Equipment For Sale

PHL Horizontal Slab Saw with 40HP Motors

PHL High Speed Edger 20' Tailing System 125hp Motor

PHL Edger high speed 4 saw edger; Complete with the following features: --Independently shifted blades. --48″ opening. --2-3/4″ max cut depth. --125 HP Arbor Motor. --Operates up to 800 linear feet per minute. --Infeed Table and Outfeed Table with Picker and Hydraulic Power Unit. NOTE: Removed from service November 2015. Set up for transverse scanning. No scanner included.

PHL Horizontal Band Resaw

2-saw PHL horizontal resaw (38") w/75 HP motor

Industries PHL log length scragg mill, 48" dia. blades, electric drive, 2 slab drop belts, all electrical and controls included, this machine was recently in production and is in very good condition

PHL Industries 48" dia chipper, 6 knife wheel with 3 blocked, includes some spare knives, good working condition

PHL 6' AIR Strain Linebar Resaw with Cab, Controls, 25hp Hyd Pack, 65" Line Bar

PILLAR MACHINE HPLD 96" CNC BORE & LOCK-DOWEL INSERTER: -- Specifications:(4) Working zones of 24" each and "OPTIONAL" working table length of 96"; CNC controlled head assembly with rapid (side-to-side) traverse.Head assembly with: (1) Horizontal boring & insertion unit with a 3 HP - 18,000 RPM Direct-Drive Spindle motor; "X" Axis is servo controlled for positioning; Digital Mechanical Readouts For Height and DepthHead is currently set up to bore/machine/insert 20 mm Lock-Dowel "Eclips", H-clips, Channel Locks & 8 mm Spring Pin Fasteners.Material thickness capacity 0.5" - 1" max. Material thickness with digital readout for height adjustment. -- Clamping System:(8) Pneumatic, quick side-to-side adjustable hold-down clamps for horizontal "Lock-Dowel" processing on the panel edge.(1) Pneumatic Clamping Bar for vertical boring into the panel face/back. -- Operator Interface:15" Color Touchscreen control + Windows 10 Operating System. Ethernet 1 x PCIE Broadcom GbE (or similar), USB: 2 x USB 2.0 (or similar), Serial Port: 1 x RS-232 (or similar)The on-screen graphics of the operator interface have been designed to allow for quick programming at the machine. Typically, programs can be written and recalled in less than one minute.The Interface is open architecture allowing it to integrate with design software that can give hole locations in the form of a .xml file or a bar code (with bar code reader purchase found in options).Standard Features in the software include: 1. Graphic interface to show where holes are to be drilled and if a dowel is to be inserted. 2. Pattern Drilling/Inserting.3. Password protection of certain features/functions. 4. Online diagnostic capability (if machine is connected to an internet connection). 5. Toggle between Metric or Imperial programing parameters. -- Features: This machine will insert H-clips, Channel Locks and Spring Pins with ease. Using CNC control, this machine positions the drilling spindle to bore holes and insert the Lockdowel hardware. -- Complete with:Anti slip table surface, rack & pinion drive, and centralized dust collection manifold. -- Actual model is: PILLAR MACHINE HPLD

Pinheiro 2002 Mdl SFA7-1600 62" Dbl Cut Band Mill S/N 16869, Air Strain, 3HP Hyd Pack

The seller has confirmed that this Pinheiro planer is in good working/running condition. - Double sided planer with side saw - Complete package - Manual - no year...Motor HP 20 bottom, 10 top

PINHEIRO MODEL MF 4-630 4-SIDED PLANER. -- 24" Planing width and 20" Molding width cap., 8" max. motorized opening via 1/2 HP motor; -- Top head 18 HP, 5" X 25", 4 knives, 5,500 RPM, Cutting circle 5 1/4", Max chip removal 3/8" -- Bottom head 12 HP motor,5" X 25", 4 knives, 5,500 RPM, Cutting circle 5 1/4", Max chip removal 3/8" -- (2) side heads (opposed) with 8" spindle capacity, 9 HP motor each., Vertical adjustment 4" -- 11/16" Max. profile depth, 5-1/2" max. tool dia., 1-13/16" spindle dia.X 8" long at 5,000 RPM; -- 4 HP feed drive, variable feed speed 10 - 100 FPM, 39" infeed bed, (6) powered feed rolls, sectional feed rolls, sectional chipbreaker, central lubrication system. Complete with: -- high speed steel knives in the top and bottom heads, and dust hoods.

Piper Chain Type Log Turner, hydraulic drive, includes hydraulic drive in cab

PIQUA - PW72-50, Semi-Automatic Wide-Mouth Horizontal Baler with MAX-PAK ConveyorSpecifications: -- Cylinder: 7" -- Main motor: 30 HP -- Bale size: 48″ x 36″ x 72″ -- Feed opening: 46" x 50" -- Cycle time: 20 Seconds -- Platen force: 86,600 Lbs -- Bale weight: 1,500 – 1,800 Lbs -- Door cylinder: 4" -- Door cylinder stoke: 12"; -- Conveyor belt: 60"Equipped with: -- 60" Infeed Conveyor with rubber belt.NOTE: New Conveyor rubber belt, paint, and safety stickers.

(2) 2-1/2 HP motors 5/8” arbors 12” blade capacity max width 3 - 5/16” nax depth 2-5/8”

12” blades 1-1/2 HP motors - 3 phase foot pedal control

2020 PITTS, Plantation Log Trailer, 40', 4"" Drop, 11R24.5 Hub Pilot, Air Ride, Dead Bolster, Maxi Brakes, Grapple Bar, Covered Tandem. Same spec trailer 4 Spring Hutch Susp $25,100 Single Point Susp $27,200 Single Point with Vulcan Scales $30,300 Headboard adds $1,500 All prices are plus FET Please give LMI-Tennessee LLC a call to discuss your financing needs.

Plantation Log Trailer, 40', 4" Drop, 11R24.5 Hub Pilot, 4 Spring Hutch Susp., Dead Bolster, Maxi Brakes, Grapple Bar, Covered Tandem Same spec trailer with Single Point Suspension $27,200 Single Point Vulcan Scales $30,300 Air Ride $28,500 Headboard add $1500 All prices are plus FET

Plantation Log Trailer, 40', 4" Drop, 11R24.5 Hub Pilot, Single Point Susp, Dead Bolster, Maxi Brakes, Grapple Bar, Covered Tandem Same trailer with Vulcan Scales $30,300 4 Spring Hutch Suspension $24,900 Air Ride $28,500 Headboard $1500 All prices are plus FET

Load Payin Series Log Trailer, 40', 8" Drop, Air Ride, 11R24.5 Tires, Maxi brakes, Heavy Duty Biumper wFull Width Grapple Bar, Heavy Duty Lonck N Go Landing Gear, Covered Tandem. Same trailer with 4 Spring Hutch Suspension $25,300 Single Point $26,500 Single Point Vulcan Scales $29,500 Headboard adds $1500 All Prices are plus FET
