Boring Machines For Sale

HOMAG CENTATEQ T-700/PROFI (BOF 712/32/18/A) TWIN POD SHUTTLE TABLE MACHINE (W/ATC/BORING): -- Specifications Twin Pod Shuttle Table, Bridge Gantry machine with: NC Controlled, User-Friendly support rails & vacuum pods. -- Working Area:"X" Axis is 126" (3,200 mm, "Y" axis 72" (1,828 mm), "Z" axis stroke Routing is 12.8" (325 mm), "Z" axis stroke Boring is 7.3" (185 mm) max. material thickness of 4" (100 mm). -- Positioning Speed"X" & "Y" Axes 426 FPM (130 MPM); "Z" axis is 66 FPM (20 MPM); machine head travels on THK linear motion guides on all axes. -- Worktable x 2Twin Pod Table "Bridge Gantry" machine with: NC Controlled, User-Friendly support rails & vacuum pods, with electronic surveillance of all vacuum rails/pods/stops.(2) Independent 10.5' x 6' working areas, for Pendulum processing during loading & offloading of the materials being processed. -- Boring Unit x 2(1) 3 HP (2.3 kW) Motor; variable speed from 1,500 - 7,500 RPM; (21) independent "Quick Change" vertical spindles; (13) in "X" axis & (8) in "Y" axis.10-Horizontal Spindles; (3+3 in X axis & ( 2+2) in Y axis. (1) 100 mm X-Axis Saw slot. -- Machining x 2(1) 20 HP (15 kW) Air-Cooled, high-speed constant duty Router with HSK F63 adaptor & tool length "touch off" probe.Programmable speed from 1,250 - 24,000 RPM; constant torque achieved at 9,000 RPM, RH or LH rotation.Router is powered by a 14 kW frequency inverter; integrated air jet blow off located in the extraction hood.(1) 10-Position ATC plate mounted at the back of the machine. -- Operator Interface:PC87 Front-End with: "Power Control with PowerTouch2" + Windows© 10 + woodWOP7 Operating System.21" TFT Color graphic touchscreen for data entry; PC 85T hand control pendant; INTEL Core 2 Duo Processor; 1 SATA 160 GB hard disk CD R/W drives.Ethernet Connection 10/100 MBIT RJ45 (without switch) for LAN connection to office PC; USB ports & central USB connection at the operating panel.BECKHOFF Programmable logic control for (3/4) axes; linear, circular & helical interpolation.The machine control is contained on a separate freestanding console that can be placed at either the LH or RH side of the machine. woodWOP can be programmed offline with the same intuitive icon-driven software that the Operator has on the machine controller. -- Shuttle Tables x 2Manual LH & RH facing/loading & automatic shuttle into & out of the working field. Integrated dust/scrap/chip conveyor to clean/remove material form the work/processing area. -- Complete with (2) 100 m³/Hr Vacuum Pump: All zone perimeter Safety System. -- Actual Model is: HOMAG - CENTATEQ T-700/PROFI (BOF 712/32/18/A).This machine is New, NEVER INSTALLED!!

