Gang Saws For Sale

This mighty bull gang edger is ready for work. Cutting 6.25" X 27.5" cuts down to 1/2" boards. This 100 HP single arbor machine has diamond circular saws, Single saw arbor is fixed. Hydraulic feed through with hydraulic top press roll. Infeed table with hydraulic feed roller and fence for accuracy in sawing. This machine is available in a double arbor machine which will cut a little faster than the single. This saw has (2) 50 hp independent arbor motors for the double arbor machine. 931-698-3342

Akkuslar 8" Double Arbor gang Saw. 125hp bottom, 100hp top. New- Never used. Located in GA. #C972

The HCD2M 250 Double Arbor Gang Saw is designed for cutting timbers with a thickness of 9-3/4" and 27-1/2" wide Saw arbors are fixed. Hydraulic feed with knurled rolls top press roll is adjust hydraulically. Cutting rate is 65' per minute. For more information call Jackie Kittrell 931-698-3342 - 931-797-6284

AUTO-V-GROOVE LG-2-SS-FT UNIVERSAL V-GROOVER: -- Specifications:(1) 10 HP - 3,600 RPM V-Grooving head;(1) 10 HP - 3,600 RPM Coving head on opposite side of overhead tool gantry.Both heads are positioned on vertical & horizontal linear rails & bearings for smooth, accurate adjustment. -- Working Cap:Maximum material thickness 1"; 4" min. material width; approx. 12" min. material length; 15" Max. cut from fixed fence; unlimited length of part when cross-grooving. -- Positioning:(1) 2 HP Hydraulic power unit for variable lineal feed rate from 0 - 60 FPM,Extra wide belt feeder moves workpiece on flat phenolic table; raising & lowering of feeder mechanism via manual gear drive. -- Complete with: 100" x 24" Lineal table work surface, 96" Long Cross-Grooving support table set 90° to linear feed direction; Tape applicator; Linear fence, electrical controls. -- Options Include: Auto Transformer for 240/480 v hook-up; ProScale Digital indicator. -- Actual Model is AUTO-V-GROOVE LG-2-SS-FT

AUTO-V-GROOVE AVG-48 MFT UNIVERSAL V-GROOVER: -- Specifications:(1) Head automatic cross & linear V-Groover, 48" max. material width on cross-groove,Unlimited length for linear grooving, 1-1/4" max. material thickness. -- Features:(1) 10 HP - 3,600 RPM Motor, 30 mm dia. belt driven precision cutter arbor, 3-1/4" max. cutter width.2 HP Hydraulic feed motor for infinitely variable crosscut feed speed from 0 - 50 FPM & 0 - 60 FPM for linear feeding.Heavy-duty double belt feeder assembly for linear grooving. -- Includes: Adjustable pneumatic material hold-down bar.(1) 84" x 24" Main table, (1) 20" x 58" auxiliary table, (1) large 96" long floating table on rails. -- Complete with: Automatic tape applicator (12" max. dia. tape roll), manual quick crank tape applicator positioning system. -- Options Include: An assortment of V-Groove cutters as pictured.Actual Model is AUTO-V-GROOVE AVG-48-M/FT.

Brewer 8112 Gang Saw S/N 052391

Brewer Gang Saw Model 1280

Complete Brewer Pallet Line consisting of: Brewer infeed cant deck; Brewer operators cab with controls; electric motor panel with starters; Brewer   bar-type unscrambler and infeed belt conveyor to Brewer cut-off saw with setworks; Brewer out feed belt conveyor to gang saw; Brewer 24" wide gang with motors and sizer; Cornell stacker and West Plains notcher and conveyors to connect stacker and notcher;  and waste conveyor.  Removed from service and ready to load.   Price:  $155,000.00 loaded on your truck.   NOTE: Year-end taxes or machinery investment-- Your Choice.

