Boilers For Sale

BARKER Boiler and Fuel System built & tested in 2011 as a pilot unit. Successful testing has been completed. This surplus equipment includes the following main features: -- Combustion Temp Capability- 2,000 deg.F.; Steam Flow 24,000 lbs/hr saturated; Steam Pressure 1,500 PSI @ 600 deg. F. -- Fuel Feed rate - 3,000 Lbs/hr at 1/4" biomass (5% moisture) -- Heat Input - 7,500 btu/Lbs HHV @ 22 mmbtu/hr. -- All equipment has less than 2,500 actual operating hours since installation.EQUIPMENT MAJOR COMPONENTS: Combustor, Cyclonic combustion technology, Refractory lined Heat Recovery. Steam Generator. Rotary Drum Dryer for Fuel drying - capable of 30% moisture reduction (at the above combustion parameters) and 1.5 tons per hour (installed as used equipment).BALANCE OF PLANT FUEL FEED SYSTEM: Live-bottom bin, Bunker, Feed conveyors, Wood hog, Vibrating screen, Drag and screw conveyors. Boiler water system - feed pump,water and steam piping Emissions Control: All required baghouses (SJVUAPCD) California permitted. -- Now REDUCED PRICE from $1.5 million !!

Wood-Fired BOILERSMITH Boiler fitted with CHALLENGER Cumbustion Unit;Complete with the following major components and features: -- 250 PSIG design pressure. -- BOILERSMITH Boiler Model HRT2H8-2600SF-XW-250 with 2600 Sq. Ft. boiler surface area. -- Fuel can vary in moisture up to 50%. (Boiler HP is reduced as moisture increases.) -- Fuel feed Auger with Variable Frequency Drive. -- Fire-Tube Boiler with integrated Air Blast Tube Cleaning. -- De-Ash Augers. -- All Electrical Controls and starters. -- All mechanical/ electircal engineer's drawings.NOTES: &#9679 Removed and ready to load onto two trucks, 38,000 and 42,000 pounds. &#9679 15,000 to 16,000 pounds per hour steam if burning wood pellets. &#9679 No building included but same building can be purchased from STAR.

Boilersmith Boiler System Installed But Never Run

BRYAN BOILERS Water Tube Boiler:This boiler was taken out of an Office furniture factory where it was used to heat drying tunnels to a temp of 120 F. Has been discinnected nd in storage for 1.5 years,Detail and Specifications:Model # CL240-W-GIInput MBH 2160/1080Output MBH 1728BRYAN # 971292RElief Valve setting 50 PSIGHeating surface SqFt 287MAWP Water PSIG 60National bond # 41033Canadian reg # E6190.25GAS DATA:Natural GasMax Input CFH 2160Min. Input CFH 1080Min. supply presure 7 IN. WCMax supply presure 14 IN. WCManifold presure In WC 3.5Orifice size DMS 29

Bryan Low Pressure Boiler, Fuel Oil fired

Cleaver Brooks 200 HP Boiler

CB Package Boiler Natural Gas, CBI 700-300-15, Max Pressure 15st PSI, Input 12.600.000 BTU/HR Serial# OL 094585, 460 3Phase

Cleaver Brooks 300 HP Boiler High pressure steam, 150 PSI Natural Gas This unit has already been removed and is ready to load.

Coen 230 Combustion Wood/LP Gas Fired Burner

Plant Boiler System for up to 60,000 pounds of steam production per hour (1790 HP) with the following features and main components: -- (2) ENGLISH BOILER AND TUBE, INC. Boilers each rated for 20,700 pounds of steam per hour each. However, manufacturer specified they can be operated at 30,000 pounds per hour with dry wood or bark fuel (12 percent moisture). -- 250 PSI operating pressure ratings on each Boiler. -- VFD Drives on all main Motors. (The plant uses a maximum 75 HP for each boiler.) -- Electrical Controls. -- (1) Boiler has an Oil Burner for operating optionally on oil if sawdust or wood chips is not available. -- Chemical Water Conditioning System and Pumping System. -- De-aerator and Condensate Tank. -- Multi-clones for particle emissions reduction and abatement. -- (2) Fuel Storage Silos (25’x40’ & 20’x38’) with LAIDIG Model 243 Track-Driven Unloaders. -- Fuel Transfer Conveyors. -- The Silos also are included at the price shown and are available individually. See our listings DB-010162 and DB-010163 for details and individual pricing. -- Boilers can be purchased individually or as a pair. -- Professional removal and installation services are available.