HOMAG BAZ 211 VENTURE 21M Machining Center W "C" Axis -- Maximum Working field: X-Axis 3,225 mm (126.9"), Y-axis 1,500 mm (59"), Z-axis stroke 300 mm (11.8"), max work piece thickness 60 mm (2.4"). -- X-axis travel speed 80 MPM (262 FPM), -- Y-axis travel speed 60 MPM (197 FPM), -- Z-axis 40 MPM (131 FPM), AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. -- Working area: Working tables consist of (6) adjustable support rails, (2) vacuum cups per rail; laser unit to aid in the quick positioning of the vacuum cups. -- Machining unit: (1) 14.75 HP (11 kW) liquid cooled electro-spindle router (1,500 - 18,000 RPM), "HSK F63" quick change tooling; 12-position ATC automatic tool changer, "C" axis for 360ø horizontal processing. -- Drilling Unit: Vertical drilling head with (17) individual vertical spindles, 11-spindles in "X", 7-spindles in "Y", spindles on 32 mm centers. (1) saw blade aggregate, 125 mm dia; (1) 4-spindle lock case horizontal trimming unit aggregate. -- "POWER CONTROL PC 85" Numerical control with: "WOODWOP + BAZ" interface software, "WINDOWS NT"; icon driven with a graphical interface to allow the operator to quickly and efficiently create programs. -- Includes: 144 MB Disk drive, CD ROM drive, 12" color LCD monitor. -- Features: RS-422 Serial & USB connection to PC (up to 300 meters), (2) line adaptors RS-232 & 485.2 with 9-25 pin and card for RS-232 line (cable not included). -- Features: Multitask operating system, input/output modules, axes override, 4-axis interpolation, "WOOD SCOUT" diagnostic graphics aid for programming, machine data & tool management. -- Editor Module for PC with same look and functionality of software on the machine, allows transmission of programs and work lists; Required office PC configuration (not included): Pentium processor, 8 MB RAM, 8 MB hard disk; VGA video card. Complete with: -- ELMO 100 cm/h vacuum pump; perimeter protection cage; user & maintance manuals on CD with wiring diagrams and operation of Numerical Control. -- "C" Axis -- Actual Model is BAZ 211 VENTURE 21M.Riggers are required for tear down and loading

HOMAG DRILLTEQ V-310 CNC Machining Center (Vertical, W/ATC/Boring): -- Specifications:Flexible "Vertical" Machining Center with "ATC" that uses less than 11-meter² of valuable floor space in addition to an innovative panel handling system. -- Working Capacity:Max. workable part size for "X" axis is 120" (3,050 mm), "Y" axis 49.2" (1,250 mm), and max. part thickness 3.1" (80 mm).Min. worktable part size for "X" axis is 7.8" (200 mm), "Y" axis 1.97" (50 mm), min. part thickness of 0.31" (8 mm). Max. workpiece weight 132 LBS (60kg)LH or RH infeed & outfeed. -- Positioning Speed:The V-310 can reach vector speeds of 210 FPM (64 MPM) in "X" & "Y" axis, & 66 FPM (20 MPM) in "Z" axis with total safety, providing an unmatched working capacity. -- Boring unit BHV310:(1) 3 HP (2.3 kW), variable speed from 1,500 - 7,500 RPM motor. Boring Head with (12) independent Vertical spindles, (6) Horizontal spindles with (2+2) in "X" axis & (1) in "Y" axis. (1) "X" / "Y" 90° grooving saw, 125 mm saw blade dia. -- Machining:(1) 13.4 HP (10 kW) Air cooled Electro spindle router with HSK-F63 adaptor, variable speed from 6,000 - 24,000 RPM. (1) 8-position ATC tool rack mounted on the side of the machine base for easy access. -- Operator Interface:HOMAG "powerTouch2" + Windows + WoodWOP operating system; "IntelCore 2 DUO" Processor. 21" TFT Monitor with pop up keyboard display, Industrial keyboard & mouse, Serial ports, USB ports, modem, Ethernet connection. Real-time multitask processing. -- Complete with:Pneumatic part clamping; sound enclosure and safeSCAN safety technology. -- Actual Model is HOMAG DRILLTEQ V-310

Interwood B3223 Boring Machine 23-Spindles Manufacturer Specs (to be confirmed): (2) 1.5kw, 220/380v, 3ph motors (2) banks of (23) drills 32mm drill spacing (8) spring hold downs (2) pneumatic locators 50-1/2 inch x 30 inch table Pneumatic operation / foot pedal

Ironwood BR23 Boring Machine 230V/3PH

J & P MACHINES 6V2HD2GC BORING MACH. (FEED THRU, DRAWER PARTS) -- SpecificationsDrawer part Boring Machine is ideal for small to medium size production: Drills approx. 15 parts/minute; 12" min. working length; 28" max. working length; 2" min. working width; 28" max. working width; hopper loading/belt feeding magazine for automatic (1-man) operation. -- (2) Horizontal boring units with: 5-Spindle drilling chucks on 32 mm centers; ea. with 2 HP - 3,600 RPM motors; (3) vertical boring units with: 5-Spindle drilling chucks on 32 mm centers; ea. with 2 HP - 3,600 RPM motors. -- Drilling heads travel on linear guides with: Manual digital counter adjustments; manual digital counter boring depth adjustment; PLC control for cycle functions of the machine. -- Machine requires 100 PSI Air pressure; dimensions are approx. 55" long x 34" wide x 58" high; weight is approx. 1,300 Lbs.

KOCH BD-A BORING MACH. (FEED THRU CNC): -- Specifications: Model BD-A Boring Machine for straight rail-stock work pieces for Horizontal & Vertical Drilling; Infeed and outfeed pass height is 36.2" (920 mm) . The work pieces are transported through the working stations by means of a cam transport system.Stock is worked in clamped position. -- Stock dimensions: Stock length 9.8" - 59" (250 - 1500 mm), Stock width 1.50" - 9.8" (38 - 250 mm), Stock thickness 0.63" - 1.18" (16 - 30 mm) Note: The specified dimensions do not allow all possible combinations. -- Horizontal drilling station:Each side with (1) drilling unit with 2.7 HP (2 kW) - 3,400 RPM, Each horizontal boring heads with (3) Spindle Type D-1277 boring chucks on 16 mm centers;10 mm dia shank & 70 mm max bit lengthEach head moving on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holesLinear path control for stock transport with low profile machine bed and linear guides, fixed stock stops,Adjustable working stations with motorized width adjustment. -- Vertical Drilling head with rotating device:(2) LH & (2) RH Type D -1277, 2.7 HP (2 kW) Adjustable vertical boring heads with dust extraction hoods & variable speed from 3,000 - 6,000 RPM; Each Drilling chuck with (1) Drilling Spindle per chuck. Drilling Chucks with KOCH "QC" (quick change) system & rotating device each head; 10 mm dia drill bit shank & 70 mm max bit lengthEach head moving on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holesLinear path control for stock transport with low profile machine bed and linear guides, fixed stock stops,Mechanical digital read out for manual finite adjustment, (2) air hold down clamps, foot pedal control to start activation. -- Features:The stationary machine side is on the LH side (seen in transport direction) and not adjustable. The RH is adjustable via NC controlled "X" axis.The machine is equipped with Hopper Feed & has a part stack capacity of approx 9.8" (250 mm) & working capacity of approx 48 Pieces/Min.Stock infeed belts move the workpiece through an intermediate hopper to the stock support. Then the workpiece is transported through the working stations by means of transfer belts with lateral stock alignment; working pass height (36.2" (920 mm).Stock is worked in clamped position; There are stock outfeed belts at the machine outfeed. The workpiece is transferred to the out-feed hopper & removed manually. -- Operator & Machine Control:Beckoff SPS PLC for running the machine. -- Complete With: Open Station to add Dowel Inserting units at a later time ( Dowel units are not included) Manual Hand Pump Central Lubrication system for working units (1) NC controlled positioning of machine RH side (X), LH side is a fixed "0' point. Hopper Rail Feeding devices with capacity of approx 48 Work Pieces/Min. Separate drive for outfeed belt. Center Stock support. -- O

1- 5mm Boring and Inserting Unit with Vibratory Hopper 1-8mm Boring and Inserting Unit with Vibratory Hopper Power: 208v-220v, 3 Phase, 30 Amps 96? Maximum Work Zone 4 zone stops 3-Axis Control For Positioning Weight 6,000lbs Solid One-Piece Welded Tubular Steel Frame Footprint (L x W x H): 135? x 45? x 82? Shipping Dimensions (L x W x H): 42.3? x 49? x 43? Shipping Weight: 7500 lbs

LAGUNA BM23E-2 ... Double Row Line Borer(2) 23-Spindle heads on 32 mm centers, (2) 3 HP motors, drills vertically from bottom.Specifications: -- Distance between first and last spindle 851 mm (33.50"). -- Spacing between zero and max. on the first head 0 - 4". Min. distance between two heads 7.25". Max. boring line spacing to the second head 24". -- 2,800 RPM spindle speed; collets accept 10 mm shank bits. -- Heavy overhead material holddown system with (4) pneumatic material clamps. -- (2) independent air throttles to control the drill-heads upstroke speed.Complete with: -- "Set screw" drill adapters, "quick set" system for depth of drilling. -- Extension fence with (3) flip-stops and foot pedal control.

