Pallet Equipment For Sale

LHI AUTOMATIC RAKE FEEDER with the following equipment: -- Panel Feeder with up to 18' Long x 5' Wide x 1" Thick Sheet Capacity (with 4' min. sheet length) -- Feeder loads from right side when viewed from the End of the Scissors Lift -- Auto-cycle for Rake Feeder -- 6' Line-Up conveyor with Fence & Powered Pinch Wheel -- 8000 Lbs. Tandem Scissors Lift with 5' x 17' top, 600-Volt, 3-phase, 2 HP motor -- 5-Section Gravity Rollers on Scissors Lifts -- 12' Powered 5 Strand Chain Conveyor Feeds Tilt Lift w/forward/ reverse, jog controls -- Wired for 600-Volt/3-Phase/60-Cycle Operation (other voltages available) -- Arranged for Customer Provided MultiScore Panel Ripper with right side arbor loading

LHI MBR-10 ROLL FEED GANG RIPSAW: Saw arbor with 25 HP arbor motor (30 HP and 40 HP available, see Options for pricing).Specifications: -- 1-15/16" Saw arbor bearings and 10" usable arbor. 12" useable arbor available. Uses 12" dia. x 1-3/4" bore saw blades. -- 1/8" to 2" Max. cutting depth on hardwoods and softwoods; 18" minimum stock length; 17" maximum stock width; removable and replaceable phenolic throat plates. -- Unique “swing down arbor frame"; for easy and fast blade changing. Blades are positioned using spacers.Feed system with: -- (2) 1 HP Feed motors with constant feed speed to be determined from thickness of wood, type of wood, and maximum number blades (average speed is set at 80 FPM). -- (6) Non-marking steel drive rollers; top and bottom rolls are powered for superior feeding capabilities; hand crank for easy feed roll height adjustment. -- Includes safe, fully enclosed belt and chain guards and double anti-kickback device. Features: -- Simple design, low cost, high performance. -- High production, fast setup, workhorse. -- Off-The-Shelf Parts are found locally for ease of maintenance.Options: -- 30 HP arbor motor & starter, add $1,150, -- 40 HP arbor motor and starter, add $2,300, -- Variable Speed Drive with speeds from 10 to 100 FPM, add $2,450. -- 12" Useable arbor space, add $2,950. -- 12" x 24T Blade,1.75" Bore, $115 each. -- 12" x 30T Blade,1.75" Bore, $165NOTE: PRICING DOES NOT REFLECT Mfg's 7% MATERIALS SURCHARGE

LHI RFPR ROLL FEED PANEL RIPPER - "BUILT TO ORDER SYSTEM" with the following equipment: -- Ripsaw: -- 72" Arbor - 50 HP arbore motor and 14 to 80 FPM Variable Speed Feed Rate (4-speed programmable via VFD) -- (8) Polyurethane Feed Rollers -- Arranged for 10" dia. blades to rip panel thickness from 1/8" to 1-1/2"; -- Single Point Thickness Adjustment -- Quick-Change Arbor Kit Additional Arbor Setup Including: -- (1) Arbor Cart, (1) Blade Box, (1) Arbor Shaft, (1 set) Bearings, (1) Arbor Sheave, and (1) Throat Plate Rack Automatic Infeed System: -- 4,500 Lbs. Capacity Hydraulic Scissors Lift with (4) loading ramps to feed and align 4’ x 8’ sheets into Panel Saw -- 110VAC/1PH Scissors Lift power unit -- Auto-Cycling Rake Feeder -- 6’ Line-Up Conveyor With Power Pinch WheelOutfeed Scissors Lift: -- 4,500 Lb. Capacity Hydraulic Scissors Lift with 4' x 8' top, (3) support ramps/cross-bars to allow fork access -- 110VAC / 1Phase power unit -- Auto Down Indexing -- Auxiliary Foot Pedal Control Blades, Collars and Throat Plates: 10" x 40T x 4 3/16 Bore, TGC, $105 eachBlade Collars: 3-15/16" ID x 4.18" bore x 1.25" wide, $135 eachAluminum Throat Plates, $35 each TERMS AND CONDITIONS: -- Delivery: 16-18 Week ESTIMATED delivery date assumes your order is received within one week of date of this quotation. -- A 5% Tooling & Steel Surcharge to be added to the machinery price when the total is known -- Installation technical assistance, $125/hr. plus travel time and expenses (if required) -- Customer responsible for own rigging -- Quote assumes customer will deliver material for testing (if required) -- Warranty: 1-year mechanical parts (electrical controls excluded) -- FOB: Shannon, MS 38868. ESTIMATED SHIPPING DATE: 16 TO 18-WEEKS --The delivery date is quoted as “estimated"; because the equipment manufactured is built to our customer's specifications. This estimate is made under the assumption that there will be no interruptions of labor, material shortages, or any environmental or other unforeseen circumstances. -- LHI is not responsible for any installation or production costs resulting from actual delivery dates which exceed the quoted estimated delivery dates. Accurate dates for the delivery will not be available until the equipment is in the manufacturing phase. If there are custom features for the quoted equipment then accurate delivery dates will be available when testing is complete. Please consult with the factory for updates to the expected delivery date.NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LHI PIGTAIL Crosscut saw with conveyor and air stopSpecifications -- 62" Cut width --Saw motor 5 HP -- 14 FT gravity conveyor cutting surface -- Cam Lock adjustable stop -- Power feed wheel for rip saw infeed assist -- Blade dia. 12"Equipped with and Features -- 4,500 lb lift with loading ramps 1 HP, 30" X 72" platform -- 4,500 lb Outfeed lift with 3 ramps, 48" X 96" Platform, Auto down indexing -- 10" X 40T X 4-3/16" , 30 Blades -- 3-15/16" ID x 4.18" bore x 1.25" wide 30 collars -- 32 Throat Plates

