Equipment For Sale

BIESSE ROVER 20 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working field: "X" Axis 113.9" (2,893 mm); "Y" axis 37.4" (950 mm); "Z" axis stroke is 3.9" (100 mm), max. panel thickness 2-1/2" (65 mm). -- Positioning Speed:"X" Axis at 246 FPM (75 MPM); "Y" axis 147 FPM (45 MPM); "Z" axis 49 FPM (15 MPM)."X" Axis moves on high precision prismatic guides and ground helical rack; "Y" & "Z" axis via hardened ground ball screw. -- Worktable:(6) Pneumatically locked & manually positioned panel supports with (2) vacuum cups each.(2) Working zones with: (6) Pneumatic backstops; (2) pneumatic side & (2) center stops; stops raised & lowered automatically by start/stop of machining cycle. -- Boring Unit:(1) 2.3 HP - 5,135 RPM Motor; (10) vertical spindles independently operated with (6) in "X" axis & (4) in "Y" axis.(6) Horizontal spindles: (2 +2) in "X" Axis & (1 + 1) in "Y" axis; 2-1/2" (65 mm) max. boring depth.(1) "X" Axis grooving saw with: 120 mm Dia. blade - 5,200 RPM. -- Machining: Equipped with: (1) 9 HP (6.6 kW) Air-cooled "Quick Change" electro spindle with ISO 30 adaptor.Router is driven by: 10.2 HP (7.5 kW) Inverter for variable speed from 1,000 - 24,000 RPM; RH & LH rotation.(1) 3-Position automatic tool changer mounted at the back of the machine for "on the fly" ATC. -- Operator & Machine Control: Separate Control Console with: CNi "NC 410" Operating System housed in air-conditioned cabinet.8" LCD Monitor: Displays programming graphics, numerical & function keyboard; 512 KB RAM memory; (1) "UPGRADED" USB drive.RS-422 Serial port for PC and RS-425 port for inverter connection; EPROM for machine data & subroutines; machine runs production programs while programming and editing. -- Complete with:Stabilized autotransformer for voltages between 200 - 600 Volt 50/60 Hz; (1) 100 cbm/Hr Vacuum Pump; triple photocell barrier; assortment of misc. parts and tooling; Users operator/maintenance manuals & backup disks. -- Actual Model is: BIESSE - ROVER 20.

BIESSE ROVER K 1532 CNC MACHINING CENTER (W/ATC & "C" AXIS): -- Specifications:"BRIDGE GANTRY" machine with a working field in "X" axis 126" (3,200 mm), "Y" axis 61" (1,560 mm), max. material thickness 6" (165 mm). -- Positioning speed:"X" Axis 279 FPM (85 MPM), "Y" Axis 196 FPM (60 MPM), "Z" axis 65 FPM (20 MPM). -- Work Table:(8) "ATS" Panels supports with lifting rails for heavy pieces; (4) "ATS" vacuum pods with universal clamping systems on each panel support.BIESSE "Set Up Assist" & digital readouts for pod & rail placement.(2) Independent working areas with (8) pneumatic back stops, (2) pneumatic side stops & (2) pneumatic central stops. -- Boring Unit:4 HP (3 kW) motor with variable speed from 1,500 - 7,500 RPM;"BL 30" Boring head with (20) "Quick Change" independent vertical spindles, (9) spindles in "X" axis & (11) spindles in "Y" axis;(8) Horizontal boring spindles with (2+2) in "X" axis & (2+2) in "Y" axis;(1) "X" axis grooving saw with 120 mm dia. blade. -- Machining:(1) 17 HP (12.6 kW) electro-spindle router with HSK F63 adaptor, variable speed from 3,000 - 24,000 RPM.Motorized dust deflector shield & 6-position adjustable dust suction hood,(1) NC controlled "C" axis for 360° horizontal processing.(1) 16-position ATC tool plate mounted on board the "X" axis at the rear of the machine. -- Operator & Machine Control:PC Front End with Biesse "BH 660" + Biesse "bSolid" + Windows "7 WRT" operating system,15" Flat screen monitor, full standard keyboard & mouse, 1.44MB & CD ROM disk drives for data entry,RS 232 & USB ports, Ethernet connection, specific function controls & internet trouble shooting capabilities.Electronics are mounted in an air conditioning & dust free environment control cabinet. -- Biesse "bSolid" is a 2D/3D Cad/Cam software program that supports the performance of any machining operation thanks to vertical modules designed for specific manufacturing processes.Planning with "bSolid" takes just a few clicks & has endless possibilities; "Real-Time" simulation allows the operator to visualize the piece prior to processing, it provides virtual prototyping of the piece to avoid collisions & ensures optimal machine performance. -- Complete with:(1) 250 m³/Hr Vacuum pump; Hand-held "Remote Control" pendant for immediate operator control; LED bar with (5) colors that show the machine's status in "Real-Time".Safety fences, safety bumpers, safety photocells & safety mats; scrap conveyor; original documentation + user & maintenance manuals, wiring diagrams and operation of Numerical Control. -- Actual Model is BIESSE ROVER K 1532 G VS2

