Equipment For Sale

Homag D-200 Drill & Dowel Inserter

HOMAG - BHT 500: CNC Through-Feed Machining Center (2-Head) + BARGSTEADT Stacker -- SpecificationsHOMAG "BHT 500" CNC 2-Head Through-Feed PtP Machining Center: -- Working Capacity Single panel processing: "X" Axis 98.4" (2,500 mm); "Y" axis 55.4" (1,406 mm); "Z" axis 0.5" - "2.36" (12 - 60 mm) min./max. panel thickness.(2) Panel processing: "X" Axis 98.4" (2,500 mm); Y" Axis 23.6" + 23.6" (600 + 600 mm); 1/2" - "2.36" (12 - 60 mm) min./max. panel thickness. -- Positioning SpeedVertical boring unit(s) Positioning speed: "X" Axis 328 FPM (100 MPM); "Y" axis 230 FPM (70 MPM); "'Z" axis 82 FPM (25 MPM).Panel transfer belt variable feed speed from: 0 - 295 FPM (0 - 90 MPM). -- Horizontal Through-Feed Boring Units(2) 2 HP (1.5 kW) Motors (1-motor each side) with: Variable rotation speeds up to 9,000 RPM. (2) 19-Spindle LH units, (38) total LH spindles; (2) 19-spindle RH units, (38) total RH spindles; spindle are on 32 mm centers.LH Horizontal drilling support is fixed; RH support motorized & equipped with: LED Indicator for precision positioning, pneumatic locking, and individual adjustment for positioning according to the panel size. -- Horizontal PTP Boring UnitsCNC Controlled horizontal PtP boring units with: (2 + 2) spindles in the "Y" axis on each boring head; (8) "Y" axis spindles total) -- Vertical PTP Boring Units(2) 4 HP (3 kW) Motors (1-motor each head) with: Variable rotation speed; up to 9,000 RPM.(2) Independently controlled top mounted CNC PtP boring/grooving heads; each head with: (30) Independent vertical spindles; spindle are on 32 mm centers. -- Grooving Saws(2) 2 HP (1.5 kW) Motors (1-motor each head); "X" axis grooving saw with: Variable rotation speed up to 12,000 RPM & 100 mm dia. blade. -- Operator InterfaceIPC with: HOMAG "Power Control 85T" + WoodWOP + Windows "XP" Operating System; icon driven software with: Graphical interface allows Operator to quickly & efficiently create programs & diagnose malfunctions in simple terminology. 17" TFT Color monitor; multitask Operating System; input/output modules; axes override; 4-axis interpolation; diagnostic graphics aide for programming; machine data & tool management. -- Options Include: BARGSTEADT - "TBH 250/QL/25/12": Vacuum Stacker Device.Work cap. "X" Axis 98.4" (2,500 mm), "Y" axis 55" (1,400 mm), 2.3" (60 mm) Max. panel thickness.High-speed workpiece stack exchange with a cycle time of 35 seconds; thin work piece device for panels from 8 mm thick. -- Actual Model is HOMAG BHT 500

HOMAG BAZ 211 VENTURE 21M Machining Center W "C" Axis -- Maximum Working field: X-Axis 3,225 mm (126.9"), Y-axis 1,500 mm (59"), Z-axis stroke 300 mm (11.8"), max work piece thickness 60 mm (2.4"). -- X-axis travel speed 80 MPM (262 FPM), -- Y-axis travel speed 60 MPM (197 FPM), -- Z-axis 40 MPM (131 FPM), AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. -- Working area: Working tables consist of (6) adjustable support rails, (2) vacuum cups per rail; laser unit to aid in the quick positioning of the vacuum cups. -- Machining unit: (1) 14.75 HP (11 kW) liquid cooled electro-spindle router (1,500 - 18,000 RPM), "HSK F63" quick change tooling; 12-position ATC automatic tool changer, "C" axis for 360ø horizontal processing. -- Drilling Unit: Vertical drilling head with (17) individual vertical spindles, 11-spindles in "X", 7-spindles in "Y", spindles on 32 mm centers. (1) saw blade aggregate, 125 mm dia; (1) 4-spindle lock case horizontal trimming unit aggregate. -- "POWER CONTROL PC 85" Numerical control with: "WOODWOP + BAZ" interface software, "WINDOWS NT"; icon driven with a graphical interface to allow the operator to quickly and efficiently create programs. -- Includes: 144 MB Disk drive, CD ROM drive, 12" color LCD monitor. -- Features: RS-422 Serial & USB connection to PC (up to 300 meters), (2) line adaptors RS-232 & 485.2 with 9-25 pin and card for RS-232 line (cable not included). -- Features: Multitask operating system, input/output modules, axes override, 4-axis interpolation, "WOOD SCOUT" diagnostic graphics aid for programming, machine data & tool management. -- Editor Module for PC with same look and functionality of software on the machine, allows transmission of programs and work lists; Required office PC configuration (not included): Pentium processor, 8 MB RAM, 8 MB hard disk; VGA video card. Complete with: -- ELMO 100 cm/h vacuum pump; perimeter protection cage; user & maintance manuals on CD with wiring diagrams and operation of Numerical Control. -- "C" Axis -- Actual Model is BAZ 211 VENTURE 21M.Riggers are required for tear don and loading

Honey Badger Pallet Nailer

7' x 23' Honeyville Bag House Dust Collecting System with Blower & Stand 86 10' Tubes, Ready to Ship.

