Equipment For Sale

Weinig Unimat Gold - 6-Head Machine Weinig Rondamat R960 Grinder Includes: Tooling and approx (200) profiles from tool room

2002 Weinig U23E 5-Head Moulder 2021 Doucet MFE-150-12 Infeed System This system is still in production and ready to be loaded out.

Manufacturers Specifications tool diameter: 100 - 300 mm tool width: max. approx. 230 mm motor / grinding disc drive: approx. 1,1 kW free angle, adjustable 15 - 35° drive for coolant pump: approx. 0,065 kW tank capacity: approx. 90 l

WEINIG - Rondamat 934, ...Profile Knife GrinderSpecifications: -- 9-3/8" Max. arbor length, 4" - 9" tool dia. -- 6" - 8-7/8" Grinding wheel dia., grinding wheel speed inverter controlled with grinding wheel speeds 1,500 to 3,000 RPM; 1.1 kW (1.5 HP) Motor.Equipped with: -- Hydro-clamping of grinding wheel to arbor. -- Tool carriage movement with precision linear table bearings; setting gauges for axial constant; axial (side) clearance angle 0° - 20°. -- Onboard diamond wheel dressing, 13-Gallon Coolant tank with 1.2 HP Pump.Dimensions: 50" x 43" x 62" HWeight: 1,600 Lbs

WEINIG RONDAMAT R960 Profile Grinder Working Dimensions: -- 9-29/64" maximum tool width; 3-15/16" Minimum to 11-13/16" Maximum cutting circle. -- Grinding Wheel: Diameter 5-29/32" min to 8-7/8" max. grinding wheel bore - 60 mm. Onboard diamond wheel dressing tool. -- Drive: Variable Frequency Controlled Drive giving a spindle speed - 1,500 to 3000 RPM; 1.5 HP Motor. -- Template carrier: Utilizes a template stylus-copy system, whereby the tool head table copying-grinding is effortless (precision linear floating table movement feels smooth as if there is zero gravity). Resistance template cross support with setting gauges for axial constant system; axial (side) clearance angle 0° - 20°. Holder for fixed and revolving tracing pins; for easy follow of the template to grinding aggregate. -- Coolant: 13 Gallon coolant tank capacity with 1.2 HP coolant pump. -- Includes: Manuals and 1-13/16" arbor.

WEINIG RONDAMAT R960 Profile Grinder. Working Dimensions: -- 9-29/64" Maximum tool width; 3-15/16" Minimum to 11-13/16" Maximum cutting circle. -- Grinding Wheel: Diameter 5-29/32" min. to 8-7/8" max. grinding wheel bore - 60 mm. Onboard diamond wheel dressing tool. -- Drive: Variable Frequency Controlled Drive giving a spindle speed - 1,500 to 3000 RPM; 1.5 HP Motor. -- Template carrier: Utilizes a template stylus-copy system, whereby the tool head table copying-grinding is effortless (precision linear floating table movement feels smooth as if there is zero gravity).Resistance template cross support with setting gauges for axial constant system; axial (side) clearance angle 0° - 20°. Holder for fixed and revolving tracing pins; for easy follow of the template to grinding aggregate. -- Coolant: 13-Gallon coolant tank capacity with 1.2 HP coolant pump. Includes: -- 1-13/16" arbor

WEINIG PROFIMAT 23 Feed Through Moulder;(6)-Heads (B-R-L-T-T-B), working cap. 9-1/16" x 4-11/16".Specifications: -- Spindles 1-1/2" dia. with cutterhead speed of 6,000 RPM. -- Feed System & Features: variable feed speed from 20 - 78 FPM, powered by a 5.5 HP motor. -- Receding chip breaker at top spindles. Side pressure opposite right spindle; spring-loaded with (2) rollers; driven outfeed roller in bed. -- In-feed straightening table 2 M (78"), side pressure roller mounted to in-feed table. Note: Bare Machine: No dust manifold or tooling.

