UHLING HP-3000 CASE CLAMP (SINGLE-BAY): --Specifications:Clamping Capacity: 55" L x 96" H x 24" D; large enough for multiple boxes. Offers versatility, quick 30-second setup or changeover. -- Pressure Elements:(4) Dual air pod pressure bars that are pneumatically activated; counterweight balanced; position them effortlessly and let go. The counterweight keeps them in place; no need to secure them! -- Air Pod Stroke:3-1/2" Stroke of air pod with 0 - 120 PSI pressure adjustment. -- Vertical Beam:Moves easily on roller bearings with pneumatic carriage locks; (4) small air cylinders from (1) control point. -- Operator Control Panel:Mounted on vertical beam, so it is always where it is needed; single-lever lock-or-unlock control & front/rear pressure selection. -- Counter Support by:Solid laminated panel opposite to pressure bars.

UHLING HP-4000 ... is a versatile, quick and easy-to-use Case Clamp.Specifications: -- 100" x 50" x 24" Clamping cap. that's UHLING's most versatile Clamp ever. -- (3) Counterweight balanced, fully adjustable horizontal dual air pod pressure bars and (2) vertical, easy adjustable dual air pod pressure bars. -- 3-1/2" Stroke with individual controls for each air pod pair. -- Roller bearing mounted carriage with pneumatic locks (considered to be the fastest 2-axis Clamp on the market). -- Single lever lock-or-unlock control and front/rear pressure selection. -- Solid panel counter support that is opposite the pressure bars. -- Easy access operator's control panel that's mounted on the vertical beam. -- Approximately (30) Sec or less changeover time. -- Options: Additional dual pod pressure bar assembly for vertical or horizontal.

UHLING HP-3000 Case Clamp ... offers versatility, quick (30) second set-up or changeover. -- Clamping Capacity, 55"- L x 96"- H x 24"- D, that's large enough for multiple boxes. -- Pressure Elements, (4) horizontal @ with (3) individual air pods, counter-weight balanced, position them effortlessly and let go, the counter-weight will keep them in place, no need to secure them! -- Air Pod Stroke, 3-1/2" with individual controls for each air pod set. -- Vertical Beam, moves easily on roller bearings with pneumatic carriage locks. -- Operator Control Panel, mounted on vertical beam, so it is always where it is needed, single lever lock-or-unlock control & front/rear pressure selection. -- Counter Support, by solid laminated panel opposite to pressure bars. OPTIONAL: Top Clamping, removable top pressure element for applications such as a vertical center partition or similar needs, removes easily if not needed. Add $ 1,000.00 to standard machine price.CUSTOM:HP-3000 F, ... comes with a "Solid Floor" for easy clamping of upper cabinets, add $ 1,000.00 to standard machine price.HP-3000 M, ... clamping capacity, 60"- L x 96"- H x 36"- D, that's large enough for deep commercial Case Goods. Please call for pricing.

UHLING - HP-3000: Case Clamp (Single-Bay) -- SpecificationsClamping capacity: 72" L x 74" H x 24" D; Large enough for multiple boxes; offers versatility, quick 30-Sec setup or changeover. -- Pressure Elements(4) Dual air pod pressure bars that are pneumatically activated; counterweight balanced; just position them effortlessly and let go: Counterweight will keep them in place; no need to secure them! -- Air Pod Stroke3-1/2" Stroke of air pod with 0 - 120 PSI pressure adjustment. -- Vertical BeamMoves easily on roller bearings; pneumatic carriage locks with: (4) Small air cylinders from (1) control point. -- Operator Control Panel:Mounted on vertical beam so it is always where it is needed; single lever lock-or-unlock control & front/rear pressure selection. -- Counter SupportBy solid laminated panel opposite to pressure bars. -- Actual Model is: UHLING HP-3000

UKIAH TAE 6”x30” Thin Kerf gang edger w/(2) 150 hp arbor drive motors, US 20 hp motor to TIGEAR 11.40:1 reducer, knurled & hold down rolls, UKIAH & ALEMITE lube system, clamshell opening Serial# WS-10-6-85 6" Splined Arbor.