--This machine is in an Auction on exfactoryauctions.com--NO RESERVE-- (2 Available) BIESSE SKIPPER 100 2-Head CNC Machining Center, with Infeed & Outfeed Tables – Seller states that machine was run (2) shifts from 2005 - 2021, then only a few hours per day since! Specifications: Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system. Working Capacity: "X" Axis 3,000 mm (118.11"), "Y" Axis 1,000 mm (39.37"), Max. part thickness 60 mm (2.36"). Min. workable part size: "X" Axis 90 mm (3.54"), "Y" Axis 70 mm (2.76"), & "Z" Axis 8 mm (0.31"). Work Table: Left-hand infeed & Right-hand outfeed, Each with 20-1/2” x 66” x 35-1/2” H infeed & outfeed areas with Fixed caster-type conveyor rails. Positioning Speed: "X" Axis 120 MPM (393 FPM), "Y" Axis 90 MPM (295 FPM), "Z" Axis 30 MPM (98 FPM). Boring Units: (1) Top & (1) Bottom boring blocks, Each with: 3 kW (4 HP) Motor, Boring spindle speed 4,000 RPM, (29) Vertical spindles with (17) "X" Axis & (12) "Y" Axis, (10) Horizontal spindles with (4 + 4) "X" Axis & (1 + 1) "Y" Axis, & (1) "X" Axis Grooving saw with 3 kW (4 HP) Motor, Blade speed 5,000 RPM, & Blade diameter 150 mm (5.91"). Machining: (1) Top & (1) Bottom 3.5 kW (4-3/4 HP) Electrospindles, Each with: Variable spindle speeds 7,000 - 18,000 RPM, Right-hand/Left-hand rotation, HSK D-50 Adapters for Manual push-button quick tool change, ERC-32 Toolholders & RC-32 Collets. Operator & Machine Control: Mobile Control Console, with PC-Based Control, 18" LCD Monitor, BIESSE "WORKS" + "WINDOWS" Operating system. Pedestal & Pendant controls. Equipped with: Universal transformer, 200 - 600 V, 50/60 Cy, 3-Ph., Automatic lubrication system for guides & ways, Sound hood, 79" H Safety fence with Lock-out door, & TAPESWITCH "CONTROLMAT CKP" 24" x 72" Heavy-duty ribbed pressure-sensitive safety mat. Complete with: 7’ x 9’ x 35-1/2” H Infeed Table, with Rails & Pusher. 6-1/2’ x 8’ x 35-1/2” H Outfeed Table, with Transfer Belts. Handheld Bar Code Reader. Dust Manifold. Dimensions including Safety Fence: 307" x 184" x 98" H.

