TAYOR 16-Section Clamp Carrier 20.5' width cap., (7) clamps per section (128 clamps total). .48" max. clamp opening clamps with 4-1/2" X 3 1/4" jaw height (128) Rocker plates 4" X 6" @ 80-1706 (purchase in June 2024)Complete with: -- Semi-automatic clamp tightening, -- (2) Air drive carrier rotation. -- (2) Pneumatic panel flattener -- OAL approx. 24' X 14' X 12'Note: The buyer will be responsible for tear down and loadingMachine model CC 20,5-16-481

--In Auction: https://exfactoryauctions.com/Detail/CR-230068/event/A122024$1 --No Reserve!-- TAYLOR 800036 7' W 12-Section Semi-Automatic Pneumatic Clamp Carrier, with Flattener & Tightener Equipped with: (71) 32” Cap. Clamps, with 4-5/8” W x 3-1/2” H Jaws. Air motor drive. Dual foot pedal control. Complete with: Pneumatic Panel Flattener. Pneumatic Clamp Tightener.

TEREX ATLAS 1604 K ZW Wheeled Excavator w/ Grapple and MagnetSpecifications: -- 120 HP Diesel Engine -- 7.5 kW generator.Equipped with: -- Grapple -- Magnet -- Just replaced the solenoids fuel injectors and the exhaust valve. Hours: approx. 3,500

WEEKE VANTECH 512 FLAT TABLE MACHINE (W/ATC/BORING) -- Specifications 5' x 12' Flat Table "Bridge Gantry" machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. -- Working Capacity "X" Axis 156.7" (3,980 mm); "Y" axis 61" (1,550 mm); "Z" axis stroke is 9.6" (243.8 mm); max. material thickness is 3.9" (99 mm). -- Positioning Speed "X" & "Y" Axes 315 FPM (96 MPM); "Z" axis is 82 FPM (25 MPM). -- The head travels via AC brushless drives & THK linear motion guides on all axes. -- Worktable: User-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement. -- (6) Pop-up pneumatic locator/positioning on the front side & (1) on the back side in "X" axis & (2) pop-up pneumatic locator/positioning pins on RHS facing side in "Y" axis. -- (4) Vacuum Table work zones can be used independently or together for full table area foot pedal vacuum zone controls. -- Boring Unit: 2 HP (1.5 kW) motor; 3,450 RPM motor with: (7) Independent vertical spindles; (4) in "X" axis & (3) in "Y" axis. -- Machining: (1) 12 HP (9 kW) High speed constant duty, variable speed electrospindle router with "HSK F 63" adaptor. -- Router is programmable from 1,250 - 24,000 RPM, RH or LH rotation. -- (1) 10-Position ATC rack located at the end of machine. -- Operator Interface: PC Front-End with: WEEKE "PC 85T" + "Windows XP" + WoodWOP Operating System. -- 17" TFT Color graphic monitor; keyboard for data entry; PC 85T hand control pendant; central USB hub; Ethernet interface for LAN connection to office PC; RS-232 serial interface. -- BECKHOFF Programmable logic control for (3/4) axes; linear, circular & helical interpolation; the controller is contained in a separate freestanding, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with: (4) 100 cm/Hr Vacuum Pumps; safety light curtain (the machine will stop when the Operator enters the work area); safety fencing; separate control cabinet. - Manuals & Documents. -- Options Include: NC Controlled Touch Off Tool Probe length measuring device. (9) HSK F63 Tool Holders, as pictured. -- Actual Model is: WEEKE - VANTECH 512 OPTIMAT NBP084.

