100 HP - 1800 RPM Belt driven. -- Jacketed water-cooled requiring 14 Gpm. -- All stainless wetting surfaces and replaceable stainless tools. -- 24" Inside diameter x 102" inside length. -- 14-1/2" x 18" inlet and 12" x 30" outlet. -- Capacity rating is 6,600 to 26,400 pounds per hour at 6 pound density.

Lobo 3-Head 43″ Wide Belt Sander (+ Flap/Brush Head)43" width cap, Drum, Drum, Combination HeadHead Configuration:1st Head: 9"; diameter grooved rubber-covered contact roll, with 20 HP – 1,760 RPM Motor.2nd Head: 9"; diameter grooved rubber-covered contact roll, with 15 HP – 1,760 RPM Motor.3rd Head: Combination Head with 6"; diameter grooved rubber-covered contact roll, smooth steel contact roll, with a 2″ air-inflated finishing platen, & 15 HP – 1,760 RPM Motor.Specifications -- All (3) heads have dial indicators for positioning PLUS a FOURTH dial indicator on the platen. The fourth head is a flap sander brush with a 3 HP motor -- Between heads one and two you will find hold-down shoes. Hold-down shoes control a workpiece as it passes through the sander, making it easier to run shorter parts through and prevent trailing edges and sniped or dubbed leading edges. -- Overall all capacity is 43″ wide X 5-5/8″ thick. -- Sanding Belt Dim. 43" X 75"Equipped with & Features: -- The feed mat, besides having 100% life, is 43″ wide and 7-1/2′ long. -- The feed motor is 3-1/2 HP and has variable speed from 5-45 FPM. -- The “FPC-515"; Touchpad Position Controller with LED Display for programmable thickness adjustment is in near flawless condition..

Lobo TS-P3200AU Sliding Table SawSpecifications: 126" Cutting length with w/scoring. -- 14-1/2" Anodized sliding table that locks in any position for easy loading. -- 45° Tilting (30 mm) main saw arbor. -- 16" Main blade dia. with scoring. -- 5" Max. material thickness at 90°. -- 49" Max. ripping cap. -- 10 HP Main and 0.75 HP scoring motor. -- (3) Choices in cutting speeds of 3,000 - 4,000 or 5,000 RPM. -- 120 mm (4-11/16") Dia. scoring blade cap. which rotates at 7,000 RPM.Features: Easily adjustable scoring unit with external knob. -- Manual height & tilt adjustment using a hand wheel. -- Articulating overarm protection guard and 35" x 27-1/2" cast iron main table. -- 31" x 18" Outboard and 28" x 25" rear extension table. -- Micro-adjustable rip fence and removable crosscut fence with (2) repeat stops. -- 47" Long clamping miter fence w/flip-stop.

LOBO CT508 STRAIGHT KNIFE PLANER20" x 8" Capacity, 5 HP single phase motor, 4-knife - 5,000 RPM cutterhead, 7" minimum part length, 1/4" maximum stock removal, manual bed height adjustment. -- 20" X 26" Bed dimensions. -- Feed speeds 16 /20 FPM -- Cutter head speed 5,000 RPM -- Chain drive feed rollers -- Solid chip breaker -- Extension rollers for longer stock. -- Complete with magnetic control, start/stop feed clutch, and dust hood.

