woodworking Equipment For Sale

Two Bay 52" capacity Pneumatic clamping

2005 Marathon Spray Booth 14' wide x 25.5' long x 8'9" tall Booth only no racks, spray guns, paint pots etc included

MARINUS - Promax: End Matcher with Defecting, Cut to Length, & Optimizing Cutoff CapabilitiesFeatures & Specifications -- Heavy and stable construction. -- Cutterhead carriage and Clamp System utilizes: HD Lineal bearings; grease lubricated. -- Heavy-Duty, low maintenance Feed Chains into machine: Takeaway of material after cutting/end matching. -- Continuous high-speed feeding system with: Accurate positioning utilizing HD Servo Drives. -- (2) Servo Motors for: Max. feed control and acceleration & deceleration control. -- Servo driven feed motor & gearbox for: Highest efficiency speed feeding & control of the cutterhead carriage. Includes: Independent stepless speed control forward & reverse. -- Pneumatic side pushers (holding material firmly against the fence) for: Guaranteed square angle cut. -- (2) Cutoff sawing Servo motors: 5 HP Each (3.0 kW) – 450 mm (17.7";) dia. blades with: Inverters (VDFs) for varying blade speed. -- (2) High-speed milling head Servo motors with Inverter (VFD): 12 HP - 7.5 kW Each; speeds to 12,000 RPM; 5"; (125 mm) dia. -- Adjustable cutterhead stroke based on material width to increase throughput speed based on the width of material input. -- (1) Luminescence sensor camera for defect crayon mark. -- Inductive Sensors: For detecting the position of the carriage and others for detecting the positions of the saw blades. -- Cutoff waste powered belt conveyor in machine (below feed system; 12"; from floor) with: Drive motor for waste cutoff pieces taken to the outfeed end of the machine. Other Technical Specification -- Machine with: Completely enclosed by safety doors; produced to CE Safety & Electrical Standards to UL/CSA Standards. -- LENZE PLC Control. -- Operation from Operator Control with: Touchscreen control; mounted on the front right cover of the machine. -- Air pressure required: 85 PSI (6 Bare). -- 1" x 8"; (200 mm) & 2 x 4-3/4"; (120 mm) Dia. dust outlets; approx. 5,000 - 5,500 mm and from 3,050 - 3,350 CFM. -- Router Remote Access with: Internet connection; factory can monitor the performance of your machine. - Also allows for easy access to service, softwareupdates, & downloads.Input & Output Material Specifications -- Board widths: 2"; (50 mm) Min. to 12.28"; (312 mm) max.; min. width: 1-3/4"; (44.5 mm) min. -- Board input lengths: 17.9"; (450 mm) min. to 20 ft. (6,000 mm) max. -- Board output lengths: 15-3/4"; (400 mm) min. -- An available short piece option can be added to reduce output; length to 10"; (250 mm) min. -- Board widths: 2"; (50 mm) Min. to 12" (300 mm) max. -- Board input lengths: 17.9"; (450 mm) Min. to 20 ft. (6,000 mm) max. -- Board thickness: Min. to 0.315"; (8 mm) on request to 1 1/3"; (32 mm).Standard Programs / Programming -- Machine is equipped with: (2) Primary Programs. 1. End matching: Trimming ends and end matching. 2. Cutting only (no end matching). -- (3) Subprograms 1. Defecting cutting & end matching: Operator marks defects with a crayon; machines cut out

