CAM-WOOD TRS 150F Frame SawCAM-WOOD Frame Saws are engineered and designed to make extremely accurate cuts, cutting products with very tight tolerances up to 0.004" and often eliminating sanding before proceeding to the next step . The unique thin frame saw design accepts different saw frames, blade combinations, and allows multiple saw fence configurations to produce single, double or multiple cuts in a single pass.Specifications: -- 3/4" Min. to 6" max. working width; 1-1/4" min. to 7-3/4" max. working thickness (height); 7-1/2" minimum length; finished material > 0.1094". -- 0.043" to 0.055" Saw blade thickness; runs up to (22) blades at one time at (450) stroke/minute with a 8-1/4" stroke length; accommodates blades 1.575" wide x 19.685" long. -- Saw blade frame is powered by a 15 HP motor. Feed speeds of 1 to 5 FPM by 1 HP motor. -- Features automatic oil lubrication system requiring 90 PSI air pressure. Cooling system via water and air. -- Minimum kerf multi-blade frame saw designed to maximize production and minimize material losses to kerf. -- Machine supplied with PLC controller to allow operator fast, instant set-up changes. -- All controls are centrally located for the operator to easily adjust & control operation. -- Material waste reductions of up to 20% are achievable by use of the thin kerf blades (0.043" ~ 0.055"). -- A special air blast system cools the blade for longer service intervals and removes saw dust from the gullet of the blade to reduce temperature and increase blade life.Note: Frames are available in different configurations.

CAM-WOOD - XL 300, ...Dip Chain Gang Rip Saw: (...Typically in stock for immediate delivery!)12" Width cap.; 3/8" min. to 4-3/4"; max. cutting depth; 14"; min. stock length.Specifications: -- 70 mm Dia. saw sleeve (one is included) with (2) keyways and the following spacers: (4) 15 mm, (4) 10 mm, (18) 1 mm, (10) 0.5 mm, and (8) 0.25 mm (see drawing after the "literature link); with 12"; usable cutting width. -- Accepts saw blades from 12"; - 14"; dia.; arbor is powered by a 50 HP motor driving the spindle at 3,200 RPM. -- Feed chain is powered by a 2 HP motor with variable chain speeds from 30 - 100 FPM; feed chain is 12"; wide. -- Table: 30"; Wide x 62"; with 12"; between the column and the 1st saw blade. - Integrated 6"; dia. dust extraction connection.General Description: -- Designed for high quality Production Line use. CAM-WOOD’s Rip Saws are manufactured to precise tolerances and feature the newest designs for operator safety and volume production. -- Precision fence ensures absolute accuracy between blade & fence; equipped with: Measuring ruler gauge. -- Triple anti-kickback fingers mounted at the infeed side provide max. safety protection; (2) rows from the top and (1) row from the bottom. -- Heavy-Duty industrial motor for powerful cutting capacity. -- Ruggedly constructed cast iron frames for durability usage.Feed System: -- Variable feed speed enables the machines to meet different requirement of work. -- V-way track and chain block surface are heat-treated for long wear resistance. -- Automatic lubrication to V-Way track facilitates chain running smoothly. -- Auto lubrication device is equipped with an alarm that sends signals upon a lack of lubrication oil to increase the durability of the machines. Features & Equipped with: -- Precision-built saw head ensures accuracy for straight line rip saw operations. -- (4) Bearing spindle assembly ensures rigidity & long life. -- Power raise & lower to the arbor. -- (4) Pressure rollers & (2) hold-down plates for precise cutting of large and small workpieces. -- 10-Piece V-Belt for max. motor power output and guarantees Heavy-Duty multiple rip cutting. -- The saw arbor is manufactured from NI-Cr-MO alloy steel for durability and anti-fatigue, heat treated, precision ground, and balanced, providing precise cutting performance. -- Adjustable guide rollers make cutting straight or slight radial rip cuts. They also firmly secure lumber to the feed chain for glue joint work on short parts or longer length boards. Options when ordering with machine: -- (1) Set spare feed chain link, please add ...$ 96. -- (1) Set of arbor drive belts consisting of (6) matched belts, add ...$680. -- Additional saw sleeve with spacer set consisting of: (2) 50 mm, (3) 25 mm, (4) 10 mm, (18) 1 MM, (10) 0.5 mm, (8) 0.25 mm, Please add... $745

