BIESSE - ROVER 24 FTS: Flat Table Machine (w/ATC/Boring) -- Specifications4' x 10' "Matrix" Grid phenolic surface table for "Nested Base Manufacturing". -- Working Capacity"X" Axis is 122" (3,100 mm);"Y" axis 49.2" (1,250 mm); "Z" axis stroke is 9.8" (250 mm); max. material thickness of 6.1" (155 mm). -- Positioning Speed "X" & "Y" Axis is 328 FPM (100 MPM); Z-axis 98 FPM (30 MPM); "X" axis uses a helical rack & pinion system; "Y" & "Z" axes use precision ball screws.All axes movement is on precision linear guides & ways & controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system. -- Work AreaFlat table design with: "Matrix" grid phenolic surface for "Nested Base Manufacturing"; (2) independent working areas.(14) External pop up reference pins with: (6) Pins on the front of the table: (4) On the back of the table; (2) on the RH side; (2) on the LH side.Prepared for (optional): "Quick fit" Vacuum outlets for optional clamping of small or awkward shaped parts; each work zone with: (1) "Quick Connect" vacuum outlet for custom vacuum fixtures. -- Boring Unit(1) 2-1/2 HP (1.7 kW) - 4,000 RPM Motor; (14) independent vertical spindles: (7) In "X" axis & (7) in "Y" axis.(6) Horizontal spindles with: (2 + 2) In "X" axis & (1 + 1) in "Y" axis; (1) 120 mm dia. "X" axis grooving saw.(1) 6-Position "Ride Along" Automatic tool changer for "on-the-fly" ATC. -- Machining(1) 10.2 HP (7.6 kW) Air-cooled electrospindle with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM. -- Operator & Machine ControlPC Front End with: NC 1000" + WINDOWS "NT" Operating System; 17" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. -- Complete with:(1) 250 cbm/Hr Vacuum Pump; universal Autotransformer for voltages between: 200 - 600 V, 50/60 Hz; includes: Manuals, documents, safety mats, fencing. -- Actual Model is: BIESSE - ROVER 24 FTS.

BIESSE - ROVER 37XL FT: w/ATC/Boring -- Specifications 5' x 12' Phenolic "MATRIX" grid vacuum Flat Table design for: "Nested Base" processing.Working Cap. -- "X" Axis: 243-1/2" (6,180 mm); "Y" axis: 72.8" (1,850 mm); "Z" axis stroke: 7.1" (180 mm).Positioning Speed -- X" & "Y" Axes: 328 FPM (100 MPM); "Z" axis: 98 FPM (30 MPM); "X" axis: Uses helical rack & pinion system; "Y" & "Z" axes use: Precision ball screws.All axes movement: Precision linear guides & ways; controlled by digital, brushless AC Servo motors; all motion components are maintained by an automatic lubrication system.Worktable -- Phenolic "MATRIX" grid vacuum table for: FT "Nesting" or single part processing using (optional) pods or jigs; (2) sides & (8) rear & (4) side pop-up pins for easy material location.Boring Unit -- (1) 4 HP (3.3 kW) - 4,000 RPM motor; (14) independent vertical spindles: (7) X-axes & (7) Y-axes; (6) horizontal spindles with: (2 + 2) in X-axis & (1 + 1) in Y-axis; (1) "X" axis grooving saw with: 150 mm dia. blade.Machining Unit -- (1) 16.3 HP (12 kW) HSD electro spindle router with: HSK F63 Adaptor; inverter driven 1,000 - 20,000 RPM with: Max. torque from 12,000 - 20,000 RPM.(1) 6-Position "Ride Along" Automatic tool changer for: "On-the-fly" ATC.Operatory Interface -- PC Front-End with: BIESSE "NC 1000 + WINDOWS "2000" operating system; 15" color CRT; 40 GB hard drive; full keyboard & mouse; Ethernet connection capabilities. Programs can be transferred via diskette or downloaded by wire.Built-in 1,500 W air conditioner for: Constant temperature & dust-free environment.Complete & supplied with: -- (1) 11 KVA stabilized autotransformer for: Voltages between 200 - 600 V; automatic "forced" lubrication system for: Guides & ball screw. -- Includes: Emergency stop rope & pressure sensitive safety mats that will instantly place machine in "pause cycle" when stepped on; sound absorbing protective head enclosure with: Debris curtain around bottom edge. -- Actual Model: BIESSE ROVER 37 XL FT.Note: There is "NO" Vacuum Pump with the machine.

