Equipment For Sale

The Vantec Veneer Auto Stacker, ELV 1.82B is a Vacuum stacker for 2800 mm Veneer lathe. It is fitted with double stacking system (04 bins), with four veneer transport lines and four 5hp exhausters. with of two stoppers and eight ejecting arms. With drive Panel, VSD for exhaust fans and hydraulics lifting tables. Min veneer sheet length sheet: 2300 mm; • Max veneer sheet length sheet: 2700 mm (or Two sheets of 1350mm); • Min veneer sheet width: 800 mm; • Max veneer sheet width: 1500 mm; • Max height of stacks: 1000 mm; • Exhaust motor: 10 hp 4P (8x); • Inlet conveyor motor: 2hp 8P; • Transport conveyor motor: 6hp 4P; • Hydraulic pump motor: 5hp 4P (3x);

The Vantec 2800mm Spindleless Veneer Lathe is designed to process veneer for plywood production from both hard and soft logs. Its metal tempered grooved rollers and lathe knife inclination system work perfectly to make sure there will always be a precise contact area between the lathe knife and the log during the peeling process by eliminating vibration that could cause damage to the Veneer sheets. Vantec Spindleless lathe proves its efficiency by delivering consistent thickness variation and a impressive top linear speed of 180 m/ min throughout the peeling process for face or core veneers with smooth surfaces. - Log diameter up to 600 mm; - Max log length: 2750 mm; - Min log Length: 2300mm; (with stacker) - Min log length:1800mm (no stacker); - Veneer thickness: 1.0 to 4.0 mm; (Pine and eucalyptus); - Log core after peeling: 40 to 45mm; - Maximum linear speed 180 m/min; - Drive panel included; - Each motor is individually connected by a Variable Speed Drive for torque control in two points of traction on the rollers to pre- vent excessive load on tip ends; - Log Central aligner with maximum of 2200 mm of movement; - Pneumatic scriber Knives (02 fitted on the sides to cut in width and 01 in the Center to cut the length); - Width: 7640 mm; - Length: 3400 mm; - Height: 2550 mm; - Approximate weight: 14000 kg.

The Vantec Automatic Rotary clipper is designed to clip 2800 mm veneer sheets into specific sheet sizes as per the auto stacker preselection. It comes with electronic drive panel, automatic gauge system, positioning of clipper knife by Servomotor and encoder. It is de- signed to work with one tensioned clipper knife with gear motor. It also comes with a 2 HP motor on the output. The clipper knife is not included. - Veneer Thickness : 1 to 4 mm; - Max. Log: 2.750mm; - Minimum veneer width cut: 800 mm; - Max. Veneer length cut: 2700 mm; - Min. Veneer length cut: 700 mm; - Min. Venner rounding length: 150 mm; - Rotor gear motor: helical gears; - Clpper rollers power drive: 4 hp 6P; - Outlet conveyor Motor: 2hp 4P (input) 1 hp 8P (output); - Clipper Servomotor: 40 Nm (2x); - Width: 4800 mm; - Length: 6000 mm; - Height: 1700 mm; - Approximate weight: 7.000 kg

