Equipment For Sale

FD21 Waratah sawhead from a JD cutter

WEB MECAHNICAL JET 10M Jet Air Oven Supply Side complete with the following: -- 400,000 BTUH rating, 3,200 CFM forward curved blower, 5 HP motor 575 V /3 Ph /60 Cy. -- Inlet filter section HEPA 99% DOP rated, Magnehelic gauge across the filter section. -- Thermometer to show outlet temperature, Thermostat to set and control temperature design from 60° -70° C, -- Jets designed to control flow across the belts. Exhaust Side complete with the following: -- Vane axial fan set to exhaust 600 CFM,1/2 HP motor. -- Direct drive fan with motor out of air stream, external grease fittings for lubrication.Heating Module: -- Air makeup sized for 3,200 CFM, 2 HP motor, rated for 400,000 BTUH. --Fan to exhaust through 2"; pleated filter and 12"; HEPA filter, Down discharge,3 HP motor, 3,200 CFM @ 2.0"; E.S.P. -- Engineered for 90° F temperature rise, 0.4 MBTU/hr hydronic coil, features FUJI temperature selector. Conveyor: -- Robust 10-gage steel frame, Novo 40 grey belt designed for up to 90° C and with Auto tracking mechanism. -- Large size 6"; driver and idler pulleys, Support pulleys 3"; as required. -- Heavy duty NORD gear box and a 2 HP direct coupled motor. OPTIONAL (Not included in Price):IR Adder (Lamps): -- Three (3) MW IR lamps in the center of the oven, Three (3) MW IR lamps at the end of the oven, -- Heated length of lamps 54";, dual gold plated element, 3,200 watts per bulb. -- Lamps are designed to sit between the jets on the oven with lamps 8"; (200 mm) above belt and 8"; apart. - Please add ...$ 7,700Control Panel for the above (600 V - Electric) complete with: -- Line interlock, E-stop, fuses, disconnect switch, DC power supply. -- Phase angle controller to control two (2) banks of three (3) lamps. CSA approved panel. - Please add ...$ 12,100BOILER: -- One (1) RBI dominator boiler "DB 600" to supply up to 600,000 BTUH. - Please add ...$ 18,900

WEB MECHANICAL HYDRONIC OVEN - Low Velocity Flash Off - STAGE # 1 and High Velocity Bake Oven - STAGE # 2 STAGE # 1, Low Velocity Flash Off Oven. -- The oven consist of one (1) only hot water oven, 14' wide x 9' high x 30' long with Air flow requirement of 30 FPM/ 9,000 CFM.Supply side complete with the following: -- 400 000 BTUH heat exchanger -- Motor/blower, 2 HP 575 V / 3 Ph / 60 Hz -- Thermometer to show outlet temperature -- Thermostat to set and control temperature to design temperature -- RTD's (1) for accurate oven dispersion temperature -- Eighteen gage galvanized steel panels -- Perforated metal side walls for even air distribution -- Design temperature of 30 -40°C -- Adjustable inlet mixing damper with intake filter (70% recycle) -- Exhaust fan for combustible gasesExhaust will be complete with the following: -- Size 14 direct drive aluminum fan wheelset to exhaust 30% of the contaminated airflow (2,500 CFM) -- Direct drive with the motor out of air stream -- External grease fittings -- Fan module c/w aluminum extrusions and galvanized panels, and will be complete with HEPA style filter, -- DWDI fan, space for hot water heat exchanger STAGE 2 HIGH-VELOCITY OVEN BAKEThe oven consist of one (1) only hot water oven, 14' wide x 9' high x 20' long with Air flow requirement of 50 FPM/ 9,000 CFM Supply side will be complete with the following: -- 1,500,000 BTUH heat exchanger -- 10,000 CFM -- Motor/ blower 5 HP 575v / 3 Ph / 60 Hz -- Thermometer to show outlet temperature -- Thermostat to set and control temperature to design temperature -- Eighteen gage galvanized steel panels c/w 3" insulation -- Perforated metal side walls for even air distribution -- Design temperature of 40 - 60C 104 - 140 F -- Adjustable inlet mixing damper with intake filter (85% recycle) -- Exhaust fan for combustible gases Exhaust will be complete with the following: -- -- -- Size 12 direct drive aluminum fan wheelset to exhaust 15% of the contaminated airflow (1,500) CFM) -- Direct drive with motor out of air stream -- External grease fittings There will be two (2) air knives one at start of the oven and one art the exit to control heat and fume exhaust Air knives will be complete with Multivee filters for inlet air Fan module c/w aluminum extrusions and galvanized panels will be complete with HEPA style filters, DWDI fan, space for hot water heat exchanger.

