COMEVA - NICRON DOOR PRO, ...CNC Door/Jamb Machining Center with Automatic Tool ChangerGantry style flexible Door CNC Machining Center which can machine Hinges, Locks, Grooves, Door Face Patterns and many similar applications. The advantage of this machine over the NICRON DOOR C is this model can also resize the doors and its ability to machine the top/bottom of doors with the 90° rotation feature. It also has a floating head for grooving designs on the door faces while compensating for uneven door surfaces. Specifications: -- Max. working area - door length on X-Axis is 118.1" (3,000 mm). Max. X-axis speed of 230 FPM (70 MPM). -- Max. door width on Y-Axis is 51.18" (1,300 mm). Max. Y-axis speed of 230 FPM (70 MPM). -- Max. travel on Z-Axis is 7.87" (200 mm). Max Z-axis speed of 98 FPM (30 MPM).Working Heads: -- The machine is equipped with: (1) 9 kW Vertical router head with a 5-position Automatic Tool Changer (ATC); (1) 3.5 kW Horizontal head with double-end output spindles and 0° - 90° rotation; (1) 3.5 kW Horizontal motor for the lock milling, and a 0.37 kW floating head motor for grooving patterns on the door face. All drives are powered by Servo motors, X- & Y-Axis movement are via Rack & Pinion; Z-movement is with a recirculating ball-shaft.Working table: -- Table work area is 51.1" x 118.1" (1,300 x 3,000 mm). Table equipped with: (2) Adjustable width bars and (6) suction cups Load wheels, regulated by (5) reference pistons that rise & fall to secure the workpieces. The bars have integral suction cups powered by a VENTURI vacuum system. To work with doors, the machine is equipped with stops and gaskets for securing the door. Stops are mobile, and they can be used to hold doors and other parts.Operator Control Panel/CNC: -- Floor-standing operator panel is mounted on casters and houses the PC & OSAI CNC control hardware. PC motherboard is an ''INTEL Atom" 1.6 GHz CPU, modular system that offers a solution for the control of Servo drives and distributed input/output modules in a digital field bus and integrated II/O's. The dual-axes gantry has a Velocity-Feed-Forward function (VFF) that tries to look ahead with 256 precalculated blocks. It also incorporates a firmness control (Jerk) of the axes through advanced algorithms as well as tool store management & tool life. Advanced NC control powered by OSAI which is set up to control the Interpolated axes and all machine functions.COMEVA Software: Specially developed COMEVA DOORS software allows the machining of the main designs of hinges and slots you may find all over the market, including the machining on the upper side/edge of the door. Software carries a series of predesigned macros that help the operator when performing the different operations, thus speeding up various job designs. The software carries out a special program of parametric macros for doors/door frames.Includes: -- Centralized machine lubrication system. Owner’s Manual with schematics software on USB

COMEVA - G-300, ...4-Axes CNC Controlled Door Frame/Jamb Milling Machine: Designed for cutting and milling the stiles and rails (headers) of door frames/jambs using a saw blade which rotates from +/- 45° & 90° straight cuts (rabbet-step cuts) and a router head for the milling pockets of all types of hinges and locks. --Specifications: Max. frame length of 118.1" (3,000 mm); max. frame thickness of 1.18" (30 mm); max. frame width of 9.84" (250 mm). Saw cut positions at +45°, 90°, -45°. Saw blade diameter of 11.81" - 12.28" (300 - 314 mm).Milling Group: Cutting and milling with (4) axes, X, Y, Z, & A , each with Servo motors controlled by CNC. Components from reputable manufacturers for guaranteed reliability, performance and quality. 1.5 kW - 18,000 RPM Router motor and 4kW - 5,640 RPM saw motor. X-Axis reaches a speed up to 290 FPM (90 MPM)COMEVA Software: -- Specially developed COMEVA DOORS software allows the machining of the main designs of hinges and slots you may find all over the market, including the machining on the upper side/edge of the door. Software carries a series of predesigned macros that help the operator when performing the different operations, thus speeding up various job design. Software carries out a special program of parametric macros for doors/door frames. This software is normally installed in user's own PC.NC Control: NC Controls for X, Y, Z & A-axis for tool positioning & processing. Axis movement via hardened round ways & ground ball screws. Advanced NC control powered by OSAI which is set up to control the (4) Interpolated axes. Comes with a PC with 19" display.Rails//Workholding: (4) Sliding rail units with (4) pneumatic fixturing clamps (aluminum and plastic) that can be moved for all frame sizes. (2) Side pistons put both frame stiles and the head rail in the correct position before starting the cycle. -- Includes: Owner’s Manual with mechanical & electrical schematics and parts breakdown; covered by a 1-Year Factory Warranty on parts. -- Overall machine dimensions: 134" x 99" x 63" high (3,400 x 25 mm x 1,600 mm) -- Engineered & Manufactured by COMEVA S.L, in Spain.

