CAM-WOOD IAT 620-100HX INVERTER DRIVEN FINGER JOINT SYSTEM 3" X 6" X 16.5 feet long medium capacity Finger Jointing SystemIncoming Block Specifications: -- Incoming block lengths from 6"; to 31.5"; -- Blocks must be at least 50% longer than their width. -- Block thickness from 1/2"; to 3" -- Block width from 1"; to 6" -- Assembled lengths from 10’ to 16’ (Options 20’ or 24’) -- For use with PVAC adhesives (glue pump and nozzle not included) -- Works equally well with soft and hardwoods. -- Moisture content from 8 to 12% -- Blocks to be surfaced on (4) sides through a Moulder or 4-sided Planer to ± 0.2 mm with 90° right angle corners.Lay-Up and Block-Staging Infeed Conveyor: -- 24" Wide x 31.5" long belt conveyor powered with 1/2 HP motors. The conveyor is controlled by the operating system. Feeds at a constant rate of 180 FPM. Block delivery is controlled by the operator and machine system criteria to feed the Shaper. The conveyor facilitates keeping the system full and productive. FSR-62I Right Hand Inverter Type Finger Joint Shaper: -- Feed table is 24" wide and accepts blocks from 6" to 31.5" long -- 5/8" to 6" width -- 1/2" to 3" thickness -- Shaper spindle is driven by a 20 HP motor and is equipped with provisions for vertical adjustment of 20 mm up and 20 mm down. Spindle diameter is 50 mm and runs at 6,600 RPM. 6.3"; (160 mm) maximum shaper cutterhead diameter (cutter head not included) -- 5 HP - 4,800 RPM Cutoff and trim saw; accepts 10" dia. x 100 tooth x 5 mm blades. -- 2 HP - 2,850 RPM Scoring saw, accepts 7" dia. x 50 tooth x 5 mm blades. -- Conveyor powered by 1/2 HP motor. -- Table movement is inverter driven; powered by a 3 HP inverter motor with cycle speeds from 1 to 4 cycles per minute. Motor senses load and varies travel as needed. TC-62 Single Table Transfer Conveyor to the 2nd (Left Hand) Shaper: -- 24" Wide x 31.5" long belt conveyor. Powered with (1) 1/2 HP motor. Controlled by system criteria. Feeds at a constant rate of 180 FPM. FSL-62I Left Hand Inverter Type Finger Joint Shaper with Glue Extruder: -- Feed table is 24" wide and accepts blocks from 6" to 31.5" long -- 5/8" to 6" width. -- 1/2" to 4" thickness -- A 20 HP motor drives shaper spindle. Spindle diameter is 50 mm and runs at 6,600 RPM. 6.3" (160 mm) Maximum shaper cutterhead diameter (cutter head not included). -- 10 HP - 4,800 RPM Cutoff and trim saw; accepts 10" dia. x 100 tooth x 5 mm blades. -- 2 HP motor scoring saw, running at 2,850 RPM; accepts 7" dia. x 50 tooth x 5 mm blades. -- Conveyer powered by 1/2 HP motor. -- Table movement is Inverter driven; powered by a 3 HP inverter motor with cycle speeds from 1 to 4 cycles/Min. Motor senses the load and varies travel as needed. Speed is controlled by system criteria. Included Injection Type Glue Applicator: -- Extrudes adhesive into the fingers without a messy runoff. 4" Comb height is standard. -- Finger pitch 4 mm, 10 - 12 mm finger length is standard equipm

CAM-WOOD FJ-17 (FM) 6" X 16' Long Semi-Automatic Finger Jointer System(4) Version possible on this model. Choose the one that suits your needsTechnical Specifications:Incoming Block Requirements: -- Incoming block lengths No Limit (Manual Loaded). Blocks must be at least 50% longer than their width. -- Block thickness from 1/2"; to 3" -- Block width from 1"; to 6" -- Assembled lengths from 8’ to maximum 16’ or (20’ Options Add Extra ...$4,900.00) or 24’ (Options Add Extra ...$9,900.00) -- For use with PVAC adhesives Glue pump is not included -- Works equally well with soft and hardwood Blocks. Moisture content from 8 to 12% -- Blocks to be surfaced (4) sides through a Moulder or 4-sided Planer to ±0.2mm with 90° right angle cornersThis semi-automatic system is offered in (4) different versionsVersion 1: -- Finger Shaper (FSM-460A) + Conveyor (RO-62) x 2 + Assembly Press (FJ-500A) The price: $82,900.001. Semi-Auto Finger Shaper Process the finger at one side 2. Manually flip/turn to the other side and make fingers again at the same shaper,3. Manual blush applied the glue,4. Semi-Automatic finger jointer press The price: $82,900.00Version2: -- Finger Shaper (FSM-460A) + Conveyor (RO-62) x 2 + Manual Gluer (FSH-150) + Assembly Press (FJ-500A) 1. Semi-Auto Finger Shaper Process the finger at one side.2. Manually flip/turn to the other side and make fingers again at the same shaper,3. Manual Glue Spreader applied the glue,4. Semi-Automatic finger jointer pressThe price: $92,990Version 3: -- Finger Shaper with Gluer (FSM-621) + Conveyor (RO-62) x 2 + Assembly Press (FJ-500A) 1. Semi-Auto Finger Shaper Process the finger at one side.2. Manually flip/turn to the other side and make fingers again at the same shaper,3. Automatic Glue Spreader applied the glue at the second finger process,4. Semi-Automatic finger jointer press The price: ...$104,900Version 4:Finger Shaper (FSM-460A) + RO-62 x 3 + Finger Shaper with Gluer (FSM-621) + Assembly Press (FJ-500A)1. Semi-Auto Finger Shaper Process the finger at one side.2. Push to the next (2nd) Semi-automatic finger shaper with Auto Glue Spreader and applied the glue at the other side,3. Semi-Automatic finger jointer pressThe price: ...$ 143.900Description of Each Unit:FSM-460A Semi-auto finger shaper (Air-hydraulic type) -- Working timber width (Horizontal Direction); 1"; to 6"; -- Maximum timber total width fit on working table 18"; -- Maximum working height (Vertical direction); 4"; -- Maximum timber thickness (Height feed into assembly press); 3"; -- Working timber length; No Limit (Timber length must be at least 50% longer than the timber width to be processed.) -- Trim saw/Hogging blade 180 mm x 50T x 5 mm x 1 pcs. Trim/Hogging saw speed; 2,850 RPM -- Trim/Hogging saw motor 5 HP x 1 -- Finger shaper motor; 10 HP x 1 . Finger spindle Speed; 5,500 RPM. Spindle size; 50 mm, OD of finger cutter; OD160 mm -- Table movement by pneumatic–hydraulic cylinder -- Cycle time 2 to

