BLACK BROTHERS - 22-D-875-32, ...Top Only Glue Spreader.Capacity 32" Working width. -- 8-3/4" Dia. Rubber roll -- 6-1/2" Dia. chromed steel doctor rolls. -- Top elevator opening w/Readout -- Constant pass line: 36-3/4" -- Outfeed roller conveyor -- 7.5 HP MotorComplete with:1 Spare rollerNOTE: Machine is currently wired for 220v

BLACK BROTHERS 22-D-875-74, Wide Format (74") Top & Bottom Glue Spreader74" Working width, 8-3/4" dia. grooved rubber covered applicator rolls, 6-1/4" chrome plated doctor rolls -- Complete with: Push button magnetic starter, safety guards, and safety reversing bar. -- Top elevator style glue spreader, constant pass line --Main Motor 1HP, 3ph --Feed speed 88FPM --Thickness adjustment via manual hand crank

BLACK BROTHERS 22-D-875-74, Wide Format (74") Top & Bottom Glue Spreader74" Working width, 8-3/4" dia. Grooved rubber covered applicator rolls, 6-1/4" hard rubber covered doctor rolls --Main motor 1.5hp -- Bottom roll adjustment -- Complete with: Push button magnetic starter, safety guards, and safety reversing bar.NOTE: Currently wired for 460v

BLACK BROTHERS - Cold Press Laminating Line (Complete)with: BLACK BROTHERS - APP PL: 5 x 12, 50 PSI End-Loading Fixed Opening Air Pod PressCurrent line setup: Infeed Scissor Lift; Panel Pusher; Panel Cleaning Brush; Glue Spreader; Stack building Scissors Lift; Laminate Rack over Conveyor; Stack Staging; Press Loading Conveyor; Cold Press. -- Station 1: Pneumatic Panel Feeder. Panel Pusher feeds individual panels from side loaded (w/Forklift) Scissor Lift into Panel Cleaner. Photoelectric eye activates arm that pushes panel into Panel Cleaner. Pusher Arm: Feed panels into machine on demand. Switch: Remote mounting. Pass Line: 44"; 24" Stroke with 4' of adjustment: Feeds panels from 1/2 thickness (up to 250#) in lengths of: 8', 10', or 12'; controls on (Left or Right). NEMA 12 Enclosure with: Main power disconnect switch & overcurrent protection: 230 or 460 Volt: 3-Phase; 60 Hertz, 24 VDC Control Circuits. Dual Limit Switch Arrangement controls the Scissors Lift with: "Hand/Auto" selector; Barrier Guard to prevent double board feed. -- Station 2: Scissors Lift. 36" Vertical travel foot operated raise/lower switch. 48" x 120" Plain deck with: 6,000 Lbs Capacity. Pin adjustable edge guides, mounted on: SL & Anchor Clips for mounting. Transverse Conveyors with: Air brake to allow loading or unloading from side. -- Station 3: MIDWEST AUTOMATION - PC160: Panel Cleaner. 63" Working width capacity; (2) spiral type cleaning brushes; 0" - 3" thickness opening; single end adjustment with roll opening (scale-type) indicator. Variable feed speed 30 - 150 FPM with: 1 HP - 1,725 RPM Drive; (2) 6" dia. infeed & (2) 6" dia. outfeed rolls; variable brush speed with: 3 HP Motor. - Equipped with: All guards, dust hoods, and magnetic starter. -- Station 4: BLACK BROTHERS - 775: Top & Bottom Adhesive Spreader; 68" width capacity. Application: Apply water-based adhesive to top & bottom particle board, plywood, and MDF substrate. Upper Elevator: 0 - 4-1/2" Opening. Roll opening indicator: Shows opening between rolls in 0.001 increments. Riser Base: 44" Pass line height. Caster arrangement: (4) Plain rigid casters with guide track & lock. Coating Rolls: (2) 7-3/4" Max. O.D.; 60 durometer - neoprene/SPR; grooved: 16 TPI. Doctor Rolls: (2) 7" Max. O.D.; 100 durometer - ebonite; ground smooth single-hand wheel doctor roll adjustment with: Mechanical digital readout. - Electrical Interlocks on nip guard(s). NEMA 12 Enclosure with: Main power disconnect switch & overcurrent protection. 1-1/2 HP Single speed with: 3" Reverse lockout 88 FPM. Pivoting infeed table. Operating handwheels & controls: Parallel to the direction of flow on the right; motor on left end. Operating control bars. Liquid level control: FIBER OPTIC. Machine mounted double diaphragm pump: l" Ports; alumi