Denis 948 Gang Saw

Cornell 8" Double Arbor Gang Saw. #C860

Cornell 42" Edger Converted to Gang Saw with 5 Blades and Infeed Roll Case. (no Motor) S/N HE593-7/79

Cornell 620 Single Arbor Gang with Sizer

Cornell 621 Double Arbor Gang Saw with #612 Sizer

Cosmec CM100 12" Dip Chain Gang Saw Parts Machine Only

Potential 9 saw Trimmer on Common Shaft run off 1 Electric Motor

Diehl MR90 Roll Feed Gang Saw

DOUCET ERS-96/RS-75/AP-508 MULTI-BLADE PANEL GROOVE/RIP SAW SYSTEM:Specifications:• The Doucet ERS-96 / RS-75 / AP-508 Automated Panel GROOVE/RIP Saw System is designed to GROOVE and/or RIP panels as well as edge the sides of core materials. Ideal for plywood, OSB, MDF, HDF and other composite panels. This Line was originally designed for Engineered Flooring Blanks.Material Specifications:• 5x5 and 4x8 material to groove and rip for engineering floor core• Incoming panel thickness: ½" to 5/8"• Incoming panel sizes: nominal 5x5 and 4x8• Grooving pattern at every 4" center across the width of panel• Depth and width of grooves estimated at 3/16" kerf width by 1/8" deep• Ripping patter not mentioned• Maximum weight of stack: approx. 5,000 pounds per stackLine Consists of:• Doucet AP-508 Automatic panel feeder with scissor lift to automatically feed panels as needed• Cross Transfer Chain Conveyor to feed panels sideways by the long edge through the Groover• Doucet ERS-96 Panel Groover • Cross Transfer Chain Conveyor to feed panels short end wise through the panel rip saw• Doucet RS-75 Panel Rip Saw• Outfeed Lift Table to automatically stack ripped strips AP-508 Feed system:• (1) Doucet AP-508 Automatic panel feeder with Indexing scissor lift to automatically feed panels as needed.• (1) Cross Transfer Chain Conveyor to feed panels sideways by the long edge through the Groover, max width 96".• (1) Cross Transfer Chain Conveyor to feed panels short end wise through the panel RIPSAW, max. width 60" • (1) Outfeed Lift Table to automatically stack ripped strips. • 5 HP - 1,750 RPM feed motor, variable feed speed up to 75 FPM.• (4) Powered bottom feed rollers & adjustable top idler pressure rolls with positive panel support during grooving operations.• Top & bottom feed rollers have slip resistant urethane covered rollers, feed rollers are chain driven with air tensioning.• Maximum weight of stack: approx. 5,000 LBS.ERS-96 Panel Groover• 40 HP - 3,500 RPM belt driven saw arbor motor,• Material Width 96"; maximum.• Depth of cut 0.25" - 0.75" (6 - 19 mm) maximum.• 3" dia. Arbor shaft with 1.5 HP motor for motorized arbor adjustment for panel thickness. • Saw arbor accessible from above for tool changes. • 5 HP - 1,750 RPM feed motor, feed speed up to 75 FPMRS-75 Panel Ripper:• 20 HP - 3,500 RPM belt driven saw arbor motor;• Material width cap. 60" maximum.• Strip width cap. 2.5" minimum.• Depth of cut 0.25" - 0.75" (6 - 19 mm) maximum.• 3" dia. Arbor shaft with 1.5 HP motor for motorized arbor adjustment for panel thickness. • Saw arbor accessible from above for tool changes. • 5 HP - 1,750 RPM feed motor, feed speed up to 75 FPMOperator Interface: • Doucet OI/HMI Control System for automatic loading & stacking with minimal human intervention other than a forklift operator to bring in new material and remove the processed parts/strips.Complete with:• Dynamic saw arbor brake;• Infeed anti-kickback fingers;• Saw blade safety interlock cover; •12" dia. du

