Equipment For Sale

Northtech NT SLR-16SC Precision 16″ Straight Line Rip Saw FEED SYSTEM --Saw motor: 15HP, 3PH 230/460V -- Feed: 1.5HP variable from 40′ – 120′ FPMPRODUCT DIMENSIONS -- Min. thickness: 3/16″ -- Max depth of cut: 4-1/16″ with 16"; Blade -- Max depth of cut: 3-1/16"; with 14"; BladeSpecifications: -- Direct Drive = Direct Drive -- Feed Hp. = 1.5 Hp. -- Feed System = 4"; Split Chain with True Trac -- Feed Speed = 40-120 FPM -- Assisted Start = Wye Delt"; -- Throat Capacity = 18-1/4"; -- Min. Length = 12"; 2nd Roller to Kickback -- Min. Thickness = 3/16″ -- Max. Thickness = 4-1/16"; W/ 16"; BladeGlue Line Rip = Guaranteed 12′ 4/4 stock @ 50 FPMEquipped with & Features -- Blade Size = 14"; Tungsten Carbide Tipped -- Dust Collection = 1417 Total CFM -- Dust Port Out = 4"; Top 6"; Bottom -- Arbor Diameter = 2″ Arbor -- Idle Rollers = (8) Idle Rollers -- Hold Down Style = 8 Spring Loaded Hold Downs -- Kickback Finger = (59) Lower (32) Top -- Automatic Mechanical Oiler -- Low Oil Warning = Low Oil Shut-off -- Laser = 100mw Laser Light & Mount Bracket

Northtech Chop Saw

Northtech 12" Resaw Model NT-HBR12V Self contained hydraulic pack

Northtech MRS-14-DXL 460v Manufacturer notes: This is a very popular machine and cost effective. New open ended design allows for you to cut wide material up to 27-1/8? wide. Plus spare arbors, lasers, and the optional quick locking, easy to adjust infeed will not break the bank. The Northtech heavy-duty 50 HP multi-rip (“gang-rip”) saw with 15? maximum blade diameter quickly and accurately cuts material up to 4-15/16? thick and 27-1/8” wide. Cutting both sides of your blanks at once provides incredible parallelism, reducing required moulder allowance, and increasing your yield. Laser guides (one included) and an optional 103” fence make proper alignment of even the longest material simple and precise. Variable feed speeds of 25 – 120 FPM and powered height adjustment further improve operator efficiency.

NORTHTECH NT-610EL Top & Bottom Planer:24" Wide x 7.5" thick capacity; 1/4" minimum thickness; 12" minimum stock length.Specifications: -- Cutterheads: 25 HP top head; 20 HP bottom head; 5,800 RPM on cutterheads; (6) row spiral insert cutterheads, Carbide knives 15 mm x 15 mm x 2.5 mm 4-sided -- Feed works: 3 HP variable speed feed with speeds from 20 to 75 FPM; 1 HP motorized raise and lower of bed; DP-525 digital thickness controller; Overhead carpet style feed system Equipped with & Features -- Sectional chip breaker; Hard chrome plated bed; Automatic lubrication for feed system; Amp load meter -- Dust Requirements: 3,800 CFM; (1)10" and (1) 7" dust outlet Seller states this machine has less than 600 Hours of use.

2007 Northtech NT-CS14R-53 3 phase 460 volts 5 horsepower SN 07113 Operates good

NORTHTECH - NT-920C-200: 2-Head Planer Sander Specifications -- 2-Head. 37" width cap.; 1-knife planer head followed by a wide belt sander head. -- 0" - 6" Motorized opening with: PLC control; keypad entry; LED readout for part thickness. -- 1st Head. 6" Dia. helical planer head with: (6) Rows of staggered carbide inserts; each insert has (4) usable sides; 30 HP motor. -- 2nd Head. Combination sanding head with: 4-5/8" Dia. rubber covered contact roll; 2-1/2" wide finishing platen; 20 HP motor. -- 37" x 75" Abrasive sanding belt; solid-state belt tracking. -- 3 HP Variable feed drive from 15 - 50 FPM; endless belt conveyor with automatic tracking.Complete with: -- Infeed over thickness bar. -- Emergency stops at infeed & outfeed. -- Air-operated disc brakes on sanding heads. -- Electrical interlocks on main access doors. -- Electrical controls with overload protection. -- Motor load meters. -- Panel cleaning brush.

