Equipment For Sale

HOLYTEK - YRT 100: Round End Tenoner -- Twin positioning tables with: Traversing single cutterhead design; fully automatic work cycle; tables alternate into the cutting cycle for continuous operation; rotational movement of cutterhead is externally adjusted. Capacity: -- Width of tenon: 0" - 3.9" Plus both radii; thickness of tenon: 1/8" - 1-3/16"; depth of tenon: 3/8" - 1-3/4"; 1/4" - 3-1/2" with special tooling. Specifications: -- Belt driven cutterhead, 3 HP - 6,000 RPM spindle; 1 HP motor with variable rotational movement of cutterhead; straight, simple or compound angles are easily adjusted with tables. -- (2) 14" x 9" Tilting tables: 0° - 15° Up, 0° - 30° down, and 0° - 20° to the side; each table with: Pivoting fences & miter gauges, vertical height adjustment. -- Overhead pneumatic holddowns. -- Production rate approx.: (13) Pieces per Min.

HOLYTEK - KL-36PC, ...2-Head Sander 2-Head Planer Sander 36" with planer head & combination head.Description: -- Planing Head (P): 6'' Dia. made of steel with spiral design for heavy stock removal. 228 TCT Tips: 15 x 15 x 2.5 mm; each disposed on (6) rows. Each knife has: (4) Usable cutting edges; easy access to planing head for tips rotation or replacement. -- Precise dial indicator showing the exact positioning of the sanding pad; quiet & smooth oscillation! Pneumatic oscillation system controlled electronically by an infrared system, which is not affected by dust. -- Combination Head: (1) Drum & (1) sanding pad (C) for superior quality of finishing. Sanding belt with: 120 or 150 Grit; allows finishing sanding in a single pass. -- Elevation Table: (4) Screws. -- Infeed roller table extension: 15-3/4". -- Outfeed roller table: 15-3/4" with (2) Rollers. -- Centralized Control Panel with: Electronic digital readout (Metric or Imperial) for elevation; precise positioning at the elevation requested. -- Ammeter indicating: Electrical intensity on the spiral cutterhead and the combination head motors. -- Electrical box with: CSA Approved electrical components ensuring maximum dependability and an outstanding long-lasting performance.Specifications -- Spiral cutterhead motor: 20 HP - 600 V; 60 Hz - 3 Ph. -- Combination head motor: 15 HP - 600 V; 60 Hz - 3 Ph. -- Table elevation motor: 1/4 HP - 600 V; 60 Hz - 3 Ph. -- Feed motor: 2 HP - 600 V; 60 Hz - 3 Ph. -- Spiral cutterhead dia.: 6''. -- TCT Tips dim.: 15 x 15 x 2 mm (228); (6) rows. -- Max. working width: 36". -- Min. working length: 12". -- Max. working thickness: 5". -- Sanding belt dim.: 37" x 75". -- Dust hoods dia.: 4'' x 2 & 5" x 2. -- Machine dim.: 71" L x 76" W x 77'' H. -- Net weight: 1,450 kG or 3,190 Lbs.

HOLYTEK HP-11P Horizontal Resaw -- Hydraulic Feeding conveyor, hydraulic pump with 3 HP motor -- Main saw motor 20 hp. Specifications: -- Working width capacity 12“ (300 mm) -- Variable Feed Speed 0- 17 m/min (0 to 55 FPM) -- Thickness capacity 4mm to 125 mm (.11/8" to 4.92") -- Conveyor tilting 0 ° to 7° -- Electroni display of cutting height -- Blade Capacity 4270 X 25 X 0.89 mm. -- Wheels Diameter 725 mm -- Return conveyor on machine top

Holytek 37DA Wide Belt Sander (2) Heads37" Width cap Drum, Combination Head1st Head: 7" Dia. spiral grooved rubber covered contact roller, 20 HP motor;2nd Head: Combination sanding head with 5" dia. spiral grooved rubber covered contact roll & 2" wide polishing platen, 15 HP motor.Specifications -- Abrasive belt size of 37" x 60" -- Pneumatic belt tensioning and electronic abrasive belt tracking -- 12" min. working length. -- 2 HP Conveyor belt motor, -- Variable feed speed from 13 - 52 FPM,Equipped with & Features -- Infeed & outfeed rubber covered holddown rolls; -- 0" - 4" motorized thickness adjustment by 0.5 HP motor. -- Safety stop bar, emergency rail stop across the front of conveyor -- Motor load meters.