BLACK BROTHERS - 22-D-875-56, ...Roller Coater56" Nominal length; 8-3/4" dia. applicator, Chrome doctor roll, upper elevator and top only. -- Setup to 0" - 6" thick. -- Smooth EPDM applicator rolls and Chrome doctor rolls. -- Variable feed speed drive, pass line height 34". -- Drip Pan, Feed Pan, Continuous Flow Trough to be Stainless Steel or Teflon Coated. -- Trough for continuous flow 1" pneumatic pump and hose to supply product.Complete With: -- NEMA-12 Electrical enclosure, operating control bars, magnetic brake, electrical interlocks, reverse lockout and cleanup pan.

BLACK BROTHERS - 22-D-875-56, ...Roller Coater56" Nominal length; 8-3/4" dia. applicator, Chrome doctor roll, upper elevator & top only. -- Setup to 0" - 6" thick. -- Smooth Chrome applicator rolls and Chrome doctor rolls. -- Stationary feed speed drive, passline height 34". -- Drip Pan, Feed Pan, Continuous Flow Through. -- Trough for continuous flow 1" pneumatic pump and hose to supply product. -- (30) Day warranty for workmanship and manufacture's warranty for all parts used.Complete with: -- NEMA-12 Electrical enclosure, operating control bars, magnetic brake, electrical interlocks, reverse lockout, and cleanup pan.

BLUE GIANT SFSRH33/575 Scissor LiftHydraulic 3,000 Lbs. scissors lift -- 34" x 108" platform with idle roller -- Low 9" x high 53",Hydraulic pumping unit with 3 HP motor.

BLUM - Mini Press: Hinge Borer -- Tabletop "Mini Drill" unit for BLUM Hinge Boring; 1.5 HP (1.1 kW) - 2,450 RPM drill head assembly for hinge cup boring. -- Head assembly rotates for several hinge & drawer system boring patterns; pneumatic drill cycle with air blow-off. -- Includes: 48" x 24" Tabletop. -- Machine also used for line boring by purchasing an auxiliary BLUM spindle head; not included. -- Complete with: 3-Drawer mobile storage base for all hinge components.

BOARKE - BKM-43103RRK: (3) Head 42″ Wide Belt Sander (3 NEW Drums)43" Width cap.: Drum, drum, platen.Head Configuration1st Head: 30 HP; 10″ Helical grooved drum.2nd Head: 25 HP; 10″ Helical grooved drum.3rd Head: 20 HP; Helical grooved (idler) with a platen. Specifications -- 42″ Width capacity; 5″ height capacity running. -- 43″ X 103″ Abrasives. -- 1st Head: 30 HP; 10″ helical grooved drum. -- 2nd Head: 25 HP; 10″ helical grooved drum. -- 3rd Head: 20 HP Helical grooved (idler) with a platen. -- 1st & 2nd Heads: Dial indicators to dial in abrasives; has optional 5 HP vacuum feed bed.Equipped with & Features: -- Feed: Variable from 7 - 45 FPM via a 2 HP motor; VFD for speed control. -- Feed Mat: Thick; with usual crazing, but plenty of life. -- Elevation: Handled by a 1/2 HP motor. -- Machine includes: Digital readout; touchpad control combined with auto thickness calibration unit on the right.

