Equipment For Sale

2020 CMI C3003200 hours, Rebuilt final drives, New rails, sprockets, and rollers, FAE 200 mulching head

CUMMINS B4.5 STAGE V (173HP) 4 PUMP HYDRAULIC SYSTEM 12 VOLT ELECTRICAL SYSTEM 78.5 GAL FUEL TANK 29 GAL HYDRAULIC RESERVOIR SEALED AND GREASED, D3 CHAIN 22” SINGLE GROUSER TRACK PADS WITH MUD HOLES TWO SPEED HYDRAULIC MOTORS PUSH BUTTON CAB LIFT BACK UP CAMERA AM/FM BLUETOOTH RADIO HYDRAULIC OIL FILLER PUMP AIR SUSPENSION SEAT ROPS/FOPS/OPS CERTIFICATION 12 VOLTS DC OUTLET ELECTRICAL SYSTEM WITH BREAKERS IN DASH STANDARD 15,000LB WINCH FAE 140U 200 MULCHING HEAD

2019 CMI 300 Mulcher, Cat Engine with 1600 hrs. Good undercarriage, FAE mulching head… MACHINE Overall Length: 197 inches Ground Clearance: 19 inches Overall Height: 116 inches Overall Tractor Width: 89 inches MULCHER Overall Width Attachment: 107 inches Working Width: 89 inches Overall Height (pushbar fully retracted): 64 inches Total Weight (Crawler & Mulcher): 28,840 lbs Disclaimer The information is the best of our knowledge at the time of the listing. The price may change without notice and additional charges may apply, including freight, taxes, duties, tariffs, quarantine, etc.

CML NEW FINISHING TOWER/6 Multi Level Oven System: This type of oven is very flexible thanks to the FIFO (First In / First Out) operation and the possibility to adjust the stay time using more or less belt trays.It is particularly suitable to help the evaporation of the volatile components contained in UV curable paints, or to carry out a first degree of drying of conventional paints in an 'out of dust' environment. - Its technical characteristics also make this system extremely suitable for drying or curing materialDescription of the Standard Equipment & Specifications: -- Overall dimensions: 7,650 x 3,300 mm x 3,250 mm height (25’ x 11’ x 10.67’ H). -- Weight: 4.000 kG (8,819 Lbs)Multiple Floors Dryer, mod. TOWER/6 Paint Coated parts (panels components) are transported on (6) belt conveyor trays, moving vertically up/down, having a length of 6,500 mm (256") each. This practical length makes it possible to load "two panels charges" having a length of 3,000 mm. (9.85 feet) each. -- Max. weight supported by every belt tray level: 115 kG (253.5 Lbs). -- Max. allowed thickness 50 mm (1.97 inches) -- Speed controlled by inverter at belt travel steps of 3.250 mm (127.9") or in continuous model. -- Vertical movement on (4) pre-tensioned chains controlled by motor with gearbox. -- Cabinet made of structural carbon steel profiles and pre-painted insulated panels, complete with entry door and windows. -- Ventilation by means of laminar air distribution among the floors. Average air speed 2 m/Sec (6.56 feet/Sec) - (100% of the air volume is taken from the outside and exhausted to the outside). -- Air supply unit complete with centrifugal fan taking the air from the outside of the building, complete with heat exchanger to be supplied with hot water, with temperature adjustment system and double set of pocket filters. -- Air ductworks between air supply and exhaust fans and distribution boxes (plenum) is included. -- Ready to be connected to emergency system to stop the line -- Curing Tunnel operating functions controlled by SCHNEIDER PLC via electronic keypad input. -- Separate electrical cabinet in IP 55 execution - IP 55 motors -- Manufactured according to CE Standards and covered by a (12) Months or 2,000 Operating Hours Warranty for defective parts or materialOther Dims, Operation & Utilities: -- Dimensions of the electrical switchboard: 800 x 600 x 2,000 mm (2.7’ x 1,97’ x 6,56’) -- Total power: kW 10,5 -- Compressed air:: lt/Min 20 (5.29 gal/Min) -- Exhausted air volume: m³/Hr 7.500 (264,860 feet³/Hr) -- Supply air volume: m³/Hr 7.500 (264,860 feet³/Hr) -- Thermal power: Kcal/h 125.000 (326,000 BTU/Hr), - AIR In/Out: 50°C (122°F)

This machine is in good working condition and can be inspected under power. Specs (to be confirmed): - Electric spindle 18.1 HP - X-axis stroke 145.66î - Y-axis stroke 82.67î - Z-axis strke 13î - Working area 145.66î x 68.90î - Automatic tilting head - Telescoping spindle extension for surface polishing - (26) ISO 40 tool holders at rear - Bar code reader for program interface

