Multiple Drills Single For Sale

CAM-WOOD BR-50 Universal Boring MachineFeatures & Specifications: -- 3 HP Pneumatic Universal Boring Machine, all adjustments feature an index plate for accurate and convenient reading, workplace clamping. -- Vertical Base travel, 24". Horizontal Base travel 12". -- 0" - 4" Spindle stroke, 7/16" - 14-thread screw shank, 1/2" max. bit capacity. -- Table Size: 15" x 22". -- Complete with: Air operated overhead holddown clamp and foot pedal operated drill cycle. -- Drill Head can be swiveled 360° and Optional Multi-Spindle drill heads available.

CAM-WOOD BR 25 Horizontal DrillFeatures & Specifications: -- Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back. -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic holddown clamp for up to 3" thickness. -- 12" x 10" Table size. -- 1/2" Drill chuck / 3/4" max. bit diameter.

CAM-WOOD BR 25 + 1 Horizontal and Vertical DrillFeatures & Specifications: The model BR-25+ 1 has the same features as the BR-25, except it's fitted with an additionaluniversal boring head, making it ideal for drilling holes on K/D furniture. -- The boring head can be swiveled 360 degrees for angular drilling, as desired -- Vercical Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back., spindle node threaded 7/16-14" -- Horizontal spindle 2 HP, 3450 RPM-3 phases motor, adjustable 360 degree, spindle nose threaded 7/16-14" -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic holddown clamp for up to 3" thickness. -- 12" x 10" Table size.

CEMCO SBV-120 Vertical Boring MachineSpecifications: -- 113" x 22" boring area Capacity, (14) 1.5 HP - 1,800 RPM motors driving (14) spindles, on/off switch controls for all motors -- Spindle nose with chuck 5/65" - 1/2" capacity -- 121" x 30.5" table size, (4) Spring loaded hold downs, -- 6" Spindle stroke adjustment with min. of 4" to max. of 10" between spindle nose and tabletop. -- Spindle assemblies advance hydraulically at 0 - 30 strokes/Min with single or continuous stroke -- 2 HP hydraulic feed pump w/variable speed control.Also included: -- 4 CHIP BLOW OFFS WITH INDIVIDUAL ON/OFF POSITIONS -- INSTRUCTION MANUAL/PARTS LIST -- DRILLING SAFETY GUARDS -- EMERGENGY STOP CABLE AND EMERGENCY STOP BUTTONFLOOR SPACE FOOT PRINT: 48: X 121"

CEMCO MBV 54 Vertical Boring Machine54" x 15" Cast iron table with wooden top,Equipped With:(2) Universal spindles with movable spindle supports,(3) 2 HP - 1,725 RPM direct drive spindle motors,36" Stationary table height; 6" Max. vertical stroke, spindles advance hydraulically at 0 - 30 strokes/Min;Foot pedal actuated w/single cycle & continuous automatic modes;2 HP hydraulic feed pump, 12-gal. hydraulic pump system;Note: Riggers are required for loading

Craftsman Drill Press

DELTA 11-990C 12" 5-Speed Bench-Top Drill PressSpecifications: -- Table size 8-1/2" x 8-1/2" with 15-1/2"; x 40"; x 11/16"; Thick Plywood top, Table tilt 40° Left/Right. -- Base size 8-1/4" x 8-1/4". -- Quill travel 2-3/8", Chuck capacity 1/2", JT33 Spindle taper. -- Spindle speeds 620, 1,100, 1,720, 2,340, & 3,100 RPM.Equipped with: -- 1/3 HP - 1,720 RPM Motor.Complete with: -- Portable Wood Cabinet.Dimensions with cabinet: 41" x 36" x 57" H

Delta/Rockwell DP 220 1/3 HP Drill Press! Features: Foot Pedal Actuation, 16-Speed Pulley Drive, 10" x 10" Table Includes NO. 1 Arbor PressNOTE: The above specifications are taken from the Seller and literature and are considered accurate. As always, please take advantage of the inspection period to verify. Items seen in the background are NOT a part of this Lot.

GRIZZLY G4185 2-Spindle Horizontal Boring Machine, Will Accept 3-Spindle Boring HeadSpecifications: -- Max. stock width 7-1/2";. -- Table size 9-3/4"; x 15-3/4";, Max. table height 35";, Table height adjustment 3-1/2";. -- Max. bit cap. 9/16"; (Right-hand threaded), Spindle travel adjustment 3";, Spindle speed 4,000 RPM, Max. speed 12 SPM at 90 PSI. -- Hold-down force 600 Lbs.Equipped with: -- 2 HP 3,450 RPM TEFC Direct drive motor. -- Pneumatic spindle travel. -- 2-1/4"; Pneumatic hold-down. -- Pneumatic foot pedal control. -- Steel stand.Complete with: -- GRIZZLY "G5952"; 2C-W19"; 2-Spindle Boring Head, Max. bit cap. 5/8";, Bit threads 7/16 - 14 TPI Right-hand, Spindle speed 4,000 RPM.

Vent Block Drill VBD New never used Motor: Heavy Duty 5 HP - 3 phase - 220v or 440 v (Please specify when ordering) Block Sizes: 2 x 4 through 2 x 12 on center 2 x 14 and larger off center Air Supply: 100 psi Drills: 3-wing Carbide Tipped Spindles: Alloy Steel - Double ended Frame: 2" Steel With Powder Coat Finish Covers: 10 Gauge (1/8" Thick) Aluminum Dimensions: Height - 60 inches, Width - 60 inches, Depth - 33 inches Shipping weight: 750 lbs. - (Including crate) New Never Used!!