Rip Saw Model SDL 1200 Edging Conveyor Model UHY 1900

MEREEN-JOHNSON Model 524-DDCSR 2+4 Double Arbor Gang Rip SawSPECIFICATIONS: -- First Arbor Arranged with Two (2) Independently Adjustable Select Saw Assemblies for Mounting Hogging Blades -- Second Arbor with Four (4) Independently Adjustable Select Saw Assemblies -- Arbor Space 24" -- Thickness Capacity to 1-3/4" with 12" Tooling and 2-3/4" Using 14" Tooling -- Minimum Length 30"Equipped with & Features -- Two (2) M-J Direct Drive Motors 75 HP Each -- Feed Motor 7.5 HP TEFC, 30' to 235' rate with Frequency Inverter Speed Control -- Saw Set Up for Second Party Optimizing System.

MEREEN-JOHNSON - 431DC, ...Gang Rip Saw: Specifications: -- 31" Arbor width cap., 14" max. dia. tooling, 3-1/2" max thickness. -- Motorized thickness adjustment. -- 29" Min. length for glue joint accuracy and 22" min. for busting only; 6" throat. -- 75 HP - 3,600 RPM TEFC direct drive motor. -- Arbor with disc brake & load meter. -- Arbor lockout on the access door.Equipped with & Features: -- Feed, Chain & Holddown. -- 5 HP Variable feed speed 30 - 150 FPM with adjustable jam protection. -- MEREEN-JOHNSON "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain. --"Quad Life" hardened dip cams. -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips. -- Automatic chain oiler with low-level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls. -- Full width spring loaded overhead bed plate. -- Pressure rolls & bed plate unit with powered adjustment; scale & pointer for thickness reference; -- Antikickback Finger System with: (1) Lower & (2) Upper on Infeed; (1) upper assembly on outfeed.

Mereen-Johnson 424 DCS Short Stock Gang Rip sawSpecifications -- 24" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max. manual thickness adjustment, -- 14" min. length for glue joint accuracy and 22" min. for busting only, -- 6" throat. Equipped with and Features -- 75 HP - 3,600 RPM TEFC Direct drive motor, -- 2-3/16" dia. arbor with disc brake, -- load meter and slip-off outboard bearing. -- Feed & chain: 3 HP Variable feed speed 30 to 170 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain -- "Quad Life" hardened dip cams -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips --, Automatic chain oiler. -- (4) 3" Dia. air loaded overhead pressure rolls; full width spring loaded overhead bed plate, -- Pressure rolls and bed plate unit with scale & pointer thickness reference; -- Anti-kickback finger system with (1) lower & (2) upper on infeed. -- Sound enclosure, -- (2) Upper dust hoods (1) 10" & (1) 5" dia. and (1) lower 4" dia. hood, -- Requires 3,820 CFM;NOTE: Laser Rack with 10 Lasers

The seller has confirmed that this Mereen Johnson 441 Rip saw is in great working/running cnodition and it is ready to load! - 2004 Cameron Auto Opti-Rip Infeed - Model: 34F-M1 - Serial: OR164 - 100% Servo (only Servo is this Cameron) - Full amp load 81 - 44" W bed - Up to 20 saws can be run on the arbor - No moving blades BUT there are moving lasers Although this one has been pulled from service, they have an identical one still running and available for inspection....

