Equipment For Sale

BIESSE ROVER 24 FTS FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:4' x 10' "Matrix" grid phenolic surface table for "Nested Base Manufacturing". -- Working Cap."X" Axis is 122" (3,100 mm), "Y" axis 49.2" (1,250 mm), "Z" axis stroke is 9.8" (250 mm).Max. material thickness of 6.1" (155 mm). -- Positioning Speed:"X" & "Y" Axis is 328 FPM (100 MPM), "Z" axis 98 FPM (30 MPM)."X" axis uses a helical rack & pinion system, "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides / ways & controlled by digital, brushless AC Servo motors.All motion components are maintained by a lubrication system. -- Work area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas.(4) External pop-up reference pins: Reference pins are adjustable & can be placed on the front of the table, on the back of the table, on the RH side & on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts,Each work zone with (1) "quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) - 4,000 RPM Motor; (14) Independent vertical spindles, (7) in "X" axis & (7) in "Y" axis.(6) Horizontal spindles with: (2+2) in "X" axis & (1+1) in "Y" axis; (1) "X" axis grooving saw for max. 120 mm dia blade.(1) 6-Position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Machining:(1) 10.2 HP (7.6 kW) Electro-spindle Router, variable speed from 1,000 - 20,000 RPM; -- Operator & Machine Control:PC Front End with: NC 1000" + WINDOWS "NT" operating system; 15" color CRT display.40 GB Hard drive; floppy & CD drives; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:Universal Auto-Transformer for voltages between 200 - 600 V, 50/60 Hz.; Manuals, documents & safety perimeter devices. -- Actual Model is BIESSE ROVER 24 FTS.NOTE: The Vacuum Pump is NOT Included with this machine

BIESSE - STREAM A 6.5: Edgebander w/Premill & Corner Rounding + NC Axis PackageFeatures -- "NC Axis Package". The machine adapts to the process being executed based on the edge's thickness and material.Machine management: 100% Touch with no need for external devices. - "Intelligent" language management.Easy program management and usability with rapid transition from one machining operation to the next. Specifications -- Edgebanding CapacityEdge thickness for strips: Min./max. 0.4 - 22 mm (0.02" - 0.87"); coiled material: 0.4 - 3 mm (0.02 - 0.12").Panel thickness: 10 - 60 mm (0.39 - 2.36"); Workpiece width: Min. of 85 mm (3.34"); workpiece length: Min. 140 mm (5.51").Feed speeds: 12 - 18 - 20 - 25 MPM (39 - 59 - 65 - 82 FPM).Machine Infeed Configuration -- Premilling Station: FL 502(2) 3.5 kW (4.7 HP) - 12,000 RPM Motors; LH & RH counterrotating spindles; NC (Servo) controlled with: Automatic intervention that guarantees a perfect base for gluing. -- Anti-Adhesive: VC 710Automatic Spray Unit with: Glue release agent preventing glue from adhering to workpiece's surfaces. -- Infrared Heating Lamp: PH 700Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine(1) Coil/position magazine for processing coiled & strip edgebanding material in real time. -- Pressure SectionServo Controlled programmable pressure section with: (1) Large driven roller and (4) idle rollers.Gluing System w/Premelter -- EVA (Hot Melt) Quick premelting granulate with: Glue roller applicator to cover conventional edgebanding material. Workstations -- End Trimming: IT 90SFront & rear linear end trimmer with: Tilt function for high speeds; (2) 0.65 kW (0.87 HP) - 12,000 RPM motors. Machine axis movement on linear tracks allow the achievement of very high processing speeds.Copying & tracing system guarantees optimal finish quality, also on high gloss edges with film. -- Flush/Bevel Trimming Unit: RF 400Top & Bottom flush or bevel trims with: (2) "Quick Change" 2 kW (2.7 HP) - 12,000 RPM motors. -- Fine Trimming Unit: RF 12(2) 0.65 kW (0.8 HP) - 12,000 RPM Motors; (2) Servo motors for tool positioning (one for horizontal tool position; one for up/down tool position).Prepositioning of motors by pneumatic air cylinders while using a combination bevel/radius/flush insert knives.Absolute machining flexibility thanks to the full adjustment of the machine according to the required edge thickness. -- Corner Rounding Unit: AR 30(2) 0.65 kW (0.8 HP) - 12,000 RPM Motors for front/back corner and upper & lower edge profiling.The controlled axis on the Corner Rounding unit supports the management of infinite machining settings. -- Profile Scraping Unit: RB 02Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit: RCC 701: Flat, top/bottom, digital positioning indicators, pneumatically controlled for in/out position. -- Buffing Station: SZ30: Top & Bottom buffing motors: 0.37

BIESSE ROXYL 6.0 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + "AIR FORCE" PUR/EVA GLUING TECHNOLOGY: Features: -- Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high-temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers.This technology allows changes based on banding colors without any setup. Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. -- In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Specifications: -- Edgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"), coiled material from 0.4 - 3 mm (0.02 - 0.12"); panel thickness from 10 - 60 mm (0.39 - 2.36"), workpiece width min. of 85 mm (3.34"); workpiece length min. 140 mm (5.51"); feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). -- Machine Controls: "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System, floppy drive, and 4 GB HD; USB port, keyboard, and mouse interface. -- Flat Screen (17") with color graphics interface: Programs can be easily created and recalled at will; Graphic interface makes programming easy; icons of each unit may be brought up on the screen to show the operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without the necessity to write a program.Machine In-Feed Configuration: -- Pre-Milling Station "FL-502": (2) LH & RH Rotating NC-controlled spindles with automatic center positioning. -- Edge Magazine: Automatic for processing coiled and strip edge banding material + a (2) position vertical Coil Magazine Cart. -- Pressure Section: Servo-controlled programmable pressure section with (1) large driven roller and (4) idle rollers.Gluing System: -- EVA (Hot Melt) "QM-705": Quick premelting granulate with glue roller applicator to cover conventional edgebanding material. -- AirForce "VC-710": High pressure, hot air system to reactivate special precoated edge material (commonly referred to as laser edge).Workstations: -- End Trimming Unit "IT90-S": Front & rear trimming motors, uni-point swivel 0° - 15° bevel, programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-100": Top/Bottom pre- or flush trimming motors -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled, (4) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-positioning of motors by pneumatic air cylinders. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to workpiece's surfaces. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner

BIESSE ROVER B 4.40 FT FLAT TABLE MACHINE (W/ATC/BORING) -- Specifications:4' x 10' Flat Table with "Matrix" grid phenolic surface for "Nested Base Manufacturing". -- Working cap:"X" Axis 126" (3,200 mm), "Y" axis 53.5" (1,360 mm), "Z" axis stroke is 6.3" (160 mm), max. material thickness 5.9" (150 mm). -- Positioning Speed:"X" & "Y" axis is 262 FPM (80 MPM), "Z" axis is 98 FPM (30 MPM); helical rack and pinion drive on "X" axis & ball screw on "Y" & "Z" axis. -- Work area:Flat table design with "Matrix" grid phenolic surface for "Nested Base Manufacturing", (2) independent working areas; (4) external pop-up reference pins with (3) on the back of the table & (1) on the LH side.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with (1) "quick connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit: (1) 2.5 HP (1.7 kW) - 4,000 RPM motor: (12) independent vertical spindles, (6) in "X" axis & (6) in "Y" axis.(6) Horizontal spindles with (2+2) in "X" axis & (1+1) in "Y" axis; (1) 120 mm dia "X" axis grooving saw. -- Machining:(1) 10.2 HP (7.5 kW) Electro-spindle with ISO 30 adaptor, variable speed from 1,000 - 20,000 RPM;(1) 10-Position ride along tool changer for "on the fly" ATC. -- Operator Interface: PC Front End with Biesse "XP600 + WINDOWS "XP" operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with: Universal Auto-Transformer for voltages between 200-600 V, 50/60 HZ; (2) 10 HP, (7.5 kW) BUSCH Vacuum Pumps; safety mats & fencing. -- Actual Model is BIESSE ROVER B 4.40 FT.

BIESSE - AKRON 246: Edgebander with Corner Rounding 0.4 - 8 mm (5/16") Cap. Edgebanding thickness; min. panel width: 85 mm; min. length: 140 mm; panel thickness: 10 - 50 mm; automatic strip & coil feed magazine with: Robust shear type 3 mm PVC guillotine.Equipped with: -- Adjustable top pressure beam positioning. -- Hot Melt glue system (12 min. heat up time) with: Teflon coated glue pot; digital thermostats with automatic kickdown when machine is in idle mode. -- 1" Dia. glue applicator roller; pressure section with: (1) Large dia. "non-stick" coated drive roller & (2) chrome plated idle rollers with pneumatic positioning.Workstations -- Front & Rear end trims (0.33 HP - 12,000 RPM motors); motors travel on (2) straight slides; pneumatic tilt 0° - 25° on horiz. plane. -- Top & Bottom flush trims with "Quick Change" motors (1.0 HP - 12,000 RPM motors), digital readouts for easy setup. -- Corner rounding unit for trimming leading & trailing upper & lower edge/corners with "Fast Position"; can be used as a 2nd Top & Bottom fine trimmer, as well. -- Top & Bottom scrapers for 3 mm thick PVC banding; digitals for horiz. adjustments. -- Top & Bottom (2,000 Watt) hot air blowers with temperature adjustment. -- Top & Bottom buffing (0.5 HP - 2,800 RPM motors); units tilt 0° - 30°. -- Feed Speed: 39 FPM, 3 HP feed drive.Complete with: -- Microprocessor for workstations & feed speed; insulated sound enclosure over all trim stations with: Triple split dust hood; industrial lights; viewing windows. -- Extendible side panel support rail; 12 KVA - 240 Hz digital frequency inverters. -- Includes: Used tooling on all workstations.NOTE: Seller states that all workstations are functioning properly as can be seen in the video, but the End Trim needs adjustment. The Return Conveyor is not included.

BIESSE AKRON 440 AX EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications Material infeed for strips & coiled edge material like: PVC, ABS, veneer, and solid wood. -- Edge & Workpiece Capacity: 0.4 - 3 mm (0.016 - 0.12") Edge; 10 - 60 mm (0.39 - 2.36") panel thickness; 140 mm (5-1/2") min. panel length, and 85 mm (3.3") min. width. -- Working Units:Premilling Station: (2) 3 kW (4 HP) - 150 Hz, 9,000 RPM Motors; equipped with: Panel blow off device; SIKO digital counters for adjustments. -- EVA Gluing Unit: Edge Feeding & Pressing Unit; automatic loading of tape in rolls and strips; quick-change glue pot system. -- Pressure Section: (1) Large 150 mm dia. driven; (5) idle pressure rollers. -- Feed Speeds: Operating feed speeds: 12 & 18 MPM (39 & 60 FPM). -- Workstations: Double motor End Trim; tiltable from 0° - 15°; each motor: 0.8 kW (1 HP) - 12,000 RPM; sliding in a slicing motion on a 45° precision guide bar with oversized bearing blocks. -- Top & Bottom Trimming: (2) Motors, 0.65 kW (0.87 HP) each; "Pro-Nesting" copiers; cutters: R=2 mm. -- Fine Trim/Corner Rounding Unit: (2) Motors; each 0.65 kW (0.87 HP) - 12,000 RPM; motors carry out Corner Rounding and Top & Bottom Trimming on panel edge with: PVC, ABS, etc. material; wood edge banding up to 3 mm max. edge thickness. -- Top & Bottom Flat Glue Scrapper: To remove potential glue squeeze out. -- Buffing Station: Top & Bottom; (2) motors; each 0.37 kW (0.5 HP) - 2,800 RPM. -- Operator Interface:Operator Control Panel; "HDI" high definition touchscreen control; Windows XP-based. -- User-friendly graphic user interface with: Diagnostic and assisted maintenance. -- USB and Ethernet port; 1.44 MB floppy drive, automatic or manual startup. -- Complete with:High frequency motors (200 Hz): Padded sound enclosure. -- Top pressure beam with staggered double row holddown wheels mounted on ball bearings. -- Actual Model: BIESSE AKRON 440 AX