LOCATELLI "OMK-300" Automatic Lathe with Sanding; From automatic feeding to finished product ejection - a complete "Turning & Sanding" System. -- 11-13/16" Max. between centers, 3-1/8" max. & 5/16" min. stock dia., 5.5 HP spindle motor with (3) spindle rotations of 3,020 - 4,580 & 6,400 RPM.6-Station Rotary Carousel/Drum with the following operations: -- Station 1: Pickup and centering of workpiece. -- Station 2: Turning with hydraulically operated roughing & finishing gouge. -- Station 3: Finish turning with hydraulically operated finishing gouge; rough & finish gouges advance via 1.5 HP hydraulic motor at a rate of 0.33 - 52 FPM. -- Station 4: Initial sanding with adjustable 0.5 HP vibrating brush. -- Station 5: Secondary sanding with adjustable 0.5 HP vibrating brush. -- Station 6: Ejection of finished workpiece. -- PLC Function for immediate fault detection and facilitates setup. Complies with CE high standards for operator safety. -- Features: Billet capacity has been increased to a special 5.9" x 5.9" (150 mm square). -- Complete with: Separate operator control panel. -- Includes: Inventory of spare parts and tooling. -- Machine kept under power but has not been used for production for several years.

LOEWER DENIBBING SANDER4-Head, 53" width cap., great Denibbing Sander -- The patented conbination of rollers and rotating / oscillating discs makes the Perfection BBDD sanding machiine the ideal finishing solution for entry doors, cabinet doors, drawer fronts, sheet foods, shutters, face frames, furniture and much nore. -- The LOWER DMBBDD sanding machine is sthe ideal soluton for all sanding applications including whitewood, stain and sealer coats(inciuding UV). The work piece first passes under two large counter rotating spiral hubs, then under eleven rotating discs that oscillate from left to right. This provides very uniform edge breading in whitewood sanding and eliminates most (if not all) hand sanding of the sealer coat. -- The patented combination of roller and rotating discs provieds very uniform sanding across the entire work piece, even into deep profiles without loosing detail. -- SPECIFICATIONS OF MACHINE --Thickness of work piece Min: 10mm (1/2")-- Max: 80mm (3") --Feed belt width Max:1350mm (53") --Feed belt motor 1.5 KW (3Hp) 3-15 M/min (10-50 Ft/min) --Top sanding roller 2.2KW (3Hp) 25-300 O/min (RPM) --Disc Rotation 2.2KW (3Hp) 25-300 O/min (RPM) --Disc Osciliatiojn ).37KW (0.5) 10-60 O/min (RPM) --Vacuum motor 7.5KW (10Hp) --Machine weight 1,800 kg -- Aproximate Machine dimensions based on similr machine W:2000mm (6'7")/ L:2780mm (9'2")/ H:6'11")

LOEWER DISC MASTER 3DBB Denibbing Sander with (2) Sanding Stations, 53" Width Capacity:53" Width cap. Denibbing Sander with a patented combination of rollers and rotating/oscillating discs make the LOEWER Discmaster 3DBB Sanding Machine the ideal finishing solution for entry doors, cabinet doors, drawer fronts, sheet goods, shutters, face frames, furniture and much more. -- Ideal solution for all sanding applications including whitewood, stain and sealer coats (including UV). -- Operation: The workpiece first passes under (16) rotating discs with abrasive brush loadings and then under (2) large counter-rotating spiral brush roller type hubs,Head Configuration: -- 1st Unit: (16) Rotating discs 250 mm (10") diameter each with (24) keyways 75 mm (3") long that oscillate from left to right; provides very uniform edge breading in whitewood sanding and eliminates most (if not all) hand sanding of the sealer coat. The discs are variable speed from 50 - 300 RPM by frequency inverter. Eccentric orbital disc movement (patent pending). Separate height adjustment of the disc station to run discs only or brush rollers only or everything together. Digital display to show the height of the discs. -- 2nd Unit: (2) - 400 mm 16" dia. rotating brushes sanding rollers powered by 2.2 kW gear motor with external coolers. -- Variable spindle speed 14 - 300 RPM adjusted by frequency inverter on each spindle and separately adjustable. The first drum rotates with the feed and the second rotates against the feed. Includes a panel blow-off station. -- The patented combination of rollers and rotating discs provides very uniform sanding across the entire workpiece, even into deep profiles without losing detail. Specifications: -- Disc oscillation by 0.37 kW (0.5 HP) motor, (0 - 60 Cycles/Min). -- Min. part thickness 4 mm (3/16") and max. 4"; -- Vacuum bed with 7.5 kW (10 HP) motor; Vacuum blower outlet on side of the machine has 200 mm outlet. -- Variable vacuum bed conveyor feed speed from 3 - 15 m/Min (8 - 50FPM). -- Pneumatic belt centering system. -- Fixed bed height for installation in a line. -- Separate variable speed adjustment for disc & roller. -- Antistatic brush strip device. -- Control panel Left Side-mounted. -- Emergency stop pull cords at both infeed and outfeed. -- Dust extraction outlets 3 x 80 mm (3.2") 4 x 140 mm (5.6") and 1 x 200 mm (8").Equipped with: -- PLC Touch-screen control: Simple & user-friendly "TOUCH SCREEN" PLC control with color monitor; PLC storage capacity for up to (25) individual sanding programs; -- the PLC control interface also allows for easy machine connection to a flat-line, tow-line or hanging-ling finishing system.

