Biomass Equipment For Sale

WEIMA WLK 4 Vertical Hopper-Fed, Low-Noise GrinderSpecifications: -- 31-1/2" x 39" Hopper opening at the top, 1.1 cu. yds. cap. Features: -- 30 HP rotor motor, Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter knife to ensure uniform discharge free of splinters, reduce friction, and dedicate more horsepower to grinding. Equipped with: -- (14) Replaceable back bolt-on cutter knives, welded knife holders standard, recessed concave cutters with low clearance over the 10" dia. rotor extends cutter life, protects the bolts, and reduces machine wear. -- 6" Dia. dust collection outlet (1,200 CFM required); 3/8" - 2" interchangeable screens to produce chips from 1/2" to 2" (Output depending on screen size, material density, and moisture content); -- Hydraulic ram optimizes feed pressure by monitoring rotor motor amperage, the lateral force on the ram is minimized by a unique "U-Joint" mounting system. Includes: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for an additional charge). Options: -- Flared hopper, log Spacer, 2nd row of knives, material discharge auger; programmable logic controls;

WEIMA - WLB 400, ...Horizontal Low Speed Grinder Equipped with: -- 25 HP Rotor motor; rotor with (18) 4-way indexable, replaceable cutter knives. Features: -- Top infeed roller; 15-1/2" x 2-1/2" feed opening; Heavy-Duty Industrial Grade construction with stress relieved shell and frame; Heavy-Duty outboard roller bearings; separate electrical control panel. Complete with: -- 8" Dia. collection outlet; 3/4" screen.

WEIMA C 150 Briquette PressSpecifications & Features: -- Produces 2" (50 mm) dia. Briquettes; -- Hopper opening of 41" x 41" (1,040 x 1,040 mm); hopper volume 1.43 cu/yd (1.1 cbm). Equipped with: -- 9 HP Hydraulic motor; 0.75 HP auger motor; hydraulic oil volume of 26.4 gallons (100 liters). -- Vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material; extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio at 2,600 PSI; hourly output up to 80 - 120 Lbs/Hr ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors").Features: -- Briquette length control, chrome plated clamp, oil level switch, control panel side-mounted to hopper, and overheating protection for hydraulic oil. Solid German engineering. - Freight, start-up, discharge pipes, etc. not included.

WEIMA TH 1500 M Briquette Press (Square Brick)Specifications: -- Produces 5.9" x 2.3" (150 x 60 mm) rectangular briquette; hopper opening of 55" x 55" (1,400 x 1,400 mm); hopper volume of 2.46 cu/yd (1.88 cbm). -- Equipped with: -- 40 HP Hydraulic motor; 2.6 HP auger motor; 3.0 HP agitator motor; hydraulic oil volume of 264 gallons (1,000 liters). -- Volume reduction from chip/dust to block up at a 10:1 ratio; hourly output up to 800 - 900 Lbs. -- Features: -- Conical shaped agitator with curved hopper corners, "Bridge Breaker" mounted on agitator; automatic "On/Off" integrated in feeding hopper; hydraulic oil cooling, overheating protection for hydraulic oil. -- Complete with: -- Touch-Screen control panel on swivel mount; discharge ramp for briquette extraction, chrome plated clamp, and an oil level switch. -- Solid German engineering.

WEIMA TH 814 Briquetter A volume reduction of 90% is possible through the briquetting of wood, paper, aluminum and biomass or synthetics, providing significant savings in labor, disposal and storage costs.Material is hand fed or by dust system into the hopper, where an agitator pulls it into the auger and pressing chamber. Specifications: -- Produces 80 mm (approx. 3.1") dia. compacted logs; approx. 2.4 cu. yd. (55.1 x 55.1 x 37") square vertical hopper, 18 HP motor. -- Hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio; approx. hourly output between 300 - 400 Lbs/Hr.Features: -- Auto on/off integrated into feeding hopper; automatic briquette length adjustment; conical-shaped agitator; dust connection at pressing unit.Options: -- Hydraulic cooling for 24-hour operation, heating for cold weather start-ups; plastic tubing discharge into Gaylord or carousel bagging system. .

WEIMA TH 714 Briquette Press (Cylindrical)Produces 2-3/4" (70 mm) dia. x 4" (100 mm) long compacted logs. -- Specifications: -- Approx. 1.4 m³ vertical hopper, 18 HP (13.5 kW) motor; vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Approx. hourly output between 240 - 280 Lbs/Hr ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors"). -- Equipped with: -- Centralized control panel for easy operation, MITSUBISHI Logic control & solid German engineering. -- Complete with: -- Auto on/off switch, auto length adjustment, & oil level sensor. -- Optional:: -- Hydraulic oil heater, hydraulic oil cooler, transfer piping and customization to customer material handling.