C.R. ONSRUD 122RH18CDA Roller Hold Down Series with Roller Hold-Down, Boring, ATC, "C" axis, Loading & Off Loading: 5 x10 - Work Envelope. Manufactured in the USA. Designed and engineered utilizing Finite Element Analysis. Fabricated base consisting of heavy steel construction, cast iron bridge and fabricated vertical supports. All structural components are stress relieved utilizing thermal heat treatment. -- Specifications:Fixed bridge design with single moving table allows for up to – 4,000 IPM programmable feed rates. and 1G of acceleration. High precision ball-screw drive for all axis movements. -- Aluminum Universal Vacuum Table System - Includes: 4"; intake manifold, high-capacity vacuum plumbing, high-flow 45mm wide waffle patterns, with Onsrud’s Unique High Flow Vacuum Inlets, to offer maximum vacuum airflow & absolutely minimal airflow restriction for excellent part holding. -- High Flow Vacuum Zone - Pneumatic Ball Valve, actuated via Push Button or PLC Controlled -- 10' x 5' worktable with, 11-inches of Z stroke - 14"; under bridge clearance & 11"; Z axis stroke. -- Table includes pressure sensitive safety stop “edge switch"; on front and rear. In addition, a 360-degree emergency stop cable surrounds the machine. Industrial machine control system with full 3D capability (multi-axis interpolation). -- Operator Interface:FANUC 0i Machine Controller System - Industrial CNC Machine Controller with Fanuc Panel-i HMI w/High-Res touch screen. Fanuc 0i is not a PC with a control card but is a dedicated Industrial PLC designed to control CNC motion, for maximum reliability and performance. -- Full remote diagnostic troubleshooting capabilities. M-code controlled vacuum zones. Provided with 4-port network hub. Network capability, FANUC Digital Drives & Servos. Air-Conditioned Electronics Cabinet. -- Machining:18 HP Spindle - 4-Pole, 13.5kW, 18HP – 24,000 RPM fully programmable & reversible, variable speed, HSK 63F tool interface, quick-change spindle, with air blast, capable of routing & drilling, programmable feed rates w/override capability. -- (1) 12 Tool - Dynamic Automatic Rotary Tool Changer - Fully Servo controlled instead of Stepper controlled or Rack-Style tool changers. Design eliminates misfires & quickly changes between 12 different tools. -- C-Axis Ability for Use with Aggregates - Adds a continuous rotation, rotational C-axis to Aggregate Tool Changer & Capability. Includes Aggregate Anti-Rotation Spindle Adapter Ring Option. -- Boring:9 Spindle Drilling Block Package - (Multi-Spindle Line Drills) Includes 9 independent or simultaneous firing. Vertical spindles arranged to drill up to 5 holes at a time in the X axis or 5 holes at a time in Y axis. -- Features:Roller Hold Down Option - 2 Rollers on each side of the cutting spindles, automatically extend & retract as rollers roll off cutting table, for holding down warped sheet stock such as low-grade plywood. Each roller’s pressure can be r