CAM-WOOD TRS-405-SS Short Stock Rip Saw ...with the following specifications and features:Specifications: -- Max cutting width: 12.6"; -- Min length part: 3.15"; -- Short stock ratio of thickness to length: 2:5 -- Distance from center of chain to throat, 30"; -- Saw arbor powered by 50 HP Std. - 30 HP, 60 HP and 75 HP optional -- Spindle speed, 3,200 RPM -- Sawblade diameter to thickness: 10"; dia = 2"; thick, 12"; dia = 3"; thick, 14"; dia = 4"; thick, 16"; dia = 5"; thick -- Sleeve diameter (sawblade bore), 70 mm -- Sawblade keyway, 2 each 20 mm wide -- Spacer size, 70 mm ID x 95 mm OD -- 2 HP feed motor, 3 HP optional -- Variable feed speeds from 20 to 80 FPM -- Head elevation powered by ¼ HP motor -- With (2) 6"; dia. dust outlets -- NET weight, 5,500 Lbs. Features and Benefits: -- Exclusive feed track - Design for short stock feed – see literature! -- Exclusive length capacity on a standard Gang Ripsaw, as short as 3";! -- Turn waste blocks into useable parts -- Pressure rolls supported from both sides hold stock securely for even, smooth ripping -- Pressure plate (hold-down shoe) supported from both sides; helps prevent split parts from damaging sawblades -- Power raise and lower for overhead pressure roll and hold-down assembly -- Variable feed speeds allow ripping a variety of material, hard or soft, thick or thin -- 2-Top and 1-bottom rows of kickback fingers plus side splitter guards provide operator safetyNOTE: ...Where have you seen a Gang Ripsaw capable of ripping as short as 3"!!! ...Also perfect for slats!

CAM-WOOD TRS-190-2VS 7.5"; x 6"; VERTICAL SPINDLE MOULDER FOR SMOOTH SLAT RIPPINGIncludes one setup including Splitter Set, Holddown Plate, Fence, Sawblades, and Spacers WORKING CAPACITY -- Working width: 3"; to 7-1/2"; -- Working height: 3/4"; to 6"; RIGHT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. LEFT VERTICAL SPINDLE -- With 25 HP motor: -- Spindle diameter: 1.968"; with keyway and blade cooling device -- Spindle speed: 3,500 RPM -- Cutting circle: 9"; to 12"; -- Axial adjustment range: 2"; -- Table adjustable to cutting circle. -- Blade cooling device. SPINDLE COMPONENTS AND ASSEMBLY -- Precision spindles are manufactured from SCM-4 tool steel imported from MITSUBISHI Japan, heat treated to HR 46° (ROCKWELL C Scale) fitted with class 6 -- SKF-matched ball bearings then mated to precision machined spindle housings. -- The spindle body and bearing housing are burnished. -- Spindle hardness and accuracy, high precision SKF bearings, and precise spindle housing and bearing installation by SHEN KO provides a spindle assembly -- Capable of speeds to 9,000 RPM and will meet every user’s requirement. -- Spindles are powered by V-shaped belts (MITSUBISHI) without slippage. FEED SYSTEM -- Powered with a 5 HP motor -- Feed speed is infinitely variable by inverter drive from 20 to 120 FPM -- Infeed rolls consist of (3) top and (2) bottom-powered feed rolls. -- Outfeed with (1) set of top and bottom-powered feed rolls -- Pneumatic pressure to all (4) top feed rolls -- Top rolls with independent pressure adjustment -- All top and bottom feed are driven by a universal joint drive -- Feed rolls are 5-1/2"; diameter TABLE AND FENCE -- 4’ infeed table with (1) driven roller above the tablet -- Table is harden and chromed. -- Fence is harden PRESSURE ELEMENTS -- A pneumatic pressure plate assures stability during slicing -- Precision splitting wedge guide for saw kerf SETUP FEATURES -- Mechanical digital read-outs -- Mobile jog box for ease of setting up -- Central lubrication system for spindles -- Oil pump to remove the resin from table -- Each table has (2) holes for lubrication ELECTRICAL -- Operating voltage 230.460/575/600-volt, 60-cycle, 3-phase -- All “name brand"; electric components. -- Operating panel separate from motor control cabinet for ease of operation MISCELLANEOUS -- Machine cover/hood with a lamp for ease of set up -- Includes a toolbox and operator’s manual