Dust Collection Pipe (Snap Ring type Pipe)Quantity - Diameter - Length Description(2) 22" - 12" - 38" Branch.(1) 24" - 12" - 38" Branch.Many loose Snap Rings in the tote.(1) 25" - 59" Pipe.(4) 22" - 59" Pipe.(2) 24" - 59" Pipe.(1) 24" x 22" x 6" 21"; Reducer with branch.(1) 22" x 20" x 12" 33"; Reducer with branch.(1) 11" x 10" x 10" 29"; Reducer with branch.(1) 12" Auto gate.(18) 10" - 59" Pipe.(2) 9" - 59" Pipe.(1) 11" - 59" Pipe.(4) 12" - 59" Pipe.(1) 22" - 29" Pipe.(1) 20" - 50" Elbow.(1) 20" x 16" x 12" - 33" Reducer with branch.(1) 24" x 24" x 10" - 29" Branch.(1) 24" x 24" x 6" - 24" Branch.(1) 16" x 12" x 7" x 7" - 45" Reducer with branch.(1) 22" x 22" x 6" - 20" Branch.(7) 12" - 59" Pipe.(4) 14" - 59" Pipe.(1) 16" - 43" Pipe adj.(18) 8" - 59" Pipe.(68) 6" - 59" Pipe.(10) 3" - 59" Pipe.(2) 8" - 32" Pipe.(32) 8", 9", 10", 11" - 59" Pipe.(46) 5" - 59" Pipe.(8) 7" - 59" Pipe.(39) 4" - 59" Pipe.(1) 14" x 12" x 6" - 21" Reducer & branch.(1) 14" x 14" x 6" - 21" Branch.(20) 3", 4", 5", 6" - Various pipe. (1) 6" x 6" x 6" - 21" Branch.(1) 10" x 10" x 4" - 17" Reducer.(1) 10" x 7" x 7" - 23" Reducer.(1) 10" x 9" x 4" - 17" Reducer & branch.(1) 10" x 7" x 7" - 23" Reducer & branch.(1) 10" x 7" 9" Reducer(5) 10" - 18" 90° Elbows.(20) 5" - 8" 90° Elbows.(7) 7" - 8" 90° Elbows.(23) 6" - 8" 90° Elbows.(20) 8" - 20" 90° Elbows(4) 5" - 6" Saddle.(1) 7" x 4" x 4" - 19" Reducer & branch.(2) 8" x 7" x 6" - 21" Reducer & branch.(1) 7" x 6" x 4" - 17" Reducer & branch.(1) 11" x 11" x 9" - 31" Branch.(1) 12" x 8" x 8" - 19" Reducer & branch.(1) 7" x 6" x 5" - 19" Reducer & branch.(1) 11" x 10" x 4" - 17" Reducer & branch.(1) 14" - 39" - 90° Elbows.(1) 9" - 20" 90° Elbows.(2) 10" - 16" 90° Elbows.(1) 7" 22" Pipe.(1) 10" x 10" x 4" - 17" Branch.(2) 10" x 8" x 6" - 21" Reducer & branch.(1) 14" - 39" 90° Elbow.(1) 9" - 20" 90° Elbow.(2) 10" - 16" 90° Elbows.(1) 7" - 22" Pipe.(1) 10" x 10" x 4" - 17" Branch.(2) 10" x 8" x 6" - 21" Reducer & branch.(1) 8" x 8" x 6" - 23" Branch.(1) 12" x 10" x 6' - 21" Reducer & branch.(1) 8" x 6" x 4" - 18" Reducer & branch.(28) 4", 5", 6", 7", 8", 9", 10", 14" Misc.(1) 14" x 11" x 6", 6" 42" Reducer & branches.(1) 8" x 7" x 6" - 21" Reducer & branch.(1) 12" x 7" x 7" - 34" Reducer & branch.(1) 12" x 11" x 4" - 17" Reducer & branch.(1) 5" x 5" x 5" - 17" Branch.(1) Batch 50' - 24" Straight pipe.(1) Batch various 24" - 90° elbow.(1) Batch various 24" - 45° elbow.(1) Batch 150' - 12" Straight pipe.(1) Batch various 12" various fitting.