UKIAH 8" x 66" wide gang saw. (8) 6" knurled and chromed bottom feed rolls, 2-15/16" shafts; (3) 8" knurled & chromed top feed rolls, 2-15/16" shafts, powered; 1-1/4" thick side plates; Rex ZBR type bearings; all sprockets in good condition; 3-15/16" outboard bearings and floored platform for drive; attached to main arbor by extra heavy duty universal joint system; door on right; drive system on left; clam-shell opening with both cylinders; (2) 10 HP motors for 2 speed drive system; approximate base size 9'6"  x  12'6"; no infeed or outfeed or main electric motors.  $26,500 OBO.

UKIAH 8" x 66" wide gang saw. (8) 6" knurled and chromed bottom feed rolls, 2-15/16" shafts; (3) 8" knurled & chromed top feed rolls, 2-15/16" shafts, powered; 1-1/4" thick side plates; Rex ZBR type bearings; all sprockets in good condition; 3-15/16" outboard bearings and floored platform for drive; attached to main arbor by extra heavy duty universal joint system; door on right; drive system on left; clam-shell opening with both cylinders; (2) 10 HP motors for 2 speed drive system; approximate base size 9'6"  x  12'6"; no infeed or outfeed or main electric motors.  $26,500 OBO.

ULTRA GL-630H Feed Through Moulder: 6-Head (B-T-R/L-T-B), "Flooring" working capacity of 12" x 6".Specifications: -- Head sequence: Bottom 25 HP, top 30 HP, right 20 HP/left 20 HP (opposing), top 25 HP, and bottom 25 HP motor. -- Spindle dia. of 1-13/16" with cutterhead speed of 6,000 RPM; all spindles with high prevision bearings. -- Auto. positioning of the left & top spindles radially; all additional spindles with digital readouts, including chipbreaker & pressure elements. -- Pneumatics on all chipbreakers, pressure elements, and holddown rollers. -- Horizontal spindles with HydroLock outboard bearings on #1, #2, #5 & #6. -- Straight jointer on spindles #5 & #6; Profile Jointers on spindles #3, #4, #5 & #6. Equipped with: -- Inverter controlled feed drive, variable speed of 26 - 260 FPM. -- Infeed table 1.2 M (4') with all table plates & fences hard chromed to RC 70. -- Machine table includes: (5) Table rollers for smooth through feed; short stick attachment for through feed on pieces down to 230 mm. -- Electrical cabinet & pedestal for machine controls separate from machine, Heavy Duty sound enclosure. -- Includes Startup training and Warranty!

UMP - BP 450 A: 450 kG/Hr Briquette PressSpecifications: -- Cap. 450 kG/Hr (992 Lbs). -- Max. pressure: 1,700 kG/cbm (24,175 PSI). -- Max. chip moisture content: 15%. -- Max. chip size: 15 mm (0.59"). -- Wood shaving to briquette ratio: 10 to 1 (using mahogany). -- Briquette configuration: Rectangular. -- Briquette length: 40 - 105 mm (1.57" - 4.13"); Briquette width 150 mm (5.91"); Briquette height: 60 mm (2.36"). -- Briquette heat energy: 4,200 kCal/kG (7,558 BTU/Lbs). -- Hopper size: 31"; x 36"; x 36"; with: 1-Side sloping so cutaway from cube of 18"; x 36";; mounting flange at top allows additional capacity to be added.Equipped with: -- Automatic material density adjustment. -- Automatic hopper shutoff. -- SIEMENS PLC Control.

UMP BP500A Briquette Press New System - Ready to ship!