BIESSE ROVER A 1536 G FT: Flat Table Machine with C-Axis -- Specifications5' x 12' "Matrix" grid Phenolic surface for: "Nested Base Manufacturing". -- Working Capacity"X" Axis: 148.2" (3,765 mm); "Y" Axis: 62.4" (1,585 mm); "Z" Axis stroke: 12.8" (325 mm); max. material thickness: 6.2" (160 mm). -- Positioning Speed"X" & "Y" Axes: 197 FPM (60 MPM); "Z" Axis: 98.4 FPM (30 MPM).All axes movement on precision linear guides & ways; controlled by digital, brushless AC Servo motors. - All motion components are maintained by an automatic lubrication system."X" & "Y" Axes: Use precision rack & pinion system; "Z" Axis uses precision ball screws. -- Work AreaFlat table design with: HI-FLOW, Multizone Matrix grid Phenolic surface for: "Nested Base Manufacturing"; automatic NC controlled zoning of the vacuum table with: (9) Individual zones.(2) Pneumatic "side" pop-up reference stops; (4) pneumatic "back" pop-up reference stops; (6) pneumatic "front" pop-up reference stops.Prepared for (optional) "quick fit" vacuum outlets: Optional clamping of small or awkward shaped parts; "quick connect" vacuum outlet: Custom vacuum pods & fixtures. -- Boring Unit(1) 2.5 HP (1.7 kW) Motor; variable speed up to 6,000 RPM; BH-40L Boring block with: (24) Independent spindles; (16) Vertical: (8) in "X" axis; (8) in "Y" axis. (8) Horizontal: (4) in X & (4) in Y. -- "X" Axis grooving saw with: 120 mm Dia. blade. -- Machining(1) 16.1 HP (12 kW) Air-cooled HSD Electrospindle with: HSK F63 adaptor; variable speed from: 1,000 - 20,000 RPM.(1) NC Controlled "C" axis for: 360° Horizontal operating; (1) 16-position ATC tool changer plate located at the back of the machine base.NC Controlled presetting for the measurement of the tool length. -- Operator & Machine ControlPC Front-End with: BIESSE XP 660 + BiesseWORKS + BiessNEST + WINDOWS WRT Operating System.15" TFT Flat screen monitor; server; full keyboard, & mouse all mounted on a mobile cart; Ethernet connection capabilities.BiesseWORKS Graphic interface makes full use of the operating methods typical of the WINDOWS operating system: Assisted graphic editor used to program machining operations; programming, and guided creation of parametric macros.Import of CAD and other external software files in DXF & CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces.BiesseNEST integrated with BiesseWORKS makes nesting simple & effective for every kind of shapes using parametric programs to optimize machining programs. -- Complete with:(2) 300 cbm/Hr BUSH Vacuum Pump; safety mats & fencing.Automatic program update according to the tool length; Automatic Lubrication System for linear guides, pads and recirculating ball screw.Universal Autotransformer for voltages between: 200 - 600 V - 50/60 Hz; Teleservice capabilities. -- Options (must be purchased separately). BIESSE Aggregate HSK F63. 360° Rotation on C-axis C with: 2-Opposite spindles; "AEROTECH" Tool Holder for

Biesse Rover B Edge semi automatic pod setting 4 coil magazine vertical and horizontal drill bank main spindle with U axis Milling X1: 5055 mm Y1: 1600 mm Edgebanding X2: 4100 mm Y2: 1600 mm Milling Module H74 - Z1: 245 mm Module H29 - Z2: 290 mm

BIESSE ROXYL 6.0 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + "AIR FORCE" PUR/EVA GLUING TECHNOLOGY: Features: -- Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high-temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers.This technology allows changes based on banding colors without any setup. Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. -- In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Specifications: -- Edgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"), coiled material from 0.4 - 3 mm (0.02 - 0.12"); panel thickness from 10 - 60 mm (0.39 - 2.36"), workpiece width min. of 85 mm (3.34"); workpiece length min. 140 mm (5.51"); feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). -- Machine Controls: "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System, floppy drive, and 4 GB HD; USB port, keyboard, and mouse interface. -- Flat Screen (17") with color graphics interface: Programs can be easily created and recalled at will; Graphic interface makes programming easy; icons of each unit may be brought up on the screen to show the operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without the necessity to write a program.Machine In-Feed Configuration: -- Pre-Milling Station "FL-502": (2) LH & RH Rotating NC-controlled spindles with automatic center positioning. -- Edge Magazine: Automatic for processing coiled and strip edge banding material + a (2) position vertical Coil Magazine Cart. -- Pressure Section: Servo-controlled programmable pressure section with (1) large driven roller and (4) idle rollers.Gluing System: -- EVA (Hot Melt) "QM-705": Quick premelting granulate with glue roller applicator to cover conventional edgebanding material. -- AirForce "VC-710": High pressure, hot air system to reactivate special precoated edge material (commonly referred to as laser edge).Workstations: -- End Trimming Unit "IT90-S": Front & rear trimming motors, uni-point swivel 0° - 15° bevel, programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-100": Top/Bottom pre- or flush trimming motors -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled, (4) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-positioning of motors by pneumatic air cylinders. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to workpiece's surfaces. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner

BIESSEROVER B 4.40 CNC MACHINING CENTER (W/ATC/BORING)Specifications: -- Working cap "X" Axis 143.3" (3,640 mm), "Y" axis 51.4" (1,306 mm), "Z" axis stroke is 8.8" (225 mm), max. material thickness 7"(180 mm). -- Positioning Speed: "X" & "Y" axis is 262 FPM (80 MPM), "Z" axis is 98 FPM (30 MPM); helical rack and pinion drive on "X" axis & ballscrew on "Y" & "Z" axis. -- Work Table: (6) Panel support rails with (4) lifting bars to assist with panel loading/unloading, digital display readouts for rail & pod placement according to the programs, (3) Vacuum pods per panel support, (2) independent working areas with pop-up locating pins for positioning of parts on the worktable -- Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with (1) "quick connect" vacuum outlet for custom vacuum fixtures. -- Boring unit: (24) Independent vertical boring spindles with (14) spindles in "X" axis & (10) spindles in "Y" axis, (10) horizontal spindles with (3+3) in "X" axis & (2+2) in "Y" axis, (1) "X" axis grooving saw with 120 mm dia blade. -- Machining unit: (1) 16 HP (12 kW) Vertically mounted HSD "Electro-spindle" router with ISO 30 adapter, inverter driven 1,000 - 20,000 RPM with max. torque from 12,000 - 20,000 RPM -- (1) 12-position ride-along ATC for "on the fly" tool change. -- Operator & Machine Control: PC Front End with: Biesse "XP 600" + BiesseWORKS Advanced + Windows "XP" operating system, INTEL "Celeron" 2.0 GHZ processor; 4 GB Hard drive; 15" color monitor, international keyboard, soft touch keypad & industrial mouse, RS-232 serial port, USB ports, CD ROM & 1.44MB disk drives -- Separate control panel with built-in 1,500 W air conditioner for constant temperature & dust-free environment, 11 KVA Stabilized auto-transformer for voltages between 200 - 600 Volts. -- Complete With: (1) 100 M3/Hr Vacuum Pump, Centralized manual lubrication system for guides & ball screw, emergency stop rope, safety mat protection barrier & sound absorbing protective head enclosure with debris curtain around bottom edge.

BIESSE - ROXYL 5.5: Edgebander (w/Premill & Corner Rounding)SpecificationsEdgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"); coiled material from: 0.4 - 3 mm (0.02 - 0.12"); panel thickness from: 10 - 60 mm (0.39 - 2.36"); workpiece width min.: 85 mm (3.34"); workpiece length min.: 140 mm (5.51"); feed speeds: 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). Machine Interface -- "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System; floppy drive; 4 GB HD; USB port, keyboard, and mouse interface. -- Flat-Screen (17") with Color graphics interface: Programs can be easily created & recalled at will; graphic interface makes programming easy: Icon of each unit may be brought up on the screen to show the Operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine Infeed Configuration -- Premilling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to work piece surfaces. -- Infrared Heating Lamp: Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine: Automatic for processing coiled and strip edgebanding material. -- Pressure Section: Servo controlled programmable pressure section with: (1) Large driven roller and (4) idle rollers.Gluing System -- EVA (Hot Melt) "QM-705" Quick premelting granulate with: Glue roller applicator to cover conventional edgebanding material. Workstations -- End Trimming Unit "IN-801": Front & rear trimming motors; uni-point swivel: 0° - 15° Bevel; programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors. -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled; (2) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-positioning of motors by pneumatic air cylinders. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner and upper & lower edge profiling. -- Profile Scraping Unit "RBK-503": Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit "RCC-701": Flat top/bottom; digital positioning indicators; pneumatic controlled for in/out position. -- Buffing Station "SP-501" Top & Bottom buffing motors with: 150 mm (6") Cloth buffing wheel diameter; adjusts in multiple directions. -- Edge Reactivation Unit "PH-700": Top/Bottom hot air blowers to restore original color to profile scraped PVC edge material.Complete with: -- Top Pressure Beam with: Driven flat belt and programmable height positioning.Includes" Multi-Tap Transformer. - Sound Hoods with interior lights. - Outboard panel support.

BIESSE - ROXYL 5.5: Edgebander (w/Premill & Corner Rounding)SpecificationsEdgebanding Cap. - Edge thickness for strips: Min./max.: 0.4 - 22 mm (0.02" - 0.87"); coiled material from: 0.4 - 3 mm (0.02 - 0.12"); panel thickness from: 10 - 60 mm (0.39 - 2.36"); workpiece width; Min.: 85 mm (3.34"); workpiece length min.: 140 mm (5.51"); feed speeds: 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). Machine Interface -- "Roxyl-Matic" Automated machine setup; MS/Windows XP Operating System; floppy drive; 4 GB HD; USB port, keyboard, and mouse interface. -- Flat-Screen (17") with Color graphics interface: Programs can be easily created & recalled at will; graphic interface makes programming easy: Icon of each unit may be brought up on the screen to show the Operator the status of the unit & parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine Infeed Configuration -- Premilling Station "FL-502". (2) LH & RH Rotating NC controlled spindles with: Automatic center positioning. -- Anti-Adhesive: "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to workpiece surfaces. -- Infrared Heating Lamp. Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine. Automatic for processing coiled & strip edgebanding material. -- Pressure Section Servo controlled programmable pressure section with: (1) Large driven roller and (4) idle rollers.Gluing System -- EVA (Hot Melt) "QM-705" Quick premelting granulate with: Glue roller applicator to cover conventional edgebanding material. Workstations -- End Trimming Unit "IN-801": Front & Rear trimming motors; unipoint swivel: 0° - 15° Bevel; programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors. -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled: (2) Servo motors (one for horizontal tool position; one for tool up/down position); uses combination bevel/radius/flush insert knives; prepositioning of motors by pneumatic air cylinders. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner and upper & lower edge profiling. -- Profile Scraping Unit "RBK-503": Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit "RCC-701": Flat top/bottom; digital positioning indicators; pneumatic controlled for in/out position. -- Buffing Station "SP-501" Top & Bottom buffing motors with: 150 mm (6") Cloth buffing wheel diameter; adjusts in multiple directions. -- Edge Reactivation Unit "PH-700": Top/Bottom hot air blowers to restore original color to profile scraped PVC edge material.Complete with: -- Top Pressure Beam with: Driven flat belt & programmable height positioning.Includes: Multi-Tap Transformer. - Sound Hoods with interior lights. - Outboard panel support.