CAM-WOOD SM-324D 4-Sided Planer for L-Shape MouldingSpecial Design for “L"; Shape Mouldings; One set of Cutter heads IncludedSpecifications: -- Maximum Working Width 12";, Max. Thickness 4"; -- Hard chrome-plated table for maximum wear resistance. -- Anti-impact plate for over-width and over-thickness protection. -- Oversized top and bottom rollers run synchronized, ensuring smooth feeding. -- FRP plastic steel safety guard provides maximum durability and impact resistance. -- The three independent sections; pneumatic pressures for the infeed rollers, in-process rollers, and outfeed rollers can be set with individual pressure allowing for consistent feeding and outstanding results. -- The smooth initial feeding of the stock is achieved by the independently powered infeed rollers. -- Specifically designed template inserted pressure plate suits various stock thicknesses and profile variations. -- A special pressure plate based on the table feeding roller design provides smooth and precise cutting of dry and wet wood, reducing the possibility of material jams.Features: -- The base is machined by CNC machine equipment to ensure the utmost working accuracy. -- The first bottom horizontal spindle can be fitted with a trimming cutter for trimming a groove on the workpiece side to achieve perfect straightness. -- The specially designed short stock feeding mechanism combined with auxiliary pressure wheels permits the machine to perform machining on extra short stocks. -- All spindles are precision constructed and specially heat treated to provide maximum cutting stability and permanent accuracy. -- Each spindle is equipped with a mechanical digital readout giving accurate adjustment. -- Every cutter spindle can be adjusted "up and down" and "in and out" for quick setup. -- Industrial full-power motors for maximum cutting capacity.Capacity and Heads: -- Max. Working Width 12"; -- Max. Working Thickness 4-3/4" -- Min. Working Length 9½" -- Vertical stroke of side head 30 mm (1.18") -- 1st Spindle Horsepower 10 HP -- 2nd, 3rd, 4th Spindle Horsepower 10, 10, 10 HP -- Feed Motor 7½ HP -- Elevation motor 1 HP -- Spindle arbor Diameter 40 mm -- Cutter Speeds (RPM) 6,500 -- Variable Feed Speeds (FPM) 16 ~ 82Cutterhead Diameter -- 1st Bottom Head 6"; Dia x 12"; L -- 2nd & 3rd Vertical Head 6"; Dia x 3"; L -- Top Head 6"; Dia x 12"; L -- Pneumatic Air 90 PSI (CFM) 5 -- Dust Outlets Diameter 5" x 4 outlets -- N.W. (Lbs) 9800Option: -- Sound enclosure Add ...$10,900

CAM-WOOD PL-24 TOP & BOTTOM STRAIGHTENING PLANER8" x 24" Capacity Planer for accurate and powerful two-sided planing in one pass.Includes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $3,000 Specifications: -- 25"; Max. Planning Width, 3/8" to 8"; Max. Planning Thickness. -- 1/4";Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 70 FPM Feed Speeds (Variable). -- 4,200 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges -- 25 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor and 1/2 HP Elevation Motor. -- Net weight 7,200 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-fre