COMEVA C-600 TOP CNC Door Milling Machine with (7) Axes and Rotary style (ATC) Automatic Tool Changer. The faster and more versatile version of the COMEVA NICRON DOOR models which can perform two jobs simultaneously on the door, ie. mill the hinges and machining the lock at the same time.Milling all types of hinges, including security locks and the recess for the bezel, the longitudinal recess for safety lock, front holes for knob handle, lock, digital locks, peepholes, machined holes or windows (stained glass), and floating probe. Operations performed in minimal time via two separate working channels. Will machine the top and bottom, resize, and bevel doors. Also available with optional loading and unloading of doors. -- Construction: Heavy duty Bridge configuration with two drives, one on end of the Gantry which ensures maximum reliability in the movement of the machine without any oscillation at minimum clearances. Top quality component brands for all linear guides, bearings, brushless servo and reducer. -- General Specifications: Maximum door length 118.1" (3,000 mm). Maximum door width 51.18" (1,300 mm); Minimum door width 15.75" (400 mm). Max door thickness 3.15" (80 mm). Gantry movement, the X axis, max. speed is up to 230 FPM (70 m/Min). Machine features (7) interpolated axes with (2) channels that work independently. -- Horizontal Heads - Hinge & Lock Milling: (2) high frequency motors at 2 HP (1.5KW) on the left and right side. -- Horizontal heads - Top and Bottom of doors: Top/bottom of doors is achieved with one 3 HP (2.2 KW) double-end head which swivels 180°. -- Vertical Milling Router: HSD Motor with ISO 30 ATC of 12 HP (9 KW) for routing hole for handle, crank, standard lock, security lock, electronic locks for hotels/commercial doors; milling or grooving work on the upper side of the door, with upper sensor for automatic measurement.The main milling router with variable speed from 1,000 to 24,000 RPM from the CNC programmable. Ceramic bearings are installed and it has right-left turn. The 10-position ATC is a the Rotary style mounted on the vertical head. -- Vertical Floating Motor: Vertical group also has a floating milling motor head for machining lines or groves top face of the door. Motor is 0.5 HP (0.37 KW). -- Vacuum Unit: BECKER vacuum producer at 100 m³/Hr. -- Production capacity: C-600 max. productivity can be less than one minute per door. Machine has an automatic calibration and automatic detection system of the door, plus roller guides to help load the door.The horizontal working groups on both sides (hinge and lock) work simultaneously allowing time for milling standard doors below (1) minute, approximately. -- Numerical Control/CAD Software: Advanced numerical control type S500 ETX 800 LX AMD PC (or equal) for the control of its (7) interpolated axes. It comes with a 19" display screen. The included COMEVA DOOR software is a special purpose package designed to facilitate the machining of all door ele

COMEVA BR-605E 5-Axes CNC Controlled Door Frame Milling Machine with ATC: Designed for cutting and milling wood and aluminum stiles and rails (headers) of door frames/jambs using a saw blade which rotates approx. 270° (universal) for straight cuts (rabbet-step cuts), router for the milling pockets of all types of hinges and locks, and other tooling stored in the approx (8) Position Rotary Tool Magazine. -- Specifications: Frame length is 15.72" (450 mm) to unlimited; Maximum frame thickness of 2.36" (60 mm); Door frame width from 2.36" (60 mm) to 7.08" (180 mm). Saw cut positions at almost any angle. Saw blade diameter approx. 12".Universal Milling Group: HITECO 11.4 HP (8.5 KW) 24,000 RPM 5-axes head. Cutting and milling with axes, X, Y, Z, A (for parts feeder) and B Universal rotation. with servo motors controlled by CNC.Feed Servomotor: Automatic parts feeding system composed of (2) movable clamps driven by servomotors for continuous operation. Reduces loading/unloading times.Controller/COMEVA Software:: -- OSAI (open series) CNC controls its (7) Interpolated axes. Intuitive graphical interface with 19" display. Built-in barcode scanner/reader. -- Specially developed CAD COMEVA DOOR 4.0 software allows the machining of the main designs of hinges and slots you may find all over the market. Software carries a series of predesigned macros that help the operator when performing different operations, thus speeding up various job designs. The software carries out a special program of parametric macros for frames. -- Includes: Owner’s Manual with mechanical & electrical schematics and parts breakdown; covered by a 1-Year Factory Warranty on parts. -- Engineered & Manufactured by COMEVA S.L, in Spain.