Webb Dryer System

10x40 Triple Pass Drum Dryer Webb Dust Burner All piping and controls Cyclone Additional blower Airlock

Webster 30" x 25' Vibrating Conveyor

(2) Webster 18’ x 30’ Vibration Conveyor

Webster Vibrating Conveyor 50' long x 18" wide Includes Chipper Transition

Webster Vibrating Conveyor 18” Bottom, 57’ Length

Webster vibrating conveyor, 18" wide pan x 25' long, electric drive, includes chipper feed spout, good working condition

Webster vibrating conveyor, 18" wide pan x 20' long, electric drive, good working condition

WEEKE BHC 555 OPTIMAT CNC MACHINING CENTER (W/ATC/BORING/"C"AXIS): -- Specifications:Working Capacity:"X" Axis 167" (4,250 mm), "Y" axis 59" (1,500 mm), "Z" axis stroke is 14.6" (370 mm), max material thickness 6.6" (170 mm) when routing & 4" (100 mm) when using all other units. -- Positioning Speed:"X" axis is 263 FPM (80 MPM), Y-axis 197 FPM (60 MPM), Z-axis 65 FPM (20 MPM). -- Worktable:(8) Movable "K-Table" support rails with (6) side mounted raise-and-lower panel feeding rails; LED light bar positioning assistance;(3) Matrix vacuum pods per support, rubber seals in the matrix of the vacuum pod makes it possible to hold 50 mm wide strips. (8) Pneumatic back stops for large panels, (8) pneumatic front stops for small (narrow) panels, (2) movable pneumatic side stops that create (2) working zones. -- Boring unit:3.5 HP (2.7 kW) motor with variable programmable spindle speed from 1,500 -7,500 RPM, "Quick Change" tooling.(23) Independent vertical spindles, (15) spindles in "X" axis & (8) in "Y" axis(6) Horizontal spindles with (2+2) spindles in "X" axis & (1+1) in "Y" axis;(1) "X" Axis grooving saw with 100 mm dia. saw blade cap, 2 HP (1.5 kW) variable speed motor from 2,000 -7,500 RPM. -- Machining units:(1) 12 HP (9 kW) liquid cooled Electro spindle with HSK F63 adaptor, variable speed from 1,200 - 24,000 RPM & constant torque from 9,000 RPM, RH & LH rotation;(1) NC controlled "C" axis for 360° horizontal processing.(16) Total ATC positions with (1) 8-position ATC tool plate magazines mounted on the head for "on the fly" ATC & (1) 8-position ATC tool plate magazines mounted at the back of the machine.The machining unit is controlled by a "KEB" solid state frequency inverter, the inverter output is programmable through the control. -- Operator Interface:Weeke IPC "MMC Control" + Windows "XP" + "WOODWOP 5.0" operating system; "Beckhoff" programmable logic (PLC) to ensure high-speed precision for axes, linear, circular & helical interpolation15" High resolution TFT color graphic monitor, industrial keyboard for data entry; 20.0 GB hard drive, 128 MB of RAM1.44MB Floppy & CD ROM drive,EtherNET interface for LAN connection to office PC is possible; report generation software included; post processor for DXF file conversion is includedRS-232 serial interface & USB ports for simple PC connection; all mounted in separate free-standing control cabinet. -- Complete with:(1) 100 m³/Hr Vacuum pump; scrap conveyor; safety mats & safety fencing; original docs/manuals. -- Actual Model is WEEKE BHC 555 OPTIMAT