CAM-WOOD TRS-340 M2 Gang Rip Saw With (2) Moveable Blades:Capacity: -- Depth of cut with 14"; dia. blades: 4"; at movable blades, 4.3"; at fixed blades -- Depth of cut with 12"; dia. blades: 2.95"; at movable blades, 3.34"; at fixed blades -- Depth of cut with short stock holddown and 14"; dia. blades: 3.14"; -- Depth of cut with short stock holddown and 12"; dia. blades: 2.36"; -- Max. rip width cap. 13.4"; -- Max material width, 25.6"; -- Min. rip length, 22"; -- Min rip length with short stock holddown, 15.8";Other Specifications: -- Max. sawblade dia., 14"; -- Min. sawblade dia., 12"; -- Sawblade bore, 90 mm (3.54";) -- Saw arbor dia., 70 mm (2.75";) -- Arbor motor, 50 HP -- Arbor speed, 3,800 RPM with 50 or 60 HP motors -- Feed speed from 20 to 135 FPM -- Feed motor by 3 HP VFD -- Overhead pressure roll raise & lower motor, 1/2 HP -- Dust collection; (2) 8"; diameter -- Overall dims., 62"; wide x 88"; long x 72"; high x 5,000 Lbs Features: -- Machine combines edging, selective, and gang rip functions -- Control Panel can be located for easy access -- Edges of random width boards can be trimmed in a single pass -- The positions of the movable saw blades are accurately controlled from the control panel for fast and convenient sets. -- Saw blade movement is driven through precision ball screws along a linear slideway for accurate, effortless traverse -- Exclusive laser projection system ensures accuracy -- Digital display for saw blade traverse; readouts in inch and metric displays are switchable -- Pressure rolls are supported on both sides and hold stock firmly and evenly -- Overhead pressure roll mechanism includes powered raise and lower -- Variable feed speed permits effortless ripping of a variety of stock; hard or soft, thick, or thin -- Double top and single bottom anti-kickback fingers, plus a side guard, provide excellent safety for the operator. -- Stepping motors drive precision ball screws for fast and accurate width settings. -- Same as above. f equipped with optional shifting fence and includes a digital display to accurately indicate fence travel -- Suspension of pressure plate from two sides helps prevent split or broken parts from damaging the saw arbor or saw blades -- Saw blade's movements are concentric for perfect rip accuracy and parallelism of ripped boards. Comes standard with: -- (3) 15 Mw Laser -- (2) Fixed saw seats -- (3) 12" Carbide Tipped SawbladesOptional: --TRS-FTAO-3: Automated In-Feed Table, 3 Meter Powered Conveyor System with Movable Fence, Shifting Laser Lights for 2-Moveable Blades for Rip Width Settings, and Digital Display, -- TRS-FTMU-3: 3 Meter Powered In-feed Table, Manual,

CAM-WOOD TRS-350X Heavy-Duty Dip Chain Gang Ripsaw75 HP! ... plenty of power for those with a lot of ripping work!Specifications: -- Maximum cutting width, 13-3/4"; -- Maximum depth of cut, 5-1/4"; -- Distance from column to first blade, 15"; -- Minimum working length, 25"; -- Maximum blade diameter, 16"; -- Minimum blade diameter, 10"; -- Sawblade bore, 2.756"; -- Saw arbor diameter, 2.165"; -- Saw arbor speed, 3,000 RPM -- Saw arbor motor, 75 HPFeatures: -- Variable feed speeds, 25 to 100 FPM -- Feed motor, 2 HP -- Roller holddown elevation motor, 1/2 HP -- Table working area 72"; x 31";Shipping dimensions, 84"; x 71"; x 68"; x 6,000 Lbs

CAM-WOOD WX-1504HC Horizontal Grinder w/ConveyorImpact resistant tooling with excellent wear capability. Specifications: -- Horizontal feed with (2) 1 HP infeed roller motors; 20 HP - 1,750 RPM drive motor; -- 15-3/8" x 4" Infeed chute; 8" dia. air discharge.Equipped with: -- (18) Rotary cutter sets with cutter head angle to allow aggressive cutting rates and high-speed shredding of waste; -- (4) Stationary cutter sets; 10" dia. rotor; 680 RPM. -- The shaft rest for the cutter head is constructed by a round hollow with a special angle for cooling during production. Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD WX-1510 Vertical Grinder-ShredderImpact resistant tooling with excellent wear capability. Specifications & features: -- Vertical-feed Chute, 10 HP - 1,750 RPM drive motor; 15" x 11" infeed chute; (6) rotary cutter sets & (2) counter-knives with cutter head angle to allow aggressive cutting rates and high speed shredding of waste. -- The shaft rest for the cutter head is constructed by round hollow with special angle for cooling during production. -- Complete with: -- Removable screen for easy clean up and chip size changes from standard 1/2". -- OutPut: -- 300 - 900 Lbs/Hr, depending on material and moisture content. -- Includes: -- Operators' & Parts Manual and covered by (1) Year Warranty.