MAGGI SYSTEM 23 Construction Line BorerConstruction Boring Machine that drills vertically from bottom and horizontally from rear.Specifications: -- 23-Spindle head on 32 mm centers. -- Table size: 38" x 16". -- Max. working width: 25". -- Drilling stroke: 2-1/2". -- Main motor: 2 HP. -- Adjustable drilling depth with patented spiral setting device: ?0 to 2-1/2". -- Tilts pneumatically from lower to rear position with locking points between 0° - 90° for drilling any angle. Equipped with: -- 120" Back fence with: (4) Stops. -- Foot pedal control. -- Magnetic Starter with overload protection. -- (23) Quick-change chucks. -- (2) Patented quick-release pneumatic holddown clamps with independent manual movement. -- Dust outlet: 3".

MAGGI - System 21 Prestige: Construction/Line Borer Adjustable 21-spindle boring head on: 32 mm Centers with position indicator.Specifications -- Stops in 0° & 90° with pneumatic positioning in vertical & horizontal. -- 0" - 2-1/2" Adjustable drilling depth with: Patented setting device. -- (2) Patented material clamps with: Auto setting & safety feature. -- Head height fine adjustment with: Mechanical digital readout. -- 2 HP - 2,800 RPM Motor. -- 34" x 15" Table with: Mechanical digital side fences for mirror image. -- 120" Line Boring fence with: (2) Repeat stops. -- Foot actuated: Pneumatic clamps & drill cycle. -- Equipped with: Magnetic starter; overload protection; (1) set of "quick change" chucks.

MAGGI SYSTEM 46 Double Head Line Boring Machine:Heavy Double Head Line Borer with (2) 23-spindle heads; 32 mm spindle spacing.Specifications: -- Drilling from the bottom up and with 5-1/8" - 25-19/32" distance between rows. -- Drilling vertically from the bottom allows the chips to drop down falling out of the holes. -- Drilling depth of up to 2-1/16" (55 mm) max., takes only seconds to set. -- (2) 2 HP - 3,500 RPM Commercial Duty motors; spindles with steel gears & high quality bearings. -- Easy repetition by (2) air index pins for continuous line drilling, left and right roller track supports extend up to 400 mm (15-3/4") for larger panels.Features and Includes: -- 120" Back fence with (4) repeat "flip" stops; includes 27-3/4" (704 mm) fence for quick positioning of flip stops. -- (6) Pneumatic holddowns to automatically actuate when the drill cycle begins. -- (46) "Quick Change" chucks for easy tool change. -- Magnetic motor controls and 1/4" air regulator with filter and oiler; 100 PSI required air pressure.

MAGGI SYSTEM 21 PRESTIGE Construction & Line BorerAdjustable 21-spindle boring head on 32 mm centers with position indicator.Specifications: -- Stops in 0° and 90° with pneumatic positioning in vertical & horizontal. -- 0" - 2-1/2" Adjustable drilling depth with patented setting device. -- (2) Patented material clamps with auto-setting & safety feature. -- Head height fine adjustment with magnifying glass viewer. -- 2 HP - 2,800 RPM Motor. -- 34" x 15" Table with mechanical digital side fences for mirror-image. -- 120" Line Boring fence with (2) repeat stops. -- Foot actuated pneumatic clamps & drill cycle. -- Magnetic starter, overload protection and (1) set of "quick change" chucks.OPTIONAL: -- 230V Single Phase add $600.00 --29900100 Stop Reference Pin for Line Boring $195.00 -- 26000069 Set of Reference Fences for 45 and 90 degrees $195.00 -- 36000061 Additional Quick Change Bit Adaptor $27.50 ea -- 29971019 Additional Holddown Cylinder Assembly $395.00 ea -- Hinge Boring Head (Specify Blum, Grass, Salice, or Hettich) $695.00 -- TDBSE5705LH or RH 5mm x 57mm LH OR RH Brad Point $9.85 ea -- TDBSE5708LH or RH 8mm x 57mm LH OR RH Brad Point $11.95 ea -- TDBSEHB5735LH or RH 35mm x 57mm LH OR RH Hinge Point $26.80 ea -- FREIGHT TO ANYWHERE IN THE CONTINENTAL USA $ 300.00