--high output machine-- COMIL XPRESS Case Clamp (Automatic Feed Through) Specifications: Working width 180 - 760 mm (7.09" - 29.92"). Working length 250 - 2,500 mm (9.84" - 98.43"). Working height 250 - 1,300 mm (9.84" - 51.18"). Working table height 500 mm (19.69"). Conveyor speed 35 MPM (114 FPM). Beam speed: 18 MPM (59 FPM) Horizontal, 20 MPM (65 FPM) Vertical (Combined). Beam pressure: 1,800 kg Horizontal (3,968 Lbs.), 2,000 kg Vertical (4,409 Lbs.). Equipped with: 31” W x 17’ L x 26-1/2” H Motorized belt conveyor. (2) Vertical beams, with Ball screw drive, Each with (3) Pressure bars, 0.37 kW (1/2 HP) - 2,750 RPM Motor, Rack & pinion drive. Top beam, with 2.9 kW (4 HP) - 1,500 RPM AC Servo motor and Rack & pinion drive. Length & Height Sensors. BIESSE "NC 400" CNC Control, with 6" Color LCD display. Complete with: 3' x 12' Pressure-Sensitive Safety Mat. NOTE 1: Infeed & Outfeed Conveyors Not included. NOTE 2: Machine is currently being fed by 600 V, and Seller states there is a built-in Multi-Tap Transformer converting to 400 V. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

COMIL CF-2000 JUNIOR ... Automatic Feed Through Case Clamp; - 28" Feed Through CapacityAutomatically self-adjusting Feed Through Clamp with pneumatic clamping pressure & electronic self-setting of clamping units according to cabinet size; cycle of machine can be timed to interlink with production line.Specifications:In-feed & thru-feed conveyor belt (feed speed 24 - 123 FPM) at 19.7" floor height. Max. feed through opening 28", max. length 100", max. height 48".Clamping System:(3) Horizontal clamping units, (1) top vertical clamping beam operated by (3) pneumatic (double acting) cylinders.Controls:Built-in operating control console with controller with LED readouts, for programming of cycle time & pressure control.Comes With:20 ft Motorized out feed conveyor - original COMIL

EMC EXPLORER 1100 2RK ... Wide Belt Sander with (2) Sanding Heads; Roller and Combination head roller/pad.Versatile, medium duty machine, ideal for cabinet shops etc.TECHNICAL DATA: -- Useful working width 1,100 mm (43"). -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Abrasive belt dimension (length) 1,900 mm (75") x (width) 1,120 mm (44"). -- Feed belt speeds adjustable by electronic inverter from 3 to 17 m/Min (10 - 55 FPM). Head configuration:1st Head: Steel Contact Roller -- Roller diameter 142 mm (6") -- Automatic abrasive belt grit compensation with "Grit-Set System". -- On/Off Selector control with pneumatic piston to select roller. -- Motor power 11 kW (15 HP). -- Automatic Star-delta starter. -- Speed rotation: 18 m/Sec (59 FPS).2nd Head: Combination Roller & Pad. -- Roller diameter 142 mm (6"). -- Rubber covered roller with hardness 45 Shore. -- Automatic abrasive belt grit compensation with "Grit-Set System". -- On/Off Selector control with pneumatic piston to select roller. Flexible sanding pad. Quick Change System for removable pad with felt, rubber and graphite. Rotating cutting speed 17 m/Sec (55.8 FPS). --Driven by same main motor.Abrasive belts oscillation by means of electronic photocell sensor.Feed System: -- Working thickness min./max. mm 3 - 190 (1/8" - 7-1/2"). -- Motorized table lifting including fine adjustment, on 4 precision screws. Natural rubber conveyor belt, machined. Automatic feed belt centering device. Electronic digital display for working thickness; resolution 0.1 mm (0.004"). -- Feed belt speeds adjustable by electronic inverter from 3 to 17 m/Min (10 - 55 FPM). Centralized Control Cabinet: -- Control panel with self-diagnostics alarm control unit. -- Analog load meters on main control cabinet. -- Table lifting-lowering thickness system, electrically controlled. -- AUTOMATIC Delta - Star starter on main motor and IP 54 protection against dust & moisture. Centralized Independent Pneumatic Control Cabinet: -- Pneumatic air filter with automatic water-drain system. -- Pneumatic adjustment for "Grit set system". --Pneumatic plant working without lubrication. Compressed air pressure 6 bar (85 PSI). IP 54 protection against dust & moisture. Safety Features: -- Anti-kickback infeed protection. -- Oversized parts infeed protection by swinging bar. -- Emergency push buttons front & rear. --Automatic brakes on main motor. -- Automatic emergency stop and alarm displayOption: TAMPICO Cleaning Brush, 150 mm (6") diameter. Please add ...$3,400USA UL or Canada CSA Safety Features