CAM-WOOD IAH-SC Inverter Drive, End-Less Auto Finger Jointer SystemFinger jointer shaper with gluer and troughfeed press for unlimited lengthTechincal Specifications: -- Infeed timber working length(min-max) L = 300MM ~ 2500MM (11.9" - 98.4") --Timber length to be processed must be at least 50% longer than the timber width to beprocessed. -- Timber working thickness T = 15MM ~ 75MM (1/2" - 3") -- Timber working width W = 35MM ~ 255MM (1 3/8" - 10") -- Timber out-feed length L = ENDLESS -- Glue type to be used PVAC (glue pump not included) -- Timber moisture 8 ~ 12 % -- lnfeed qualities: Timber must be processed via four sides moulder machine (tolerance: ±0.2mm) and wood needs 90 degrees right angle, four planning clear, straight. FSL 6121 Inverter Type FingerShaper With Glue ApplicatorSpecifications: -- Working dimension W=620mm (24.5"). L=150mm~2500mm. (6" - 98") Thickness=15mm~75mm (1/2" - 3") -- Motor of finger spindle 20HP 1pcs -- Spindle size 50mm -- OD of finger cutter OD160 mm(without finger cutter) -- Finger spindle RPM 5500RPM -- Power of Cut-off saw 7.5HP 1pcs -- Size, cut-off saw 255mm x 100T x 5mm (with saw blade) 1pcs -- RPM, cut-off saw 4800rpm/min -- Power of scoring saw 2HP 2pcs -- Size, scoring saw 180mm x 50T x 5mm (with saw blade) 2pcs -- RPM, scoring saw 2850rpm/min -- Conveyor drive power 1/2HP 1pcs -- Table movement INVERTER system power, 3HP + 3HP inverter 1pcs -- Glue Applier injection glue spreader -- Standard glue height H=100mm (3.9") Pitch 4.0mm .157") L=10-12mm (3/8" -7/16") (special size made by optional) -- Cycle speed packing/min 1-4 times/min (TOP SPEED) -- Double cylinder clamping -- ROLLER DEVICE AT FEEDING & OUTPUT LOCATION OF SHAPERUFJ-600 Unlimited lenght Finger Joint PressSpecifications: -- Working dimension Width: 35mm-255mm (1 3/8" - 10"). Thickness: 25mm-100mm. 1" -3.9") Length : Unlimited -- Infeed speed 10M-90M / min (32.5' - 292'/min.) -- Power of upper roller 2H P 1: 10 2pcs -- Power of lower roller 2HP 1: 10 2pcs -- In-feed Inverter 5HP 2pcs -- Cut-off saw, power 7.5HP 1pcs -- Cut-off dimensions 455 x 120T x 25.4M M (with saw blade) 1pcs -- Cut-off saw, RPM 2850rpm/min -- Hydraulic power 15HP 1pcs -- Out-feed table size 2M x 3 -- Oil tank 200L -- Max. capacity without HSC 18M / min(full status)Production Capacity: -- Working time 480 MIN/SHIFT -- Finger length MADE BY ORDER -- Average infeed length at the finger jointing line 2500 MM (98") -- Average timber cross section 255X50 MM (10.2" X 2") -- Shaper max speed 4/2 TABLE/MIN; the speed will change by the working height of wood -- Number of timber pieces per shaper table(horizontal finger jointing 50X255 mm (2" X 10")) 2 PIECES -- Capacity of the press 18M/MIN (58.5'/min) -- The data is the max capacity for one-section cutting, the capacity will be amended while multi­ section cutting. -- Rate of utilization 80%CAPACITIES OF THE COMPONENTCAPACITY OF THE SHAPER -- (HORIZONTAL FINGER JOINTING for 50X255 mm