WEEKE VANTECH 480 FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications: 4' x 8' Flat Table Bridge style gantry machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. -- Working Area: "X" Axis is 98.4" (2,500 mm); "Y" axis 49.2" (1,250 mm); "Z" axis stroke is 9.6" (243.8 mm); max. material thickness of 3.9" (99 mm). -- Positioning Speed: "X" Axis is 236 FPM (72 MPM); "Y" axis is 203 FPM (62 MPM); "Z" axis 82 FPM (25 MPM).The head travels via AC brushless drives & THK linear motion guides on all axes. -- Worktable: User-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement.(3) Pneumatic "X"/"Y" locator/positioning pins. -- Boring Unit(6) Independent vertical spindles with: (3) in "X" Axis & (3) in "Y" axis. -- Machining: (1) 12 HP (9 kW) High-speed electro-spindle router with: "HSK F 63" Adaptor; constant duty; variable speed from 1,250 - 24,000 RPM; RH or LH rotation.(1) 7-Position ATC rack located at the LH end of machine. -- Machine & Operator Control: PC Front-End with: WEEKE "PC 85T" + Windows "XP" + WoodWOP Operating System.Free-standing control cabinet with: 17" TFT Color graphic monitor, keyboard for data entry, PC 85T hand control pendant; EtherNET interface for LAN connection to office PC; RS-232 serial interface; USB ports.BECKHOFF Programmable logic control for: (3/4) Axes: Linear, circular & helical interpolation; the controller is contained in a separate free-standing, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with: (4) 100 cbm/Hr Vacuum pumps; Tool Length Control; light curtain (the machine will stop when the operator enters the work area); safety fencing. -- Actual Model is WEEKE VANTECH 480.

WEEKE VANTECH 512 CON2/BHP 008 FLAT TABLE MACHINE (W/ATC/BORING): + AUTO IN-FEED/RAKE/OUT-FEED: -- Specifications:5' x 12' Flat Table "Bridge Gantry" machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. -- Working Capacity: "X" Axis 156.7" (3,980 mm), "Y" axis 61" (1,550 mm), "Z" axis stroke is 9.6" (243.8 mm); max. material thickness is 3.9" (99 mm). -- Positioning Speed:"X" & "Y" Axes 315 FPM (96 MPM); "Z" axis is 82 FPM (25 MPM).The head travels via AC brushless drives & THK linear motion guides on all axes. -- WorktableUser-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement.(6) Pop-up pneumatic locator/positioning on the front side & (1) on the back side in "X" axis & (2) pop-up pneumatic locator/positioning pins on RHS facing side in "Y" axis.(4) Vacuum Table work zones can be used independently or together for full table area Foot pedal vacuum zone controls. -- Boring Unit1.5 kW (2 HP) Motor, with "Quick Change" drill bit holders; programmable variable speed from 1,500 - 7,500 RPM; -- Machining(1) 12 HP (9 kW) High speed constant duty, variable speed electro-spindle router with "HSK F 63" adaptor.Router is programmable from 1,250 - 24,000 RPM, RH or LH rotation.(1) 10-Position ATC rack located at the end of machine. -- Operator InterfacePC Front-End with: WEEKE "PC 85T" + "Windows XP" + WoodWOP Operating System.17" TFT Color graphic monitor; keyboard for data entry; PC 85T hand control pendant; central USB hub; Ethernet interface for LAN connection to office PC; RS-232 serial interface.BECKHOFF Programmable logic control for (3/4) axes, linear, circular & helical interpolation; the controller is contained in a separate freestanding, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with: (4) 100 cbm/Hr Vacuum Pumps; safety light curtain (the machine will stop when the Operator enters the work area); safety fencing; separate control cabinet. - Manuals & Documents -- Options Include: NC Controlled Touch-Off Tool Probe, length measuring device. (1) NC controlled scissor lift/vacuum in-feed device. (1) NC controlled, powered flat belt outfeed table with Automatic Dust Control Vacuum Sweep Arm Rake system. Laser fence surround for safety -- Actual Model is: WEEKE VANTECH 512 CON2/BHP 008.