Double end automatic operation, for straight, right-angled work pieces Stock dimensions Stock length 220 - 2500 mm Stock width 15 - 200 mm Stock thickness 15 - 50 mm Double-sided trim saw: The saws are cutting downwards through the clamped work-piece.Each side 1 sawing unit. Horizontal drilling station: each side 1 drilling unit with 1 drilling motor 2 kW Distribution of vertical drilling units: 3 units at the front of the overhead beam 2 units at the back of the overhead beam

Pneumatic Single Spindle Tabletop continuous operation drill;Specifications: -- 1.25 HP direct drive pneumatic motor; 8" tabletop working height; 1 Sec cycle time. -- Drills the pocket hole with a 3/8" dia. step bit in (1) smooth operation; the bit is supported all the way to the workpiece by a hardened steel drill guide that ensures tear-out free holes and consistent placement in virtually any material. -- Capacity: Materials from 1/2"- to 1-1/2" thick.Features: -- Pneumatic drill motor, pneumatic clamping. -- 15° Boring angle for greater stability, reduced screw breakout & splitting; this produces a smaller "flat-bottom" pocket hole with rounded sides that can be plugged with a dowel if desired.Includes: -- External regulator, filter & lubricator, 3/8" cobalt drill bit, and foot pedal actuation.Requires a compressor able to produce 8 CFM at 120 PSI (50% duty cycle).

KREG DK 3100 Pocket Hole Boring MachineElectric 3-spindle Pocket Drill; 1.5 HP direct drive electric motor; 39-1/2" table/ top working height; (0.5 - 1) Sec cycle time. -- Drills (2) pocket holes in (1) machining cycle across rails of varying widths with 3/8" dia. step bit in (1) smooth operation.... Drill spindles in the machine are fixed at 3/4" - 1" and 1-3/4" on center allowing it to handle most common rail widths of 1-1/2" up to 3-3/4" with ease. -- One of the (3) Spindles is with left-handed, simply remove one bit from the spindle not being used to set the desired 2-hole spacing. -- The bits are supported all the way to the workpiece by a hardened steel drill guide that ensures tear-out free holes and consistent placement in virtually any material. -- Features: 15° Boring angle for greater stability, reduced screw breakout & splitting. This produces a smaller "flat-bottom" pocket hole with rounded sides that can be plugged with a dowel if desired. -- Includes: Pressure gauge & cycle counter, fence, holddown & clamping assembly, (2) 3/8" cobalt drill bits, and foot pedal control.

Electric Single Spindle Pocket Drill. Specifications: -- Capacity: Materials from 1/2"- to 1 1/2"-thick. -- 1.5 HP direct drive electric motor (also available 1.5 HP direct drive pneumatic motor); 40" table top working height; 1 Sec cycle time. -- Drills the pocket hole with a 3/8" dia. step bit in (1) smooth operation. The bit is supported all the way to the workpiece by a hardened steel drill guide that ensures tear-out free holes and consistent placement in virtually any material. -- Electrical: 110 VAC, Pneumatics: 90 PSI, recommended for clamping. -- Dimensions: 50"H x 24"W x 24"D (40" table height), 176 lbs.Features: -- 15° Boring angle for greater stability, reduced screw breakout & splitting. -- This produces a smaller "flat bottom" pocket hole with rounded sides that can be plugged with a dowel if desired. Includes: -- Pressure gauge & cycle counter, fence, holddown tower, (1) 3/8" cobalt drill bits, and foot pedal actuation.

NOVY 1872V Multi Spindle Vertical Boring Machine 12 Spindles Vertical boring machineSpecifications: -- Table Hardwood 18" X 72' -- Table stroke 0"- 6" -- (12) Spindles in line at 5" center to center, spindle nose with 0" to 1/2" chuck -- (2) drive motor 2 HP with magnetic starter -- (4) Spring loaded hold down -- Savety guard -- Foot swtich

OLIVER 17"; SWING FLOOR DRILL PRESS17" Floor model Drill Press with a durable cast iron head, table and base.Equipped with: -- 3/4 HP motor, 240 to 3,400 RPM motor drives (16) different speeds making it suitable for heavy industrial use. -- The spindle is equipped with a heavy duty 5/8" capacity drill chuck on a MT-2 Morse taper. -- Spindle travel 3-1/8" -- Large 12" x 12" table with clamping slots. -- Rack and pinion system makes it easy to adjust the table up and down.

4 Head drill station 20' with powered roll case Hydraulic set stops

High performance Drill Tub for pocket hole boring. Foot pedal control

Ritter 3 Spindle Boring Machine

SICOTTE - J 20-5: Horizontal Boring Machine12" x 60" Steel table with: 2-1/2" Manual up-and-down adjustment. -- (3) Drive groups: with 1 HP - 3,500 RPM drive motor each; timing belt & pulley drive. -- (1) Spindles: 2" Dia. with: JACOBSCHUCK Chuck; 0 - 1/2" capacity. -- Spindle feed powered by: 3 HP Hydraulic pump; 0" - 6" stroke; variable speed up to (30) strokes/Min.Complete with: -- (3) Pneumatic holddowns. -- Cycle timer: 0 - 30 Sec. -- Automatic/manual cycle with: Foot pedal switch. -- Single or continuous stroke . -- Emergency stop.
