ZAFFARONI MSR 160 P BS/PD MULTI-BLADE PANEL SAW (W/TOP & BOTTOM ARBORS): -- SpecificationsZAFFARONI is the "Top of the Line" in Precision Multi-Rip Saws for Panels. Blade Depth is mechanically adjustable with a tolerance of +/- 0.01 mm (0.0004").The Saw is so precise it can also be used for V-Grooving.The Saw blades project through the table from above & below. A double-row of hold-down wheels are mounted above the saw, with (28) adjustable rollers to prevent contact with the blade.The Top & Bottom shafts & wheels are connected by a quick flange system that can be removed/replaced without dismounting the bearing collars.Motorized adjustment of the depth of the saw blade projection by the touch-screen operating control(4) motorized & self-adjusting (according to material thickness) upper rubber coated rollers with grooves,(4) Idle lower polyethylene coated rollers & (1) Pair of ejector rollers at the output of the machine.Automatic locking and unlocking arbor shaft with HSK collector on the LH side controlled with electro-pneumatic device for the automatic cleaning of the coupling Safety device that features a presence and positioning sensor of the shaft; closed circuit air cooling device for the shaft bearingsSaw Blade work table with interchangeable MDF inserts.Technical Characteristics: -- Working Width is 1,600 mm (63"). -- Max. panel pass through is 1,780 mm (70"), min. length is (450 mm) 17.7". -- Motorized thickness adjustment from 0 - 70 mm (2.7"). -- Adjustable projection of the saw blades from the working from 0 - 62 mm (0" - 2.4") with circular saw blades or hogger trimmer up to 280 mm dia. (11"). -- Working table height is variable, from 970 - 1270 mm (38" - 50"). -- Material Feed Speed from 3 - 45 MPM (9.8 - 147.6 FPM). -- Main Motor Power is 45 kW (60 HP) with toothed Belt Drive arbor. -- Saw Blade arbor 80 mm dia. x 1,310 mm (3-1/8" x 51-1/2"), with double-tangs and automatic anti-rotation locking clutch. -- Blade Arbor Speed of 4,000 RPM.Machine Features: -- Opening of the roller group through pneumatic cylinder with timer interlock for safety. -- Safety protection hood with sound absorbing materials to conform to ISO 7960/95 Norm. -- PLC Logic touch screen control with digital communications through profibus cable.Spacer Sets: Machine requires Spacer Sets and Saw Blades (not included); pricing is available on request.Examples:width from......1 - 10 mm ...$ 25.45width from.....11 - 25 mm ...$ 30.15width from.....26 - 50 mm ...$ 35.60width from.....51 - 75 mm ...$ 40.15width from.....76 - 100 mm ...$ 45.20width from...101 - 125 mm ...$ 49.75width from...126 - 150 mm ...$ 54.90Example of productivity:Approx. 240 panels/hour running the machine at 49 FPM (15MPM) – considering to load 4 panels/minute) & a change-over time of approx. 10 minutes.

ZANGHERI & BOSCHETTI B-35 CONSTRUCTION/LINE BORER(35) Spindles, 4 HP motor, drills vertically from the bottom/ horizontally from the back, 45° bevel drilling feature; (6) pneumatic holddown clamps for vertical & horizontal clamping, includes fences & stops. -- The 56" x 30" table shifts when changing from horizontal to vertical maintaining same boring depth and zero base. Removable table fence for extended length line boring.

ZEETECH - 200, ...Universal Hopper Feeder that can be mounted to all Moulders. - Capacity: 3/4" - 9-1/2" width, 0.38" - 5" max. material height, 10" min. length. -- Oil-free air operated drive unit mounted on THOMPSON hardened ways, damped drive travel, positive sensing sequencing actuator. -- Variable speed range from 0 - 120 FPM @ 80 - 120 PSI. -- Includes: All air logic controls (no power required) and air filters; easy to install.

MODEL ZTLP 1800 X 1600 Zeno Low Noise Single Shaft Shredder/Chipper Specifications: --Model ZTLP 1800 X 1600 -- Feed opening 70’’ (1800mm) wide x approximately 62’’ (1600mm) long. --24’’ Diameter x 70’’ long single rotor with bolt-on blades. --Hydraulic pusher ram feed. --Shredder driven by a 105 kW (140 hp) --3/60/460 volt --1780 rpm motor --No Control Panel --New in 2005

ZUCKERMANN CHALLENGER 1700 37-Z SYNCHRO Copy Lathe. Single spindle hopper feed CNC Copy Lathe for shaping & sanding asymmetrical parts. -- Size Capacity: 67" Maximum 67" (1700mm) and 4" (100mm) minimum working length, 9.8" maximum working diameter. -- Drives/Speeds: The cutter head is belt driven by 5.5 HP motor to run at 6,000 RPM, sanding motor 1.5 HP to drive a 5-7/8" wide sanding belt. Work piece rotation CNC controlled for variable rate from 12 - 130 RPM, via 4 HP motor, carriage speed CNC controlled 7- 67 inches per minute, automatic hopper feed as well as automatic unloading . -- Controls: Machine sequencing, cutting and sanding speeds controlled by SIEMENS "Sinumerik 810 T" CNC controller with programmable memory for rapid set up. --Complete with: Various spare parts & 220 or 440 V operation transformer.

