KOCH SBD-8 BORING MACH. (FEED THRU DBL END TRIM, BORE & DOWEL): -- Specifications:0.6" - 1.18" (15 - 30 mm) Material thickness; 0.9" - 9.8" (23 - 250 mm) width; & 10" - 98.4" (254 - 2,500 mm) length cap.; -- Working pass height 36.2" (920 mm); Capacity of approx 25 Work Cycles/Min. -- Features:Motorized opening with digital setting. Automatic hopper feed with hydraulic stock feed beam and automatic return conveyor to operator. -- Each side equipped with: Trim saw units, Boring units with horizontal and vertical drilling, & Dowel insertion. -- Linear path control for stock transport with low profile machine bed and linear guides. Fixed stock stops. -- Adjustable working stations with Manual & motorized adjustments. -- Horizontal Drilling:Each side with (1) 2.7 HP (2 kW) - 3,400 RPM Boring unit. -- Each horizontal boring unit has a (3) Spindle Type D-1277 drilling chucks on 32 mm centers. -- Drilling Chucks hold 10 mm dia shank & 70 mm max bit length. -- Each head moving on linear guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holes. -- Top Vertical Drilling:(2) Top Vertical Boring Units with rotating device. Each unit 2.7 HP (2 kW) - variable speed from 3,000 - 6,000 RPM. -- Each Drilling chuck with mechanical digital read out for manual finite adjustment. -- Drilling Chucks hold 10 mm dia drill bit shank & 70 mm max bit length. -- Each head moves on guides with, drilling depth control, dust extractor hoods, blow-out jets to clean holes. -- Each vertical unit can be equipped with Boring blocks (swivel 0° - 90°) with pneumatic locking. -- All Vertical units are equipped with pneumatic locking & individual adjustment of the boring block. -- Distance position readouts on all heads for finite "X"/"Y" adjustments; and "Z" axis boring depth control. -- Doweling:With (2) total dowel Inserters, (2) inserter on each side, with vibrating dowel bowl feeders. -- Includes automatic dowel measurement, pressurized glue tank, & back-wash rinsing tank. -- NOTE:This machine is currently setup for 0.437" dia. x 1.75" long dowels (11 mm dia. x 44.45 mm long dowels). Other sizes & additional dowel injectors can be purchased from Koch, at additional cost. -- Operating Features:Mechanical digital readout setting for all drill stations for "X"/"Y"/"Z" axis positioning. -- The stationary machine side is on the LH side (seen in transport direction) and not adjustable. -- The RH is adjustable via motorized movement along the "X" axis. -- The machine is equipped with Hopper Feed & has a part stack capacity of approx 9.8" (250 mm) & working capacity of approx 48 Pieces/Min. -- Stock infeed belts move the workpiece through an intermediate hopper to the stock support. Then the workpiece is transported through the working stations by means of transfer belts with lateral stock alignment. -- Work pieces are automatically feed and positioned to pneumatic stops then clamped prior to trim, drilling or insertion. -- Compl

KOCH SPRINT-PTP-2-L CNC BORE, GLUE & DOWEL INSERTER: -- Specifications: Automatic step-by-step, boring, glue injection & dowel insertion at random spacing. -- Working Capacity:Stock length (Y) from 4.25" - 31.4" (110 mm - 800 mm), Stock width (X) from 0.75" - 98.4" (20 mm - 2,500 mm),Stock thickness (Z) from 0.51" - 1.57" (13 mm - 40 mm), max. boring depth 1.1" (28 mm). 98.4" (2,500 mm) X-Axis divided into (2) work zones of 47.2" (1,200 mm) ea zone.One part can be processed, while the other is being unloaded or loaded. -- Positioning Speed: 344.5 FPM (105 MPM), boring & insertion capacity up to (60) dowels/Min -- Machining:(1) Horizontal boring spindle, 7,200 RPM, powered by 1.2 HP (0.9 kW) motor; (1) Glue injection & dowel inserting system, Dowel inserter is set up for 8 mm dia. x 30 - 35 mm long dowels (other dimensions available). -- Operator & Machine Control:12." Color touch screen monitor using Windows XP operating system with graphics & diagnostic. serial interface & USB connection.Menu driven operator interface for function control and graphic illustration of machine functions -- Complete with:Central lubrication system; (1) Vibrating hopper for dowel delivery; (8) Stock clamping cylinders; (1) Removable center stop for up to (2) working zones; "Air tight" pressurized 1:1 glue tank.(was only used with water) (2) Fixed fences (RH & LH side), double sided center fence. -- Actual Model is KOCH SPRINT-PTP-2-L