NORTHTECH - NT-KL-920-PRK- B & NT-KL-920 PRK-U, ...Top & Bottom 3-Head Planer Sander3-Head bottom with: Planer, drum and platen; 3-head top with: Planer, drum, and platen 920 mm (36") wide.Capacity: 36" x 5" thickness.SpecificationsBottom Machine Model: "NT-KL-920 PPR". -- Infeed driven Conveyor: 37" x 72" Long. -- 1st Head: Spiral cutterhead; (8) rows of 15 x 15 x 2.5 mm inserts carbide knives; (4) sides for rotation; low tool cost.Cutterhead: 175 mm (7") Dia. and 50 HP motor. Segmented chip breaker before the cutterhead. -- 2nd Head: Contact roller; (280 mm) 11" in dia.; 70 durometers, powered by a 40 HP motor; running at 3,600 FPM belt speed.Sanding belt size: 85" x 37". -- 3rd Head: 3-1/4" Pneumatic Polishing Platen; engineered as a combination station, air-cushioned & adjustable in pressure to various grits and materials application. Powered by a 30 HP motor. -- Lifting & lowering conveyor bed; 1-1/2 HP motor (includes auto. thickness setup device). -- Variable speed: 7.5 HP; inverter duty motor integrated with an AC inverter (VFD); control providing variable feed rate from 15 - 70 FPM for heavy calibration; LED readout feed speed indicator. -- Microprocessor Control for: Conveyor bed positioning to high precision via keypad entry. -- Automatic electronic preset panel thickness gauge/micrometer. -- Automatic Air Jet blast cleaning system on both sanding heads.Top Machine Model: NT-KL-920 PRR-U -- 1st Head - Spiral Cutterhead: (8) Rows of 15 x 15 x 2.5 mm inserts carbide knives; (4) sides for rotation; low tool cost.Cutterhead: 7" (175 mm) Dia.; 50 HP motor.Segmented Chip Breaker: Before the cutterhead. -- 2nd Head - Contact Roller: 11" (280 mm) Dia.; 70 durometers; powered by 40 HP motor; running at 3,600 FPM belt speed.Sanding belt size: 85" x 37". -- 3rd Head - 3-1/4" Pneumatic Polishing Platen: Engineered as combination station; air-cushioned & adjustable in pressure to various grits and materials application; powered by 30 HP motor. -- Lifting & lowering Conveyor Bed: Motor 1.5 HP (includes auto. thickness setup device). -- Variable speed 7.5 HP inverter duty motor; integrated with AC inverter (VFD) control; variable feed rate: 15 to 70 FPM for heavy calibration; LED readout feed speed indicator. -- Microprocessor Control: For conveyor bed positioning to high precision via keypad entry. -- Automatic electronic preset panel thickness gauge/micrometer. -- Automatic Air Jet blast cleaning system on both sanding heads. -- Powered dropdown Conveyor between Bottom & Top machine.Features (includes both machines) -- Massive monoblock base: 3/4" Thick plate steel weldments. -- Large dia. roller hold-downs; ball bearing supported; 65 duro UV rubber are standard features. -- Automatic soft start of main motors (Y-Delta). -- Disc braking/emergency shut down protection for: Sanding belt breaking, non-tensioned sanding belt; and mistracking of sand belt. -- All motors & electrics are CE-approved. -- Electronic oscillating belt tracking system. -- Au

Northtech MRS-12N Gang Rip 50 HP Motor Needs a new safety with on the door

16 HP 12 filter bags up 4 collection bags lower Lots of pipe

6” width capacity 8” thickness capacity 30 hp main motor, 1.4 hp feed motor 3 hp blower motor…460 volt 3 phase 559 rpm blade speed digital oiling