CAM-WOOD SET-402TS-N Double End NotcherDouble end notchine machine for pallet componentsSpecifications: -- Working Length: 24" to 49" -- Working Thickness: 3/4" to 4" -- Pneumatic Hold Down x 4 units (2 sets at Top & 2 set at Bottom) -- Notch Cutter Speed 6,000 rpm -- Notch Cutter Stroke 4" -- Notch Cutter Diameter 1-1/4" -- Notch Cutter Motor 5 HP x 2 -- Feeding Hydraulic Motor 1 HP -- Linear servo drive feeding rails system -- Cycle time 4 to 7 second per piece -- Dust Hood 4" x 2

CAM-WOOD SET-42TS-S 2 Heads 48" Double End Tenoner: Trimming only Capacity: -- Max. 48" working capacity, min. 12"; max. 4" opening, 24" load area in front of hold-downs. -- Motorized opening with LED indicator; -- Single-post machine, single "dual-track" base, right side fixed, left side movable.Each side equipped -- Top trim head, 5 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade; -- Variable feed speed from 12 - 52 FPM, 1 HP motor, steel feed chains with plastic anti-slip pads and dogs at 6" center, --Spring loaded overhead hold-down beams w/endless belts. -- Separate electrical control cabinet with operator controls.Options Available: -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional $38,900) -- Hopper feed magazine (additional $3,990)Extended infeed 42" (additional $4,500) -- Pneumatic jump control on scoring or shaping unit -- Same machine with 8' opening

CAM-WOOD SET-108TS- SHJC Double End Tenoner, (8) HeadsCapacity & Style: -- Max. 120" working capacity, min. 12"; max. 2" opening(thickness), 24" load area in front of hold-downs. -- Single-post machine, single "dual-track" base, right side fixed, left side movable. -- Motorized opening with LED indicator.Each side equipped with: -- Top scoring head, 2 HP - 3,600 RPM motor, 1" dia. arbor for up to 10" blade. -- Top trim head , 10 HP - 7,200 RPM motor, 5-7/8" (150 mm) long & 1" dia. arbor, 8" max. dia. cutter-head. -- Cope shaping head, 7.5 HP - 7,200 RPM motor, (150 mm) 5-7/8" long x 1" diameter arbor, 6" to 8" max. dia. cutter head -- Jump coping head, 7.5 HP - 7,200 RPM motor, (150 mm) 5 7/8" long X 1" diameter arbor, 6" to 8" maximum dia. cutter head -- Variable feed speed from 12 - 52 FPM, 2 HP motor, steel feed chains with plastic anti-slip pads, and dogs at 6" center. -- Spring-loaded overhead hold-down beams with endless belts. -- Separate electrical control cabinet with operator controls.Options Available: (Pricing to be confirmed at time of order) -- Cross transfer system with transfer line 4' X 8' transfer table with rollers (additional ...$39800). -- Hopper feed magazine (additional ...$3,990). -- 42" Infeed extension (additional ...$4,500) -- Pneumatic jump control on scoring or shaping unit. -- Sound enclosure (...$6,900) -- Electric motor brake -- Central support Included for 10' opening machineNote: Pictures are showing the machine with several options included

CAM-WOOD - VPS I, ...Vertical Panel Saw (82.677" x 161.417" w/Scoring)Top to Bottom cutting height is 2,100 mm with or without scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 4,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness. Standard features: -- 4 HP Motor with a 250 mm (10") dia. 80-tooth main saw blade. -- Separate 3.15" Dia. scoring blade, belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto-shifting material back support grid; shifting away from the saw blade cut line prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading and positioning of the larger or heavy panels; both standard inch and metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock-in the saw beam for vertical crosscuts. -- (2) Adjustable flip stops on inch (metric available) measuring scales, one located on the lower rail and the other on the foldout shelf at the middle of the frame. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down.Includes: -- (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade; Repeat Cutting Device.Optional Equipment available: Built-in Dust Collector, please add ...$ 1.250.

CAM-WOOD - VPS I +, ...Vertical Panel Saw (82.67" x 161.41" w/Scoring), Vertical-Horizontal Digital Readouts & Auto Lock System. Top to Bottom cutting height is 2,100 mm with or without scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 4,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness.Standard features: -- 4.0 HP Motor (5.5 HP Option) with a 250 mm (10") dia. 80-tooth main saw blade. -- Separate 80 mm (3.15") Dia. scoring blade, belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto-shifting material back support grid; shifting away from the saw blade cut line, prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading and positioning of the larger or heavy panels; both standard inch and metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- (2) Adjustable flip-stops on inch (metric available) measuring scales, one located on the lower rail and the other on the foldout shelf at the middle of the frame. -- Repeat Rip Gauge for duplicating multiple horizontal cuts. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down.Includes: Vertical-Horizontal Digital Readouts; Pneumatic lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-teeth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade.Optional Equipment available: Built-in Dust Collector, please add ... $ 1,250.