--In auction: https://exfactoryauctions.com/Detail/SH-230492/event/A122024$1 --NO RESERVE!-- MARTIN T 23 Tilting Spindle Shaper, with 30 mm (1.18") Interchangeable Spindle & Power Feeder Specifications: Table size 940 x 1100 x 850 mm (37.01” x 43.31” x 33.46”) H, with Table insert dia. 90, 130, 205, 305, & 480 (3.54”, 5.12", 8.07”, 12.01”, & 18.90”). Spindle tilt 0° to 45°. Maximum capacity under nut 7". Vertical spindle adjustment 145 mm (5.71"). Spindle speeds 3000, 4,500, 6,000, & 90,000 RPM. Equipped with: 6.4/7.8 HP Motor. "MK5" Spindle shaft. Mechanical spindle brake, with Foot pedal. Hand spindle lock. Complete with: 11-1/2” x 4-3/4” Left & Right Fences, with 21” x 6” H Left & Right Wood fences. 1996 CO-MATIC 1 HP 4-Speed 4-Roll Power Feeder, with Speeds 13, 26, 26, & 72 FPM. Dimensions with Power Feeder: 42" x 42" x 63” H.

MARTIN T71 10' Sliding Table SawSpecifications: -- 10' Cutting cap.; 9-1/2' sliding table, 3-position table locking mechanism; cast iron machine table; 7.5 HP motor; tilting saw arbor (arbor speed 2,800 - 4,000 & 5,500 RPM) with tilting from 0° - 45.5°, 450 mm (17.72") saw blade cap.; 1 HP - 9,400 RPM scoring motor. -- Max. cutting height: 5-11/16"; Hydraulic saw blade height & tilt adjustment by foot pedal control; cutting width between saw blade & rip fence: 49". -- Complete with: -- Rip fence with micro-adjust; crosscut fence flip stops.

MARTIN - SHM-08622: Shaper -- Specifications7.5 HP - 3,450 RPM Motor.1-1/4" Dia. spindle.8" Max. cap. under nut. -- 42" x 37" Solid cast iron precision ground Table; ribbed construction. -- NOTE: Machine runs great; however, we do not have the micro adjustment fence.

MARTIN - T-72 A: Sliding Table Saw Specifications -- 3,300 mm (10'-10") Cutting cap.; infinitely lockable anodized aluminum sliding carriage; wear resistant hardened steel V-way guides with self-cleaning system. -- 7-1/2 HP Main saw motor with: Electronic "wireless" brake; 2,800 - 4,000 & 5,500 RPM arbor speed (quick change via tabletop opening) with: 400 mm main blade max. Features -- Max. cutting height of 6-3/4"; tilt mechanism; motor saw blade height adjustment (up to 5"). -- Hydraulic foot pedal elevation: 0 - 170 mm with LCD display; hydraulic foot pedal tilting: 0 - 46° with LCD display; 3,300 mm Sliding table with: 90° Lock for absolute square cuts every time.Complete with -- Aluminum swiveling table suitable for miter cuts by scale without adjusting the crosscut fence: -46° to +46° cuts; 26" x 52" Traverse table; telescoping crosscut fence to 131" with sliding stop; also adjustable for: Miter cuts; digitally displayed; handwheel controlled cutting width between saw blade & rip fence up to 53" with digital readout.

MARUNAKA Model RD – 8J WIDE Single Deck Veneer Roll Dryer;Complete with the following features: -- 1988 - year of manufacture. --Working width – 51"; --Length of the dryer – 24 Ft (4 Sections) --Type of heating - Steam --Operational in 2018 when mill closed --Professional rigging and loading available.

MARUNAKA Model RD-3UB/RD-6UB (Connected) Single Deck Veneer Roll Dryer;Complete with the following features: -- (3) 3 HP circulating fans with (1) 3 HP exhaust blower thru the ceiling. -- Optional heat source: electric (7) Elements/Zones, computer controlled thermocouples in addition to (2) Natural gas burners (OEM).. Both dryers have a 100amp circuit breaker with 100amp fuses. The RD 8 operates with 4 fan motors and 4 heaters. The RD 6 has 3 fan motors and 3 heaters";.. -- Capable of temperatures to 120° Celsius (250° Fahrenheit). -- Working width 1000 mm or about 39 inches. Veneer is fed endo.Please Note: -- Dryer is (2) separate units; all equipment will fit into a 40' container for shipment from Eastern USA. -- All equipment is in good working condition including all fans and blower, temperature control works properly; feed roll drive works well. -- Rolls have been nickel treated to minimize corrosion/oxidation. -- This dryer equipment is still in place. -- MARUNAKA (2) Models: RD-3UB and RD-6UB currently connected to increase capacity. Can easily be separated.NOTE: Refurbished in 2005, operated from 2005 - 2012. Still operational ready to work!