UNIMAK GS140-S Single Sided Hot Melt Glue Laminator4-Foot Wide Hot Melt Glue Spreader for PUR and other Hot Melt Adhesives. Panel Types: MDF, Particleboard, door spar, XPS and Polystyrene sandwich panels. All kinds of panels where adhesive application is required.Glue Types: Polyurethane Hotmelt (PUR) glue. Unfilled EVA.Pressure Sensitive Foil Types: As roll material - PVC, P.P., finish foils and CPL foils. As sheet Stock - Veneer, PVC, laminate, acrylic sheets and door surfaces. Working Speed : 5 - 25 m/Min (16.4 - 82 FPM).Technical Specifications: -- Max. External Working Temperature: 180 ° C (365° F), Chromed Roller. -- Working Width: 200 - 1,400 mm (7-7/8" - 55"). -- Board Thickness: 4 - 210 mm (1/8" - 2-1/4"). -- Upper Spreader Roller - 240 mm (9-1/2") diameter, Silicone Coated. -- Upper Dosing Roller: 215 mm (8-1/2") dia., Chromed. -- Lower Transport Roller: 240 mm (9-1/2") diam., Silicone coated. -- Total Power: 15 kWMelter and Hose are not Included, they are optional and can be quoted separately or purchased locally.

UNIMAK 160-S 5-Foot Wide Single-Sided Hot Melt Glue Spreader for Hot Melt Glue including PURHot Melt Glue Spreader for PUR and other Hot Melt Adhesives. Panel Types: MDF, particleboard, door spar, XPS, and polystyrene sandwich panels. All kinds of panels that adhesive application is required.Glue Types: Polyurethane hot melt (PUR) glue. Unfilled EVA,Pressure Sensitive Foil Types: As roll: PVC, P.P., finish foils and CPL foils As sheet Stock: Veneer, PVC, laminate, acrylic plates and door surfacesWorking Speed: 5 - 25 meter/Min (16.4 - 82 FPM)Technical Specifications: -- Max. External Working Temperature: 180 ° C (365° F) - chromed roller. -- Working Width: 200 - 1,600 mm (7-7/8" - 63"). -- Board Thickness: 4 - 40 mm (1/8" - 1-5/8"). -- Upper Spreader Roller, Silicone Coated and Ø 240 MM (9-1/2"). -- Upper Dosing Roller: Ø 215 MM – Chromed (8-1/2"). -- Lower Transport Roller: Ø 240 MM – Silicone coated. -- Total Power: 15 kWMelter and Hose are not Included, they are optional and can be quoted separately.

UNIQUE 2753 Arch Shaper with Sanding HeadThe Unique Model 2753 Is A Single End Machine Designed For High Quality, High Production, Cabinet And Passage Door Arching Of Top Rails And Panels. Its Two Counter-Rotating Spindle Motors are Easily Programmed For Multiple Cuts With Hogging And Finishing Cutters To Eliminate Tear-Our And Extend Tool Life. A Sanding Station Provides A Multi-Pass Sanding Finish On Arched Door Panel Profiles. Unique “ArchPro"; Software Guarantees High-Speed Measuring And Fully Dynamic Programming Abilities.• Shaper Motor: (2) 10 HP Himmel Direct Drive , 440V - 39.2A, 3PH Motor• 5" Stack Height • Compressed Air Requirements: 90 PSI - 2 CFM• Dust Collection: (2) 5" Diameter 1200 CFM each (1) 4" Diameter 800 CFM each• Work Height: 3’6"• Machine Footprint: 113" Width X 78" DepthIncludes - Safety Mats, Dust Collection Manifold, and Owner's Manual

UNIQUE 4522 Shape and Sand with DOUCET Return Conveyor(4) Stations (2 Floating shapers, 2 floating sanders), each with 5" stack capacity.Configured as follows:(2) Shaper Stations with: 10 HP Direct drive HIMMEL motors, 1-1/4" dia. arbors.(2) Sanding Stations with: 2 HP Direct drive BALDOR Motors, 1" dia. arbors tiltable up to 45 °.Sanding Stations are variable speed from 6,000 - 9,000 RPM and reversible.Shaper Stations are variable speed from 6,000 to 9,000 RPM and reversible.Specifications & Features:Variable speed conveyor speed from 0 - 35 FPM; 6"Heavy Duty conveyor and roller hold-down system.Features: Digital indicators for both horizontal & vertical adjustment on all spindles from the front.PLC Controlled "jump-cope"; machine is equipped with Windows/XP-based computer touch-screen & software. - Software stores feed rates, positions, cutter rotation, profile pictures, and RPM settings.Includes "DRO" Option: (Software and hardware upgrade from standard "Trueset" software - linear encoders on each station send real-time location of spindle back to the computer and give the operator the desired position; Machine will not start until all spindles are manually brought to the correct setting; a ...$ 10,950 value option).Includes Optional "Inset" automated size &squaring infeed fence ($ 16,850.00 option value).Max. material thickness - 2-1/2"; min. material width - 1-1/2" plus the depth of the cut.(2) 5" Dia. dust ports and (2) 4" dia. dust ports; Tooling not included.Complete with: DOUCET Feedback Return Conveyor ($ 10,000 option value).Floorspace required with DOUCET Return is 17-1/2' x 10'.