WEEKE BHP 100/VANTAGE 480 FLAT TABLE MACHINE, with ATC, Boring, Infeed Roller & Outfeed & 4,771 Hrs. (As of 10/31/23) -- Specifications:4' x 8' Bridge style gantry machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. -- Working Area:'X" axis 99.21" (2,520 mm), "Y" axis 49.21" (1,250 mm), Max. material thickness of 3.94" (100 mm). -- Travels:“X"; axis 146.06"; (3,710 mm), “Y"; axis 81.30"; (2,065 mm), “Z"; axis 13.70"; (348 mm) Routing, 8.46"; (215 mm) Boring. -- Positioning Speed:"X" & "Y" axis Vector speed is 314 FPM (96 MPM), "Z" axis 65 FPM (20 MPM);The head travels via AC brushless drives & THK linear motion guides on all axes. -- Worktable:User-Friendly "S/C Tech "MATRIX" grooved phenolic vacuum table for easy vacuum pod placement.(2) Fixed LH side & (2) Fixed RH side pneumatic pop-up positioning stops. -- Boring Unit:(1) 3 HP (2.3 kW) Motor, variable speed for 1,500 - 7,500 RPM;(21) Independent vertical spindles with (8) in "X" axis, (9) in "Y" axis (1st Row), & (4) in "Y" axis (2nd Row). -- Machining:(1) 12 HP (9 kW) Air Cooled High speed constant duty Router with HSK F63 adaptor,1,250 - 24,000 RPM, constant torque achieved at 9,000 RPM, RH or LH rotation(1) 14-Position tool changer Carousel located at the back side of the spindle carriage. -- Machine & Operator Control:PC Front-End with WEEKE "Power Control + Windows + WoodWOP operating system.17" TFT Color graphic monitor, Hand-held control pendant, Foot pedal control;"BECKHOFF" Programmable logic control for (3/4) axes, linear, circular & helical interpolation;The controller is contained in a separate free-standing, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with: 488"; W x 96"; L Infeed electric/hydraulic Scissor Lift platform, with 3"; x 3"; Support beams on 7"; Centers; 4’ L Roller track intermediate table; vacuum arm with (2) 10"; dia. vacuum pads; rake off-feed System; 49"; W x 10’ L x 36"; H Outfeed motorized belt conveyor. BUSCH "MM 1322 A VM3" 10 HP (7.6 kW) 300 mbar Vacuum Pump; 6’ H Safety fencing. -- Actual model is WEEKE BHP 100/VANTAGE 480Machine Dimensions: 292"; x 202"; x 96"; H.Machine with Scissor Lift Dimensions: 389"; x 202"; x 96"; H.

WEEKE VANTECH 510 V7 PO FLAT TABLE MACHINE (LOADING & UNLOADING): -- Specifications:5' x 10' Flat Table "Bridge Gantry" machine with User-Friendly "S/C Tech" "MATRIX" grooved phenolic vacuum table. -- Working Area:"X" Axis is 122" (3,100 mm), "Y" axis 61" (1,550 mm), "Z" axis stroke is 9.6" (243.8 mm), max. material thickness of 3.9" (100 mm). -- Positioning Speed:"X" Axis is 236 FPM (72 MPM), "Y" axis is 203 FPM (62 MPM), "Z" axis 82 FPM (25 MPM).The head travels via AC brushless drives & THK linear motion guides on all axes. -- Worktable: User-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement.(2) Pop-up Pneumatic locator/positioning bars, one on each side in "X" axis & (1) Pop-up pneumatic locator/positioning pins in "Y" axis.(4) Vacuum Table work zones can be used independently or together for full table area Foot pedal vacuum zone controls. -- Machining:(1) 16 HP (12 kW) High speed electro-spindle router with "HSK F 63" adaptor; constant duty, variable speed from 1,250 - 24,000 RPM, RH or LH rotation.(1) 8-Position ATC rack located at the end of machine. -- Operator Interface:PC Front-End with WEEKE "PC 85T" + Windows "7" + WoodWOP operating system.17" TFT Color graphic monitor, keyboard for data entry, PC 85T hand control pendant; central USB hub, EtherNET interface for LAN connection to office PC, RS-232 serial interface, "BECKHOFF" Programmable logic control for (3/4) axes, linear, circular & helical interpolation; the controller is contained in a separate free-standing, dust-free control cabinet that can be placed at either the LH or RH side of the machine. -- Complete with:(2) 225 m³/Hr Vacuum pumps; safety light curtain (the machine will stop when the operator enters the work area), safety fencing, separate control cabinet. -- Options Include: Boring unit with 2 HP (1.5 kW) motor & (7) Independent vertical spindles with "Quick Change" drill bit holders; programmable variable speed from 1,500 - 7,500 RPM; Touch-off tool length measuring device (1) SCHMALZ "Jumbo Ergo 85" Vacuum Lift (1) NC controlled, powered flat belt outfeed table (1) Automatic Dust Control Vacuum Sweep Arm/Rake system. -- Actual Model is WEEKE VANTECH 510 V7 PO