BIESSE ROVER 24 FTS FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications: 4' x 10' Flat table design for "Nested Base" processing: Working cap.: X-Axis is 122" (3,100 mm), Y-axis is 49" (1,250 mm), Z-axis is 6.1" (155 mm). -- Worktable:Phenolic "MATRIX" grid vacuum table for FT "Nesting" or single part processing using (optional) pods or jigs; (2) side & (4) rear pop-up pins for easy material location. -- Positioning Speed:X- & Y-axis 262 FPM (80 MPM), Z-axis 98 FPM (30 MPM); "X-axis uses a helical rack & pinion system, Y- & Z-axis use precision ball screws; all axes movement is on precision linear guides & ways & controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Boring Unit:(1) 4 HP (3.3 kW) - 4,000 RPM motor: (14) independent vertical spindles, (7) in X-axis & (7) in Y-axis; (6) horizontal drills with (2 + 2) in X-axis & (1 + 1) in Y-axis. -- Machining:(1) 16 HP (12 kW) Liquid-cooled vertically mounted HSD electro-spindle router with HSK F63 adaptor, inverter driven 1,000 - 20,000 RPM with max. torque from 12,000 - 20,000 RPM; (1) 6-position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Operator & Machine Control:PC Front End with: BIESSE "XP600 + WINDOWS" XP-operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities; programs can be transferred via diskette or downloaded by wire; built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with: 11 KVA Stabilized autotransformer for voltages between 220 - 600 V; automatic "forced" lubrication system for guides & ball screw; emergency stop rope & pressure sensitive safety mats that will instantly place machine in "pause cycle" when stepped on; sound absorbing protective head enclosure with debris curtain around bottom edge. -- NO Vacuum Pump is included but let us know if needed we can source a good used unit.

BIESSE FSE SEMI-AUTOMATIC DOWEL INSERTER W/BORING 21-Spindle head (spindles on 32 mm centers) fixed horizontally for end boring, -- Equipped with:(8) Glue injectors & dowel inserters,(4) overhead "HD" pneumatic hold-down clamps. -- After the drilling cycle is complete, the head assembly traverses down to the glue & dowel injector line for the glue & dowel injection; quick cycle time. -- PLC function selector control for boring only, inserting only, or boring & inserting. -- Capacity: Handles 8 mm - 10 mm dia., digital indicator for adjustable dowel length from 25 mm - 50 mm, max. boring depth 70 mm. -- Features: Height adjustment w/digital readout for panel thickness, hydraulic brakes for adjustment of boring speed; 2.3 HP - 4,000 RPM motor.Complete with: -- (2) Side fences, front support table w/stop, glue reservoir tank with pressure control & rinsing tank for glue nozzles. -- 4way dowel feeding vibrator, and foot pedal for starting cycle.Note: Only (4) dowel line on the machine, you just need to add more dowel tube

BIESSE0 - Levia 110: 43" 2-Head Wide Belt SanderWidth cap: 43"; Drum: Combination Head.Head configurations1st Head: 5" diameter steel contact roll2nd Head 5" diameter rubber drum 45 shore with 2 1/2" wide platenSpecification -- Width cap 43" -- 1st Head: Steel contact roll, 30 HP motor. -- 2nd Head: Combination head with a rubber covered contact roll and finishing platen 24 HP motor. -- 43" x 85" abrasive belts, electronic abrasive belt tracking, abrasive belt grit compensation on both heads with 4-position turret stop. -- Conveyor belt feed, 10 - 40 FPM variable feed speed with inverter control from control panel, 1.5 HP feed drive,Equipped with & Features -- Automatic conveyor belt tracking, -- 0" - 7-7/8" motorized thickness adjustment with LED readout. -- Automatic part thickness adjustment, -- Infeed and outfeed rubber covered holddown rolls. infeed panel -- Over-thickness" sensor, -- Electronic brakes on both sanding head motors. -- Infeed emergency stop, -- 3-Roll infeed extension -- Twin motor load meter.