C.R. ONSRUD "MATE" 97M12 Series Moving Gantry 4 X 8 CNC Router with ATC: -- Specifications:• 97" x 49" Axes travel in a front-to-back configuration• Onsrud Universal High Flow Vacuum Table System for flow-through spoil boards and dedicated fixtures• (1) vacuum zone with (3) pop-up positioning pins.• (1) Router Head (HSD Mechatronics ES 929 4-Pole Spindle) 12 HP, 24,000 RPM• Fully Programmable, Variable Speed, Reversible, Capable of Routing & Drilling• Spindle adaptor HSK 63 Tooling (4 Tool Holders Included)• (10) Position Fixed Rack Automatic Tool Changer• Approximate Travel: X-Axis 97", Y-Axis 49"• Z-Axis 10" under bridge clearance and 9" Z-stroke.• Machining Speed 1,400 IPM• X & Y Rapid Traverse 2,500 IPM• Integrated Dust Transition System & Dust Extraction Hood• B & R Pendant CNC Controller• Airtech Vacuum Pump 8.6KW (11.5HP), 3,460 RPM

CALPE TH5-1600 Heavy-Duty High-Production, Fully Automatic CNC Lathe: General Description: -- Multi-Spindle cutting simultaneously, (5) spindles using V-type gouge knives. -- 63" (1,600 mm) Max. distance between centers; 5-1/2" (140 mm) max. swing diameter between spindles. -- CNC Controlled with 2.95" (75 mm) travel for depth of cut. Motors/Speeds: -- Servo controlled CNC drives: -- CNC controlled electronic variable speed head drives the movement of the (5) gouge tools. -- CNC controlled feed speed carriage, variable up to 50 FPM (15 MPM). -- (1) Head stock variable speed drive for the (5) spindles, up to 6,000 RPM, approx 10 HP. -- Fast return travel of up to 590 IPM (15,000 mm/Min). 2 HP approx hydraulic drive -- Loading device & tail stock powered by hydraulic pump with 2 HP - 1,750 RPM motor; No. 5 Morse taper on main spindle shaft. Features: -- Automatic loading & unloading device; carriage mounted with linear guides providing high precision movement. -- Full CNC controller with on-screen CAD programming for all products.Matching CALPE L6-1600, record number LC-010996 spindle sander is available at additional cost at same facility.

CALPE L6-1600 Spindle Sander with Hopper Feed. -- (6) Spindles, semi-automatic sanding machine; distance between centers 63", 6-3/16" max sanding diameter, capable of sanding 1800 spindles per hour. -- 4 HP - 1,800 RPM head motor, (5) sandpaper holders, each for different grits, 4000-3200-2200-850 RPM head spindle speeds. Copier unit that follows all contours. -- Oscillating sanding units & stationary pick up of part. -- NOTE: This sander was running with lathe on our record number LC-010811 and owner prefers to sell at the same time.

CAM-WOOD AC-5080X Piston Air CompressorCompact unit with a 5 HP induction motor.Features & Specifications: -- 18 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 80-Gal. vertical tank that meets the ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD AC-100120 Piston Air CompressorHeavy Duty unit with a 10 HP induction motor.Features & Specifications: -- 34.2 CFM @ 90 PSI, Splash lubricated cast iron 2-stage pump. -- Automatic start/stop operation. -- 120-Gal. horizontal tank that meets the ASME standards. -- Manual tank drain & pressure gauge. -- Deep finned after-cooler. -- Fully enclosed belt guard and ON/OFF pressure switch. -- Deep finned cylinder head for cooling and replaceable air filter/silencer. -- Durable painted finish for years of service under the worst conditions.

CAM-WOOD BR-2132 Boring Machine21-Spindle boring head on 32 mm centers with position indicator.Features & Specifications: -- Stops in 0° & 90° with pneumatically assisted positioning in vertical & horizontal. -- 0" - 3" Adjustable drilling depth with speed control. -- Head height fine adjustment with mechanical digital readout. -- 2 HP - 3,400 RPM Motor. -- Cast iron 37-1/2" x 19-1/4" table with side fences for mirror-image. -- Line boring fence with repeat stops. -- Foot actuated pneumatic clamps & drill cycle.Complete with: Magnetic starter, overload protection. -- Optional: Quick-change chucks $28.00 ea.