Mereen Johnson 424 Gang Rip Saw

Mereen-Johnson Model 441-DC Gang Rip Saw Capacity: Arbor space 41” Arbor Drive: 75 HP 3600 RPM TEFC motor Feed Drive: HP TEFC variable speed direct; 45’ to 225’ feet per minute Hold Downs & Bed Plate: Four 5” dia. Air loaded high yield idle press rolls Saw Sleeve: One 41” capacity sleeve Dust Collection: Four upper dust pick-ups: two (2) 8” dia., two(2) 4” dia., one lower 4”dia. Pick-up:(requires total 4820 CFM @ 5,000 feet per minute) Swing Arm & Tip-Up Cart: One floor mounted dual shaft swing arm and one tip-up saw sleeve set-up cart Electrical: Arranged for 3 phase, 60 cycle, 460V Cameron Automated Opti-Rip Model #34F-M1 System: Manufacture Year: (2004) Complete with length measurement Tally System 5 infeed belt and chains for feeding a Gang Rip saw up to 41” wide 16 width sensors 3 sets of pinch rolls for short stock 1 fixed & 4 movable laser lights This system feed for 4’ to 16’ max lumber length It feeds from operator right to left Wired 220V; If 440V required, a transformer will be needed

Mereen Johnson Gang rip saw

Mereen-Johnson 312-DC/SR2 Gang Rip Saw with Rip Navigator Scout InfeedSpecifications -- Arbor Space: 12" -- Thickness Capacity: Up to 3" (w/ 14" Blades) -- Minimum Length: 22" (30" for Glue-Joint) -- Two Shifting Blades -- 1"Minimum Net Rip Between Shifting Blades -- Machine-Mounted Laser Stand -- Arbor Motor: 50 HP, Direct-Drive -- Feed Motor: 3 HP -- Variable Speed Feed: 30 - 150 FPM -- "Posi-Feed" Friction Feed Chain w/ Aluminum Slats and Replaceable Rubber Inserts (Rubber Inserts are Brand New) -- Hardened Steel Feed Chains & Track w/ Oil Mist Lubrication -- Air-Loaded Press Rolls -- Single Lower, Double Upper Infeed Anti-Kickback Fingers w/ Single Upper OutfeedEquipped with & Features -- Rip Navigator Scout Arranged to Receive 17'-6" Maximum Length Boards from Scissors Lift Manually placed on Board Dealer ArmsIndividual Boards are Automatically Dealt onto Lateral Chains and Conveyed to a Board Stop -- Board Stop Queues Boards for Advancement to Disappearing Fence -- Automatic Adjusting Fence Positions Boards for Placement into Gang Rip Saw Fence Positioning Through Rip Navigator -- Fence Mounted Pinch Roll Feeds -- Board to Gang Rip Saw Mounted Power Table -- Voltage: 480 with Transformer (Original Voltage as built is 575) -- New Bearing in Saw Arbor -- New Rails for Scout Infeed Chains -- 5743 HOURS -- NEW IN 2013

Mereen-Johnson 424 Gang Rip sawSpecifications -- 24" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max. manual thickness adjustment, -- 14" min. length for glue joint accuracy and 22" min. for busting only, -- 6" throat. Equipped with and Features -- 75 HP - 3,600 RPM TEFC Direct drive motor, -- 2-3/16" dia. arbor with disc brake, -- load meter and slip-off outboard bearing. -- Feed & chain: 3 HP Variable feed speed 30 to 170 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain -- "Quad Life" hardened dip cams -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips --, Automatic chain oiler. -- (4) 3" Dia. air loaded overhead pressure rolls; full width spring loaded overhead bed plate, -- Pressure rolls and bed plate unit with scale & pointer thickness reference; -- Anti-kickback finger system with (1) lower & (2) upper on infeed. -- Sound enclosure, -- (2) Upper dust hoods (1) 10" & (1) 5" dia. and (1) lower 4" dia. hood, -- Requires 3,820 CFM;Also included: -- (7) laser with mounting rack -- (2) additional arbor and lots of spacers

MEREEN-JOHNSON - 431DC, ...Gang Rip Saw: Specifications: -- 31" Arbor width cap., 14" max. dia. tooling, 3-1/2" max thickness. -- Motorized thickness adjustment. -- 29" Min. length for glue joint accuracy and 22" min. for busting only; 6" throat. -- 75 HP - 3,600 RPM TEFC direct drive motor. -- Arbor with disc brake & load meter. -- Arbor lockout on the access door.Equipped with & Features: -- Feed, Chain & Holddown. -- 5 HP Variable feed speed 30 - 150 FPM with adjustable jam protection. -- MEREEN-JOHNSON "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain. --"Quad Life" hardened dip cams. -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips. -- Automatic chain oiler with low-level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls. -- Full width spring loaded overhead bed plate. -- Pressure rolls & bed plate unit with powered adjustment; scale & pointer for thickness reference; -- Antikickback Finger System with: (1) Lower & (2) Upper on Infeed; (1) upper assembly on outfeed.