MAC 120-MCF-572 High Capacity Baghouse Dust Collection system with Rotary Air Lock (RAL) and Medium-pressure Controlled air cleaning dust Filter (MCF). -- Baghouse Capacity: 50,000 CFM @ 7.2:1 Air-to-cloth ratio (ACR), approx. 6,921 sq-ft of filter area based on (572) Filter bags; 120" long x 5" dia. -- Equipped with: (1) AIR TECH size 402, BISW, Backward Inclined Air Handling Fan, Class IV, with 40" inlet, ground-mounted on unitary base, flanged inlet box & outlet. For prior application fan operating point (RPM/SP) is set up for about 41,526 CFM @ 12" WG at 1566 RPM, drawing 119 BHP. the fan is equipped with a variable volume damper on discharge. Fan range is about 40,000 - 55,000 CFM. Powered by a TOSHIBA 150 HP TEFC, 444T, 1800 RPM motor packaged with a belt drive -- Bag Cleaning: Mac "Never-Miss" Cleaning System with rotating arm, diaphragm valve for pulse cleaning Approx. 3 HP positive displacement (PD) pump for bag cleaning at only 7- 9 PSIG. 1 HP direct drive gear motor for distribution arm, integral manifold/surge tank, pneumatically controlled firing mechanism activating the diaphragm valves/nozzles. When cleaning arm & bag segments are correctly aligned air nozzles fire directly into bags without wasted cleaning air. -- Includes: MAC FS24x24 AIRLOCK Rotary Air Lock (RAL) with approx. 2 HP SYNCROGEAR MODULE gear motor; sprinkler package; 60° Cone-shaped hopper attached to MAC at bottom of cone. -- Features: Floor-standing Electrical controls (excluding shared controls) with MOTORTRONICS Solid State AC Softstart for main 150 HP motor. -- Additional Features: Explosion vents. Summer/Winter diverter and return air ductwork. Support structure. Caged access ladder from ground Service Platform and to the top plenum. -- Baghouse constructed of 7 gauge carbon steel containment; one piece body all welded construction, 180" (15') diameter shell panelized unit, walk-in plenum for maintenance and bag replacement. -- MAC design features: MCF 4HVP Pump package. MCF Medium-pressure air requires less HP and yet offers high dust and air collecting efficiency with unmatched baghouse cleaning at lower operating cost. MCF pulses each bag the same number of times with the same amount of air. (Unlike some competitors which clean the inside rows of bags more often than necessary thus wasting energy, causes uneven pressure drop, and bag wear). -- (2) of these identical units are installed per photos, one only is available based on Owner/buyer agreement and price point. Material handling fan/drive is not included and is assumed to stay with the remaining filter unit. -- Overall dimensions: 580.5" high x178.5" square frame with an estimated weight of filter unit (less structure and accessories) 31,000 Lbs. -- Professional dismantling/rigging, truck loading and transportation are available at extra cost. -- NOTE: Per photo #1 on the Ex-Factory website the unit for sale is on the right-hand side. The left-hand unit is not easily accessible.