CAM-WOOD - VPS APL , ...Vertical Saw w/Scoring & Panel Lifting ClampsCapacity: -- Top to Bottom cutting height is 82-1/2" (2,100 mm) without scoring and 78-3/4 (2,000 mm) with scoring; saw head w/motor rotates 90° for rip or crosscutting. -- Cutting length "rip cut from left/right" is 161.417" (4,100 mm); cuts single or stacked panels up to 1-7/8 (50 mm) in thickness. Equipped with: -- 4 HP Motor; 250 mm (10") dia. x 80-tooth x 30 mm bore main blade; separate 3.15" dia. scoring blade belt driven at 7,800 RPM to insure clean cuts on everything from Plywood to Melamine to Hardwood. -- 2-Motorized panel lifting clamps "grab panel on top edge" for bottom cuts, clamps travel on (2) vertical screws for positioning of panels (660 Lbs. cap). -- (2) LED Readouts, (1) for crosscutting at the middle of the frame and (1) for horizontal rip cuts; (2) flip stops for crosscut measuring, one located on the bottom rail and the other on the mid-height measuring rail. Complete with: -- Foldout shelf at the middle of the frame for small part cutting; automatically shifting material back support grid shifting away from the saw blade cut-line prevents cutting into the grid support strips while rip cutting horizontally. -- Precision ground bottom edge support rollers to facilitate easy loading & positioning of the larger or heavy panels; standard inch preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- Rip gauge for repeat (same size) rip cuts and (3) adjustable preset stops; material always rests firmly against the "angled" back grid support. Includes: -- Spring-loaded floating saw blade enclosure shoe glides over panel surface applying a holddown force while it enhances dust collection & safety by enclosing the saw blades. -- (1) Main blade; (1) scoring blade.

CAM-WOOD - VPS I +, ...Vertical Panel Saw (76" x 122" w/Scoring), Vertical/Horizontal Digital Readouts & Auto-Lock SystemTop to Bottom cutting height is 2,000 mm (76") with or without scoring; saw head w/motor rotates 90° for rip or crosscutting; cutting length 3,100 mm; cuts single or stacked panels up to 60 mm (2.36") in thickness.Standard features: -- 4.0 HP Motor (5.5 HP Option) with a 250 mm (10") dia. 80-teeth main saw blade. -- Separate 80 mm (3.15") Dia. scoring blade, belt driven at 7,800 RPM; single-screw adjustment for side-to-side and depth. -- Auto-shifting material back support grid; shifting away from the saw blade cutline, prevents cutting into the grid support strips while rip cutting horizontally; it senses the blade/cutter position and automatically shifts away. Equipped with: -- Precision ground bottom edge steel support rollers to facilitate easy loading and positioning of the larger or heavy panels; both standard inch and metric preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock-in the saw beam for vertical crosscuts. -- (2) Adjustable flip-stops on inch (metric available) measuring scales, one located on the lower rail and the other on the fold-out shelf at the middle of the frame. -- Repeat Rip Gauge for duplicating multiple horizontal cuts. -- Retractable Material Support Shelves throughout the entire length of the machine frame allows for ergonomic cutting of smaller parts, at any cutting station without the need for the operator to bend down.Includes: Vertical/Horizontal Digital Readouts; Pneumatic lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 80 mm (3.14") dia. 24-tooth, 20 mm bore scoring blade.Optional Equipment available: Built-in Dust Collector, please add ...$ 1,250.

