SCMI - K201 HFE: Single Sided Edgebander1/8" Max. edge cap.; 1-1/2" max. panel thickness; semiautomatic strip & coil feed magazine (manual single strip feed); Teflon coated glue pot w/fast 8-Minute heat up time; 1.2 mm cap. guillotine. -- Workstations: Single motor front & rear end trim; 0.8 HP - 10,000 RPM motor; top & bottom flush trims, 0.8 HP - 27,000 RPM ea. motor; straight or 12° bevel cutters. -- Top & Bottom buffing unit, 0.25 HP - 2,800 RPM motors; 25 FPM fixed feed speed with 0.8 HP drive. -- Complete with: Sound enclosure, frequency converter, and used tooling.

SCMI - M-2: Dip Chain Gang Rip SawSpecifications -- 7-7/8" Width cap.; 36 HP - 3,600 RPM belt driven arbor (pulls 42 amps); dip chain feed. -- 70 mm Dia. arbor for 11-3/4" - 13-3/4" dia. saw blades; 4-1/2" Max. depth of cut; 23-1/2" throat depth; 14" min. stock length. -- 1.8 HP Variable feed motor; 30 - 150 FPM.Equipped with & Features -- Automatic chain lubrication. -- 64" x 35" Table. -- (2) Upper infeed & (2) upper outfeed rollers at 4" in dia., top & bottom. -- Anti-kickback fingers. -- Dust hood with: 7" Dia. outlet. -- Long infeed adjustable fence. -- Motor load meter.NOTE: Includes extra spacers & sleeves.

SCM - SI 400 NOVA: Sliding Table Panel SawSpecifications & Features -- 126" Stroke with scoring; telescoping crosscut fence with panel support; back squaring fence: (2) Flip stops; 3/4" dado capacity. -- Max. cutting height: 3-3/4" at 90°; 2-3/4" at 45°; 51" rip cut cap. with movable fence; "EZ Dial" adjustable split scoring blade assembly. -- 35" x 21" Main fixed table.Equipped with: -- 9 HP Main blade motor; 1 HP scoring blade motor; tilting arbor 0° - 45°; 300 mm (11.8") main saw blade dia.; 1" main blade arbor; 4,000 RPM. -- 100 mm (3.9") scoring blade dia.; 3/4" scoring blade arbor; 8,000 RPM; 2-position table lock mechanism. Complete with: -- "EZ Dial" Adjustable split scoring blade assembly: Simply turn the dial to adjust the width of the score.This system eliminates the need for shims and is fully adjustable in 0.1 mm increments. -- Handwheels in front for lifting & tilting of saw blades; blade guard on riving knife with dust outlet. Includes: 120 mm Main dust collection outlet.

SCMI - OLIMPIC K 560 R HP. Edgebander (w/Premill & Corner Rounding) -- Specifications Edge Capacity: 0.4 to 6 mm (0.016 to 1/4") for strip feeding. -- Panel Capacity:Min. panel width: 60 mm (2.375"); min. panel length: 140 mm (5-1/2").Min./max. panel thickness: 8 - 54 mm (0.375" - 2.125"); min. distance between panels: 600 mm (24").Equipped with: -- Premilling Station. (2) 2.0 HP (1.5 kW) motors; Servo controlled; to rectify/clean panels already sized. -- Adjustable Infeed Fence: Manually preset with digital indicator; pneumatic in/out positioning. -- Automatic Strip & Coil Feed Magazine. For straight edges; 3 mm guillotine for coils. -- Gluing Station: For EVA (Hot Melt) with quick-change/disconnect Teflon glue pot for fast glue tanks change if needed. Heat up time approx. 10 Min. -- Pressure Section. Manual digital positioning: Teflon coated pneumatic driven roller; (2) spring-loaded idle rollers.Workstations -- End Trimming Station.: Front & rear: (2) 0.5 HP - 12,000 RPM Motors mounted on THK guides; swivels 0° - 15° for straight & angle cutting. -- Top & Bottom Trimming Unit. (2) 0.7 HP - 12.000 RPM motors; capable of tilting & pneumatic positioning for (3) settings: flush/bevel/radius trimming for quick setup. -- Top & Bottom Profile Scraping Unit with: Digital indicators; large dia. copy wheels for max. accuracy; pneumatic in/out positioning. -- Glue Scraping Unit: Eliminates any excess glue. -- Buffing Unit. Top/Bottom; (2) 1/4 HP - 2,800 RPM motors; tilting up to 12°.Operator & Machine Control -- "STARTOUCH" Controller with: 21-1/2" Touchscreen display; capable of storing (100) programs. Machine automation by: PLC Function; encoder positioned in the panel feed track pinion.Diagnostics for a quick solution to errors; process statistics data: i.e., Number of pieces/edges and track feeding.Features & Complete with: -- 2-Speed feed speed of: 40 & 60 FPM (12 & 18 MPM); (1) 2-1/2 HP feed drive motor. -- 200 Hz Frequency inverter for all trimming units. -- Servo controlled; adjustable top holddown pressure beam. -- Auto. panel spacer to eliminate premature loading -- Anti-adhesive spray. -- Full sound enclosure cover and outboard panel support. -- THIS MACHINE IS FULL SERVO CONTROLLED. -- Actual Model: SCM - OLIMPIC K 560 R HP

SCM Minimax T-50 Tilting Spindle Shaper -- Specifications: -- 1-1/4" Dia. interchangeable spindle tilts -5° to +45°, -- 6.6 HP motor; 3-1/2" cap. under nut, (4) spindle speeds of 1,700 - 4,000 - 7,000 & 9,000 RPM. -- Table size 18" x 43" with adjustable side extension tables; 3" - 5" - 7" & 8" table insert openings -- 4-1/2" max. spindle height above table -- 2" max. tooling retraction under table with 7" max. tooling dia.; working height 37".Equipped with: Outrigger Sliding Table, micro-adjustable fence, spindle lock, magnetic starter w/overload protection, reversing switch, and 4-3/4" dia. dust outlet. Includes: Several New Cutter-heads

SCM - M3: Multi-Blade Dip Chain Gang Rip SawSpecifications -- Width cap.: 300 mm (11.81"). -- Max. depth of cut.: 110 mm (4.33"). -- Throat depth: 8-3/4". -- Min. stock length: 390 mm (15.35"). -- Blade diameter: 200 - 350 mm (7.87" - 13.78"). -- Arbor dia.: 70 mm (2.76"). -- Table size: 750 x 1,530 x 750 mm H (29-1/2" x 60.24" x 29-1/2" H). -- Blade speed: 4,200 RPM. -- Feed speeds: 6 - 48 MPM (19 - 157 FPM).Equipped with: -- 44 kW (60 HP) - 3,554 RPM Blade motor. -- Variable speed drive feed chain motor. (2) Upper infeed & (2) Upper outfeed 4" Dia. rollers; automatic chain lubrication. -- Top & Bottom anti-kickback fingers. -- Main dust hood with: 200 mm (7.87") Dia. outlet. -- Adjustable infeed fence: 40"; x 2-3/4"; H. -- Motor load meter.NOTE: Some spec's need to be verified

SCM Sandy 10 -RCS-110 Wide Belt Sander (2) Heads43" Width cap. Drum, Combination HeadHead Configuration:1st. Head: 7" diameter corrugated metal roller for calibration 35 HP ( Drives both Heads )2nd Head: Combination head with 7" dia. contact roller (spiral grooved rubber covered); air/jump finishing platen controlled with timers to eliminate any rounding on leading & trailing edges of the panel, 2" wide platen.Specifications --103" long x 43" wide Abrasive belts --Air tracking, floating & rigid bed for sanding of veneers & solid panels; infeed & outfeed spring loaded holddown rolls -- Minimum workpiece length 16" --Thickness capacity 6.25". --Separate 2.5 H.P. variable speed feed motor delivering feed speeds from 15 to 70 FPMNote: The seller has 20 boxes of various sandpaper belts (80 – 150 grit) that will be included.

SCM SANDYA - 40 M3 135, ...3-Head Wide Belt Sander 52" Width cap. Drum, Drum, Combination HeadHead Configuration:1st Head: Steel Contact 22 kW Pneumatic blowdown and alignment.2nd Head : Rubber Contact 18.5 kW Pneumatic blowdown and alignment.3rd Head: Combination Platen 15 kW Pneumatic blowdown and alignment.Note:The SCM sander does not have a brush. After the 3rd head, it has this pneumatic blow-off bar with multiple blow-offs running the length of the sanders width. Sander can be seen under power if needed.Specifications: -- 53" x 103" Abrasive belts with electronic tracking. -- All heads with abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 5 HP motor. -- Automatic part thickness adjustment. -- Motorized thickness opening via (4) precision conveyor bed jacks with LED readout. --0" - 7-7/8" opening. -- Equipped with & Features -- Outfeed rubber covered holddown rolls or shoes on all heads. -- Motor load meters. --Infeed and outfeed conveyor extensions. -- WYE-DELTA soft start.Note: The SANDYA model "40" is more or less the same as the SANDYA "30" but more Heavy Duty.

SCM SANDYA 15S (3) Head Wide Belt Sander42" Width cap, Drum, Drum, Combination HeadHead Configuration:1st Head: Steel contact roll, 7" dia., 35 HP motor;2nd Head: Rubber-covered contact roll, 24 HP motor3rd head: Combination head, rubber-covered contact roll (45 Shore) and 3" wide finishing platen, 17.4 HP motor.Specifications: -- 43" x 103" Abrasive belts -- Electronic tracking & pneumatic belt tensioning, abrasive belt grit compensation. -- Conveyor belt feed with dual feed speed, 4 HP motor -- Automatic part thickness adjustment -- Motorized thickness opening via (4) precision conveyor bed jacksEquipped With & Features: -- LED readout, 0" - 6-1/4" opening. -- Infeed & outfeed spring loaded rubber covered hold-down rollers -- Motor load meters -- Infeed and outfeed roller conveyor extensions.

SCMI OLIMPIC K 800 T-FR2 EDGEBANDER EDGEBANDER (W/PRE-MILL & CORNER ROUNDING): Specifications: -- Edge Capacity, 0.4 to 8 mm (0.016 to 5/16") for strip feeding. -- Panel Capacity, min. width 65 mm and 140 mm min. length, (2-3/8" and 5-1/2"). Panel thickness min./max. 8 - 60 mm (3/8" - 2-3/8"). Equipped With: -- Adjustable In-feed Fence: Manually pre-set with digital indicator and pneumatic panel spacing device. -- Pre-Milling Station, RT-E: Spindles 2 x 3.0 HP, 12,000 RPM, (1) with PLC controlled jump action and manual digital indicators positioning. -- Automatic Strip & Coil Feed Magazine: For straight edges and 3 mm guillotine for coils. -- Gluing Station: For EVA (Hot Melt) with Teflon coated glue tank and quick disconnect to change glue tanks fast if needed. Heat-up time approx. 10 Min. -- Pressure Section: Servo motor positioning, (4) pressure rollers, first larger, Teflon coated and powered. Workstations: -- End Trimming Station K-SEL: Front & rear 2 x 0.5 HP, 12,000 RPM motors mounted on THK guides, swivels 0ø - 15ø, rapid set up between straight and angled cutting with the automatic swivel cylinder. -- Flush Trimming Unit: Top/Bottom, 2 x 1.0 HP, 12,000 RPM with 2 pre-set pneumatic positions, flush and overhang, remote pneumatic in/out positioning. -- Bevel/Radius Trimming Unit: Programmable, servo motor positioning, 2 x 1.0 HP - 12.000 RPM motors for change-over on the fly. -- Corner Rounding / Trimming Unit: For additional top & bottom trimming of linear an/or vertical leading & trailing corner when edgebanding all (4) sides, 2 x 0.8 HP - 12,000 RPM motor. -- Profile Scraping Unit "RAS/1000": Top/Bottom with (2) indexed manual pre-sets. Large dia. copy wheels for max. accuracy and pneumatic in/out positioning. -- Glue Scraping Unit, "RC-V": Top/bottom flat glue scraper with pneumatic positioning through controller and air-blow off nozzle to keep the knifes clean. -- Buffing Unit "SPN": Top/bottom, oscillating 2 x 0.25 HP - 3,000 RPM motors, tilting up to 12°. -- Hot Air Unit: Single blower with adjustable heat range and directional heat shield for top/bottom coverage. Restores color luster on thick pvc edging materials that my be lost during the edge scraping process.Operator Interface: -- Startouch Controller, 12" color touch screen, swivels 270° at in-feed of machine. Capable to store (100) programs, (6) at the touch of a single key. Graphical display of all working units. Tracks production data, diagnostic information and monitors maintenance schedules. Complete With & Features: -- Feed-speed, 36/52 FPM, 1 x 2.5 HP feed drive motor, 200 Hz frequency inverter for all trimming units. -- Electronic, programmable hold-down pressure beam positioning, lighted safety/sound enclosure cover and outboard panel support. -- Actual Model: OLIMPIC K 800 T-FR2

This item is in an Auction on exfactoryauctions.com. Go here to view item: http://exf.ac/i6p STEGHERR KSF Closed Halving Joint Cutter (Cross Joint Milling Machine) Specifications: Max. width 53 mm (2.09"), Max. depth 72 mm (2.83"). Table size 9-3/4” x 26” x 34” H. Tool dia. (2) 150 mm (5.91") & (1) 180 mm (7.09"). Spindle speeds 6,300 RPM. Equipped with: (2) 2.2 kW (3 HP) - 3.470 RPM Motors. Hydro-Pneumatic table feed. Pneumatic clamping. Fence. Foot pedal control. Complete with 1740 mm (68.50") Length stop gauge.

STEINEMANN OSUS NOVA 160/6 K-FS/NS-OPTIMAT Top and Bottom Calibrating Sander(6) heads consisting in 2 machines, first machine top/bottom opposed head. Secoind machine (4) head with Combi and finishing platenFeatured: -- 2-Head K, (1) top & (1) bottom; both heads directly opposed. for calibrating -- (4) head FS/NS top/bottom first Combi head, second finishing platenSpecifications:First machine Calibrating Sander: -- Top/bottom opposed single head -- Working width 1,600 mm (63") both heads 11" dia. steel contact roll -- Thickness capacity 3 - 150 mm ( 1/8" - 5.9") -- Working height (passline) 1400 mm (55") -- Cutting speed on K head 34 M/sec. (6,667 SFM) -- Tolerance within the board +/- 0,075 mm (+/- 0,003") -- 100 HP motor each head. -- 63" x 103" Abrasive belt size. (to be confirmed) -- Air jet abrasive belt tracking. -- Variable feed speed 7 - 43 M/min. (24' -138"/min.), 20 HP feed motor,. -- Control panel for this machine only Second Machine Finishing Sander: -- Top/bottom (2) head each as Combination drum/platen and finishing platen -- Working width 1,600 mm (63") both heads 11" dia. steel contact roll -- Thickness capacity 3 - 150 mm ( 1/8" - 5.9") -- Working height (passline) 1400 mm (55") -- Cutting speed on FS head 22 M/sec. (4,330 SFM) -- Cutting speed on NS head 22M/sec. (4,330 SFM) -- Tolerance within the board +/- 0,075 mm (+/- 0,003") -- No motor installed -- 63" x 103" Abrasive belt size. (to be confirmed) -- Air jet abrasive belt tracking. -- Variable feed speed 7 - 43 M/min. (24' -138"/min.), 20 HP feed motor,. -- Control panel for this machine Not included: -- infeed and outfeed conveyor -- Conveyor between the machine -- “all the control wiring goes into a cabinet that is separate on each machine. That is just the wiring for the sensors and solenoids for braking and belt tracking stuff. There are no motor controls with these so there are no starters included. The 2 head comes with (2) 150 HP motors and the 4 head has no motors on it. In order to make these operational you would need a PLC and HMI to run the controls and motor starters and would need to buy motor controls

2023 Stema "Alphard" CNC Machine for Drilling, Routing & Tenoning on Doors & Frames Description: CNC haunch/mortise/Tenon/dowel machine for cabinet doors, beaded face frames, full size door mortice/tenon, French miters, dowel insertion. X-Axis w/ 3200mm of Stroke 70 m/min Y-Axis w/ Ballscrew Movement 25 m/min Z-Axis, 25 m/min Ten-Position Automatic Tool Changer/Revolver Tool Changer Allows for Tenoning, Profiling, Mortising, Drilling Haunching Unit (for French Miter Product), 5.5 HP Motor Dowel Insertion Unit (8mm) Vibrating Dowel Hopper Glue Inserting Unit PC User-Interface w/ Windows 10, USB, & 19"; LCD Screen Pegasus Software Total Working Length 3200mm (120") Manually Adjustable Pneumatic Clamps Heavy Steel Frame

STETON P85 Hydraulic Cold PressDual platen hydraulic cold press -- Platen size 1,300 mm X 2,500 mm (51" X 98") Overall platen size -- Side loading on 98" side. -- 420 mm (16.5") Max. daylight opening. -- Pressure from bottom (4) 3.34" diameter upstroke hydraulic pistons. 2 HP hydraulic pump. 90 PSI.