CAM-WOOD BR-OO42BX DOUBLE ROW LINE BORERHeavy Double Head Line Borer with (2) 21-spindle heads; 32 mm spindle spacing.Specifications: -- Drilling from the bottom up and with 5-1/2" - 23-1/2" distance between rows. -- Drilling vertically from the bottom allows the chips to drop down falling out of the holes. -- Drilling depth of up to 3" max., takes only seconds to set. -- (2) 2 HP - 3,400 RPM motors; spindles with steel gears & high quality bearings. -- Easy repetition by (2) air index pins for continuous line drilling, left and right roller track supports extend up to 400 mm (15-3/4") for larger panels.Features and Includes: -- 120" Back fence with (4) repeat "flip" stops; includes 27-3/4" (704 mm) fence for quick positioning of flip stops. -- (6) Pneumatic holddowns to automatically actuate when the drill cycle begins. -- (42) "Quick Change" chucks for easy tool change. -- Magnetic motor controls and 1/4" air regulator with filter and oiler; 100 PSI required air pressure.

CAM-WOOD BR-50 Universal Boring MachineFeatures & Specifications: -- 3 HP Pneumatic Universal Boring Machine, all adjustments feature an index plate for accurate and convenient reading, workplace clamping. -- Vertical Base travel, 24". Horizontal Base travel 12". -- 0" - 4" Spindle stroke, 7/16" - 14-thread screw shank, 1/2" max. bit capacity. -- Table Size: 15" x 22". -- Complete with: Air operated overhead hold-down clamp and foot pedal operated drill cycle. -- Drill Head can be swiveled 360° and Optional Multi-Spindle drill heads available.

CAM-WOOD BR 25 Horizontal DrillFeatures & Specifications: -- Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back. -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic hold-down clamp for up to 3" thickness. -- 12" x 10" Table size. -- 1/2" Drill chuck / 3/4" max. bit diameter.

CAM-WOOD BR 25 + 1 Horizontal and Vertical DrillFeatures & Specifications: The model BR-25+ 1 has the same features as the BR-25, except it's fitted with an additionaluniversal boring head, making it ideal for drilling holes on K/D furniture. -- The boring head can be swiveled 360 degrees for angular drilling, as desired -- Vercical Single Spindle, 2 HP - 3450 RPM 3-phase motor, adjustable vertically and front to back., spindle node threaded 7/16-14" -- Horizontal spindle 2 HP, 3450 RPM-3 phases motor, adjustable 360 degree, spindle nose threaded 7/16-14" -- 5" Horizontal spindle travel (drilling depth) w/foot pedal control. -- 3-1/2" Vertical table adjustment. -- Pneumatic holddown clamp for up to 3" thickness. -- 12" x 10" Table size.

CAM-WOOD DC-102 Dust CollectorSmall radial-finned Dust Collector mounted on wheels for portability.Features & Specifications: -- Large 13-1/2" fan that produces 2,100 CFM. -- Heavy Duty 3 HP motor pre-wired at 230 Volts. -- Large capacity dual station cloth top bags of 31.2 sq. ft. total cloth filter area. -- Low sound level of 75 - 90 dB.

CAM-WOOD DC-8075 Dust Collector Radial-finned type impeller for the best efficiency with large 15-3/4" dia. fan that produces 5,800 CFM.Includes: -- Heavy Duty 7.5 HP motor pre-wired at 220 V. -- (4) Large top filter bags and (4) lower collection bags with 48 cu. ft. capacity. -- Standard steel spring clamps to secure bags without leakage.Features: -- Low sound level of 75 - 90 db. keeps the work area quiet. -- Optional connection for using barrels.

CAM-WOOD DC-8100X Dust Collector Radial-finned type impeller for the best efficiency with large 15-3/4" dia. fan that produces 7400 CFM.Includes: -- Heavy Duty 10 HP motor pre-wired at 230 V. -- 10" Inlet -- (4) Large top filter bags and (4) lower collection bags with 48 cu. ft. capacity. -- Standard steel spring clamps to secure bags without leakage.Features: -- Low sound level of 75 - 90 Db keeps the work area quiet. -- Optional connection for using collection barrels.Note: 230 or 460 Volt, 60 Cy, 3-Ph please advise.