LEADERMAC MODEL LMC-1300M – 51"; GANG RIPSAW -- Specifications: -- Width capacity: 0.6"; to 51"; -- Thickness capacity: 0.4"; to 4"; -- Up & Down motor: 1 HP -- Feed motor: 7-1/2 HP with VFD -- Saw Spindle HP: 75 HP, larger motors are optional - see below -- Saw Spindle diameter: 3.15"; (80mm) double keyed -- Spindle RPM: Std. 4,000 RPM. 5,000 RPM optional with 10"; Blade capacity -- Saw blade Diameter 12"; diameter for 4"; thick material -- Feed speed, Infinitely variable: 20 To 50 FPM. 100 or 200 FPM optional -- Standard Features & Equipment: -- Extra Heavy Main Frame – Stress Relieved -- Sound & Safety enclosure included – with internal strobe-free lighting -- High Precision Spindle - Double Keyed assembly with Hydro-Loc outboard bearing assembly on outboard side -- Entire Spindle assembly slides out on support for Quick, Easy and Precision Saw Setting & Changing -- Hardened & Hard Chromed Infeed Table -- (7) Sets of Top Power Driven Rolls – full width -- (5) Sets Bottom Power Driven Rolls – full width -- Infinitely Variable Pneumatic Pressure to Top Feed Rolls -- Top & Bottom Feed Rolls are all Driven by Cardan Shaft Drive with HD Gearboxes interconnected -- 1st Top & 1st Bottom Powered Roll Combination and then 2 Rows Anti Kick Back Finger Units – Full Width and then to the rest of the Powered Top & Bottom Rolls giving you the best Feeding Capability with good safety Features -- HD VFD – 7.5 HP Feed System – Infinitely Variable -- Main motor has Wye-Delta low amperage soft start -- Electrics are 230, 450 or 575 volts 3/60 with all controls to CSA/UL Specifications -- Documentation: Maintenance manual, Operation manual, Electrical diagrams, Parts list & Tool Box (Electronic Version on Request) -- (4) Top & (4) Bottom 6"; Dust hoods included -- Saws, Dado Heads &/or cutterhead(s) and spacers optional extra -- Price Includes: -- Hanging Control Panel – in lieu of Control standard setup as shown in machine photo -- Moveable Main Electrical Panel with 10 ft. of main cable -- Amp Meter for the Arbor Motor -- 4"; thickness Capacity – using 12"; or 14"; diameter blades Available at extra cost: -- Adjustment of the Rear guide with digital readout from the front of the machine (only desirable if Side Heads are supplied) -- Additional Side Pressure Roller System on the Infeed Table of the Machine -- 100 HP saw spindle motor -- 125 HP saw spindle motor -- 150 HP saw spindle motor -- Scoring Saw Arbor ahead of main saws if desired -- Saw Spacers for Main Arbor quick Setup -- Mechanical Quick Lock Saw collars if desired for independent saw setting -- Spare Spindle Assembly, complete, including Drive Side Bearing Assembly with support slide and roller transfer support assembly per photo for preloaded saws, add $ 13,045 -- Questions? Call Jeff @ Ext 349!