MASTER MACHINERY - MC-MDS-1: Single Spindle ShaperSpecifications -- Table size: 27-1/2" x 32". -- Spindle speed: 7,500 - 10,000 RPM. -- Main motor: 3 HP.

MASTERWOOD PROJECT 313 CNC MACHINING CENTER (W/ACT/BORING): -- Specifications:Working Capacity:"X" Axis 3,080 mm (121"), "Y" axis 1,100 mm (43") width; -- Positioning Speed:Programming speed in X-axis 197 FPM (60 MPM), Y-axis 162 FPM (49 MPM), Z-axis 58 FPM (18 MPM). -- Boring unit:(13) independent vertical spindles, (9) in X-axis, (5) in Y-axis; (4) horizontal spindles with (1 + 1) in X-axis for edge boring in the left- & right-hand panel edges. -- Machining:(1) 7.5 HP (5.6 kW) high speed router (1,000 - 24,000 RPM) by frequency inverter; 1.5 HP (1.1 kW), 6,000 RPM grooving saw with manual rotation for X-axis or Y-axis; -- Work Table: (6) moveable support rails with (2) vacuum cups ea., double zero settings, (6) pneumatic backstops and (2) pneumatic side stops creating (2) working zones. -- Operator & Machine Control:TECNOSUD "K68800" Microprocessor control for (3) axis, lineal, circular, and helical interpolation. Equipped with 14" color video graphic monitor, keyboard for data entry, 1.44 MB floppy disk drive, 64K RAM, RS-232 for possible connection to office PC, all mounted in separate free-standing control cabinet; features to run CPL/Parametric "TRIG" programming and "Spline" CAD/CAM. -- Complete with: Dual zone vacuum pump. Ontario Hydro approved electrics. -- Actual Model is MASTERWOOD PROJECT 313

MASTERWOOD - Project 450L: CNC Machining CenterSpecifications -- X-Y-Z Axis strokes: 5,820 - 1,900 - 350 mm.Axis speed X-Y-Z: 80 - 80 - 25 MP.Aluminum panel support blocks: 8.Middle reference stops: 8.Front reference stops: 9.Side reference stops: 2 dx - 2 sx.Panel carrying knives: 4. -- Distance between drills: 32 mm.Engine power: 1.7 kW.Drill rotation speed: 4,000 RPM.12 kW Air-cooled motor with: HSK 63 Tool holder. -- Numerical Control with: P; max. power: 37.3 kVA.Amps: 53.8.Working Pressure: 7 - 8 bar.Compressed air consumption: ~ 100 Nl/Min. -- Upper dust extraction outlet: Ø 250 mm. Dust extraction outlet for sawdust coming out of the conveyor belt: Ø 120 mm; dust extractor air output speed: 25 - 30 m/Sec; dust extractor air consumption: 4,900 cbm/Hr.Includes -- Vacuum Pump; (12) extra ISO collets; aggregate HSD.Note: Description based on Model Type, manufacturer's plate, and information from Seller. Please inspect to confirm the required specifications. Dimensions & Weight data are based on 3rd party information and could be incorrect; please verify & confirm if accurate dimensions & weight are required.

