woodworking Equipment For Sale

WEINIG Powermat 2400 Feed Through Moulder; 5-Heads, (B-R--L-B-T), working capacity 230 x 160 mm (9-1/16" x 6-5/16").Specifications: -- Max working width 230 mm (9 1/16") -- Min working width 20 mm (0.787") -- Max working thickness 160 mm (6.29") -- Min working thickness 8 mm (0.315") -- Feed speed 5 to 50 M/min.( 16' to 162'/min) -- (1) Weinig lateral conveyor table to the infeed side of the machine -- Infeed table length 2450 mm (96.4") -- Sick IVC -3D infeed material scanner system (System detects material width and thickness and automatically adjusts side heads for feeding random width material) -- Cardan feed system -- Adjustable upper pressure beam Head Sequence: -- 1st head: bottom horizontal spindle, 15 Kw,(20 HP), 6000 rpm spindle speed, 2-1/8" diameter spindle (8" wide aluminum carbide insert spiral planer head on the spindle) -- Short stock feed attachment between 1st and 2nd spindles -- 2nd head: right hand vertical spindle,7.5 Kw,(10 HP)8,000 rpm spindle speed, 1-13/16" diameter spindle, Hydrolock cutterhead on the spindle -- 3rd head: left hand vertical spindle, 11 Kw,(15 HP) , 8,000 rpm spindle speed, 1-13/16" diameter spindle -- 4th head: bottom horizontal spindle, 18.5 Kw, (25 HP, 6000 rpm spindle speed, 2-1/8" diameter spindle, Jointing attachment on 4th head(8" wide aluminum carbide insert spiral planer head on the spindle) -- 5th head: top horizontal spindle, 11 Kw, (15 HP), 6000 rpm spindle speed, Jointing attachment on 5th top head, Pneumatic top head chip breaker with electronic digital indicator, (8" wide aluminum carbide insert spiral planer head on the spindle) -- Servo spindle adjustments for spindles 2 through 5Also included: -- Electronic digital displays for axial adjustments -- Cardan feed system -- Sound and safety enclosure around all stations -- Lift up front doors with inspection windows and safety interlocks -- Freestanding operator control station -- Color touch screen display with push button master controls -- Siemens Simatic servo controls -- Includes the machine operators manuals and the tooling on the machineActual model is WEINIG Powermat 2400 Feed Through Moulder; 4-HeadsNote: EX-FACTORY’s Logistic Department is experienced and setup to provide “Full Service Logistic"; from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door), US or Canadian Customs, Duty and domestic shipping to your Plant Door.

Manufacturers Specifications tool diameter: 100 - 300 mm tool width: max. approx. 230 mm motor / grinding disc drive: approx. 1,1 kW free angle, adjustable 15 - 35° drive for coolant pump: approx. 0,065 kW tank capacity: approx. 90 l

Weinig R950 Profile Grinder

1999 Weinig Hydromat 23C 5 Head Moulder

WEINIG - UNIMAT 10005-Head (B-R-L-T-B), 9-1/16" x 4-3/4" cap. -- Head sequence: Bottom 10 HP; right 15 HP; left 15 HP; top 25 HP; 20 HP motor. -- WEINIG "Memory Re-Dial" System with: Storage of (100) separate profiles; electronic LED readouts for all spindles. -- Spindle dia. 1-13/16" with Cutterhead speeds: Spindle #1 at 6,000 RPM; spindles #2 - #5 at 7,000 RPM with high precision bearings & mechanical spindle brakes; adjustment of vertical spindles 3-1/8" axially. -- Electronic LED readouts for: Chip breaker & pressure elements for top spindles. -- Cutting circles: 8-7/8" On spindles #2 - #5; vertical spindles with adjustable table plates to cutting circles; hardened infeed bed plates before-and-after 1st bottom head. -- Motorized feed beam adjustment; variable feed speed from: 20 - 118 FPM; 10 HP inverter controlled Cardan feed drive, overhead feed wheels with pneumatic pressure. -- (1) Powered table roller in bed at outfeed. -- Infeed straightening table 2 M (6-1/2') with adjustable fence; adjustable table at outfeed. -- Equipped with: Central location of lubrication points; side pressure roller at infeed; manual Waxilit pump; (2) lights inside sound enclosure. -- Includes Set-Up Stand.NOTE: Machine is in good running condition, but electric brakes are not functional; does not affect running or performance.