KOCH - SPRINT 200 Classic: Feed-Through Boring & Dowel Inserter -- SpecificationsSPRINT 200 CLASSIC, Double-end, automatic BGD machine for straight workpieces with: (2) PTP Bore, Glue & Dowel Units & Automatic Belt Feeding. -- Working DimensionsStock length: 10.8" - 98.4" (275 - 2,500 mm); stock width: 2-3/4" - 27-1/2" (70 - 700 mm); stock thickness: 0.59" - 1.18" (15 - 30 mm).NOTE: Specified dimensions do not allow all possible combinations. -- Horizontal Drilling StationsEach side traveling on "precision" linear guides; (1) horizontal drilling unit with: (1) 1.2 HP (0.9 kW) - 7,200 RPM motor. 1.1" (28 mm) Max. drilling depth; total length of drill bits: 2.76" (70 mm). -- Dowel InsertingDowel dia.: 8 mm; dowel length: 30 mm; dowel projection: 7 - 14 mm.(2) Vibrating hoppers with: (1) Outlet tube for feeding of dowels on each side; Dowel size: 8 mm dia., 30 mm in length, and 7 - 14 mm projection. -- Operating ProcessStationary machine side is on the left side (seen in transport direction) and not adjustable.Machine is equipped with: Stock feed belts; belts move the workpiece to the BGD station & clamp it into position for processing.Workpiece is transported out of the machine after processing is complete. The workpiece is transferred to the next machine or taken out manually. -- Complete with: Central lubrication for working units: Air pressure intensifier with 2:1 ratio for constant compressed air supply for glue valves. Hopper Infeed Device. Separate drive for outfeed belt. Tele-diagnostic service compatible. Perimeter Safety Devices. All Docs, Manuals, Tools, Spare Parts associated with this machine. -- Actual Model: KOCH SPRINT 200 CLASSIC

100 HP - 1800 RPM Belt driven. -- Jacketed water-cooled requiring 14 Gpm. -- All stainless wetting surfaces and replaceable stainless tools. -- 24" Inside diameter x 102" inside length. -- 14-1/2" x 18" inlet and 12" x 30" outlet. -- Capacity rating is 6,600 to 26,400 pounds per hour at 6 pound density.

MIDWEST AUTOMATION GS 214 Top and Bottom Glue Spreader53" Cap., top & bottom opposed glue applicator rolls, max. 3" opening, 40" pass-line height, 7-3/4" dia. grooved rubber spreading rolls. -- Rolls fitted with Teflon end seals and water tight bearings, upper elevator opening by single hand wheel on left with dial indicator; dual hand wheel opening glue film thickness adjustment. -- Galvanized collection tank; 54 FPM feed speed, top & bottom direct drive, 1.5 HP direct drive motors. -- Complete with: (2) Protection safety guards at roller in- & outfeed with safety interlocks, complies with UL & CE safety standards.

Newman HP-688 Twin Bay Hydraulic Cold Press6-Sections (top platens) each 24" x 30" each, Center posts between third and fourth platens, creating two overall areas of 30" x 74". Specifications: -- Max. fixed opening 48" with 11" cylinder stroke, each platen section has (1) 10" bore with 5" dia. ram cylinder; -- Each platen is 15/16″ thick and it’s back structure is webbed every 5-1/2″ X 7-1/2″. -- Side-mounted self-contained hydraulic system w/tank, 10 HP continuous operating pressure compensating pump. -- Hand-Valves to Cycle Individual Platens with pressure gauges for each platen. -- Idle Pop-Up Bed Rollers in the bottom platen for easy loading and unloading.Over all the press is in excellent condition, is extremely heavily built, and is also a beautiful impressive press in person.