CAM-WOOD - VPS AV, ...CNC Fully Automatic Vertical Saw w/Scoring & Panel Lifting ClampsPC Control Panel with Software Optimizing Panel Cuts, Automatic Positioning System; the machine automatically switches to the vertical and horizontal position by Automatic Positions System.Capacity: -- Top to Bottom cutting height is 82-1/2" (2,100 mm) without scoring and 78-3/4 (2,000 mm) with scoring; saw head w/motor rotates 90° for rip or crosscutting. -- Cutting length 161.4" (4,100 mm); cuts single or stacked panels up to 1.57" (40 mm) in thickness. Equipped with: -- 4 HP Motor; 250 mm (10") dia. x 80-tooth x 30 mm bore main blade rotate at 5,800 RPM; separate 3.15" dia. scoring blade belt driven at 7,800 RPM to insure clean cuts on everything from Plywood to Melamine to Hardwood. -- 2-Motorized panel lifting clamps "grab panel on top edge" for bottom cuts, clamps travel on (2) vertical screws for positioning of panels (660 Lbs cap.). -- (2) LED Readouts, (1) for crosscutting at the middle of the frame and (1) for horizontal rip cuts; (2) flip stops for crosscut measuring, one located on the bottom rail and the other on the mid-height measuring rail. -- Programmable Panel Drive System with +/- 0.1 mm accurate positioning to preprogrammed lengths. Complete with: -- Foldout shelf at the middle of the frame for small part cutting; automatically shifting material back support grid shifting away from the saw blade cutline prevents cutting into the grid support strips while rip cutting horizontally. -- Precision ground bottom edge support rollers with double bearings to facilitate easy loading & positioning of the larger or heavy panels; standard inch preset "beam lock" stations. -- Vertical cutting stations are spaced at 40" or 1,000 mm increments to lock in the saw beam for vertical crosscuts. -- Rip gauge for repeat (same size) rip cuts and (3) adjustable preset stops; material always rests firmly against the "angled" back grid support. -- Spring-loaded floating saw blade enclosure shoe glides over panel surface applying a holddown force while it enhances dust collection & safety by enclosing the saw blades. -- Includes: -- Automatic Lock System; Repeat Cutting Device; (1) 250 mm (10") dia. 80-tooth, 30 mm bore main blade; (1) 125 mm (4.92") dia. 24-tooth, 20 mm bore scoring blade.Optional label printer available for additional cost.

CAM-WOOD TX-E8V Automatic Vertical Panel SawSpecifications: -- 98-1/2" Cutting length (cuts vertically top to bottom), adjustable depth of cut up to 2-3/8", 12" blade dia. with 1" dia. bore, single blade scoring; 5 HP main motor.Equipped with: -- Manually positioned pusher fence with grippers; precision ground guide rod, made from medium carbon steel coated with hard chrome, provides smooth and accurate travel. -- (3) Cutting modes: Standard, trim & cutoff to permit clean burrs, repeat cutting mode; heavy gauge base frame & table rest is welded from cold rolling steel plate, offering rugged construction. -- The uniform holding pressure through the entire pressure beam is achieved through a linkage mechanism, ensuring synchronized cylinder actuation on both sides. Flexible saw stroke adjustment enables the operator to select the desired stroke either full way or run out panel return depending on the panel length to be cut, this reduces considerable cycle time. Complete with: -- Fence made of cast iron and the surface precision ground is fitted with a flip-over stop for convenient repetitive cutting; saw carriage runs with bronze wheel, which is CNC lathe precision machined or accurate concentrically producing fine smooth surface cut; the guide rods, hard chrome-plated, provides rigid support for saw carriage; the ripping accuracy is guaranteed. -- 1 HP drive, variable speed saw carriage, cuts 16 - 98 FPM; return speed 98 FPM. Includes: -- Dust chute is covered with a split rubber to form a totally enclosed dust collection system, and fully prevents the hose from being broken resulting from its fatigue. -- Sectional dust guard not only acts as a surrounding saw blade guard but also fully prevents sawdust from spraying out of the machine.

CAM-WOOD TX-C8VX Automatic Vertical Panel Saw (Servo Gripper)Specifications: -- 98-1/2" Cutting length (cuts vertically top to bottom), adjustable depth of cut up to 2-3/8", 12" blade dia. with 1" dia. bore, single blade scoring; 5 HP main motor.Equipped with: -- PLC Controlled automatic pusher fence with grippers with Auto Stops or Auto Program Sizing mode; 40 FPM pusher speed, +/- 0.004" accuracy; precision ground guide rod, made from medium carbon steel coated with hard chrome, provides smooth and accurate travel. -- (2) Cutting modes: Standard cutting & scoring pass and cutting; the heavy gauge base frame & table rest is welded from cold rolling steel plate, offering rugged construction. -- The uniform holding pressure through the entire pressure beam is achieved through a linkage mechanism, ensuring synchronized cylinder actuation on both sides. Flexible saw stroke adjustment enables the operator to select the desired stroke either full way or run out panel return depending on the panel length to be cut; this reduces considerable cycle time. Complete with: -- Fence made of cast iron and the surface precision ground is fitted with a flip-over stop for convenient repetitive cutting; saw carriage runs with bronze wheel, which is CNC lathe precision machined or accurate concentrically producing fine smooth surface cut; the guide rods, hard chrome-plated, provides rigid support for saw carriage; the ripping accuracy is guaranteed. -- 1 HP drive, variable speed saw carriage, cuts 16 - 98 FPM; return speed 98 FPM. Includes: -- Dust chute is covered with a split rubber to form a totally enclosed dust collection system, and fully prevents the hose from being broken resulting from its fatigue. -- Sectional dust guard not only acts as a surrounding saw blade guard but also fully prevents sawdust from spraying out of the machine.