Vance PT600R8 Drum Chipper See this machine at IWF Atlanta 2024! This Wood Drum chipper PT600 is used in production of wood chips from logs and veneer waste. It has a toothed roller system that allows efficient material infeed, a rubberized conveyor belt and a Hydropneumatic unit to lift the rotor cover for maintenance. It comes with 01 chipper Knife set and 01 nose bar set. It does not come with the output conveyor. - Width of inlet: 600 mm; - Height: 300 mm; - Rotor diameter: 800 mm; - Toothed roller: 01 upper and 01 lower; - Grooved rollers: 01; - Rollers gear motor: GD (helical gears); - Metal detector: Flat model; - Rollers motor size: 5 hp (2x); - Number of rotor knives: 02; - Wood chip size: 25 - 40 mm; - Main motor 125 hp 4P: Included; - Drive panel: Included; - Lead Time: 240 Days; - Estimated production: 55 m3 / h (it may vary according to the type of material and time used with blade sharpening); - Infeed conveyor length: 3 500 mm (included); - Width: 1 850 mm; - Height: 1 .150 mm; - Overall length: 6 700 mm; - Approximate weight: 4,900 kg.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5h VANTEDGE MM 6.5 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): + EVA & Polyolefin Adhesive ready. Specifications: Working Capacity: Edgebanding thickness 0.4 - 3 mm coil stock capacity & 10 mm strip capacity. Min. panel width 85 mm (3.3"); min. panel length 125 mm (4.9"); panel thickness 10 - 60 mm (0.39" - 2.36"). Tape and Panel Infeed System: 750 mm Coil support table; adjustable track feed speed 14, 16 & 20 MPM (66 FPM). Heavy-Duty large solid polished steel panel infeed fence guide system. Large industrial digital adjustment for the Premill panel material removal amount. Top Pressure Beam Adjustment: Automatic adjustment from the PLC control; pneumatic Pop-Up Stop system. Red LED panel feed indicator light for correct panel spacing. Equipped with: Dual 3 HP Pre-milling motors w/diamond cutter heads; pneumatic "JUMP In/Out function. Misting unit prior to Pre-milling; large dual dust housing ports to help clean the Pre-milling system. Quick change Glue Reservoir for EVA & PO glues; Pressure Section/Infrared Heat Lamp System. Heavy-Duty automatic shear type Guillotine with: "Auto-Set" automatic intervention for strip & coil materials. (4) Pneumatic polished Pressure Rollers with manual digital adjustment to edge thickness. (1) Rubber infeed Tape Roller, (1) metal infeed Tape Roller; direct Universal Drive system - NO Chains. Teflon-coated glue pot; digital thermostats with automatic kick down when the machine is in idle mode. Workstations: End Trimming Unit: Dual 0.5 kW (0.67 HP) high frequency End Trim motors on precision "Auto Lube" Linear Guideways; 90° to 10° pneumatic tilt cut adjustment. Electronic sensors to safely monitor motor positions; thumb screw pneumatic adjustments for simplicity. Tilting Super Finish Top & Bottom Trimming Station: Dual High Frequency 0.65 kW (0.75 HP) motors with Combi Finish insert tooling.Top Servo driven positioning of motors for different edge trimming profiles & positions. Corner Rounding Unit: Motors on precision billet aluminum swing tracer arms with pneumatic guidance and Face Copy System. (2) Independent motors can be adjusted to match tape thickness via digital scales. Profile Scraping Unit: Top, bottom & side Copy Wheels to properly follow your panels edge. Panel Nesting System: Triple Copy System for panels with blind dados & hinge cup holes. Digital adjustment for fine-tuning the unit to the proper tape thickness. Flat Scraping Unit: Large copy wheels. Buffing Unit: Top & bottom Buffing Unit; 0.5 HP (0.37 kW) - 2,800 RPM motors; units tilt 0° - 30°. Dual Hot Air Blowers: To re-embellish edge materials. Operator Interface 10" Color touchscreen PLC with swivel Control Panel. The PLC controls all working units & the adhesive thermostats with 1-touch icon programmable selections. Photo indicator alarms to easily troubleshoot errors/issues. Complete with: I

Brand new never used!! 16’8” long 22” wide 19” height (adjustable)

Vecoplan Model 45/12/2VU HZF Grinder 75 HP Motor 18" Wide opening No Vibrating Infeed conveyor

Low Noise Grinder with Horizontal Feed; 50 HP Main drive motor, 16" diameter rotor with (24) 40 x 40 cutters; top & bottom knurled infeed rolls control feeding. -- 5" x 18" Infeed opening; 390 RPM rotor speed. -- Includes: (1) 18" Wide x 6" deep x 16' long vibratory horizontal infeed conveyor; sizing screen with 7/16" screen hole. -- Approximately 10,163 hrs on this unit.