EMC MERCURY 1350 2RK ... Wide Belt Sander with (2) Sanding Heads; Roller and Combination head roller/pneumatic pad.Versatile, medium duty machine, ideal for cabinet shops etc.TECHNICAL DATA: -- Useful working width 1,350 mm (53"). -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Abrasive belt dimension (length) 2,200 mm (86-5/8") x (width) 1,320 mm (52"). -- Feed belt speeds adjustable by electronic inverter from 3 to 19 m/Min (10 - 62 FPM). Head configuration:1st Head: Steel Contact Roller -- Roller diameter 180 mm (7"), spirally grooved. -- Automatic abrasive belt grit compensation with "Grit-Set System". -- Motor power 11 kW (15 HP) driving both heads, with soft starter. -- On/Off Selector control with pneumatic piston to select roller. -- Automatic Star-delta starter. -- Speed rotation: 18 m/Sec (59 FPS).2nd Head: Combination Roller & Pad. -- Roller diameter 140 mm (5-1/2"). -- Rubber covered roller with hardness 45 Shore. -- Automatic abrasive belt grit compensation with "Grit-Set System". -- On/Off Selector control with pneumatic piston to select roller. -- New pneumatic aluminium sanding pad, lamina 40 mm. With On/Off selector. -- Quick Change System for removable pad with felt, rubber and graphite. -- Rotating cutting speed 18 m/Sec (59 FPS). -- Driven by same main motor, with soft starter.Abrasive belts oscillation by means of electronic photocell sensor.Feed System: -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Motorized table lifting including fine adjustment, on 4 precision screws. Natural rubber conveyor belt, machined. Automatic feed belt centering device. Electronic digital display for working thickness; resolution 0.1 mm (0.004"). -- Feed belt speeds adjustable by electronic inverter from 3 to 19 m/Min (10 - 62 FPM). -- Table rollers. Extension supports with idle rollers in infeed & outfeed.Centralized Control Cabinet: -- Control panel with self-diagnostics alarm control unit. -- Analog load meter on main control cabinet. -- Table lifting-lowering thickness system, electrically controlled. -- AUTOMATIC Delta - Star starter on main motor and IP 54 protection against dust & moisture. Centralized Independent Pneumatic Control Cabinet: -- Pneumatic air filter with automatic water-drain system. -- Pneumatic adjustment for "Grit set system". -- Pneumatic plant working without lubrication. Compressed air pressure 6 bar (85 PSI). IP 54 protection against dust & moisture. Safety Features: -- Anti-kickback infeed protection. -- Oversized parts infeed protection by swinging bar. -- Emergency push buttons front & rear. --Automatic brake on main motor. -- Automatic emergency stop and alarm displayUSA UL or Canada CSA Safety Features