MASTERWOOD PROJECT 317 CNC MACHINING CENTER (P.T.P): Specifications -- Working Capacity: "X" Axis: 102" (2,600 mm); "Y" Axis: 37-1/2" (950 mm); "Z" Axis stroke: 5.9" (150 mm); max. material thickness: 2.36" (60 mm). -- Positioning Speed: "X" Axis: 164 FPM (50 MPM); "Y" Axis: 131 FPM (40 MPM); "Z" Axis: 25 FPM (8 MPM). -- Work Area: (6) Adjustable panel supports; ea. with: (2) Vacuum pods; (4) panel lifting blades for heavy parts; (6) fixed pop up rear stops; (1) side R/H stop; (1) L/H stop.Machine bed is divided into: (2) Independent working zones with mirror image capability. -- Boring Unit:.2 HP (1.5 kW) - 4,000 RPM Motor; (10) independent vertical boring spindles with: (7) Spindles in "X"-axis & (3) spindles in "Y"-axis. (6) Horizontal spindles with: (2 + 2) In "X"-axis; (1 + 1) in "Y"-axis; (1) 12,000 RPM "X"-axis grooving saw with: 125 mm Dia. blade. -- Machining: (1) 9 HP (6.7 kW) Vertically mounted electrospindle router with: ISO 30 Adaptor & ceramic bearings; variable speed: 6,000 - 24,000 RPM.(1) 4-Position automatic tool changer mounted to the machine head for "on the fly" ATC. -- Operator & Machine Control: PC Front-end controller; MASTERWOOD "MW 310" CNC + Windows Operating System; multitask software with: Graphic interactive editing & boring optimization program.Features -- 14" VGA Color monitor; MHZ processor; 64 MB SDRAM; 6.4 GB hard drive; 56 K modem, 1.44 MB floppy & CD ROM drives; Ethernet card; serial port; mouse; RS-232 port for remote programming from an office PC is possible -- Software includes: Realization of profiles & parametric drawings; graphic basic macros for simple & complex elaboration; graphic visualization of the surfaces to be machined; IN/OUT diagnostic; programming for drilling & routing operations with machine settings & tool editor.Includes -- Vacuum Pump.NOTE: Description based on Model Type, manufacturer's plate, and information from Seller; please inspect to confirm the required specifications. Dimensions & Weight data are based on: 3rd Party information and could be incorrect; please verify & confirm if accurate dimensions & weight are required.

MATTISON - 404, ...Straight Line Rip SawSpecifications: approx.20HP - 3,600 RPM Direct drive arbor motor; 14" dia. max. saw blade cap. (9" smallest dia.), 1-1/2" dia. arbor; 4" thickness capy. -- Table size: 65" x 77" Long. -- 30" Distance from saw to left edge of table. -- 24-1/4" Between saw & column and 24" rip distance to right of gauge. -- Top roller holddown with 7-1/2" shortest stock handled under (1) roll, 15" under (2) rolls.Equipped with & Features: -- Overhead cutting design with single cast chain links. -- Chain with automatic oil lubrication. -- 2 HP Feed motor with (2) feed speeds of 50 & 100 FPM

The Rip Saw is still in good running condition and still in use.

Mattison 404 Rip Saw Seller was using until they upgraded to a gang rip. Ready to ship.

Mattison 404 Straight Line Rip 230 Volt 3 Phase 25 HP Total 230/460 Dual Voltage on 20HP Mandrel Motor

Mattison 202 Straight Line Rip

Description Mattison "55-F" Turning Lathe - Back Knife 30" Cap. in length and 4" x 4" cap. dia. - Pneumatic feed; rear arbor with cutter-head driven by a 10 HP V-belt motor. Work piece rotation is belt driven by main motor with variable speed gear box, double end drive, mechanical feed of work piece into cutter head. Rear dust shroud with collection outlet.

MATTISON - 404, ...Straight Line Rip SawSpecifications: -- 15 HP - 3,600 RPM Direct drive arbor motor; 14" dia. max. saw blade cap. (9" smallest dia.), 1-1/2" dia. arbor; 4" thickness capacity. -- Table size: 65" x 77" long. -- 30" Distance from saw to left edge of table. -- 24-1/4" Between saw & column, and 24" rip distance to right of gauge. -- Top roller holddown with 7-1/2" shortest stock handled under (1) roll; 15" under (2) rolls.Equipped with & Features: -- Overhead cutting design with single cast chain links. -- Chain with automatic oil lubrication.. --4-Speed Feed: 62 - 93 - 124, & 186 FPM.
