Mellott For Sale

Michael Weining Profile Grinder, Model R929 machine 929-808, 6" grinding wheel

Weinig R950 Profile Grinder

Weinig Rondamat 960 Grinder

WEINIG - Rondamat 934, ...Profile Knife GrinderSpecifications: -- 9-3/8" Max. arbor length, 4" - 9" tool dia. -- 6" - 8-7/8" Grinding wheel dia., grinding wheel speed inverter controlled with grinding wheel speeds 1,500 to 3,000 RPM; 1.1 kW (1.5 HP) Motor.Equipped with & Features: -- Hydro-clamping of grinding wheel to arbor. -- Tool carriage movement with precision linear table bearings; setting gauges for axial constant; axial (side) clearance angle 0° - 20°. -- Onboard diamond wheel dressing, 13-Gallon Coolant tank with 1.2 HP Pump.Dimensions: 50" x 43" x 62" HWeight: 1,600 Lbs

WEINIG RONDAMAT 934 Profile Grinder: -- 9" Arbor length, 11-1/2" max. tool dia., 1.5 HP motor, tilting head assembly for back relief grinding, clearance angle on peripheral of tools 10° - 30° and to each side 0° - 20°. -- Variable feed speed 1,800 - 3,000 rpm via a vari-speed gearbox, on-board wheel dressing, 9" max. wheel dia.; 0.16 HP coolant pump with built-in coolant tank. -- Includes: Operators manual, clamping nut, and pull-off bolt, 1-1/2" arbor, and an extra set of grinding wheels and toolingWEINIG OCMS measuring stand -- With a working width of 300 mm. -- The allowable tool dimension of 3" to 11-3/4" head diameter. The measuring stand allows for electronic measuring and indicating of cutter head dimensions with electronic digital readouts; visually establishing the tool measurement, no setting errors, and no expensive CNC control. -- Magnifier screen viewer with 20:1 magnification; the cutterhead is placed in Powerlock tool post, all the operator does is view the scope and move the measuring carriage via precision dialing left to right. -- Measured values (radial) and (axial), tool dimensions both minimum and maximum are displayed. -- Includes: 1-1/2" arbor.

WEINIG RONDAMAT R 950 Profile Grinder Working dimensions 9-1/2" Max. arbor length, tool cutting circle 4" min., 9" maximum.Specifications: -- Tool carriage movement with linear table bearings, setting gauges for axial-constant. -- Radial (back) clearance angle 15° - 35°, axial (side) clearance angle 0° - 10°. -- Drive motor 1.5 HP, Grinding wheel diameter: 5-7/8" to 8-7/8", -- Grinding spindle; speeds via ribbed belt adjustment: 1,500, 1,700, 2,400 and 3,000 RPM, manual clamping of grinding wheel to spindle. -- Coolant tank capacity: 10 gallons. -- Includes: 1-1/2" arbor, (1) grinding wheel flange wrench set for wheel change-out, and dressing attachment for wheel. -- Includes: 1-1/2" arbor, (1) grinding wheel flange, gracing pins, wrench set for wheel change-out and dressing attachment for wheel. -- Dimensions: 60" L x 48" W x 48" H NOTE: The machine is currently in storage and prepped for transport, Seller can load.

WEINIG RONDAMAT R 950 Profile Grinder;Specifications: -- Working dimensions 9-1/2" Max. arbor length, tool cutting circle 4" min., 9" maximum. -- Tool carriage movement with linear table bearings, setting gauges for axial-constant. -- Radial (back) clearance angle 15° - 35°, axial (side) clearance angle 0° - 10°. -- Grinding spindle; speeds via ribbed belt adjustment: 1,500, 1,800, 2,400 and 3,000 RPM. Manual clamping of the grinding wheel to the spindle. -- Includes: Grinding arbor 1-1/2".diameter.

WEINIG RONDAMAT R960 Profile Grinder Working Dimensions: -- 9-29/64" maximum tool width; 3-15/16" Minimum to 11-13/16" Maximum cutting circle. -- Grinding Wheel: Diameter 5-29/32" min to 8-7/8" max. grinding wheel bore - 60 mm. Onboard diamond wheel dressing tool. -- Drive: Variable Frequency Controlled Drive giving a spindle speed - 1,500 to 3000 RPM; 1.5 HP Motor. -- Template carrier: Utilizes a template stylus-copy system, whereby the tool head table copying-grinding is effortless (precision linear floating table movement feels smooth as if there is zero gravity). Resistance template cross support with setting gauges for axial constant system; axial (side) clearance angle 0° - 20°. Holder for fixed and revolving tracing pins; for easy follow of the template to grinding aggregate. -- Coolant: 13 Gallon coolant tank capacity with 1.2 HP coolant pump. -- Includes: Manuals and 1-13/16" arbor.