Honeyville bag house, includes filters, very good condition

50' Honeyville Bucket Elevator

Honeyville 32" Blower with 12" in & 12" Out No Motor.

Honeyville Metal baghouse is approx. 8' x 8', 72 - 5" x 60" bags, 11" x 13" inlet, 28" x 63" bottom outlet, includes blower and numerous pipes, good condition

Hood 7000 Knuckleboom Log Grapple Good Pump Included

Hood 7000 log loader with trailer. Trailer is (Bill of Sale only)

2001 Hood 24000 loader -unknown hours -Loader is continuous rotation -Live heal set up to run circle saw -50/52 Rotobec bucket Needs trailer

2012 HOOD 24000 HEEL SLASHER GOOD TIRES CLEAN CAB RUNS GREAT FINANCING AVAILABLE WITH NO MONEY DOWN 3 MONTHS NO PAYMENTS WITH GOOD CREDIT GRANITEHE.COM

2003 HOOD 24000 SELF PROPELLED LOG LOADER HOURS ARE UNKNOWN DEERE ENGINE PILOT CONTROLS NEW SWING BEARING REBUILT BUCKET LIVE HEEL SLASHER VERY GOOD CONDITION FINANCING AVAILABLE WITH NO MONEY DOWN 3 MONTHS NO PAYMENTS WITH GOOD CREDIT GRANITEHE.COM

Feeder hopper with 85ft Superior belt conveyor, Mclanahan cross belt sampler 24" x 85' Transfer Superior Conveyor with 15hp Motor running at approx. 400FPM, 100TPH, @60PCF Material. Comes with McLanahan 24" cross Belt Sampler: LHD 18" Wide Enclosure 2-7/16" Dia Shaft, 6" Wide Cutter. 260k tons lifetime use and hopper conveyor. Sampler available separately.

Houfek Buldog 7-3M-1100-RRC 3 Head wide belt sander43" width cap, Roller / Roller / Combination-headHead Configuration1st Head – Rubber – 90 shore @ 200mm (7.9";) dia.2nd Head – Rubber - 90° shore @ 2000mm (7.9";) dia.3rd Head– Rubber - 45° shore @ 200mm (7.9";) dia. with adjustable platen.Specifications -- Sanding width 1100 mm 43" -- Work piece height 3-160 mm 0.118"~6.3" -- Sand belt size 1120 x 2620 mm 44" x 103" -- Conveyor feed speed 3~15 m/min 9.8~49 FPM -- Table motor 0.18 kW 1/4 HP Equipped with & Features -- Main motor 1st head 18 kW 24HP -- Motor 2nd head 15 kW 20HP -- Motor 3rd head 15 kW 20HP -- Voltage 460/3/60 -- Exhaust outlet (4) 180mm; (1) 100mm (4) 7"; (1) 4" -- CFM requirements 6700 m3/hr 3950 CFM -- Weight 3100 kg (approx) 6820 lbs -- Floor space 3885x1715x2260mm153"x68"x89"

Houfek Maxx 1100 2 Head Widebelt Sander43 width cap Drum, Combination headHead Configuration1st Head : Contact roll2nd Head : Combination contact roll and finishing platen.Specifications -- 1st Head: 6" Dia. rubber covered contact roll, 25 HP motor; -- 2nd Head: Combination head with rubber covered contact roll 6" Dia. and air cushioned finishing platen, timers control platen inflation and deflation, 20 HP motor. -- 43" x 75" Abrasive belts, -- TRU-TRAK solid state belt tracking, -- Variable feed speed with inverer control 15 - 45 FPM -- 1 HP motor, endless belt conveyor with automatic tracking. Equipped with & Features -- Motorized part thickness opening with LED 0" - 6" opening. -- Infeed and outfeed rubber covered holddown rolls, -- Infeed over thickness bar, -- Emergency stops at infeed & outfeed, -- Air operated disc brakes on sanding heads, -- Electrical interlocks on main access doors, and motor load meters.Note from Seller :This machine was damaged by the straps going over the machine during transport. The doors work fine, they just have dents on the top where the straps dented them. Price has been reduced to reflect this (cosmetic) damage.