CAM-WOOD WS-DA4375X DUAL HEAD WIDE BELT SANDERWith the two-head wide belt sander, you can accurately, heavily sand your stock with the first drum head, and with the second combination head, you can give an unlimited fine finish.Application: -- Rugged heavy-duty sheet metal construction designed for durability usage. -- Powerful industrial motors drive sanding and auto infeed smoothly. -- Infeed and outfeed have spring-loaded hold-down rollers to ensure positive feeding without sanding marks. -- Combination platen & drum sanding head for best sanding choice such as: --With the platen up, the sander functions as a drum only machine, for sanding with a 40 ~ 100 grit belt. -- With the platen and drum same level, intermediate and final finishing is possible, using a grit of 120 ~ 180. -- With the platen down (below drum), used for the fine finishing or lacquer sealer sanding, with 180 ~ 600 grit.Head Configuration:1st Head : 30 HP Drum2nd Head : 20 HP Combination HeadSpecifications: -- Max. Working Width 43" Max. -- Max. Working Thickness 5". -- Min Working Length 12½". -- Sanding Belt Dimensions (W x L) 43" x 75". -- Dust Collection Hood (Dia x Holes) 6" x 2. -- Main Motors 30 and 20 HP. -- Conveyor bed Feed Motor 3 HP. --Table Raising / Lowering Motor 1/2 HP -- Variable Feed Speed 20 - 80 FPM. -- Working Air Pressure 6 CFM. -- Exhaust Volume Require 3,800 CFM. -- N.W. weight 6,160 Lbs.Equipped with and Features: -- Sanding platen with a quick release and lock down design for easy removal or loading of graphite platen. -- Computerized thickness adjustment control with accurate digital readout; key in the size desired and automatic table movement for sanding thickness within 0.005"; accuracy -- Large size diameter contact drum is dynamically balanced, rubber covered spiral grooves designed to provide considerable advantages for the effective removal of material. -- Special rubber feed belt for safe non-slipping, transporting the workpieces. -- The abrasive belts are tracked by oscillating cylinders linked to the upper roller. The edge of the belt is detected by an electric eye sensor, which in turn controls the air supply to the position via solenoid value. Also, one limit switch is located on each end of the top roller of the sandpaper for quick stop in case of belt breakage. -- Main table designed with the convenient leveling adjustment which ensures greater stability with excellent tolerance providing a variable from 0"; ~ 5"; range sanding thickness. -- (4) Heavy-duty jackscrews power conveyor table elevation.

CAM-WOOD BR-2132 Boring Machine21-Spindle boring head on 32 mm centers with position indicator.Features & Specifications: -- Stops in 0° & 90° with pneumatically assisted positioning in vertical & horizontal. -- 0" - 3" Adjustable drilling depth with speed control. -- Head height fine adjustment with mechanical digital readout. -- 2 HP - 3,400 RPM Motor. -- Cast iron 37-1/2" x 19-1/4" table with side fences for mirror-image. -- Line boring fence with repeat stops. -- Foot actuated pneumatic clamps & drill cycle.Complete with: Magnetic starter, overload protection. -- Optional: Quick-change chucks $28.00 ea.

CAM-WOOD BR-OO42BX DOUBLE ROW LINE BORERHeavy Double Head Line Borer with (2) 21-spindle heads; 32 mm spindle spacing.Specifications: -- Drilling from the bottom up and with 5-1/2" - 23-1/2" distance between rows. -- Drilling vertically from the bottom allows the chips to drop down falling out of the holes. -- Drilling depth of up to 3" max., takes only seconds to set. -- (2) 2 HP - 3,400 RPM motors; spindles with steel gears & high quality bearings. -- Easy repetition by (2) air index pins for continuous line drilling, left and right roller track supports extend up to 400 mm (15-3/4") for larger panels.Features and Includes: -- 120" Back fence with (4) repeat "flip" stops; includes 27-3/4" (704 mm) fence for quick positioning of flip stops. -- (6) Pneumatic holddowns to automatically actuate when the drill cycle begins. -- (42) "Quick Change" chucks for easy tool change. -- Magnetic motor controls and 1/4" air regulator with filter and oiler; 100 PSI required air pressure.

CAM-WOOD BR-2732X Boring Machine32-Spindle boring head on 32 mm centers with position indicator.Features & Specifications: -- Stops in 0° & 90° with pneumatically assisted positioning in vertical & horizontal. -- 0" - 3" Adjustable drilling depth with speed control. -- Head height fine adjustment with mechanical digital readout. -- (2) 2 HP - 3,400 RPM Motors. -- Cast iron 45" x 31-1/2" table with side fences for mirror-image. -- Line boring fence with repeat stops. -- Foot actuated pneumatic clamps & drill cycle.Complete with: -- Magnetic starter, overload protection. -- Optional quick-change chucks $28.00 ea.

CAM-WOOD BR-3532X CONSTRUCTION BORING MACHINE35-Spindle boring head on 32 mm centers with position indicator.Features & Specifications: -- Stops in 0° & 90° with pneumatically assisted positioning in vertical & horizontal. -- 0" - 3" Adjustable drilling depth with speed control. -- Head height fine adjustment with mechanical digital readout. -- (2) 2 HP - 3,400 RPM Motors. -- Cast iron 52" x 19-1/4" table with side fences for mirror-image. -- Line boring fence with repeat stops. -- Foot actuated pneumatic clamps & drill cycle.Complete with: -- Magnetic starter, overload protection. -- Optional quick-change chucks $28.00 ea.