EMC MERCURY 1350 3WRK Abrasive Planer / Wide Belt Sander with (3) Heads; Planer Head, Contact Roller, and Combination Head.Useful working width 1,350 mm (53"). Working thickness min./max. 3 - 170 mm (1/8" - 6-11/16"). The machines uses abrasive belts 2,620 x 1,370 mm (103" x 54") for longer life of the sanding belts.Head configuration:1st Head: Planer Head "W" -- Cutter head knives diameter 140 mm (5-1/2"). -- Shaft for helicoidal position knives with (380) Interchangeable knives with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 20 independent segments. -- Anti kickback protection made of 72 independent elements. -- On-Off pneumatic cylinder for planer. group in working position. -- Working pressure adjustment. -- Motor power: 15 kW (20 HP). -- Automatic Star-delta starter. -- Speed rotation: 32 m/Sec (115 FPS). -- Soft starter for slow starting2nd Head: Steel Roller "R", Belts dimensions: 2,620 x 1,370 mm (103" x 54"). -- Roller diameter: 180 mm (7"), spirally grooved. -- Electronic motorized roller pressure adjustment "Grit-set system". -- On-Off selector switch control for roller. -- Constant control to any position with accuracy 0.02 mm. -- Rotation: Against feed (clockwise). -- Motor power: 11 kW (15 HP) with Automatic star-delta starter. -- Abrasive Belt cutting speed: 18 m/Sec (59 FPS). -- Timing oscillating cleaning abrasive belt blower located at the bottom 3rd Head: COMBINATION Unit "K", Belt dimensions: 2,620 x 1,370 mm (103" x 54"). -- Roller diameter: 140 mm (5-1/2"). -- Roller rubber hardness 45 Shore, Constant control to any position with accuracy 0.02 mm. -- On-Off selector switch control for 3rd roller including pneumatic piston -- Pneumatic Aluminum PAD , lamina 40 mm, On-Off. -- Quick changing system, extractable blade with felt, rubber and graphite. -- Rotation: Against feed (clockwise). -- Motor power: 11 kW (15 HP) with automatic star-delta starter. Abrasive Belt cutting speed:18 m/Sec (59 FPS).Feed system: -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 18 m/Min (9.8 - 58 FPM) Inverter Controlled. -- Automatic feed belt centering device. General Machine Features: -- Large diameter screws on machined guides with columns and pistons. -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each (head) working group. Electronic programmable color TOUCH SCREEN display, 7" wide -- PLC with micro-processor of latest generation, modular and expandable. -- Connection USB, RS232, Ethernet 10/100/1000. -- Memory capacity: 100 working programs or more. -- Graphic synoptic to facilitate programming.Software facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, programming and display for thickn

EMC GIANT 1350 2WR Abrasive Planer with (2) Heads, Planer Head and RollerTop of the line Heavy Duty Abrasive Planer from EMC. The series of GIANT machines are available in many configurations. Abrasive Planer has a helicoidal head with insert tooling.Useful working width 1,350 mm (53"). Working thickness min/max mm 3 - 170 (1/8" - 6-5/8").Head configuration: 1st Head: Planer Head "W" -- Cutter head knifes diameter 180 mm. -- Shaft for helicoidal position knifes with (512) Interchangeable knifes with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 24 independent segments. -- Anti kickback protection made of 72 independent elements. -- On-Off pneumatic cylinder for planer group in working position. Working pressure adjustment. Motor power 30 kW (40 HP), Star-delta starterSpeed rotation: 35 m/Sec (115 FPS).2nd Head: Roller "R" Belts dimensions: 3,250 x 1,370 mm (128" x 54"). -- Roller diameter: 320 mm (12-5/8"). -- Roller rubber hardness 45 Shore. Constant control to any position with accuracy 0.02 mm. -- On-Off pneumatic piston, controlled from the electrical panel. -- Rotation: Against feed (clockwise). -- Motor power: 22 kW (30 HP) Automatic star-delta starter. Rotating cutting speed: 21 m/Sec (99 FPS). Blower for the roller unit.Feed system: -- Constant pass line, 900 mm (35.4") from floor (In line machine). -- Vacuum bed, 4 kW (5,5 HP) for hold down of smaller parts, mounted inside of the machine base. -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 20 m/Min (9.8 - 65.6 FPM). Inverter Controlled. -- Large diameter screws on machined guides with columns and pistons. -- Automatic feed belt centering device.General Machine Features: -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each working group.Electronic programmable color TOUCH SCREEN display, 7" widePLC with micro-processor of latest generation, modular and expandableConnection USB, RS232, Ethernet 10/100/1000Memory capacity: 100 working programs or moreGraphic synoptic to facilitate programmingSoftware facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, programming and display for thickness. -- Command, programming and display for feeding. -- Command, programming and display for all inverters. -- Command, programming and display for selected groups. -- Command, programming and display for blowers, including compressed air saving function. -- Display report and reset of alarms (self diagnostic) with memory records.Options Included: -- Vacuum bed, 4 kW (5,5 HP) for hold down of smaller parts, mounted inside of the machine base. -- Rotating blowers for part and feed belt cleaning. -- LED light inside the machine. -- Telemetry for remote computer assistance