CAM-WOOD PL-18 18" Wide Top & Bottom Straightening Planer. -- 18" Planer with straight knife heads with HSS knives for accurate and powerful two-sided planning in one pass.ADD for Spiral Heads with Carbide Insert Knives... $4,000.00Specifications: -- 17-3/4"; Max. Planning Width. -- 3/8 to 8" Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 10"; Min. Planning Length. -- 15 to 70 FPM Feeding Speed (Inverter Driven). -- 4,200 RPM Cutter Straight Knife Head Speed. (6,000 RPM for Spiral Cutter Head). -- (4) Knife Cutterheads. -- 15 HP Upper Motor. -- 10 HP Bottom Motor. -- 2 HP Feed Motor. -- 1/2 HP Elevation Motor. -- Table Size (L x W) 88" x 16". -- N.W. 6,500 Lbs.Features: -- Standard equipped with automatic thickness controller, easy, accurate and quick setting for the cutting thickness. -- Upper & lower straight knives or spiral cutterheads for accurate and powerful two-sided planing in one pass. -- The worktable surface is precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planning. -- Stepless variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The infeed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then accurate planing of the surface can be performed to prevent jumping during processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with heavy-duty drive chains and gears to provide a smooth even feeding during rough or finish planning. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- The heavy-duty rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial motor for maximum cutting capacity. -- All precision sealed long-life bearing for durability -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Changing the knife on the upper cutterhead only requires removal of the upper dust chute. -- The optional spiral insert head design allows for fast, accurate insert changes and minimum down time. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth chatter-free planing regardless of the feed rate or hardness of material being planed. -- A powerful motor is utilized to make adjustments quickly

CAM-WOOD PL-38 TOP & BOTTOM STRAIGHTENING PLANERIncludes (1) set of Spiral Insert Cutterheads with (1) set of 15 x 15 x 2.5 mm Insert Carbide Knives with (4) Cutting EdgesReplacement Knives: CT-SCH-15T 15 x 15 x 2.5 mm Spiral Knives - $3.60 EACHDeduction for HSS Knives in lieu of Carbide Insert Spiral Heads - Deduct $8,000Specifications: -- 3" to 38"; Max. Planning Width -- 3/8" to 7"; Max. Planning Thickness. -- 1/4"; Max. Cutting Depth. -- 12"; Min. Planning Length. -- 15 to 52 FPM Feed Speeds (Variable). -- 4,000 RPM Cutter Head Speed. -- Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm carbide insert knives with (4) cutting edges 40 HP Top Head Motor. -- 20 HP Bottom Head Motor. -- 5 HP Feed Motor -- 2 HP Elevation Motor. -- Net weight 9,800 Lbs. Equipped with: -- Standard equipment includes Automatic Thickness Controller for quick, accurate thickness adjustments. -- Top and bottom Spiral Carbide Insert Cutterheads with 15 x 15 x 2.5 mm Insert Knives for accurate and powerful two-sided planing in a single pass. -- The Planer’s table surface is precision ground then chrome-plated and polished to a mirror finish; wear resistance, easy to clean and maintain.Feed System: -- Heavy-duty upper feed carpet (conveyor) with spring-loaded steel “fingers"; holds stock firmly against the Planer’s table; prevents stock splitting while providing positive feed and smooth finish for rough and finish planing. -- The conveyor (carpet) is fitted with numerous pressure pins, or fingers, which firmly holds and stabilizes stock during the planing process. Fingers apply moderate pressure to the stock and provides accurate planing while preventing wide cupped boards from splitting and feeding problems while planing narrow material. -- (4) Powered feed rolls are driven via a gearbox linked to heavy-duty chains and sprockets; provides smooth even feeding during rough and finish planing. -- Stepless variable speed control (Inverter driven) for smooth adjustment of feed speed depending on the material hardness, depth of cut & width; allows for the best finish and feed speed. -- Anti-kickback device provides safety and is designed to work in unison with a conveyor stop. Safeguards mechanical parts in case of overload situations.Features: -- The heavy-duty CAST IRON frame supports the worktable, helps dampen vibration, and ensures years of dependable service. -- Powerful industrial motors for maximum cutting capacity. -- All precision sealed-for-life bearings for long and durable use. -- A built in cutterhead stand is designed for convenient knife changing at the bottom cutterhead. -- Changing knives on the upper cutter head only requires removal of the upper dust chute. -- Setup time is minimized to set cutter head height using the auto material thickness device. -- The top and bottom cutter heads are precision balanced to provide smooth, chatter-free planing regardless of the feed rate or hardness of planed material.