ZUCKERMANN CHALLEGER Copy Lathe w/Sander for asymmetric/irregular shaped parts.Hopper feed, single spindle; approx. 149" (3,800 mm) max. between centers, 8-13/16" (250 mm) max. part dia.; 5 HP cutter head motor at 6,000 RPM, oscillating belt sanding unit, both units work together. -- 'Cup' style Cutter head; 2 HP spindle & pattern rotation motor; mechanical & pneumatic traverse of cutter head and sanding carriage. -- Complete with: Built-in operator push button control panel and overhead dust collector hood.

ZUCKERMANN OPTIMA-S-8/1000 Copy Lathe with integral sanding.For asymmetrical or symmetrical wood turnings ranging from furniture legs (Queen Anne), gunstocks, guitar necks, to tool handles and the like. -- General Specs: 8-Spindle Copy Lathe, 39.3" (1000 mm) max. copying length, max. working dia. 200 mm (7.86"); 5.5 HP motor on each spindle, 6,000 RPM belt-driven spindle with cup cutters. All cutters are copying according to one sample specimen. -- Equipped with: (8) Single head sanders for simultaneously shaping & sanding; (2) 2.8 HP motors power all sanding heads, 6" wide sanding belts. -- Speeds: Stock rotation variable from 15 - 75 RPM, variable feed speed of shaping & sanding cycle from 200 mm/Min - to 1,200 mm/Min (0.75 IPM to 47 IPM), pneumatic clamping of workpiece. Includes: Installed used cup cutter heads. -- Larger working dia. is possible by omitting adjacent workpieces and as the copier allows. -- Actual model is OPTIMA-S-8/1000. -- Machines are connected and can be viewed in operation. --NOTE: Several machines of the same model are available at the same location.

BIESSE - ROVER A 1232: CNC Machining Center (with ATC/Boring)SpecificationsWorking Field "X" axis: 123.6" (3,140 mm); "Y" axis 50" (1,260 mm); "Z" axis stroke 10.8" (275 mm); max. material thickness 9.6" (245 mm). -- Positioning Speed: "X" Axis 262 FPM (80 MPM); "Y" axis (60 MPM); "Z" axis 82 FPM (25 MPM). -- Worktable(8) Adjustable panel supports with: (4) Lifting bars for heavy panels; (3) vacuum pods per panel support.(2) Independent working areas with: (8) Pneumatic back stops; (2) pneumatic side stops; (2) pneumatic central stops. -- Boring Unit"BH 24" Boring unit with: 4 HP (3 kW) Motor with variable speed from 2,800 - 6,000 RPM; (13) independent vertical spindles with: (8) Spindles in "X" axis; (5) spindles in "Y" axis.(10) Horizontal boring spindles with: (3 + 3) In "X" axis; (2 + 2) in "Y" axis.(1) "X" Axis grooving saw for max. 120 mm dia. blade. -- Machining(1) 17.4 HP (13 kW) Liquid-Cooled, electrospindle Router with: HSK F63 Adaptor; variable speed from 3,000 - 24,000 RPM. Prewired for "C" Axis.(25) Total ATC positions with: (1) 13-Position ATC tool plate located at the back of the machine base; (1) 12-position ATC rack mounted on the base of the machine frame. -- Operator InterfacePC Front-End with: BIESSE "BH 660" + "BiesseWORKS" + WINDOWS "7" Operating System; 21" color CRT; full keyboard; mouse; 1.44 MB & CD ROM disk drives.RS 232 & USB ports; Ethernet connection; specific function controls & and Internet troubleshooting capabilities; air conditioning; dustfree environment."BiesseWORKS" is a: Multitask Operating System; input/output modules; axes override; (5) axes interpolation; diagnostic graphics aid for programming; machine data; tool management. -- Complete with:(1) 300 cbm/Hr Vacuum Pump: Handheld remote control pendant; safety Bump Stop system; scrap conveyor; original documentation; user & maintenance manuals, wiring diagrams, and operation of Numerical Control. Automatic chips removal conveyor. -- Actual Model is: BIESSE "ROVER A 1232"