CAM-WOOD DC-535X DUST COLLECTOR 2900 CFM5 HP Motor and 14" Dia. Radial-fin type steel impeller to get the best efficiency usage.Specifications: -- Two top filters and two collection bags. -- Heavy-duty motor for powerful operation. -- Larger size impeller and extra long top air exhaust bags enabling to collect sawdust and wood chips more easily. -- Standard steel spring clamps to secure the bags with the body without leaking dust. -- Low sound levels keep the working area quiet. -- Replacement bags or 5 micron bags for fine dust are available. Optional connect bags for barrels are available.

TS-24ATSM:Features:• Through feed conveyor with cleaning brush for the belt, no minimum length limitation.• PLC control for easy operator and variability setup.• Fast spraying processing for profile strips and two edges in one pass through the machine.• Spray gun "On/OFF" controlled by photocell sensor for automatic spray control saving the spray material.• Individual coating volume adjustment control for each spray gun.• Variable feed speed control for the best finish results.• Two collection trays to catch overspray. • Powerful collection fan for air filtration by dry filter in totally enclosed cabinet eliminating no spray or fumes in the air.• Heavy sheet metal total enclosure frames and see through cabinet window.• Standard equipment comes with (1) one pneumatic paint pump and (4) four spay guns.• Extra spray guns are optional additional cost.SPECIFICATIONS: Max. Working Width - 12" Max. Working Thickness - 3-1/2" Max. Working Length - Infinite Min. Working Length - 19" Conveyor Feed Motor - ½ HP Feed Speed (Variable) - 32 ~ 96 FPM Spray Gun Capacity and included - 4 Paint Pump (piston type) included - 1 Set Exhaust Fan Motor - 3 HP Machine Size (L x W x H) - 138" x 62" x 99" Net Weight - 3200 LBS (Customer is responsible for local regulations and connecting utilities)

TS-24ATSPX:Features:• Through feed conveyor with cleaning brush for the belt, no minimum length limitation.• PLC control for easy operator and variability setup.• Fast spraying processing for profile strips and two edges in one pass through the machine.• Spray gun "On/OFF" controlled by photocell sensor for automatic spray control saving the spray material.• Individual coating volume adjustment control for each spray gun.• Variable feed speed control for the best finish results.• Two collection trays to catch overspray. • Powerful collection fan for air filtration by dry filter in totally enclosed cabinet eliminating no spray or fumes in the air.• Heavy sheet metal total enclosure frames and see through cabinet window.• Standard equipment comes with (1) one pneumatic paint pump and (4) four spay guns.• Extra spray guns are optional additional cost.SPECIFICATIONS: Max. Working Width - 24" Max. Working Thickness - 3-1/2" Max. Working Length - Infinite Min. Working Length - 21.5" Conveyor Feed Motor - ½ HP Feed Speed (Variable) - 32 ~ 96 FPM Spray Gun Capacity and included - 6 Paint Pump (piston style) included - 1 Set Exhaust Fan Motor - 5 HP Machine Size (L x W x H) - 138" x 73" x 78" Net Weight - 3960 LBS (Customer is responsible for local regulations and connecting utilities)

CAM-WOOD ST-3VFD Variable Speed 3-Roller Feeder -- With the powerful feeding strength, one can freely & simply assemble, dismantle & adjust it. It may be installed onto the circular saw, shaper, sander, router, planer serving as one’s invisible third hand at work. -- There are three (3) feed rollers on this feeder. Each roller has a suspender to hold simultaneously the workpiece at different degrees of thickness. It is also used to help the feed pressure. In case you need a large space between the rollers, you can take off the middle roller so the remaining rollers may be used for curve driving. Feeding Speed: 10 - 79 FPM (VAR). -- For spindle molder, the feeder may be adjusted to the leveling direction for side feed to meet the requirement of various processing condition. -- There are two (2) sets of matching & interchangeable gears of variable sizes to create for stages of feeding speed. -- Forward & reverse feeding switch. -- Universal support stand with cast iron base, main bracket, thick refaced column and aluminum hand wheels for vertical and horizontal positioning.