MAC/SCHENCK 144-RPT-252 STYLE III Baghouse Filter System with Pulse Jet Cleaning and Rotary Air Lock (RAL) discharge.RPT Filters (Rectangular Pulse Top-Removal) Rectangular top removal bodied filter unit designed to handle high air volumes. • Bags are removed vertically from the top clean section. Walk-in plenum so the filter media replacement and maintenance can occur in an enclosure for inclimate weather. -- Baghouse Capacity: 4,770 sq. ft. of cloth consisting of (252) bags, 144" long 16 Oz P84 Top Load bags and bright wire cages. Depending on your application, for example at an air-to-cloth ratio of 3.14:1 it can develop 15,000 CFM. -- Equipped with: (1) PHELPS FAN, Material Handling, WRM-380 CCW-TAU HD ARR. 8 with A-36 inlet flange Performance at 15,000 ACFM & 15" SPWG, 1780 RPM, 315°F, 0.050 #/cu. ft..500' elev. Direct drive MOTOR IS NOT INCLUDED but was designed for 75 HP, 1800 RPM,, 365T. Fan was connected in a negative pressure configuration, flanged inlet & outlet. -- Bag Cleaning; Requires 33 SCFM of clean, dry air at 90-100 PSIG. -- Complete with: Auger on bottom of hopper feeding Rotary Air Lock (RAL) with approx. 1.5 HP gearmotor at 22 RPM.; (3) Rupture style explosion vents.. -- Features: Equipped for High Temperature (400°F) bags Special equipment includes VITON Diaphragm valves, copper line (in lieu of polyflo tubing)high temperature air header connections and hi-temp purge pipe compression on couplings. (2) 2" NPT couplings with plugs are included in the plenum section for future addition of sprinkler/deluge system. -- Filter unit constructed of carbon steel containment with 3/8" x 4" reinforcing ribs. 34" diam. high entry inlet and top outlet. -- Includes: Nema 4 Timer Board and solenoid valve enclosure. Each require 110/60 Hz power supply. Filter has (2) solenoid valve enclosures. -- Dimensions: 492" overall height (ground to top), 156" square sides. Separates into (3) sections: Top Plenum, filter section and bottom hopper/support steel. -- Dismantling/rigging is included. Please inquire for transport to your location.. -- NOTE: Extra high Stainless Steel stack is available if you want it.

MACDONALD STEEL 65 ST Dust Collector System with Shaker filter cleaning, Rotary Air Lock, and 18' dia. housing. -- Specifications: Capacity for 65,000 CFM, 18' dia. shell, with 8,199 sq-ft. of filter area for an air-to-cloth ratio of 7.7:1. T-150 polyester bags 14 oz. with a 30 - 40 CFM.@ 1/2" WG permeability. -- Current Fan configuration: System 1: Fan inlet of 33" at 32,500 CFM; System 2: .Future capacity for a second fan as per System 1. Return air duct is 42" x 72". -- Filter Cleaning: Top mounted electrically operated & timed mechanical shaker, approx. 2 HP motor which will automatically operate on all shutdowns. -- Equipped with: MACDONALD 18" Rotary Air Lock (RAL) with bottom eductor/T-section for connection to a relay/transfer fan (not included.). -- Complete with Fire Damper, Summer/Winter Damper with Silencer, Explosion doors, safety ladders, and access platform. -- Features: 13" MH/HT 20 HP Transfer/Transport fan -- Overall height is currently 57'-3" with 12' clearance under RAL. Weight of filter with structural steel is 29,000 Lbs plus fan is about 3,000 Lbs. -- Shell panelized construction (made of separable panels allowing for road/Hwy travel).Professional rigging, loading and transportation are available at extra cost; quote upon request.