Multiple Rip Saw with One Fixed and One Moveable Blade Two 10 HP Saw Motors, One for Each Blade Width of Fence Movement from Fixed Blade: 0" - 9.45" Moveable Saw Blade Traverse (From Fixed Blade): .78" - 8.35" Minimum Working Length: 12" Maximum Cutting Thickness: 2.56" Maximum Width of Cut from Fence: 17.71" Saw Blade Diameter: 12" Arbor Diameter: 1" Arbor Speed: 4,500 RPM Aluminum Chain w/ Rubber Slat Inserts Width of Feed Chain: 11-3/4" Feed Motor: 2 HP Variable Speed Feed from 39 - 98 FPM Three Rows of Upper Anti-Kickback Fingers Width Setting Drive Motor: 2 HP

NORTHTECH - NT-SL2000XL, ...Straight Line Rip SawSpecifications: -- 20 HP Direct Drive Straight Line Rip Saw. -- 2" Arbor. -- Distance from column to blade: 18 in. -- Saw blade size: 10" - 14". -- 3-1/8" Cutting capacity. -- Glue Line Saw. -- Feed Motor: 1.5 HP. -- Feed Speed: 20 - 105 FPM.

Northtech FR-200 Frame SawSpecifications: -- Saw capacity of 6" width x 8" vertical capacity. -- Minimum working 2"; high X 12"; long. -- Main drive motor to saw frame is 30HP 3PH, wired 460 --V servo drive system to feed works is 1/4HP 3PH, --Blower to saw frame rack for added cleaning value is 3HP 3PH, -- Body of frame saw is (2) sections allowing for fast access to the saw frame, -- Saw blade speed is fixed at 550RPM, -- Dust extraction requires min 3000 CFM and is arranged with (4) 5" ports, -- Blade size is standard with 500mm L x 40mm W x 0.9mm body in stellite or TCT tip,Equipped with & Features -- Digital electronic oiling system provides proper lubrication to the saw frame guides -- Vertical rail system which allows optimum cooling and long term durability, -- (4) guide blocks are thermo- censored to allow auto shut-off of machine should possible heat buildup occur.Machine dimensions 122"; L X 40"; WX, 79"; H weight 7100 lbs. Machine was new in 2007.

Norwood LumberPro HD36 23hp (627cc) B&S V-Twin OHV electric start gas engine , 4 ft. bed extension for 16 ft. total , log rolling ramp, auto dog assist. Used as hobby mill - low hours. Includes any new blades available jack stands for levelling Stationary now but can easily converted to mobile.From Mgf.

NOVA TTF-6200 Dry Kiln System; Unassembled Front Load Kiln Designed to hold 5,100 bd. ft 4/4 Lumber, or 6,120 bd. ft 8/4 Lumber, Using 3/8" (9 mm) stickers. -- Specifications: Interior Dimensions: H 10' 3,5" (3.14 m), D 7'2"(2.19 m), W 25' 3" (7.7 m). -- Loading Door Opening: H 9' 10" (2.85 m), W 25' 3" (7.7 m). 1/8 " Aluminum sidewall bumpers, side hinged doors, exterior installation. -- Average 4/4 capacity: 5,100 bd. ft (12 m3) with 3/8" (9 mm) stickers. -- Average 8/4 capacity: 6,120 bd. ft (14 m³) with 3/8" (9 mm) stickers. -- Price shown is for kiln only. -- High horsepower heat requirement: 128 k BTU/hour. -- Heated Floor System, manuals and blueprints. -- Electrical Requirements: 230 VAC, 1 Phase, 60 Cycle, 25 kw/Hr max.

(2) Unassembled front load Kilns only System with high HP heat and exhaust designed to hold 8,461 bd/ft (20 cub.m) of 3/4" (25 mm) lumber and 10,475 bd/ft (25 cub.m) of 8/4" (50 mm) lumber (35 cbm). -- Kilns internal dimension: Height 12'3-1/2" (3.75 m), Depth 16' (4.88 m), Width 21' (6.4 m). -- Loading door opening of 10' (3.05 m) x 21' (6.4 m); 1/8" aluminum side wall bumpers, side hinged doors, exterior installation. -- High HP will service the heat requirements up to 245k BTU/Hr. -- Electrical requirement of 230 VAC, 3-Phase, 60 Cy; 7.21 kW/Hr. -- System includes: Timber Dry management automated Dry Kiln Controls for each kiln, touch-screen operator interface, data recording, optional remote access, and networking capability, Replacement part kit for a kiln. Manuals & Blueprints

