Equipment For Sale

WEIMA WLK 13 Vertical Hopper-fed Low Noise Grinder Specifications: -- Single shaft Shredder/Grinder, 51" x 47" hopper opening (straight sided), 2 cu. yds. cap.; 368 mm (14.5") rotor dia. x 51.2" rotor length; 60 HP motor and hydraulic ram. -- Equipped with: -- Patented "V-ROTOR" design utilizes a V-groove rotor closely matched to grooves in the counter-knife to ensure uniform discharge free of splinters; reduce friction, and dedicate more horsepower to grinding. -- (68) welded knife holders, recessed concave cutters with low clearance over the rotor to extend cutter life, protect the bolts, and reduce machine wear; drop out discharge, lift up door for easy purge cleaning when used in plastics application. -- Hydraulic serrated ram optimizes feed pressure by monitoring rotor motor amperage, lateral force on the ram is minimized by a unique "U-Joint" mounting system, Hydraulic clutch enables motor to start with the hopper full. -- Features: -- Heavy Duty structural steel frame, welded construction; integrated "plug-and-play" electrical control system with UL approved components (system UL certification available upon request for additional charge). -- Recommended for plastic, paper or wood applications.

Weima WLB 1300 Horizontal Grinder 50 HP Motor System works, not currently in use, will need main bearing replaced.

WEIMA TH 1500 M Briquette Press (Square Brick) -- Specifications: Produces 5.9" x 2.3" (150 x 60 mm) rectangular briquette; hopper opening of 55" x 55" (1,400 x 1,400 mm); hopper volume of 2.46 cu/yd (1.88 cbm). -- Equipped with: 40 HP Hydraulic motor; 2.6 HP auger motor; 3.0 HP agitator motor; hydraulic oil volume of 264 gallons (1,000 liters). -- Volume reduction from chip/dust to block up at a 10:1 ratio; hourly output up to 800 - 900 Lbs. -- Features: Conical shaped agitator with curved hopper corners, "Bridge Breaker" mounted on agitator; automatic "On/Off" integrated in feeding hopper; hydraulic oil cooling, overheating protection for hydraulic oil. -- Complete with: Touch-Screen control panel on swivel mount; discharge ramp for briquette extraction, chrome plated clamp, and an oil level switch. -- Solid German engineering.

WEIMA TH 814 Briquetter A volume reduction of 90% is possible through the briquetting of wood, paper, aluminum and biomass or synthetics, providing significant savings in labor, disposal and storage costs.Material is hand fed or by dust system into the hopper, where an agitator pulls it into the auger and pressing chamber. Specifications: -- Produces 80 mm (approx. 3.1") dia. compacted logs; approx. 2.4 cu. yd. (55.1 x 55.1 x 37") square vertical hopper, 18 HP motor. -- Hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio; approx. hourly output between 300 - 400 Lbs/Hr.Features: -- Auto on/off integrated into feeding hopper; automatic briquette length adjustment; conical-shaped agitator; dust connection at pressing unit.Options: -- Hydraulic cooling for 24-hour operation, heating for cold weather start-ups; plastic tubing discharge into Gaylord or carousel bagging system. .

WEIMA ZM-40 Quad Shaft 4-Shaft ShredderEquipped with: -- Dual drive motors - (2) 30 HP Drive motors. -- Hopper opening measures 51" x 55.1" (1,300 x 1,400 mm); cutting chamber opening of 30" x 27.6" (762 x 700 mm). -- Rotor length of 30" (762 mm); Rotor speed 25 RPM; cutting disc 11" (280 mm) diameter. -- Complete with: -- Control Panel with soft start and 16' cable bundle. -- Note: "Quad Shaft" Shredders, unlike Dual Shaft Shredders, allow shredded material to be circulated through the cutting chamber until it is small enough to pass through the sizing screen. -- Machine weight: 5,500 Lbs.

Weima TH1500 Briquette Press

2008 Weima WL 6/18.5 V-Rotor Drop Feed Wood Grinder Machine number 500-8876 460V 3 Phase 60 Hz Motor Output- main drive 18.5 KW 1760 rpm Motor Output- hydraulic system 1.5/2.0 KW 21 tools Rotor speed ca.90 Rotor diameter 252 mm Includes spare rotor

Weinig Unimat 22AL Electrical Panel

Good Condition 230V 60Hz

Weinig R950 Profile Grinder

WEINIG RONDAMAT R960 Profile Grinder. Working Dimensions: -- 9-29/64" maximum tool width; 3-15/16" Minimum to 11-13/16" Maximum cutting circle. -- Grinding Wheel: Diameter 5-29/32" min to 8-7/8" max. grinding wheel bore - 60 mm. Onboard diamond wheel dressing tool. -- Drive: Variable Frequency Controlled Drive giving a spindle speed - 1,500 to 3000 RPM; 1.5 HP Motor. -- Template carrier: Utilizes a template stylus-copy system, whereby the tool head table copying-grinding is effortless (precision linear floating table movement feels smooth as if there is zero gravity). Resistance template cross support with setting gauges for axial constant system; axial (side) clearance angle 0° - 20°. Holder for fixed and revolving tracing pins; for easy follow of the template to grinding aggregate. -- Coolant: 13 Gallon coolant tank capacity with 1.2 HP coolant pump. -- Includes: Manuals and 1-13/16" arbor.