OGDEN PUR LAMINATING LINE for Engineered FlooringSystem consists of:POS 1. PLYWOOD HOPPER FEEDER Plywood boards (two-track or single-track) are loaded vertically into the hopper and push-fed from the hopper into the Roll Coater where the rolls from the Coater take over feeding the plywood. The plywood hopper feeder is centered to the press; adjustments of the fence are via hand crank where both sides of the fence move simultaneously. The hand crank has a digital indicator to assist the operator in the width setup. Specifications:Length 4 ft to 8 ftWidth with single track 6" to 12"; tolerance of +/- 1/64";Width with double track 3" to 7" tolerance of +/- 1/64";Hopper capacity height 16";Pass line-height 37"; POS 2. DRUM MELTER Drum melter melts the glue which is contained in a 55-gallon drum, it pumps the glue out through heated hoses and delivers the glue to the roll coater. The roll coater sends the drum melter signals when to pump glue and when to run the pump off, a signal is sent according to glue level height. POS 3. TOP HEAD PUR ROLL-COATER Roll coater to apply hot melt PUR glue to the top of the Substrate. Roll coater will be equipped with wheel casters in order to move the unit out of the line for cleaning. Touch Screen Control panel for the coater is mounted on the left-hand side when facing the in-feed of the unit. Adjustment of doctor roller will be with hand wheel (not powered) and mechanical digital display in increments of 0.001" in relationship to application roller. Adjustment of the coating roller will be powered and will include a hand wheel with a mechanical digital display in increments of 0.001" Roll coater is equipped with a fume extraction hood which is located above the roll coater. Feed speed 20 - 250 FPMMin coater length 21"Maximum thickness 4"Minimum thickness 3/8"Effective coating width 14"Doctor roller ground chromeCoating roller silicone, 60 durometerVoltage 480 VPass line height 37"; POS 4. PLYWOOD TRANSFER CONVEYOR Conveyor length 20’Veneer lengths 2’ to 12’ ’Width with single track 7" to 12"; tolerance of +/- 1/64";Width with double track 3" to 7" tolerance of +/- 1/64";Pass line-height 37";Feed speed range from 20 to 250 FPMPop up gate will be installed to st

OMAL HBD 2500 CNC BORE, GLUE & DOWEL INSERTER: Specifications: -- NC Controlled, automatic step-by-step boring, glue injection & dowel insertion into panel components: Drawer parts, chair pieces, etc. at random spacing or automatic hole-spacing with simple what-if statement: i.e. parametric programming.Working Capacity: -- 2,500 mm (98.4") In the X-axis; 30 mm (1-1/4") stroke in the Y-axis; 10 mm - 40 mm (0.39" - 1.57") thickness capacity in the Z-axis. (4) Working zones: Center fence and both side fences dropdown for 2- or large 1-zone operation.Tool Plate Configuration: -- X-Axis rack & pinion drive CNC Controlled; carriage speed of 90 MPM (295 FPM); Y- & Z-axis: Manual ball screw with digital indicators.Equipped with: -- (1) Horizontal drilling unit with: 3/4 HP - 6,000 RPM Motor; (1) gluing & (1) dowel insertion unit.Control System: -- PC Numerical Control operating system; Windows/XP, color video flat screen monitor; 40 GB hard drive; keyboard & mouse. -- Graphic operator inter-phase, parametric programming standard; OMAL patented "SURE SHOT" Revolver System with fiber optic sensor to guaranty reliable dowel presence & insertion.Complete with: -- (1) 18-Liter (4-3/4 Gallon) cap.; high pressure glue tank. -- (1) 18-Liter (4-3/4 Gallon) cap.; water tank (for cleaning). -- (1) Vibratory Dowel Hopper, (6) pneumatic hold-down clamps; machine is setup for 8 mm dowels.