Weinig R-930 Profile Grinder Mach. No 820/299

Weinig Rondomat R 934 Profile Grinder S/N 934-1028

Weinig Profimat 22 N Moulder Work ready

Weinig Molder Electrical Panel U23 460V

WEINIG Powermat 1000 7-Head Feed Trough Moulder(B-R-L-T-T- B-U); working cap. 9-1/16" x 4-3/4". Head sequence: -- Bottom 15 HP, Right 15 HP, Left 15 HP, Top 30 HP, Top 40 HP , Bottom 30 HP, and Universal 15 HP motor. All motors with electronic brakes. WEINIG Touch-Screen "Power Com" -- PowerCom Plus software system features: Profile drawing storage, profile dimensions, tool changes and production optimization. -- Electronic LED readouts for all tool holder settings, including chip breakers & pressure elements.Spindle arrangement: -- Spindle #1: 1-13/16" w/Cutterhead speed of 8,000 RPM; -- PowerLock tool holders on #2 - #5 with 12,000 RPM, universal tool holder variable from 4,000 to 12,000 RPM and with high precision bearings; -- Adjustment of vertical tools 2-3/16" axially. -- Motorized tool positioning; radial & axial on tool holders #2 - #5; motorized feed beam adjustment with independent adjustment top head; top head with independent adjustment of chip breaker & pressure element. -- Universal spindle with 270° of movement.Feed System: -- Variable feed speed from 20 - 118 FPM, 7.5 HP inverter-controlled Cardan feed drive, overhead feed wheels with pneumatic pressure. -- Vertical tools with adjustable table plates to cutting circles, hardened infeed bed plates before & after 1st bottom head. -- Chromed tables and fences, (2) powered table rollers in bed and (1) between left and top spindles and (1) at outfeed. -- Infeed straightening table 2 M (6-1/2').Equipped with: -- Pedestal for machine controls separate from the electrical cabinet, central location of lubrication points. -- The safety hood, automatic table lubrication pump, and (2) lights inside the reinforced sound enclosure are electromagnetically interlocked, as is the phone modem..

WEINIG PROFIMAT 23 Feed Through Moulder5-Head (B-R-L-T-B) Moulder with working cap. 9-1/16" x 4-11/16". -- Spindle sequence: Bottom 10 HP, right & left by 10 HP motor, top 15 HP, bottom 10 HP motor. -- Spindle diameter 1-1/2" with cutterhead speed of 6,000 RPM. All spindles equipped with mechanical digital readouts. Digi-set readouts on left and top spindles. Chipbreaker and pressure for left and top spindles with digital readouts. -- Feed: 4 HP Carden feed drive (chainless feed system), variable feed speed 18 - 78 FPM; (1) driven outfeed roller in bed. -- Equipped with: Infeed straightening table: 2 M (6-1/2') central lubrication system, central lubrication and full sound and safety enclosure. -- Extras: Includes manuals, used cutter-heads, many sets of assorted Knifes, and dust collection manifold. -- Machine is set up for 460V and it comes with a 230 V to 460 V step-up transformer -- Low hours, used for production of cabinet door rail and stiles components.

WEINIG UNIMAT 23 ATS, 6 HEAD MOULDER6-Head (B-R-L-T-T-B), working capacity 9-1/16" x 6" profiling. -- Head sequence: Bottom 10 HP, right & left by 15 HP, top 20 HP, top 15 HP and bottom 15 HP motor; Spindle dia. 40 mm with cutterhead speed of 6,000 RPM. -- WEINIG ATS (Automatic Tool Setting), Storage for up to (99) profiles; automatic positioning (radially) of left and top spindles (linked). -- Mechanical digital readouts on all other spindle adjustments for both axis, radial adjustment only on 1st bottom head. -- Motorized feed beam adjustment with independent adjustment of top heads, Receding chip breakers on left and top heads. -- Feed motor 7.5 HP, variable speed 18 - 118 FPM, overhead feed wheels with pneumatic pressure, (2) powered rollers in machine table. -- Large tool cutting circles, table plates adjustable to the cutting circle on vertical spindles with axial adjustment of 3-1/8" for multiple profiles. -- Infeed straightening table 2 M (6'6") with adjustable fence & adjustable outfeed table. Side pressure roller mounted to infeed table. -- Includes: Central lubrication, full sound/safety enclosure, manual bed lubrication pump.