BIESSE ROVER A 1432 ATS CNC MACHINING CENTER (W/ATC/BORING): Specifications: -- Working Capacity:"X axis 125.9" (3,200 mm), "Y" axis 52" (1,320 mm), "Z" axis stroke 13.7" (350 mm), max material thickness 9.6" (245 mm). -- Positioning speed:"X" 262 FPM (80 MPM), "Y" Axis 196 FPM (60 MPM), "Z" axis 98 FPM (30 MPM);AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. -- Work Table:(6) Tube-less panel supports with (4) lifting bars for heavy panels & (3) ATS vacuum pods per panel support;(6) Pneumatic back stops, (6) pneumatic front stops, (2) pneumatic side stops & (2) pneumatic central stops. -- Boring Unit:4 HP (3 kW) motor with variable speed from 1,500 - 7,500 RPM; (20) "Quick Change" independent vertical spindles with (10) spindles in "X" axis & (10) spindles in "Y" axis;(8) horizontal boring spindles with (2+2) in "X" axis & (2+2) in "Y" axis;(1) "X" Axis grooving saw for max 120 mm dia saw blade. (1) "Y" Axis grooving saw for max 120 mm dia saw blade. -- Machining:(1) 17 HP (13 kW) Liquid Cooled "HSD" electro-spindle router with HSK F63 adaptor, variable speed from 1,500 - 24,000 RPM;(1) 8-Position ATC tool plate located on the machine head for "on the fly" ATC. -- Operator & Machine Control:PC Front End: Biesse "BH 600" + bSOLID + WINDOWS "7" operating system,15" TFT monitor, full standard keyboard & mouse, CD ROM disk drives,RS 232 & USB ports, Ethernet connection, specific function controls & and internet trouble shooting capabilities;Control cabinet with air conditioning & dust free environment."bSOLID" is a multitask operating system, input/output modules, axes override, 4-axes interpolation, diagnostic graphics aid for programming, machine data & tool management. -- Complete with:(1) 100 m³/Hr vacuum pump; automatic lubrication system; original documentation; hand held pendant; safety fences & mats; scrap conveyor; CE mark. -- Actual Model is BIESSE ROVER A 1432 ATS

--This machine is in an Auction on exfactoryauctions.com--NO RESERVE-- (2 Available) BIESSE SKIPPER 100 2-Head CNC Machining Center, with Infeed & Outfeed Tables – Seller states that machine was run (2) shifts from 2005 - 2021, then only a few hours per day since! Specifications: Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system. Working Capacity: "X" Axis 3,000 mm (118.11"), "Y" Axis 1,000 mm (39.37"), Max. part thickness 60 mm (2.36"). Min. workable part size: "X" Axis 90 mm (3.54"), "Y" Axis 70 mm (2.76"), & "Z" Axis 8 mm (0.31"). Work Table: Left-hand infeed & Right-hand outfeed, Each with 20-1/2” x 66” x 35-1/2” H infeed & outfeed areas with Fixed caster-type conveyor rails. Positioning Speed: "X" Axis 120 MPM (393 FPM), "Y" Axis 90 MPM (295 FPM), "Z" Axis 30 MPM (98 FPM). Boring Units: (1) Top & (1) Bottom boring blocks, Each with: 3 kW (4 HP) Motor, Boring spindle speed 4,000 RPM, (29) Vertical spindles with (17) "X" Axis & (12) "Y" Axis, (10) Horizontal spindles with (4 + 4) "X" Axis & (1 + 1) "Y" Axis, & (1) "X" Axis Grooving saw with 3 kW (4 HP) Motor, Blade speed 5,000 RPM, & Blade diameter 150 mm (5.91"). Machining: (1) Top & (1) Bottom 3.5 kW (4-3/4 HP) Electrospindles, Each with: Variable spindle speeds 7,000 - 18,000 RPM, Right-hand/Left-hand rotation, HSK D-50 Adapters for Manual push-button quick tool change, ERC-32 Toolholders & RC-32 Collets. Operator & Machine Control: Mobile Control Console, with PC-Based Control, 18" LCD Monitor, BIESSE "WORKS" + "WINDOWS" Operating system. Pedestal & Pendant controls. Equipped with: Universal transformer, 200 - 600 V, 50/60 Cy, 3-Ph., Automatic lubrication system for guides & ways, Sound hood, 79" H Safety fence with Lock-out door, & TAPESWITCH "CONTROLMAT CKP" 24" x 72" Heavy-duty ribbed pressure-sensitive safety mat. Complete with: 7’ x 9’ x 35-1/2” H Infeed Table, with Rails & Pusher. 6-1/2’ x 8’ x 35-1/2” H Outfeed Table, with Transfer Belts. Handheld Bar Code Reader. Dust Manifold. Dimensions including Safety Fence: 307" x 184" x 98" H.