OMAL - INSERT 1300 / Lock-Dowel HBD 1300: CNC Bore, Glue, and Dowel Inserter with: Lock-Dowel"; Processing + Laser Measuring System -- SpecificationsPLC Controlled automatically step-by-step: Boring, glue injection & dowel insertion into panel: Components, drawer parts, chair pieces, etc., at random spacing. -- Working Capacity1,300 mm (51.18") In the "X" axis work area; 40 mm (1.57") "Y" axis stroke with: Manual depth setting; 40 mm (1.57") "Z" axis stroke with: Manual vertical settings.10 mm to 30 mm (0.39" - 1.18") Material thickness capacity in the "Z" axis. -- Positioning Speed: Carriage travel speed: 164 FPM (50 MPM).Equipped with: Brushless motor; ball nut & ball screw for quick positioning. -- Work Areas15-1/2" x 50" x 33-1/2" H Table; (2) 23-1/2" Loading zones with: Cycle time of (1) second for each bore, glue, & dowel insertion when holes are on: 32 mm Intervals. -- Dowel Inserter(1) Dowel Vibrating Hopper feeding System with: (1) OMAL "SURE SHOT" Revolver system guarantees a dowel is inserted every time. 2-Spindle Drill Head on: 32 mm centers & (1) Dowel inserting unit with: 8 mm Diameter dowel capacity.Standard dowel dimension: 8 mm x 35 mm; Max. dowel length: 40 mm; max. dowel projection: 14 mm. -- Lock-Dowel Processing(1) "Lock-Dowel" Vibrating Hopper feeding system + (1) Manual “Lock-Dowel"; loading system; (2) Automatic “Lock-Dowel"; hopper feeders; (1) Automatic “Lock-Dowel"; inserting system. -- Laser SystemLaser automatically measures the part, populates the program list of parts width, and calculates all the inserting location for the part being processed. -- Operator & Machine Control17" Touchscreen Control for: Writing & storing programs and is programmable in the "X" axis.Graphics programming 2.5D with: Simultaneous working display; automatic mirror-Image (left & right) programming; parametric programming; gGraphical aids.Internal self-diagnosis; historical report of alarms -- Complete with:CNC Controlled retractable side & center stop fences for various part sizes; (1) 2-gal (8-Liter) cap. high pressure glue tank; (1) 2-gal. (8-liter) cap. water tank (for cleaning); (4) large 2-3/4" x 5-1/2" pneumatic holddown clamps; dual foot pedal controls. -- Options include: Handheld, Bar Code scanner/reader. Set up for (4) Working Zones, which can be excluded for larger panels. OMAL "Sure Shot" Revolver System (eliminates misfeeds). Laser measuring system..Actual Model: OMAL - INSERT 1300 / LOCK-DOWEL HBD 1300 OF

OMAL VELOX 1300 CNC BORE, GLUE & DOWEL INSERTER + Optional LASER MEASURING DEVICE SpecificationsPLC Controlled automatic step-by-step boring, glue injection, & dowel insertion into panel components, drawer parts, chair pieces, etc. at random spacing. Features"Optional" Auto Laser measuring device with: Parametric Control and Touchscreen PLC Control. Working Capacity51" (1,300 mm) In "X" Axis work area; 1.57" "Y" Axis stroke with manual depth setting; 1.57" "Z" Axis stroke with manual vertical settings. -- 10 mm to 30 mm (0.39" - 1.18") Material thickness capacity in the "Z" axis. -- Machine is currently set up for 8 mm dia. x 30 mm long max. dowel dimension.Work Areas(2) Loading zones with: Cycle time of (1) second for each bore, glue and dowel insertion when holes are on 32 mm intervals. -- Equipped with: Brushless motor; ball nut and ball screw for quick positioning.Dowel InserterOMAL "SURE SHOT" Revolver system guarantees a dowel is inserted every time. (1) Dowel insertion unit with: 8 mm Diameter dowel capacity -- Standard dowel dimension: 8 mm x 35 mm; Maximum dowel length: 40 mm; Maximum dowel projection: 14 mm.Operator InterfaceTouchscreen Control for writing and storing programs & is programmable in the "X" Axis. -- Graphics programming 2.5D with: Simultaneous working display; Automatic Mirror Image (left & right) programming; Parametric programming; Graphical aid.Internal self-diagnosis; Historical report of alarms, Complete with:(2) Working zones, (1) horizontal drilling unit, (1) gluing, (1) dowel insertion unit.(1) 8-Liter cap. high pressure Glue Tank, (1) 8-liter cap. Water Tank (for cleaning), (1) Vibratory Dowel Hopper, (4) pneumatic Hold-down Clamps, Dual foot Pedal controls. -- Actual Model is: OMAL VELOX 1300