1st Head – Bottom– 40mm spindle – 11kw 8,000 RPM • Electronic digital display for radial adjustment Marathon Coating Table plates 2nd Head – Right – 40mm Spindle – 11kw 8,000 RPM 3rd Head – Left – Powerlock Spindle – 15kw 8,000 RPM Pressure shoe in front of left tool holder, incl. 2 lateral Pressure rollers, pneumatic. Vario hood (2 axes) Central adjustment of the pressure and guide elements before and after Left tool holder incl. electronic digital display. 4th Head – Right – Powerlock – 11kw 8000 RPM 5th Head – Top – Powerlock – 15kw 8000 RPM Vario hood (2 axes) Central adjustment of the pressure and guide elements before and after Upper tool holder incl. electronic digital display Split pressure shoe in front of upper tool holder, pneumatic Oscillating axial adjustment 6th Head – Top – Powerlock – 11kw 8000 RPM Vario hood (2 axes) Central adjustment of the pressure and guide elements before and after Upper tool holder incl. electronic digital display Split pressure shoe in front of upper tool holder, pneumatic Oscillating axial adjustment 7th Head – Bottom – Powerlock – 11kw 8000 RPM 8th Head – Right – Powerlock – 11kw 8000 RPM An additional pressure roller from above opposite 3rd right Tool holder, swing away for easy Tool change, pneumatic 9th Head – Left – Powerlock – 11kw 8000 RPM Vario hood (2 axes) Central adjustment of the pressure and guide elements before and after left Tool holder incl. Electronic digital display. Frequency controlled feed, 11 KW (6-36m/min 5 meter in-feed table Automatic lubrication pump Two driven rollers in the machine table, hardened Pressure rollers from above, pneumatic PowerCom Plus Software CNC controlled adjustment and positioning. Axial CNC – controlled adjustment and positioning of the Tool holders in connection with the Memory function or PowerCom. For tool holder no. • 2,3,4,5,6,7 Radial CNC – controlled adjustment and positioning of the Tool holders in conjunction with the memory function or PowerCom. For tool holder No. 3,4,5,6,7 CNC – controlled adjustment and positioning of the feed Automatic central lubrication of the oscillating Tool holders Two interior lights in the safety hood Comes with new Transformer.

Weinig 4-Head Moulder 1-1/2" Spindles Full set of cutterheads 230 volt 3-phase

WEINIG RONDAMAT R960 Profile Grinder. Working Dimensions: -- 9-29/64" maximum tool width; 3-15/16" Minimum to 11-13/16" Maximum cutting circle. -- Grinding Wheel: Diameter 5-29/32" min to 8-7/8" max. grinding wheel bore - 60 mm. Onboard diamond wheel dressing tool. -- Drive: Variable Frequency Controlled Drive giving a spindle speed - 1,500 to 3000 RPM; 1.5 HP Motor. -- Template carrier: Utilizes a template stylus-copy system, whereby the tool head table copying-grinding is effortless (precision linear floating table movement feels smooth as if there is zero gravity). Resistance template cross support with setting gauges for axial constant system; axial (side) clearance angle 0° - 20°. Holder for fixed and revolving tracing pins; for easy follow of the template to grinding aggregate. -- Coolant: 13 Gallon coolant tank capacity with 1.2 HP coolant pump. -- Includes: Manuals and 1-13/16" arbor.

WEINIG R 960 Profile Grinder 12"12" Max. arbor length, tool dia. 9" max. to 4" min. -- Grinding wheel speed inverter controlled 1,500 to 3,000 RPM by 1.5 HP motor. -- Hydro-clamping of grinding wheel to arbor. -- Tool carriage movement with precision linear table bearings, setting gauges for axial constant, axial (side) clearance angle 0ø - 20ø. -- Onboard diamond wheel dressing, 8-7/8" max. 6" min. grinding wheel dia.; 13-gal. coolant tank with 1.2 HP pump. Includes -- arbor dia. 1- 13/16".Note: New bearings on carriage

WEINIG Profi Joint Short Stock Finger JointerThe ProfiJoint model is a flexible finger jointing line which is used for processing timber packages and manufacturing horizontal as well as vertical finger joints. -- This model is perfect for first-time buyers and can be modified to accommodate a shaper combination if need be. -- The ProfiJoint Eagle is easy to operate, has a compact design, and provides you with the same high-quality product you expect from the Weinig brand. High-capacity shaper and shaper table (19"; wide) carrying the packaged timber pieces to finger joint them either horizontally or vertically. -- Shaping unit includes axial adjustment providing 1/100mm of precision for the finger length. -- Scoring units (optional) for horizontal jointing and to avoid any tear-out. Technical Specifications: -- Utilizing the FlankenJet Glue System, only the exact amount of glue needed is automatically applied.GRECON Flanken-JetA Flanken jet is a system developed by GreCon for glue spreading in finger-jointing plants.Until the introduction of Flankenjet, glue spreading through ridged glue rollers used to be common. The biggest disadvantage of such system is a perpetual glue circulation.With Flankenjet a targeted glue dosage via slotted nozzles takes place. This way the glue spreading can be controlled and only takes place when the workpiece has absolutely passed the system.Advantages:Order quantity can be simply adjusted and variegated in a relatively big area.constant properties of the glue, because it can be in a closed system until the actual orderlow adhesive wastagedeployment possible by PUR glue. -- Single worker operation typical. -- Infeed Length: 5-7/8" - 27-1/2" -- Material Thickness: 7/8" - 1-15/16" -- Material Width: 1-9/16" - 5-7/8" -- Outfeed Press Length: 118" - 240" -- Saw Motor: 15kW (20HP) -- Hogger & Scoring Motor: 5.5kW (7.37HP)

1998 Weinig Moulder H23 MDL Hydromat 23. Call for pricing.