CAM-WOOD BR-50 Universal Boring MachineFeatures & Specifications: -- 3 HP Pneumatic Universal Boring Machine, all adjustments feature an index plate for accurate and convenient reading, workplace clamping. -- Vertical Base travel, 24". Horizontal Base travel 12". -- 0" - 4" Spindle stroke, 7/16" - 14-thread screw shank, 1/2" max. bit capacity. -- Table Size: 15" x 22". -- Complete with: Air operated overhead holddown clamp and foot pedal operated drill cycle. -- Drill Head can be swiveled 360° and Optional Multi-Spindle drill heads available.

CAM-WOOD BR 25 Horizontal DrillFeatures & Specifications: -- Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back. -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic holddown clamp for up to 3" thickness. -- 12" x 10" Table size. -- 1/2" Drill chuck / 3/4" max. bit diameter.

CAM-WOOD BR 25 + 1 Horizontal and Vertical DrillFeatures & Specifications: The model BR-25+ 1 has the same features as the BR-25, except it's fitted with an additionaluniversal boring head, making it ideal for drilling holes on K/D furniture. -- The boring head can be swiveled 360 degrees for angular drilling, as desired -- Vercical Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back., spindle node threaded 7/16-14" -- Horizontal spindle 2 HP, 3450 RPM-3 phases motor, adjustable 360 degree, spindle nose threaded 7/16-14" -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic holddown clamp for up to 3" thickness. -- 12" x 10" Table size.

CAM-WOOD CC-388PA Clamp Carrier (8 Sections)8-Section Pneumatic Clamp Carrier with 98" length capacity.Equipped with: -- (6) Heavy Duty zinc plated clamps per section (48 clamps total). -- 40" Opening on clamps. -- Jaw sizes of clamps are 3-1/2" with inward draft. -- Pneumatic overhead panel flattener. -- Pneumatic clamp tightener and 1/2 HP electric motor rotation.Standard features: -- Large I-beam frame & legs for max. rigidity and durability. -- Heavy-duty zinc-plated clamp with huge 3/4" diameter jack bolt for super strength. -- Powerful caterpillar chain drive for clamp rotation. -- Select switch control for auto or manual mode.Includes: -- Clamp tightener with pneumatic wrench for rapid tightening and loosening of clamp. -- Pneumatic panel flattener to hold panels flat while clamps are tightened.Versatile and reliable Edge Gluing Machine for Solid Wood gluing, including laminate board, parquet, flat stock, table top, core block, truck flooring, turnings, chair seat, legs, spindle blanks, stair tread, and many others.

CAM-WOOD CC-4108PA Clamp Carrier (8 Sections)8-Section Pneumatic Clamp Carrier with 125" length capacity.Equipped with: -- (8) Heavy Duty zinc plated clamps per section (64 clamps total). -- 50" Opening on clamps. -- Jaw sizes of clamps are 3-1/2" with inward draft. -- Pneumatic overhead panel flattener. -- Pneumatic clamp tightener and 1/2 HP electric motor rotation.Standard features: -- Large I-beam frame & legs for max. rigidity and durability. -- Heavy-duty zinc-plated clamp with huge 3/4" diameter jack bolt for super strength. -- Powerful caterpillar chain drive for clamp rotation. -- Select switch control for auto or manual mode.Versatile and reliable Edge Gluing Machine for Solid Wood gluing, including laminate board, parquet, flat stock, tabletop, core block, truck flooring, turnings, chair seat, legs, spindle blanks, stair tread, and many others.

CAM-WOOD CM3636NA-BX Box / Drawer PinnerBox Nailing Assembler is designed to automatically nail / fasten 4 or 5 pcs with bottom, PB, MDF, solid wood boxes or draw togetherFeatures: Complete cycle to square, clamp and nail / fastens different size and style boxes or drawing, maximum 36"; x 36";. -- Fast and easy operation, 600 to 1,100 units per shift.. -- High Quality and safe processing, automatically senses the materiel and automatic nailing at settled pitch. -- Automatic shutting staples from top to bottom by detecting sensor. -- Clamps from both width & length direction with adjustable clamp pressure for differentthickness or material. Specifications: -- Maximum working capacity 36"; L x 36" W. -- Minimum working capacity 7" L x 7"; W. -- Maximum working height 10", minimum working height 3";. -- Panel thickness 5/8"; tor 3/4". -- Building frame 0 to5 degrees tilted to back side. -- Standard staple gun Senco SNTSLS20 x 4 units (other guns will be optional). -- Staple size 1-1/4"; length, ¼"; crown. -- Automatic shutting staples space distance 1"; (adjustable pitch by 1";). -- Minimum pneumatic required 90 psiOther sizes available with special order.