HOLYTEK SS-512 TS Shaper with Tilting Spindle, and Power FeederSpecifications: -- 1-1/4" Interchangeable spindle, 7.5 HP motor with (5) spindle speed settings of 3,000 - 4,000 - 6,000 - 8,000, & 10,000 RPM. -- Approx. 6" max. cap. under nut, 31" x 39" cast iron table. -- Insert ring diameters 2.8", 4/3", 6" and 8". -- Tilting spindle +10° and -45° -- Vertical movement of the spindle 7" -- sliding tableComplete with: -- Reverse rotation switch, adjustable fence assembly, and dust hood. -- 3-Roll Power Feeder

HOLYTEK - HRS-12TK, ...Straight Line Rip SawSpecifications: -- Overhead saw arbor, 15 HP motor belt driven, 4,500 RPM arbor. -- 12" Dia. max. saw blade. -- 3-3/8" Max. depth of cut. -- 18" Max. throat depth. -- 2 HP Stepped feed speeds of 50 - 65 - 83 - 100. -- Automatic lubrication of chain. -- Magnetic controls. -- Saw is glue line rated.Equipped with & Features: -- Overhead holddown rolls. -- Double-row of antikickback fingers. -- (6) Pressure rollers. -- Infeed adjustable fence line. -- Cast Iron table with rip fence.

HOLYTEK MHB 242 Top/Bottom Wide Belt SanderHeavy-duty and powerful double surface sander providing significant time saving and improved productivity.Smooth and quiet oscillation. Belts oscillation controlled electronically by an infrared system which resists dust.Pneumatic sanding belts tensioning ensuring fast and easy belt replacement.Independent motor for each sanding belt.Pneumatic disc brake system automatically activated if power supply is interrupted, thus preserving the sanding belts from being damaged. Top and bottom 24" wide belt sanderFeatures: -- Spiral grooved 8" (D) rollers (R) and 3-1/2" (D) rollers (K) keep the sanding belts cool. -- Sanding belts: 75" Long. -- Elevation of table with digital readout and activated by independent motor. -- Control panel with: Ammeters indicating main motors current. Specifications: -- Upper Drum motor: 15 HP; 600 V; 60 Hz - 3-Ph. -- Upper Combination head motor: 10 HP; 600 V; 60 Hz - 3-Ph. -- Lower Drum motor: 15 HP; 600 V; 60 Hz - 3-Ph. -- Lower Combination head motor: 10 HP, 600 V, 60 Hz - 3-Ph. -- Feeding motors: 2 HP (x2). -- Table elevation motor: 0.5 HP. -- Electrical intensity: 53 A. -- Drums: 8" (D) - 75 DUROS. -- Max. working width: 24". -- Min. working length: 13-3/4". -- Working thickness: 3/16" ~ 5" -- Sanding belts dimensions: 25" x 75". -- Variable feeding speed: 8 - 16 MPM. -- Dust hoods Top: 4 x 4"(D); Bottom: 3 x 4"(D). -- OAL 127" x 70" x 75" high. -- Weight: 9,460 Lbs.

Holytek heavy duty band vertical resaw Model# HB-900H

Holytek heavy duty band vertical resaw

HOLZ-HER 1270 Automatic Panel Saw w/Supercut Scoring75" x 169" Cap., 4 HP motor, 2" depth of cut, 220 mm (8-5/8") dia. saw blade at 6,640 RPM.Features: -- Saw head traverses automatically when rip or crosscutting and returns to starting position; (2) cycle lengths for long or short panels. -- 36 & 72 FPM saw carriage travel speed, 0.75 HP feed drive; -- Automatically moving back grid w/interlocks. Complete with: -- Rip gauge with (3) cam settings. -- (2) Gauging bars throughout frame length with (2) flip stops. -- Bottom rollers for easy movement of larger panels.Includes: -- Spare Blades.