EMC GIANT 1350 3WRF Abrasive Planer with (3) Heads, Planer Head, Roller and Superfinishing PadTop of the line Heavy Duty Abrasive Planer from EMC. The series of GIANT machines are available in many configurations. Abrasive Planer has a helicoidal head with insert tooling.Useful working width 1,350 mm (53"). Working thickness min/max mm 3 - 170 (1/8" - 6-5/8"). Head configuration:1st Head: Planer Head "W" -- Cutter head knives diameter 180 mm (7-1/16"). -- Shaft for helicoidal position knives with (512) Interchangeable knifes with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 24 independent segments. -- Anti kickback protection made of 72 independent elements. -- On-Off pneumatic cylinder for planer group in working position. Working pressure adjustment. -- Motor power 30 kW (40 HP), Star-delta starter.Speed rotation: 35 m/Sec (115 FPS).2nd Head: Roller "R" Belts dimensions: 3,250 x 1,370 mm (128" x 54"). -- Roller diameter: 250 mm (9-13/16"). -- Roller rubber hardness 60-65 Shore. Constant control to any position with accuracy 0.02 mm. -- On-Off pneumatic piston, controlled from the electrical panel. -- "Grit-set system". -- Rotation: Against feed (clockwise). -- Motor power: 22 kW (30 HP) Automatic star-delta starter. Rotating cutting speed: 21 m/Sec (99 FPS). Blower for the roller unit.3rd Head: SUPERFINISHING PAD "F" Electronic PAD segmented in (75) sections. -- Belts dimensions: 3,250 x 1.370 mm (127-15/16" x 54"). -- Width of a single element (section): 18 mm (11/16"). -- APC - Automatic Programmable Control and setting of the air pressure. -- Electronic motorized roller pressure adjustment "grit-set system". -- Rotation: Against feed (clockwise). -- Timed oscillating abrasive belt "air jets" cleaning. -- Motor power: 18,5 kW (25 HP) with electronic inverter variable abrasive belt speed 3 to 18 m/Sec (9.8 - 59 FPS).Feed system: -- Constant pass line, 900 mm (35.4") from floor (In line machine). -- Vacuum bed, 4 kW (5,5 HP) for hold down of smaller parts, mounted inside of the machine base. -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 20 m/Min (9.8 - 65.6 FPM). Inverter Controlled. -- Large diameter screws on machined guides with columns and pistons. -- Automatic feed belt centering device.General Machine Features: -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each working group.Electronic programmable color TOUCH SCREEN display, 7" widePLC with micro-processor of latest generation, modular and expandableConnection USB, RS232, Ethernet 10/100/1000Memory capacity: 100 working programs or moreGraphic synoptic to facilitate programmingSoftware facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, program

EMC FLEXY 1350 3WRK Abrasive Planer / Wide Belt Sander with (3) Heads; Knife Head, Roller, Combination Head Roller/Pad.Useful working width 1,350 mm (53"). Working thickness min./max. 3 - 190 mm (1/8" - 7-1/2").Head configuration: 1st Head: Knife Planer Head "W" -- Cutter head knives diameter 140 mm (5-1/2"). -- Shaft for helicoidal position knives with (380) Interchangeable knifes with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 24 independent segments. -- Anti kickback protection made of 70 independent elements. -- On-Off pneumatic cylinder for planer. group in working position. -- Working pressure adjustment. -- Motor power 15 kW (20 HP). -- Automatic Star-delta starter. -- Speed rotation: 35 m/Sec (115 FPS).2nd Head: Steel Roller "R", Belts dimensions: 2,620 x 1,370 mm (103" x 54"). -- Roller diameter: 250 mm (10"), spirally grooved. -- Electronic motorized roller pressure adjustment "Grit-set system". -- Constant control to any position with accuracy 0.02 mm. -- Rotation: Against feed (clockwise). -- Motor power 15 kW (20 HP). -- Automatic star-delta starter. -- Abrasive Belt cutting speed: 18 m/Sec (59 FPS). -- Air Jet Blower for abrasive belt cleaning.3rd Head: Combination Head "K", Belt dimensions: 2,620 x 1,370 mm (103" x 54"). -- 3° roller diameter mm 150, Roller rubber covered, hardness 45 shores, Roller pressure adjustment control and "grit-set system" -- ON-OFF selector switch control for 3° roller, including pneumatic piston -- PNEUMATIC aluminum pad, lamina 40 mm, ON-OFF -- Quick changing system; extractable blade with felt, rubber and graphite -- Abrasive belt motor power 15kW (20hp) • Soft starter for slow starting 15kW• Rotating cutting speed 18 m/sec. -- Air Jet Blower for abrasive belt cleaning.Feed system:Constant pass line, 900 mm (35.4") from floor -- Idle table rollers support in infeed and outfeed. -- Rubber covered presser rollers, grooved. -- Variable feed belt speed, adjustable from 3 to 18 m/Min (9.8 - 59 FPM) Inverter Controlled. -- Large diameter screws on machined guides with columns and pistons. -- Automatic feed belt centering device.General Machine Features: -- Independent main motors. -- Analog ammeters, for each motor, on main control cabinet. -- Electronic motorized grit set system, control from touch screen for each (head) working group. Electronic programmable color Touch Screen display, 10" wide -- PLC with micro-processor of latest generation, modular and expandable. -- Connection USB, RS232, Ethernet 10/100/1000. -- Memory capacity: 100 working programs or more. -- Graphic synoptic to facilitate programming.Software facilities: -- Automatic motor sequence starting. -- Command, programming and display for all electronic pad functions. -- Command, programming and display for thickness. -- Command, programming and display for feeding. -- Command, programming and display for all inverters. -- Command, programming and display for selected groups