2019 Vecoplan VHZ1600 | 1300 run hours | Excellent Condition | 2 Available in June of 2025

MLS Number 11342021 2008 Vecoplan RG32/20U Grinder/Shredder Single shaft grinder / shredder 80 DBA noise level 32 in. by 42 inch opening waste grinder with vertical 2 cubic yard hopper 20 HP rotor motor Equipped with10 inch rotor with 20 indexable/replaceable cutter knives Rotor / cutter head grinds at 95 R.P.M. Hydraulic pusher ram with 1.5 HP two speed pump motor Separate electrical panel with push button controls 80 DBA noise level 8 inch exhaust 8 inch hump magnet screen to produce ½ in.in size Handles 1,000 to 1,200 lbs./ hour depending on product mix and loading. Machine still operating. Will be available sometime in May/June 2022

2016 Vecoplan RG52-60 U Stretch Slow Speed Grinder 60HP Electric Main S/N 112901

Vecoplan RG52-60 U Stretch Slow Speed Grinder 60 HP Motor No Control Panel

VECOPLAN RG 42-40 SINGLE SHAFT SHREDDERSpecifications; -- 40 HP MotorVecoplan ShredderModel: RG 42/40 XL PVYear: 2007Motor: 40 HP, 460V, 60HZRPM: 1465Feed Opening: 42" x 48"Blades on rotor: 27Weight: 3,700 lbs

Vecoplan RG 42/60 XL 60 HP Motor 15" Rotor 42" x 52" Hopper Opening 1" Screen This machine went through a rebuild. It was not big enough for the buyers application. Available immediately.

VECOPLAN RG52/60 SINGLE SHAFT SHREDDER Includes Box Dumper and ConveyorsSpecifications: --In Feed Opening: 52″ x 58″ --Rotor Length: 52″ --Rotor Diameter: 15″ --Hopper Volume: (4) Cubic Yards --Cutters: 37 --Drive Motor: 60 HP --Box Dumper / Table --Infeed Conveyor --Discharge Conveyor for Gaylord Box Loading

This Grinder was recently taken out of service and was running good. No electrical controls. Ready to load.

This Grinder was recently just taken out of service. It ran very good before taken out. Does not include electrical controls.

VECOPLAN RG 70/200K Shredder with Steel Belt Conveyor & Dust CollectorSpecifications: -- Hopper Opening: 70″ x 80″ -- Hopper Volume: 4 – 6-1/2 Cubic Yards -- Main motor: 200 HP -- Rotor diameter: 20″ -- Number of cutters: 84 (triple row) -- Size of cutters: 40 mm x 60 mm -- Screen size: Holes 2″ -- Rotor speed: 145 RPM -- Rotor diameter: 20″ -- Hydraulic Feed Ram: 10 HP - 2-Speed -- Throughput: 2,000 – 28,000 Lbs/HrEquipped with: -- 10 HP Motor Dust Collector -- 48″ W kW SCHMIDT Shredder Infeed Conveyor w/ 20′ pit section

VECTOR REVOLUTION - 180, ...CNC Contour Edgebander + Vector Vision UpgradeNumerically controlled automatic Edgebanding Machine precisely applies ABS & PVC edgebanding automatically to square or irregularly shaped parts as the banding head travels on a bridge gantry along the X - Y & Z axis.Machine FeaturesBanding unit simultaneously rotates on a high precision C-Axis; AC Brushless Servo motors with: Digital drives and linear guides ensure high speeds & accuracy with a smooth acceleration-and-deceleration. -- NO PROGRAMMING required; extremely simple changing from one tape size to another; Operator only has to make simple adjustments like: Setting the start position, glue height, feeding the new width of tape. and adjusting tape guide height. All else is performed by the machine. -- Cartridge Glue System: Glue height is set by positioning a pin in a hole in the index ring setting for the glue dosing rod; standard positions are:16 mm (5/8"); 19 mm (3/4"); 25 mm (1.0"); 28 mm (1-1/8"); and 31 mm (1-1/4") eliminating any need for fine adjustment. -- Working Field:X-Axis 139.7" (3,550 mm); Y axis 72" (1,830 mm); 0.63" - 1.57" (16 - 40 mm) min. - max. material thickness.0.79" (20 mm) Min. external radius & 1.97" (50 mm) min. internal radius, depending on the type of banding materials. 1 mm Minimum banding material thickness & 3 mm maximum banding material thickness. (NOTE: 1 mm PVC is not suitable for butt joints). -- Worktable:Phenolic worktable with embedded vernier scales in X & Y axes allow for simple & flexible positioning of 2-stage vacuum pods. Worktable allows for single or pendulum processing with: (2) 48" x 72" (1,219 x 1,828 mm) Work Zones for processing small to large parts. With average cycle times under (2) minutes, the Contour Edgebander consistently produces quality parts, including 360° lap joints.Workpiece is supported by means of: Vacuum cups sitting on a large flatbed; enables absolute flexibility in positioning pods to ensure the workpiece is held securely. Full vacuum achieved with: 100 cbm/Hr Vacuum Pump. Pump is mounted inside the frame of the machine reducing noise and avoiding airborne dust.Exact workpiece positioning is not critical as the patented VECTOR Revolution 180 Operating System is unaffected by panel position.Patented process is controlled by a simple and intuitive interface that does not require CNC programming. -- Edge Banding Unit:VECTOR Revolution 180 Uses a cartridge & nozzle glue extrusion system, which is ideally suited to this Contour Banding application.Cartridge Glue Nozzle is a closed system, which only heats the glue as it is used. Glue is not exposed to the atmosphere. Result: There is no burning of the glue or discoloration, and the original color of the glue & its properties are maintained.Another benefit of the Glue Nozzle System: Close proximity to the first pressure roller. This means that even when slowing for corners, the glue remains molten until pressed onto the panel by the first pressure

