Barr Mullin Wondersaw Optimizer with Computerized Laser Controls Tichniess: Up to 3" Width: 31" Min cut: 4" Feed height: 34-1/2" Floor Space: Apprx 21' x 15' 480 volt

Belfab Pyradia NBM-OP Dust Collector (3) Systems available

Machine Equipped as follows: NC 410 PC Based Controller Keyboard with Floppy Drive Automatic Strip Feed Magazine Belt Driven Top Pressure Beam Multi-Coiled Infeed Magazine RT63 Pre-Milling Unit SP20 Glue System w/ Pre-Melt Unit Hot Air Gluing system Automatic Infeed Pressure System T45 Front & Rear End Trimming Units w/Tilt RS10 Top & Bottom Rough Trimming Units RF30 Top & Bottom Fine Trimming Units AR10 4 Motor Corner Rounding Trimming Units RB30 Top & Bottom Profile Scraping Units RC10 Top & Bottom Glue Scraping Units SZ30 Top & Bottom Oscillating Buffing Units PH10 Top & Bottom Edge Heaters Specifications: Min. Panel Thickness:....................10mm? Max. Panel Thickness:....................60mm? Height of Edge-Band Material:…..15-65mm? Min. Banding Thickness:.................0.3mm ? Max. Banding Thickness:........ ...... 20mm? Min. Panel Length:...........................150mm? Min. Panel Width:............................ 100mm? Feed Speeds:.................................10-24m./min? Electrics: ......................................... 460-480V 3 Phase

Biesse Elix B Boring Machine

Manufacturer Specs premill hot glue end trim top/bottom trim corner rounding scraping buffing Computer interface

Biesse Elix K3

Min. Panel Thickness: 0.39? Max Panel Thickness: 2.36? Height of Edge-Band Material: 0.55-2.51? Min. Banding Thickness: 0.01? Max Banding Thickness: 0.39? Min. Panel Length: 5.51? Min. Panel Width: 1.96? 2 Feed Speeds: 39ft/min & 59ft/min Electrical: 230V, 60Hz, 3Phase Equipped With Siemens TD200

Biesse Levia 310-1350 Sander

Biesse Akron 245 Edgebander System is still under power until approx mid-October 2024. Touch PLC will need to be replaced. Everything else is working good on the machine. Owner has had it serviced by Biesse.

Biesse Stream B1 9.0 Edgebander With Doucet Return Conveyer 0.4 mm - 15 mm edge thickness capacity100 mm minimum panel width10 mm - 60 mm panel thickness150 mm minimum panel lengthExternal edgebanding storage and feeding magazinePremill Two (2) motorsGlue station Pre-melt hopper Glue application roller Pressure rollers, one (1) driven, six (6) idleTwo (2) motor end trimTwo (2) motor rough top/bottom trimTwo (2) motor fine top/bottom trimFour (4) motor corner roundingTop mounted milling station for solid wood edge profilingTop/bottom profile scrapeTop/bottom glue scrapeTop/bottom buffTop/bottom hot air blowersPC controlTop feed beltMotorized raise/lower of top beamVariable track speedOutboard roller supportLighted sound enclosuresDoucet return conveyor

Capacity; Edge thickness; strips (0.4 - 22mm) Edge Thickness; coiled stock; (0.4 - 3mm) Panel thickness; 10 - 60 mm (0.39 - 2.36") Work piece width min.;85 mm (3.34") Work piece length min.; 140 mm (5.51") Feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM) Machine Layout Motorized top beam positioning Adjustable infeed fence Pre-Milling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. Infrared Heating Lamp: Preheating workpiece edge to ensure best possible surface adhesion EVA (Hot Melt) gluepot, equipped with quick pre-melting 2 Coil Magazine Pressure Section: Servo controlled programmable pressure section with (1) large driven roller and (4) idle rollers. End Trimming; Front & rear trimming motors, swivel to 0° - 15° bevel, programmable pneumatic change Rough Trimming (first set); Top/Bottom pre- or flush trimming motors Fine Trim/Bevel/Radius Trimming; Servo controlled, pneumatic pre-positioning of motors Corner Rounding; (2) Motor corner rounding Profile Scraping; Top/Bottom 2-axis NC programmable knife positioning Glue Scraping; Flat, top/bottom, digital positioning indicators, pneumatic controlled positioning Buffing; Top & Bottom buffing motors with 150 mm (6") cloth buffing wheel. fully adjustable Hot air blowers Overhead belt hold down Centralize lubrication system External multitap transformer

Biesse Skipper 100 CNC Center Still under power - ready to be packed and shipped!

Biesse Rover 15 Pod and Rail. In Great condition for its age!