MACDONALD STEEL 37 PTFU Dust Collector with Shaker type bag cleaning. -- 30,500 CFM, 150 HP blower with 37" inlet dia., 4,354 square feet of cloth filter area with 7.0 to 1 air to cloth ratio, (114) 9" dia. X 168" (14') long bags, 1.5 HP shaker motor, -- MACDONALD 37 AT main fan belt driven by a 150 HP WEG motor. Silencer on fan discharge. 11' dia. baghouse with 2,160 cubic feet storage cap; overall height of approx. 55' -- Includes: Retrofitted hopper with transition to bottom auger to Rotary Air Lock (RAL). Explosion Doors -- Features: Enclosure with SIEMENS Variable Frequency Drive (VFD) for efficient ramp-up control convenient fan speed control as needed.Summer/Winter diverter on return air line. Truck level loading .'Y' branch on inlet with approx. 33" & 16" supply lines. -- Complete with: Electrical control panels with with starters for auger and RAL. All external ducting, and about 100' manifold of 33" dia. steel flanged main trunk supply line. Safety ladders & access platforms.

MACDONAL STEEL - 26 PT: Dust Collector with RAL/Auger and Diverter Gate.Overall data: 16,700 CFM; 1,780 sq/ft. of cloth area comprised of: (85) Bags: 8" Dia. & 120" long; 60 HP blower; 26" inlet dia. with retrofitted Auger/Rotary Air Lock. -- Equipped with: Electrically operated mechanical bag shaker; back pressure damper on inlet manifold; Diverter/Abort Gate. -- Complete with: Safety hoop access ladder; (1) access platform to filter media; (1) top mounted fan/motor; silencer on return air. -- Starter/electrical control panels and disconnects inside/outside for each drive. -- Used 150 HP; rated VFD is available at extra cost.

NORDFAB NFK Series Modular Dust Collector with (8) Modules, reverse air cleaning and drag chain unloading into a Rotary Air Lock (RAL) --23,000 CFM approx. capacity based on filter area and desired Air to Clothe Ratio. With 50 HP. Consisting of (248) filter bags of 8.7" dia. x 77.2 " long(220 mm x 1,960 mm long) also (8) filter bags of 8.7" dia. x 54.1" long.(220 mm x 1,375 mm long) - located at cleaning fans - for a total of 3,680 sq. ft. of filter area. -- Consists (8) modules and (1) inlet blank module. Fan inlet approx 26" dia. -- Bottom conveyor chain with scrapers carrying the dust to one end and fed into the RAL -- Includes NRS-10 Rotary Air Lock and Transfer Blower to convey the dust to an enclosed waste container (not included). -- Electrical control panel with starters included. -- Overall dimensions 32' long x 7.5' depth x 13.5' high (without support steel)., Approx weight 10,000 lbs. --Actual model is NFK 8AJ/1BL

This item is in an Auction on exfactoryauctions.com. Go here to view item: http://exf.ac/i6q NORTHFIELD 12HD 12" Heavy-Duty Jointer Specifications: Max. depth of cut 5/8", Rabbeting cap. 5/8" x 12". 17” x 51-1/2” x 32-1/2” H. Outfeed table size 17” x 43” x 32-1/2” H. Equipped with: 3-1/2” Dia. 3-Knife Cutterhead. 5 HP - 1,735 RPM Motor. 52” L x 5-1/2” H Cast-iron fence, with 0° - 45° Tilt. Swing-away guard.

