Gang Rip Saws For Sale

MEREEN-JOHNSON 412DC Dip Chain Gang Rip Saw:Specifications: -- 12" Cap. arbor & 6" throat, thickness 1/8" - 3-1/2" using 12" or 14" dia. tooling, 2-3/16" dia. arbor, min. length 22". -- Arbor Drive: 50 HP - 3,600 RPM TEFC Direct drive motor, electrical lockout on access door, arbor hand brake, and motor load meter. -- Feed Drive: 3 HP Feed motor, 30 - 150 FPM feed speed, shear pin drive pulley. -- Feed Bed: 5" Pitch double-V chains with extruded aluminum slats & replaceable steel-backed rubber inserts, and automatic oil mist lubrication system.Equipped with & Features: -- Holddowns & bed plate: -- (4) 3" Dia. spring-loaded overhead idle press rolls, -- (1) full-width overhead spring loaded bed plate, thickness adjustment with scale & pointer; -- (1) 8" and (1) 5" dia. upper and (1) 5" dia. lower dust outlets require 3,150 CFM total.From the seller Mereen-Johnson 412-D.C.W. rip saw. Missing saw sleeve (Part number: P19575KI3).

MEREEN-JOHNSON - 431DC, ...Gang Rip Saw: Specifications: -- 31" Arbor width cap., 14" max. dia. tooling, 3-1/2" max thickness. -- Motorized thickness adjustment. -- 29" Min. length for glue joint accuracy and 22" min. for busting only; 6" throat. -- 75 HP - 3,600 RPM TEFC direct drive motor. -- Arbor with disc brake & load meter. -- Arbor lockout on the access door.Equipped with & Features: -- Feed, Chain & Holddown. -- 5 HP Variable feed speed 30 - 150 FPM with adjustable jam protection. -- MEREEN-JOHNSON "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain. --"Quad Life" hardened dip cams. -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips. -- Automatic chain oiler with low-level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls. -- Full width spring loaded overhead bed plate. -- Pressure rolls & bed plate unit with powered adjustment; scale & pointer for thickness reference; -- Antikickback Finger System with: (1) Lower & (2) Upper on Infeed; (1) upper assembly on outfeed.

MEREEN-JOHNSON - 312-DC/SR2 'Select-A- Rip': Gang Rip Saw Line with (2) Movable Blades.Loaded with elaborate material handling at infeed & outfeed.Specifications -- Arbor Space 12" featuring: 1" Min. to 12" max. cutting capability between select Saws. -- Thickness capacity: 2-3/4" (with 14" blades). -- 6" Throat. -- 30" Min. length glue-joint accuracy; 18" min. length for Bust-up only. -- Min. rip width using TwistLock collars: 1". -- Min. rip width with: Traveling shoe hold-downs; Twist lock collars: 1-1/8". -- Min. rip width between outboard select saw & TwistLock collar blade: 1" Including movable shoes. -- Arbor: 2-9/16" Dia.; (2) 1/2" wide x 1/8" deep keyways; 180° opposed. -- (2) Shifting blades. -- Machine mounted Laser Stand. -- Arbor motor: 75 HP; severe duty M-J Direct Drive. -- Feed motor: 3 HP TEFC Heavy-Duty feed drive Assembly with: Variable frequency drive; feed rates: 30' - 235 FPM; programmable current Trip Jam Protection. -- "Posi-Feed" Friction feed chain with: Aluminum slats; replaceable rubber inserts. -- Hardened steel Feed Chains & Track with: Oil mist lubrication. -- Air-Loaded press rolls -- Single lower, double upper Infeed anti-kickback Fingers w/single Upper Outfeed.Equipped with & Features -- "Rip Navigator Scout" arranged to receive: 17'-6" Max. length boards from Scissors Lift; manually placed on board dealer arms. Individual boards: Automatically dealt onto lateral chains & conveyed to a board stop. -- Board stop queues boards for advancement to disappearing fence. -- Automatic adjusting fence positions boards for placement into Gang Rip Saw Fence positioning through Rip Navigator. -- Fence mounted pinch roll Feeds. -- Board to Gang Rip Saw Mounted power table. -- (TBA) Hours. -- "NEW" in 2016.