BIESSE ROVER 20 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working field: "X" Axis 113.9" (2,893 mm); "Y" axis 37.4" (950 mm); "Z" axis stroke is 3.9" (100 mm), max. panel thickness 2-1/2" (65 mm). -- Positioning Speed:"X" Axis at 246 FPM (75 MPM); "Y" axis 147 FPM (45 MPM); "Z" axis 49 FPM (15 MPM)."X" Axis moves on high precision prismatic guides and ground helical rack; "Y" & "Z" axis via hardened ground ball screw. -- Worktable:(6) Pneumatically locked & manually positioned panel supports with (2) vacuum cups each.(2) Working zones with: (6) Pneumatic backstops; (2) pneumatic side & (2) center stops; stops raised & lowered automatically by start/stop of machining cycle. -- Boring Unit:(1) 2.3 HP - 5,135 RPM Motor; (10) vertical spindles independently operated with (6) in "X" axis & (4) in "Y" axis.(6) Horizontal spindles: (2 +2) in "X" Axis & (1 + 1) in "Y" axis; 2-1/2" (65 mm) max. boring depth.(1) "X" Axis grooving saw with: 120 mm Dia. blade - 5,200 RPM. -- Machining: Equipped with: (1) 9 HP (6.6 kW) Air-cooled "Quick Change" electro spindle with ISO 30 adaptor.Router is driven by: 10.2 HP (7.5 kW) Inverter for variable speed from 1,000 - 24,000 RPM; RH & LH rotation.(1) 3-Position automatic tool changer mounted at the back of the machine for "on the fly" ATC. -- Operator & Machine Control: Separate Control Console with: CNi "NC 410" Operating System housed in air-conditioned cabinet.8" LCD Monitor: Displays programming graphics, numerical & function keyboard; 512 KB RAM memory; (1) "UPGRADED" USB drive.RS-422 Serial port for PC and RS-425 port for inverter connection; EPROM for machine data & subroutines; machine runs production programs while programming and editing. -- Complete with:Stabilized autotransformer for voltages between 200 - 600 Volt 50/60 Hz; (1) 100 cbm/Hr Vacuum Pump; triple photocell barrier; assortment of misc. parts and tooling; Users operator/maintenance manuals & backup disks. -- Actual Model is: BIESSE - ROVER 20.

BIESSE ROVER K 1532 CNC MACHINING CENTER (W/ATC & "C" AXIS): -- Specifications:"BRIDGE GANTRY" machine with a working field in "X" axis 126" (3,200 mm), "Y" axis 61" (1,560 mm), max. material thickness 6" (165 mm). -- Positioning speed:"X" Axis 279 FPM (85 MPM), "Y" Axis 196 FPM (60 MPM), "Z" axis 65 FPM (20 MPM). -- Work Table:(8) "ATS" Panels supports with lifting rails for heavy pieces; (4) "ATS" vacuum pods with universal clamping systems on each panel support.BIESSE "Set Up Assist" & digital readouts for pod & rail placement.(2) Independent working areas with (8) pneumatic back stops, (2) pneumatic side stops & (2) pneumatic central stops. -- Boring Unit:4 HP (3 kW) motor with variable speed from 1,500 - 7,500 RPM;"BL 30" Boring head with (20) "Quick Change" independent vertical spindles, (9) spindles in "X" axis & (11) spindles in "Y" axis;(8) Horizontal boring spindles with (2+2) in "X" axis & (2+2) in "Y" axis;(1) "X" axis grooving saw with 120 mm dia. blade. -- Machining:(1) 17 HP (12.6 kW) electro-spindle router with HSK F63 adaptor, variable speed from 3,000 - 24,000 RPM.Motorized dust deflector shield & 6-position adjustable dust suction hood,(1) NC controlled "C" axis for 360° horizontal processing.(1) 16-position ATC tool plate mounted on board the "X" axis at the rear of the machine. -- Operator & Machine Control:PC Front End with Biesse "BH 660" + Biesse "bSolid" + Windows "7 WRT" operating system,15" Flat screen monitor, full standard keyboard & mouse, 1.44MB & CD ROM disk drives for data entry,RS 232 & USB ports, Ethernet connection, specific function controls & internet trouble shooting capabilities.Electronics are mounted in an air conditioning & dust free environment control cabinet. -- Biesse "bSolid" is a 2D/3D Cad/Cam software program that supports the performance of any machining operation thanks to vertical modules designed for specific manufacturing processes.Planning with "bSolid" takes just a few clicks & has endless possibilities; "Real-Time" simulation allows the operator to visualize the piece prior to processing, it provides virtual prototyping of the piece to avoid collisions & ensures optimal machine performance. -- Complete with:(1) 250 m³/Hr Vacuum pump; Hand-held "Remote Control" pendant for immediate operator control; LED bar with (5) colors that show the machine's status in "Real-Time".Safety fences, safety bumpers, safety photocells & safety mats; scrap conveyor; original documentation + user & maintenance manuals, wiring diagrams and operation of Numerical Control. -- Actual Model is BIESSE ROVER K 1532 G VS2