NORTHFIELD - #4, ...Table SawSpecifications: -- 16" Dia. saw blade cap.; 7.5 HP - 3,450 RPM motor; 1" dia. arbor; 13/16" dado cap. with: Thin collar; blade tilts: 0° - 45°; 32" rip cap. with T-type fence.

Northtech FR-200 Frame SawSpecifications: -- Saw capacity of 6" width x 8" vertical capacity. -- Minimum working 2"; high X 12"; long. -- Main drive motor to saw frame is 30HP 3PH, wired 460 --V servo drive system to feed works is 1/4HP 3PH, --Blower to saw frame rack for added cleaning value is 3HP 3PH, -- Body of frame saw is (2) sections allowing for fast access to the saw frame, -- Saw blade speed is fixed at 550RPM, -- Dust extraction requires min 3000 CFM and is arranged with (4) 5" ports, -- Blade size is standard with 500mm L x 40mm W x 0.9mm body in stellite or TCT tip,Equipped with & Features -- Digital electronic oiling system provides proper lubrication to the saw frame guides -- Vertical rail system which allows optimum cooling and long term durability, -- (4) guide blocks are thermo- censored to allow auto shut-off of machine should possible heat buildup occur.Machine dimensions 122"; L X 40"; WX, 79"; H weight 7100 lbs. Machine was new in 2007.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5z NORTHTECH NT-EV-920RC DUAL HEAD WIDE BELT SANDER 2-Head wide belt sanding machine with 37" capacity. - Heads: 1st head: 8-1/4" Dia. grooved rubber contact roll, with 20 HP motor. 2nd head: Combination finishing platen with grooved rubber roller and polishing pad, with 15 HP motor. Two (2) infeed and outfeed spring loaded hold-down rollers; 2 HP variable speed feed drive. Sanding belt size: 37" X 85" and with electronic belt tracking. Motorized opening between the conveyor and sanding bed. Ammeters for measuring motor loads.

Northtech NT SLR-16SC Precision 16″ Straight Line Rip Saw FEED SYSTEM --Saw motor: 15HP, 3PH 230/460V -- Feed: 1.5HP variable from 40′ – 120′ FPMPRODUCT DIMENSIONS -- Min. thickness: 3/16″ -- Max depth of cut: 4-1/16″ with 16"; Blade -- Max depth of cut: 3-1/16"; with 14"; BladeSpecifications: -- Direct Drive = Direct Drive -- Feed Hp. = 1.5 Hp. -- Feed System = 4"; Split Chain with True Trac -- Feed Speed = 40-120 FPM -- Assisted Start = Wye Delt"; -- Throat Capacity = 18-1/4"; -- Min. Length = 12"; 2nd Roller to Kickback -- Min. Thickness = 3/16″ -- Max. Thickness = 4-1/16"; W/ 16"; BladeGlue Line Rip = Guaranteed 12′ 4/4 stock @ 50 FPMEquipped with & Features -- Blade Size = 14"; Tungsten Carbide Tipped -- Dust Collection = 1417 Total CFM -- Dust Port Out = 4"; Top 6"; Bottom -- Arbor Diameter = 2″ Arbor -- Idle Rollers = (8) Idle Rollers -- Hold Down Style = 8 Spring Loaded Hold Downs -- Kickback Finger = (59) Lower (32) Top -- Automatic Mechanical Oiler -- Low Oil Warning = Low Oil Shut-off -- Laser = 100mw Laser Light & Mount Bracket

NORTHTECH NT-6108ES-6 Edge SanderSpecifications: Sanding Belt is powered by a 3 HP 230/460V motor. -- The platen measures 6-3/4″ X 39″ and has NEW graphite. Rubber covered direct drive pulley. -- Equipped with: (1) 7-3/4" x 37" Adjustable side table and (1) 11-1/2" x 19" Adjustable end table; both side & end tables have vertical table travel w/hand wheel adjustment. Complete with: -- Magnetic controls with overload protection & dust hood with 4" dia. outlet.