BIESSE - AKRON 855, ...Edgebander with Premill & Corner Rounding (Loaded!)Specifications: -- Edge & Workpiece Capacity: 0.4 - 15 mm (0.016" - 0.59") Edge thickness; 14 - 65 mm (0.55" - 2.56") edge height; 10 - 60 mm (0.39" - 2.36") panel thickness; 140 mm (5-1/2") min. panel length; 85 mm (3.3") min. panel width. Infeed Section: -- Premilling Unit - "FI-701"Rectifies face to be edged before applying glue; horizontal & vertical movement of (2) motors on linear guides; independent automatic temporized intervention of (2) 1.8 kW (2-1/2 HP) - 12,000 RPM motors; independent copying pads on each unit, Autoset device to ensure optimum positioning of cutters according to thickness of panel being machined. -- Edge Feeding, Gluing & Pressing Unit - "VC-710"With automatic edge magazine for strip & coil stock; 3 mm (0.04") PVC guillotine; "TEKNO-GLUE" System includes: Pre-Melt "QM-701"; for quick heating & tank changing with floating & bidirectional glue roller applicator & NC axis idle presser roller movement device. -- Pressure Section: (1) Large driven & (5) Idle rollers, Independent pneumatic pressure control, Programmable servo motor for quick edge thickness changeover, Feed speeds 10, 14 & 20 MPM (33, 46 & 65 FPM).WORKSTATIONS: -- End (Edge) Trimming Unit - "IN-701-V"(2) 0.35 kW (0.5 HP) - 12,000 RPM Motors; automatic 4-position programmable chamfer from Control Panel (0°, 3.6°, 11°, 15°); sliding in slicing motion on 45° precision guide bar with oversized bearing blocks. -- Superimposed Flush (Double Edge) Trimming Unit - "RS-701"Top & bottom; (2) 0.8 kW (1 HP) - 12,000 RPM motors with superimposed motor position; 1° tilt capability; includes: Pneumatic exclusion device & Pneumatic top/bottom motor positioner. -- Tilting Top & Bottom Trimming Unit - "RI-701"(2) 0.65 kW (0.87 HP) - 12,000 RPM Motors; for radius top & bottom fine trimming; unit can be tilted 0° - 45°; includes: NC axis multiple machining device. -- Corner Rounding Unit - "CR-200V"For corner rounding; top & bottom trimming on panel edge with synthetic material & wood edgebanding up to 5 mm (0.20") max. edge thickness. -- Edge Scraping Unit - "RB-701"For finishing rounded off edges in PVC or ABS up to 5 mm (0.20") thickness includes: Pneumatic Unit Lifter. -- Flat (Glue) Scraper - "RCC-700"Top & Bottom, Removes potential excess glue before buffing unit. -- Buffing Unit, "SPL-700":Top & Bottom. -- Hot Air Blower Unit - "PH-700" - (2) STEINEL "2346" 2,000 W; reactivates color of thick plastic.Complete with: -- PC-Based Control Panel with: 15" Color LCD monitor, HF (High Frequency motors on all cutting & trimming workstations. Top pressure beam programmable via positioning motor; top pressure provided by belt holddown. 36" Dia. Coil table: Padded sound enclosure. -- Manuals (as pictured).Dimensions: 280" x 42" x 72" H. - Weight: 3,500 kG (7,750 Lbs.).

BIESSE AKRON 1330 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Computer controlled interface for workstations with servos and pneumatic positioning devices. Programmable selections for 1-touch changeover between edgebanding types and thicknesses.Top Pressure Beam with automatic adjustment from the machine control. -- Working Capacity: Edgebanding thickness, 0.4 - 5 mm capacity. Min. panel width 85 mm (3.3"); min. panel length 140 mm (5.5"); panel thickness 10 - 50 mm (0.39" - 1.96").3 HP (2.2 kW) Variable Feed Speed from 10 - 20 MPM (32 - 65 FPM).Front-End Equipped With: -- Pre-milling Unit with "Auto-set" automatic intervention, Strip & Coil Edge magazine, automatic shear type guillotine. -- Hot-Melt Glue System: Teflon coated glue pot, digital thermostats with automatic kick-down when machine is in idle mode.Pressure Section with (1) large dia. "non-stick" coated drive roller & (5) Teflon plated idle rollers with servo positioning NC controlled material thickness adjustment.Workstations: -- End Trimming Unit:NC controlled end trimming unit, 0.33 HP (0.24 kW) - 12,000 RPM motors.Motors travel on (2) straight slides and pneumatic tilt 0° - 15° on horizontal. plane -- Top & Bottom Multi- Function Flush/Bevel/Radius Trimming Unit: NC Controlled 2-motor Top & Bottom Multi- Function Flush/Bevel/Radius Trimming Unit, 0.3 HP (0.24 kW) - 12,000 RPM.Servo driven positioning of motors for different edge trimming profiles & positions. -- Corner Rounding Unit:2-motor 0.3 HP (0.24 kW) - 12,000 RPM motors for trimming leading & trailing upper & lower edge/corners with "Fast Position",Unit can be used as a second top & bottom fine trimmer as well. -- Profile Scraping Unit:Top & bottom 2 mm or 3 mm thick PVC banding, digitals for horiz. adjustments. -- Flat Scraping Unit:Top & bottom glue scraping unit. -- Buffing Unit: Top & bottom Buffing Unit, 0.5 HP (0.37 kW) - 2,800 RPM motors), units tilt 0° - 30°Operator & Machine Control: -- Biesse SMART TOUCH 7" + Windows operating system, user friendly touchscreen control panel for workstations, rotating operator control panel w/keypad and LCD readout.Graphic 7" display touch screen. High-resolution screen for defined and intuitive images and text. Integrated 4GB hard disk for filing media files and the programs back up.USB port for managing in a simple and efficient way multimedia files, programs and updates. Ethernet port for connecting the machine to the net.Complete With: -- Insulated sound enclosure over all trim stations with split dust hood, viewing windows. -- Actual Model is BIESSE AKRON 1330 A