WEEKE BHX 055 CNC MACHINING CENTER (VERTICAL W/ATC): -- Specifications: Flexible "Vertical" Machining Center that uses less than 5 sq/m of valuable floor space in addition to an innovative panel handling system. -- Working Cap.:Max. workable part size for X-axis is 120" (3,050 mm); Y-axis 33.4" (850 mm), max. part thickness 2.4" (60 mm).Min. worktable part size for X-axis is 7.8" (200 mm); Y-axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The "BHX 055" can reach movement speeds of 164 FPM (50 MPM) in X- & Y-axis & 50 FPM (15 MPM) in Z-axis with total safety, providing an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW) Variable speed from 1,500 - 7,500 RPM motor; (13) independent spindles with: (8) Spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal spindles with: (2 + 2) in X-Axis & (1 + 1) in Y-axis.Boring block with "Quick Change" vertical spindle system. -- Operator Interface:WEEKE "Power Control PC 85" + Windows + WoodWOP 6.0 Operating System; Intel Core "2 DUO" Processor.17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive, modem, Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure and complete set of safety devices. -- Options Include:(1) 10 HP (7.5 kW) Air-cooled electro-spindle router with HSK F63 adaptor, variable speed from 6,000 - 18,000 RPM.(1) 4-Position ATC too rack mounted on the machine cabinet side.(1) "X" Axis grooving saw; 9,000 RPM, max. saw blade dia. 100 mm.

WEEKE BHC 350 4/10 CNC MACHINING CENTER: Specifications: -- Working cap.:"X" axis: 3,750 mm (147.6"), "Y" axis: 1,250 mm (49.2"), 80 mm (3.1") max. material thickness. -- Positioning Speed: "X" axis is 196 FPM (60 MPM), "Y" axis 164 FPM (50 MPM) & "Z" axis 66 FPM (20 MPM). The heads travels on THK linear motion guides on all axes. -- Worktable: (6) Moveable support rails, raise-and-lower panel feeding rails, (3) matrix style vacuum pods per rail.(6) Pneumatic backstops, (6) Pneumatic front stops, (2) movable pneumatic side stops, and the dual central zero-stop creates (2) working zones. -- Boring Unit:(1) 3.5 HP, 1,500 - 7,000 RPM Motor; equipped with (24) independent vertical spindles with (16) spindles in "X" axis & (8) spindles in "Y" axis.(4) Horizontal spindles with (1+1) in the "X" axis & (1+1) in "Y" axis;(1) "X" axis grooving saw for max. 100 mm dia. blade, 2,000 - 7,000 RPM. -- Machining:(1) 8 HP HSK F63 Liquid cooled electro-spindle powered by KEB frequency inverter, programmable from 1,200 - 18,000 RPM (constant torque from 9,000 - 18,000 RPM), RH or LH rotation. -- Operator & Machine Control:IPC control with "WEEKE MCC" + Windows "XP" + WoodWOP 5.0 operating system; 15" high resolution color graphic monitor, standard keyboard & mouse for data entry, 1.44MB floppy disk drive, CD ROM drive.EtherNET interface for possible LAN connection to office PC, RS-232 serial interface for simple PC connection; all mounted in separate free-standing control cabinet.WoodWOP allows for the machine to be programmed off-line with the same intuitive icon driven software that the operator has on the machine controller."BECKHOFF" programmable logic control (PLC) operating system for (3) axes; linear, circular & helical interpolation. -- Complete with:(1) 100 m³/Hr Vacuum pump, man-height safety enclosure around rear & sides of machine, 2-zone safety mats (will stop machine if operator enters work area). Actual Model is WEEKE BHC 350 4/10 .