CAM-WOOD WP-4S-500-2C 4-SIDED, 19-5/8" WIDE X UP TO 20" HIGH PLANER SPECIFICATIONS FOR 6"; X 19-5/8"; HEAVY-DUTY PLANER: -- Width Capacity from 2-3/4" to 19-5/8" -- Thickness Capacity from 3/4" to 6"; (see options for taller side spindles) -- Variable Feed Speeds from 18 to 75 FPM (higher on request) -- 25 HP Top and Bottom Spindle Motors -- 20 HP Left and Right Vertical Spindle Motors -- (2) 1/2 HP Left & Right Chamfer Motor -- (2) 7-1/2 HP Feed Motors -- Belt-driven, high speed, 7,000 RPM spindle speeds. -- TEFC motors with sealed-for-life ball bearings provide accurate, vibration-free spindle vibration. -- Top & Bottom Cutterhead Dia. 5" -- Right & Left Cutterhead Dia. 5" or 6" -- Top & Bottom Spindle Dia. 60 mm -- Right & Left Spindle Dia. 40 mm (1-13/16" available) -- Chamfer Spindle Dia. 30 mm -- Insert Cutter Size 15 x 15 x 2.5 mm -- (4) 6" Diameter Dust Hood -- Machine Size 110" x 86" x 94" x net 15,200 Lbs. Additional Equipment and Options: -- Right side fixed fence (no charge) -- Change side head spindle rotation to rotate with the direction of feed (no charge) -- 1-13/16" side spindle dia. (no charge) -- Top & bottom spindle rotation against the direction of feed (standard) -- Wired for 480-Volt operation (no charge). -- Pair Auto-Set and Power Raise/Lower of right and left side spindles (included). -- Pair Spindle Brake on right and left side spindles (included). -- 12"; High side spindle with outboard bearing, add $19,000 -- 16"; high side spindle with outboard bearing, add $25,500 -- 20"; high side spindle with outboard bearing, add 30,700. FEATURES: -- Compact construction, huge moulding or planing capacity, extremely flexible and high-performance design. -- Digital controller automatically sets thickness & width adjustment -- Rigidly mounted alloy steel spindles with outboard bearing support provide accurate vibration-free power transfer. -- Spindle height adjustment by precision rack & gear sets -- Beds and fences are precision ground then chrome-plated and polished to a smooth mirror finish. The wear resistant surfaces are easy to clean and maintain -- Variable speed invertor controls for smooth adjustment of feed rate depending on the material hardness, depth of cut & width will provide the best finish surface and fast cutting performance -- The floating powered feed rollers are driven by geared transmission boxes linked to the feed rolls by heavy-duty universal joint axels while firmly holding stock securely to the bed; feeds positively to provide a smooth, even feed rate during rough or finish planning -- The heavy-duty welded and heat treated steel frame supports the beds and helps dampen vibration while safeguarding future years of dependable service -- Industrial rated motors for maximum stock removal and feed rates -- Precision sealed, long-life bearings throughout -- Removable cutter heads are designed for convenient knife changing even on the on the bottom cutterhead -- Changing

CAM-WOOD MODEL WP-4S 650 2C 25" 4-SIDED PLANER WITH MOULDING CAPABILITIES: -- WP-4S2C-650-6 25"; wide x 6"; high 4-Side Planer $189,900 -- WP-4S2C-650-12 25"; wide x 12"; high 4-Side Planer $208,900 -- WP-4S2C-650-16 25"; wide x 16"; high 4-Side Planer $226,900 -- WP-4S2C-650-20 25"; wide x 20"; high 4-Side Planer $238,900Designed for heavy furniture, cabinet, flooring, intermittent planing millwork, and other industrial uses. Perfect Planer for S2S and S4S planing up to 16" high x 25" wide timbers, tongue & groove flooring, wall paneling, etc. up to approximately 75 FPM depending on depth of cuts and dimensions of parts.SPECIFICATIONS: -- Width capacity from 2-3/4"; to 25";. -- Thickness capacity from 3/4"; to 6";. (up to 16"; with O/B Bearings is optional) -- Feed speeds variable from 18 to 65 FPM -- 15 HP Bottom head motor (20 HP optional) -- 20 HP Top head motor (25 HP optional) -- 20 HP Left (outside) spindle motor -- 15 HP Right (inside) spindle motor -- 1/2 HP motors on right & left champhering (top eased edge) spindles -- 10 HP feed motor -- 5"; dia. top and bottom cutterheads -- 5"; or 6"; dia. right & left cutterheads -- 60 mm (2.362";) dia. spindles on top and bottom heads -- 40 mm (1.574";) dia. spindles on top and bottom heads -- 30 mm (1.181") champhering spindles -- 15 x 15 x 2.5 mm insert knives -- (4) Dust outlets, each 6"; diameter -- Planer measurements: 110"; long x 91"; wide x 94"; high -- Planer weighs 19,500 Lbs. FEATURES: -- Compact construction with planing and moulding capabilities; provides flexible performance at an affordable price -- Equipped with a digital controller to set thickness & width automatically -- Rigidly mounted alloy steel spindle with outboard bearing support for accurate, vibration-free planing surfaces on horizontal spindles -- Spindle height adjustment by precision rack & pinion gear sets. -- Bedplates are precision ground, chrome-plated and polished to a mirror finish; provide a smooth, wear-resistant surface -- Variable speed inverter control for smooth feed speed adjustment depending on lumber hardness, depth of cut & width. Speed adjusts to provide the best finish and highest speed for best overall performance. -- Feed rolls are driven by geared transmission boxes and drive shafts with heavy-duty universal joints and drive shafts; provide smooth, even feeding for rough or finish planing -- Heavy fabricated steel plate frame, heated and stress relieved for vibration-free finishes, supports the worktable and helps dampen vibration for a superior finish. Ensures years of dependable service -- Industrial-grade, standard off-the-shelf motors for maximum cutting capacity and ease of service -- Bearings are precision, sealed, long-life bearings for durability and service life -- Removable cutterheads on all spindles, designed for convenient knife changing or rotating, including the bottom head. -- Changing or rotating knives on the top head only requires r