BIESSE SKIPPER 100 L CNC MACHINING CENTER (2-HEAD): -- Specifications:Flexible "Top & Bottom" Machining Center that uses an innovative panel handling system. -- Workable part size:"X" axis is 118" (3,000 mm), "Y" axis is 39.4" (1,000 mm), max. part thickness of 2.4" (60 mm).Min. workable part size in "X" axis is 3.5" (90 mm), "Y" axis is 2.7" (70 mm), "Z" axis is .3" (8 mm). -- Worktable:Automatic LH infeed transfer conveyor with belts & rollers, Automatic RH outfeed transfer conveyor with belts & rollers; infeed/outfeed table is "robot ready". -- Positioning Speed:"X" Axis is 394 FPM (120 MPM), "Y" axis 295 FPM (MPM), "Z" axis is 98 FPM (30 MPM). -- Boring units: (1) Top mounted boring block, 4.2 HP (3 kW), 4,000 RPM; (29) vertical spindles, (17) spindles in "X" axis & (12) spindles in "Y" axis; -- (10) Horizontal spindles, (4+4) spindles in "X" axis & (1+1) horizontal spindles in "Y" axis; -- (1) "X" axis grooving saw with 2.2 HP (1.7 kW) motor - 5,000 RPM, 150 mm dia blade. -- (1) Bottom mounted boring block, 4.2 HP (3 kW), 4,000 RPM, (29) vertical spindles, (17) spindles in "X" axis & (12) spindles in "Y" axis; -- (10) Horizontal spindles, (4+4) spindles in "X" axis & (1+1) horizontal spindles in "Y" axis; -- (1) "X" axis grooving saw with 2.2 HP (1.7 kW) motor - 5,000 RPM, 150 mm dia blade. -- Machining:(1) Top mounted 4.8 HP (3.5 kW) electro spindle, 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick-tool" change, ERC-32 tool holders & RC-32 collets. -- (1) Bottom mounted 4.8 HP (3.5 kW) electro spindle, 7,000 - 18,000 RPM with RH/LH rotation; HSK D-50 adaptors for manual push button "quick-tool" change, ERC-32 tool holders & RC-32 collets. -- Operator Interface: PC Front-End with BIESSE "NC 1000" + Windows "Biesse Work" Operating System; 15" color monitor; international keyboard with soft-touch keypad & industrial mouse.RS-232 serial ports for possible down-loading from an office PC, USB ports; (1) 48x CD ROM drive; all mounted in a separate control console with a built-in 1,500 W air conditioner for constant temperature & dust-free environment. -- Complete with:Universal transformer for voltages from 200 - 600 volts, 50/60 Hz, 3-Phase; automatic lubrication system for guides & ways; sound enclosure and complete set of safety fences/devices; machine docs & manuals. -- Options include:"BiesseWORKS Advanced" Office version with: (2) Hardware keys; pneumatic part clamping with motorized infeed & outfeed transfer conveyors; Software Disclaimer: EX-FACTORY INC. Offers NO warranty or support, written or implied concerning any/all "optional" or "additional" manufacturer or 3rd party software supplied with this machine. All software related issues including relicensing fees/requirements/functionality & training is ultimately the sole responsibility of the "Buyer".Note : Tear down and loading not included

BIESSE ROXYL 5.5 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + "AIR FORCE" PUR/EVA GLUING TECHNOLOGY: -- Features: Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material. "AirForce" emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers. This technology allows changes based on banding colors without any setup. Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important now that "AirForce" can use PVC. -- In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Specifications: -- Edgebanding Capacity: Edge thickness for strips min./max. 0.4 - 22 mm (0.02" - 0.87"), coiled material from 0.4 - 3 mm (0.02 - 0.12"); panel thickness from 10 - 60 mm (0.39 - 2.36"), workpiece width min. of 85 mm (3.34"); workpiece length min. 140 mm (5.51"); feed speeds 10 - 14 - 18 - 20 MPM (33 - 46 - 59 - 65 FPM). -- Machine Controls: "Roxyl-Matic" Automated machine setup, MS/Windows XP Operating System, floppy drive, and 4 GB HD; USB port, keyboard, and mouse interface. -- Flat Screen (17") with color graphics interface: Programs can be easily created and recalled at will; Graphic interface makes programming easy, icon of each unit may be brought up on the screen to show the operator the status of the unit and the parameters, which can be programmed; Edgebander may be operated manually when required, without necessity to write a program.Machine In-Feed Configuration: -- Pre-Milling Station "FL-502": (2) LH & RH Rotating NC controlled spindles with automatic center positioning. -- Anti-Adhesive "ADZ-700" Automatic Spray Unit with: Glue release agent preventing glue to adhere to work piece's surfaces. -- Infrared Heating Lamp: Preheating workpiece edge to ensure best possible surface adhesion quality of edgebanding material. -- Edge Magazine: Automatic for processing coiled and strip edgebanding material. -- Pressure Section: Servo controlled programmable pressure section with (1) large driven roller and (4) idle rollers.Gluing System: -- EVA (Hot Melt) "QM-705": Quick premelting granulate with glue roller applicator to cover conventional edgebanding material. -- AirForce "VC-710": High pressure, hot air system to reactivate special pre-coated edge-material (commonly referred to as laser edge).Workstations: -- End Trimming Unit "IN-801": Front & rear trimming motors, uni-point swivel 0° - 15° bevel, programmable pneumatic change-over from flush to bevel. -- Rough/Flush Trimming Unit "RS-701": Top/Bottom pre- or flush trimming motors -- Flush/Bevel/Radius Combination Trimming Unit "RF-400": Servo controlled, (2) Servo motors (one for horizontal tool position, one for tool up/down position); using combination bevel/radius/flush insert knives; pre-posit