EMC EXPLORER 1100 SUPER WK Abrasive Planer / Wide Belt Sander with (2) Sanding Heads; Planer Head, Combination head roller/pad.TECHNICAL DATA: -- Useful working width 1,100 mm (43"). -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Abrasive belt dimension (length) 2,200 mm (86.6") x (width) 1,120 mm (44"). -- Feed belt speeds adjustable by electronic inverter from 3 to 19 m/Min (10 - 63 FPM). Head configuration:1st Head: Planer Head "W" -- Cutter head knives diameter 142 mm (5-9/16"). -- Shaft for helicoidal position knives with (316) Interchangeable knifes with 4 cutting edges, 14 x 14 x 2 mm. -- Sectioned pressure bars in 20 independent segments. -- Anti kickback protection made of 60 independent elements. -- On-Off pneumatic cylinder for planer group in working position. -- Working pressure adjustment. -- Motor power 15 kW (20 HP). -- Automatic Star-delta starter. -- Speed rotation: 30 m/Sec (97.5 FPS).2nd Head: Combination Roller & Pad. -- Roller diameter 142 mm (5-9/16"). Rubber covered hardness 45 Shore. Automatic abrasive belt grit compensation with "Grit-Set System". On Off Selector control for 2° roller incl. pneumatic piston -- Pneumatic elastic pad high resistance with quick changing system; extractable felt, rubber & graphite. . Complete with On-Off Selector and Quick Change System for removable pad with felt, rubber and graphite. Rotating cutting speed 18 m/Sec (59.1 FPS). -- Motor power 15 kW (20 HP). Belt blowers, oscillating, for cleaning of abrasive belt. Abrasive belts oscillation by means of electronic photocell sensor. -- Cleaning Brush: -- Tampico brushing unit for panel cleaning, at outfeed, 150 mm diameterFeed system: -- Working thickness min./max. mm 3 - 170 (1/8" - 6-11/16"). -- Motorized table lifting including fine adjustment, on 4 precision screws. Natural rubber conveyor belt machined. -- Automatic feed belt centering device. Electronic digital display for working thickness; resolution 0.1 mm (0.004"). -- Feed belt speeds adjustable by electronic inverter from 3 to 19 m/Min (10 - 62 FPM). -- Idle table rollers support in infeed and outfeed.Centralized Control Cabinet: Analog ammeters on main control cabinet. Table lifting-lowering thickness system electrically controlled. AUTOMATIC Delta - Star starter on main motors and IP 54 protection against dust & moisture. Centralized independent pneumatic control cabinet: Pneumatic air filter with automatic water-drain system. Pneumatic adjustment for "Grit set system". Pneumatic plant working without lubrication. Compressed air pressure 6 bar (85 PSI). Features: -- Control panel with self-diagnostics alarm control unit. -- Telemetry computer remote diagnostics control. Direct connection with EMC via internet for assistance.USA UL or Canada CSA Safety Features

3" Min. & 16" max. wedge length, taper from 1/2" to 2" thickness, mixed in hopper, angle & width of wedge is fully adjustable with one face at 90°. -- Equipped with: 10" Dia. saw blade with 2 HP direct drive motor, hopper feeds material up to 16" long with a width up to 8"; air operated with 6 CFM compressed air requirement, 1.8 Sec/stroke, 4-3/4" dust outlet. -- Features: Walk away, "hands free" operation. Auto-shutoff feature and capability to cut glue blocks. -- Complete with: Self-diagnostics, built-in starter, automatic shutoff feature, air filter & lubricator.