MAGGI SYSTEM 35 CONSTRUCTION/LINE BORINGAdjustable 35-spindle boring head on 32 mm centers with position indicator. -- Stops in 0° & 90° with pneumatic positioning in vertical & horizontal. -- 0" - 2-1/2" Adjustable drilling depth with patented setting device. -- (2) Patented material clamps with auto-setting & safety feature. -- Head height fine adjustment with mechanical digital readout. -- 2 HP - 2,800 RPM Motor. -- 45" x 16" Table with mechanical digital side fences for mirror-image. -- 120" Line boring fence with (4) repeat stops & spring loaded repeat pin. -- Foot actuated pneumatic clamps & drill cycle. -- Magnetic starter, overload protection and (1) set of "quick change" chucks. -- Other Accessories also Available!

MAGGI GT 800 CNC MACHINING CENTER: -- SpecificationsFlexible "Vertical/Horizontal" Boring & Grooving Machining Center that can reach movement speeds of: 82 FPM (25 MPM) in "X" & "Y" axis & 49 FPM (15 MPM) in "Z" axis with total safety. -- Working FieldMax. part size for "X" axis is virtually infinite; "Y" axis 31.5" (800 mm); max. part thickness 2" (50 mm). Min. part size for "X" axis is 9.84" (250 mm); "Y" axis 3.93" (100 mm); min. part thickness of 0.39" (10 mm).Panel End/Edge Reader for perfect panel positioning/placement. -- Boring Unit:Suitable for drilling on face & sides of panels including Holes for dowels, hinges, KD fittings, and shelf holes.(1) Boring block with: 3 HP (2.2 kW) - 3,400 RPM Motor; (7) vertical spindles with: (4) Spindles in "X" axis & (3) spindles in "Y" axis.(1) Horizontal spindles with: (1+1) In "X" axis for top & bottom edge boring.Boring Capacity: 0 to 800 mm (31-1/2") with any spindle. -- Operator InterfacePC Front End with: Extremely intuitive user interface with up to (1,000) program storage space; real-time multitask processing.12" TFT "Touchscreen "Monitor; soft touch keypad & industrial mouse; RS-232 Serial ports, USB ports; (1) CD ROM drive. -- Complete with:Pneumatic part clamping roller devices; auto lubrication system; sound enclosure & safety devices. -- Actual Model is MAGGI GT 800

MAGGI - GT 800: CNC Machining Center -- SpecificationsFlexible "vertical/horizontal" Boring & Grooving Machining Center reaches movement speeds of: 82 FPM (25 MPM) in "X" & "Y" Axis & 49 FPM (15 MPM) in "Z" axis with total safety. -- Working FieldMax. part size for "X" axis: Virtually infinite; "Y" axis 31-1/2" (800 mm); max. part thickness 2" (50 mm). Min. part size for "X" axis: 9.84" (250 mm); "Y" Axis: 3.93" (100 mm); min. part thickness: 0.39" (10 mm).Panel End/Edge Reader: Perfect panel positioning/placement. -- Boring UnitSuitable for drilling on face & sides of panels including: Holes for dowels, hinges, KD fittings, and shelf holes.(1) Boring block with: 3 HP (2.2 kW) - 3,400 RPM Motor; (7) vertical spindles with: (4) Spindles in "X" axis & (3) spindles in "Y" axis.(1) Horizontal spindles with: (1 + 1) In "X" axis for top & bottom edge boring.Boring Capacity: 0 - 800 mm (31-1/2") With any spindle. -- Operator InterfacePC Front end with: Extremely intuitive user interface; up to (1,000) program storage space; real-time multitask processing.12" TFT "Touchscreen "Monitor; soft touch keypad & industrial mouse; RS-232 serial ports; USB ports; (1) CD ROM drive. -- Complete with:Pneumatic part clamping roller devices; auto lubrication system; sound enclosure; safety devices. -- Actual Model: MAGGI GT 800