Biesse Rover 24 FT Router Series # 09665 Year: 2001 Power Supply: 20 KW, 480 V, 28 A., 60Hz., 110 24 Low Tensions Air supply: 7 minimum Bar Suction Air Speed: 30 M/1 Vacuum Pump Additional photos and details available Router is still hooked up and running. Price includes dismantling & loading Contact us for a freight rate

BIESSE ROVER A 2231 G FT FLAT TABLE MACHINE (W/LOADING, UNLOADING): -- Specifications:7' x 10' "Matrix" grid Phenolic surface for "Nested Base Manufacturing". -- Working Capacity: "X" Axis 122 (3,100 mm), "Y" axis 86.6" (2,200 mm), "Z" axis stroke is 12.7" (325 mm), max. material thickness 4.7" (120 mm). -- Positioning Speed: "X" axis 262 FPM (80 MPM), "Y" axis 197 FPM (60 MPM), "Z" axis 66 FPM (20 MPM). All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors.All motion components are maintained by an automatic lubrication system. "X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws. -- Work area:Flat table design with HI-FLOW, multi-zone Matrix" grid Phenolic surface for "Nested Base Manufacturing";Automatic NC controlled zoning of the vacuum table with (9) individual zones.(2) Pneumatic "side" pop-up reference stops, (4) pneumatic "back" pop-up reference stops, & (6) pneumatic "front" pop-up reference stops.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with "quick connect" vacuum outlet for custom vacuum pods & fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) Motor, variable speed up to 6,000 RPM: Boring block with (10) independent vertical spindles, (7) in "X" axis & (3) in "Y" axis;(1) "X" axis grooving saw for max 120 mm dia blade. -- Machining:(1) 18 HP (13.2 kW) Air cooled HSD Electro Spindle with HSK 63 adaptor, variable speed from 1,000 - 20,000 RPM.(1) 8-position ATC tool changer plate located at the back of the machine base;NC controlled presetting for the measurement of the tool length. -- Operator & Machine Control:PC Front-End with: BIESSE XP 660 + BiesseWORKS + WINDOWS WRT operating system;17" TFT Flat screen monitor; server, full keyboard, & mouse all mounted on a mobile cart; Ethernet connection capabilities.BiesseWORKS Graphic interface makes full use of the operating methods typical of the WINDOWS operating system: Assisted graphic editor used to program machining operations; programming, and guided creation of parametric macros.Import of CAD and other external software files in DXF & CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(1) 900 m³/Hr Vacuum Pump; Safety mats & fencing; Tool touch-off probe for automatic program update according to the tool length;Automatic Lubrication System for linear guides, rack & recirculating ball screw. Tele-Service capabilities. -- Options Include: (1) NC Controlled infeed Scissor Lift table with vacuum loading; (1) Rake system; (1) NC controlled & powered belt outfeed table with vacuum sweeping system; (1) Additional NC controlled powered belt outfeed table; Bar code label printer. -- Actual Model is BIESSE ROVER A 2231 G FT

BIESSE ROVER B 4.40 FT FLAT TABLE MACHINE (W/ATC/BORING) -- Specifications:4' x 10' Flat Table with "Matrix" grid phenolic surface for "Nested Base Manufacturing". -- Working cap:"X" Axis 126" (3,200 mm), "Y" axis 53.5" (1,360 mm), "Z" axis stroke is 6.3" (160 mm), max. material thickness 5.9" (150 mm). -- Positioning Speed:"X" & "Y" axis is 262 FPM (80 MPM), "Z" axis is 98 FPM (30 MPM); helical rack and pinion drive on "X" axis & ball screw on "Y" & "Z" axis. -- Work area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing", (2) independent working areas; (4) external pop-up reference pins with (3) on the back of the table & (1) on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with (1) "quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit: (1) 2.5 HP (1.7 kW) - 4,000 RPM motor: (12) independent vertical spindles, (6) in "X" axis & (6) in "Y" axis.(6) Horizontal spindles with (2+2) in "X" axis & (1+1) in "Y" axis; (1) 120 mm dia "X" axis grooving saw. -- Machining:(1) 10.2 HP (7.5 kW) Electro-spindle with ISO 30 adaptor, variable speed from 1,000 - 20,000 RPM;(1) 10-Position ride along tool changer for "on the fly" ATC. -- Operator Interface: PC Front End with Biesse "XP600 + WINDOWS "XP" operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with: Universal Auto-Transformer for voltages between 200-600 V, 50/60 HZ; (2) 10 HP, (7.5 kW) BUSCH Vacuum Pumps; safety mats & fencing. -- Actual Model is BIESSE ROVER B 4.40 FT.