BIESSE SPARK 3.3 Edgebander (Compact)0.4 mm to 3 mm Material thickness. Min. panel thickness 10 mm, max. panel thickness 40 mm. Min. panel width 90 mm, min. panel length 140 mm.Equipped with: -- 2 Liter Glue Teflon coated tank with quick heating system. -- Top pressure beam with manual adjustment through numerical read-out equipped with rubberized holddown wheels. -- Pneumatic Guillotine knife for automatic edge cutting with a max thickness of 3 mm with automatic “kickback"; of the edge. -- Adjustable edge pressure unit with (2) rollers: 1st roller motorized with separate adjustable pressure system; 2nd idle roller with separate adjustable pressure system. Workstations: -- Double Motor End Trimming Unit - 2 tilting motors HF 0.5 HP each. -- Top and bottom Trim with (2) HF motors, 0.75 HP (0.55 kW) each and micrometric adjustment with numerical read-out. Cutters with 3 mm radius with (4) knives. -- Top and bottom Buffing station. -- Material feed speed 12 MPM (39 FPM).

BIESSE - SKIPPER 100 L: CNC Machining Center (2-Head) -- SpecificationsFlexible "Top & Bottom" Machining Center that uses an innovative Panel Handling System. -- Workable Part SizeX-Axis: 118" (3,000 mm); Y-axis: 39.4" (1,000 mm); max. part thickness: 2.4" (60 mm).Min. X-axis workable part size: 3-1/2" (90 mm); Y-axis: 2.7" (70 mm); Z-axis: 0.3" (8 mm). -- WorktableAutomatic LH Infeed Transfer Conveyor with: Belts & rollers; automatic RH outfeed transfer conveyor with: Belts & rollers; infeed/outfeed table is "robot ready". -- Positioning SpeedX-Axis: 394 FPM (120 MPM); Y-axis: 295 FPM (MPM); Z-axis: 98 FPM (30 MPM). -- Boring Units (1) Top mounted boring block: 4.2 HP (3 kW); 4,000 RPM; (29) vertical spindles; (17) spindles in X-axis & (12) spindles in Y-axis. -- (10) Horizontal spindles: (4 + 4) Spindles in X-axis; (1 + 1) horizontal spindles in Y-axis. -- (1) X-Axis grooving saw with: 2.2 HP (1.7 kW) motor - 5,000 RPM; 150 mm dia. blade. -- (1) Bottom mounted boring block: 4.2 HP (3 kW) - 4,000 RPM; (29) vertical spindles; (17) spindles in X-axis; (12) spindles in Y-axis. -- (10) Horizontal spindles: (4 + 4) Spindles in X-axis; (1 + 1) horizontal spindles in Y-axis. -- (1) X-Axis grooving saw with: 2.2 HP (1.7 kW) motor - 5,000 RPM; 150 mm dia. blade. -- Machining(1) Top mounted 4.8 HP (3.5 kW) electrospindle; 7,000 - 18,000 RPM with: RH/LH rotation; HSK D-50 adaptors for manual push button "quick-tool" change; ERC-32 tool holders; RC-32 collets. -- (1) Bottom mounted 4.8 HP (3.5 kW) electrospindle: 7,000 - 18,000 RPM with: RH/LH Rotation; HSK D-50 adaptors for manual push button "quick-tool" change; ERC-32 tool holders & RC-32 collets. -- Operator InterfacePC Front-End with: BIESSE "NC 1000" + Windows "BIESSE Work" Operating System; 15" color monitor; international keyboard with soft-touch keypad; industrial mouse.RS-232 serial ports for possible downloading from an office PC; USB ports; (1) 48x CD ROM drive; all mounted in a separate control console with: Built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with:Universal transformer for voltages from: 200 - 600 Volts, 50/60 Hz, 3-Phase; automatic lubrication system for guides & ways; sound enclosure and complete set of safety fences/devices; machine docs & manuals. -- Options include:"BiesseWORKS Advanced" Office version with: (2) Hardware keys; pneumatic part clamping with motorized infeed & outfeed transfer conveyors.Software Disclaimer: EX-FACTORY INC. Offers NO warranty or support, written or implied, concerning any/all "optional" or "additional" manufacturer or 3rd party software supplied with this machine. All software related issues including relicensing fees/requirements/functionality & training is ultimately the sole responsibility of the "Buyer".Bottom spindle or drive needs to be repaired NOTE: Teardown and loading not included.