WEEKE BHC VENTURE 7L CNC MACHINING CENTER (W/ATC, "C" AXIS): Specifications: Working Capacity "X" Axis is 190.5" (4,850 mm), "Y" axis is 83.5" (2,120 mm), "Z" axis stroke is 14.9" (380 mm), max. material thickness 5.9" (150 mm).Positioning Speed: "X" Axis travel speed of 328 FPM (100 MPM), "Y" axis travel speed of 164 FPM (50 MPM), "Z" axis travel speed of 66 FPM (20 MPM); The machine head travels on THK linear motion guides on all axes.Worktable: (8) Movable K-Table support rails with (3) vacuum pods per rail; (8) pneumatic back-stops, (8) pneumatic front-stops, (2) pneumatic side fence stops, (2) working zones.Boring Unit: 3 HP (2.2 kW) Motor, variable speed from 1,500 - 7,500 RPM; (25) vertical drill spindles, (14) spindles in "X" axis, & (9) in "Y" axis, and (2) offset for large 35mm drills. (6) Horizontal spindles with variable speed from 1,500 - 7,500 RPM, (2 + 2) in "X" axis & (1 + 1) in "Y" axis, grooving saw with 125mm diam. saw blade (1) NC controlled 0° - 90° "X" / "Y" grooving saw, variable speed from 1,500 - 7,500 RPM, 125 mm dia. saw blade.Machining: (1) 16 HP (12 kW) Liquid cooled electro-spindle router with HSK F63 adaptor, programmable 1,200 - 24,000 RPM, constant torque from 9,000 - 24,000 RPM, RH or LH rotation; powered by a frequency inverter. (1) NC Controlled "C" axis for 360° horizontal processing; (1) 8-position ATC tool changer magazine.Operator & Machine control: WEEKE IPC "MMC" Control + Windows "XP" + WoodWOP operating system; "Beckoff" PLC for (3/4) axes linear, circular & helical interpolation. 15" TFT color monitor, industrial keyboard for data entry, CD ROM & 1.44 MB floppy drives, modem, USB slot, RS-232 serial interface for possible simple PC connection; 40.0 GB hard drive, 512 MB of RAM, all mounted in separate free-standing control panel.Complete with: (1) 100 m³/Hr Vacuum Pump, 2-zone safety mats (will stop the machine if the operator enters the work area), and hand-held pendant controller.Under power and available for inspection.

WEEKE VENTURE 08M CNC MACHINING CENTER (W/ATC, "C" AXIS); -- Specifications:Working Capacity "X" Axis is 127.9" (3,250 mm), "Y" axis is 49.2" (1,250 mm) for boring & 52.2" (1,325 mm) for routing, "Z" axis stroke is 7.2" (185 mm), max. material thickness 4.9" (125 mm). -- Positioning Speed: "X" & "Y" Axis 263 FPM (80 MPM, "Z" axis 66 FPM (20 MPM); The machine head travels on THK linear motion guides on all axes. -- Worktable:(6) Movable K-Table support rails w/side mounted raise-and-lower panel feeding rails, (2) vacuum pods per rail; (6) pneumatic backstops, (2) pneumatic side stops create (2) working zones.Setup assistance through the PC control display for precise rail & vacuum pod positioning. -- Boring Unit:3 HP (2.2 kW) Motor, variable speed from 1,500 - 7,500 RPM; (12) vertical "QUICK CHANGE" drill spindles, (8) spindles in "X" axis & (4) in "Y" axis.(6) Horizontal spindles with (2 + 2) in "X" axis & (1 + 1) in "Y" axis; -- Machining: (1) 12 HP (9 kW) Liquid cooled electro-spindle router with HSK F63 adaptor, w/programmable 1,250 - 24,000 RPM, constant torque from 9,000 - 24,000 RPM, RH or LH rotation; powered by a 11 KVA frequency inverter.(1) NC Controlled "C" axis for 360° horizontal processing; (18) Total ATC positions with (1) 8-position ATC tool changer plate mounted on the head for "on the fly" ATC & (1) 10-position ATC rack mounted at the RH side of the machine base. -- Operator & Machine control: WEEKE IPC "PC 85T Power Control" + Windows "XP" + WoodWOP 5.0 operating system; "Beckoff" PLC for (3) axes with linear, circular & helical interpolation.15" TFT Monitor with 2D / 3D "REAL TIME" graphics, industrial keyboard for data entry, CD R/W & 1.44 MB floppy drives, modem, USB slot, RS-232 serial interface for possible simple PC connection; all mounted in separate free-standing control panel. -- Complete with:(1) 100 m³/Hr Vacuum Pump, 2-zone safety mats (will stop machine if operator enters work area), safety fences, scrap conveyor, hand held pendant controller. -- Actual Model is WEEKE VENTURE 08 M BHC