OMAL - HBD 1300 OF, ...CNC Bore, Glue, and Dowel Inserter -- Specifications:PLC Controlled automatic step-by-step, boring, glue injection & dowel insertion into panel components, drawer parts, chair pieces, etc., at random spacing. -- Positioning Speed: Carriage travel speed is 164 FPM (50 MPM).Equipped with: Brushless motor, ball nut, and ball screw for quick positioning. -- Working Capacity:1,300 mm (51.18") In the X-Axis work area; 1.57" Y-Axis stroke with manual depth setting; 1.57" Z-Axis stroke with manual vertical settings.10 mm to 30 mm (0.39" - 1.18") Material thickness capacity in the Z-Axis. -- Work Areas:15-1/2" x 50" x 33-1/2" H Table; (2) 23-1/2" loading zones with a cycle time of (1) Sec for each bore, glue, and dowel insertion when holes are on 32 mm intervals. -- OMAL "SURE SHOT" Revolver System guarantees a dowel is inserted every time. 2-Spindle Drill Head and (1) Dowel Insertion unit with 8 mm diameter dowel capacity.Standard dowel dimension is: 8 mm x 35 mm; max. dowel length: 40 mm; max. dowel projection is 14 mm. -- Operator & Machine Control:17" Touchscreen Control for writing and storing programs & is programmable in the X-Axis.2.5D Graphics programming with: Simultaneous working display; automatic Mirror Image (left & right) programming; parametric programming; graphical aids.Internal self-diagnosis; historical report of alarms. -- Complete with:(1) Electronic Control programmable gluing unit; (1) dowel insertion unit; (1) 2-gal (8-Liter) cap. high pressure glue tank, (1) 2-gal. (8-liter) cap. water tank (for cleaning); (1) 14-1/2" dia. vibratory Dowel Hopper; (4) 2-3/4" x 5-1/2" pneumatic hol-down clamps; dual foot pedal controls. -- Options Include: OMAL "Sure Shot" revolver system (eliminates miss-feeds). -- Actual Model is: OMAL HBD 1300 OF.

OMAL INSERT 900 CNC BORE, GLUE & DOWEL INSERTERSpecifications: -- Capacities: X-Axis 900 mm (35.44"); Y-Axis 40 mm (1.57") stroke; Z-Axis 10 - 40 mm (0.39" - 1.57") thickness. -- Table size; 15-5/8"; x 49"; x 35"; H; (4) working zones: (2) 450 mm (17.72") W. -- Max. dowel size: 8 mm Dia. x 30 mm L (0.31" dia. x 1.18" L). -- Max. dowel projection: 15 mm (0.59"). -- Spindle speed: 6,000 RPM. -- Cycle time: 0.8 Sec.Equipped with: -- (4) 2-1/4" Dia. pneumatic hold-downs. -- (1) Horizontal drilling unit with: 3/4 HP - 3,380 RPM TEFC Motor; (1) glue injection unit & (1) dowel insertion unit. -- PC-Based controller with: 12" Display; (2) foot pedal controls.Complete with: -- BROVIND VIBRATORI "OB 300 DC": 14" Dia. x 5-1/2"; D vibratory Bowl Feeder with: "NC-02M-50 DC" Variable Speed Controller. -- (1) 8 L Cap. High Pressure Glue Tank; (1) 8 L Cap. Water Tank.

OMAL VELOX 1300 CNC BORE, GLUE & DOWEL INSERTER + Optional LASER MEASURING DEVICE SpecificationsPLC Controlled automatic step-by-step boring, glue injection, & dowel insertion into panel components, drawer parts, chair pieces, etc. at random spacing. Features"Optional" Auto Laser measuring device with: Parametric Control and Touchscreen PLC Control. Working Capacity51" (1,300 mm) In "X" Axis work area; 1.57" "Y" Axis stroke with manual depth setting; 1.57" "Z" Axis stroke with manual vertical settings. -- 10 mm to 30 mm (0.39" - 1.18") Material thickness capacity in the "Z" axis. -- Machine is currently set up for 8 mm dia. x 30 mm long max. dowel dimension.Work Areas(2) Loading zones with: Cycle time of (1) second for each bore, glue and dowel insertion when holes are on 32 mm intervals. -- Equipped with: Brushless motor; ball nut and ball screw for quick positioning.Dowel InserterOMAL "SURE SHOT" Revolver system guarantees a dowel is inserted every time. (1) Dowel insertion unit with: 8 mm Diameter dowel capacity -- Standard dowel dimension: 8 mm x 35 mm; Maximum dowel length: 40 mm; Maximum dowel projection: 14 mm.Operator InterfaceTouchscreen Control for writing and storing programs & is programmable in the "X" Axis. -- Graphics programming 2.5D with: Simultaneous working display; Automatic Mirror Image (left & right) programming; Parametric programming; Graphical aid.Internal self-diagnosis; Historical report of alarms, Complete with:(2) Working zones, (1) horizontal drilling unit, (1) gluing, (1) dowel insertion unit.(1) 8-Liter cap. high pressure Glue Tank, (1) 8-liter cap. Water Tank (for cleaning), (1) Vibratory Dowel Hopper, (4) pneumatic Holddown Clamps, Dual foot Pedal controls. -- Actual Model is: OMAL VELOX 1300