Working Capacity: "X axis 125.9" (3,200 mm), "Y" axis 52" (1,320 mm), "Z" axis stroke 13.7" (350 mm), max material thickness 9.6" (245 mm). Positioning speed:"X" 262 FPM (80 MPM), "Y" Axis 196 FPM (60 MPM), "Z" axis 98 FPM (30 MPM) AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. Work Table:(6) Tube-less panel supports with lifting bars for heavy panels, (3) ATS vacuum pods per panel support (6) Pneumatic back stops, (6) pneumatic front stops, (2) pneumatic side stops & (2) pneumatic central stops. Boring Unit:4 HP (3 kW) motor with variable speed from 1,500 - 7,500 RPM; (18) "Quick Change" independent vertical spindles with (9) spindles in "X" axis & (9) spindles in "Y" axis;(8) horizontal boring spindles with (2+2) in "X" axis & (2+2) in "Y" axis;(1) 0° - 90° NC controlled "X"-"Y" Axis grooving saw for max 200 mm dia saw blade. Machining:(1) 17 HP (13 kW) Liquid Cooled "HSD" electro-spindle router with HSK F63 adaptor, variable speed from 3,000 - 22,000 RPM;(26) Total ATC positions with (1) 8-Position ATC tool plate located on the machine head for "on the fly" ATC Operator & Machine Control:PC Front End: Biesse "BH 600" + BiesseWORKS Advanced + WINDOWS "XP" operating system,15" TFT monitor, full standard keyboard & mouse, CD ROM disk drives,RS 232 & USB ports, Ethernet connection, specific function controls & and internet trouble shooting capabilities;Control cabinet with air conditioning & dust free environment. "Biesse WORKS" is a multitask operating system, input/output modules, axes override, 4-axes interpolation, diagnostic graphics aid for programming, machine data & tool management. Complete with:(1) 250 m³/Hr vacuum pump; automatic lubrication system; original documentation; hand held pendant; safety fences & mats; scrap conveyor;

BIESSE - ROVER A 3.65 FT: Flat Table Machine (w/ATC/Boring) -- Specifications4' x 21.3' with (2) 10' Long Flat Table Workstations: "GANTRY TYPE" "Phenolic" Table machine for Nested Base Manufacturing. -- Working Capacity"X" Axis: 254" (6,450 mm); Any unit; "Y" Axis: For routing; 51" (1,290 mm); "Y" Axis: Vertical drilling, 57" (1,436 mm); "Z" Axis: Stroke, 7.9" (200 mm); max. material thickness: 6.2" (160 mm). -- Positioning Speed"X" & "Y" Axis: 262 FPM (80 MPM); "Z" Axis: 82 FPM (25 MPM); helical rack & pinion drive on "X" Axis; ball screw: "Y" & "Z" Axis. -- WorktableFlat table designed for: "Nested Base Manufacturing", (2) independent vacuum zones and working areas.(16) External pop-up reference pins with: (2) On RH side; (2) on the LH side; plus (6) on the front of the table & (6) on the back of the table.Prepared for (optional); "Quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick connect" vacuum outlet for custom vacuum fixtures. -- Boring UnitBoring Head with: (7) Independent vertical boring spindles in "X" axis. -- Machining(1) 16.1 HP (12 kW) Liquid-cooled electrospindle with: HSK F63 Adaptor; 14 kW inverter; 1,000 - 24,000 RPM with max. torque from: 12,000 - 24,000 RPM.(1) 10-Position "Ride-Along"; gantry mounted automatic tool changer. -- Operator InterfacePC Front-end with: BIESSE "XP600" + "BiesseWorks" + Windows "XP Professional" Operating System; 15" color monitor; international keyboard; soft touch keypad; Industrial mouse; RS-232 serial port; (1) 1.44 MB; CD ROM disk drive.BiesseWorks: Easy Operating System for real-time multitask processing; programs can be transferred via diskette or downloading by wire (is possible).Components housed: 1,500-Watt Air conditioner control cabinet for constant temperature control & dust free environment. -- Complete with:(1) 300 cbm/Hr Vacuum pumps; centralized manual lubrication system for guides & ball screw; safety mats; Emergency Stop rope; protective head enclosure with debris curtain around bottom edge. -- Actual Model: BIESSE ROVER A 3.65 FTNOTE: Machine runs, was in use until taken from production. It has had occasional program stoppage mid run, once reset runs well quite a few cycles before stoppage.

BIESSE - AKRON 1440A: Single Side Edgebander (2/Premill & Corner Rounding) + with "AIR FORCE" PUR & EVA Technology -- SpecificationsLatest Technology combines: Productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" Emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. The layer is activated & bonds the banding to the panel fibers. This technology allows changes based on banding colors without any setup.Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. Also featured is a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Working Capacity: -- Min. panel height: 10 mm; Max. panel height: 60 mm; height of edgebanding material: 14 - 64 mm; thickness of edgebanding material in rolls: 0.4 - 3 mm; thickness of edgebanding in strips: 0.4 - 10 mm.Min. panel protrusion from the track: 25 mm; Panel length: 140 - 3,200 mm; min. panel width (with length 140 mm): 85 mm; min. panel width (with length 250 mm): 50 mm.Multifeed speed: 8 - 12 - 15 & 18 MPM.Glue & Pressure Section -- Infrared lamp: IRL 700; Gluing unit: Quickmelt "QM 703 EVA" melting glue. - Special glue container for: PU glue; additional glue container: EVA Gluing unit with melting device.Additionally equipped with AirForce "VC-710": High pressure, hot air system to reactivate special precoated edge material (commonly referred to as laser edge).Automatic edge feed; cutter knife; pressure zone with: 1-Drive & 2 pressure rollers.Working Units -- Premilling unit: (2) x 0.8 kW - 12,000 RPM Motors; front/rear inclination: 0° - 15°. -- "RT 02": Gluing, edge feeding, and "VC-511" pressing unit. -- End trimming unit with: (2) x 0.8 kW - 12,000 RPM; front/rear; inclination: 0° -15°. -- Fine trimming unit: (2) 0.6 kW - 12,000 RPM Top/bottom. -- (2) Multifunction Corner Rounding units: 0.65 kW Each; for corner rounding; straight workpieces; post and soft-forming 90° -180°. -- Edge Scraper unit. -- Glue Scraper unit. -- Buffing unit: (2) × 0.37 kW motors. Machine Features -- Belt pressure beam. The Top Presser comprises a rubber belt with a stainproof coating. The thrust exercised on the panel is provided by springs housed on technopolymer connecting rods. -- Auto-adjustment of infeed fence. -- Automatic track lubrication system with: Dynamic track absorption. -- Manual infeed system for narrow pieces. -- (1) Coil automatic edge feeding. -- Hybrid gluing head for: Granulated EVA & Polyurethane glue. -- Premelter "TM10" for: Polyurethane glue in cartridges. On-demand top loading pre-melter for PUR glues. -- Adaptive infrared lamp to heat up the panel side before the glue application, to optimize the adhesion process. -- Independent pneumatic exclusion of the top/bottom fine trimming unit. Operator Interface -- BIESSE Windows-based "Smart Touch" control & O