BIESSE AKRON 1440A SINGLE SIDE EDGEBANDER (W/PRE-MILL & CORNER ROUNDING) + with "AIR FORCE" PUR & EVA TECHNOLOGY: -- Specifications: Latest Technology combines productivity, efficiency, and flexibility for all types of edgebanding material."AirForce" emits high temperature compressed air through a slot nozzle directly onto the reactive layer of laser banding. That layer is activated and bonds the banding to the panel fibers. This technology allows changes based on banding colors without any setup.Environmentally friendly providing a “clean - green"; technology that eliminates glue and fumes, which becomes timely & important. In addition, it features a conventional EVA (Hot Melt) Gluing System to cover the full range of edgebanding processes in use today!Working Capacity: -- Min. panel height: 10 mm; Max. panel height: 60 mm; Height of edgebanding material: 14 - 64 mm; Thickness of edgebanding material in rolls: 0.4 - 3 mm; Thickness of edgebanding in strips: 0.4 - 10 mm.Min. panel protrusion from the track: 25 mm; Panel length: 140 - 3200 mm; Min. panel width (with length 140 mm): 85 mm; Min. panel width (with length 250 mm): 50 mm.Multi-Feed speed 8-12-15 &18 MPM.Glue & Pressure Section: -- Infrared lamp IRL 700; Gluing unit Quickmelt QM 703 EVA melting glue. Special glue container for PU glue; Additional glue container for EVA gluing unit with melting device.Additionally equipped with the AirForce "VC-710", High pressure, hot air system to reactivate special pre-coated edge material (commonly referred to as laser edge.Automatic edge feed; Cutter knife; Pressure zone with 1-Drive & 2 pressure rollers.Working Units: -- Pre-milling unit with 2 x 0,8 kW, 12000 RPM motors, front/rear inclination 0° -15°. -- RT 02; Gluing, edge feeding, and pressing unit VC-511. -- End trimming unit with 2 x 0,8 kW, 12000 RPM, front/rear, inclination 0° -15°. -- Fine trimming unit 2 × 0,6 kW, 12000 RPM top/bottom. -- (2) Multifunction Corner Rounding unit, 0,65 kW each, for Corner Rounding, Straight Work pieces, Post and Soft-Forming 90° -180° degrees. -- Edge scraper unit; -- Glue scraper unit; -- Buffing unit 2 × 0,37 kW motors. Machine Features: -- Belt pressure beam. The top presser comprises a rubber belt with a stain-proof coating. The thrust exercised on the panel is provided by springs housed on techno polymer connecting rods. -- Auto adjustment of in feed fence. -- Automatic track lubrication system with dynamic track absorption. -- Manual infeed system for narrow pieces. -- One coil automatic edge feeding. -- Hybrid gluing head for granulated EVA and Polyurethane glue. -- Pre-Melter TM10 for Polyurethane glue in cartridges. On-demand top-loading pre-melter for PUR glues. -- Adaptive infra-red lamp to heat up the panel side before the glue application, in order to optimize the adhesion process. -- Independent pneumatic exclusion of the top/bottom fine trimming unit. Operator & Machine Control: -- Biesse, Windows-based