G C BROACH Heater for THERMINOL 55; Complete with the following components and features: -- GE 10 HP Fan. -- NORTH AMERICAN Igniter and Burner. -- 5 M BTU per hour Burner. (absorption 7.8 BTUs/Hr.) -- Pumping station, 352 GPM flow rate. -- Heat Exchanger. -- On this application 450° F input and 500° F output. -- Control Panel. -- 12,000 Gal. Insulated product storage/surge Tank (appears unused). NOTE: manufacturer regularly provides a backrate (re-rate) study for $4,750.

HURST 600 HP Waste Fired Boiler;Complete in-place with the folloiwng features: --Decommissioned July 2019. -- 150 psi. (300 psi max wp), -- 20,700 lb per hour. -- Fuel House, Boiler Building and all Controls -- System has been "pickled" to maintain tube integrity.

400 HP HURST Boiler System;Complete with the following major components: -- HURST Heat Tube Boiler with 13,800 Pounds per hour steam production and 160 PSI Max. working pressure (Serial S2000-150-84). -- FINTUBE TECHNOLOGIES, INC. Kentube Economizer (Serial 20077106). -- PHELPS Fan (serial 35393). -- FUEL EFFICIENCY, LLC Boiler Tube Cleaner System. -- ONIX CORPORATION Biomass Burner System complete with Fans, fuel Feeder, Controls and Heat Ducting.NOTES: &#9679 This system was installed along with the BRUKS hammermill (our listing HM-010178) but never fully used. &#9679 This is part of the Dynamotive system listed as PB-010420. &#9679 The biomass burner can be purchased separately, estimated capacity at 25-30 M BTUs per hour. &#9679 Also available at the site for this system or for another application is a complete MAC baghouse filter system (our listing DO-011591).

Hurst Boiler 150HP

1989 Hurst Wood Waste Fire Boiler System MDL 710 W/Water Tank Condensate Tank, Infeed Auger, Ash Removal Unit, Controls, 150 PSI, Max WP PSI 975, 5, 175 lbs Steam Per HR & S/N HYB-150-2

Hurst 400 HP Boiler

Hurst Boiler System 1. 1- Used1995 200HP 150 PSI Hurst Hybrid Vessel 2. 1- Used 1995n refractory lined boiler furnace 3. 1- 8” underfeed stoker system 4. 1- 10” Fuel feed metering conveyor system 5. 1- Overfire air combustion fan with ductwork 6. 1- Underfire air combustion fan with ductwork 7. 1- Multi cyclone flyash collector 8. 1- Induced draft fan with exhaust stack 9. Muti cyclone and ID fan support steel with legs 10. Access platforms to boiler with ladders 11. Hurst open vented feedwater tank with 2 Grundfos feedwater pumps and control panel 12. Blowdown separator 13. Hurst Boiler control panel 14. Boiler piping parts 15. Boiler electrical parts 16.Equipment loaded onto trucks Optional: Fuel handling and storage supply system: Walking floor Vibrating Screen Screw conveyor Controls

Three systems available. Pricing will include removal and loading onto trucks. - Hurst Hybrid 600 HP 150 PSI - Hurst Hybrid 200 HP 150 PSI - Hurst Hybrid 300 HP 150 PSI Each system should include (email for specifics): Hurst Hybrid Vessel Hurst Boild Furnace with cast grates Hurst underfeed stoker system Hurt Metering conveyor system Overfire air combustion fan Underfire air combustion fan Hurst combustion air preheater Access platforms with ladders Boiler system control panel (PLC, frequency drives, UDC, control for automatic operation)

Used 1995 Hurst Hybrid Boiler system 200 HP 150 PSI 1– Hurst Hybrid Boiler 200 HP 150 PSI Boiler 1 - Hurst Boiler 200 HP Woodfired Furnace for Boiler vessel with cast iron grate system. 1 – Deaerator Tank 1 – Blowdown Separator for fuel storage equipment 1 – 8” Underfeed stoker System 1 – 10” Metering Bin Screw Conveyor with Hopper 1- 20HP Over fire air combustion fan 1- 15HP Under fire air combustion fan 1- Hurst multi-cyclone collectors 1- Induced draft fan

12" blade 7-1/2 HP motor 3 phase Foot Pedal control Left Hand machine