CAM-WOOD SM-124TAX 4-Sided Planer/Moulder; 11-3/4"; Wide x 4" to 9"; HighCompact construction with moulding & planing capabilities and flexible performance at an attractive price. Designed for furniture, cabinet, and yes, even industrial arts and large hobby shops. The perfect machine for tongue & groove flooring, wall paneling, S4S work, etc. Specifications: -- 2-Sided Planing Capacity: 7/16"; to 9"; thick x 11-5/8"; wide -- 4-Sided Planing Capacity: 7/16"; to 9"; thick x 10-1/4"; wide. -- All cutters run at 7,000 RPM -- Top and bottom heads are 2-27/32"; (72 mm) diameter. -- Right and left side heads are 3-1/2"; (90 mm) diameter -- All spindles powered by 4.1 HP (3 kW) motors -- Top Spindle will profile to a 3/8"; pattern depth and 5/16"; max. stock removal when planing. -- Bottom Spindle will profile to a 3/16"; pattern depth and 3/16"; max. stock removal when planing. -- Right & left side spindles are 4"; long and have a max. moulding depth of 13/16";. -- Machined and hard chromed table is 24"; wide x 40"; long and travels 9"; (230 mm) vertically -- Feed system runs at 11 to 52 FPM and is powered by a 1/2 HP variable speed drive. -- Overall dimensions are 54"; long x 42"; wide x 44"; high and weighs 1,370 Lbs.Features: -- Large 11-5/8"; wide x 9"; thick 2-sided planing capacity or 10-1/4"; wide x 4"; thick 4-sided planing and moulding work. -- Individual motors drive each spindle; 7,000 RPM spindle speeds on all heads. -- Mechanical meter for accurate thickness adjustments. -- Heavy-duty spindle assemblies for durability & run-out free finishes. -- Rigidly mounted alloy steel spindles in precision bearings provide accurate and vibration-free power transfer. -- Spindle height adjustment by precision rack & pinion gear system. -- Compact construction, Heavy-duty welded steel frame and See through top guard. -- Magnetic overload switch for protection. -- Industrial-rated TEFC motors with sealed-for-life ball bearings.

CAM-WOOD PL-12SX 12" Wide Top & Bottom Straightening PlanerFeatures & Equipped with: -- Spiral Insert Cutterheads. -- Standard equipped with Automatic Thickness Controller, easy and quick setting for the cutting thickness. -- Top & bottom carbide cutter heads for accurate and powerful two-sided planing in one pass. -- Auto digital thickness control for quick and accurate setup. -- The worktable surface was precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain. -- A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planing. -- Variable speed control by inverter for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance. -- The in-feed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then an accurate planing surface can be performed to prevent jumping during the processing of narrow or bent material. -- The (4) power feed rollers are driven with a geared transmission box linked with a heavy-duty drive chain and gears to provide a smooth even feeding during rough or finish planing. -- A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload Specifications: -- 7-1/2 HP Top Head Motor -- 5 HP Bottom Head Motor -- 12-1/2"; Max. Working Width -- 4-3/4"; Max. Working Thickness -- 19/32"; Min. Working Thickness -- 13"; Min. Working Length -- 1/4"; Max. Cutting Depth per Head -- 2 HP Feed Motor -- Feed Speed (Inverter drive) from 15 to 52 FPM -- 5,000 RPM Cutter Head Speed -- 1/2 HP Elevation Motor -- With (2) 6" diameter dust outlets -- Spiral Insert Cutterheads with (45) 12 x 30 x 1.5 mm carbide insert knives with (2) cutting edges. Allows for fast, accurate insert changes and minimum downtime -- If required, change of electrics, will be quoted separately

CAM-WOOD MODEL PL-40-SH 40" TOP AND BOTTOM SURFACER with Spiral CutterSPECIFICATIONS: -- 40"; Maximum Working Width. -- 12-1/4"; Maximum Working Thickness. -- 2"; Minimum Working Thickness. -- 1/2"; Max. Depth of cut (Per Side). -- 4,500 RPM Cutter Head Speed. -- 6-1/4"; Cutter Head Diameter. -- 15 x 15 x 2.5mm Spiral Cutter Head Carbide Insert Knives. -- 30 HP Top Cutter Head Motor -- 20 HP Bottom Cutter Head Motor -- 2 HP Elevation Motor -- (2) 5 HP Feed Motors -- Feed Speed (Variable by Inverter drive) from 12 to 55 FPM -- 5-3/4 Feed Roll Diameter. -- Universal Joint & Shaft Drive System. -- Machine Weight, 11,600 Lbs. -- Machine Size (L x W x H) 81" x 106" x 63". FEATURES: -- Roll feed eliminates slipping when running green and heavy wood. -- Universal Joint and Shaft Driven Feed Rolls ensure adequate feeding power for wet, rough lumber as well as warped, cupped and bowed material and provide needed power transmission against heavy cutting depths. -- Top and bottom feed rolls are directly driven by universal joints and drive shafts for full-power transmission. -- A movable control box provides additional convenience in operation and setup. -- Standard equipment includes automatic thickness control to aid in easy and quick setting for the thickness to be planed. -- Worktable surface is precision ground and electric chrome-plated and polished to a smooth mirror finish. The durable wear-resistance surface is easy to clean and maintain and promotes good feeding of all types of wood. -- Stepless variable speed control (VFD) for smooth adjustment of feed rate depending on the material hardness, depth of cut & width. Used to provide the best finish surface and fast feed performance. -- Twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload. -- Heavy, rigid cast iron frame supports the worktable, helps dampen vibration and ensures years of dependable service. -- Powerful industrial-duty motors for maximum power transmission. -- All precision sealed, long-life bearings for durability. -- A swivel stand is designed for convenient knife changing on the bottom cutterhead. -- Setup time is minimized to set cutterhead height using the auto material thickness device. -- The top and bottom cutterheads are precision balanced to provide consistently smooth, chatter-free planing regardless of the feed rate or hardness of material being planed.