BIESSE ROVER A 2231 G FT FLAT TABLE MACHINE (W/LOADING, UNLOADING): -- Specifications:7' x 10' "Matrix" grid Phenolic surface for "Nested Base Manufacturing". -- Working Capacity: "X" Axis 122 (3,100 mm), "Y" axis 86.6" (2,200 mm), "Z" axis stroke is 12.7" (325 mm), max. material thickness 4.7" (120 mm). -- Positioning Speed: "X" axis 262 FPM (80 MPM), "Y" axis 197 FPM (60 MPM), "Z" axis 66 FPM (20 MPM). All axes movement is on precision linear guides & ways and controlled by digital, brushless AC Servo motors.All motion components are maintained by an automatic lubrication system. "X" & "Y" Axes use a precision rack & pinion system; "Z" axis uses precision ball screws. -- Work area:Flat table design with HI-FLOW, multi-zone Matrix" grid Phenolic surface for "Nested Base Manufacturing".Automatic NC controlled zoning of the vacuum table with (9) individual zones.(2) Pneumatic "side" pop-up reference stops, (4) pneumatic "back" pop-up reference stops, & (6) pneumatic "front" pop-up reference stops.Prepared for (optional) "quick fit" vacuum outlets for optional clamping of small or awkward shaped parts; with "quick connect" vacuum outlet for custom vacuum pods & fixtures. -- Boring Unit:(1) 2.5 HP (1.7 kW) Motor, variable speed up to 6,000 RPM: Boring block with (10) independent vertical spindles, (7) in "X" axis & (3) in "Y" axis;(1) "X" axis grooving saw for max 120 mm dia blade. -- Machining:(1) 18 HP (13.2 kW) Air cooled HSD Electro Spindle with HSK 63 adaptor, variable speed from 1,000 - 20,000 RPM.(1) 8-position ATC tool changer plate located at the back of the machine base.NC controlled presetting for the measurement of the tool length. -- Operator & Machine Control:PC Front-End with: BIESSE XP 660 + BiesseWORKS + WINDOWS WRT operating system.17" TFT Flat screen monitor; server, full keyboard, & mouse all mounted on a mobile cart; Ethernet connection capabilities.BiesseWORKS Graphic interface makes full use of the operating methods typical of the WINDOWS operating system: Assisted graphic editor used to program machining operations; programming, and guided creation of parametric macros.Import of CAD and other external software files in DXF & CID3 format; 3D simulation of the tool path, calculation of machining time & the ability to create rotate virtual faces. -- Complete with:(1) 900 m³/Hr Vacuum Pump; Safety mats & fencing; Tool touch-off probe for automatic program update according to the tool length.Automatic Lubrication System for linear guides, rack & recirculating ball screw. Tele-Service capabilities. -- Options Include: (1) NC Controlled infeed Scissor Lift table with vacuum loading; (1) Rake system; (1) NC controlled & powered belt outfeed table with vacuum sweeping system; (1) Additional NC controlled powered belt outfeed table; Bar code label printer. -- Actual Model is BIESSE ROVER A 2231 G FT

BIESSE - ELIX B: CNC Bore, Glue, and Dowel InserterBIESSE Drill & Dowel Inserter features: Single spindle for drilling; dowel insertion unit; glue injecting unit installed on a carriage moving in the X-axis.Position for drilling dowel insertion provided through simple programs through the NC control or third-party software. Operator Control interface is: Intuitive, user-friendly, and very easy to use. -- Specifications Max. parts length: 1,300 mm (51";); min. parts length:120 mm (4.7";); parts thickness: 10 - 40 mm (0.4"; to 1-1/2";). -- Positioning Speed "X" & "Y" Axis positioning speed: 40 MPM (131 FPM); "Z" axis has manual adjustment with: Max stroke of 40 mm (1.57").The working unit's travel on Precision machine ground ball screws; powered by brushless AC Servo motors. -- Worktable(4) Working Zones with: Center fence position in up mode; (2) large work zones in down position; (4) hold-down cylinders. -- Boring UnitDrilling Unit. High-speed unit with: 6,000 RPM spindle; max. drilling depth of 30 mm (1-1/4"); max. drill bit dia.: 12 mm (0.47"); manual adjustment of depth with: Digital indicator. -- Dowel Insertion UnitDowel prepositioning ensures high repeatability of inserting dowels for each hole; distance between the dowel insertion unit and the drilling spindle: 32 mm (1.3") for simultaneous drilling; dowel insertion when holes are spaced at 32 mm; standard dowel dimensions: 8 x 30 mm; Max. dowel projection: 14 mm (0.551"). Glue Tank: Holds up to 8 liters (3.1 gallons) of glue; max. glue density: 900 CPS. - Glue inserting unit: Flow sensor and electronic adjustment of the amount of glue. -- Operator InterfaceIndustrial Numerical Control with: Extremely simple Program Editor; macro & parametric programming. Icon driven. -- Includes: Original Factory Machine Documentation. -- Actual Model: BIESSE ELIX B