CNC FACTORY PYTHON XPR FLAT TABLE MACHINE (W/ATC): -- Specifications:4' x 8' Flat Table "Bridge Gantry" machine with: "Phenolic "MATRIX" grooved flat table for "NESTED BASE MANUFACTURING". -- Working capacity:"X" Axis 97" (2,464 mm); "Y" axis 49" (1,245 mm); "Z" axis stroke is 20.2" (515 mm); max. material thickness 10" (250 mm). -- Positioning Speed:"X" & "Y" Axis 279 FPM (85 MPM); "Z" axis 115 FPM (35 MPM).All axes movement is with 5G driverless Servo System with direct helical rack & pinion & 5G no homing calibration. -- Work Area:Flat table design with: "Matrix" grid phenolic surface for "Nested Base Manufacturing".The machine has: (6) Independent working zones with dual layer high flow vacuum; 2-left origins, 2-right origins, 1-front origin & 1-rear origin.Auto-material alignment pins, auto-unloading arm, material loading wheels; rear & side material alignment pushers. Automatic on/off vacuum flow, vacuum hold-down communication, automatic parts hold down, and release.Robotic Material Sensing Dust Hood; Single and dual vacuum ports. -- Machining:(1) 12 HP (8.9 kW) Air-cooled "HSD Electro-Spindle" with: ISO 30 adaptor, RH & LH rotation; variable speed from 1,000 - 24,000 RPM.(1) Rapid Fire 12-position revolving tool changer for "on the fly "ATC". -- Operator & Machine Control:"SYNTEC" PC Front End with: CNC Factory 5G, 5th generation CNC control + At machine cabinet and cutting software. Handheld MPG remote control with individual axis & real time simulation control; CNC speed control overrides & compensation at machine virtual support, HD digital monitoring camera, Wi-Fi, and Ethernet ready.Air-Conditioned control cabinet, 21" "TOUCH SCREEN" monitor; All mounted on a mobile cart. -- Complete with:(1) 150 cbm (60 Hz) Vacuum Pump; automatic pressurized Lubrication System for linear guides, pads and recirculating ball screw. Auto tool length measurement probe. Perimeter Safety System & fencing. -- Actual Model is: CNC FACTORY PYTHON XPR CNC

COE 249D Veneer Lathe with the following: -- 27" maximum log diameter, Approx.110" knife length. -- 1484 Veneer Lathe Big Bar. -- 1390 Veneer Lathe Core drive. -- 3 to 1 inner drive ratio. -- Capable of peeling approx. 35 cubic meters per hour. -- Includes: • Linden step feeder• Small log offset x-y spindle chucks• 27"; maximum log diameter• 1484 big bar• 3 to 1 inner drive ratio• Digital ball feed carriage drive -- Note: Sold without 'charger or drive' included. -- This COE Veneer lathe line was completely rebuilt and installed in 2006. The lathe was operated less than one year and is reportedly in very good condition.

Coe 47' x 26' Package type dry Kiln with Controls, 1989 Hurst gas boiler 150 PSI, 6900# Steam Per Hour S/N 51000-750-3, Condensate Tank & Pumps & Electrical. can Buy as a Package or Seperate the Hurst Boiler.

Coe 6' x 9" Double Cut Air Strained Band Mill Model# 972 Serial# 114

COE 233 Rotary Veneer Lathe. -- 30" Swing and 44" Knife length., -- Turning motor LINCOLN 50 HP 230/460 -- Complete with: Hydraulic unit, all drive motors and controls. -- Includes: veneer knife. - Ideal for peeling short blocks.

Coen 230 Combustion Wood/LP Gas Fired Burner

144L X 120"D X 144"H (25) Filter Screens (4) 12" X 48", (4) 4-tube light panels(1) Exhaust Fan 1HP 120V

Comac TAG 100 Package Kiln 30'x36' Gas fired with control room Looks like 70 MBF with 4/4 lumber

MLS Number 11922341 Denis Comact 948 Gang Saw Edger 6" infeed table Spare guides

Denis 948 Gang Saw

Photos coming Compact DDM6 Profile Canter Line Double Length Infeed Production: 27,000 Logs/ 24 hours, 360 FPM (2x6), 500 FPM 2x4 Infeed belt conveyor V flight scanning conveyor without the scanner and optimization system One pass small log processor Outfeed belt conveyor #1 Outfeed lifting belt conveyor #2 Outfeed belt conveyor #3 Lumber landing table Motor Control Centers (MCC) Programmable Logic Controller (PLC) - obsolete

COMEC - LON-LS, ...Horizontal Belt SanderSpecial design for sanding of straight or curved solid wood parts such as: Chair legs, chair backs and other similar & difficult-to-sand parts.10 HP Belt driven motor; 12" dia. contact drum for 10" wide x approx. 140" long abrasive belt; air tracking & belt tensioning. -- Stock is fed over the contact drum with an overhead variable speed, pneumatically tensioned feed wheel. -- Sander belt power: 6.6 kW (9 HP approx.) - 220/440 V, 60-Cy, 3-Ph motor.