CANTEK MRS-610M-4 GANG RIPSAW WITH (4) SHIFTING BLADES: Specifications: -- (4) Shifting Blades and 4.2" Max. cutting thickness without pressure plate, 3.7" with pressure plate; 24" Max. cutting width; 35.4" Max. material width of pass-through; -- 60 HP Saw motor (larger optional); 2.8" (70 mm) Saw arbor diameter turning at 3800 RPM; 12" Min. or 14" max. Sawblade diameter; 2.8" (70 mm) Sawblade bore when mounted directly on shaft, 3.5" (90 mm) when mounted on saw sleeve; -- 5 HP feed motor with variable feed speeds from 25 to 200 FPM; 1/2 HP pressure roller raising motor; 24" Min. stock length; 31.9" Min. stock length with board under (2) rollers.Features and Benefits: -- The main frame is cast iron, all the main parts are enclosed, ensuring protection and perfect stability -- Nickel chrome steel saw arbor with 70 mm OD double keyed quick removal sleeve. -- Heavy duty precision straight line feeding caterpillar chain type. -- Feed chain with easily replaceable bolt in cast steel or urethane pads - optional. -- The top pressure roller system is electronically positioned from the front control panel with regard to lumber thickness with position readout. -- Top roller hold down system is mated to the servo positioning short stock shoe providing optimum straight-line ripping performance and comprehensive safety. -- Pneumatic pressure (infinitely variable) to the holddown feed rollers provides better control of the lumber. -- Nickel chrome steel saw arbor. -- Variable feed speeds of 16 - 200 FPM. (5 - 60 m/min) via an inverter motor and speed control with led readout. -- Electronic overload sensing system is integrated to the inverter feed system providing automatic speed reduction under heavy amperage load. -- New - short stock cutting device included. -- Digitally controlled lubricator for chain. -- Centralized lubrication system. -- (2) Powered top & bottom outfeed rollers are a standard feature. The powered roll system facilitates positive flow of the stock through the gang saw and onto outfeed conveyors or transfers. -- (3) Rows of anti-kickback fingers. -- Telemechanique - automatic star-delta starter (low amperage soft-start) and low voltage controls -- Controls are mounted on the saw for easy convenient machine operation. -- Includes 12' infeed table -- Gang saw sleeve is an optional extra. -- Electrics to 230/460 or 575-volt, 3-phase, 60-cycle to UL/CSA standards -- Complete Shifting Fence Infeed Tables and complete Outfeed Sweep Systems, handling decks and Stacking Systems are available.Options available: -- Add a 75 HP saw arbor motor instead of 60 HP - including a Wye-Delta low amp Starter. -- 100 HP Saw arbor motor in lieu of 60 HP - including Wye-Delta low amp Starter -- 125 HP Saw arbor motor instead of 60 HP - including Wye-Delta low amp Starter. -- Short Stock Feeding device (min. length 12" - must use 12" blades for max. thickness of cut of 2.16" (55 mm). -- 20 mW Laser (FP MLC1320W) & Laser Holder w/12" B

CANTEK P 630HV Single-Sided Planer with Helical Head. --PLC digital control for auto-thickness setting. -- Sectional infeed roller and sectional chip breaker. -- Anti-kickback safety fingers for safe operation. -- Variable speed drive for optimum finish results according to the planing depth and material being planed. -- Quick-set table roll adjustment to aid in feeding difficult-to-feeling material. -- Steel spiral cutterhead with carbide inserts – 6 rows 86 inserts 30 x 12 x 1.5 mm cutters mounted on an angle for 'shear' cut. -- Exhaust hood with 6″ outlet. -- Flip open the upper hood for easy and convenient access to change the knives on the cutterhead. Safety limit switch on the cover will not allow the operator to run the machine with the hood open. -- 4 Table raising jackscrews.Specifications: -- Maximum planing width 24-3/4″. -- Maximum planing thickness 11-13/16″. -- Minimum planning thickness 3/8". -- Max. depth of cut 5/16″. -- Minimum length 8-3/4″. -- Table size 27″ x 34″. -- Feed speed 20-39 FPM Variable. -- Main motor 10 HP. -- Feed motor 1 HP. -- Power rise and fall of table 1/2 HP. -- Dust hood (1) 6". Machine dimensions: 51"; x 38"; x 47";. -- Shipping dimensions 44"; x 39"; x 52. -- Net weight 1804 Lbs. -- Shipping weight 2024 Lbs. -- Machine Electrics 230/3/60 - 31.6 amps, 460/3/60 - 15.8 amps. -- 575/3/60 - 12.8 amps