WEINIG RONDAMAT R960 Profile Grinder. Working Dimensions: -- 9-29/64" maximum tool width; 3-15/16" Minimum to 11-13/16" Maximum cutting circle. -- Grinding Wheel: Diameter 5-29/32" min to 8-7/8" max. grinding wheel bore - 60 mm. Onboard diamond wheel dressing tool. -- Drive: Variable Frequency Controlled Drive giving a spindle speed - 1,500 to 3000 RPM; 1.5 HP Motor. -- Template carrier: Utilizes a template stylus-copy system, whereby the tool head table copying-grinding is effortless (precision linear floating table movement feels smooth as if there is zero gravity). Resistance template cross support with setting gauges for axial constant system; axial (side) clearance angle 0° - 20°. Holder for fixed and revolving tracing pins; for easy follow of the template to grinding aggregate. -- Coolant: 13 Gallon coolant tank capacity with 1.2 HP coolant pump. -- Includes: Manuals and 1-13/16" arbor.

Grade Resaw 16” x 16”, set up very much like a West Plains, Heavy Duty W/ 44” x 5” Band Wheels, Dual Slat Feed Through Conveyor, Top Press Rolls Air, 75 HP Saw Motor, Includes 4’ x 4’ x 7’ Sawyer’s Cab W/ A/C, Complete Run Around System W/ Transfer Conveyors and Return Roll Cases, Includes Motor Control Cabinet W/ Variable Feed Drive, (22) Bands, Note: Seller has contact information for someone who will remove & load on truck, Ref # 187

Setworks: Computer setworks - 15 preset locations / Manual setworks - Handcrank adjustment Frame: Heavy duty 1/4" (6.35mm) x 4" (10.16cm) x 10" (25.4cm) tubular steel for vibration free cutting. Feed System: Steel slat bed feed chain. 200fpm max speed / 20fpm min speed. Bands: .042" x 4" / .083 Kerf / Swedge tooth or stelite tipped Guides: Interchangeable pressure guides Drive Wheels: 42" (106.65cm) custom drive wheels mde of high quality carbon steel and dynamicaly balanced. Hold Downs: CS - Double tire hold down / MS - Double sprocket hold down Cutting Specs: Max Length w/ out Return - Unlimited / Max Length w/ Return - per customer requirement Min Length - 18" / Max Width - 14" / Min Width - 3" / Max Height - 14" Motors: 40 H.P. TEFC 1800rpm per head. 3 H.P. to 7-1/2 H.P. variable speed drive Electrical: Includes all TEFC motors, starters, breakers, 440 volt standard. System is prewired, Customer responsible for electric wiring to equipment. Dust Removal: 6" (15.25cm) diameter outlet / Customer is responsible for air suction. Options: Automatic cant return, Breakdown equipment, Operators cab, 2 or 3 way cant/board seperator, Can't turner in crossover, Other voltages available.

Specifications: Setworks: Computer setworks - 15 preset locations (1/2" tp 9" sets) / Manual setworks - Handcrank adjustment Frame: Heavy duty 1/4" (6.35mm) x 4" (10.16cm) x 10" (25.4cm) tubular steel for vibration free cutting. Feed System: Steel slat bed feed chain. 200fpm max speed / 20fpm min speed. Bands: .042" x 5" / .092 Kerf / Swedge tooth or stelite tipped Guides: Interchangeable pressure guides Drive Wheels: 42" (106.65cm) custom drive wheels made of high quality carbon steel and dynamicaly balanced. Hold Downs: CS - Double tire hold down / MS - Double sprocket hold down Cutting Specs: Max Length w/ out Return - Unlimited / Max Length w/ Return - per customer requirement Min Length - 18" / Max Width - 16" / Min Width - 3" / Max Height - 16" Motors: 60 H.P. TEFC 1800rpm per head. 3 H.P. to 7-1/2 H.P. variable speed drive Electical: Includes all TEFC motors, Y Delta Soft Start starters, breakers, 440 volt standard. System is prewired, Customer responsible for electric wiring to equipment. Dust Removal: 6" (15.25cm) diameter outlet / Customer is responsible for air suction. Options: Automatic cant return, Breakdown equipment, Operators cab, 2 or 3 way cant/board seperator, Can't turner in crossover, Other voltages available.

West Plains 5 Head Resaw

2 Head | Manual Set Works | 440V

West Salem Vibratory Conveyor.20" wide 12' long. Located in MN #00786

48" 6-knife, horizontal fed, fan discharge

Estimated screen area per deck 134” width x 240” length. This screener will need a new bearing for the main shaft, and some welding of the internal framework. There are spare hangers, universal joints, support arms.

TECO 100hp 1170rpm direct-coupled motor with guard cover, powered infeed roll

West Salem 2422 H2 Hog