WEEKE BP 80 CNC MACHINING CENTER: -- Specifications: X-Axis 122.6 (3,105 mm); Y-axis 40.3" (1,020 mm); Z-axis stroke is 5.3" (135 mm); max. material thickness 3.9" (100 mm). -- Positioning Speed:X-Axis is 213 FPM ((65 MPM); Y-axis 164 FPM ((50 MPM) & Z-axis is 49 FPM (15 MPM); head travels on THK linear ways on all axes. -- Worktable:(6) Movable support rails with: (2) Square matrix vacuum cups ea.; (6) pneumatic backstops & (2) pneumatic side stops creating (2) working zones. -- Boring Unit:2 HP (1.5 kW) Motor; (11) independent vertical spindles: (6) in X-Axis & (5) in Y-axis; (6) horizontal spindles with (1 + 1) in X-axis & (1 + 1) in Y-axis; (1) X-axis grooving saw with 100 mm dia. blade. -- Machining:(2) 7.5 HP (5.6 kW) High speed routers with: "Hydro-Grip" Spindle & EPT 25 adaptors, 6,000 - 18,000 RPM; controlled by frequency inverter. (One of the router spindles is not operational & needs rebuilding.) -- Operator & Machine Control:PC Front-End with: HOMATIC + Windows + WoodWOP 4.0 Operating System; NUM PLC for (3) axes; linear, circular & helical interpolation;15" monitor; keyboard for data entry; floppy disk drive; 40 MB hard drive,;32-bit processors; RS-232 port for possible connection to office PC; all mounted in separate free-standing control cabinet. -- Complete with:(1) 40 cbm/Hr Vacuum Pump; safety mats. -- Actual model is: WEEKE - BP 80

WEEKE BHX 200-25 OPTIMAT CNC MACHINING CENTER (VERTICAL): + PANEL RETURN SYSTEM + CLAMEX-P PROCESSING: -- Specifications: Flexible "Vertical" Machining Center that uses less than 10 sq/m of valuable floor space in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for "X" axis is 120" (3,050 mm); "Y" axis 49.2" (1,250 mm) max. part thickness 3.1" (80 mm).Min. worktable part size for "X" axis is 13.8" (350 mm); "Y" axis 2.36" (60 mm); min. part thickness of 0.31" (8 mm) automatic infeed & outfeed. -- Positioning Speed:The BHX 200 can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axes & 50 FPM (15 MPM) in "Z" axis with total safety; provides an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW) Motor, variable speed from 1,500 - 7,500 RPM; (15) independent spindles with: (9) Spindles in "X" axis & (6) spindles in "Y" axis.(10) Horizontal spindles with: (3 + 3) in "X" axis & (2 + 2) in "Y" axis; boring block has "QUICK CHANGE" spindle system. -- Operator & Machine Control:WEEKE "POWERTOUCH" + Windows "7"+ WoodWOP Operating System; "i5" Processor.21.5" HD multitouch Wide Screen Display Monitor; soft-touch keypad & USB connection; Digital Field Bus System; RS-232 Serial ports, Ethernet connection.Real-time multitask processing; programs can be transferred via USB or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include:(1) NC Controlled 0° - 90° "X/Y" Grooving Saw for max. 125 mm dia. x 5 mm thick blade.(1) 13.4 HP (10 kW) Air-Cooled electrospindle router with HSK F3 adaptor; variable speed from 1,500 - 24,000 RPM.(1) 4-Position ATC tool rack mounted on the side of the machine base.(1) "CLAMEX-P Connecting Hardware Processing System; ...watch the Literature Video @ 3:45!(1) NC Controlled Panel Return System; ...watch the Literature Video @ 4:30! -- Actual Model is: WEEKE - BHX 200-25 OPTIMAT