EMG SEMI-AUTOMATIC Twin Stair Trencher; 2" x 12" Max. stringer size, semi-automatic operation. The feed/indexing of boards is automated and the routers are moved manually for the stair cuts.Specifications: -- (2) 3 HP Belted motors to "top & bottom" 18,000 RPM spindles, 1-1/2" depth of plunge cut, T & B heads are arranged to advance in-and-out to facilitate open plain stairs. -- Pneumatic advance and twin table clamps each rated at over 2,000 Lbs.Features: -- Any rise and run, whether straight or tapered, can be achieved in just a few minutes of setup. Includes: -- Overload protection with on-control resets, individually timed motor startup with adjustable 2nd delay.NOTE: Available with CNC fully automatic operation. the top automated section is a bolt-on to the base of the semi-auto frame. Please ask for a Quote.

ENCORE - EP-100, ...Portable Tire BalerSpecifications: -- Bale chamber: 60" x 30" -- Cylinder size: 6" (2-Cylinder) -- Cycle time: under 30 Sec -- Passenger tire processing time: 400 per Hour -- Type of trailer: Gooseneck -- Number of retainer dogs: 10Equipped with: -- KABOTA Diesel Engine

Plant Boiler System for up to 60,000 pounds of steam production per hour (1790 HP) with the following features and main components: -- (2) ENGLISH BOILER AND TUBE, INC. Boilers each rated for 20,700 pounds of steam per hour each. However, manufacturer specified they can be operated at 30,000 pounds per hour with dry wood or bark fuel (12 percent moisture). -- 250 PSI operating pressure ratings on each Boiler. -- VFD Drives on all main Motors. (The plant uses a maximum 75 HP for each boiler.) -- Electrical Controls. -- (1) Boiler has an Oil Burner for operating optionally on oil if sawdust or wood chips is not available. -- Chemical Water Conditioning System and Pumping System. -- De-aerator and Condensate Tank. -- Multi-clones for particle emissions reduction and abatement. -- (2) Fuel Storage Silos (25’x40’ & 20’x38’) with LAIDIG Model 243 Track-Driven Unloaders. -- Fuel Transfer Conveyors. -- The Silos also are included at the price shown and are available individually. See our listings DB-010162 and DB-010163 for details and individual pricing. -- Boilers can be purchased individually or as a pair. -- Professional removal and installation services are available.

ENTERPRISE - 1616 2-RAM: Horizontal Baler -- 300 HP. -- Overall length: 34'-7" x Width 17'-3". -- Charging chamber: 28" D x 60" W x 110" L. -- Approx. bale size: 31" x 45" x 62".

Industrial Grade EUROVAC I Cyclone Separator & Cartridge Dust Collector Combination. -- Primary Separator: Cyclone on support stand and barrel waste collection: (A Rotary Air Lock with a larger waste bin can be added). Cyclonic action can remove up to 99% of dust and particles. -- SYS-030 Secondary Dust collection: Remaining 1% of dust collected using Cartridge Filter which are automatically cleaned by Pulse Jet cleaning using compressed air housed in a separate compressed air storage tank. -- Vacuum Producer: Heavy Duty cast iron turbine type pump with 10 HP energy efficient squirrel cage motors designed to run continuously all day. built-in thermal heat protection device, and overload protection in Control Panel. High 85" WC vacuum level. -- Control panel house pump starter controls with hand/auto selector for on demand starting. -- Features: Quiet operation with built sound deadening. Diaphragm valves for pulse jet cleaning. -- Approximate dimensions: 180" long x 70" wide x 72" high.

EVASHRED EV60E Dual Shaft Shredder with Infeed ConveyorEvashred is a well-known brand of commercial mobile and stationery shredders for solid waste designed and manufactured by F.V. Evans and Sons also known as Evans Engineering.Every type of shredder is designed specifically to shred a particular type of solid waste including Documents, Car & Truck Tyres, E-scrap (Hard Drives, Computers, Printers known as E-waste and e-scrap), Plastic, Foam rubber, Green Waste, Building Waste even Hospital WasteSpecifications: --30 kW / 40 HP Maximum Power --28-30 RPM Cutter Speed Rotation --Width 640 mm x 37 5mm Cutting Chamber Opening