CANTEK CM626 Single-Sided Planer with Helical Head26" x 11-3/4" capacity Planer w/Helical Cutter HeadFeatures: -- Spiral cutterhead with (6) rows insert knives provides high removal, superior finish, and low noise. -- Solid cast iron construction. -- Variable feed speed. -- Drive top and bottom feed rolls. -- Front & rear bed rollers easily adjusted from the front of the machine. -- Power table elevation by digital thickness control. -- Serrated solid infeed roll. -- Section chip breaker. -- Anti-kickback fingers for added safety. -- Dual heavy jack screws with slides for accuracy & rigidity. -- Dust/Chip exhaust outlet 6"; in diameter. -- Sound dampening machine cover. -- All operations on a convenient control panel. -- Two-sided solid carbide inserts are easily changed while providing optimum wear lifeSpecifications: -- Maximum planing width 26" -- Maximum planing thickness 11 ¾" -- Minimum planning thickness 0.15"; (4 mm) -- Maximum depth of cut 0.31"; (8 mm) -- Minimum planning length 10.35" (263 mm) -- Table area 35" x 27" -- Feed speeds variable 16 – 70 FPM -- Main motor 20 HP -- Feed motor 1 HP -- Table motor 1/2 HP -- Knives 30 x 12 x 1.5 qty 100 -- Cutterhead 4 ¾" dia. x 5000 RPM -- Top feed rollers 3" dia. -- Dust hood outlet 6" dia.

CANTEK JF-330A Profile Knife Grinder Clamping length of 12" (300 mm) for both straight and profile grind; dia. of knife swing 12" (300 mm). -- Grinding Arbor: 3 HP grinding motor with VFD (LED Readout) drive from 1.500 to 4.200 RPM. Quick change removable (140 mm) wheel adapter. Machine set for axial constant grinding and template set up on right-hand side.Over the wheel precision diamond dresser assembly for dressing and dimensioning of wheel. Manual positioning: of grinding wheel to tool; positioning of back clearance angle and side clearance angle 5°/10° and 15°. Quick change stylus turret for applications; (6) included with machine. -- Carriage: SCHNEEBERGER linear bearing table movement. Table movement 12" x 6". -- Coolant system: 1/8 HP motor from coolant pump located in the tank below; (3) coolant nozzles for smooth flow of coolant to knife rest during grinding. Additional hose with nozzle for cleanup. Stainless steel splash guards throughout! -- Includes: Set up tools, coolant, HD worklight, grinding wheels and (1) arbor of choice - (1.25", 1.5", 40mm, 1-13/16", 2.125" or 50 mm).

CANTEK - GOODSPEED CP-1250 AP Hydraulic Copy Lathe. -- General Data: 44" Length cap. with 4" min. length of stock and 1/2" - 4" max. diameter cap., hopper feed with automatic chucking, square or round stock can be hopper fed. -- Equipped with: 7.5 HP Spindle motor, 1,800 - 3,200 RPM spindle speed adjustable by pulley change, 3 HP hydraulic motor. -- Complete with: Swivel control panel, PLC sequence controller built into separate control cabinet, (3) pressure gauges, automatic way & support collar lubrication & safety wire mesh across the front of machine. -- Includes: Two hydraulic copiers (rough + fine). Travelling steady rest and installed knives. -- Production capacity: Approx. (5 - 7) pieces/Min for 600 mm length, (3 - 5) pcs./Min for 900 mm length, (2 - 3) pcs./Min for 1,200 mm length, depending on cutting speed, type of material, etc. -- Electrical load: 11.4 amps, 10.5 HP @ 575/3/60.volts.

CANTEK - GT635ARD-16 25″ Double Surface Planer25″ Wide x 16″ thickness capacity Add on $2,500 for increase HP of top head to 30 HPFeatures: -- Cutterheads are spiral insert types with six (6) rows of carbide inserts. -- (2) Driven and (1) idle bedroll for superior feeding of even difficult material. -- Swiveling control panel for more ergonomic access to machine controls. -- Inverter variable speed control with feed speeds from 26 to 80 FPM. -- Easy to access external handwheel adjustment of infeed bed. -- Hard chromed worktable for high wear resistance. -- Auto lubrication to conveyor chain, central lubrication for dovetail elevation guideways. -- Sectional chip breaker and sectional feed roller before top cutterhead.. -- Rubber outfeed top roller to prevent chip marking. -- Over thickness safety shut-off bar across infeed. -- Ammeter for each motor on the control panel to monitor motor load.Specifications: Maximum working width 25″Maximum working thickness 16″; Minimum thickness 0.394"; Min. workpiece length 12.2″Bottom head motor 20 HP, Top planing head motor 25 HP - Feed motor 5 HPTable elevation motor 1/2 HP.Cutterhead diameter 4", Knife dimensions 30 mm x 12 mm x 1.5 mm w/bevels (96 pcs per head)Cutterhead speed 5400 RPM;Feed speed (variable) 26 - 80 FPMDust ports 2 @ 6";; Table dimensions 27" x 103" (41.85" from the floor);Machine voltage 460/3/60 = 70 amps.Dims & Weight (LxWxH) 105″ x 45.1″ x 92.9″; (max.) Net weight 6700 Lbs,Packaging dimensions 109″ x 49″ x 89″; Gross weight 7800 Lbs