Pressure Beam Type: Rollers Pre-Milling Station: 2 Motors Glue Station Pressure Rollers: 4 End Trimming Station: Straight & Bevel (2 motors) Rough Milling Station: 2 Motor Fine Milling Station: 2 Motor Corner Rounding Station: 2 Motor Flat Scraping Station: Top & Bottom Profile Scraping Station: Top & Bottom Buffing Station: Top & Bottom Heat: Top & Bottom Panel Height: 10-50 mm Edge-banding Material Height: 13-55 mm Min. Thickness of Edge-Banding Strip in Rolls: 0.4-3 mm Max. Edge Thickness w/Trimming Unit: 8 mm Max. Edge Thickness w/o Trimming: 3 mm Max. Section of Solid Wood: 8 x 55 mm Panel Protrusion from Track: 25 mm Min. Panel Length: 150 mm Min. Panel Width (150mm Length): 85 mm Min. Panel Width (250mm Length): 55 mm Chain Feed Speed: 12 m/min Dimensions: 18' L x 4' W x 5' H Weight: 4,000 lbs Electrical: 230 V 3 Phase

BIESSE ROVER A 1432 ATS CNC MACHINING CENTER (W/ATC/BORING): Specifications: -- Working Capacity:"X axis 125.9" (3,200 mm), "Y" axis 52" (1,320 mm), "Z" axis stroke 13.7" (350 mm), max material thickness 9.6" (245 mm). -- Positioning speed:"X" 262 FPM (80 MPM), "Y" Axis 196 FPM (60 MPM), "Z" axis 98 FPM (30 MPM);AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. -- Work Table:(6) Tube-less panel supports with (4) lifting bars for heavy panels & (3) ATS vacuum pods per panel support;(6) Pneumatic back stops, (6) pneumatic front stops, (2) pneumatic side stops & (2) pneumatic central stops. -- Boring Unit:4 HP (3 kW) motor with variable speed from 1,500 - 7,500 RPM; (20) "Quick Change" independent vertical spindles with (10) spindles in "X" axis & (10) spindles in "Y" axis;(8) horizontal boring spindles with (2+2) in "X" axis & (2+2) in "Y" axis;(1) "X" Axis grooving saw for max 120 mm dia saw blade. (1) "Y" Axis grooving saw for max 120 mm dia saw blade. -- Machining:(1) 17 HP (13 kW) Liquid Cooled "HSD" electro-spindle router with HSK F63 adaptor, variable speed from 1,500 - 24,000 RPM;(1) 8-Position ATC tool plate located on the machine head for "on the fly" ATC. -- Operator & Machine Control:PC Front End: Biesse "BH 600" + bSOLID + WINDOWS "7" operating system,15" TFT monitor, full standard keyboard & mouse, CD ROM disk drives,RS 232 & USB ports, Ethernet connection, specific function controls & and internet trouble shooting capabilities;Control cabinet with air conditioning & dust free environment."bSOLID" is a multitask operating system, input/output modules, axes override, 4-axes interpolation, diagnostic graphics aid for programming, machine data & tool management. -- Complete with:(1) 100 m³/Hr vacuum pump; automatic lubrication system; original documentation; hand held pendant; safety fences & mats; scrap conveyor; CE mark. -- Actual Model is BIESSE ROVER A 1432 ATS

Pressure Beam Type: Rollers Pre-Milling Station: 2 Motors Glue Station Pressure Rollers: 4 End Trimming Station: Straight & Bevel (2 motors) Rough Milling Station: 2 Motor Fine Milling Station: 2 Motor Corner Rounding Station: 2 Motor Flat Scraping Station: Top & Bottom Profile Scraping Station: Top & Bottom Buffing Station: Top & Bottom Heat: Top & Bottom Panel Height: 10-50 mm Edge-banding Material Height: 13-55 mm Min. Thickness of Edge-Banding Strip in Rolls: 0.4-3 mm Max. Edge Thickness w/Trimming Unit: 8 mm Max. Edge Thickness w/o Trimming: 3 mm Max. Section of Solid Wood: 8 x 55 mm Panel Protrusion from Track: 25 mm Min. Panel Length: 150 mm Min. Panel Width (150mm Length): 85 mm Min. Panel Width (250mm Length): 55 mm Chain Feed Speed: 12 m/min Dimensions: 18' L x 4' W x 5' H Weight: 4,000 lbs Electrical: 230 V 3 Phase