HOLZ-HER 1270 Automatic Panel Saw w/Supercut Scoring75" x 169" Cap., 4 HP motor, 2" depth of cut, 220 mm (8-5/8") dia. saw blade at 6,640 RPM.Features: -- Saw head traverses automatically when rip or crosscutting and returns to starting position; (2) cycle lengths for long or short panels. -- 36 & 72 FPM saw carriage travel speed, 0.75 HP feed drive; -- Automatically moving back grid w/interlocks. Complete with: -- Rip gauge with (3) cam settings. -- (2) Gauging bars throughout frame length with (2) flip stops. -- Bottom rollers for easy movement of larger panels.

HOLZ-HER ACCURA 1556 4.0 PREMIUM EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + GLU-JET EVA & PUR GLUING TECHNOLOGY:Specifications: -- Working Capacity: Edge thickness min./max. 0.4 - 3 mm (0.02 - 0.12") for coiled material, 15 mm (0.59") 1/2"+ max for strips.Panel thickness 8 - 60 mm (0.315" - 2.36"); workpiece width min. 60 mm (2.36"); workpiece length min. 140 mm (5.5"); Feed speed 10 - 20 MPM (33 - 66 FPM).Machine In-Feed Configuration: -- Pre-Milling Station "1802": 2 x 1.2 KW (1.6 HP) - 12,000 RPM motors; Diamond cutter-heads with ProLock quick clamping system. Quick-Lock adjustable in-feed fence with digital indicator. -- Edge Magazine "1901": for coil and strip processing, utilizing motion detector to ensure accurate, trouble-free positioning of edge material; exclusive "Tractor-Belt feed System", edge guide equipped with automatic guillotine lock-out for safety, 3° approach angle allows easy feeding of solid wood edges. -- Pressure Section "DW 701": with (1) large driven (synchronized with feed-speed) roller and (2) cantered idle rollers, adjustable by hand wheel and scale. -- GLUING SYSTEM "GJ 301" (Glue Jet)... Processes "EVA" or "PUR" Glue in Cartridge or Granulate Form, granulate requires an "optional" hopper. Upper glue line height positioning is set automatically with hold-down beam setting. Heat-up time to ready stage takes only 2 - 3 minutes!Additionally equipped with "iTRONIC" Adaptive pressure and glue quantity control for intelligent automation. Adaptive trimming blade. Automatic glue quantity control. Adaptive pressure unit control. Automatic cleaning routine. Remaining glue quantity indicator.Workstations: -- End Trimming Unit "KA 702": Front & rear 2 x 0.45 KW (0.6 HP) - 9,000 RPM motor each, uni-point swivel-axis for no re-indexing when changing from flush to bevel end trim (0° - 10° bevel),"PCS" programmable pneumatic change-over from flush to bevel. -- Flush Trimming Unit: Top & bottom Flush 15 mm unit; 2 x 0.65 KW (0.88 HP) - 12,000 RPM, each motor. -- Fine/Bevel/Radius Combination Trimming Unit "FR 701": Radius 2 mm trimming, servo controlled, 2 @ servo motors (1) for horizontal copy wheel & (1) for tool spindle position) programmable top & bottom unit 2 x 0.65 KW (0.88 HP) - 12,000 RPM each motor.Uni-Point design with no second adjustment, pneumatic, programmable tilt action for changing the degree of bevel, digital counters for vertical copy wheel position and pneumatic air cylinder for in/out pre-positioning of trimming motor. -- Corner Rounding Unit "FF 701": (4) Motors 0.22 KW (0.30 HP) - 9000 RPM for up to 3 mm edge thickness and work-piece thickness min./max. 12 - 60 mm (0.473 - 2.362"), max. feed speed 10 MPM (33 FMP). -- Profile Scraping Unit "ZK 501": Top/Bottom, servo motor controlled/programmable knife position, vertical copy wheel adjustment with quick setting spindle.For PVC edges, reversible insert carbide knives, equipped with air-jet blowers and chip collector box. -- Glue Scraping Unit " FK": Flat surf