VECTOR REVOLUTION 180 CNC CONTOUR EDGEBANDER + Vector Vision Upgrade: Numerically controlled automatic Edgebanding Machine precisely applies ABS & PVC edgebanding automatically to square or irregularly shaped parts as the banding head travels on a bridge gantry along the "X", "Y" & "Z" axis.Machine Features:The banding unit simultaneously rotates on a high precision "C" axis; AC Brushless Servo motors with digital drives and linear guides ensure high speeds & accuracy with a smooth acceleration-and-deceleration. -- NO PROGRAMMING required, extremely simple changing from one tape size to another, the operator only has to make simple adjustments like setting the start position, the glue height, feed the new width of tape and adjust the tape guide height. All else is taken care of by the machine. -- Cartridge Glue System, glue height is set by positioning a pin in a hole in the index ring setting for the glue dosing rod, standard positions are, 16 mm (5/8"), 19 mm (3/4"), 25 mm (1.0"), 28 mm (1-1/8"), 31 mm (1-1/4") eliminating any need for fine adjustment. -- Working Field:"X" Axis 139.7" (3,550 mm), "Y" axis 72" (1,830 mm), 0.63" - 1.57" (16 - 40 mm) min. - max. material thickness.0.79" (20 mm) Minimum external radius & 1.97" (50 mm) minimum internal radius, depending on the type of banding materials. 1 mm Minimum banding material thickness & 3 mm maximum banding material thickness. (NOTE: 1 mm PVC is not suitable for butt joints). -- Work Table:Phenolic worktable with embedded vernier scales in "X & Y" axis allows for simple & flexible positioning of 2 - stage vacuum pods. The worktable allows for single or pendulum processing with (2) 48" x 72" (1,219 x 1,828 mm) work zones for processing small to large parts. With average cycle times under two minutes, the contour edgebander consistently produces quality parts, including 360° lap joints.The work piece is supported by means of vacuum cups sitting on a large flat bed. This enables absolute flexibility in positioning pods to ensure the workpiece is held securely. Full vacuum is achieved with a 100 m³/Hr vacuum pump. The pump is mounted inside the frame of the machine reducing noise and avoiding airborne dust.Exact workpiece positioning is not critical, as the patented VECTOR Revolution 180 operating system is unaffected by panel position.This patented process is controlled by a simple and intuitive interface that doesn't require CNC programming. -- Edge Banding Unit:The VECTOR Revolution 180 uses a cartridge & nozzle glue extrusion system which is ideally suited to this contour banding application.The cartridge glue nozzle is a closed system which only heats the glue as it is used. The glue is not exposed to the atmosphere. This means there is no burning of the glue or dis-coloration & the original color of the glue & its properties are maintained.Another benefit of the glue nozzle system is its close proximity to the first pressure roller. This means that even when slowing for corners, the