MAGGI - SYSTEM 23: Construction Boring Machine -- Drills vertically from bottom & horizontally from rear; tilts manually from lower to rear position with locking points from 0° - 90° for drilling any angle; table size: 37.375" x 13-1/2". -- Specifications & Features -- (23) Spindle head on: 32 mm Centers; 2 HP - 2,800 motor; 25" max. working width; 2-1/2" drilling stroke; 2 HP motor. -- Complete with: (2) Patented quick release pneumatic holddown clamps with: Auto. setting (move simultaneously for mirror-image); mirror imaging side fences; foot pedal control. -- Accurate positioning of the boring unit to the table; 0 to 2-1/2" adjustable drilling depth with: Patented spiral setting device. -- Features. (2) Patented quick release material clamps with: auto-setting to firmly hold material to table; side fences with mechanical digital readout for quick & accurate setting. -- Equipped with: 120" Back fence with (4) stops; foot actuated pneumatic clamps; drill cycle; magnetic starter with: Overload protection; (23) quick-change chucks; dust outlet: 3". -- Net weight: 630 Lbs; dimensions: 51.7" x 37.8" x 50".

MAGGI SYSTEM 29 CONSTRUCTION/LINE BORERAdjustable 29-spindle boring head on 32 mm centers with position indicator. -- Stops in 0° & 90° with pneumatic positioning in vertical & horizontal. -- 0" - 2-1/2" Adjustable drilling depth with patented setting device. -- (2) Patented material clamps with auto-setting & safety feature. -- Head height fine adjustment with mechanical digital readout. -- 2 HP - 2,800 RPM Motor. -- 45" x 16" Table with mechanical digital side fences for mirror-image. -- 120" Line boring fence with (4) repeat stops & spring loaded repeat pin. -- Foot actuated pneumatic clamps & drill cycle. -- Magnetic starter, overload protection and (1) set of "quick change" chucks. -- Other Accessories also Available!

MAGGI SYSTEM 23 Construction Hole Boring Machine Adjustable 23-spindle boring head on 32 mm centersSpecifications: -- Stops in 0° & 90° with pneumatic positioning in vertical & horizontal. -- 0" - 2-1/2" Adjustable drilling depth with patented setting device. -- (2) Patented material clamps with auto-setting & safety feature. -- Head height fine adjustment with a mechanical digital readout. -- 2 HP - 2,800 RPM Motor. -- 38" x 16" Table with mechanical digital side fences for mirror-image. -- 120" Line Boring fence with (4) repeat stops & spring loaded repeat pin. -- Foot actuated pneumatic clamps & drill cycle. -- Magnetic starter, overload protection and (1) set of "quick change" chucks. -- Dust Outlet: 3".Net weight: 630 Lbs; Dimensions: 51.7" x 37.8" x 50" Tall; Crated Dimensions: 44" x 38" x 42" Tall; Crated Weight: 664 lbs.Available in single phase ... Add $ 600.00

MAGGI - SYSTEM 46: Double Row Line Borer(2) 23-Spindle heads on 32 mm centers; drills from bottom up.Specifications -- (2) 1-1/2 HP - 2,800 RPM motors; 5" min. & 25-19/32" max. working width between heads; 4" drilling stroke; drills vertically from bottom so chips fall out of holes. -- Heavy overhead material holddown system with: (6) Pneumatic material clamps. -- 16" Retractable infeed & outfeed support roller system for long panels. Complete with: -- "Quick Change" drill adapters; patented "quick set" system for depth of drilling. -- 120" Extension fence with: (4) Flip stops; reference pin for continuous line drilling; foot pedal control.