OSAMA SP/RSI-1600 1600 mm (63") Top & Bottom Brush Panel CleanerSpecifications: -- Min. panel length 430 mm (16.93"), Panel thickness 0 - 100 mm (3.94"). -- Feed speed 22 MPM (72 FPM).Equipped with: -- 290 mm (11.42") Dia. Top & bottom brush rolls, with 0.6 mm (0.02") Dia. Black nylon bristles.Available at additional cost: -- Spare pair of brushes.NOTE: This machine is also being offered for sale as a part of a Feed Through White Glue Laminating Line (EXF #LA-011187).

OSAMA S2R-1600 1600 mm (63") Top & Bottom Glue SpreaderSpecifications: -- Panel thickness 0 - 100 mm (3.94"). -- Pass line height 800 mm (31.50"). -- Feed speed 18 MPM (59 FPM).Equipped with: -- 185 mm (7.28") Dia. x 64" L Grooved anti-acid rubber-covered top & bottom applicator rolls, each with Manual brush washer, Side glue wipers. -- 21-3/4"; x 72"; x 2-3/4"; D Removable stainless steel bottom pan. -- Front & rear safety fences.NOTE: This machine is also being offered for sale as a part of a Feed Through White Glue Laminating Line (EXF #LA-011187).

Complete OSAMA Feed Through White Glue Laminating Line, with MIDWEST AUTOMATION Laminate Indexing/Lay-up Table & HMT Laminator Specifications: Line was designed to use the HMT Laminator as a pinch roller with heaters for large quantity runs. The HMT Laminator was used as a stand-alone machine for small quantity runs. Max. panel size 60" x 120" (Based on current outfeed scissor lift platform size. With a 60" x 144" or larger scissor lift, 144" L panels could be run.) Consisting of the following machines as late as 2016: AREDON 48" x 96" Electric/Hydraulic Scissor Lift Platform. 2007 OSAMA SP/RSI-1600 1600 mm (63") Top & Bottom Brush Panel Cleaner, S/N 8103, Min. panel length 430 mm (16.93"), Panel thickness 0 - 100 mm (3.94"), Feed speed 22 MPM (72 FPM), with 290 mm (11.42") Dia. Top & bottom brush rolls with 0.6 mm (0.02") Dia. Black nylon bristles, Spare pair of brushes, 460 V, 60 Cy, 3 Ph., Dimensions 108" X 36" X 70" H, Weight 1,100 Lbs. 2006 OSAMA S2R-1600 1600 mm (63") Top & Bottom Glue Spreader, S/N 20944, Panel thickness 0 - 100 mm (3.94"), Pass line height 800 mm (31.50"), Feed speed 18 MPM (59 FPM), with 185 mm (7.28") Dia. x 64" L Grooved anti-acid rubber-covered top & bottom applicator rolls, each with Manual brush washer, Side glue wipers, Removeable bottom pan, Front & rear safety fences, 230 V, 60 Cy, 3 Ph., Dimensions 90" x 30" x 60" H, Weight 1,500 Lbs. MIDWEST AUTOMATION LT 500 60” x 144” Laminate Indexing/Lay-up Table. 2016 HMT ADVANTAGE PLUS 61" Laminator, S/N 5A391, with 10.5 kW Heatbank, 208 V, 60 Cy, 1 Ph., Dimensions 120" x 83" x 55" H, Weight 1,400 Lbs., NOTE: This machine is also being offered for sale separately (EXF #LA-011186). SOUTHWORTH 5,000 Lb. Capacity 60” x 120” Electric/Hydraulic Scissor Lift Platform, with Gravity roller conveyor top. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