BIESSE ROVER B 7.65 R FTK FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:5' x 20' Flat table design for "Nested Base" processing: Working field; "X" axis 240" (6,095 mm), "Y" axis 61.4" (1,552 mm), "Z" axis stroke is 7" (180 mm); max material thickness 5.9" (150 mm). -- Positioning Speed:"X" & "Y" axis 262 FPM (80 MPM), "Z" axis 98 FPM (30 MPM); "X" axis uses a helical rack & pinion system, "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides & ways & controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Work Table:Phenolic "MATRIX" grid vacuum table for FT "Nesting" or single part processing using (optional) pods or jigs; (1+1) side pop-up pins for easy material location. -- Boring Unit:(1) 2.5 HP (1.7 kW) - 4,000 RPM motor: (14) independent vertical spindles, (7) in "X" axis & (7) in "Y" axis; (4) horizontal spindles with (1+1) in "X" axis & (1+1) in "Y" axis. -- Machining unit:(1) 16 HP (12 kW) liquid cooled electro-spindle with HSK-F63 adaptor, variable speed from 1,000 - 24,000 RPM; (1) 12-position ride along tool changer for "on the fly" ATC. -- Operator Interface:PC Front End Controls with Biesse "NC 1000" + WINDOWS "XP" operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:(2) 10 HP (7.5 kW) BUSH vacuum pump; original manuals & documentation; safety fencing & perimeter devices. -- Actual Model is Biesse Rover B 7.65 R FTK.

BIESSE AKRON 1440 SINGLE SIDE EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + with "AIR FORCE" PUR & EVA TECHNOLOGY: -- Specifications: Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers. This technology allows changes based on banding colors without any setup.Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Working Capacity: -- Min. panel height: 10 mm; Max. panel height: 60 mm; Height of edgebanding material: 14 - 64 mm; Thickness of edgebanding material in rolls: 0.4 - 3 mm; Thickness of edgebanding in strips: 0.4 - 10 mm.Min. panel protrusion from the track: 25 mm; Panel length: 140 - 3200 mm; Min. panel width (with length 140 mm): 85 mm; Min. panel width (with length 250 mm): 50 mm.Multi-Feed speed 8-12-15 &18 MPM.Glue & Pressure Section: -- Infrared lamp IRL 700; Gluing unit Quickmelt QM 703 EVA melting glue. Special glue container for PU glue; Additional glue container for EVA gluing unit with melting device.Additionally equipped with the AirForce "VC-710", High pressure, hot air system to reactivate special pre-coated edge material (commonly referred to as laser edge.Automatic edge feed; Cutter knife; Pressure zone with 1-Drive & 2 pressure rollers.Working Units: -- Pre-milling unit with 2 x 0,8 kW, 12000 RPM motors, front/rear inclination 0° -15°. -- RT 02; Gluing, edge feeding, and pressing unit VC-511. -- End trimming unit with 2 x 0,8 kW, 12000 RPM, front/rear, inclination 0° -15°. -- Fine trimming unit 2 × 0,6 kW, 12000 RPM top/bottom. -- (2) Multifunction Corner Rounding unit, 0,65 kW each, for Corner Rounding, Straight Work pieces, Post and Soft-Forming 90° -180° degrees. -- Edge scraper unit; -- Glue scraper unit; -- Buffing unit 2 × 0,37 kW motors. Machine Features: -- Belt pressure beam. The top presser comprises a rubber belt with a stain-proof coating. The thrust exercised on the panel is provided by springs housed on techno polymer connecting rods. -- Auto adjustment of in feed fence. -- Automatic track lubrication system with dynamic track absorption. -- Manual infeed system for narrow pieces. -- One coil automatic edge feeding. -- Hybrid gluing head for granulated EVA and Polyurethane glue. -- Pre-Melter TM10 for Polyurethane glue in cartridges. On-demand top-loading pre-melter for PUR glues. -- Adaptive infra-red lamp to heat up the panel side before the glue application, in order to optimize the adhesion process. -- Independent pneumatic exclusion of the top/bottom fine trimming unit. Operator & Machine Control: -- Biesse, Windows-based "