WEEKE BHX 050 CNC MACHINING CENTER (VERTICAL): -- Specifications: Flexible "Vertical" Machining Center that uses less than 5 sq/m of valuable floor space, in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for "X" axis is 98.4" (2,500 mm); "Y" axis 33.4" (850 mm); max. part thickness 2.4" (60 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The "BHX 050" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axes & 50 FPM (15 MPM) in "Z" axis with total safety, providing an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW), Variable speed from 1,500 - 7,500 RPM motor, (8) independent vertical spindles with: (4) spindles in "X" axis & (4) spindles in "Y" axis.(3) Horizontal Spindles with (1+1) in "X axis & (1) spindle in "Y" axis.Boring block has QUICK-CHANGE spindle system. -- Operator & Machine Control:WEEKE "POWER CONTROL" + Windows + WoodWOP 6.0 + Operating System; "IntelCore 2 DUO" Processor.17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive, modem, Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure and complete set of safety devices. -- Options Include:&#9679 (1) "X" Axis grooving saw; 9,000 RPM, saw blade dia. 100 mm. &#9679 (1) 7 HP (5 kW) Electro-spindle router with hydraulic "QUICK-CHANGE" tool system & "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. -- Actual Model is WEEKE BHX 050.

WEEKE BHX 050 CNC MACHINING CENTER (VERTICAL): -- Specifications: Flexible "Vertical" Machining Center that uses less than 5 sq/m of valuable floor space, in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for "X" axis is 98.4" (2,500 mm); "Y" axis 33.4" (850 mm); max. part thickness 2.4" (60 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The "BHX 050" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axes & 50 FPM (15 MPM) in "Z" axis with total safety, providing an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW), Variable speed from 1,500 - 7,500 RPM motor, (6) independent spindles with: (4) spindles in "X" axis & (2) spindles in "Y" axis.Boring block has QUICK-CHANGE spindle system. -- Operator & Machine Control:WEEKE "POWER CONTROL" + Windows + WoodWOP 5.0 + Operating System; "IntelCore 2 DUO" Processor.17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive, modem, Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure and complete set of safety devices. -- Options Include:&#9679 Max. workable part size for "X" axis is 120" (3,050 mm. &#9679 (1) "X" Axis grooving saw; 9,000 RPM, saw blade dia. 100 mm. &#9679 (1) 7 HP (5 kW) Electrospindle router with hydraulic "QUICK-CHANGE" tool system & "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. -- Actual Model is WEEKE - BHX 050.

WEEKE ABD 050 CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:(1) Horizontal drilling aggregate with (1) individual spindle; with servo control of the "X" Axis; (1) glue & dowel injector with glue flow control; (1) vibrating hopper dowel feeder. -- Working Capacity:Part size: Length 20 mm - 1,250 mm (.75" - 49") Width 20 mm - 800 mm (.75" - 31.5") Thickness 10 mm - 60 mm (.4" - 2.4") thick.Machine is set up for 8 mm Dia. x 30 or 35 mm long dowels -- Work Area(2) Separate working fields with (4) pneumatic top clamps can process up to (2) parts independently on the left-hand, right-hand or center stops; work pieces can be loaded in (1) field while being machined in the other to allow fast production of varying parts. -- Operator Interface:PC Front-end with Homag Power Control PC 85T, WoodWOP 5.0 operating system with graphic programming & error messaging.17" TFT flat screen monitor, CD-RW drive, 1.44 MB floppy drive, standard keyboard & mouse; Software allows program design with automatic mirror-image by use of an active center stop located 600 mm (23.6") from zero. -- Complete with:Bar code reader. All manuals, documentation & program disk provided with machine. -- Actual Model is WEEKE ABD 050/12/NA.