BIESSE AKRON 245 Edgebander with Corner Rounding: Left-hand material infeed for strips & coiled edge material like PVC, ABS, veneer, and solid wood.Specifications: -- 0.4 - 8 mm (5/16") Cap. Edgebanding thickness, min. panel width 85 mm & min. length 140 mm, panel thickness 10 - 50 mm.Equipped with: -- Adjustable top pressure beam positioning. -- Automatic strip & coil feed magazine with robust shear type 3 mm PVC guillotine. -- Hot-Melt glue system (12 min. heat up time) with Teflon coated gluepot, digital thermostats with automatic kick-down when machine is in idle mode; 1" dia. glue applicator roller. -- Pressure section with (1) large dia. "non-stick" coated drive roller & (2) chrome plated idle rollers with pneumatic positioning.Workstations: -- Front & Rear End Trims (0.33 HP - 12,000 RPM motors), motors travel on (2) straight slides and pneumatic tilt 0° - 25° on horizontal plane. -- Top & Bottom Flush Trims with "Quick Change" motors (1.0 HP - 12,000 RPM motors), digital readouts for easy setup. -- 2-Motor (0.3 HP - 12,000 RPM motors) Corner rounding unit for trimming leading & trailing upper & lower edge/corners with "Fast Position" and can be used as a second Top & Bottom fine trimmer as well. -- Top & bottom Scrapers for 3 mm thick PVC banding, digitals for horizontal adjustments. -- Top & bottom Buffing (0.5 HP - 2,800 RPM motors), units tilt 0° - 30°. -- Top & bottom (2,000 Watt) Hot Air Blowers with temperature adjustment. -- Feed Speed 39 FPM, 3 HP feed drive.Complete with: -- Microprocessor for workstations & feed speed. -- Insulated sound enclosure over all trim stations with triple split dust hood, industrial lights and viewing windows. -- Extendable side panel support rail, 12 KVA - 240 Hz digital frequency inverters. - Includes: Used tooling on all workstations.

Biesse Levia 110 43" (2) head wide belt sanderWidth cap 43" , Drum , Combination HeadHead configurations1st Head: 5" diameter steel contact roll2nd Head 5" diameter rubber drum 45 shore with 2 1/2" wide platenSpecification -- Width cap 43" -- 1st Head: Steel contact roll, 30 HP motor. -- 2nd Head: Combination head with a rubber covered contact roll and finishing platen 24 HP motor. -- 43" x 85" abrasive belts, electronic abrasive belt tracking, abrasive belt grit compensation on both heads with 4-position turret stop. -- Conveyor belt feed, 10 - 40 FPM variable feed speed with inverter control from control panel, 1.5 HP feed drive,Equipped with & Features -- Automatic conveyor belt tracking, -- 0" - 7-7/8" motorized thickness adjustment with LED readout. -- Automatic part thickness adjustment, -- Infeed and outfeed rubber covered holddown rolls. infeed panel -- Over-thickness" sensor, -- Electronic brakes on both sanding head motors. -- Infeed emergency stop, -- 3-Roll infeed extension -- Twin motor load meter.

BIESSE AKRON 1330 EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): -- Specifications: Computer controlled interface for workstations with servos and pneumatic positioning devices. Programmable selections for 1-touch changeover between edgebanding types and thicknesses.Top Pressure Beam with automatic adjustment from the machine control. -- Working Capacity: Edgebanding thickness, 0.4 - 5 mm capacity. Min. panel width 85 mm (3.3"); min. panel length 140 mm (5.5"); panel thickness 10 - 50 mm (0.39" - 1.96").3 HP (2.2 kW) Variable Feed Speed from 10 - 20 MPM (32 - 65 FPM).Front-End Equipped With: -- Pre-milling Unit with "Auto-set" automatic intervention, Strip & Coil Edge magazine, automatic shear type guillotine. -- Hot-Melt Glue System: Teflon coated glue pot, digital thermostats with automatic kick-down when machine is in idle mode.Pressure Section with (1) large dia. "non-stick" coated drive roller & (5) Teflon plated idle rollers with servo positioning NC controlled material thickness adjustment.Workstations: -- End Trimming Unit:NC controlled end trimming unit, 0.33 HP (0.24 kW) - 12,000 RPM motors.Motors travel on (2) straight slides and pneumatic tilt 0° - 15° on horizontal. plane -- Top & Bottom Multi- Function Flush/Bevel/Radius Trimming Unit: NC Controlled 2-motor Top & Bottom Multi- Function Flush/Bevel/Radius Trimming Unit, 0.3 HP (0.24 kW) - 12,000 RPM.Servo driven positioning of motors for different edge trimming profiles & positions. -- Corner Rounding Unit:2-motor 0.3 HP (0.24 kW) - 12,000 RPM motors for trimming leading & trailing upper & lower edge/corners with "Fast Position",Unit can be used as a second top & bottom fine trimmer as well. -- Profile Scraping Unit:Top & bottom 2 mm or 3 mm thick PVC banding, digitals for horiz. adjustments. -- Flat Scraping Unit:Top & bottom glue scraping unit. -- Buffing Unit: Top & bottom Buffing Unit, 0.5 HP (0.37 kW) - 2,800 RPM motors), units tilt 0° - 30°Operator & Machine Control: -- Biesse SMART TOUCH 7" + Windows operating system, user friendly touchscreen control panel for workstations, rotating operator control panel w/keypad and LCD readout.Graphic 7" display touch screen. High-resolution screen for defined and intuitive images and text. Integrated 4GB hard disk for filing media files and the programs back up.USB port for managing in a simple and efficient way multimedia files, programs and updates. Ethernet port for connecting the machine to the net.Complete With: -- Insulated sound enclosure over all trim stations with split dust hood, viewing windows. -- Actual Model is BIESSE AKRON 1330 A