WEINIG UNIMAT 23 ATS, 6 HEAD MOULDER6-Head (B-R-L-T-T-B), working capacity 9-1/16" x 6" profiling. -- Head sequence: Bottom 10 HP, right & left by 15 HP, top 20 HP, top 15 HP and bottom 15 HP motor; Spindle dia. 40 mm with cutterhead speed of 6,000 RPM. -- WEINIG ATS (Automatic Tool Setting), Storage for up to (99) profiles; automatic positioning (radially) of left and top spindles (linked). -- Mechanical digital readouts on all other spindle adjustments for both axis, radial adjustment only on 1st bottom head. -- Motorized feed beam adjustment with independent adjustment of top heads, Receding chip breakers on left and top heads. -- Feed motor 7.5 HP, variable speed 18 - 118 FPM, overhead feed wheels with pneumatic pressure, (2) powered rollers in machine table. -- Large tool cutting circles, table plates adjustable to the cutting circle on vertical spindles with axial adjustment of 3-1/8" for multiple profiles. -- Infeed straightening table 2 M (6'6") with adjustable fence & adjustable outfeed table. Side pressure roller mounted to infeed table. -- Includes: Central lubrication, full sound/safety enclosure, manual bed lubrication pump.

WEINIG Unimat Gold Feed-through MoulderSpecifications: --6-Head (B-R-L-T-T-B), working cap. 230 mm x 120 mm (9-1/16" x 4-3/4"). -- Head sequence: 1. Bottom 7.5 KW (10 HP), 2. right 7.5 KW (10 HP), 3. left 7.5 KW (10 HP), 4. top 11 KW (15 HP), 5. top 14.9 KW (20 HP) and 6. bottom 7.5 KW (10 HP) motor. Mechanical brakes on all motors. -- Spindles: dia. 40 mm (1-9/16") with cutterhead speed of 6,800 RPM. Mechanical digital readouts on all spindles. -- Feed system: Overhead feed wheels with pneumatic pressure. Motorized feed beam height adjustment. Inverter controlled feed speeds up to 30 m/Min (98 FPM), driven by 4 KW (5.5 HP) motor. Cardan drive, chainless, maintenance-free. (2) Powered table rollers in machine bed; (1) between top spindles & (1) at outfeed. Infeed straightening table 2,000 mm (6-1/2'), with adjustable fence. (1) side pressure roller mounted to infeed table. -- Complete with: Chromed tables. Central location of lubrication points. Manual Waxilit pump. Sound & safety enclosure. Automatic star delta starters. (2) emergency stop buttons. CE Compliance.This WEINIG Unimat Gold Moulder only has 186 Hours of use !Seller states that front bottom spindle is missing its digital readout.This machine will include Heads, Tooling, and the Dust Manifold.

1978 Weinig 7 Head Moulder S/N 2816/2248

Weinig U22N Moulder 7 head Mid 80s Freshe rebuild

Weinig Unimat 22AL Electrical Panel

Weinig Unimat 22E 6-Head Moulder OLDER MACHINE BUT STILL WORKING FINE WHEN REMOVED FROM SERVICE. Working dimensions: 4-3/4" x 8-5/8" Spindle configuration: B-R-L-R-T-B Motors: B-7.5 HP, R-7.5 HP, L-7.5 HP, R-7.5 (tilt), T-10 HP and B-10 HP. Amp meters on all spindle motors. Spindles: 1-1/2" dia. at 6,000 rpm. Mechanical dials for spindle positioning. Second right spindle tiltable. Feed: Cardan drive with 5.5 HP motor with feed speed; dial adjustable from 18-118 FPM. Tables: Infeed 6'0" with manual waxilit pump and siode pressure rollers Includes: Box of misc parts and cutterheads.