UNIQUE - 313, ...Automatic Cope & Dowel Door MachineMiters the end & drills for dowels of (2) cabinet door rails on each pass; automatic cycle for accurate & easy alignment of mitered corners.Equipped with: -- (2) 5 HP Dual motor set for shaping w/1-1/4" spindles; (2) 0.33 HP dowel alignment drills. -- Automatic cycle with: Dowel hole boring for accurate alignment of mitered door corners in (15) Sec/cycle. -- 1" Material thickness cap., 4" max. material width, 5" max. cutter diameter. Features: -- (2) Pneumatic clamps hold material during operation for safe machining of parts; adjustable stops for dowel drilling; air over oil rodless cylinder driven table. -- Staggered tables with angled fences allow: (2) 1" Thick parts to be machined simultaneously; digital position indicator. -- Dust Collection: (2) 5" Dust ports require approx. 1,000 CFM per spindle.

UNIQUE 79 Face Frame Assembly Table. The UNIQUE Face Frame Assembly System simplifies the assembling process. -- This is to ensure flush alignment of frames reguardless of thickness of material. -- Major face sanding is eliminated. -- 60° Laminated 5' x 8' assembly table, squaring bar. -- Over arm with (5) hold down clamps.

UNIQUE 310 Automatic Cope Shaper; Copes multiple workpieces up to 6" wide x 24" long in only (1) pass, quickly and accurately. -- Equipped with: (2) 5 HP motors with magnetic starter; (2) 1-1/4" dia. counter-rotating cutterheads eliminate tear-out on detail edge of cope/tenon cuts. -- Pneumatic safety clamps hold work in place until sliding table is returned to its forward position.

UNIQUE "318-3" Rail MachineThe UNIQUE "318-3" Rail Machine is designed to cut precise profiles in rails, ideal for higher volume or production applications. Specifications: -- Climb cutting provides better than moulder quality cuts, capable of cutting up to 35 FPM. -- Equipped with: 10 HP HIMMEL Direct Drive Motor, 1-1/4" Spindle with 5-1/4" stack height for tooling with up to (3) cutters on the spindle. -- Max. Material width 8", max. material thickness 2", Z-axis spindle movement adjustable with a digital indicator.Complete with: In-feed fence with digital read out, dust collector hood with 4" outlet; emergency stop and cutter shields.

UNIQUE 82 Face Frame Assembly System The UNIQUE Face Frame Assembly System simplifies the Drilling and assembling process. This combination is designed to ensure flush alignment of frames reguardless of thickness of material. -- Major face sanding is eliminated. -- 60° Laminated 5' x 12' assembly table, squaring bar. -- Over arm with 2 hold down clamps.

Unique 3450 Mortise &Tennon Machine The Model "3450" CNC Mortise and Tenon Miter Machine is a 4-zone machine designed to accept pre-moulded material. The machine will cut a mortise or tenon at a 45° miter to produce a hidden joint mitered door. High precision ball screws to drive each axis, the machine is able to provide an exact tolerance every time. "UMTPro" software can be customized for cutting different shapes and sizes of pre-moulded material. These settings can later be recalled by the operator for a perfect joint every time. Specifications: (2) 6 kW (8.2 HP) Router motors, Work height: 37"; Compressed Air Requirements: 90 PSI - 1.5 CFM; Dust Collection: 6" Port, 2,000 CFM; Machine Footprint: 85" Width x 40" Depth.