BIESSE ROVER B EDGE 1667 CNC MACHINING CENTER (W/EDGEBANDING) -- Specifications:This "Bridge Gantry" machine is "IDEAL" for window, stair, door & component parts manufacturing. -- Working Field considering "all" units when Routing, "X" Axis is 265" (6,735 mm), "Y" axis is 75.9" (1,930 mm), "Z" axis stroke 13.6" (345 mm), max. material thickness when machining 9.6" (245 mm)When "Edge Banding" "X" Axis is 227" (5,780 mm), "Y" axis is 75.9" (1,930 mm), the max. banding material thickness is 2.55" (65 mm); the minimum internal radius is 30 mm & minimum external radius is 8 mm (depending on flexibility of the banding material). -- Positioning Speed: "X" & "Y" axis is 279 FPM (85 MPM), "Z" axis is 98 FPM (30 MPM); AC Brushless Servo motors with digital drive and linear guides ensure high speeds with a smooth acceleration-and-deceleration. -- Worktable: (10) "EPS" (Electronic Positioning System) Vacuum bar support rails with pneumatic lifting blades, (4) "ATS" (auto Table Setting) vacuum pods per rail; set up assistance according to the program to process.(10) Pneumatic pop-up back stops, (10) pneumatic pop-up front stops, (4) pop-up side stops, (4) pop-up/removable central stops create (2) independent work zones.Edge Banding unit:The edgebanding unit GU60C with glue pot automatically applied EVA glue to square or irregularly shaped parts as the CNC head rotates along the "X" "Y" & "Z" axis and simultaneously rotates the tooling up to 360° on a high precision "C" axis.Floating "hot melt" glue pot & application roller with separate thermostats apply glue on the panel edge.Pneumatically controlled pressure roller with manually adjustable guides for coil & strip feeding; numerically controlled with encoder that measures strip feeding process.(1) 4-Coil tape magazine with warning sensor when the end of the spool is near; edge banding unit precisely applies 0.4 - 3 mm ABS & PVC with 60 mm (2.3") max. edge height.Pneumatically activated saw blade performs the end trimming at a 35° angle for precise fitting of overlapping joints on adjoining edges. -- Boring Unit: BH17 Boring Head with 4 HP (3 kW) motor, variable speed from 1,500 - 6,000 RPM; (10) Independent "Quick Change" vertical spindles with (5) spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal boring spindles with (2+2) in "X" axis & (1+1) in "Y" axis; (1) "X" axis grooving for up to 120 mm dia blade. -- Machining: (2) 18 HP (13.2 kW) Air cooled electro-spindle router with HSK F63 adaptor; 1,000 - 24,000 RPM. (1) NC controlled "C" axis for 360° horizontal processing.(21) Total ATC slots, with(1) 6-position ATC Tool Plate mounted on the "Y" carriage at the back of the machine & (1) 16-position ATC Changer on the "X" carriage. -- Operator Interface: PC Front End with Biesse "BH 660" +"bTouch" +"bSolid" + "bEdge" + Windows "WRT" (Windows Real Time) operating system.21" LCD monitor, CPU Intel(R) Core I5 or superior, 8 GB RAM memory, 128 SSD GB hard disk or superior. graphic card, LCD dis

BIESSE/ARTECH - SEKTOR 470 (SELCO SK4): Front Load, Automatic Panel Saw -- SpecificationsWorking capacity: 149.6" (3,800 mm) Max. rip cut cap. & 149.6" (3,800 mm) max. pusher stroke; 3.54" (90 mm) max. saw blade projection; 15 HP (11 kW) main & 3.6 HP (2.6 kW) scoring motor. -- Saw CarriageFeed speed from: 3 - 394 FPM (1 - 120 MPM); return speed: 394 FPM (120 MPM); automatic cutting length limiter adjusts the cutting length at the end of the workpiece; automatic saw carriage lubrication. -- Pusher Fence 196 FPM (60 MPM) Forward positioning speed; 196 FPM (60 MPM) return speed; rack & pinion movement on both sides to assure the pusher remains parallel. (7) Material gripper clamps open to 3.34" (85 mm). -- Operator InterfacePC Front-End controller: 19" Monitor display with real-time graphics: Virtually unlimited program storage via disk drives; function control keypad; USB & RS-232 serial port; keyboard, mouse & CD ROM drive.Diagnostic for errors or machine malfunction by means of an error signal code; incremental or absolute programming in mm or inches."Quick Opti" Software for optimization of cutting patterns directly on machine; all enclosed in an air-conditioned control cabinet. -- Complete with:Automatic side aligner device: 0 to 114" Stroke; automatic saw blade height adjustment; "PROLOCK" quick-change blade system; (3) air support tables: 78" x 24" (1,981 x 609 mm). -- Actual Model: BIESSE/ARTECH - SEKTOR 450 (SELCO SK4)