Weinig Unit 500 Moulder

Unimat Gold 6-Head Moulder Manufacturer's specs to be confirmed Unimat Gold 6-Head Moulder . 4-3/4" x 9-1/16" capacity. 1-1/2" diameter spindles Spindle Configuration: 10 HP Bottom, 10 HP Right, 10 HP Left, 15 HP Top, 20 HP top, 10 HP Bottom. . 6,800 RPM on all spindles . 5.5 HP inverter controlled variable speed feed 20 to 78 FPM with LED readout. 78" in-feed straightening bed. Mechanical digital readouts on all spindles. Digiset readouts on left and top spindles. Mechanical readouts on chip-breaker and pressure element of top spindle. Pneumatically pressurized feed rollers. (2) powered table rollers in machine bed (one between top spindles and one at out-feed). Motorized up/down adjustment of feed beam Chrome table plates. Central lubrication point. All spindles are equipped with mechanical brakes. Sound and safety enclosure. Machine Weight: 6,720 lbs. Dust Requirements: (6) each (6,000 CFM)

Weinig Unimat Gold - 6-Head Machine Weinig Rondamat R960 Grinder Includes: Tooling and approx (200) profiles from tool room

Wemhoner Variopress

West Salem model 2420GR1-H wood grinder/hog 480 v Bottom discharge No screen - machine has breaking bars Disconnected and ready to ship

1988 Western Pneumatic Complete Finger Jointing Line Complete Finger Jointing Line MORE INFORMATION COMING SOON!

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i61 WHIRLWIND 1000 L Upcut Saw Specifications: 2-3/16" x 8-1/4" Cap., 14" blade cap., 3,450 RPM, left-hand unit feeding from right-to-left, 5 HP BALDOR motor. Complete with: (5 - 90) Cycles/Min; magnetic starter with low voltage controls, air filter, regulator, coalescing filter, and 4" dust chute. NOTE: The above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

Whirlwind Undercut Saw with Tiger Stop Fence

WHITFIELD 43-1C-43 Wide Belt Sander (4) Heads52" wide belt with Steel drum, Rubber drum, Rubber drum and Combi headSpecifications: -- Maximum working width 52" -- Maximum working height 5" -- Heavy-duty structure with base consisting of a cast iron base integrated with stress-relieved steel to ensure machine rigidity and flatness -- The bottom transfer bed is, guided on re-circulating guides and driven by 4 precision ball-screws to ensure a perfect flatness of the working bed.FEEDING SYSTEM -- Bottom rubber vacuum belt driven by hydraulic motor to ensure consistent feed speed as load varies. -- Vacuum suction unit with 7.5 HP motor and noise dampening silencer -- Infeed safety switchMachine configured as follows: Pos.1- -- Steel Drum 300mm diameter x 1350mm length -- 40HP auto oscillating belt with through beam sensors to control belt tracking. -- Lead in and lead out hold down shoes -- Dust collection at exit of belt -- Belt brake switch -- Mechanical braking -- Belt cleaning with oscillating air blow off -- Belt Size 54" x 103" Pos.2 - -- Rubber Drum 300mm diameter x 1350mm length -- 40HP auto oscillating belt with through beam sensors to control belt tracking. -- Lead-in and lead-out hold-down shoes -- Dust collection at exit of belt -- Belt brake switch -- Mechanical braking -- Belt cleaning with oscillating air blow off -- Belt Size 54" x 103"Pos.3 - -- Rubber Drum, Inverter driven for control of rotation direction and speed; 300 mm diameter x 1350 mm length -- 30HP auto oscillating belt with through beam sensors to control belt tracking. -- Lead in and lead out hold down shoes -- Dust collection at exit of belt -- Belt brake switch -- Mechanical braking -- Belt cleaning with oscillating air blow off -- Belt Size 54" x 103"Pos.4 -- Combi Head 160mm diameter x 1350mm length -- 25HP auto oscillating belt with through beam sensors to control belt tracking. -- Lead in and lead out hold down shoes -- Dust collection at exit of belt -- Belt brake switch -- Mechanical braking -- Belt cleaning with oscillating air blow off -- Belt Size 54" x 103" --Combi Head 160mm diameter x 1350mm lengthAlso Included: -- Panel Cleaning Brush mounted at Out-Feed --1HP motor -- Dust extraction portControl -- Mitsubishi Touch screen and PLC to control; -- Thickness setting -- Manage 1/0 -- Control Belt Feed Speed -- Head 3 Rotation Direction and Speed -- Display 1/0 for trouble shootingNote: Installed in January 2025 and ran until July 2025