BIESSE - SKIPPER 100 L, ...CNC Machining Center (2-Head): -- SpecificationsFlexible "Top & Bottom" Machining Center that uses an innovative panel handling system. -- Workable Part Size"X" Axis is 118" (3,000 mm); "Y" axis is 39.4" (1,000 mm); max. part thickness of 2.4" (60 mm).Min. workable part size in "X" axis is 3-1/2" (90 mm); "Y" axis is 2.7" (70 mm); "Z" axis is 0.3" (8 mm). -- WorktableAutomatic LH infeed transfer conveyor with: Belts & rollers; Automatic RH outfeed transfer conveyor with: Belts & rollers; Infeed/outfeed table is: "Robot Ready". -- Positioning Speed"X" Axis is 394 FPM (120 MPM); "Y" axis 295 FPM (MPM); "Z" axis is 98 FPM (30 MPM). -- Boring Units (1) Top mounted boring block: 4.2 HP (3 kW) - 4,000 RPM; (29) vertical spindles: (17) Spindles in "X" axis & (12) spindles in "Y" axis. -- (10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis. -- (1) "X" Axis grooving saw with: 2.2 HP (1.7 kW) Motor - 5,000 RPM; 150 mm dia. blade. -- (1) Bottom mounted boring block: 4.2 HP (3 kW), 4,000 RPM; (29) Vertical spindles: (17) Spindles in "X" axis & (12) spindles in "Y" axis. -- (10) Horizontal spindles: (4 + 4) Spindles in "X" axis & (1 + 1) horizontal spindles in "Y" axis. -- (1) "X" Axis grooving saw with: 2.2 HP (1.7 kW) Motor - 5,000 RPM; 150 mm dia. blade. -- Machining(1) Top mounted 4.8 HP (3.5 kW) electro-spindle; 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change; ERC-32 tool holders & RC-32 collets. -- (1) Bottom mounted 4.8 HP (3.5 kW) electro-spindle; 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick tool" change; ERC-32 tool holders & RC-32 collets. -- Operator InterfacePC Front-End with: "BIESSE Work" + Windows Operating System; 15" color monitor; international keyboard with soft touch keypad & industrial mouse.RS-232 Serial ports for possible downloading from an office PC; USB ports; (1) 48x CD ROM drive; all mounted in a separate control console with: Built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with:Universal transformer for voltages from: 200 - 600 Volts, 50/60 Hz, 3-Phase; automatic lubrication system for guides & ways; sound enclosure and complete set of safety fences/devices; machine docs & manuals.

BIESSE/ARTECH - SEKTOR 470 (SELCO SK4): Front Load, Automatic Panel Saw -- SpecificationsWorking capacity: 149.6" (3,800 mm) Max. rip cut cap. & 149.6" (3,800 mm) max. pusher stroke; 3.54" (90 mm) max. saw blade projection; 15 HP (11 kW) main & 3.6 HP (2.6 kW) scoring motor. -- Saw CarriageFeed speed from: 3 - 394 FPM (1 - 120 MPM); return speed: 394 FPM (120 MPM); automatic cutting length limiter adjusts the cutting length at the end of the workpiece; automatic saw carriage lubrication. -- Pusher Fence 196 FPM (60 MPM) Forward positioning speed; 196 FPM (60 MPM) return speed; rack & pinion movement on both sides to assure the pusher remains parallel. (7) Material gripper clamps open to 3.34" (85 mm). -- Operator InterfacePC Front-End controller: 19" Monitor display with real-time graphics: Virtually unlimited program storage via disk drives; function control keypad; USB & RS-232 serial port; keyboard, mouse & CD ROM drive.Diagnostic for errors or machine malfunction by means of an error signal code; incremental or absolute programming in mm or inches."Quick Opti" Software for optimization of cutting patterns directly on machine; all enclosed in an air-conditioned control cabinet. -- Complete with:Automatic side aligner device: 0 to 114" Stroke; automatic saw blade height adjustment; "PROLOCK" quick-change blade system; (3) air support tables: 78" x 24" (1,981 x 609 mm). -- Actual Model: BIESSE/ARTECH - SEKTOR 450 (SELCO SK4)

BIESSE - ROXYL 5.5: Edgebander (w/Premill & Corner Rounding)SpecificationsEdgebanding Cap. - Edge thickness for strips: Min./max.: 0.4 - 22 mm (0.02" - 0.87"); coiled material from: 0.4 - 3 mm (0.02 - 0.12"); panel thickness from: 10 - 60 mm (0.39 - 2.36"); workpiece width; Min.: 85 mm (3.34"); workpiece length min.: 140 mm (5.51"); feed speeds: 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). Machine Interface -- "Roxyl-Matic" Automated machine setup; MS/Windows XP Operating System; floppy drive; 4 GB HD; USB port, keyboard, and mouse interface. -- Flat-Screen (17") with Color graphics interface: Programs can be easily created & recalled at will; graphic interface makes programming easy: Icon of each unit may be brought up on the screen to show the Operator the status of the unit & parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine Infeed Configuration -- Premilling Station "FL-502". (2) LH & RH Rotating NC controlled spindles with: Automatic center positioning. -- Anti-Adhesive: "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to workpiece surfaces. -- Infrared Heating Lamp. Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine. Automatic for processing coiled & strip edgebanding material. -- Pressure Section Servo controlled programmable pressure section with: (1) Large driven roller and (4) idle rollers.Gluing System -- EVA (Hot Melt) "QM-705" Quick premelting granulate with: Glue roller applicator to cover conventional edgebanding material. Workstations -- End Trimming Unit "IN-801": Front & Rear trimming motors; unipoint swivel: 0° - 15° Bevel; programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors. -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled: (2) Servo motors (one for horizontal tool position; one for tool up/down position); uses combination bevel/radius/flush insert knives; prepositioning of motors by pneumatic air cylinders. -- Corner Rounding Unit "CR-202": (2) Motors for front/back corner and upper & lower edge profiling. -- Profile Scraping Unit "RBK-503": Top/Bottom 2-axis NC programmable knife positioning (i.e. 2 - 3 mm radius) for PVC edges. -- Glue Scraping Unit "RCC-701": Flat top/bottom; digital positioning indicators; pneumatic controlled for in/out position. -- Buffing Station "SP-501" Top & Bottom buffing motors with: 150 mm (6") Cloth buffing wheel diameter; adjusts in multiple directions. -- Edge Reactivation Unit "PH-700": Top/Bottom hot air blowers to restore original color to profile scraped PVC edge material.Complete with: -- Top Pressure Beam with: Driven flat belt & programmable height positioning.Includes: Multi-Tap Transformer. - Sound Hoods with interior lights. - Outboard panel support.