CAM-WOOD "PROFORMA" CNC Routers w/ATC for "Nested Base Manufacturing" including Cabinets, Three-Dimensional Wood Processing, Wooden Doors, Furniture & Window Processing; as well as Plastic Processing and Engraving.SERIES 404: $ 35,500SERIES 408: $ 37,720SERIES 510: $ 39,940Models Include (Table Sizes): 404 (4' x 4'), 408 (4' x 8'), 510 (5' x 10')General Specs: Machine Gantry X Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Y Axis Square Rails Parallel Vertical Accuracy 0.001"; (0.03mm), Z Axis Ball Screw Parallel Vertical Accuracy 0.001"; (0.03mm), Re-Position Accuracy 0.001"; (0.02mm), Working Accuracy 0.004"; (0.10mm), Grating Ruler Travel Accuracy 0.002"; (0.05mm).Control System: WEIHONG NK105 G3Spindle: 9.0kW (12 Hp) Air-Cooled Spindle 6,000 - 24,000 RPMBed Frame: Heavy-Duty Metal WeldingTable: (6) Zone Vacuum TableDriving System: Servo-Motor and DriverY Axis Driving System: Helical Rack & PinionX & Z Axis Driving System: HIWIN Ball-screw Axis Square Rail: HIWIN Linear Square RailATC: SERIES 404: Rear Linear (6) Tools ISO30, ER32 - SERIES 408/510: Rear Linear (8) Tools ISO30, ER32Inverter: SCHNEIDER 11 kWLimit Switch: OMRONElectrical Wiring: SIEMENSControl Switch: MOELLERWorking Size:SERIES 404: 51’’ (X) x 51’’ (Y) x 7-3/4’’ (Z)SERIES 408: 51’’ (X) x 98’’ (Y) x 7-3/4’’ (Z)SERIES 510: 63’’ (X) x 126’’ (Y) x 7-3/4’’ (Z)Machine Size (L x W x H):SERIES 404: 87’’ (X) x 74’’ (Y) x 71’’ (Z)SERIES 408: 87’’ (X) x 122’’ (Y) x 71’’ (Z)SERIES 510: 99’’ (X) x 149’’ (Y) x 71’’ (Z)Max Travel Speed: 2350 IPMMax Working Speed: 1100 IPMMachine Net Weight: SERIES 404: 3,520 lbs / SERIES 408: 3,960 lbs / SERIES 510: 4,480 lbsFeatures Include: -- Automatic (12) Tools Linear Type Auto Tool Changer Under the Bridge for Increased Productivity. -- All “Servo Motor"; Driving System: All Axes are Driven by Brush-less Type, High Torque AC Servo Motors. -- DSP CNC Controller is Setup to Accept Standard G-Code Programming Formats Along with On-Board Conversational Applications. -- Optional CAD/CAM System can Create and Edit Part Programs Then Send to Machine for Easy Cutting. DXF Files can be Imported, Modified, and Edited from Here to Create a G-Code. -- DNC is No Longer Required as the PC Directly Stores all Part Programs in a Text Editable File. -- Machine Designed Ready for 3-D Cutting Usage and Superior Performance. -- Moving Gantry Construction for Space Saving. -- The Rigid Steel Frame Construction has been Stress-Relieved Prior to Finish Machining to Provide Repeatability and Accuracy. -- Automatic Frequency Brake for the Spindle Allows Rapid Deceleration Resulting in Faster Tool Changes. -- Linear Guides and Sliding Blocks are Pre-loaded with Recirculation Bearings to Ensure Maximum Rapid Traverse and Precision. --Th