Pressure Beam Type: Rollers Pre-Milling Station: 2 Motors Glue Station Pressure Rollers: 4 End Trimming Station: Straight & Bevel (2 motors) Rough Milling Station: 2 Motor Fine Milling Station: 2 Motor Corner Rounding Station: 2 Motor Flat Scraping Station: Top & Bottom Profile Scraping Station: Top & Bottom Buffing Station: Top & Bottom Heat: Top & Bottom Panel Height: 10-50 mm Edge-banding Material Height: 13-55 mm Min. Thickness of Edge-Banding Strip in Rolls: 0.4-3 mm Max. Edge Thickness w/Trimming Unit: 8 mm Max. Edge Thickness w/o Trimming: 3 mm Max. Section of Solid Wood: 8 x 55 mm Panel Protrusion from Track: 25 mm Min. Panel Length: 150 mm Min. Panel Width (150mm Length): 85 mm Min. Panel Width (250mm Length): 55 mm Chain Feed Speed: 12 m/min Dimensions: 18' L x 4' W x 5' H Weight: 4,000 lbs Electrical: 230 V 3 Phase

Pressure Beam Type: Rollers Pre-Milling Station: 2 Motors Glue Station Pressure Rollers: 4 End Trimming Station: Straight & Bevel (2 motors) Rough Milling Station: 2 Motor Fine Milling Station: 2 Motor Corner Rounding Station: 2 Motor Flat Scraping Station: Top & Bottom Profile Scraping Station: Top & Bottom Buffing Station: Top & Bottom Heat: Top & Bottom Panel Height: 10-50 mm Edge-banding Material Height: 13-55 mm Min. Thickness of Edge-Banding Strip in Rolls: 0.4-3 mm Max. Edge Thickness w/Trimming Unit: 8 mm Max. Edge Thickness w/o Trimming: 3 mm Max. Section of Solid Wood: 8 x 55 mm Panel Protrusion from Track: 25 mm Min. Panel Length: 150 mm Min. Panel Width (150mm Length): 85 mm Min. Panel Width (250mm Length): 55 mm Chain Feed Speed: 12 m/min Dimensions: 18' L x 4' W x 5' H Weight: 4,000 lbs Electrical: 230 V 3 Phase

Biesse Akron 245 Machine was in good working condition when removed from service. Computer works, but the screen does not.

Working Capacity: "X axis 125.9" (3,200 mm), "Y" axis 52" (1,320 mm), "Z" axis stroke 13.7" (350 mm), max material thickness 9.6" (245 mm). Positioning speed:"X" 262 FPM (80 MPM), "Y" Axis 196 FPM (60 MPM), "Z" axis 98 FPM (30 MPM) AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. Work Table:(6) Tube-less panel supports with lifting bars for heavy panels, (3) ATS vacuum pods per panel support (6) Pneumatic back stops, (6) pneumatic front stops, (2) pneumatic side stops & (2) pneumatic central stops. Boring Unit:4 HP (3 kW) motor with variable speed from 1,500 - 7,500 RPM; (18) "Quick Change" independent vertical spindles with (9) spindles in "X" axis & (9) spindles in "Y" axis;(8) horizontal boring spindles with (2+2) in "X" axis & (2+2) in "Y" axis;(1) 0° - 90° NC controlled "X"-"Y" Axis grooving saw for max 200 mm dia saw blade. Machining:(1) 17 HP (13 kW) Liquid Cooled "HSD" electro-spindle router with HSK F63 adaptor, variable speed from 3,000 - 22,000 RPM;(26) Total ATC positions with (1) 8-Position ATC tool plate located on the machine head for "on the fly" ATC Operator & Machine Control:PC Front End: Biesse "BH 600" + BiesseWORKS Advanced + WINDOWS "XP" operating system,15" TFT monitor, full standard keyboard & mouse, CD ROM disk drives,RS 232 & USB ports, Ethernet connection, specific function controls & and internet trouble shooting capabilities;Control cabinet with air conditioning & dust free environment. "Biesse WORKS" is a multitask operating system, input/output modules, axes override, 4-axes interpolation, diagnostic graphics aid for programming, machine data & tool management. Complete with:(1) 250 m³/Hr vacuum pump; automatic lubrication system; original documentation; hand held pendant; safety fences & mats; scrap conveyor;

Max. Width: 51.2? Thickness: 0.4? – 1.6? Min. Depth: 4.7? X Axis:51.2? Head Movement Speed: 131.2 ft/min Z Axis: 1.6? Boring Unit: Rotation Speed: 6000 rpm Depth: 1.2? Max. Bits Diameter: 0.47? Modified Dowel Insertion Size: .19? to .24? Standard Dowel Insertion Unit: Standard Dowel Dim: 0.31? x 1.18? Max. Dowel Projection: 0.55? Glue System: Glue Tank Capacity: 2.1 gallons Max. Glue Density: 900 cps Equipped With: – The Smart-Shot Dowel Insertion Unit – 2 Sensors to Prevent Dowel or Glue Misfire. – Dowel Unloading System – Glue Electronic Proportioning – Glue Injector Sensor

?????Rover 24 FIXL CNC Router

Carolina Machinery Sales (CMS) is proud to offer Thermo-Modification Technology from the Italian manufacturer Big on Dry. ????Big on Dry has improved the Thermo-Modification process with their THERMOWOOD (THW) line and provides complete "turn key" systems. The PLC control systems allow programming for a wide variety off wood applications. This allows the same systems to work with very delicate wood that is hard to treat to thicker wood that will be used for outdoor products. The THW system can also be used as a conventional kiln with steam. Basic systems include: - Kiln completely built with stainless steel and aluminum - Initial humidy of 10-15% is reduced to 5-6% - Loading options: Side or Trolley - Heating options: Gas or Wood Burner - Humidification: Combined Spraying System - Controls: Fully Automatic Controls with PLC - Interface & Software: Allows communication with Big on Dry technicians to provide online support - Complete installation and training in the USA Contact CMS to get a quote for your Thermal Modification system