Nova Dry Kiln 26’ wide x 25’ deep holds 5500-12000 board feet propane or Natural Gas fired

Unassembled Front Load Kiln with Standard Heat and Exhaust -- Interior dimensions: H 17' 6" (5.33 m), D 25' 8" (7.8 m), W 26' (7.9 m). -- Loading Door Opening: height 14'6" (4.4 m), width 25'3" (7.7 m). 1/8" Aluminum Bumper Walls, Top Hinge Door, Exterior Installation. -- Average 4/4 capacity: 25,459 Bd Ft. with 3/4" stickers. Average 8/4 capacity: 33,293 Bd Ft with 3/4" stickers. -- Price shown is for kiln only. -- Standard HP Heat requirement: 382k BTU suitable for drying dark hard woods; Optional high HP Heat requirement: 674k BTU suitable for drying softwood and white hardwoods. -- Electrical requirements: 480 VAC, 3 Ph., 60 Cy; 16.5 kW/Hr. Timber Management Control System with touch screen operator interface, data recording, remote access & networking capability. -- Features: Control room with heated air intake; 12'H x 4'D x 26'W. Top Hinge door opening System includes "230" electric chain hoist. Boiler Room: 12' W x 25' D x 17'6" H. 10' roll up & (1) access door. - Timber Dry Management Network Capability.

NOVA PELLET - N-Plus Plant Complete Wood Pellet Manufacturing Plant including Dryer and Bagging Line: -- Capacity: 1.5 - 2.4 tons/Hr (1.4 - 2.2 metric tons/Hr). -- Raw Material: Wood chips, sawdust, and wood shavings. -- Power: 523 HP (390 kW) installed, 443 HP (330 kW) average.The Pellet Plant consists of the following main components: -- (1) Wood Chip Hopper: 706 cu. ft. (20 cbm) volume; includes: Discharge Screw and Motor. -- (1) Rotary Drum Dryer: 1.5 - 2.0 Tons/Hr (1.4 -1.8 metric tons/Hr) dry material capacity, moisture reduction from ...25% to 12% (Optional: Dryer for higher moisture contents); includes: Cyclone, Rotative Valve, Electrical Cabinet with PLC (Optional: additional Dust Filter). -- (1) Biomass Burner: Approx. 955 Lbs/Hr (433 kG/Hr) Wood Chips, max. 45% moisture content. -- (1) Magnetic Separator. -- (1) Hammer Mill: 1.6 - 2.2 tons/Hr (1.5 - 2.0 metric tons/Hr) dry material capacity, 177 HP (132 kW) installed power, 1.2" x 0.78" x 0.2" (30 x 20 x 5 mm) max. grain size. -- (1) Dry Chip Silo: 1,130 cu. ft. (32 cbm) volume, 154" (3,900 mm) diameter, 476" (12,100 mm) height; includes: Dust Filter, Pulse Jet Cleaning System, Safety System with Spark detection, and Rotative Valve. -- (1) Pellet Mill (Type: N-PLUS): 1.5 - 2.2 tons/Hr (1.4 - 2.2 metric tons/Hr) capacity; 215 HP (160 kW) main drive; includes: (1) x Die, (2) x Rollers, Electrical Cabinet with PLC. -- (1) Vibrating Screen. -- (1) Pellet Cooling Column. -- (1) Double Pellet Bin: 159 cu. ft (4.5 cbm) volume. -- (1) Automatic Packaging Machine: (5) bags/minute capacity; includes: Screen, Conveyors, Storage Hopper, Pneumatic Valve, 15 kG Bags, semiautomatic Pallet Wrapping machine. -- Auxiliary Equipment: Conveyors, Ducts for Dedusting, Fan for Silo loading, etc. -- Shipment to US port; Mechanical & Electrical installation, start-up, and training included.