HOLZ-HER ARTEA 1020 EDGEBANDER (W/PRE-MILLING): + "GLU JET" EVA/PUR GLUING TECHNOLOGY: -- Specifications:Features the HOLZ-HER Patented Dual "GLU-JET" EVA & PUR Zero Joint Technology System.Working capacity: Min./Max. 0.4 - 5 mm edge cap; 8 - 50 mm panel thickness; min. panel length 160 mm; feed speed: 9 MPM (29.5 FPM) single speed.Equipped with: -- Pre-milling: (2) Vertical spindles, counter rotating, and manually adjustable infeed fence. -- HOLZ-HER "GLU JET": Cartridge System and flat glue nozzle applicator; Glue heat up time: (2 - 3) minutes max! -- Pressure Section with: (1) Large dia. drive roller and (1) pneumatic pressure controlled idle rollers; horizontal adjustment w/digital indicator. -- Automatic Edge Magazine: For coil and strip feed.Workstations: -- End Trimming Unit: Single-motor end trims, travels on 45° slides; tilt from 0° to 15°. -- Multifunction Trimming Unit: Top & Bottom trim station for flush/bevel/radius with digital readouts. -- Profile Scraping Unit: Top & Bottom radius scraping unit with mechanical digital readouts positioning. -- Flat Scraping Unit: Top & Bottom flat glue/finish scrapers. -- Buffing Unit: Top & Bottom. Operator Interface: 15" Flat "Touch Screen" control. Programs can be easily created and recalled at will.The graphic interface makes programming easy; icons of each unit may be brought up on the screen to show the operator the status of the unit and the parameters that can be programmed.Edgebander can be operated manually when required, without the necessity to write a program.. Complete with: -- Safety/Sound Hood over all workstations, fixed panel support outrigger, manually adjustable hold-down beam. -- Original factory documentation; used tooling on the machine. -- Actual Model is: HOLZ-HER ARTEA 1020.

HOLZ-HER DYNESTIC 7532 FLAT TABLE MACHINE (W/LOADING, UNLOADING) -- Specifications:5' x 10' Phenolic MATRIX Table for "Nested Base" Manufacturing. -- Working Area:"X" Axis 1122" (3,100 mm), "Y" axis 61.45" (1,561 mm), "Z" axis stroke is 4.72" (120 mm). -- Positioning speed: "X" & "Y" Axis 230 FPM (70 MPM), "Z" axis is 65 FPM (20 MPM). -- Worktable: Flat table designed for "Nested Base Manufacturing";(4) Pneumatically controlled reference stop pins with (3) in "Y" axis & (1) in "X" axis. -- Boring Unit:2 HP (1.7 kW) motor for spindle speed from 1,000 to 6,000 RPM; (13) independent vertical boring spindles with (5+4) spindles in the "X" axis & (4+2) spindles in the "Y" axis;(4) Horizontal spindles with (1+1) in "X" axis & (1+1) in "Y" axis. -- Machining unit: (1) 15 HP (11 kW) Electro-spindle Router with HSK F63 adaptor, 1,000 - 24,000 RPM;(1) 14-position ATC tool plate for "on the fly" ATC. -- Operator & Machine Control: PC Front-End with Holz-Her "CAMPUS" V 7Basic Bundle + Windows operating system Intel Core i5-6600; 17" Color monitor; standard keyboard, mouse & CD ROM for data entry; (3) axes simultaneous control; feed rate and spindle speed override & axis movement.CAMPUS/NC Hops offers "Real Time" 2D or 3D graphics; Campus aCADemy is a full fledged, high-performance CAD/CAM software package with versatile import features. -- Complete with:(1) 25 HP BECKER Vacuum Pump; "forced" lubrication system for guides & ball screw; sound absorbing protective head enclosure. -- Options Include:(1) NC Controlled infeed Scissor Lift table with vacuum loading; (1) Rake system; (1) Outfeed table with vacuum sweeping system; Manual label printer at the outfeed table. Actual Model is HOLZ-HER DYNESTIC 7532.