WEINIG R 960 Profile Grinder 12"12" Max. arbor length, tool dia. 9" max. to 4" min. -- Grinding wheel speed inverter controlled 1,500 to 3,000 RPM by 1.5 HP motor. -- Hydro-clamping of grinding wheel to arbor. -- Tool carriage movement with precision linear table bearings, setting gauges for axial constant, axial (side) clearance angle 0ø - 20ø. -- Onboard diamond wheel dressing, 8-7/8" max. 6" min. grinding wheel dia.; 13-gal. coolant tank with 1.2 HP pump. Includes -- arbor dia. 1- 13/16".Note: New bearings on carriage

Michael Weining Profile Grinder, Model R929 machine 929-808, 6" grinding wheel

WEINIG UNIIMAT 23E Moulder Feed Through;6-Head (B-R-L-T-T-B), working cap. 9-1/16" x 4-11/16". -- Head sequence: Bottom 20 HP, right & left by 20 HP, top 20 HP, top 20 HP and bottom 15 HP motor. -- Spindles; Dia.1-13/16" with cutterhead speed of 6,000 RPM; Digiset readouts for left and top spindles, mechanical readouts all other spindles including chipbreaker and pressure element. -- Feed System: Feed motor 5 HP, variable speed of 20 - 78 FPM. One(1) powered feed roller at outfeed end on the machine. Infeed: Straightening 2 M (6'6") table, side pressure roller mounted to infeed table. -- Features: Central lubrication system, table inserts for right/left vertical spindles and manual Waxilit pump. -- Full sound and safety enclosure, operator/spare parts manuals.

Weinig 4-Head Moulder 1-1/2" Spindles Full set of cutterheads 230 volt 3-phase

WEINIG - RONDAMAT 934: Profile Grinder -- Basics: 9" Arbor length; 11-1/2" max. tool dia.; 1.5 HP motor; tilting head assembly for back relief grinding; clearance angle on peripheral of tools: 10° - 30°; to each side: 0° - 20°. -- Variable feed speed: 1,800 - 3,000 RPM via Vari-Speed gearbox; onboard wheel dressing; 9" max. wheel dia.; 0.16 HP coolant pump with built-in coolant tank. -- Includes: Operators manual; clamping nut; pull-off bolt; 1-1/2" arbor; an extra set of grinding wheels & tooling.WEINIG "OCMS" Measuring Stand -- Working width: 300 mm. -- Allowable tool dimension: 3" - 11-3/4" Head diameter. Measuring stand allows electronic measuring & indicating cutterhead dimensions with: Electronic digital readouts; visually establishing the tool measurement; no setting errors; no expensive CNC control. -- Magnifier screen viewer with: 20:1 magnification; cutterhead placed in: Powerlock tool post; Operator views the scope & moves the measuring carriage via precision dialing left-to-right. -- Measured values (radial & axial); tool dimensions (both min. & max.) are displayed. -- Includes: 1-1/2" Arbor.

WEINIG UNIMAT 23EL Feed Through Moulder: 6-Head (B-R-L-T-T-B), working capacity 9-1/16" x 4-3/4". -- Head sequence: Bottom 15 HP, Right 15 HP, Left 15 HP, Top 25 HP, Top 25 HP and Bottom 15 HP motor. -- Spindles: dia. 40 mm with cutterhead speed of 8,000 RPM. WEINIG ATS (Auto-Tool Setting) for left and right spindle. All other settings with mechanical readouts. -- Feed System: 7.5 HP variable feed drive, feed speed 18 - 118 FPM. (4) Powered machine table rollers. -- Includes: Central lubrication at front side of machine and side pressure roller at mounted at infeed table. Infeed table 2 M (6'-6") with manual table lubrication pump. Infeed fence with rollers for addition of hopper feeder.Note: The electronic brake is not working on (1) side and and the feed motor

Weinig Profile Grinder MDL R929

Manufacturers Specifications tool diameter: 100 - 300 mm tool width: max. approx. 230 mm motor / grinding disc drive: approx. 1,1 kW free angle, adjustable 15 - 35° drive for coolant pump: approx. 0,065 kW tank capacity: approx. 90 l