WEEKE ABD 050/12/NA CNC BORE, GLUE & DOWEL INSERTER, with 350 Hrs. Only!: -- Specifications:(1) Horizontal drilling aggregate with (1) individual spindle with 0.55 kW (3/4 HP) - 2,750 RPM Motor; (1) glue & dowel injector with glue flow control; (1) MAFU “MRA 250"; vibrating hopper dowel feeder, with Bowl size 14-1/2"; Dia. x 4-1/2"; D. -- Working Capacity:Part size: Length 20 mm - 1,250 mm (.75" - 49") Width 50 mm - 800 mm (2" - 31.5") Thickness 10 mm - 60 mm (.4" - 2.4") thick.Machine is set up for 8 mm Dia. x 30 or 35 mm long dowels -- Work Area(2) Separate working fields with (4) 3-1/8"; x 4-5/8"; pneumatic top clamps can process up to (4) parts independently on the left-hand, right-hand or center-stops;work can be loaded in (1) field while being machined in the other to allow fast production of varying parts. -- Operator & Machine Control:PC Front-end with Homag Power Control PC 85T, WoodWOP 5.0 operating system with graphic programming & error messaging;17" TFT flat screen monitor; Software allows program design with automatic mirror-image by use of an active center stop located 600 mm (23.6") from zero. -- Complete with:HONEYWELL “HYPERION 1300G-2"; Bar code control reader. All manuals, documentation & program disk provided with machine. Actual Model is WEEKE ABD 050/12/NA

WEEKE ABD 050 CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:(1) Horizontal drilling aggregate with (1) individual spindle; with servo control of the "X" Axis; (1) glue & dowel injector with glue flow control; (1) vibrating hopper dowel feeder. -- Working Capacity:Part size: Length 20 mm - 1,250 mm (.75" - 49") Width 20 mm - 800 mm (.75" - 31.5") Thickness 10 mm - 60 mm (.4" - 2.4") thick.Machine is set up for 8 mm Dia. x 30 or 35 mm long dowels -- Work Area(2) Separate working fields with (4) pneumatic top clamps can process up to (2) parts independently on the left-hand, right-hand or center stops; work pieces can be loaded in (1) field while being machined in the other to allow fast production of varying parts. -- Operator Interface:PC Front-end with Homag Power Control PC 85T, WoodWOP 5.0 operating system with graphic programming & error messaging.17" TFT flat screen monitor, CD-RW drive, 1.44 MB floppy drive, standard keyboard & mouse; Software allows program design with automatic mirror-image by use of an active center stop located 600 mm (23.6") from zero. -- Complete with:Bar code control reader. All manuals, documentation & program disk provided with machine. -- Actual Model is WEEKE ABD 050.

WEEKE ABD 100 CNC BORE, GLUE & DOWEL INSERTER: -- Specifications:(1) Horizontal drilling aggregate with (1) individual spindle; (1) glue & dowel injector with glue flow control; (1) 23" Dia. x 4" D vibrating hopper dowel feeder. -- Working Capacity: Material size from 20 mm - 1,250 mm (.75" - 49") long, 50 mm - 800 mm (1.9" - 31.5") wide, 10 mm - 60 mm (.4" - 2.4") thick. Machine is set up for 8 mm dia. x 30 or 35 mm long dowels (additional dowel sizes are optional). -- (2) Separate working fields with (4) 2-3/4"; LR x 3"; FB pneumatic top clamps can process up to (4) parts independently on the left-hand, right-hand or center-stops; work can be loaded in (1) field while it is being machined in the other to allow fast production of varying parts. -- Operator Interface:PC Front-end with Windows XP + Weeke "WoodWOP 5.0" operating system with graphic programming & error messaging; USB front side bus, 17" TFT flat screen monitor, CD-RW drive, Modem, standard keyboard & mouse.Software allows program design with automatic mirror-image by use of an active center stop located 600 mm (23.6") from zero. -- WEEKE "ABD 100" is designed for small or large capacity horizontal drilling, gluing and dowel insertion; built on a Heavy Duty welded steel base; main horizontal beams hold the carriage for the boring head and glue/water injector. -- Complete with: HAND-HELD PRODUCTS "ADAPTUS 5.0 3800G04E" Handheld Barcode Reader.