LEADERMAC MODEL LMC-1600M - 63"; GANG RIPSAW Specifications: -- Width capacity: 0.6"; to 63"; -- Thickness capacity: 0.4"; to 2"; (thicker material processing is available as an option) -- Up & down motor: 1 HP -- Feed motor: 15 HP HD VFD -- Feed speed, infinitely variable: 20 - 200 FPM. -- Feed direction from Right to Left is standard -- Saw Spindle HP: 150 HP, Wye-Delta low amperage soft start (larger motors are available as an option) -- Saw Spindle diameter: 3.15"; (80 mm) double keyed -- Saw blade Diameter 12"; diameter for 2"; thick material -- Spindle RPM: Std. 4,000 RPM. 5,000 RPM optional with 10"; Blade capacity Standard Features & Equipment: -- Extra Heavy Main Frame – Stress Relieved -- Sound & Safety enclosure included – with internal strobe-free lighting -- High Precision Spindle - Double Keyed assembly with Hydro-Loc outboard bearing assembly on outboard side -- Entire Spindle assembly slides out on support for Quick, Easy and Precision Saw Setting & Changing -- Hardened & Hard Chromed Infeed Table -- (7) Sets of Top Power Driven Rolls – full width -- (5) Sets Bottom Power Driven Rolls – full width -- Infinitely Variable Pneumatic Pressure to Top Feed Rolls -- Top & Bottom Feed Rolls are all Driven by Cardan Shaft Drive with HD Gearboxes interconnected -- 1st Top & 1st Bottom Powered Roll Combination and then 2 Rows Anti Kick Back Finger Units – Full Width and then to the rest of the Powered Top & Bottom Rolls giving you the best Feeding Capability with good safety Features -- HD VFD – 15 HP Feed System – Infinitely Variable -- Main motor has Wye-Delta low amperage soft start -- Electrics are 460 volts 3/60 with all controls to CSA/UL Specifications -- Documentation: Maintenance manual, Operation manual, Electrical diagrams, Parts list & Tool Box (Electronic Version on Request) -- (8 - 4) Top & (4) Bottom 6"; Dust hoods included -- Saws, Dado Heads &/or cutter head(s) and spacers are optional at extra cost.Price Includes: -- Pedestal for all controls, on a 11 meter long cable to get around the front right (infeed side) of the ripsaw -- Moveable Main Electrical Panel with 10 ft. (3m) of main cable -- 150HP Saw Arbor Spindle motor in lieu of std. 75HP -- Pneumatic hold over on infeed table to hold wide, and allow holding over of narrow boards up to the fence -- Increased Feed Speed to 200FPM (60mpm) includes Heavier gearboxes and drive components) with 15 HP VFD -- Amp Meter for the Arbor Motor -- Faster removal speed for the arbor assembly (50% faster than standard machine) -- 1 Spare complete New Design Spindle Assembly including Drive Side Bearing Assembly with support slide and roller transfer support assembly per photo for preloaded saws Extended length per discussion.(1 only unit included in price of machine, this is for a 2nd cart and spindle assembly- total of (2) will come with the machine – additional units available, see below) -- Schneider / Telemecanique VFD drive uni

LHI 96" x 60" ANGULAR TYPE RIP & CROSS-CUT SYSTEM: Specifications: -- Automatic Angular Rip & Crosscut 5-Position System; max. panel size of 8' (96") long x 5' (60") wide x 1" - 4" thick; 1.25" minimum spacing between the blades; variable feed speed from 0 - 150 FPM. This system will process a unit of material in approx. (7) Min. -- Pos. # 1: LHI Automatic Staging/Infeed/Transfer & Panel Rake Feeding System: 10' (120") Long, powered 3-chain staging conveyor; (2) units can be preloaded while (1) unit is in process. Automatic up-indexing 4,500 Lbs capacity Scissors Lift with auto. rake infeed system: infeed rake system designed with a thin material device that can automatically load material as thin a 1/8". -- Pos. # 2: LHI "72": 72" Arbor length designed for panels up to max. of 5' (60") wide, min. panel length 30"; 40 HP main arbor motor; 1/8" min. - 1" max. material thickness with no adjustment needed over a 3/8" thickness variation. 2-3/4" Dia. arbor with 1-15/16" "Fafnir" arbor bearings; positive non-marking steel contact feed rollers with (optional) poly-covering, driven from top & bottom. Includes: (6) blade collars; (2) 6" dia. vertical dust outlets with an easy access strip separator box. -- Pos. # 3: LHI Cross-Transfer System: Transfer conveyor with panel hold-down & chain drive system to change direction 90° & automatically feed LHI 102". -- Pos. # 4: LHI "102": 102" Arbor length designed for panels up to max. 8' (96") long; 30 HP main arbor motor; 1/8" min. - 1" max. material thickness with no adjustment needed over a 3/8" thickness variation; 2-3/4" dia. arbor with 1-15/16" "Fafnir" arbor bearings. Positive non-marking steel contact feed rollers with (optional) poly-covering, driven from top & bottom. Includes: (6) blade collars; (2) 6" dia vertical dust outlets with an easy access strip separator box. -- Pos. # 5: LHI Stacking & Outfeed Transfer System: Auto. down-indexing 4,500 Lbs cap. Scissor Lift; (4) adjustable alignment posts & (4) bin separators to keep processed stacks square. 98' (96") Long outfeed gravity conveyor.Operating System: -- (1) LHI ALLEN-BRADLEY "Inter-Link" PLC for simple single-operator management of the entire system from (1) central control.NOTE: ...Attached description & pictures are for INFO purposes only; ...a NEW System can be modified to your exact specifications!NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE
