Black Brothers 22-D-875-68 Top Only Glue Spreader with 68" working width, 8-3/4" dia. Smooth Neoprene applicator roller, 6-1/2" dia. neoprene doctor roll, top roll applicator only, upper elevator opening 0" - 4-1/2", REEVES variable feed drive 1.5 HP. -- Complete with: Electrical interlocks, and safety shutoff bars.

Black Brothers Top Only Glue Spreader with 56" working width capacity. -- 8 3/4" dia. Chrome applicator roll with Chrome doctor roll and flow is controlled by single hand wheel adjustment. -- 1-1/2 HP motor variable speed drive. -- Upper elevator opening 0" - 4-1/2" w/manual hand wheel adjustment. -- Includes: safety guards, electrical disconnect box and magnetic starter.

BLACK BROTHERS 22-D-650-32 Top & Bottom Adhesive Spreader; Top & Bottom Roll Glue Spreader with 32" capacity. -- 6-1/2" Rubber glue applicator rolls with 16 TPI Grooving, flow controlled by 4-1/2" Neoprene doctor rolls. -- Single speed feed drive motor - 88 FPM. -- Lower elevator opening 0" - 3-1/2". -- Complete with: Magnetic start and all guards and labels.

BLACK BROTHERS TOP and BOTTOM GLUE SPREADER with 74" working width, 8-3/4" dia. Neoprene coated application rollers and 6-1/4" dia. Neoprene coated doctor rolls. -- Upper elevator opening 0" - 4-1/2" -- 40 - 120 FPM Variable speed drive. -- Complete with: Push-button magnetic starter, safety reversing bar, safety guards and all warning labels.

BLACK BROTHERS 22-D-875-44 Top and Bottom Glue Spreader with 44" Working width.Specifications: -- 8-3/4" Dia. Neoprene coated application rolls with 16 TPI -- 6-1/2" dia. chromed steel doctor rolls. -- Upper elevator opening 0" - 4-1/2" with thickness adjustment. -- Variable feed speed, approx. 30 - 88 FPM with 1.5 HP drive, Nema 12 electronics.Complete with: -- Push button magnetic starter, safety guards, safety reversing bar for cleaning, and all warning labels.

BLACK BROTHERS - 22-D-875-32, ...Top Only Glue Spreader.Capacity 32" Working width. -- 8-3/4" Dia. Rubber roll -- 6-1/2" Dia. chromed steel doctor roll. -- Top elevator opening w/Readout -- Constant pass line: 36-3/4" -- Outfeed roller conveyor -- 7.5 HP MotorComplete with:1 Spare rollerNOTE: Machine is currently wired for 220v

BLACK BROTHERS 22-D-875-74, Wide Format (74") Top & Bottom Glue Spreader74" Working width, 8-3/4" dia. grooved rubber covered applicator rolls, 6-1/4" chrome plated doctor rolls -- Complete with: Push button magnetic starter, safety guards, and safety reversing bar. -- Top elevator style glue spreader, constant pass line --Main Motor 1HP, 3ph --Feed speed 88FPM --Thickness adjustment via manual hand crank

BLACK BROTHERS 22-D-875-74, Wide Format (74") Top & Bottom Glue Spreader74" Working width, 8-3/4" dia. Grooved rubber covered applicator rolls, 6-1/4" hard rubber covered doctor rolls --Main motor 1.5hp -- Bottom roll adjustment -- Complete with: Push button magnetic starter, safety guards, and safety reversing bar.NOTE: Currently wired for 460v

BLACK BROTHERS - 775 SPRD: Top/Bottom Glue Spreader -- 68" Working width; 7-3/4" dia. neoprene coating rolls; 6-1/2" dia. rubber doctor roll; upper elevator opening: 0" - 4-1/2"; handwheel on right hand side with: Digital roll opening indicator to 0.001" increments. -- Variable speed of: 40 FPM - 120 FPM; 2 HP - 1,850 RPM feed drive.

BLACK BROTHERS - 22-D-875-56: Top Only Glue Spreader56" Working width; 7" opening. -- 8-3/4" Diameter smooth applicator roll; 6-3/4" diameter Chrome Doctor roll. -- Single-hand wheel adjustment for the Doctor Roll. -- Upper elevator opening: 0" - 7". -- Features: 1 HP Variable speed motor for feed and 2 HP variable speed motor for the applicator & chrome doctor roll. Center lower chrome pressure roll: Oversized and includes Glue Scraper. This setup gives you a lot of control over your coverage & mill thickness. -- NEMA 12 electrics. -- Complete with: Push button magnetic starter; dual variable speed Controllers; safety guards.

BLACK BROTHERS 22-D-1175-80 Glue Spreader (TOP & BOTTOM)Specifications: -- 80" Working width with 11-3/4" dia. Smooth EPDM coated rolls, 8-1/2" dia. EPDM coated doctor rolls. -- Upper elevator opening 0" - 4-1/2", 2 - 3 HP Variable speed drive, target feed speed of 20 FPM; Nema-12 electrics. -- Complete with: Push button magnetic starter, safety guards, and reversing bar.LITERATURE PHOTO - Not actual equipment offered, for reference only.

BLACK BROTHERS “22-D 875-62"; TOP & BOTTOM GLUE SPREADER with 62"; working width. -- Upper elevator opening 0"; – 4";. -- 8-¾"; dia. Neoprene coated applicator rollers with 16 TPI Grooving. -- 6-½"; dia. Smooth Neoprene doctor rolls. -- 40 - 120 FPM Variable speed drive. -- Complete with: Push button magnetic starter, NEMA 12 electronics, safety guards, all warning labels.LITERATURE PHOTO - Not actual equipment offered, for reference only.

BLACK BROTHERS 22-D-875-74, Wide Format (74") Top & Bottom Glue Spreader74" Working width, 8-3/4" dia. EPDM covered applicator rolls, 6-1/4" chrome plated doctor rolls, upper elevator opening 0" - 6". -- Single speed 1.5 HP drive for 88 FPM, NEMA 12 enclosures. -- Complete with: Push button magnetic starter, safety guards, and safety reversing bar.NOTE: Very Good overall condition, but rolls will need to be recovered, and Seller has discounted price to reflect this expense.

BLACK BROTHERS TOP AND BOTTOM 775- HOT MELT Glue Spreader with 32" working width.7-3/4" Heated Adhesive applicator rolls, with flow controlled by Chrome Doctor rolls. -- Single speed feed drive motor, operating at approximately 88 FPM. -- It has a 32″ width capacity and a 5-1/2″ thickness capacity. -- The doctor rolls are in very good condition. The price listed reflects that the 2 applicator rolls need to be re-covered. Or we can have them recovered for you for an extra cost and re-install. Please contact us with your specifications as we do not recover rolls until a machine is sold as these machines are very application specific. Meaning type of material which is usually silicone or a blend and durometer.This Model 775 has been cleaned and checked, and it heats up, and runs as it should.

BLACK BROTHERS 22D-875-62 Top & Bottom Glue SpreaderSpecifications: -- 62" Working width, 8-3/4" dia. Grooved Neoprene applicator roll with 24 TPI, 6-1/2" dia. smooth Neoprene doctor roll -- Lower elevator opening 0" - 4-1/2", -- Single speed of 88 FPM with 1.5 HP drive; -- NEMA 12 electrics. -- Complete with: Push button magnetic starter, safety guards, all warning labels.

BLACK BROTHERS - 3004: Air Pod Press38″ x 50″ Platen Size. -- (9) 12″ Air bags. -- Manually adjustable daylight opening: Up to 36. -- Lower spring-loaded rollers for: Ease of loading & unloading. -- This Machine requires NO electrical connections; it only requires compressed air to operate.While it does have low use, this machine was reconditioned with the following items: Replaced: Air regulator; water separator (both high flow). Rebuilt the main ROSS Check Valve: Full internal replacement; shaft/seals/spring: Factory rebuild kit. NEW hand valve. (1) NEW Air bag; replumbed the top.NOTE: Paint is ...100% original to the machine.

BLACK BROTHERS - 22-D-875-56, ...Roller Coater56" Nominal length; 8-3/4" dia. applicator, Chrome doctor roll, upper elevator and top only. -- Setup to 0" - 6" thick. -- Smooth EPDM applicator rolls and Chrome doctor rolls. -- Variable feed speed drive, pass line height 34". -- Drip Pan, Feed Pan, Continuous Flow Trough to be Stainless Steel or Teflon Coated. -- Trough for continuous flow 1" pneumatic pump and hose to supply product.Complete With: -- NEMA-12 Electrical enclosure, operating control bars, magnetic brake, electrical interlocks, reverse lockout and cleanup pan.

BLACK BROTHERS - 22-D-875-56, ...Roller Coater56" Nominal length; 8-3/4" dia. applicator, Chrome doctor roll, upper elevator & top only. -- Setup to 0" - 6" thick. -- Smooth Chrome applicator rolls and Chrome doctor rolls. -- Stationary feed speed drive, passline height 34". -- Drip Pan, Feed Pan, Continuous Flow Through. -- Trough for continuous flow 1" pneumatic pump and hose to supply product. -- (30) Day warranty for workmanship and manufacture's warranty for all parts used.Complete with: -- NEMA-12 Electrical enclosure, operating control bars, magnetic brake, electrical interlocks, reverse lockout, and cleanup pan.

BLACK BROTHERS - 410-56: Panel Brush Cleaner56"+ Top & Bottom Panel Cleaner; upper elevator: 0" to 4-3/4" upper elevator opening; standard: 30" passline height. -- (2) New 61-1/2"; wide (max. brush width) fiber brush rolls. -- 3 HP Speed drive; 230 /460 V/3-phase motor voltage; currently wired for: 230 Volt / 3-phase power. -- Feed speed approx. 80 FPM -- (2) 3-1/2" Upper infeed & outfeed spring loaded idler rollers; (2) 3-1/2" lower infeed & outfeed feed rollers. -- Operating handwheel & magnetic starter: Located on left-hand side. -- Complete with: Sheet metal hood w/separate (2) exhaust ducts for upper & lower cleaning brushes; requires 2,800 CFM. Machine was refurbished & never put into production. Cleaned & checked: "New" brushes; "new" feed rollers; (3) spare feed rollers; fresh paint.

BLACK BROTHERS - 22D-875-50: Top & Bottom Glue Spreader50" Capacity; Top & Bottom Glue Spreader.; 8-3/4" diameter Grooved (FINZER BCG-1 IFS Industries 4 x 1/2 3D Grooving) Applicator Rollers; 6-1/2" diameter. Chrome Doctor Rollers; fixed Speed Feed Drive (approx. 88 FPM); upper elevator opening: 0" - 3-1/2".This reconditioned BLACK BROTHERS "22D-875-50" Top & Bottom Glue Spreader includes: 90-Day "Parts Only" Warranty.