Please see full specification in documents section. Number of vertical drilling spindles 25 Vertical drilling spindle power 2.7 kW/3.5 HP Vertical drilling spindle speed 1,500 to 7,500 rpm Number of horizontal drilling spindles 6 Horizontal drilling spindle power 2.7 kW/3.5 HP Horizontal drilling spindle speed 1,500 to 7,500 rpm X-axis grooving saw power 2.7 kW/3.5 HP X-axis saw rotation speed 2,000 to 7,500 rpm Saw blade diameter required 100 mm/4” ATC router spindle power (power constant from 9000 rpm to 18000 rpm) 9.0/12.0 kW; 12.0/16.0 HP ATC router spindle speed 1,200 to 24,000 rpm Tool magazine capacity 2 x 8 tools HSK63 tool holders supplied 4 Collets for HSK63 tool holders 4 Number of panel support benches 8 Number of vacuum pods per bench/total 3/24 Number of panel feeding rails 6 Vacuum pump capacity 100 M3/hr Length of machine 7580 mm/24’ 10” Width of machine 4650 mm/15’ 3” Height of machine 2820 mm/111” Working length 4250 mm/167” Working width - support bench width 1500 mm/59” Max. panel thickness 125 mm/4.9” Machine weight 6200 kg/13,700 lbs. Max. drilling depth for through holes 55 mm Axis stroke/positioning speed X-axis 5050 mm/80 M/min Y-axis 2150 mm/60 M/min Z-axis 370 mm/20 M/min C-axis 0-360°

--MAKE OFFER!---VERY GOOD CONDITION-- WEEKE BHP 100/VANTAGE 480 FLAT TABLE MACHINE, with ATC, Boring, Infeed Roller & Outfeed & 4,771 Hrs. (As of 10/31/23) Specifications: 4' x 8' Bridge style gantry machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. Working Area: 'X" axis 99.21" (2,520 mm), "Y" axis 49.21" (1,250 mm), Max. material thickness of 3.94" (100 mm). Travels: “X” axis 146.06” (3,710 mm), “Y” axis 81.30” (2,065 mm), “Z” axis 13.70” (348 mm) Routing, 8.46” (215 mm) Boring. Positioning Speed: "X" & "Y" axis Vector speed is 314 FPM (96 MPM), "Z" axis 65 FPM (20 MPM); The head travels via AC brushless drives & THK linear motion guides on all axes. Worktable: User-Friendly "S/C Tech "MATRIX" grooved phenolic vacuum table for easy vacuum pod placement. (2) Fixed LH side & (2) Fixed RH side pneumatic pop-up positioning stops. Boring Unit: (1) 3 HP (2.3 kW) Motor, variable speed for 1,500 - 7,500 RPM; (21) Independent vertical spindles with (8) in "X" axis, (9) in "Y" axis (1st Row), & (4) in "Y" axis (2nd Row). Machining: (1) 12 HP (9 kW) Air Cooled High speed constant duty Router with HSK F63 adaptor, 1,250 - 24,000 RPM, constant torque achieved at 9,000 RPM, RH or LH rotation (1) 14-Position tool changer Carousel located at the back side of the spindle carriage. Machine & Operator Control: PC Front-End with WEEKE "Power Control + Windows + WoodWOP operating system. 17" TFT Color graphic monitor, Hand-held control pendant, Foot pedal control; "BECKHOFF" Programmable logic control for (3/4) axes, linear, circular & helical interpolation; The controller is contained in a separate free-standing, dust-free control cabinet that can be placed at either the LH or RH side of the machine. Complete with: 488” W x 96” L Infeed electric/hydraulic Scissor Lift platform, with 3” x 3” Support beams on 7” Centers; 4’ L Roller track intermediate table; vacuum arm with (2) 10” dia. vacuum pads; rake off-feed System; 49” W x 10’ L x 36” H Outfeed motorized belt conveyor; BUSCH "MM 1322 A VM3" 10 HP (7.6 kW) 300 mbar Vacuum Pump; 6’ H Safety fencing. Actual model is WEEKE BHP 100/VANTAGE 480 Machine Dimensions: 292” x 202” x 96” H. Machine with Scissor Lift Dimensions: 389” x 202” x 96” H. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