MEREEN JOHNSON 435-H/DC Panel Rip Saw; 61" Arbor Length;This is a very hard to find 50″ width capacity Mereen Johnson 435-H Multiblade Gang Rip Saw. While older this one is priced right as new ones are 20 times our asking price. Very rare opportunity to own a 50″ width capacity MJ!Working dimensions: 50″ wide x 2-1/2″ thickness ripping dimensionSpecifications -- 75 HP - 3,600 RPM TEFC Direct drive motor, arbor with disc brake & load meter, arbor lockout on access door. -- Feed & chain: 3 HP Variable feed speed approx.20-75 FPM with adjustable jam protection.Equipped with & Features -- Feed: 3 HP feed motor 20-75 FPM. -- Feed system with oil mist lubrication of bottom chain surface and extended pins on chains including automatic -- Low oil and air supply level control, system shut-off feed drive motor to prevent running machine without proper lubrication. -- Upper in-feed pivoting anti-kickback assemblies are provided for operator safety. IIncludes: (24) 10″ inch blades and also included are (10) blade collars.Weight: Aprox 15,000 lbsNOTE: ONLY 3.800 HOURS!

MEREEN-JOHNSON 419-DC Gang Rip SawSpecifications: -- 19" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max. manual thickness adjustment, -- 29" min. length for glue joint accuracy and 22" min. for busting only, 6" throat.Equipped with & Features: -- 75 HP - 3,600 RPM drive motor with direct drive to arbor. -- Feed & chain: 3 HP Variable feed speed 30 to 150 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, and chain oiler. -- (4) 3" Dia. spring loaded overhead pressure rolls (with new springs); full width spring loaded overhead bed plate, pressure rolls and bed plate unit with scale & pointer thickness reference; anti-kickback finger system , -- (1) lower & (2) upper on infeed (kickback fingers are newly replaced). -- (2) Upper dust hoods (1) 10" & (1) 5" dia., and (1) lower 4" dia. hood; requires 3,820 CFM; -- Notice the feed chain - it's in exceptional condition!Note from the seller -- Mereen Johnson model 419 DC straight line gang rip saw. Glue joint capable 19"; width 4"; height capacity75 HP. 480 Volt. This is a very good machine with low hours and runs great . Two arbor sleeves with spacers and blades and a Set of new rubber inserts

MEREEN-JOHNSON "312-DC-OPH1" DIP CHAIN GANG RIP SAWSpecifications -- 12" Arbor cap., -- 14" max. dia. tooling, 3-1/2" max. thickness, -- 30" min. length for glue joint accuracy & 22" min. for busting only; -- 6" throat. Equipped with: & Features -- 50 HP - 3,600 RPM TEFC Direct drive motor, -- Arbor with disc brake & load meter, arbor lockout on access door.Feed & chain: -- 3 HP Variable feed speed from 30 - 150 FPM with adjustable jam protection, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, "Quad Life" hardened dip cams. -- Extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, -- Automatic chain oiler with low level shutoff. -- (4) 3" Dia. air loaded overhead pressure rolls; -- Full width segmented maple, spring loaded overhead pressure shoe -- Pressure rolls & pressure shoe unit adjust with scale & pointer thickness reference -- Anti-kickback fingers. -- Lasers at infeed for pocket location.