BIESSE ROVER - A 3.30: CNC Machining Center (w/ATC/Boring) -- SPECIFICATIONSWorking cap. - "X" Axis: 118" (3,000 mm) any unit; "Y" Axis: For routing, 45.2" (1,150 mm; "Y" Axis for: Boring; 49.6" (1,260 mm); "Z" Axis stroke: 7.8" (198 mm); max. material thickness: 5.9" (150 mm). -- Positioning Speed Both "X & Y" Axis is: 262 FPM (80 MPM); "Z": 111 FPM (34 MPM); helical rack & pinion drive: On "X" axis; precision ball screw on: "Y & Z" Axes. -- Worktable (6) Support rails with: (3) Vacuum pods per rail; (6) pop-up back stops, (4) pop-up side-stops; (2) independent working areas.Prepared for (optional) "quick fit" vacuum outlets for: Optional clamping of small or awkward shaped parts; each work zone with (1) "Quick connect" vacuum outlet: For custom vacuum fixtures. -- Boring Unit(14) Independent vertical boring spindles forming an L-configuration with: (7) Spindles in "X" Axis & (7) spindles in "Y" Axis.(6) Horizontal spindles with: (2 + 2) in "X" axis; (1 + 1) in "Y" Axis; (1) "X" Axis grooving saw for: Max. 120 mm dia. blade. -- Machining (1) 9.5 HP (7 kW) Vertically mounted HSD electrospindle router with: HSK F63 Adaptor.Inverter driven 1,000 - 24,000 RPM with: Max. torque from 12,000 - 24,000 RPM. (1) 18-Position "Ride-Along", "on the fly" automatic tool changer. -- Operator & Machine ControlPC Front-End with: BIESSE "XP600" + Windows "XP" + BIESSE "WORKS" Operating System.INTEL "Celeron" 2.0 GHz Processor; 4 GB Hard drive; 15" color monitor; international keyboard; soft touch keypad & industrial mouse; RS-232 serial port; (1) 1.44 MB floppy disk drive.BiesseWORKS: An easy CAD program that can be done from the office or at the machine; Operating System: Real-Time multitask processing; programs can be transferred via diskette or downloaded by wire. -- Complete with: (1) 250 M³/Hr Vacuum Pump; 11 KVA stabilized autotransformer for voltages between: 220 - 600 Volts. Equipped with: Centralized manual Lubrication System for guides & ball screw; built-in 1,500 W air conditioner for constant temperature & dust-free environment. Emergency stop rope & sound absorbing protective head enclosure with: Debris curtain around bottom edge. -- Actual model: BIESSE ROVER - A 3.30

BIESSE - ELIX B: CNC Bore, Glue, and Dowel InserterBIESSE Drill & Dowel Inserter features: Single-spindle for drilling; dowel insertion unit; glue injecting unit installed on a carriage moving in the X-axis.Position for drilling dowel insertion provided through simple programs through the NC control or third party software. Operator Control interface is: Intuitive, user-friendly, and very easy to use. -- Specifications Max. parts length: 1,300 mm (51";); min. parts length:120 mm (4.7";); parts thickness: 10 - 40 mm (0.4"; to 1-1/2";). -- Positioning Speed "X" & "Y" Axis positioning speed: 40 MPM (131 FPM); "Z" axis has manual adjustment with: Max stroke of 40 mm (1.57").The working units travel: Precision machine ground ball screws; powered by brushless AC Servo motors. -- Worktable(4) Working Zones with: Center fence position in up mode; (2) large work zones in down position; (4) holddown cylinders. -- Boring UnitDrilling Uunit. High-speed unit with: 6,000 RPM spindle; max. drilling depth of 30 mm (1-1/4"); max. drill bit dia.: 12 mm (0.47"); manual adjustment of depth with: Digital indicator. -- Dowel Insertion UnitDowel prepositioning ensures: high repeatability of inserting dowels for each hole; distance between the dowel insertion unit and the drilling spindle: 32 mm (1.3") for simultaneous drilling; dowel insertion when holes are spaced at 32 mm; standard dowel dimensions: 8 x 30 mm; Max. dowel projection: 14 mm (0.551"). Glue Tank: Holds up to 8 liters (3.1 gallons) of glue; max. glue density: 900 CPS. - Glue inserting unit: Flow sensor and electronic adjustment of the amount of glue. -- Operator InterfaceIndustrial Numerical Control with: Extremely simple Program Editor; macro & parametric programming. Icon driven. -- Includes: Original Factory Machine Documentation. -- Actual Model: BIESSE ELIX B