WEEKE ABD 050 CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:(1) Horizontal drilling aggregate with (1) individual spindle; with servo control of the "X" Axis; (1) glue & dowel injector with glue flow control; (1) vibrating hopper dowel feeder. -- Working Capacity:Part size: Length 20 mm - 1,250 mm (.75" - 49") Width 20 mm - 800 mm (.75" - 31.5") Thickness 10 mm - 60 mm (.4" - 2.4") thick.Machine is set up for 8 mm Dia. x 30 or 35 mm long dowels -- Work Area(2) Separate working fields with (4) pneumatic top clamps can process up to (2) parts independently on the left-hand, right-hand or center stops; work pieces can be loaded in (1) field while being machined in the other to allow fast production of varying parts. -- Operator Interface:PC Front-end with Homag Power Control PC 85T, WoodWOP 5.0 operating system with graphic programming & error messaging.17" TFT flat screen monitor, CD-RW drive, 1.44 MB floppy drive, standard keyboard & mouse; Software allows program design with automatic mirror-image by use of an active center stop located 600 mm (23.6") from zero. -- Complete with:Bar code reader. All manuals, documentation & program disk provided with machine. -- Actual Model is WEEKE ABD 050/12/NA.

Weeke BHC 750 CNC Router (2) Becker Vacuum Pumps

X-Axis Travel: 100? Y-Axis Travel: 68? Z-Axis Travel: 9? Max Workpiece Thickness: 4? Spindle Speed: 1,250 – 24,000 rpm Equipped With: Powerful HSK Router Spindle- Up to 9 kW 6 Pneumatically Fixed Work Piece Supports Safety Positioning of Work Piece Consoles and Vacuum Cups

Weeke Vantech 480 CNC Router 4x8 Table

WEEKE BP 80 CNC MACHINING CENTER: -- Specifications: X-Axis 122.6 (3,105 mm); Y-axis 40.3" (1,020 mm); Z-axis stroke is 5.3" (135 mm); max. material thickness 3.9" (100 mm). -- Positioning Speed:X-Axis is 213 FPM ((65 MPM); Y-axis 164 FPM ((50 MPM) & Z-axis is 49 FPM (15 MPM); head travels on THK linear ways on all axes. -- Worktable:(6) Movable support rails with: (2) Square matrix vacuum cups ea.; (6) pneumatic backstops & (2) pneumatic side stops creating (2) working zones. -- Boring Unit:2 HP (1.5 kW) Motor; (11) independent vertical spindles: (6) in X-Axis & (5) in Y-axis; (6) horizontal spindles with (1 + 1) in X-axis & (1 + 1) in Y-axis; (1) X-axis grooving saw with 100 mm dia. blade. -- Machining:(2) 7.5 HP (5.6 kW) High speed routers with: "Hydro-Grip" Spindle & EPT 25 adaptors, 6,000 - 18,000 RPM; controlled by frequency inverter. (One of the router spindles is not operational & needs rebuilding.) -- Operator & Machine Control:PC Front-End with: HOMATIC + Windows + WoodWOP 4.0 Operating System; NUM PLC for (3) axes; linear, circular & helical interpolation;15" monitor; keyboard for data entry; floppy disk drive; 40 MB hard drive,;32-bit processors; RS-232 port for possible connection to office PC; all mounted in separate free-standing control cabinet. -- Complete with:(1) 40 cbm/Hr Vacuum Pump; safety mats. -- Actual model is: WEEKE - BP 80