HOLZ-HER LYNX 7511 FT FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:5' x 10' Phenolic "MATRIX" table for "Nested Base" Manufacturing. -- Working Field: "X" Axis 120" (3,050 mm), "Y" axis 62" (1,575 mm), "Z" axis stroke is 16-1/2" (419 mm), max material thickness 7" (180 mm). -- Positioning Speed: "X" & "Y" Axis 230 FPM (70 MPM), "Z" axis is 65 FPM (20 MPM). -- Worktable:Flat table designed for "Nested Base Manufacturing" with (3) "Y" axis pneumatically controlled reference stop pins. -- Boring Unit:2.3 HP (1.1 kW) motor for spindle speed from 1,000 to 6,000 RPM; (10) independent vertical boring spindles with (6) spindles in the "X" axis & (4) spindles in the "Y" axis; -- Machining: (1) 15 HP (11 kW) Electro-spindle Router, HSK F63 adaptor, 1,000 - 20,000 RPM; (1) 12-position tool rack for ATC. -- Operator & Machine Control: PC Front-End with Holz-Her "CAMPUS" + Windows operating system, 17" Color monitor; continuous graphical and barcode interface,BAUMULLER - PLC for (3/4) axes simultaneous control, feed rate and spindle speed override & axis movement. -- Complete with:(1) 250 m³/Hr BECKER Vacuum Pump; automatic "forced" lubrication system for guides & ball screw; sound absorbing protective head enclosure. -- Actual Model is HOLZ-HER LYNX 7511 FT.

HOLZ-HER - 1432, ...CP/B Edgebander (Compact) -- Cartridge glue system (single cartridge system); edge thickness cap.: 0.3 to 3 mm (1/8"); max. banding height: 2"; min. panel width: 60 mm; min. length: 180 mm.Equipped with: -- Semiautomatic feed magazine; coil stock feeds automatically with guillotine cutoff; all strip stock is fed manually with pusher bar to advance the edging.Workstations: -- Single motor end trim for leading & trailing edge (trim motor recently replaced). -- Top & bottom flush/bevel trim: 1 HP - 28,000 RPM Motor ea. (recently replaced with BOSCH Trimmer motors). -- Top & Bottom buffing unit: 0.3 HP - 1,620 RPM ea. motor; equipped with: Cotton flap wheels. -- Single feed speed: 16-1/2 FPM.Complete with: -- Sound/safety enclosure; outboard panel support. - Machine is on casters.

HOLZ-HER - ARCUS 1335: Edgebander (w/Premilling) -- Specifications Edgebanding cap. edge thickness: Min./max. 0.4 - 15 mm (0.016 - 0.59"); coiled material: 0.4 - 3 mm (0.016 - 0.157"); panel thickness: 6 - 60 mm (0.236 - 2.362").Workpiece width min.:60 mm (2.36"); workpiece length: min. 160 mm (6.29"); variable feed speed: 10 - 18 MPM (33 - 59 FPM).Machine Infeed Configuration -- Premilling Station: (2) 2.0 kW (2.68 HP) - 12,000 RPM motors; equipped with "ProLock" quick-change flange including height adjustment for optimum utilization of cutters. -- Edge Feeder Magazine: Small 3° feed angle thanks to nozzle design with easy feeding of coils; strips up to 3 mm & solid wood edging up to 15 mm (5/8"). Exclusive "Tractor-Belt Feed System": Edge guide equipped with automatic guillotine lockout for safety. -- 3 mm Guillotine: For up to 3 mm coiled & strip materials. -- Gluing Section: HOLZ-HER Patented cartridge system with unrivaled properties with: 95% Less energy consumption & 70% shorter heat up time of 205° Celsius in just 3-1/2 minutes.Changing glue types takes just a minute and no special tools are required for glue and color. All that is changed is the cartridge. The time-consuming cleaning procedure of the glue pot, previously essential, is no longer necessary. The patented HOLZ-HER Cartridge System is a practical solution. -- Pressure Section: (1) Large & (3) cantered driven pressure rollers for perfect glued joints.Workstations: -- Front & Rear End Trimming: (2) 0.35 kW (0.5 HP) - 9,000 RPM each motor for edge thicknesses up to 20 mm. -- Multifunction Top & Bottom Trimming Unit Manual adjustment: (2) x 0.65 kW (0.87 HP) - 12,000 each motor.Digital counters for vertical copy wheel position and pneumatic air cylinder for manual in/out pre-positioning of trimming motor. -- Top & Bottom Fine Trimming Unit Manual Adjustment: 2 x 0.65 kW (0.87 HP) - 12,000 each motor.Digital counters for vertical copy wheel position and pneumatic air cylinder for manual positioning of fine trimming motors. -- Top & Bottom Profile Scraping Unit: For PVC edges.Reversible insert carbide knives. -- Top & Bottom Glue Scraping Unit: Flat, top/bottom, ball bearing guided. -- Top & Bottom Buffing Station: Top & bottom buffing motors with 150 mm (6.0") cloth buffing wheel diameter; 1,440 RPM wheel rotation.Operator Interface: -- HOLZ-HER "Edge Control" Electronically controlled setup processes with ...100% repetition accuracy.Flat Screen 8.4" VGA Color Monitor: Dustproof soft key input panel surface; programs can be easily created and recalled at will; graphic interface makes programming easy.Icon of each unit may be brought up on the screen to show the Operator the status of the unit and the parameters that can be programmed; Edgebander can be operated manually when required, without the necessity to write a program. Programmable Logic Control (PLC) for Pre-milling: Edge feed, glue application, end trimming, flush trimming, radius trimming, scraping, corner