WEIMA TH 514 Briquette Press (Cylindrical). Produces 2" (50 mm) dia. x 4" (100 mm) long compacted logs. Specifications: -- Approx. 1.4 m³ vertical hopper, 12 HP (9 kW) motor; vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Approx. hourly output between 80 - 120 Lbs/Hr. ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors"). Equipped with: -- Centralized control panel for easy operation, PLC Logic control & solid German engineering. Complete with: -- Auto on/off switch, auto length adjustment, & oil level sensor. Optional: -- Hydraulic oil heater, hydraulic oil cooler, transfer piping and customization to customer material handling.

WEIMA TH 1200 Briquette Press (Square Brick)Specifications: -- Produces 5.9" x 2.3" (150 x 60 mm) rectangular briquette; hopper opening of 55" x 55" x 37" (1,400 mm x 1,400 mm x 950 mm); hopper volume of 2.46 cu/yd (1.88 cbm), (2,000 x 2,000 mm available). -- Equipped with: -- 35 HP Hydraulic motor; 2.6 HP auger motor; 3.0 HP agitator motor; hydraulic oil volume of 158 gal. (600 liters). -- Volume reduction from chip/dust to block up at a 10:1 ratio; hourly output up to 1,000 lbs/hr (depending on material and moisture content). -- Features: -- Conical shaped agitator with curved hopper corners, automatic briquette length adjustment; automatic "On/Off" integrated in feeding hopper; hydraulic oil cooling, overheating protection for hydraulic oil. -- Complete with: -- Touch-Screen control panel on swivel mount; dust connection at pressing point.

WEIMA WLK-25 SJ Super JUMBO SINGLE SHAFT SHREDDER -- Feed opening 98" x 76" -- Rotor Diameter 27" -- (246) Cutters -- 215 HP

Wood Pellet Manufacturing Plant Equipment;Complete with the following features: -- Design capacity 15 tons per hour. -- (1) Pellet Mill (Pellet Press) – custom built in USA and was producing at a rate of 4½ tons per hour. Comes complete with spare parts. -- WEST SALEM Model 4-4-60S Hammer Mill. -- Bulk storage. -- Conveyors to bagging system. -- Blowers Cyclones & Piping.NOTES: Plant was planned for several pellet mills but was shut down due to lack of sales. Operated only 3-4 years but has been down for a few years now. All equipment remains installed. Wood supply was from several sources: processing plants by-product, shavings from planer mills, finger jointing plant, and ground trim blocks. No Dryer - Owner using it. More details on request. Professional rigging is available.

MLS Number 12321010 Product Description 2015 WEST SALEM WSM5472 Horizontal Grinder -60” Millpower Shaker conveyor/finger screen – deck removed, used to meter flow of material fed by operator and reduce bed depth to make cross belt and head pulley magnets most efficient. -60” Eriez cross belt electro magnet. -Eriez 10K42 kW Silicon Rectifier incorporating: To convert 480 volt, 60 Hz, 3 phase AC to230 volt DC 10,000 watts output Normal convection cooled, full wave bridge circuit Fused AC switch Nema 3r Enclosure -Eries beefy magnet stand to support magnet and chain fall. -60” x 28’6” Slider Bed (Heavy Duty Feeder Type Conveyor) with 8’ section of stainless steel non-magnetic for Eriez cross belt magnet to perform at peak -20”x60” Dodge magnetic head pulley – installed to double up on magnets on conveyor, prior to material entering WSM grinder drag chain feed. Downstream from this is the WSM 5472bh Titan horizontal grinder. Schematics and wiring diagram can be supplied as well. WSM also supplied the chip discharge conveyor and magnetic head pulley and electrical panel with touch screen (by Emerson). Manuals available for component. Sold whereis, as is. Buyer responsible for dismantling, loading and freight.

West Salem Low RPM Grinder 1636 HT 40 HP 16’ Concave conveyor with magnet 18” belt 4x5 hopper hydraulic pack

WILLIAMS - C 32 100: HP Hammermill(20) Lbs Hammers: (22) Total Hammers.1" Slot screens.Soft start: Included.Opening: 32" x 19".Video available of operation.32" x 19" Opening.Comes with: 100 HP - 1,800 RPM motor.Includes: Direct drive with Integrated base; infeed chute.

Williams Hog S/N 14482 150HP Electric Motor

Woodsman 790 Grinder Power it how ever you want Was Running off a Diesel Power Unit.

Woodsman Model 2018 Chipper SN: 45400956 Cummins 6BTA Automatic feed Works great

2011 Woodsman 420T -4948 hours -Cummins QSX-15 Tier III Engine w/600HP -Babbit Type Knife System -31.5” Triple Grouser Pads -4 sets of knives -Brand new drive belt -1 rebuilt travel motor -PT Hydraulic Clutch -Remote Control Owner is just downsizing price aggressively to move !!!!!

2018 Woodsman 332 Wood Chipper, 1600 Hours, New Knives, New Hangers

Yulong XGJ 560 Pellet Mills Available - 125HP Motor.

1994 Zeno ZTLL 1400 x 1600 Slow Speed Low Noise Grinder 55HP 480V & Hood