MEREEN-JOHNSON "312-DC-OPH1" DIP CHAIN GANG RIP SAWSpecifications -- 12" Arbor cap., -- 14" max. dia. tooling, 3-1/2" max. thickness, -- 30" min. length for glue joint accuracy & 22" min. for busting only; -- 6" throat. Equipped with: & Features -- 50 HP - 3,600 RPM TEFC Direct drive motor, -- Arbor with disc brake & load meter, arbor lockout on access door.Feed & chain: -- 3 HP Variable feed speed from 30 - 150 FPM with adjustable jam protection, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, "Quad Life" hardened dip cams. -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, -- Automatic chain oiler with low level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls; -- Full width segmented maple, spring loaded overhead pressure shoe -- Pressure rolls & pressure shoe unit adjust with scale & pointer thickness reference -- Anti-kickback fingers. -- Lasers at infeed for pocket location.

MEREEN JOHNSON 424 DC Multiple Blade Rip Saw:Specifications -- 24" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max., -- 22" min. length, -- 6" throat -- 75 HP - 3,600 RPM TEFC Direct drive motor, arbor with disc brake. -- Feed & chain: 3 HP Variable feed speed from 50 to 150 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, -- "Quad Life" hardened dip camsEquipped with & Features -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips -- Automatic chain oiler with low level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls; -- Full width spring loaded overhead bed plate -- Height adjustment with scale & pointer reference --Anti-kickback finger system with (1) lower & (2) upper on infeed -- (2) Upper dust hoods, (1) 10" & (1) 5" dia. & (1) lower 4" dia. hood, requires 3,820 CFM

MEREEN JOHNSON 424 DC Multiple Blade Rip Saw:Specifications: -- 24" Arbor cap., 14" max. dia. tooling, 3-1/2" max., 22" min. length, 6" throat. -- 75 HP - 3,600 RPM TEFC Direct drive motor, arbor with disc brake. --Feed & chain:3 HP Variable feed speed from 50 to 150 FPM, M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, -- "Quad Life" hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, automatic chain oiler with low-level shutoff. --Equipped with & Features: -- (4) 3" Dia. air-loaded overhead pressure rolls -- Full width spring-loaded overhead bed plate -- Height adjustment with scale & pointer reference -- Anti-kickback finger system with (1) lower & (2) upper on infeed. -- (2) Upper dust hoods, (1) 10" & (1) 5" dia. & (1) lower 4" dia. hood -- Requires 3,820 CFM

MEREEN-JOHNSON Model "424-DC/SR ( 1 ) Moving Blade Gang Rip SawSpecifications -- 24" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max., -- 22" min. length, 6" throat. -- "Select-A-Rip" multiple Rip Saw with rapid adjustment of (1) moveable saw blade (shifts at approx. 3" per second); can be used independently or in conjunction with a gang sleeve arrangement; provides straight line gang ripping while maintaining optimum yield and delivering glue-joint accuracy.Equipped with & Features -- Select-A-Rip includes a control console and overhead laser lights for accurate blade positioning. -- 75 HP - 3,600 RPM TEFC Direct drive motor. -- Feed & chain: 3 HP Variable feed speed from 50 - 150 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, "Quad Life" hardened dip cams, -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, -- Automatic chain oiler with low level shutoff. --: (4) 3" Dia. air loaded overhead pressure rolls; full width spring loaded overhead bed plate, -- Eight ( 8 ) adjustment with scale & pointer reference; -- Anti-kickback finger system with (1) lower & (2) upper on infeed. -- (2) Upper dust hoods, (1) 10" & (1) 5" dia., requires 3,820 CFM. -Note From The Seller Machine was used in a low production environment and has low hours.

MEREEN-JOHNSON 419-DC Gang Rip Saw --Specifications -- 19" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max. manual thickness adjustment, -- 29" min. length for glue joint accuracy and 22" min. for busting only, 6" throat. --Equipped with & Features -- 75 HP - 3,600 RPM drive motor with direct drive to arbor. -- Feed & chain: 3 HP Variable feed speed 30 to 150 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, and chain oiler. -- (4) 3" Dia. spring loaded overhead pressure rolls (with new springs); full width spring loaded overhead bed plate, pressure rolls and bed plate unit with scale & pointer thickness reference; anti-kickback finger system , -- (1) lower & (2) upper on infeed (kickback fingers are newly replaced). -- (2) Upper dust hoods (1) 10" & (1) 5" dia., and (1) lower 4" dia. hood; requires 3,820 CFM; (2) 19" saw sleeve with mics. spacers. -- New Laser Light Array complete with (5) Lasers and Mounting Hardware, --. Spare parts including extra saw sleeve, short stock holddown plates, a few sawblades, etc. -- Notice the feed chain - it's in exceptional condition! --Note From The Seller Arbor motor burnt out, needs repair