HOLZ-HER 1402 HF Compact EdgebanderFeatures: -- Cartridge glue system, 3 mm edge thickness cap., -- Semi-automatic feed magazine, coil stock feeds automatically with guillotine cutoff, all strip stock is fed manually with pusher bar to advance the edging.Digital glue height indicator.Workstations: -- Double motor end trim (1 HP - 10,500 RPM motor ea.) -- Universal top & bottom fine trim (1942M) for bevels from 0° - 15³; allows simultaneous bevel & profile trimming (1 HP - 18,000 RPM motor ea.; trim motors are 0.6 kW HF - 300 Cy). -- Top & bottom PVC scraper unit (1929) for 0.8 - 3 mm radius. -- Top & bottom buffing (1940), 0.3 HP - 1,620 RPM motor ea. -- Single feed speed of 35 FPM.Complete with: -- Fixed outboard panel support, frequency converter, sound enclosure, and used tooling.

HOLZ-HER DYNESTIC 7516 FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications: 5' x 10' MATRIX Table for "Nested Base" Manufacturing. -- Working Field: "X" Axis 122.2" (3,105 mm), "Y" axis 61.45" (1,561 mm), "Z" axis stroke is 16.5" (418 mm). -- Positioning speed: "X" & "Y" Axis 230 FPM (70 MPM), "Z" axis is 65 FPM (20 MPM). -- Worktable: Flat table designed for "Nested Base Manufacturing" with (4) pneumatically controlled reference stop pins. -- Boring Unit:2 HP (1.7 kW) motor for spindle speed from 1,000 to 4,400 RPM;(10) Independent vertical boring spindles with (6) spindles in the "X" axis & (4) spindles in the "Y" axis; -- Machining: (1) 15 HP (11 kW) Electro-spindle Router, HSK F63 adaptor, 1,000 - 24,000 RPM;(1) 8-Position ATC. (dynamic carrousel type) -- Operator & Machine Control: PC Front-End with: CAMPUS Version 6.3.0.3 (BECKHOFF CNC Version 2.3.7) machine control,17" Color Flat Panel Monitor; continuous graphical and barcode interface, (3) axes simultaneous control; feed rate and spindle speed override & axis movement. -- CAMPUS/NC Hops Software: This package provides the prerequisites for effective machining and convenient operation. Our ECO Mode automatic standby control is a standard feature on all HOLZ-HER CNC machining centers for software-controlled minimization of the power consumption.Campus aCADemy is a full-fledged, high-performance CAD/CAM software package with versatile import features. -- Complete With:(1) BECKER 250 m³/Hr vacuum pump; manual central lubrication pump for guides & ball screw; left & right-side safety enclosure; Hand Control, pendant for set-up and program try-outs -- Actual Model is HOLZ-HER DYNESTIC 7516 10.5.

HOLZ-HER - 1516 Case Clamp (Single-Bay) -- Specifications1-Bay Clamp; 100" x 50" x 24" clamping cap.; (1) movable, vertically positioned clamping beam with: (3) Horizontal clamps; (4) adjustable vertical clamps. -- Total of (14) pressure cylinders with: 3-7/8" Stroke & (4) adjustable counterpressure bars; 700 Lbs/cylinder pressure at 100 PSI compressed air; built-in controls with pressure gauge.