MEREEN JOHNSON 424 DC Multiple Blade Rip Saw:Specifications: -- 24" Arbor cap., 14" max. dia. tooling, 3-1/2" max., 22" min. length, 6" throat. -- 75 HP - 3,600 RPM TEFC Direct drive motor, arbor with disc brake. --Feed & chain:3 HP Variable feed speed from 50 to 150 FPM, M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, -- "Quad Life" hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, automatic chain oiler with low-level shutoff. --Equipped with & Features: -- (4) 3" Dia. air-loaded overhead pressure rolls -- Full width spring-loaded overhead bed plate -- Height adjustment with scale & pointer reference -- Anti-kickback finger system with (1) lower & (2) upper on infeed. -- (2) Upper dust hoods, (1) 10" & (1) 5" dia. & (1) lower 4" dia. hood -- Requires 3,820 CFM

MEREEN-JOHNSON 419-DC Gang Rip SawSpecifications: -- 19" Arbor cap., -- 14" max. dia. tooling, -- 3-1/2" max. manual thickness adjustment, -- 29" min. length for glue joint accuracy and 22" min. for busting only, 6" throat.Equipped with & Features: -- 75 HP - 3,600 RPM drive motor with direct drive to arbor. -- Feed & chain: 3 HP Variable feed speed 30 to 150 FPM, -- M-J "Posi-Feed" dip bed carried on 5" pitch hardened double-V chain, hardened dip cams, extruded structural aluminum feed bed slats with replaceable steel backed rubber insert strips, and chain oiler. -- (4) 3" Dia. spring loaded overhead pressure rolls (with new springs); full width spring loaded overhead bed plate, pressure rolls and bed plate unit with scale & pointer thickness reference; anti-kickback finger system , -- (1) lower & (2) upper on infeed (kickback fingers are newly replaced). -- (2) Upper dust hoods (1) 10" & (1) 5" dia., and (1) lower 4" dia. hood; requires 3,820 CFM; (2) 19" saw sleeve with mics. spacers. -- New Laser Light Array complete with (5) Lasers and Mounting Hardware, --. Spare parts including extra saw sleeve, short stock holddown plates, a few sawblades, etc. -- Notice the feed chain - it's in exceptional condition!Note From The Seller Arbor motor burnt out, needs repair

Morgan Splitter Saw

New Venture Manufacturing Gang Rip Saw Hydraulic Tank (5) Moving Blades Laser Tower Touchscreen Controls This machine has been removed from service. The photos showing the system setup were taken before it was removed

NEWMAN/Cameron - KF-24: Dip Chain Gang Rip Saw with CAMERON "34H-M1" Infeed SystemSpecifications -- Saw Arbor: 24" Arbor cap.; 14" max. dia. tooling; 4" max. motorized thickness adjustment;22" min. length for glue joint accuracy; 6" throat. -- 2-13/16" Dia. arbor; 24-1/2" capacity saw sleeve arranged for 3-1/8" dia. bore saw blades; saw blade options: 10" - 14" Dia.; spacers: 4-5/8" dia. includes: (1) Saw sleeve and spacers. -- 75 HP - 3,600 RPM TEFC Direct drive motor; arbor with: Disc brake & load meter; arbor lockout on the access door. Feed & Chain: -- 5 HP Variable feed speed: 20 to 100 FPM with: Jam arbor protection. Dip bed carried on: 5" Pitch hardened Double-V chain; hardened dip cams; extruded structural aluminum feed bed slats with: Replaceable steel-backed rubber insert strips; automatic chain oiler with low level shutoff. -- (2) 4" Dia. air loaded overhead pressure rolls; spring-loaded overhead bed plate; pressure rolls & bed plate unit with motorized adjustment; slide type infeed guide with: Handle block; either side of the guide can be used for a stock engraver. -- Anti-kickback finger system with: (1) Lower & (2) upper on infeed; (1) upper kickback on outfeed. Equipped with & Features: Upper outfeed main dust hood: 7-7/8" Dia. 2,150 CFM Infeed dust hood 4-7/8 dia. (855 CFM). (1) Spare sleeve; (2) setup fixtures; generous array of spacers (see photos).