PILLAR MACHINE HPLD 96" CNC BORE & LOCK-DOWEL INSERTER: -- Specifications:(4) Working zones of 24" each and "OPTIONAL" working table length of 96"; CNC controlled head assembly with rapid (side-to-side) traverse.Head assembly with: (1) Horizontal boring & insertion unit with a 3 HP - 18,000 RPM Direct-Drive Spindle motor; "X" Axis is servo controlled for positioning; Digital Mechanical Readouts For Height and DepthHead is currently set up to bore/machine/insert 20 mm Lock-Dowel "Eclips", H-clips, Channel Locks & 8 mm Spring Pin Fasteners.Material thickness capacity 0.5" - 1" max. Material thickness with digital readout for height adjustment. -- Clamping System:(8) Pneumatic, quick side-to-side adjustable hold-down clamps for horizontal "Lock-Dowel" processing on the panel edge.(1) Pneumatic Clamping Bar for vertical boring into the panel face/back. -- Operator Interface:15" Color Touchscreen control + Windows 10 Operating System. Ethernet 1 x PCIE Broadcom GbE (or similar), USB: 2 x USB 2.0 (or similar), Serial Port: 1 x RS-232 (or similar)The on-screen graphics of the operator interface have been designed to allow for quick programming at the machine. Typically, programs can be written and recalled in less than one minute.The Interface is open architecture allowing it to integrate with design software that can give hole locations in the form of a .xml file or a bar code (with bar code reader purchase found in options).Standard Features in the software include: 1. Graphic interface to show where holes are to be drilled and if a dowel is to be inserted. 2. Pattern Drilling/Inserting.3. Password protection of certain features/functions. 4. Online diagnostic capability (if machine is connected to an internet connection). 5. Toggle between Metric or Imperial programing parameters. -- Features: This machine will insert H-clips, Channel Locks and Spring Pins with ease. Using CNC control, this machine positions the drilling spindle to bore holes and insert the Lockdowel hardware. -- Complete with:Anti slip table surface, rack & pinion drive, and centralized dust collection manifold. -- Actual model is: PILLAR MACHINE HPLD

Perforated plate type glue applicator with 8" wide x 36" long applicating grid. --When the foot treadle is released the grid is submersed into a reservoir of glue and when depressed raises the grid and part up for the excess glue to drain back into the reservoir. -- Stock to be glued is placed on the grid wich leaves a mesh pattern of glue on the bottom edge of the stock. -- Standard features include Stainless Steel applicating grid, an easy slide out Stainless Steel glue pan and glue pan cover.

QUICK MACHINERY N-P80 Air Pod style Cold Press. -- Heavy Duty I-beam construction with machined steel plates for flat smooth pressing surface.Specifications: -- Platen pressing area size: 62" x 146" with end loading on 62" side. -- 80 PSI Platen pressure over the entire surface area with 105 PSI supply air pressure. Pressure is applied by (60) 12.8" dia. air pods with 5.9" stroke; -- Air powered raise and lower idler rollers in the bed of the press for loading & unloading panels; raising & lowering of conveyor by control button on panel. -- Motorized Adjustable Daylight Opening from 2" to 40"; push button controls operate an electrically powered chain driven worm gear drive system for precise positioning of upper platen setting/opening. -- Controls: 60-Min cycle timers provide visual and audible signals at the end of each cycle and automatically releases platen air pressure at the end of each cycle if desired. -- Single platen 62" X 146". (2) Air pressure zones for upper platen: (4' x 8' and 5' x 12') -- Optional powered roller tracks for an additional fee. -- The press model shown in pictures is a dual platen powered feed through end load press. -- Actual model is N-P80-05-12-EL-1PL-M-40-2Z

QUICK MACHINERY N-P50 Air Pod style Cold Press. -- Heavy Duty I-beam construction with machined steel plates for flat smooth pressing surface.Specifications: -- Platen pressing area size: 62" x 146" with side loading on 146" side (also available as end loading). -- 50 PSI Platen pressure over the entire surface area with 90 PSI supply air pressure. Pressure is applied by 12.8" dia. air pods with 5.9" stroke; (36) air pods total for this size press. -- (2) Pressure air pressure zones: 5' x 12' and 4' x 8'. -- Air powered raise and lower idler rollers in the bed of the press for loading & unloading panels; raising & lowering of idle conveyor roller tracks by control button on panel. -- Motorized Adjustable Daylight Opening from 2" to 40"; push button controls operate an electrically powered chain driven worm gear drive system for precise positioning of upper platen setting/opening. -- Controls: 60-Min cycle timers provide visual and audible signals at the end of each cycle and automatically releases platen air pressure at the end of each cycle if desired.