STETON - P150C: (2) Platen Cold Press (was built as a Hot Press, but heating does not work!) -- Approx.: 118" x 51" (3,500 x 1,300 mm) Overall platen size; side loading on: 118" Side. Pressure from bottom: 2 HP Hydraulic pump. -- Max. daylight opening: 450 mm (17") Less thickness of middle platen. - Total pressure: 150 Tons. -- Cylinders: (8); Dia. of cylinders: 3.35" (85 mm). -- Platen material: Aluminum. -- Parallel guidance by toothed rack: Yes. -- Pressing time selectable: Yes. -- Pressing force: Electro-Hydraulic -- Technical type: Upstroke Press. -- Boiler: 30 kW Approx., but heating is not working. -- Weight: 6,500 kG (14,300 Lbs).

STRIEBIG COMPACT 4164, 5' x 10' Cap. Vertical Panel Saw (No Separate Scoring).Specifications: 2-3/8" Cutting depth, 5.5 HP motor with automatic Star-Delta starter & electric brake (stops within 4 Sec); 250 mm dia. (9-7/8") blade with 30 mm bore - 5,400 RPM rotation. -- Equipped with: -- Auto-deflecting aluminum lath grid, auxiliary support channel for tall & narrow parts, full length measuring rail with locking flip stop for cross cuts, unique lower roller panel support system (1,200 Lbs cap.). -- Complete with: -- 4" Dust extraction connection; patented "TRK" dust extraction system; (2) each adjustable base & rear supports for free-standing installation.

STROUP 4' X 20' Cold PressSpecifications: -- 50" x 244" End Loading, Segmented, Bag press with motorized daylight opening. -- (2) Individually actuated, 50" x 122", segmented platens. -- Single air bag per platen with approx., 50 PSI specific pressure. -- Motorized adjustable daylight opening from 9" to 56". -- End loading with (2) rows of spring-loaded pop-up rollers in lower platen for easy loading/unloading of the press.

SULLAIR ES8-30H/A 30 HP Single-Stage Fluid Rotary Screw Air Compressor, with 53,186 Run & 49,602 Load Hrs. (As of 11/2023)Specifications: -- Cap. 111 ACFM. -- Rated pressure 60 - 125/135 PSIG. -- Noise level 85 dBA.Equipped with: -- E-Profile rotor design air end. -- 30 HP 3,530 RPM Motor. -- Air-cooled aftercooler. -- SULLAIR “SUPERVISOR II DELUXE"; Microprocessor controller & graphic monitor system, with LCD Display, Touchpad, Constant pressure & temperature readout of pressure, Power failure auto restart, & Automatic start/stop.

SULLAIR LS-10, 30 HP SCREW AIR COMPRESSOR: -- Specifications:30 HP Motor, rotary screw air end, approx. 115 PSIG - 125 PSIG max; Mounted upon 150 Gal. receiver tank.Approx. Dimensions: 64" x 32" x 65"; Approx. Weight: 2,500 lbs. -- 2,630 Approx. total operating hours. Hour meter: Inoperable.

SULLAIR ES8-30H/A 30 HP Single-Stage Fluid Rotary Screw Air Compressor, with 53,186 Run & 49,602 Load Hrs. (As of 11/2023) Specifications: Cap. 111 ACFM. Rated pressure 60 - 125/135 PSIG. Noise level 85 dBA. Equipped with: E-Profile rotor design air end. 30 HP 3,530 RPM Motor. Air-cooled aftercooler. SULLAIR “SUPERVISOR II DELUXE” Microprocessor controller & graphic monitor system, with LCD Display, Touchpad, Constant pressure & temperature readout of pressure, Power failure auto restart, & Automatic start/stop. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.