Northtech FR-200 Frame SawSpecifications: -- Saw capacity of 6" width x 8" vertical capacity. -- Minimum working 2"; high X 12"; long. -- Main drive motor to saw frame is 30HP 3PH, wired 460 --V servo drive system to feed works is 1/4HP 3PH, --Blower to saw frame rack for added cleaning value is 3HP 3PH, -- Body of frame saw is (2) sections allowing for fast access to the saw frame, -- Saw blade speed is fixed at 550RPM, -- Dust extraction requires min 3000 CFM and is arranged with (4) 5" ports, -- Blade size is standard with 500mm L x 40mm W x 0.9mm body in stellite or TCT tip,Equipped with & Features -- Digital electronic oiling system provides proper lubrication to the saw frame guides -- Vertical rail system which allows optimum cooling and long term durability, -- (4) guide blocks are thermo- censored to allow auto shut-off of machine should possible heat buildup occur.Machine dimensions 122"; L X 40"; WX, 79"; H weight 7100 lbs. Machine was new in 2007.

Northtech MRS-12N Gang Rip 50 HP Motor

Northtech MRS-14-DXL 460v Manufacturer notes: This is a very popular machine and cost effective. New open ended design allows for you to cut wide material up to 27-1/8? wide. Plus spare arbors, lasers, and the optional quick locking, easy to adjust infeed will not break the bank. The Northtech heavy-duty 50 HP multi-rip (“gang-rip”) saw with 15? maximum blade diameter quickly and accurately cuts material up to 4-15/16? thick and 27-1/8” wide. Cutting both sides of your blanks at once provides incredible parallelism, reducing required moulder allowance, and increasing your yield. Laser guides (one included) and an optional 103” fence make proper alignment of even the longest material simple and precise. Variable feed speeds of 25 – 120 FPM and powered height adjustment further improve operator efficiency.

Manufacturer’s Specification - 15HP Motor + 1HP feed motor (with Wye Delta soft start) - Mechanical variable speed (45' – 100' FPM) provides a speed range for all material types and thickness ranges of 3/16”- 3-1/2”. - Bottom & top kickback fingers - Rack and pinion fence for precise and quick positioning. - Digital electronic oiler provides maximum chain and race life. - 15-1/2? distance from column to blade. - 8' glue line tolerance.

OGAM - PO-340, ...Dip Chain Gang Rip Saw Specifications: -- 75 HP TEFC Motor, dip chain feed with overhead arbor. -- 4.3"; x 13.3"; Cut capacity. -- 16" Max. blade diameter. -- Power rise and fall. -- 70 mm dia. arbor. -- 2 HP Variable feed speed up to 115 FPM.Equipped with & Features: -- Automatic chain oiler. -- (3) Sets antikickback fingers. -- Adjustable infeed fence. -- Motor load meter. -- Many new saw blades.

Paul AB920 Rip Saw Scanning Fenceless Infeed Infeed & Outfeed (not including decks) The machine has one fixed and 2 moving blades. The minimum distance between the moving blades is 44 mm (1.73"). The maximum distance between the moving saw blades is 210 mm (8-1/4"). The machine is designed for incoming boards with the following min./max. dimensions Length: 4' - 16' Width: 2" - 19" Ripped widths: 1.75" - 8" Thickness: 1" - 2" 480 Volt, 60 hz., 3 phase electrics 75 HP main motor Automatic edging separation after the saw Feed speed up to 300 fpm Fenceless infeed system with automatic skewing capability 16 width sensors on the infeed system

This machine was reported to be in running condition when removed from service. Looks like a Pendu. Cannot find a plate on the machine to confirm. this is a single arbor gang and it does not have a sizer. 75 HP Main Motor 5 HP Drive motor

Pendu E-4000 Gang Saw 75 HP on bottom and 75 HP on top arbors 20 HP on blower Press rolls are all original and in very good condition Comes with starters and 3000 amp disconnect box Some hydraulic upgrades Very good condition Seller will disconnect and load

Pendu M-4000 Gangsaw 75 HP on bottom and 75 HP on top arbors 20 HP on blower Press rolls are all original and in very good condition Came from sheltered workshop and was never used much Comes with starter boxes Will disconnect and load.