COMEC - FAS/2, ...Corner Milling MachineCOMEC FAS is a dedicated milling machine with: Inclinable heads for machining the corner of chair seats. Specifications: -- (2) Heads with: 5.5 HP motor and 40 mm spindle shaft. -- Max. cutter size: 150 mm (5.9"). -- Tilting of milling units: 20°/ +45° in horizontal plane. -- Fixed left hand column to support head unit. -- Max. working height: 200 mm (7.8").

COMEVA - NICRON DOOR PRO, ...CNC Door/Jamb Machining Center with Automatic Tool ChangerGantry style flexible Door CNC Machining Center which can machine Hinges, Locks, Grooves, Door Face Patterns and many similar applications. The advantage of this machine over the NICRON DOOR C is this model can also resize the doors and its ability to machine the top/bottom of doors with the 90° rotation feature. It also has a floating head for grooving designs on the door faces while compensating for uneven door surfaces. Specifications: -- Max. working area - door length on X-Axis is 118.1" (3,000 mm). Max. X-axis speed of 230 FPM (70 MPM). -- Max. door width on Y-Axis is 51.18" (1,300 mm). Max. Y-axis speed of 230 FPM (70 MPM). -- Max. travel on Z-Axis is 7.87" (200 mm). Max Z-axis speed of 98 FPM (30 MPM).Working Heads: -- The machine is equipped with: (1) 9 kW Vertical router head with a 5-position Automatic Tool Changer (ATC); (1) 3.5 kW Horizontal head with double-end output spindles and 0° - 90° rotation; (1) 3.5 kW Horizontal motor for the lock milling, and a 0.37 kW floating head motor for grooving patterns on the door face. All drives are powered by Servo motors, X- & Y-Axis movement are via Rack & Pinion; Z-movement is with a recirculating ball-shaft.Working table: -- Table work area is 51.1" x 118.1" (1,300 x 3,000 mm). Table equipped with: (2) Adjustable width bars and (6) suction cups Load wheels, regulated by (5) reference pistons that rise & fall to secure the workpieces. The bars have integral suction cups powered by a VENTURI vacuum system. To work with doors, the machine is equipped with stops and gaskets for securing the door. Stops are mobile, and they can be used to hold doors and other parts.Operator Control Panel/CNC: -- Floor-standing operator panel is mounted on casters and houses the PC & OSAI CNC control hardware. PC motherboard is an ''INTEL Atom" 1.6 GHz CPU, modular system that offers a solution for the control of Servo drives and distributed input/output modules in a digital field bus and integrated II/O's. The dual-axes gantry has a Velocity-Feed-Forward function (VFF) that tries to look ahead with 256 precalculated blocks. It also incorporates a firmness control (Jerk) of the axes through advanced algorithms as well as tool store management & tool life. Advanced NC control powered by OSAI which is set up to control the Interpolated axes and all machine functions.COMEVA Software: Specially developed COMEVA DOORS software allows the machining of the main designs of hinges and slots you may find all over the market, including the machining on the upper side/edge of the door. Software carries a series of predesigned macros that help the operator when performing the different operations, thus speeding up various job designs. The software carries out a special program of parametric macros for doors/door frames.Includes: -- Centralized machine lubrication system. Owner’s Manual with schematics software on USB

COMEVA BR-605E 5-Axes CNC Controlled Door Frame Milling Machine with ATC: Designed for cutting and milling wood and aluminum stiles and rails (headers) of door frames/jambs using a saw blade which rotates approx. 270° (universal) for straight cuts (rabbet-step cuts), router for the milling pockets of all types of hinges and locks, and other tooling stored in the approx (8) Position Rotary Tool Magazine. -- Specifications: Frame length is 15.72" (450 mm) to unlimited; Maximum frame thickness of 2.36" (60 mm); Door frame width from 2.36" (60 mm) to 7.08" (180 mm). Saw cut positions at almost any angle. Saw blade diameter approx. 12".Universal Milling Group: HITECO 11.4 HP (8.5 KW) 24,000 RPM 5-axes head. Cutting and milling with axes, X, Y, Z, A (for parts feeder) and B Universal rotation. with servo motors controlled by CNC.Feed Servomotor: Automatic parts feeding system composed of (2) movable clamps driven by servomotors for continuous operation. Reduces loading/unloading times.Controller/COMEVA Software:: -- OSAI (open series) CNC controls its (7) Interpolated axes. Intuitive graphical interface with 19" display. Built-in barcode scanner/reader. -- Specially developed CAD COMEVA DOOR 4.0 software allows the machining of the main designs of hinges and slots you may find all over the market. Software carries a series of predesigned macros that help the operator when performing different operations, thus speeding up various job designs. The software carries out a special program of parametric macros for frames. -- Includes: Owner’s Manual with mechanical & electrical schematics and parts breakdown; covered by a 1-Year Factory Warranty on parts. -- Engineered & Manufactured by COMEVA S.L, in Spain.
