oiler with low level shutoff. Complete with: -- (4) 3" Dia. air loaded overhead pressure rolls; full width spring loaded overhead bed plate, pressure rolls & bed plate unit with powered adjustment; with scale & pointer for thickness reference; -- Anti-kickback finger system with (1) lower & (2) upper on infeed, (1) upper assembly on outfeed. -- Includes Saw Sleeve and spacer set
Equipment Location:WEST COAST
Jeff Terrill
800-374-5009 ext:349
MEREEN-JOHNSON 312DC Dip Chain Gang Ripsaw;12" Arbor cap., 14" max. dia. tooling, 3-1/2" max. thickness, 30" min. length for glue joint accuracy and 22" min. for busting only, 6" throat.Specifications: -- 50 HP - 3,600 RPM TEFC Direct drive motor -- Arbor with disc brake and load meter -- Arbor lockout on access door. -- 3 HP Variable feed speed 30 to 150 FPM with adjustable jam protection -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened Double-V chain, "Quad Life" hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips -- Automatic chain oiler with low level shutoff.Equipped with & Features --( 4) 3" Dia. air loaded overhead pressure rolls; full width segmented maple, spring loaded overhead bed plate --Pressure rolls and bed plate unit adjust with scale & pointer thickness reference anti-kickback finger system with (1) lower & (2) upper on infeed, (1) upper assembly on outfeed. -- (2) Upper dust hoods (1) 8" & (1) 5" dia. and (1) lower 4" dia. hood, requires 2,870 CFM; -- (1) 12" saw sleeve with an assortment of spacers, 3-1/8" bore. -- Laser Light (with 4 lights).
Equipment Location:MIDWEST
Jeff Terrill
800-374-5009 ext:349
MEREEN-JOHNSON 419 DIP CHAIN GANG RIPSAW with the following features and specifications:19" Arbor cap., 14" max. dia. tooling, 3-1/2" max. manual thickness adjustment, 29" min. length for glue joint accuracy and 22" min. for busting only, 6" throat.Equipped with: -- 75 HP - 3,600 RPM drive motor with direct drive to arbor. -- Feed & chain: 3 HP Variable feed speed 30 to 150 FPM, M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain. Hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, and chain oiler. Complete with: (4) 3" Dia. spring loaded overhead pressure rolls (with new springs); -- Full width spring loaded overhead bed plate, pressure rolls and bed plate unit with scale & pointer thickness reference; -- Anti-kickback finger system with (1) lower & (2) upper on infeed (kickback fingers are newly replaced). -- Includes: (2) Upper dust hoods (1) 10" & (1) 5" dia., and (1) lower 4" dia. hood; requires 3,820 CFM; -- INCLUDES: (2) saw sleeves with spacers, approximately (15) carbide sawblades, sleeve setup stand, spare set of rubber inserts.
Equipment Location:MIDWEST
Jeff Terrill
800-374-5009 ext:349
NEVA ORBIT Thin Cutting Frame Saw: - TOTAL RUN TIME, 1,068 HOURS!!! -- Features & Benefits: -- For cutting solid wood blocks into glueable slats with a minimum of saw kerf waste. -- ORBIT uses an up/down method of movement for cutting veneer slats; unlike conventional Frame Saws that move up & down in a reciprocating lineal motion, ORBIT uses a swing-out motion at the bottom of the saw stroke. -- During the downstroke of the saw frame, the cutting motion is perfectly linear; at the bottom of the stroke, the saw frame swings out of the cut in the same direction as the wood is moving. -- Once the saw frame has retracted out of the cut, the frame travels back to the top, remaining out of contact with the wood during the entire upward motion. The saw frame then again begins its linear downward cutting motion. -- This unique movement has several distinct advantages of the frame movements over the conventional frame saws. In a conventional frame saw, a great deal of heat is generated by sawdust that is captured/packed into and around the saw blade teeth. -- This occurs because the sawdust and wood chips are unable to clear out from the blade during the upstroke. This is especially true when cutting high, as some of the teeth in the center of the saw blades never clear out of the cut. -- Because the Orbit saw frame moves out of the cut during the upstroke, wood chips and sawdust falls clear from the saw blade resulting in less heat buildup on the saw blade, longer saw blade life, dust-free slats, and the ability to use a thinner kerf saw blade. --Technical Data: -- Main Motor is 15 kW (20 HP) -- Feed speed from 0.3 - 1.5 MPM (1 - 4.5 FPM), 210 mm (7/8") strokes of the Saw Frame, (450) strokes/Min. -- Cutting Height: Adjustable from 45 - 200 mm (8" max. height), cutting width with center guide is 2 x 25 mm to 70 mm (2-3/4"); min. block length of 300 mm; min. slat thickness of 2.5 mm (depending on cutting height). -- Cutting Accuracy: Approx. +/-0.2 mm; saw kerf is 1.25 at 4" or less 1.35 at 4" or more; saw blade LIFE-STELLITE Saws with approx. (10 - 60 Hrs). -- Dust Hood dia: 120 mm top x 160 mm bottom; machine dimensions are 2,600 mm L x 800 mm W x 1,700 mm H 102" x 31-1/2" x 67"); approx. machine Weight of 3,300 kG or 7,000 Lbs. -- Comes with: (2) sets of 10" frames and (1) frames for 12" material; (1) precision torque wrench (200 Nm); adjustable chip breakers; (1) air blast system. -- Includes: Automatic opening of the machine for frame removal, automatic central lubricating system, automatic raise & lower of the feed rollers, top & bottom driven feed rollers, and digital feed speed indicator.
Equipment Location:SOUTHEAST
Jeff Terrill
800-374-5009 ext:349