CANTEK GT610HI CARDAN SHAFT DRIVE DOUBLE SURFACE PLANERSpecifications: -- Max. working width 24" (610 mm). -- Max. working thickness 8" (200 mm). -- Min. working thickness 5/16″ (8 mm). -- Min. working length 12" (300 mm). -- Cutterhead RPM 5000 RPMCutterhead diameter 5.3" (135 mm). -- Feed speed 30-98 FPM 10 – 30 m/min. -- Top cutterhead motor 40 HP. -- Bottom cutterhead motor 30 HP. -- Feed motor 5 HP. -- Table Rolls 7 (3) driven. -- Opening hoist motor 1 HP. Machine dimensions: (LxWxH) 112"; x 67"; x 67"; 2830x1700x1700mm . Machine weight 8800 Lbs 4000 kgsShipping weight 9240 lbs 4200 kgs. -- Shipping dimensions (LxWxH) 115"; x 75"; x 75"; 2900 x 1900 x 1900mmMachine electrics (Standard) 460/3/60 = 110 amps (Other voltages on request, factory order)Key Advantages• Cast iron machine frame for superior vibration damping resulting in a long machine & bearing life.• Chrome-plated tables and top and bottom for maximum wear resistance.• Cutterheads are mounted in precision ABEC 7 RHP bearings.• The feed system uses a spring-loaded pin arrangement to pass material over the bottom jointing head.• Sectional serrated infeed roll before the top cutterhead.• Variable feed speed by frequency inverter (VFD) with digital display for the feed speed.• Digital thickness control for quickly and precisely setting the desired thickness.• The upper assembly is adjusted for desired thickness by four large-diameter cylindrical posts.• Adjustable infeed bed by easily accessible handwheel to set desired stock removal on the bottom head.• Easy to access swivel control panel with individual ammeters for load monitoring and hour meter to aid in maintenance planning.• Cutterhead starters are Y-Delta providing a soft start to the heads for reduced power consumption on startup.• Automatic lubrication to the conveyor feed system.• High-quality Schneider electrical components to CSA/UL standard.

CANTEK - GT635ARD-8 25″ Double Surface Planer25″ Wide x 8″ thickness capacity Add on $2,500 for increase HP of top head to 30 HPFeatures: -- Cutterheads are spiral insert types with six (6) rows of carbide inserts. -- (2) Driven and (1) idle bedroll for superior feeding of even difficult material. -- Swiveling control panel for more ergonomic access to machine controls. -- Inverter variable speed control with feed speeds from 26 to 80 FPM. -- Easy to access external hand wheel adjustment of infeed bed. -- Hard chromed worktable for high wear resistance. -- Auto lubrication to conveyor chain, central lubrication for dovetail elevation guideways. -- Sectional chip breaker and sectional feed roller before top cutterhead.. -- Rubber outfeed top roller to prevent chip marking. -- Over thickness safety shut-off bar across infeed. -- Ammeter for each motor on the control panel to monitor motor load.Specifications: Maximum working width 25″Maximum working thickness 8″; Minimum thickness 0.394"; Min. workpiece length 12.2″Bottom head motor 20 HP, Top planing head motor 25 HP - Feed motor 5 HPTable elevation motor 1/2 HP.Cutterhead diameter 4", Knife dimensions 30 mm x 12 mm x 1.5 mm w/bevels (96 pcs per head)Cutterhead speed 5400 RPM;Feed speed (variable) 26 - 80 FPMDust ports 2 @ 6";; Table dimensions 27" x 103" (41.85" from the floor);Machine voltage 460/3/60 = 70 amps.Dims & Weight (LxWxH) 105″ x 45.1″ x 92.9″; (max.) Net weight 6700 Lbs,Packaging dimensions 109″ x 49″ x 89″; Gross weight 7800 Lbs

CANTEK - GT400BRD 16″ Double Surface PlanerGeneral description: -- Spring-loaded conveyor pin system ensures material is passed over the bottom cutterhead to resulting in a flat and uniform board prior to planning to thickness on the top head. -- Spiral insert knife cutterheads with two-sided solid carbide knives produce a smooth finish with increased stock removal capacity and extremely quiet operation. -- Heavy-duty cast-iron machine body and table for vibration-free cutting.Digital electronic thickness adjustment in INCH and MM (Inch = 0.001"; / mm = 0.01mm resolution) for precise thickness control KEY ADVANTAGES SERVICESpecifications: -- 16″ Wide x 6.7″ thick planing capacity -- 10 HP Bottom Head and 15 HP Top Head -- Cutterheads are spiral insert types with six (6) rows of carbide inserts. Cutterhead speed 5,400 RPM. (2) Driven and (1) idle bed roll for superior feeding of even difficult material. -- Swiveling control panel for more ergonomic access to machine controls -- Inverter variable speed control with feed speeds from 26 to 80 FPM, 2 HP variable feed drive.Features: -- Easy to access external handwheel adjustment of infeed bed -- Hard chromed worktable for high wear resistance -- Auto lubrication to conveyor chain, central lubrication for dovetail elevation guideways -- Section chipbreaker and sectional feed roller before top cutterhead -- Rubber outfeed top roller to prevent chip marking -- Over thickness safety shut-off bar across infeed. -- Ammeter for each motor on control panel to monitor motor load -- Star-Delta soft start.
